www.beko.com.tr
www.beko.co.nz
RCNE450K40ZW
RCNE450K40ZX
BBM450W
BBM450X
BBM450W1
BBM450AN
EN
Please read ths gude frst!
Dear Customer,
We'd like you to achieve the optimal efficiency from our product, which has been
manufactured in modern facilities with meticulous quality controls.
For this purpose, please fully read the user guide before using the product and keep
the guide as a reference source. If you turn the product over to another person,
provide this guide along with the product.
User gude ensure the quck and safe use of the product.
• Please read the user gude before nstallng and operatng the product.
• Always observe the applcable safety nstructons.
• Keep the user gude wthn easy reach for future use.
• Please read any other documents provded wth the product.
Keep in mind that this user guide may apply to several product models. The guide
clearly indicates any variations of different models.
Symbols and Remarks
The followng symbols are used n the user gude:
C
Important nformaton and
useful tps.
A
Rsk of lfe and property.
B
Rsk of electrc shock.
The product’s packagng
s made of recyclable ma-
terals, n accordance wth
the Natonal Envronment
Legslaton.
2 /30 EN
Refrgerator / User Gude
1. Safety and environment
instructions 3
1.1. General safety . . . . . . . . . . . . . . . . . . . 3
1.1.1 HC warning . . . . . . . . . . . . . . . . . . . . . . 5
1.1.2 For models with water dispenser 5
1.2. Intended use. . . . . . . . . . . . . . . . . . . . . 5
1.3. Child safety . . . . . . . . . . . . . . . . . . . . . . 5
1.4. Compliance with WEEE Directive and
Disposing of the Waste Product. 6
1.5. Compliance with RoHS Directive 6
1.6. Package information . . . . . . . . . . . . 6
2 Your Refrigerator 7
3 Installation 8
3.1. Reversing the doors . . . . . . . . . . . .10
3.2. Reversing the doors . . . . . . . . . . . . 11
4 Preparation 12
4.1. What to do for energy saving. . . 12
4.2. First Use . . . . . . . . . . . . . . . . . . . . . . . . 12
5 Using the product 13
5.1. Indicator panel. . . . . . . . . . . . . . . . . . 13
5.2. Temperature adjustment button 15
5.3. Rapid freezing . . . . . . . . . . . . . . . . . . 15
5.4. Vacation function . . . . . . . . . . . . . .16
5.5. Indicator panel. . . . . . . . . . . . . . . . . . 17
5.6. Ice bucket . . . . . . . . . . . . . . . . . . . . . . .20
5.7. Eggholder. . . . . . . . . . . . . . . . . . . . . . .20
5.8. Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
5.9. Vegetable bin . . . . . . . . . . . . . . . . . .20
5.10.Zero degree compartment. . . . .20
5.11. Moving door rack . . . . . . . . . . . . . . . 21
5.12.Sliding storage box . . . . . . . . . . . . . 21
5.13. Moisture controlled vegetable bin 22
5.14.Automatic ice machine . . . . . . . .22
5.15.Icematic and ice storage
container . . . . . . . . . . . . . . . . . . . . . . .23
5.16.Freezing fresh food . . . . . . . . . . . .23
5.17. Recommendations for storing frozen
foods. . . . . . . . . . . . . . . . . . . . . . . . . . . .24
5.18.Deep freezer details. . . . . . . . . . . .24
5.19.Placing the food . . . . . . . . . . . . . . . .24
5.20.Door open alert . . . . . . . . . . . . . . . .25
5.21.Changing the opening direction of
the door. . . . . . . . . . . . . . . . . . . . . . . . .25
5.22.Interior light . . . . . . . . . . . . . . . . . . . .25
6 Maintenance and cleaning 26
6.1. Avoiding bad odors . . . . . . . . . . . . .26
6.2. Protecting the plastic surfaces 26
6.3. Door Glasses . . . . . . . . . . . . . . . . . . .26
6 Maintenance and cleaning 27
7. Troubleshooting 28
Table of Contents
3/30 EN
Refrgerator / User Gude
Ths secton provdes the safety
nstructons necessary to prevent
the rsk of njury and materal
damage. Falure to observe these
nstructons wll nvaldate all
types of product warranty.
Intended use
A
WARNING:
Keep ventlaton
openngs, n the applance
enclosure or n the bult-
nstructure, clear of
obstructon.
A
WARNING:
Do not use mechancal
devces or other means
to accelerate the
defrostng process,
other than those
recommended by the
manufacturer.
A
WARNING:
Do not damage the
refrgerant crcut.
A
WARNING:
Do not use electrcal
applances nsde
the food storage
compartments of
the applance, unless
they are of the type
recommended by the
manufacturer.
Ths applance s ntended to be
used n household and smlar
applcatons such as
– staff ktchen areas n shops,
offces and other workng
envronments;
– farm houses and by clents
n hotels, motels and other
resdental type envronments;
– bed and breakfast type
envronments;
– caterng and smlar non-retal
applcatons.
1.1. General safety
• Ths product should not be
used by persons wth physcal,
sensory and mental dsabltes,
wthout suffcent knowledge
and experence or by chldren.
The devce can only be used by
such persons under supervson
and nstructon of a person
responsble for ther safety.
Chldren should not be allowed
to play wth ths devce.
• In case of malfuncton, unplug
the devce.
• After unpluggng, wat at least
5 mnutes before pluggng n
agan.
• Unplug the product when not
n use.
• Do not touch the plug wth wet
hands! Do not pull the cable to
plug off, always hold the plug.
• Do not plug n the refrgerator f
the socket s loose.
• Unplug the product durng
nstallaton, mantenance,
cleanng and repar.
• If the product wll not be used
for a whle, unplug the product
and remove any food nsde.
• Do not use the product when
the compartment wth crcut
cards located on the upper back
part of the product (electrcal
card box cover) (1) s open.
1. Safety and envronment nstructons
Safety and envronment nstructons
4 /30 EN
Refrgerator / User Gude
1
1
• Do not use steam or steamed
cleanng materals for
cleanng the refrgerator and
meltng the ce nsde. Steam
may contact the electrfed
areas and cause short crcut
or electrc shock!
• Do not wash the product by
sprayng or pourng water on
t! Danger of electrc shock!
• In case of malfuncton, do
not use the product, as t may
cause electrc shock. Contact
the authorsed servce before
dong anythng.
• Plug the product nto an
earthed socket. Earthng
must be done by a qualfed
electrcan.
• If the product has LED
type lghtng, contact the
authorsed servce for
replacng or n case of any
problem.
• Do not touch frozen food wth
wet hands! It may adhere to
your hands!
• Do not place lquds n bottles
and cans nto the freezer
compartment. They may
explode.
• Place lquds n uprght
poston after tghtly closng
the ld.
• Do not spray flammable
substances near the product,
as t may burn or explode.
• Do not keep flammable
materals and products wth
flammable gas (sprays, etc.)
n the refrgerator.
• Do not place contaners
holdng lquds on top of the
product. Splashng water on
an electrfed part may cause
electrc shock and rsk of fre.
• Exposng the product to ran,
snow, sunlght and wnd
wll cause electrcal danger.
When relocatng the product,
do not pull by holdng the
door handle. The handle may
come off.
• Take care to avod trappng
any part of your hands or
body n any of the movng
parts nsde the product.
• Do not step or lean on the
door, drawers and smlar
parts of the refrgerator. Ths
wll cause the product to fall
down and cause damage to
the parts.
• Take care not to trap the
power cable.
Safety and envronment nstructons
5/30EN
Refrgerator / User Gude
1.1.1 HC warning
If the product comprses a
coolng system usng R600a
gas, take care to avod
damagng the coolng system
and ts ppe whle usng and
movng the product. Ths gas
s flammable. If the coolng
system s damaged, keep the
product away from sources
of fre and ventlate the room
mmedately.
C
The label on the nner left
sde ndcates the type of
gas used n the product.
1.1.2 For models with
water dispenser
• Pressure for cold water
nlet shall be maxmum 90
ps (620 kPa). If your water
pressure exceeds 80 ps
(550 kPa), use a pressure
lmtng valve n your mans
system. If you do not know
how to check your water
pressure, ask for the help of
a professonal plumber.
• If there s rsk of water
hammer effect n your
nstallaton, always
use a water hammer
preventon equpment n
your nstallaton. Consult
Professonal plumbers f you
are not sure that there s no
water hammer effect n your
nstallaton.
• Do not nstall on the hot
water nlet. Take precautons
aganst of the rsk of
freezng of the hoses. Water
temperature operatng
nterval shall be 33°F (0.6°C)
mnmum and 100°F (38°C)
maxmum.
• Use drnkng water only.
1.2. Intended use
• Ths product s desgned for
home use. It s not ntended
for commercal use.
• The product should be used
to store food and beverages
only.
• Do not keep senstve
products requrng controlled
temperatures (vaccnes,
heat senstve medcaton,
medcal supples, etc.) n the
refrgerator.
• The manufacturer assumes
no responsblty for any
damage due to msuse or
mshandlng.
• Orgnal spare parts wll
be provded for 10 years,
followng the product
purchasng date.
1.3. Child safety
• Keep packagng materals
out of chldren’s reach.
• Do not allow the chldren to
play wth the product.
• If the product’s door
comprses a lock, keep the
key out of chldren’s reach.
Safety and envronment nstructons
6 /30 EN
Refrgerator / User Gude
1.4. Compliance
with WEEE Directive
and Disposing of
the Waste Product
Ths product comples wth
EU WEEE Drectve (2012/19/EU).
Ths product bears a classfcaton
symbol for waste electrcal and
electronc equpment (WEEE).
Ths product has been
manufactured wth hgh
qualty parts and materals
whch can be reused and
are sutable for recyclng.
Do not dspose of the
waste product wth normal
domestc and other wastes at the end
of ts servce lfe. Take t to the
collecton center for the recyclng of
electrcal and electronc equpment.
Please consult your local authortes
to learn about these collecton
centers.
1.5. Compliance with
RoHS Directive
• Ths product comples wth EU
WEEE Drectve (2011/65/EU).
It does not contan harmful and
prohbted materals specfed n
the Drectve.
1.6. Package
information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packaging
materials together with the domestic
or other wastes. Take them to the
packaging material collection points
designated by the local authorities.
7/30 EN
Refrgerator / User Gude
1.
Cooler compartment door shelf
2.
Egg secton
3.
Bottle shelf
4. Sldng storage box
5.
Adjustable legs
6.
Deep freezer compartment
7.
Quck freeze compartment
8.
Ice cube tray & Ice bank
9.
Vegetable bn
10.
Interor lght
11.
Cooler compartment glass shelf
12.
Temperature adjustment button
13.
Cooler compartment
14.
Freezer compartment
2 Your Refrgerator
C
*optional: Pctures gven n ths manual are gven as example fgures and they
may not be exactly the same as your product. If your product does not comprse
the relevant parts, the nformaton pertans to other models.
*1
*3
*3
2
*6
*7
5
5
*9
10
*12
13
14
*11
*8
*4
8 /30 EN
Refrgerator / User Gude
3 Installaton
3.1 Approprate
nstallaton locaton
Contact an Authorized Service for the
installation of the product. In order to
prepare the product for use, refer the
information in the user manual and
ensure that electrical installation and
water installation are appropriate. If not,
call a qualified electrician and technician
to have any necessary arrangements
carried out.
B
WARNING:Manufacturer
shall not be held lable for
damages that may arse
from procedures carred
out by unauthorzed
persons.
B
WARNING:Product must
not be plugged n durng
nstallaton. Otherwse,
there s the rsk of death or
serous njury!
B
WARNING:If the door
clearance of the room
where the product shall be
place s so tght to prevent
passng of the product,
remove the door of the
room and pass the product
through the door by
turnng t to ts sde; f ths
does not work, contact the
authorzed servce.
•Placetheproductonanevenfloor
surface to prevent jolts.
•Installtheproductatleast30cm
away from heat sources such as hobs,
heater cores and stoves and at least 5
cm away from electrcal ovens.
•Productmustnotbesubjectedto
drect sun lght and kept n humd
places.
•Appropriateairventilationmustbe
provded around your product n order
to acheve an effcent operaton. If the
product s to be placed n a recess n
the wall, pay attenton to leave at least
5 cm dstance wth the celng and sde
walls.
•Donotinstalltheproductinplaces
where the temperature falls below
-5°C.
3.2 Installng the
plastc wedges
Plastc wedges suppled wth the
product are used to create the dstance
for the ar crculaton between the
product and the rear wall.
1.To nstall the wedges, remove the
screws on the product and use the
screws suppled together wth the
wedges.
2.Insert the 2 plastc wedges onto the
rear ventlaton cover as llustrated n
the fgure.
Installation
9/30 EN
Refrgerator / User Gude
3.3 Adjustng the feet
If the product stands unbalanced
after nstallaton, adjust the feet on
the front by rotatng them to the rght
or left.
C
Hot Surface Warning!
Side walls of your product is
equipped with refrigerant
pipes to improve the cooling
system. Refrigerant with
high temperatures may
flow through these areas,
resulting in hot surfaces
on the side walls. This is
normal and does not need
any servicing. Please pay
attention while touching
these areas.
3.4 Electrcal
connecton
A
WARNING:Do not make
connectons va extenson
cables or mult-plugs.
B
WARNING:Damaged power
cable must be replaced by the
Authorzed Servce Agent.
C
If two coolers are to be
nstalled sde by sde, there
should be at least 4 cm
dstance between them.
• Our company shall not be liable for
any damages that will arise when the
product is used without grounding and
electrical connection in accordance with
the national regulations.
• Power cable plug must be within easy
reach after installation.
• Do not extension cords or cordless
multiple outlets between your product
and the wall outlet.
Installation
10 /30 EN
Refrgerator / User Gude
3.1. Reversing the doors
Proceed in numerical order .
45
11
10
3
9
9
2
1
5
6
7
8
12
13
14
15
17
18
19
16
21
4
20
20
Installation
11/30 EN
Refrgerator / User Gude
3.2. Reversing the doors
Proceed in numerical order .
1
1
7
1
20
11
13
9
2
10
5
3
20
20
8
18
17
19
45 °
180°
(8) (13)
14
6
4
12
16
15
12 /30 EN
Refrgerator / User Gude
4.1. What to do for
energy saving
A
Connectng the product to
electronc energy-savng systems
s harmful, as t may damage the
product.
• Do not keep the refrgerator doors
open for long perods.
• Do not place hot food or beverages
nto the refrgerator.
• Do not overfll the refrgerator;
blockng the nternal ar flow wll
reduce coolng capacty.
• In order to store the maxmum
amount of food nto the cooler
compartment of your refrgerator, you
should take out the upper drawers
and place t onto the glass rack. The
declared energy consumpton of your
refrgerator was determned by takng
out the cooler, ce tray and upper
drawers n a way that wll enable
maxmum storage. Usng the below
drawer when storng s strongly
recommended. Energy savng
functon should be actvated for best
energy consumpton.
• You should not block the arflow by
puttng food n front of the cooler
fan. A space of mnmum 3cm must be
left n front of the protectve fan wre
when placng food.
• Dependng on the product’s features;
defrostng frozen foods n the cooler
compartment wll ensure energy
savng and preserve food qualty.
• Food should be stored usng the
drawers n the cooler compartment
n order to ensure energy savng and
protect food n better condtons.
• Food packages should not be n drect
contact wth the heat sensor located
n the cooler compartment. If they are
n contact wth the sensor, energy
consumpton of the applance mght
ncrease.
• Make sure the foods are not n
contact wth the cooler compartment
temperature sensor descrbed below.
4 Preparaton
4.2. First Use
Before usng your refrgerator, make sure
the necessary preparatons are made
n lne wth the nstructons n “Safety
and envronment nstructons” and
“Installaton” sectons.
• Keep the product runnng wth no
food nsde for 6 and do not open the
door, unless absolutely necessary.
C
A sound wll be heard when the
compressor s engaged. It s
normal to hear sound even when
the compressor s nactve, due to
the compressed lquds and gasses
n the coolng system.
C
Front edges of the product mght
heat up. Ths s normal. These
areas are desgned to warm up n
order to prevent condensaton.
C
In some models ndcator panel
turns off automatcally 5 mnutes
after the door closes. It wll be
reactvated when the door s open
or any button s pressed.
13/30 EN
Refrgerator / User Gude
5.1. Indicator panel
Indcator panels may vary accordng to the product model.
Audo – vsual functons on the ndcator panel helps you n usng your product.
C
*optional: Pctures gven n ths manual are gven as example fgures and they
may not be exactly the same as your product. If your product does not comprse
the relevant parts, the nformaton pertans to other models.
5 Usingtheproduct
45
7
6
8
9
1
2
3
1. Frdge Compartment
Indcator
2. Error status ndcator
3. Temperature ndcator
4. Vacaton functon button
5. Temperature settng button
6. Compartment selecton
button
7. Freezer compartment
ndcator
8. Economy mode ndcator
9. Vacaton functon ndcator
*optonal
Using the product
14 /30EN
Refrgerator / User Gude
1. Frdge compartment ndcator
Fridge compartment light is
illuminated while the fridge
compartment temperature is set.
2. Error status ndcator
If your refrigerator does not perform
enough cooling or in case of a sensor
fault, this indicator is activated.
When this indicator is activated,
“E” is displayed on the freezer
compartment temperature indicator,
and numbers such as “1,2,3...” are
displayed on the fridge compartment
temperature indicator. These
numbers on the indicator inform
service personnel about the error.
3. Temperature ndcator
Indicates freezer, fridge compartment
temperature.
4. Vacaton functon button
Press on Vacation Button for 3
seconds to activate this function.
When the vacation function is
activated, “- -” is displayed on the
fridge compartment temperature
indicator and no active cooling
is performed on the fridge
compartment. It is not suitable
to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press Vacation
button again.
5. Temperature settng button
Changes the temperature of the
relevant compartment between
-24°C... -18°C and 8°C...1°C.
6. Compartment selecton button
Selection button: Press compartment
selection button to switch between
fridge and freezer compartments.
7. Freezer compartment ndcator
Fridge compartment light is
illuminated while the freezer
compartment temperature is set.
8. Economy mode ndcator
Indicates that the refrigerator
operates in energy saving mode.
This display shall be activated if the
freezer compartment temperature is
set to -18°C.
9. Vacaton functon ndcator
Indicates that vacation is activated.
Using the product
15/30EN
Refrgerator / User Gude
5.2. Temperature
adjustment button
Internal temperature of your refrgerator
vares dependng on the followng reasons:
• Seasonal temperatures,
• Openng the door frequently and
leavng t open for long perods,
• Meals put nto the refrgerator
wthout beng cooled to room
temperature, Locaton of the
refrgerator n the room (e.g.
exposed to sunshne).
• Internal temperature varyng due to
these factors can be adjusted va the
adjustment button.
Numbers around the adjustment button
ndcate temperature degrees as “°C”.
If the ambent temperature s 20°C, t
s recommended to use the refrgerator
temperature adjustment at 4°C. In other
ambent temperatures ths value can be
customsed.
5.3. Rapid freezing
If you want to freeze large amounts
of fresh food, switch the temperature
adjustment button to (
) position
before putting the food into the quick
freezing compartment.
It is recommended to keep the button
at this position for 24 hours to freeze
maximum amount of food indicated
as the freezing capacity. Pay special
attention not to mix food stolen as
frozen and fresh food.
C
*optional: Pctures gven n ths manual are gven as example fgures and they
may not be exactly the same as your product. If your product does not comprse
the relevant parts, the nformaton pertans to other models.
Using the product
16 /30EN
Refrgerator / User Gude
Remember to switch the temperature
adjustment button back to its
previous position.
5.4. Vacation function
If doors of the product is not ( )
opened for at least 12 hours after
adjusting the temperature setting
button to the highest, vacation
function is automatically activated.
Button setting must be changed to
cancel the function.
It is not recommended to store food
in the cooler compartment when
vacation function is activated.
• After settng s completed, you can
conceal the temperature settng
button by pressng t nsde.
Using the product
17/30EN
Refrgerator / User Gude
C
*Optonal: The figures in this user guide are intended as drafts and may not
perfectly match your product. If your product does not comprise the relevant
parts, the information pertains to other models.
5.5. Indicator panel
Indicator panel allows you to set the temperature and control the other
functions related to the product without opening the door of the product. Just
press the inscriptions on relevant buttons for function settings.
1 2
3
45
6
789
*10
12
11
1. Power failure/High temperature /
error warning indicator
This indicator ( ) illuminates during
power failure, high temperature
failures and error warnings. During
sustained power failures, the
highest temperature that the freezer
compartment reaches will flash on the
digital display. After checking the food
located in the freezer compartment (
) press the alarm off button to clear the
warning.
2. Energy savng functon (dsplay
off):
If the product doors are kept closed
for a long time energy saving
function is automatically activated
and energy saving symbol is
illuminated. ( )
When energy saving function is
activated, all symbols on the display
other than energy saving symbol will
turn off. When the Energy Saving
function is activated, if any button
is pressed or the door is opened,
energy saving function will be
canceled and the symbols on display
will return to normal.
Using the product
18 /30EN
Refrgerator / User Gude
5.Vacation Function
In order to activate vacation function,
press the this button (
) for 3
seconds, and the vacation mode
indicator (
) will be activated. When
the vacation function is activated,
“- -” is displayed on the fridge
compartment temperature indicator
and no active cooling is performed
on the fridge compartment. It is not
suitable to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press Vacation
function button again.
6. Alarm off warnng:
In case of power failure/high
temperature alarm, after checking
the food located in the freezer
compartment press the alarm off
button (
) to clear the warning.
7. Key lock
Press key lock button ( )
simultaneously for 3 seconds. Key
lock symbol
(
) will light up and key lock mode
will be activated. Buttons will
not function if the Key lock mode
is active. Press key lock button
simultaneously for 3 seconds again.
Key lock symbol will turn off and the
key lock mode will be exited.
Press the keylock button if you
want to prevent changing of
the temperature setting of the
refrigerator (
).
Energy saving function is activated
during delivery from factory and
cannot be canceled.
3.Quck frdge functon
The button has two functons. To
actvate or deactvate the quck cool
functon press t brefly. Quck Cool
ndcator wll turn off and the product
wll return to ts normal settngs. ( )
C
Use quck coolng functon
when you want to quckly cool
the food placed n the frdge
compartment. If you want to
cool large amounts of fresh
food, actvate ths functon
before puttng the food nto
the product.
C
If you do not cancel t, quck
coolng wll cancel tself
automatcally after 8 hours or
when the frdge compartment
reaches to the requred
temperature.
C
If you press the quck coolng
button repeatedly wth short
ntervals, the electronc crcut
protecton wll be actvated
and the compressor wll not
start up mmedately.
C
Ths functon s not recalled
when power restores after a
power falure.
4. Frdge compartment
temperature settng button
Press this button to set the
temperature of the fridge
compartment to 8, 7,6, 5,4,3, 2, 8...
respectively. Press this button to set
the fridge compartment temperature
to the desired value. ( )
Using the product
19/30EN
Refrgerator / User Gude
8. Eco fuzzy
Press and hold eco fuzzy button
for 1 seconds to activate eco fuzzy
function. Refrigerator will start
operating in the most economic
mode at least 6 hours later and the
economic usage indicator will turn
on when the function is active (
). Press and hold eco fuzzy function
button for 3 seconds to deactivate
eco fuzzy function.
This indicator is illuminated after 6
hours when eco fuzzy is activated.
9. Freezer compartment
temperature settng button
Press this button to set the
temperature of the freezer
compartment to -18,-19,-20,-21,
-22, -23,-24, -18... respectively.
Press this button to set the freezer
compartment temperature to the
desired value.
( )
10. Icematic off indicator
Indicates whether the icematic is on
or off. (
)If On, then the icematic
is not operating. To operate the
icematic again press and hold the On-
Off button for 3 seconds.
C
Water flow from water tank
wll stop when ths functon s
selected. However, ce made
prevously can be taken from
the cematc.
11. Quck freeze functon button/
cematc on-off button
Press this button to activate or
deactivate the quick freezing
function. When you activate the
function, the freezer compartment
will be cooled to a temperature lower
than the set value. ( )
To turn on and off the icematic press
and hold it for 3 seconds.
C
Use the quck freeze functon
when you want to quckly
freeze the food placed n frdge
compartment. If you want to
freeze large amounts of fresh
food, actvate ths functon
before puttng the food nto
the product.
C
If you do not cancel t, Quck
Freeze wll cancel tself
automatcally after 4 hours or
when the frdge compartment
reaches to the requred
temperature.
C
Ths functon s not recalled
when power restores after a
power falure.
12. Economc usage ndcator
Indicates that the product is running
in energy-efficient mode. ( )This
indicator will be active if the Freezer
Compartment temperature is set to
-18 or the energy efficient cooling
is being performed due to Eco-Extra
function.
C
Economc usage ndcator s
turned off when quck coolng
or quck freeze functons are
selected.
Using the product
20 /30EN
Refrgerator / User Gude
5.6. Ice bucket
(Optonal)
• Take the ce bucket from the
freezer compartment.
• Fll the ce bucket wth water.
• Place the ce bucket nto the
freezer compartment.
The ce wll be ready after
approxmately two hours. Take
the ce bucket from the freezer
compartment and bend n sghtly
over the holder that you are gong
to serve. Ice wll easly pour nto
the servng holder.
5.7. Eggholder
You can put the eggholder on the
door or body rack of your choice. If you
decide to put it on the body rack, it is
recommended to prefer the shelves
below as they are colder.
A
Do not put the eggholder nto
the freezer compartment.
5.8. Fan
Fan was designed to distribute circu-
late the cold air inside your refrigera-
tor homogeneously. Operating time
of the fan might vary depending the
features of your product.
While in some products fan only oper-
ates with compressor, in others con-
trol system determines the operating
time based on the need for cooling.
5.9. Vegetable bin
(Optonal)
Product’s vegetable bn s desgned to
keep vegetables fresh by preservng
humdty. For ths purpose, the overall
cold ar crculaton s ntensfed n the
vegetable bn.
5.10. Zero degree
compartment
(Optonal)
Use this compartment to keep
delicatessen at lower temperatures
or meat products for immediate
consumption.
Zero degree compartment is the
coolest place where foods such
as dairy products, meat, fish and
chicken can be stored in ideal
storage conditions. Vegetables and/
or fruits should not be stored in this
compartment.
Using the product
21/30EN
Refrgerator / User Gude
5.11. Moving door rack
(Optonal)
Moving door rack can be fixed in 3
different positions.
In order to move the rack, push the
buttons on the side evenly. Rack will
be movable.
Move the rack up or down.
When the rack is in the position that
you want, release the buttons. Rack
will be fixed again in the position
where you have released the
buttons.
5.12. Sliding
storage box
(Optonal)
This accessory has been designed
to increase the usage volume of the
door racks.
Thanks to its ability to move
sideways, it enables you to easily
place long bottle, jar or boxes that you
put in the bottle rack below.
Using the product
22 /30EN
Refrgerator / User Gude
5.13. Moisture
controlled
vegetable bin
(Optonal)
With moisture control feature,
moisture rates of vegetables and
fruits are kept under control and
ensures a longer freshness period for
foods.
It is recommended to store leafed
vegetables such as lettuce and
spinach and similar vegetables prone
to moisture loss not on their roots
but in horizontal position into the
vegetable bin as much as possible.
When placing the vegetables, place
heavy and hard vegetables at the
bottom and light and soft ones on the
top, taking into account the specific
weights of vegetables.
Do not leave vegetables in the
vegetable bin in plastic bags.
Leaving them in plastic bags causes
vegetables to rot in a short time. In
situations where contact with other
vegetables is not preferred, use
packaging materials such as paper
that has a certain porosity in terms of
hygiene.
Do not put fruits that have a high
ethylene gas production such as pear,
apricot, peach and particularly apple
in the same vegetable bin with other
vegetables and fruits. The ethylene
gas coming out of these fruits might
cause other vegetables and fruits
to mature faster and rot in a shorter
period of time.
5.14. Automatic
ice machine
(Optonal)
Automatic ice machine enables you
to easily make ice in your refrigerator.
In order to obtain ice from the ice
machine, take out the water tank in
the cooler compartment, fill it with
water and fix it back.
First ice will be ready in about 2 hours
in the ice machine drawer in the
cooler compartment.
After placing the full water tank, you
can obtain about 60-70 cubes of ice
until it is fully empty.
If the water in the tank has waited for
2-3 weeks, it should be changed.
C
In products with automatic
ice machine, you might hear a
sound when pouring the ice.
This sound is normal and is not
a sign of failure.
Using the product
23/30EN
Refrgerator / User Gude
5.16. Freezing
fresh food
• To preserve food quality, the
food items placed in the freezer
compartment must be frozen as
quickly as possible, use the rapid
freezing for this.
• Freezing the food items when
fresh will extend the storage time
in the freezer compartment.
• Pack the food items in air-tight
packs and seal tightly.
• Make sure the food items are
packed before putting in the
freezer. Use freezer holders, tinfoil
and damp-proof paper, plastic
bag or similar packaging materials
instead of traditional packaging
paper.
C
Ice in the freezing
compartment thaws
automatically.
• Mark each food pack by wrtng
the date on the package before
freezng. Ths wll allow you to
determne the freshness of each
pack every tme the freezer s
opened. Keep the earler food
tems n the front to ensure they
are used frst.
• Frozen food tems must be used
mmedately after defrostng and
should not be frozen agan.
• Do not free large quanttes of
food at once.
5.15. Icematic and ice
storage container
*optional
Using the Icematic
Fill the Icematic with water and place
it into its seat. Your ice will be ready
approximately in two hours. Do not
remove the Icematic from its seating
to take ice.
Turn the knobs on the ice reservoirs
clockwise by 90 degrees.
Ice cubes in the reservoirs will fall
down into the ice storage container
below.
You may take out the ice storage
container and serve the ice cubes.
If you wish, you may keep the ice
cubes in the ice storage container.
Ice storage container
Ice storage container is only intended
for accumulating the ice cubes. Do
not put water in it. Otherwise, it will
break.
Using the product
24 /30EN
Refrgerator / User Gude
Freezer
Compartment
Temperature
Setting
Cooler
Compartment
Temperature
Setting
Details
-18°C 4°C This is the default, recommended setting.
-20,-22 or
-24°C
4°C
These settings are recommended for ambient
temperatures exceeding 30°C.
Quick
Freeze
4°C
Use when you want to freeze your food in a short
time. When the process ends, the product will
regain its position.
-18°C or
colder
2°C
Use these settings if you believe the cooler
compartment is not cold enough due to ambient
temperature or frequently opening the door.
5.17. Recommendations for storing frozen foods
The compartment must be set to at least -18°C.
1.
Place the food tems n the freezer as quckly as possble to avod defrostng.
2.
Before freezng, check the “Expry Date” on the package to make sure t s not
expred.
3.
Make sure the food’s packagng s not damaged.
5.18. Deep freezer details
As per the IEC 62552 standards, the freezer must have the capacity to freeze
4,5 kg of food items at -18°C or lower temperatures in 24 hours for each 100
litres of freezer compartment volume.
Food items can only be preserved for extended periods at or below
temperature of -18°C .
You can keep the foods fresh for months (in deep freezer at or below
temperatures of 18°C ).
The food items to be frozen must not contact the already-frozen food inside to
avoid partial defrosting.
Boil the vegetables and filter the water to extend the frozen storage time.
Place the food in air-tight packages after filtering and place in the freezer.
Bananas, tomatoes, lettuce, celery, boiled eggs, potatoes and similar food
items should not be frozen. In case this food rots, only nutritional values and
eating qualities will be negatively affected. A rotting threatening human
health is not in question.
5.19. Placing the food
Freezer
compartment
shelves
Various frozen goods
including meat, fish, ice
cream, vegetables etc.
Using the product
25/30EN
Refrgerator / User Gude
Cooler
compartment
shelves
Food items inside pots,
capped plate and capped
cases, eggs (in capped
case)
Cooler
compartment
door shelves
Small and packed food or
beverages
Vegetable bin Fruits and vegetables
Fresh food
compartment
Delicatessen (breakfast
food, meat products to be
consumed in short notice)
5.20. Door open alert
(Optonal)
An audible alert will be heard if the
product's door remains open for at
least 1 minute. The audible alert will
stop when the door is closed or any
button on the display (if available) is
pressed.
Door open alert is indicated to the
user both audibly and visually. Interior
lighting will turn of if the warning
continues for 10 min.
5.21. Changing the
opening direction
of the door
You can change the drecton of ope-
nng of your refrgerator dependng
on the locaton where you use t.
When you need ths, consult the clo-
sest Authorzed Servce.
The explanaton above s a general
statement. You should check the war-
nng tag located nsde the product
package about the changeablty of
drecton of the door.
5.22. Interior light
Interior light uses a LED type lamp.
Contact the authorized service for any
problems with this lamp.
Lamp(s) used in this appliance cannot
be used for house lighting. Intended
use of this lamp is to help the user
place food into the refrigerator /
freezer safely and comfortably.
26 /30 EN
Refrgerator / User Gude
6 Mantenance and cleanng
Service life of the product is increase if it
is regularly cleaned
B
WARNING:Frst unplug the product
before cleanng your refrgerator.
•
Never use any sharp and abrasve
tools, soap, household cleaners,
detergent and wax polsh for cleanng.
•
Dssolve one teaspoon of carbonate
n half lter of water. Soak a cloth wth
the soluton and wrung t thoroughly.
Wpe the nteror of the applance wth
ths cloth and the dry thoroughly.
•
Make sure that no water enters the
lamp housng and other electrcal
tems.
•
Clean the door wth a damp cloth.
To remove door and body shelves,
remove all of ts contents. Remove
door shelves by movng them
upwards. After cleanng, slde them
from top to bottom to nstall.
•
Never use cleanng agents or water
that contan chlorne to clean the
outer surfaces and chromum coated
parts of the product. Chlorne causes
corroson on such metal surfaces.
• Do not use sharp, abrasve tools,
soap, household cleanng agents,
detergents, kerosene, fuel ol,
varnsh etc. to prevent removal and
deformaton of the prnts on the
plastc part. Use lukewarm water and
a soft cloth for cleanng and then
wpe t dry.
6.1. Avoiding bad odors
Materials that may cause odor are not
used in the production of our appliances.
However, due to inappropriate food
preserving conditions and not cleaning
the inner surface of the appliance as
required can bring forth the problem of
odor.
Therefore, clean the refrigerator wth
carbonate dssolved n water every 15
days.
•
Keep the food n closed contaners.
Mcroorgansms spreadng out from
uncovered contaners can cause
unpleasant odours.
•
Never keep the food that have expred
best before dates and spoled n the
refrgerator.
6.2. Protecting the
plastic surfaces
Clean with arm water immediately as the
oil may cause damage on the surface
when it is poured on plastic surfaces.
6.3. Door Glasses
Remove the protective foil on the
glasses.
There is a coating on the surface of
the glasses.This coating minimizes the
stain build-up and helps to remove the
possible stains and dirt easily.Glasses
that are not protected with such a
coating may be subject to persistent
binding of air or water based organic or
inorganic dirt such as limescale, mineral
salts, unburned hydrocarbons, metal
oxides and silicones that can easily and
quickly cause stains or material damage.
Keeping the glass clean becomes too
difficult despite the regular cleaning.
Consequently, the appearance and the
transparency of the glass deteriorates.
Harsh and corrosive cleaning methods
and compounds will intensify these
defects and speed up the deterioration
process.
27/30 EN
Refrgerator / User Gude
Water-based cleaning products that are
not alkaline and corrosive must be used
for regular cleaning purposes.
Non-alkaline and non-corrosive
materials must be used for cleaning so
that the service life of this coating lasts
for a long time.
These glasses are tempered to increase
their durability against impacts and
breaking.A safety film is also applied to
their rear surfaces as an extra safety
measure in order to prevent them from
causing damage to their surrounding in
case of a breakage.
*Alkali is a base that forms hydroxide
ions (OH¯) when it is dissolved in water.
Li (Lithium), Na (Sodium), K (Potassium)
Rb (Rubidium), Cs (Cesium) and artificial
and radioactive Fr (Fan-sium) metals are
called ALKALI METALS.
6 Mantenance and cleanng
28 /30 EN
Refrgerator / User Gude
7. Troubleshootng
Check ths lst before contactng the
servce. Dong so wll save you tme
and money. Ths lst ncludes frequent
complants that are not related to faulty
workmanshp or materals. Certan
features mentoned heren may not apply
to your product.
The refrgerator s not workng.
• The power plug is not fully settled. >>> Plug
it in to settle completely into the socket.
• The fuse connected to the socket powering
the product or the main fuse is blown. >>>
Check the fuses.
Condensaton on the sde wall of the
cooler compartment (MULTI ZONE,
COOL, CONTROL and FLEXI ZONE).
• The door is opened too frequently >>>
Take care not to open the product’s door too
frequently.
• The environment is too humid. >>> Do not
install the product in humid environments.
• Foods containing liquids are kept in unsealed
holders. >>> Keep the foods containing
liquids in sealed holders.
• The product’s door is left open. >>> Do
not keep the product’s door open for long
periods.
• The thermostat is set to too low temperature.
>>> Set the thermostat to appropriate
temperature.
Compressor s not workng.
• In case of sudden power failure or pulling the
power plug off and putting back on, the gas
pressure in the product’s cooling system is
not balanced, which triggers the compressor
thermic safeguard. The product will restart
after approximately 6 minutes. If the product
does not restart after this period, contact the
service.
• Defrosting is active. >>> This is normal for
a fully-automatic defrosting product. The
defrosting is carried out periodically.
• The product is not plugged in. >>> Make
sure the power cord is plugged in.
• The temperature setting is incorrect. >>>
Select the appropriate temperature setting.
• The power is out. >>> The product will
continue to operate normally once the
power is restored.
The refrgerator’s operatng nose s
ncreasng whle n use.
• The product’s operating performance may
vary depending on the ambient temperature
variations. This is normal and not a
malfunction.
The refrgerator runs too often or for
too long.
• The new product may be larger than the
previous one. Larger products will run for
longer periods.
• The room temperature may be high. >>>
The product will normally run for long
periods in higher room temperature.
• The product may have been recently
plugged in or a new food item is placed
inside. >>> The product will take longer to
reach the set temperature when recently
plugged in or a new food item is placed
inside. This is normal.
• Large quantities of hot food may have been
recently placed into the product. >>> Do
not place hot food into the product.
• The doors were opened frequently or kept
open for long periods. >>> The warm air
moving inside will cause the product to run
longer. Do not open the doors too frequently.
• The freezer or cooler door may be ajar.
>>> Check that the doors are fully closed.
• The product may be set to temperature too
low. >>> Set the temperature to a higher
degree and wait for the product to reach the
adjusted temperature.
• The cooler or freezer door washer may
be dirty, worn out, broken or not properly
29/30 EN
Refrgerator / User Gude
Troubleshootng
settled. >>> Clean or replace the washer.
Damaged / torn door washer will cause the
product to run for longer periods to preserve
the current temperature.
The freezer temperature s very
low, but the cooler temperature s
adequate.
• The freezer compartment temperature is set
to a very low degree. >>> Set the freezer
compartment temperature to a higher
degree and check again.
The cooler temperature s very
low, but the freezer temperature s
adequate.
• The cooler compartment temperature is set
to a very low degree. >>> Set the freezer
compartment temperature to a higher
degree and check again.
The food tems kept n cooler
compartment drawers are frozen.
• The cooler compartment temperature is set
to a very low degree. >>> Set the freezer
compartment temperature to a higher
degree and check again.
The temperature n the cooler or the
freezer s too hgh.
• The cooler compartment temperature is set
to a very high degree. >>> Temperature
setting of the cooler compartment has an
effect on the temperature in the freezer
compartment. Wait until the temperature
of relevant parts reach the sufficient level
by changing the temperature of cooler or
freezer compartments.
• The doors were opened frequently or kept
open for long periods. >>> Do not open the
doors too frequently.
• The door may be ajar. >>> Fully close the
door.
• The product may have been recently
plugged in or a new food item is placed
inside. >>> This is normal. The product will
take longer to reach the set temperature
when recently plugged in or a new food
item is placed inside.
• Large quantities of hot food may have been
recently placed into the product. >>> Do
not place hot food into the product.
Shakng or nose.
• The ground is not level or durable. >>> If
the product is shaking when moved slowly,
adjust the stands to balance the product.
Also make sure the ground is sufficiently
durable to bear the product.
• Any items placed on the product may cause
noise. >>> Remove any items placed on
the product.
The product s makng nose of lqud
flowng, sprayng etc.
• The product’s operating principles involve
liquid and gas flows. >>> This is normal
and not a malfunction.
There s sound of wnd blowng
comng from the product.
• The product uses a fan for the cooling
process. This is normal and not a
malfunction.
There s condensaton on the
product’s nternal walls.
• Hot or humid weather will increase icing
and condensation. This is normal and not a
malfunction.
• The doors were opened frequently or kept
open for long periods. >>> Do not open the
doors too frequently; if open, close the door.
• The door may be ajar. >>> Fully close the
door.
There s condensaton on the
product’s exteror or between the
doors.
• The ambient weather may be humid, this
is quite normal in humid weather. >>>
The condensation will dissipate when the
humidity is reduced.
30 /30 EN
Refrgerator / User Gude
Troubleshootng
The nteror smells bad.
• The product is not cleaned regularly. >>>
Clean the interior regularly using sponge,
warm water and carbonated water.
• Certain holders and packaging materials
may cause odour. >>> Use holders and
packaging materials without free of odour.
• The foods were placed in unsealed holders.
>>> Keep the foods in sealed holders.
Micro-organisms may spread out of unsealed
food items and cause malodour. Remove any
expired or spoilt foods from the product.
The door s not closng.
• Food packages may be blocking the door.
>>> Relocate any items blocking the doors.
• The product is not standing in full upright
position on the ground. >>> Adjust the
stands to balance the product.
• The ground is not level or durable. >>>
Make sure the ground is level and sufficiently
durable to bear the product.
The vegetable bn s jammed.
• The food items may be in contact with the
upper section of the drawer. >>> Reorganize
the food items in the drawer.
If The Surface Of The Product Is Hot.
• High temperatures may be observed
between the two doors, on the side panels
and at the rear grill while the product is
operating. This is normal and does not
require service maintenance!Be careful when
touching these areas.
A
WARNING:
If the problem perssts after followng the
nstructons n ths secton, contact your
vendor or an Authorsed Servce. Do not
try to repar the product.
www.beko.com.tr
www.beko.co.nz
57 5754 0000/AM
EN
