Confirming the Package Contents
The following items are included in the package. If something is
missing please contact the retail outlet at which you purchased the
product.
A memory card is not included.
g
a
b
de
h
Camera Battery Pack
NB-7L
(With Terminal Cover)
Battery Charger
CB-2LZ/CB-2LZE
Interface Cable
IFC-400PCU
AV Cable
AVC-DC300
Warranty CardCanon Digital
Camera Solution
Disk
• Camera User Guide (this guide)
• Direct Print User Guide
(Connecting the camera to a printer)
• Software Starter Guide
(Connecting the camera to a computer)
User Guides
c
j
See the PDF manuals available on the Canon website.
• ZoomBrowser EX/ImageBrowser Software User Guide
(http://web.canon.jp/imaging/information-e.html)
• Digital Photo Professional Instruction Manual
Neck Strap
NS-DC8
f
i
“Canon Customer
Support” Leaflet
COPY
Let’s Get Started!
1
Let’s Get Started!
This guide is divided into the following two sections.
Next...
Learning More
p. 39
First...
p. 9
Getting Started
This section explains how to prepare the camera for use and the
basics of shooting, viewing and printing images. Start out by
familiarizing yourself with the camera and mastering the basics.
Once you have mastered the basics, use the camera’s many features
to shoot more challenging photos. Details on using each function are
described in this section, including how to connect the camera to a
television to view images.
COPY
Table of Contents
2
Table of Contents
Items marked with a are lists or charts that summarize camera functions
or procedures.
Please Read . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Components Guide 40
Using the Control Dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Using the Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Basic Operations 47
Menus and Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Information Displayed on the LCD Monitor and Menus . . . 49
The LCD Monitor Display. . . . . . . . . . . . . . . . . . . . . . . . . . 63
Customizing Display Information . . . . . . . . . . . . . . . . . . . . 66
Commonly Used Shooting Functions 68
Using the Optical Zoom . . . . . . . . . . . . . . . . . . . . . . 68
Using the Digital Zoom/ Digital Tele-Converter . . . . . . . . . 69
Using the Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Learning More . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Preparations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Shooting Still Images
( Mode) . . . . . . . . . . . . . . . . . . 17
Viewing Still Images . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Erasing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Shooting Movies
( Standard Mode) . . . . . . . . . . . . . . . 24
Viewing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Downloading Images to a Computer . . . . . . . . . . . . . 27
System Map. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
COPY
Table of Contents
3
Shooting Close-ups (Macro) . . . . . . . . . . . . . . . . . . . . . 74
Using the Self-Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Changing the Recording Pixels (Still Images) . . . . . . . . . . 80
Changing the Compression (Still Images) . . . . . . . . . . . . . 81
Changing the Image Type . . . . . . . . . . . . . . . . . . . . . . . . . 82
Setting the Image Stabilizer Function . . . . . . . . . . . . . . . . 85
Adjusting the ISO Speed . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Reducing Camera Shake When Shooting (Auto ISO Shift) 88
Shooting Using the Mode Dial 90
Mode Dial. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Shooting Modes for Specific Scenes . . . . . . . . . . . . . 91
Program AE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Setting the Shutter Speed . . . . . . . . . . . . . . . . . . . . . 96
Setting the Aperture . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Manually Setting the Shutter Speed and Aperture. . 100
Shooting Panoramic Images (Stitch Assist) . . . . . . . 102
Movie Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Setting the Recording Functions . . . . . . . . . . . . . . . . . . . 108
Saving Custom Settings . . . . . . . . . . . . . . . . . . . . . . . 109
Various Shooting Methods 111
Continuous Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Setting the Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Checking the Focus and People’s Expressions. . . . . . . . 116
Switching between Focus Settings . . . . . . . . . . . . . . . . . 120
Selecting an AF Frame Mode. . . . . . . . . . . . . . . . . . . 121
Selecting a Subject to Focus On (Face Select and Track) 125
Shooting with Servo AF . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Shooting Hard-to-Focus Subjects
(Focus Lock, AF Lock, Manual Focus, Safety MF) . . . . 128
Focus Bracketing (Focus-BKT Mode) . . . . . . . . . . . . . . . 133
Locking the Exposure Setting (AE Lock) . . . . . . . . . . . 134
Locking the Flash Exposure Setting (FE Lock) . . . . . . 136
Adjusting the Exposure Compensation . . . . . . . . . . . . . . 137
Shooting while Brightening Dark Areas (i-Contrast) . . . . 138
Auto Exposure Bracketing (AEB Mode). . . . . . . . . . . . . . 139
COPY
Table of Contents
4
Using the ND Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Switching between Metering Modes. . . . . . . . . . . . . . 141
Adjusting the Tone (White Balance) . . . . . . . . . . . . . . . . 143
Shooting in a My Colors Mode. . . . . . . . . . . . . . . . . . . . . 146
Changing the Colors and Shooting . . . . . . . . . . . . . . . . . 148
Categorizing Images Automatically (Auto Category) . . . . 154
Registering Functions to the Button . . . . . . . . . . . . . . . 155
Setting My Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Playback/Erasing 159
Viewing Magnified Images . . . . . . . . . . . . . . . . . . . . . 159
Viewing Images in Sets of Nine (Index Playback) . . . 160
Checking the Focus and People’s Expressions
(Focus Check Display) . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Jumping to Images . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Organizing Images by Category (My Category). . . . . . . . 165
Trimming a Portion of an Image. . . . . . . . . . . . . . . . . . . . 168
Viewing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Editing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Rotating Images in the Display . . . . . . . . . . . . . . . . . . . . 175
Playback with Transition Effects . . . . . . . . . . . . . . . . . . . 176
Automated Playback (Slide Shows). . . . . . . . . . . . . . . . . 177
Red-Eye Correction Function. . . . . . . . . . . . . . . . . . . . . . 182
Brightening Dark Areas (i-Contrast). . . . . . . . . . . . . . . . . 187
Adding Effects with the My Colors Function . . . . . . . . . . 189
Resizing Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192
Attaching Sound Memos to Images. . . . . . . . . . . . . . . 194
Sound-Only Recording (Sound Recorder) . . . . . . . . . . . . 195
Protecting Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Erasing Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Print Settings/Transfer Settings 207
Setting the DPOF Print Settings . . . . . . . . . . . . . . . . . . . 207
Setting the DPOF Transfer Settings . . . . . . . . . . . . . . . . 214
Configuring the Camera 216
Power Saving Function . . . . . . . . . . . . . . . . . . . . . . . . . . 216
COPY
Table of Contents
5
Setting the World Clock . . . . . . . . . . . . . . . . . . . . . . . . . . 217
Low Level Formatting Memory Cards . . . . . . . . . . . . . . . 220
Resetting the File Number . . . . . . . . . . . . . . . . . . . . . . . . 221
Creating an Image Destination (Folder). . . . . . . . . . . . . . 223
Setting the Auto Rotate Function . . . . . . . . . . . . . . . . . . . 225
Resetting Settings to Their Default Values . . . . . . . . . . . 227
Connecting to a TV 228
Shooting/Playback Using a TV . . . . . . . . . . . . . . . . . . . . 228
Customizing the Camera (My Camera Settings) 230
Changing My Camera Settings . . . . . . . . . . . . . . . . . . . . 230
Registering My Camera Settings . . . . . . . . . . . . . . . . . . . 231
Troubleshooting 233
List of Messages 244
Appendix 248
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Preventing Malfunctions. . . . . . . . . . . . . . . . . . . . . . . . . . 254
Using the AC Adapter (Sold Separately) . . . . . . . . . . . . . 258
Using the Lenses (Sold Separately) . . . . . . . . . . . . . . . . 260
Using an Externally Mounted Flash (Sold Separately) . . 265
Using a Supplementary Flash (Sold Separately) . . . . . . . 272
Using the Remote Switch (Sold Separately) . . . . . . . . . . 274
Camera Care and Maintenance. . . . . . . . . . . . . . . . . . . . 275
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276
Index 286
Addendum 290
Attaching an Externally Mounted Flash (for Macro Ring
Lite MR-14EX or Macro Twin Lite MT-24EX). . . . . . . . 290
Functions Available in Each Shooting Mode 300
COPY
About this Guide
6
Symbol Conventions in this Guide
About this Guide
: This mark denotes issues that may affect the camera’s
operation.
: This mark denotes additional topics that complement the basic
operating procedures.
Explanations in this guide are based on the camera’s default settings
at time of purchase.
The illustrations and screenshots used in this guide may differ from
the actual camera.
You can use SD memory cards, SDHC (SD High Capacity) memory
cards, MultiMediaCards, MMCplus cards and HC MMCplus cards in
this camera. These are collectively referred to as memory cards in
this guide.
73
Using the Flash
Available Shooting Modes p. 300
1
Press the button.
Mode:
Shooting ( )/
Playback ( )
Some functions may not be available in certain shooting modes.
If there is no notation to that effect, the function may be used in all modes.
COPY
Please Read
7
Please Read
Test Shots
Before you try to photograph important subjects, we highly recommend
that you shoot several trial images to confirm that the camera is
operating and being operated correctly.
Please note that Canon Inc., its subsidiaries and affiliates, and its
distributors are not liable for any consequential damages arising from
any malfunction of a camera or accessory, including memory cards,
that results in the failure of an image to be recorded or to be recorded
in a way that is machine readable.
Warning Against Copyright Infringement
Please note that Canon digital cameras are intended for personal use
and should never be used in a manner that infringes upon or
contravenes international or domestic copyright laws and regulations.
Please be advised that in certain cases the copying of images from
performances, exhibitions, or commercial properties by means of a
camera or other device may contravene copyright or other legal rights
even if the image was shot for personal use.
Warranty Limitations
This camera’s warranty is only effective in the country of sale. If a
problem arises while the camera is in use abroad, please convey it
back to the country of sale before proceeding with a warranty claim to
a Canon Customer Support Help Desk.
For Canon Customer Support contacts, please see the customer
support list supplied with your camera.
COPY
Please Read
8
Video Format
Please set the camera’s video signal format to the one used in your
region before using it with a TV monitor (p. 228).
Language Setting
Please see Setting the Display Language (p. 15) to change the
language setting.
Camera Body Temperature
If your camera is used for prolonged periods, the camera body
may become warm. Please be aware of this and take care when
operating the camera for an extended period. This is not a
malfunction.
About the LCD Monitor
The LCD monitor is produced with extremely high-precision
manufacturing techniques. More than 99.99% of the pixels
operate to specification. Less than 0.01% of the pixels may
occasionally misfire or appear as red or black dots. This has no
effect on the recorded image and does not constitute a
malfunction.
COPY
Preparations
10
Getting Started
Preparations
1. Insert the battery until it clicks into the battery charger.
2. Plug the battery charger (CB-2LZ) into a power outlet,
or attach the power cord to the battery charger
(CB-2LZE) and plug it into a power outlet.
3. Remove the battery after charging is complete.
Charging takes approximately 2 hours 20 minutes.
Charging the Battery
To protect the battery and prolong its life, do not charge it for
longer than 24 hours continuously.
Align the symbols.
Charge Indicator (Upper)
Charging: lights orange
Charge Indicator (Lower)
Charging Complete:
lights green
COPY
Preparations
11
Getting Started
1. Slide the cover (a) and open it (b).
2. Push the battery lock in the direction of the arrow (c)
and insert the battery until it locks.
Installing the Battery and Memory Card
b
a
c
Battery Lock
COPY
Preparations
12
Getting Started
3. Insert the memory card until it clicks into place.
4. Close the cover (d) and slide until it clicks (e).
Ensure that the memory card is correctly oriented before
inserting it in the camera. Inserting it backward may cause the
camera to fail to recognize the memory card or to malfunction.
Front
• Confirm that the write protect tab is
unlocked (only SD and SDHC
memory cards).
• Check the card for the correct
orientation.
Write Protect Tab
(only SD and SDHC memory cards)
d
e
COPY
Preparations
13
Getting Started
To Remove the Battery
Push the battery lock in the direction of the arrow and hold it while
pulling the battery out.
To Remove the Memory Card
Push the memory card with your finger until the memory card clicks
and then release it.
Attaching the Neck Strap
Battery Lock
Pull the strap tight in the
buckle so that it does not
slip. Perform the same
steps on the other side of
the camera.
a
b
c
In order to avoid dropping the camera, we recommend
attaching the neck strap before using the camera.
COPY
Preparations
14
Getting Started
The Date/Time settings menu will appear the first time the power is
turned on.
1. Press the power button.
2. Select the month, day, year and
time, and the display order.
1. Use the or button to select
an option.
2. Use the or button to set the
value.
• You can also set the value by using
the control dial.
3. Press the button.
To Change a Previously Set Date/Time
Use the following procedures to display the Date/Time settings menu,
and then perform Steps 2 and 3 above.
1. Press the MENU button.
2. Use the or button to select
the (Set up) menu.
3. Use the or button to select
[Date/Time].
4. Press the button.
Setting the Date and Time
Buttons
Button
MENU Button
Control Dial
Power Button
COPY
Preparations
15
Getting Started
You can change the language displayed in the LCD monitor menus
and messages.
1. Press the (Playback) button.
2. Hold down the button and press the MENU button.
3. Use the , , or button to select a language.
4. Press the button.
z A rechargeable lithium battery is built into the camera to save
such settings as the date/time. If you insert a charged battery
into the camera, or use the separately sold AC Adapter Kit
ACK-DC50, the battery will charge in about four hours. It will
charge even if the camera is turned off.
z The date/time settings may be lost after approximately three
weeks if you remove the main battery. Reset the date/time
settings if this occurs.
Setting the Display Language
Button
Button
MENU Button
Buttons
COPY
Preparations
16
Getting Started
You should always format a new memory card or one from which you
wish to erase all images and other data.
1. Press the power button.
2. Select [Format].
1. Press the MENU button.
2. Use the or button to select
the menu.
3. Use the or button to select
[Format].
4. Press the button.
3. Format a memory card.
1. Use the or button to select
[OK].
2. Press the button.
Formatting Memory Cards
Please note that formatting (initializing) a memory card erases
all data, including protected images (p. 197) and sound data
recorded with the sound recorder (p. 195).
Power Button
Buttons
Button
MENU Button
Displays when sound
data recorded with the
sound recorder is present.
COPY
Shooting Still Images
17
Getting Started
Shooting Still Images
1. Press the power button.
• The start-up sound will play and the start-up image will display in
the LCD monitor.
• Pressing the power button again turns the power off.
2. Select a shooting mode.
1. Set the mode dial to .
3. Aim the camera at the subject.
4. Press the shutter button lightly (halfway) to focus.
When the camera focuses, it beeps twice and the indicator lights
green (orange when the flash fires).
Avoiding Camera Shake
Keep your arms tight against your body
while holding the camera firmly by the
sides. Using a tripod is also effective.
( Mode)
Mode Dial
Shutter Button
Indicators
Power Button
DISP. Button
Button
COPY
Shooting Still Images
18
Getting Started
5. Press the shutter button fully (all the way) to shoot.
• The shutter sound will play and the image will record.
• Movement of the camera or subject while the shutter sound is
playing may result in blurred images.
• Recorded images are displayed on the LCD monitor for
approximately 2 seconds immediately after shooting (Rec.
Review). You can shoot by pressing the shutter button even
when an image is being displayed.
• If you hold the shutter button down after a shot, the image will
continue to display.
• The indicator will blink green and the file will record to the
memory card.
To Shoot Images in Focus
The camera automatically sets the focus when you press the shutter
button halfway*.
* The shutter button has a two-stage action. Pressing it down to the first stage is
referred to as “pressing halfway”.
Mute Setting
Pressing the button while turning on the camera power will
silence all camera sounds. You can change the setting in
[Mute] in the Set up menu (p. 59).
Press halfway
to set the focus
An AF frame will display in
green on the LCD monitor
at the point of focus.
Press fully
Incorrect
AF Frame
Correct
Beep,
beep…
Shooting Preparations
Complete: Lights green
(orange when the flash will fire)
Recording:
Blinks green
Just pressing
fully
COPY
Viewing Still Images
19
Getting Started
Viewing Still Images
1. Press the (Playback) button.
2. Use the or button to display the image you wish
to view.
• Use the button to move to the previous image and the
button to move to the next image.
• The images advance more quickly if
you keep the button pressed, but they
will appear coarse.
• You can also select images by using
the control dial. Turning it
counterclockwise displays the
previous image while turning it
clockwise displays the next image.
z In the Playback menu, you can set [Resume] to either [Last
seen]* or [Last shot]. (* Default setting)
z If you select [Last seen], the last image viewed will display
(Resume Playback).
z The following actions will display the most recent image
regardless of the [Resume] settings: shooting an image,
changing the memory card, or editing an image on the
memory card using a computer.
Button
Buttons
Control Dial
COPY
Erasing
20
Getting Started
Erasing
1. Press the (Playback) button.
2. Use the or button to select an image to erase and
press the button.
You can also select images by using the control dial.
3. Confirm that [Erase] is selected
and press the button.
To exit instead of erasing, select
[Cancel].
Please note that erased images cannot be recovered. Exercise
adequate caution before erasing an image.
Buttons
Button
Button
Control Dial
Button
COPY
Printing
21
Getting Started
Printing
1. Connect the camera to a direct print compatible printer.
• Open the camera’s terminal cover and insert the interface cable
all the way into the terminal.
• See the printer’s user guide for connection instructions.
• Since this camera uses a standard protocol (PictBridge), you can
use it with other PictBridge-compliant printers in addition to
Canon-brand printers.
For details, see the Direct Print User Guide.
2. Turn on the printer.
3. Press the camera’s (Playback) button to turn on the
power.
• The button will light blue.
Terminal Cover
DIGITAL Terminal
Buttons
FUNC./SET Button
Control Dial
Button
Button
COPY
Printing
22
Getting Started
4. Use the or button to select an image to print and
press the button.
• The button will blink blue and printing will start.
• You can also select images by using the control dial.
• After you finish printing, turn off the camera and the printer and
disconnect the interface cable.
This camera does not allow you to insert the shooting date into
an image while shooting (date stamping). However, you can
use the following method to imprint the date while printing.
- Set with the camera’s Digital Print Order Format (DPOF)
function (p. 207).
Set [Date] option to [On] in [Print Settings] in the (Print)
menu.
- Connect the camera to a printer and imprint the date.
See the Direct Print User Guide.
- Insert a memory card into the printer and imprint the date.
See your printer user guide.
- Use the supplied software.
See the Software Starter Guide.
COPY
Printing
23
Getting Started
Printing from a Print List
You can add images directly to a print list by merely pressing the
button immediately after shooting or playing back an image.
You can then print the images from the print list easily, when
connecting the camera to a printer.
Add to the Print List
1. Press the button (still images only).
2. Add to the print list.
1. Use the or button to select
the number of print copies.
2. Use the or button to select
[Add].
3. Press the button.
• To remove an image from the print
list, press the button again, use the or button to
select [Remove] and press the FUNC./SET button.
Printing Images in a Print List
This explanation is based on the use of a Canon SELPHY ES series
or SELPHY CP series printer.
1. Connect the camera to the printer.
2. Print the image.
1. Use the or button to select
[Print now].
• You can use the or button
to confirm the images added to
the print list.
2. Press the button.
• Printing will start.
• If printing is halted and resumed,
printing will start from the next image in the queue.
Number of copies to print
COPY
Shooting Movies
24
Getting Started
Shooting Movies
1. Press the power button.
2. Select a shooting mode.
1. Set the mode dial to (Movie).
2. Use the control dial to select
(Standard).
3. Aim the camera at the subject.
z Do not touch the microphone while
recording.
z The sound that buttons and other
controls make when used will be
recorded in the movie.
( Standard Mode)
Shutter Button
Indicators
Mode Dial
Power Button
Control Dial
Microphone
Top view
COPY
Shooting Movies
25
Getting Started
4. Press the shutter button halfway
to focus.
• When the camera focuses, it beeps
twice and the indicator lights green.
• The exposure, focus and white
balance are automatically set.
5. Press the shutter button fully to
shoot.
• Recording starts.
• During recording, the elapsed
recording time and [zRec.] will
display in the LCD monitor.
6. Press the shutter button fully
again to stop recording.
• The indicator will blink green and the
data will be recorded onto the memory
card.
• Max. Clip Size: 4 GB*.
• Recording will stop automatically
when the maximum recording time elapses, or the built-in
memory or memory card become full.
* Even before the recording size reaches 4 GB, recording will stop at the moment
the recording time reaches 1 hour. Depending on memory card capacity and
data write speed, recording may stop before the file size reaches 4 GB or the
recording time reaches 1 hour.
Shooting Preparations
Complete: Lights green
Elapsed Time
Recording: Blinks green
COPY
Viewing Movies
26
Getting Started
Viewing Movies
1. Press the (Playback) button.
2. Use the or button to display a movie and press
the button.
• Images with a icon are movies.
• You can also select images by using
the control dial.
3. Use the or button to select (Play) and press the
button.
• The movie will start playing.
• If you press the FUNC./SET button
during playback, you can pause and
restart the movie.
• You can adjust the playback volume
with the or button.
Buttons
Button
Button
Control Dial
COPY
Downloading Images to a Computer
27
Getting Started
Downloading Images to a Computer
We recommend using the supplied software.
Items to Prepare
• Camera and computer
• Canon Digital Camera Solution Disk supplied with the camera
• Interface cable supplied with the camera
System Requirements
Please install the software on a computer meeting the following
minimum requirements.
Windows
OS Windows Vista (including Service Pack 1)
Windows XP Service Pack 2
Computer Model The above OS should be pre-installed on computers with
built-in USB ports.
CPU Still Image Pentium 1.3 GHz or higher
Movie Core2 Duo 1.66 GHz or higher
RAM Still Image 1 GB or more
Movie 1 GB or more
Interface USB
Free Hard Disk
Space
• Canon Utilities
- ZoomBrowser EX : 200 MB or more
- PhotoStitch : 40 MB or more
- Digital Photo Professional : 200 MB or more
Display 1,024 × 768 pixels/High Color (16 bit) or better
COPY
Downloading Images to a Computer
28
Getting Started
Macintosh
1. Installing the software.
Windows
1. Place the Canon Digital Camera Solution Disk in the
computer’s CD-ROM drive.
2. Click [Easy Installation].
Follow the onscreen messages to
proceed with the installation.
3. Click [Restart] or [Finish] once the
installation is complete.
When the installation is finished,
[Restart] or [Finish] will display. Click
the button that appears.
4. Remove the CD-ROM from the drive when your normal
desktop screen appears.
OS Mac OS X (v10.4 – v10.5)
Computer Model The above OS should be pre-installed on computers with
built-in USB ports.
CPU Still Image PowerPC G4/G5 or Intel Processor
Movie Core Duo 1.66 GHz or higher
RAM Still Image 1 GB or more
Movie 1 GB or more
Interface USB
Free Hard Disk
Space
• Canon Utilities
- ImageBrowser : 300 MB or more
- PhotoStitch : 50 MB or more
- Digital Photo Professional : 200 MB or more
Display 1,024 × 768 pixels/ 32,000 Colors or better
Preparing to Download Images
COPY
Downloading Images to a Computer
29
Getting Started
Macintosh
Double-click the icon in the CD-
ROM window. When the installer panel
appears, click [Install]. Follow the
onscreen instructions to proceed.
2. Connecting the camera to a computer.
1. Connect the supplied interface cable to the computer’s
USB port and to the camera’s DIGITAL terminal.
Open the camera’s terminal cover and insert the interface cable
all the way into the terminal.
3. Preparing to download images to the computer.
1. Press the (Playback) button to
turn on the camera.
DIGITAL TerminalUSB Port
Interface Cable
COPY
Downloading Images to a Computer
30
Getting Started
4. Open CameraWindow.
Windows
Select [Canon CameraWindow] and
click [OK].
CameraWindow appears.
Macintosh
CameraWindow will appear when you establish a connection
between the camera and computer. If it fails to appear, click the
[CameraWindow] icon on the Dock (the bar which appears at the
bottom of the desktop).
Preparations for downloading images are now finished. Please
proceed to the Downloading Images Using the Camera (Direct
Transfer) section (p. 31).
If the window above does not appear, click the [Start] menu
and select [All Programs] or [Programs], followed by [Canon
Utilities], [CameraWindow], [CameraWindow] and
[CameraWindow].
Refer to the Software Starter Guide for details on downloading
images using the computer.
COPY
Downloading Images to a Computer
31
Getting Started
Use this method to download images using camera operations.
1. Confirm that the Direct Transfer menu is displayed on
the camera’s LCD monitor.
• The button will light blue.
• Press the MENU button if the Direct
Transfer menu fails to appear.
2. Press the button.
• Images not previously downloaded will download to the
computer.
Downloading Images Using the Camera
(Direct Transfer)
Install the software before downloading images via the direct
transfer method for the first time (p. 28).
Buttons
Button
Button
MENU Button
Direct Transfer Menu
COPY
Downloading Images to a Computer
32
Getting Started
You can also use the following options in the Direct Transfer menu to
set the method for downloading images.
All Images/New Images/DPOF Trans. Images
1. Use the or button to select , or and press
the button.
• The images will download. The
button will blink blue while
downloading is in progress.
• The display will return to the Direct
Transfer menu when the download is
complete.
• Pressing the FUNC./SET button will
cancel a download in progress.
Select & Transfer/Wallpaper
1. Use the or button to select or and press the
button (or button).
All Images Transfers and saves all images to the computer.
New Images
Transfers and saves to the computer only the
images that have not been previously
transferred.
DPOF Trans.
Images
Transfers and saves to the computer only the
images with DPOF Transfer Order settings.
Select & Transfer
Transfers and saves single images to the
computer as you view and select them.
Wallpaper
Transfers and saves single images to the
computer as you view and select them. The
transferred images display as the background on
the computer desktop.
COPY
Downloading Images to a Computer
33
Getting Started
2. Use the or button to select images to download
and press the button.
• The images will download. The
button will blink blue while
downloading is in progress.
3. Press the MENU button after
downloading finishes.
• You will return to the Direct Transfer
menu.
Click at the top right of CameraWindow, and select an application
from the window that appears.
When you click [×] at the bottom right of CameraWindow, the selected
application starts up.
By default, the downloaded images are saved into folders according to
their shooting dates.
Only JPEG images can be downloaded as wallpaper for a
computer.
The option selected with the button is retained even
when the camera’s power is turned off. The previous setting will
be in effect the next time the Direct Transfer menu is displayed.
The image selection screen will appear directly when the
[Select & Transfer] or the [Wallpaper] option was last selected.
Windows Macintosh
COPY
System Map
34
Getting Started
System Map
Neck Strap
NS-DC8
Battery Pack
NB-7L*
1
(With Terminal Cover)
Waterproof Case Weight
WW-DC1
AC Adapter Kit ACK-DC50
Supplied
with Camera
Interface Cable
IFC-400PCU*
1
Canon Digital Camera
Solution Disk
AV Cable
AVC-DC300*
1
Waterproof Case
WP-DC28
Soft Case
SC-DC60
series
Compact Power Adapter
CA-PS700
Speedlite
Transmitter
ST-E2
Speedlite
220EX
Speedlite
430EX II*
4
Speedlite
580EX II*
4
Battery Charger
CB-2LZ/CB-2LZE*
1
DC Coupler
DR-50
Power Cord
Remote Switch
RS60-E3
High-Power
Flash HF-DC1
COPY
System Map
35
Getting Started
USB Port
Compact Photo
Printers*
2
*
3
(SELPHY series)
Bubble Jet Printers*
2
(PIXMA series)
TV/Video
Video IN Terminal
Audio IN Terminal
*1 Also available for purchase separately.
*2 See the user guide supplied with the printer for more information on the printer
and interface cables.
*3 This camera can also be connected to the CP-10/CP-100/CP-200/CP-300.
*4 Speedlite 430EX and 580EX may also be used.
Conversion Lens
Adapter LA-DC58K
Tele-converter
TC-DC58D
Ring Accessory Kit
RAK-DC2
Windows/Macintosh
Canon Brand
Direct Print Compatible
Printers
Memory Card USB Card Reader
Speedlite Bracket
SB-E2
Off Camera Shoe
Cord OC-E3
Macro Twin Lite
MT-24EX
Macro Ring Lite
MR-14EX
Bracket
BKT-DC1
COPY
System Map
36
Getting Started
The following camera accessories are sold separately.
Some accessories are not sold in some regions, or may no longer be
available.
Lenses, Lens Adapter
• Conversion Lens Adapter LA-DC58K
This adapter is required for mounting the Tele-converter, Macro Ring
Lite or Macro Twin Lite to the camera.
• Tele-converter TC-DC58D
Converts the focal distance of the body lens by a factor of
approximately 1.4x when attached.
Flash
• EX-Series Speedlites
Speedlites for Canon EOS models. Subjects are optimally illuminated
for crisp, natural images.
• Speedlite 220EX/430EX II/580EX II*
* Speedlite 430EX and 580EX can also be used.
• Speedlite Transmitter ST-E2
This allows the wireless control of slave (remote) Speedlite flashes
(except the Speedlite 220EX).
• High-Power Flash HF-DC1
This attachable supplementary flash can be used to capture
photographic subjects that are too distant for the built-in flash to
illuminate.
• Speedlite Bracket SB-E2
This bracket helps prevent unnatural shadows from appearing on the
sides of objects when shooting from a vertical position, and is useful
for shooting portraits. The Off Camera Shoe Cord OC-E3 is supplied
with this bracket.
• Off Camera Shoe Cord OC-E3
This cord allows you to use a Speedlite up to 60 cm (2.0 ft.) away
from the camera.
Accessories (Sold Separately)
COPY
System Map
37
Getting Started
• Macro Ring Lite MR-14EX / Macro Twin Lite MT-24EX
These flashes are specially designed to allow a wider range of macro
shooting with a flash.
The Conversion Lens Adapter LA-DC58K (sold separately), Off
Camera Shoe Cord OC-E3 (sold separately), and Bracket BKT-DC1
(sold separately) are required to attach these flashes to the camera.
Power Supplies
• Battery Pack NB-7L
Rechargeable lithium-ion battery.
• Battery Charger CB-2LZ/CB-2LZE
A battery charger for Battery Pack NB-7L.
• AC Adapter Kit ACK-DC50
This is an adapter to supply power from household power outlets.
Recommended to power a camera for an extended period of time or
when connecting to a computer (cannot be used to charge the
camera battery).
Other Accessories
• Interface Cable IFC-400PCU
Use this cable to connect the camera to a computer, Compact Photo
Printer (SELPHY series), or to a Bubble Jet printer*.
* Refer to your Bubble Jet printer user guide.
• AV Cable AVC-DC300
Use this cable to connect the camera to a TV set.
• Waterproof Case WP-DC28
You can use this case to take underwater shots at depths of up to 40
meters (130 feet), and of course it’s ideal for taking worry-free
pictures in the rain, at the beach, or on the ski slopes.
• Soft Case SC-DC60 series
Protects the camera from scratching and dust. Handle with care as
the case’s leather material may discolor.
• Ring Accessory Kit RAK-DC2
A set of lens rings in three different colors.
COPY
System Map
38
Getting Started
• Remote Switch RS60-E3
Connecting the remote switch to the camera allows you to release
the shutter button without touching the camera, thereby reducing the
risk of camera shake. You are recommended to shoot with the
camera attached to a tripod or other device.
• Bracket BKT-DC1
A bracket used to attach a Macro Ring Lite or Macro Twin Lite flash
to the camera.
Canon offers the following separately sold printers for use with the
camera. You can produce photo quality prints quickly and easily by
connecting them to the camera with a single cable and operating the
camera’s controls.
• Compact Photo Printers (SELPHY series)
• Bubble Jet Printers (PIXMA series)
For more information, visit your nearest Canon retailer.
Direct Print Compatible Printers
Use of genuine Canon accessories is recommended.
This product is designed to achieve excellent performance when used with genuine
Canon accessories. Canon shall not be liable for any damage to this product and/or
accidents such as fire, etc., caused by the malfunction of non-genuine Canon
accessories (e.g., a leakage and/or explosion of a battery pack). Please note that this
warranty does not apply to repairs arising out of the malfunction of non-genuine
Canon accessories, although you may request such repairs on a chargeable basis.
COPY
39
Learning More
COPY
40
Components Guide
Front View
a Lamp (AF Assist Beam: p. 56, Red-Eye Reduction Lamp: p. 114,
Self-Timer Lamp: p. 75)
b Strap Mount (p. 13)
c Hot Shoe (p. 265)
d Flash (p. 73)
e Speaker
f Ring Release Button (pp. 261, 264)
g Ring (p. 264)
h Lens
The LCD monitor may be covered with a thin plastic film for
protection against scratches during shipment. If so, remove the
film before using the camera.
COPY
Components Guide
41
Back View
a Screen (LCD Monitor) (p. 63)
b Viewfinder
c Terminal Cover
d DC Coupler Cable Cover (p. 259)
e Memory Card/Battery Cover (p. 11)
f Tripod Socket
g A/V OUT (Audio/Video output) Terminal (p. 228)
h Remote Terminal (p. 274)
i DIGITAL Terminal (pp. 21, 29)
Using the Optical Viewfinder to Shoot
Turning the LCD monitor off (p. 63) and using the optical viewfinder
can help conserve power while shooting.
• You can adjust the viewfinder with the diopter adjustment dial to
adapt to your vision so that the subject appears in sharp focus
(p. 42). Adjustments of –3.0 to +1.0 m
–1
(dpt) can be made.
• You may be able to see part of the lens through the viewfinder
depending on the zoom setting.
• The viewfinder has a field of vision of approximately 77% of the
actual shooting image.
COPY
42
Controls
a Indicators (p. 45)
b Diopter Adjustment Dial
c (Shortcut)/
(Print/Share) Button
(pp. 21, 31, 155)
d Exposure Compensation Dial
(p. 137)
e Exposure Compensation
Lamp
f ISO Speed Lamp
g Microphone (pp. 194, 195)
h Mode Dial (pp. 17, 24, 90)
i ISO Speed Dial (p. 87)
j Shutter Button (pp. 17, 24)
k Zoom Lever (pp. 68, 159)
Shooting: (Wide Angle)/
(Telephoto)
Playback: (Index)/
(Magnify)
l Power Button/Power Lamp
(pp. 17, 24)
m (Playback) Button (p. 19)
n (AE Lock/FE Lock)/
(Microphone) Button
(pp. 134, 136, 194, 195)
o (Metering Light)/
(Jump) Button (pp. 141,
163)
p FUNC./SET (Function/Set)
Button (p. 47)
q MENU Button (p. 48)
r DISP. (Display) Button (p. 63)
s (AF Frame Selector)/
(Single Image Erase)
Button (pp. 121, 20)
t (Macro)/ Button (p. 74)
u (Manual Focus)/
Button (p. 128)
v (Flash)/ Button (p. 73)
w (Continuous Shooting)/
(Self-Timer)/ Button
(pp. 111, 75)
x Control Dial (p. 43)
COPY
Components Guide
43
Turning the control dial counterclockwise is equivalent to pressing the
button, while turning the control dial clockwise is equivalent to
pressing the button (it is equivalent to pressing the or button
with some functions).
You can perform the following operations when you turn the control
dial.
The Shooting Functions
• Selecting the shooting modes (pp. 24, 91, 104)
• Selecting options in / / / (pp. 73, 74, 111, 75)
• Selecting the FUNC. menu items (p. 47)
• Selecting the shooting direction in Stitch Assist mode (p. 102)
• Selecting the shutter speed and the aperture value (pp. 96, 98)
• Moving the AF Frame (p. 123)
• Adjusting the focus in manual focus mode (p. 130)
• Program Shift (p. 135)
• Metering Mode (p. 141)
The Playback Functions
• Selecting an image (pp. 19, 159, 160, 163)
• Operation when setting/editing (pp. 177, 187, 194, 195, 207, 214)
• Operation when viewing/editing movies (pp. 26, 171, 173)
The Shooting and Playback Functions
• Selecting a menu item and making settings (pp. 47, 48, 230)
• Changing the clock display color (p. 46)
• Setting My Camera contents (p. 230)
Using the Control Dial
Operation is
carried out using
control dial.
COPY
44
The button can turn the camera on/off and switch between the
shooting/playback modes.
* The amount of time before the lens automatically retracts can be set in [Lens Retract]
in the (Set up) menu (p. 60).
Using the Button
Shutter Button
Power Button
Button
Lens retracted*
Press
the button
Press the
power button
Press the shutter
button halfway
Playback Mode
Press the
power button
Lens extended
Press
the button
Shooting Mode
Turning
the Camera Off
COPY
Components Guide
45
The indicators on the back of the camera will light or blink under the
following conditions.
• Upper Indicator
Green : Ready to shoot (camera beeps twice)/when display
off
Blinking Green : Image recording/reading/erasing/transferring
(when connected to a computer/printer)
Orange : Ready to shoot (flash on)
Blinking Orange : Ready to shoot (camera shake warning)
• Lower Indicator
Yellow : Macro mode/Manual focus mode/AF lock mode
Blinking Yellow : Focusing difficulty (camera beeps once)
Indicators
Never do the following while the indicator on the back blinks
green. These actions may corrupt image data.
- Shake or jolt the camera
- Shut off the power, or open the memory card/battery cover
COPY
46
Displaying the Clock
You can display the current date and time
for a 5-second* interval using the following
two methods.
* Default setting.
a Hold the FUNC./SET button down while turning on the power.
b In a shooting/playback mode, hold the FUNC./SET button down
for more than one second.
If you hold the camera horizontally, it displays the time. If you hold it
vertically, the time and date display. If you use method a to display
the clock while holding the camera vertically, however, the clock will
first display as if the camera were being held horizontally.
• You can change the display color by pressing the or button or
turning the control dial.
• The clock display will cease when the display interval is over or
when a button is operated.
• The clock’s display interval can be changed in the menu (p. 60).
• The clock cannot be displayed in the magnified display or the index
playback.
COPY
47
Basic Operations
Settings for the shooting or playback modes or such camera settings
as the print settings, date/time and sounds are set using the FUNC.
menu or the Rec., Play, Print, Set up, My Camera or My Menu menus.
FUNC. Menu ( Button)
This menu sets many of the common shooting functions.
Menus and Settings
1
Set the mode dial to the shooting mode you
want to use.
2
Press the button.
3
Use the or button to select a menu item.
Some items may not be selectable in some shooting modes.
4
Use the or button to select an option for
the menu item.
• Items showing the icon can be changed with the
DISP.
button.
• After selecting an option, you can press the shutter button to
shoot immediately. After shooting, the menu will appear again,
allowing you to adjust the settings easily.
• You can also use the control dial to select an option for the menu item.
5
Press the button.
• This example shows the FUNC.
menu in mode.
2
34
51
Basic Operations
COPY
48
Rec., Play, Print, Set up, My Camera and My Menu
Menus (MENU Button)
Convenient settings for shooting, playback or printing can be set with
these menus.
1
Press the MENU button.
2
Use the or button to switch between menus.
• You can also use the zoom lever to switch between menus.
• The following menus are displayed.
Shooting: Rec./ Set up/ My Camera/ My Menu
Playback: Play/ Print/ Set up/ My Camera
3
Use the or button to select a menu item.
• Some items may not be selectable in some shooting modes.
• You can also use the control dial to select a menu item.
4
Use the or button to select an option.
Menu items followed by an ellipsis (…) can only be set after
pressing the FUNC./SET button to display the next menu. Press
the FUNC./SET button again to confirm the setting and press the
MENU button to return the menu screen.
5
Press the MENU button.
• This example shows the Rec. menu when in mode.
You can switch
between menus with
the or button.
(Set up) Menu
(Rec.) Menu
1
2
3
5
4
(My Camera) Menu
(My Menu) Menu
COPY
49
Basic Operations
Shooting Mode
Information Displayed on the LCD
Monitor and Menus
Available Shooting Modes p. 300
Information Displayed Setting Method
a
White Balance or Recording Pixels,
etc.
FUNC./SET button
(FUNC. menu)
b
Exposure Compensation
(
…
)
Exposure compensation dial
c
Digital Tele-Converter ( 1.7x/
2.2x)/Digital Zoom Factor/
Safety Zoom ( )
MENU button (Rec. menu),
zoom lever
d
Macro ( ) button
e
ISO Speed
()
dial ( in mode)
f
Flash ( ) button
g
Red-Eye Corr. ( ) MENU button
([Flash Control] menu in the Rec.
menu)
h
Drive Mode
()
/ button
Camera Shake ( )
(p. 235)
a
g
Spot AE Point Frame/
AF Frame
p
d
ec
Shutter Speed,
Aperture Value
Exposure Level Indicator
(p. 101)
q
h
n
f
b i
j
Battery Charge Indicator
l
k
t
or
Av/Tv bar (pp. 96, 98)
Histogram (p. 52)
s
Recordable Shots (Stills)/
Remaining Time/Elapsed Time
(Movies)
m
COPY
50
i
Auto Rotate ( ) MENU button (Set up menu)
j
Shooting Mode Mode dial, control dial
k
Image Stabilization
()
MENU button (Rec. menu)
l
i-Contrast ( ) MENU button (Rec. menu)
m
Audio ( ) MENU button (Set up menu)
n
Create Folder ( ) MENU button (Set up menu)
o
Time Zone ( ) MENU button (Set up menu)
p
Manual Focus ( ) MF button
q
Metering Mode ( ) button
r
Exposure Shift Bar ( ) button
s
AE Lock/FE Lock button
t
Display Overlays MENU button (Rec. menu)
About the Battery Charge Indicator
• The following icons and message will display.
Information Displayed Setting Method
Display on the LCD monitor Summary
Sufficient battery charge.
Recharge the battery as soon as possible
if you plan on using the camera for an
extended period.
(blinking red) Low battery charge. Recharge the battery.
Change the battery pack.
Battery is depleted and the camera can no
longer operate. Charge the battery
immediately.
COPY
51
Basic Operations
Playback Mode (Detailed)
If the indicator blinks orange and the camera shake warning
icon ( ) displays, this indicates that a slow shutter speed may
have been selected due to insufficient illumination. Use the
following methods to shoot:
- Set the IS mode to any setting other than [Off] (p. 85)
- Raise the ISO speed (p. 87)
- Use the Auto ISO Shift (p. 88)
- Select a flash setting other than (p. 73)
- Attach the camera to a tripod or other device
Information Displayed Setting Method
u
Print List button,
MENU button (Print menu)
v
(Playback) i-Contrast/Red-Eye
Correction Function/Trimming/Resized
image/My Colors ( )
Protection Status ( )
MENU button (Play menu)
Image with Sound Memo ( ) button
w
Compression (Still Images)/Recording
Pixels (Still Images), Movie ( )
FUNC./SET button (FUNC.
menu)
x
Auto Category ( ) MENU button (Rec. menu)
My Category ( ) MENU button (Play menu)
v
Shooting Date/Time
Battery Charge Indicator
Displayed image number/
Total number of images
Folder Number-File
Number
Shooting information
Histogram
x
w
u
File Size
Recording Pixels (Stills)/
Recording Length
(Movies)
COPY
52
The following information may also be displayed with some images.
A sound file in a format other than the WAVE format is attached or the
file format is not recognized.
JPEG image not conforming to Design rule for Camera File System
Standards (p. 279).
AVI data type
Unrecognized data type
z Information for images shot on other cameras may not
display correctly.
z Overexposure Warning
In the following cases, overexposed portions of the image
blink.
- When reviewing an image right after shooting in the LCD
monitor (information view).
- When using the detailed display mode during playback.
Histogram Function
The histogram is a graph that allows you to check the brightness of
an image. You can also display the histogram in the , , and
modes to check the brightness while shooting. The greater the
bias toward the left in the graph, the darker the image. The greater
the bias toward the right, the brighter the image. By using the
exposure compensation function, you can correct the image
brightness before shooting (p. 137).
Sample Histograms
Balanced ImageDark Image Bright Image
You can change the shutter speed, aperture value and ISO
speed to adjust the brightness of an image in the mode.
COPY
53
Basic Operations
Shooting Mode
Settings using the , , MF, or / button
Settings using the ISO Speed Dial or Exposure
Compensation Dial
Menu Item Options
Reference
Page
Still Image
pp. 17, 90
Movie pp. 24, 104
Menu Item Options
Reference
Page
Metering Mode p. 141
Macro p. 74
Manual Focus p. 130
Flash p. 73
Drive Mode
( will also display in
movie mode.)
pp. 111, 75
Menu Item Options
Reference
Page
ISO Speed p. 87
Exposure Compensation
…
p. 137
COPY
55
Basic Operations
Rec. Menu
Menu Item Options
Summary/
Reference Page
AF Frame
p. 121/ Face Detect*/AiAF/Center
/ / / FlexiZone*/Face Detect/AiAF
AF-Point Zoom On/Off* p. 116
Servo AF On/Off* p. 127
AF Mode Continuous*/Single p. 120
Digital Zoom
p. 69
(Still image) Standard*/Off/1.7x/2.2x
(Movie) Standard*/Off (In standard movie
mode only)
Flash Control
p. 113
Flash Mode Auto*/Manual
Flash Exp.
Comp
–2 to 0* to +2
Flash Output Minimum*/Medium/Maximum
Shutter Sync. 1st-curtain*/2nd-curtain
Slow Synchro
On/Off*
Red-Eye Corr. On/Off*
Red-Eye Lamp On*/Off
Safety FE On*/Off
i-Contrast Off*/Auto p. 138
Drive Settings FaceSelf-Timer: 1 – 10 (Default
is 3 shots)
Self-Timer: 10 sec.*, 2 sec.,
Custom Timer
Delay: 0 – 10*, 15, 20, 30 sec.
Shots: 1 – 10 (Default is 3 shots)
p. 75
Spot AE Point Center*/AF Point p. 142
Safety Shift
On/Off* p. 97
* Default setting
COPY
56
*1 Default setting for LCD monitor 1.
*2 Default setting for LCD monitor 2.
Auto ISO Shift On/Off* p. 88
MF-Point Zoom On*/Off p. 130
Safety MF On*/Off p. 131
AF-assist Beam On*/Off p. 40
Review
(Rec. Review)
Off/2* – 10 seconds/Hold You can set the
length of time
images display after
being shot (p. 18).
Review Info Off*/Detailed/Focus Check p. 118
Record + On/Off* p. 84
Save Original On/Off* p. 153
Auto Category On*/Off p. 154
IS Mode
p. 85
(Still image) Continuous*/Shoot Only/
Panning/Off
(Movie) Continuous*/Off
Converter Off*/TC-DC58D p. 263
Custom Display
p. 66
LCD/
Viewfinder
//
Shooting info. Off*
1
/On*
2
Grid Lines Off*
1
/On*
2
3:2 Guide Off*
1
*
2
/On
Histogram Off*
1
/On*
2
Set Shortcut
button
*
p. 155
Save Settings / p. 109
Menu Item Options
Summary/
Reference Page
COPY
58
Print Menu
Menu Item Options
Reference
Page
Print Displays the print menu. –
Select Image &
Qty.
Configures print settings for individual
images as you view them.
p. 207
Select Range Selects a range of sequential images and
makes print settings for all the images in
that range.
Select by Date Configures print settings for images
corresponding to the selected date.
Select by Category Configures print settings for images in
the selected category.
Select by Folder Configures print settings for images in
the selected folder.
Select All Images Configures print settings for all images.
Clear All Selections Removes all print settings from images.
Print Settings Sets the print style.
COPY
59
Basic Operations
Set up Menu
Menu Item Options Summary/Reference Page
Mute On/Off
*
Set to [On] to silence all
operation sounds (except for
when the memory card/battery
cover is opened during
recording).
Volume Off/ 1 / 2*/ 3 / 4 / 5 Adjusts the volume of the start-up
sound, operation sound, self-
timer sound, shutter sound and
playback sound. The volume
cannot be adjusted if [Mute] is set
to [On].
Start-up Vol. Adjusts the volume of the start-up
sound when the camera is turned
on.
Operation
Vol.
Adjusts the volume of the
operation sound that beeps when
any button other than the shutter
button is pressed.
Selftimer Vol. Adjusts the volume of the self-
timer sound played 2 sec. before
the shutter is released.
Shutter
Volume
Adjusts the volume of the sound
played when the shutter
releases. The shutter sound does
not play when a movie is
recording.
Playback Vol. Adjusts the volume of movie
sounds, sound memos or sound
recorder.
Audio
p. 108
Mic Level Auto*/Manual
Level –40 – 0 dB
Wind Filter On/Off*
* Default setting
COPY
60
LCD Brightness –7 to 0 * to +7 Use the or button to adjust
the brightness.
You can check the brightness in
the LCD monitor while you are
adjusting the setting.
Power Saving
p. 216
Auto Power
Down
On*/Off
Display Off 10 sec./20 sec./30
sec./1 min.*/ 2 min./
3min.
Time Zone Home*/World p. 217
Date/Time p. 14
Clock Display 0 – 5* – 10 sec./
20 sec./30 sec./
1 min./2 min./3 min.
p. 46
Format p. 16 (You can also select a low
level format (p. 220).)
File Numbering Continuous*/
Auto Reset
p. 221
Create Folder
p. 223
Create New
Folder
Check mark (On)/
No check mark (Off)
Auto Create Off*/Daily/Monday-
Sunday/Monthly
(Creation time also
can be set)
Auto Rotate On*/Off p. 225
Distance Units m/cm*/ ft/in Sets the units for the Zoom bar
(p. 68) and the MF indicator
distance unit (p. 130).
Lens Retract 1 minute*/0 seconds Sets the lens retraction timing
when switching from shooting
mode to playback mode.
Language p. 15
Menu Item Options Summary/Reference Page
COPY
61
Basic Operations
Print Method
The connection method with the printer can be changed for printing. Although it is
normally not necessary to change the setting, select when borderless printing an
image shot in (Widescreen) mode on wide size paper using Canon compact photo
printer SELPHY CP750/CP740/CP730/CP720/CP710/CP510. As this setting will be
stored to memory even when the power is turned off, to print using an image size other
than , return the mode to [Auto] (however, the connection method cannot be
changed while connected to a printer).
Video System NTSC/PAL p. 228
Print Method Auto*/ See below.
Reset All p. 227
Menu Item Options Summary/Reference Page
COPY
62
My Camera Menu
My Menu
Menu Item Options
Reference
Page
Theme Selects a common theme for each My
Camera settings item.
p. 230
Start-up Image Sets the image displayed when the
camera power is turned on.
Start-up
Sound
Sets the sound played when the
camera power is turned on.
Operation
Sound
Sets the sound played when any button
other than the shutter button is pressed.
Selftimer
Sound
Sets the sound played 2 seconds
before the shutter releases in self-timer
mode.
Shutter Sound Sets the sound played when the shutter
button is pressed. (There is no shutter
sound for movies.)
My Camera Menu
Contents
(Off)/ */ /
Menu Item
Reference
Page
My Menu Settings p. 157
* Default setting
COPY
63
Basic Operations
Switching LCD Monitor Display Modes
Each press of the DISP. button, changes the display mode of the LCD
monitor. See Information Displayed on the LCD Monitor and Menus for
details (p. 49).
(The following are the screens that display when shooting in
mode.)
Shooting Mode (The screens that display vary depending on the
[Custom Display] settings (p. 66).)
The LCD Monitor Display
Off
No Information Information View
COPY
64
Playback Mode or Rec. Review (Right After Shooting)
z The LCD monitor does not shut off in the ( , , ),
or mode.
z The LCD monitor will not switch to the detailed display or
focus check display in magnified display (p. 159), or index
playback mode (p. 160).
No Information Standard Display*
* Playback mode only
Focus Check*
* Still image only
Detailed Display
COPY
65
Basic Operations
LCD Monitor Brightness
The brightness of the LCD monitor can be changed in the following two
ways.
• Changing settings using the Set up menu (p. 59)
• Changing settings using the DISP. button (Quick-bright LCD
Function)
You can set the LCD monitor to the brightest setting regardless of the
option selected in the Set up menu by pressing the DISP. button for
more than one second*.
• To restore the previous brightness setting, press the DISP. button
for more than one second again.
• The next time you turn on the camera, the LCD monitor will be at
the brightness setting selected in the Set up menu.
* You cannot change the brightness of the LCD monitor with this function if you have
already set it to its highest setting in the Set up menu.
Night Display
When shooting at dusk or during the evening when the dark
surroundings make it difficult to view the LCD monitor, the camera’s
“night view” option displays the subject brightly in the LCD monitor.
This will allow you to compose a shot even in dark environments (this
setting cannot be turned off).
* Although noise may appear and the movement of the subject shown on the LCD
monitor may appear somewhat jagged, there is no effect on the recorded image.
The brightness of the image displayed in the monitor, and the brightness of the
actual image recorded will be different.
COPY
66
You can select which LCD monitor display modes are enabled when
the DISP. button is pressed, as well as select which of the following
information is displayed in each mode.
Customizing Display Information
Available Shooting Modes p. 300
LCD/Viewfinder
(//)
Select whether to enable or disable each of the display
modes for the LCD (Display 1/Display 2/No display).
The display switches between each enabled display
mode with each press of the DISP. button (p. 63). A
display mode that is disabled will not appear when you
press the DISP. button.
Shooting Info Displays shooting information (p. 49).
Grid Lines Displays grid lines to divide the screen into 9 parts.
Helps confirm the vertical and horizontal positioning of
the subject (p. 49).
3:2 Guide Helps confirm the print area for a 3:2 print*. Areas
outside the printable area are grayed out (p. 49).
* Images are still recorded at the standard aspect ratio of 4:3.
Histogram Shooting Mode: / / /
Displays histogram (pp. 49, 52).
1
Select [Custom Display].
1. Press the MENU button.
2. In the menu, use the or
button to select [Custom Display].
3. Press the button.
COPY
67
Basic Operations
2
Select [LCD/Viewfinder].
1. Use the , , or button to
select , or .
• Sets LCD monitor display mode after
the DISP. button is pressed.
• If you do not wish to change the
display mode, press the DISP. button
to display ( / / ).
• You cannot add to the current
active LCD/Viewfinder icon.
3
Make settings.
1. Use the , , or button to
select the items you wish to display
on the LCD monitor.
2. Press the button to place a
3
mark.
3. Press the MENU button.
• Even though items that are grayed out can be set, they will not
display in certain shooting modes.
• Display locations with no
3
marks will not have any information
displayed.
If you press the shutter button halfway and return to the
shooting screen from the custom display settings screen, the
settings will not be saved.
Display 1
Display Off
Display 2
Current active display
Items with
3
are displayed.
COPY
68
Commonly Used Shooting Functions
The zoom can be adjusted from 28 – 140 mm (focal length) in 35mm
film equivalent terms.
You can also use the control dial to select shooting modes or FUNC.
menu options. See p. 43.
Using the Optical Zoom
1
Press the zoom lever toward
or .
• Telephoto: Zooms in on the subject.
• Wide Angle: Zooms out from the
subject.
Focus range (approx.)
Zoom bar
COPY
69
Commonly Used Shooting Functions
You can combine digital zoom with optical zoom when shooting.
The available shooting characteristics and focal lengths (35mm film
equivalent) are as follows.
Using the Digital Zoom/
Digital Tele-Converter
Available Shooting Modes p. 300
Selection Focal Length Shooting Characteristics
Standard 28 – 560 mm
Enables shooting at zoom factors of up to
20x with digital and optical zoom combined.
Off 28 – 140 mm Enables shooting without digital zoom.
1.7x 47.6 – 238 mm
Digital zoom is fixed at the selected zoom
factor, and the focal length shifts to
maximum telephoto.
This enables a faster shutter speed and
less chance of camera shake than a shot
taken at the same angle of view with
[Standard] or [Off].
2.2x 61.6 – 308 mm
COPY
70
About the Safety Zoom
Depending on the number of recording pixels set, you can shift from
optical zoom to digital zoom without pausing up to a factor where the
image quality does not deteriorate (Safety Zoom). displays when
reaching the maximum zoom factor without image deterioration.
Pressing the zoom lever toward again allows you to zoom even
further (not available in ).
Depending on the number of recording pixels set, the Safety Zoom
zone (factor) varies as follows ( : the number is the zoom factor
at which zooming pauses).
z The digital zoom cannot be used when the LCD monitor is
turned off.
z The digital zoom cannot be used in or mode.
Recording pixels
Optical zoom
Digital zoom
The color of
the zoom bar
White ( ) Yellow ( ) Blue ( )
Zone without deterioration
Zone with
deterioration
COPY
71
Commonly Used Shooting Functions
Shooting with the Digital Zoom
1
Select [Digital Zoom].
1. Press the MENU button.
2. In the menu, use the or
button to select [Digital Zoom].
2
Make settings.
1. Use the or button to select
[Standard].
2. Press the MENU button.
3
Press the zoom lever toward and shoot.
• The combined digital and optical zoom factor will display in the
LCD monitor.
• The image may appear coarse depending upon the selected
recording pixels. The zoom factor appears in blue in this case.
• Press the zoom lever toward to zoom out.
Optical zoom (White)
Digital zoom (Yellow/Blue)
Combined optical and
digital zoom
Approximately
2 seconds later
Focus range (approx.)
COPY
72
Shooting with the Digital Tele-Converter
The digital tele-converter feature uses digital zoom to achieve the
effects of a tele-converter (a lens used in telephoto shooting).
1
Select [Digital Zoom].
1. Press the MENU button.
2. In the menu, use the or
button to select [Digital Zoom].
2
Make settings.
1. Use the or button to select
[1.7x] or [2.2x].
2. Press the MENU button.
3
Adjust the zoom level with
the zoom lever and shoot.
• and the zoom factor appear on the
LCD monitor.
• The image may appear coarse
depending upon the selected
recording pixels (the icon and the
zoom factor appear in blue).
COPY
73
Commonly Used Shooting Functions
Using the Flash
Available Shooting Modes p. 300
1
Press the button.
1. Use the or button to change the
flash mode.
: [Auto]
: [On]
: [Off]
• You can configure detailed settings for the flash when you press
the MENU button while this screen is displayed (p. 113).
You are recommended to shoot with the camera attached to a
tripod or other device if the camera shake warning icon
appears.
COPY
74
Use this mode to shoot close-ups of flowers or small items. The image
area at the minimum shooting distance from the end of the lens to the
subject (1 cm (0.39 in.)) is 32 × 23 mm (1.26 × 0.91 in).
To Cancel the Macro Mode:
Press the button and use the or button to select (Normal).
Shooting Close-ups (Macro)
Available Shooting Modes p. 300
1
Press the button.
1. Use the or button to select .
• The zoom bar will display while you
adjust the zoom.
The zoom bar disappears after
approx. 2 seconds.
You can decrease the size of the AF frame to make focusing on
specific parts of an object easier (p. 124).
z Use the LCD monitor to compose close-ups in macro mode
since images composed with the viewfinder may be off-
center.
z Using the flash in macro mode may cause image edges to
darken.
Focus range (approx.)
COPY
75
Commonly Used Shooting Functions
You can set the time delay and the number of shots you wish to take in
advance.
, ,
Using the Self-Timer
Available Shooting Modes p. 300
10 sec.
Self-Timer
Shoots 10 seconds after you press the shutter button.
• 2 seconds before the shutter releases, the self-timer lamp
and sound speed up.
2 sec.
Self-Timer
Shoots 2 seconds after you press the shutter button.
• When you press the shutter button, the self-timer sound
beeps quickly, the lamp blinks, and the shutter releases
2 seconds later.
Custom
Timer
You can change the delay time (0 – 10, 15, 20, 30 sec.) and
number of shots (1 – 10).
• When a delay time of over 2 seconds is set for the [Delay]
option, the self-timer sound beeps quickly 2 seconds before
the shutter releases. If multiple shots have been specified for
the [Shots] option, the sound will play for the first shot only.
Face
Self-Timer
When you press the shutter button, the camera shoots 2
seconds after a new face is detected within the composition.
You can change the number of shots (1 – 10).
• The self-timer sound beeps rapidly and the lamp blinks when
a new face is detected, and the shutter releases 2 seconds
later.
1
Select [Drive Settings].
1. Press the MENU button.
2. In the menu, use the or
button to select [Drive Settings].
3. Press the button.
COPY
76
To Cancel the Self-Timer:
Follow Step 1 to select .
Changing the Delay Time and Number of Shots ( )
2
Make settings.
1. Use the or button to select
[Self-Timer].
2. Use the or button to set.
3. Press the button.
4. Press the MENU button.
3
Press the button.
1. Use the or button to select the
self-timer mode.
• Pressing the MENU button while this
screen is displayed will display the
[Drive Settings] screen in Step 2.
4
Shoot.
• When you press the shutter button fully, the self-timer lamp will
blink.*
* When [Red-Eye Lamp] is set to [On] in [Flash Control] (p. 113), the lamp will
light 2 seconds before the flash fires.
1
Select [Drive Settings].
1. Press the MENU button.
2. In the menu, use the or
button to select [Drive Settings].
3. Press the button.
COPY
77
Commonly Used Shooting Functions
(Using the FaceSelf-Timer)
2
Make settings.
1. Use the or to select [Self-
Timer], and the or button to
select .
2. Use the or button to select
[Delay] or [Shots] and the or
button to change the settings.
3. Press the button.
4. Press the MENU button.
If the [Shots] option is set to 2 or more shots, the following
occurs.
- The exposure and white balance are locked at the settings
selected for the first shot.
- If the flash is used, the interval between shots lengthens.
- The interval between shots may lengthen when the built-in
memory of the camera fills.
- Shooting will automatically cease if the memory card
becomes full.
1
Select .
1. Press the button.
2. Use the or button to
select .
COPY
78
2
Set the number of shots.
1. Press the MENU button.
2. In the menu, use the or
button to select [Drive Settings].
3. Press the button.
4. Use the or button to select
[FaceSelf-Timer].
5. Use the or button to set a
value.
6. Press the button.
7. Press the MENU button.
• You can set the number of shots by
pressing the MENU button while the screen in Step 1 is
displayed.
3
Compose the image and
press the shutter button
halfway.
• A green frame appears around the
face of the main subject, while white
frames appear around the other
faces.
4
Press the shutter button fully to shoot.
• The camera prepares to shoot, and the “Look straight at camera
to start count down” message appears.
• The self-timer lamp will blink and self-timer sound will beep.
COPY
79
Commonly Used Shooting Functions
5
Have the other subject enter the composition
and face the camera.
• When the new face is detected, the blinking of the self-timer
lamp and the self-timer sound speed up, and the shutter
releases approx. 2 seconds later.
• When the number of shots is set to 2 or more, pictures will
continue to be taken at approximately 2-second intervals.
• If the subject enters the composition but the camera does not
detect the face, the shutter will release approx. 30 seconds
later.
See Face Detect Feature (p. 122) for details on face detection.
COPY
80
Approximate Values for Recording Pixels
: Approximate values for recording pixels with decimal fractions rounded off
(*1 rounded up to two significant figures according to CIPA standards). M is short for
megapixels.
*2 Paper sizes vary according to region.
Changing the Recording Pixels
(Still Images)
Available Shooting Modes p. 300
1
Select the recording pixels.
1. Press the button.
2. Use the or button to select
and the or button to change
the recording pixels.
3. Press the button.
Recording Pixels Purpose
*
2
Large
15M
*
1
4416 × 3312
High
Low
Printing to about A2 size (Approx.
420 × 594 mm (16.5 × 23.4 in.))
Medium 1 9M
3456 × 2592
Printing to about A3 size (Approx.
297 × 420 mm (11.7 × 16.5 in.))
Medium 2 5M
2592 × 1944
Printing to about A4 size (Approx.
210 × 297 mm (8.3 × 11.7 in.))
Printing to about Letter size prints
216 × 279 mm (8.5 × 11 in.)
Medium 3 2M
1600 × 1200
Printing postcard-size prints
148 × 100 mm (6 × 4 in.)
Printing L-size prints 119 × 89 mm
(4.7 × 3.5 in.)
Small 0.3M
640 × 480
Sending images as e-mail
attachments or shooting more
images
Widescreen
4416 × 2480
Printing wide size prints (Images are
recorded with 16:9 aspect ratios. Areas
not recorded will display as black bars
on the LCD monitor.)
RAW 4416 × 3312 p. 82
COPY
81
Commonly Used Shooting Functions
Approximate Values for Compression Settings
See Memory Cards, Estimated Capacities and Image Data
Sizes (Estimated) (p. 282).
Changing the Compression (Still Images)
Available Shooting Modes p. 300
1
Select a compression
setting.
1. Press the button.
2. Use the or button to select
and the or button to change
the option.
3. Press the button.
Compression Purpose
Superfine
High Quality
Normal
Shoot higher quality images.
Fine Shoot normal quality images.
Normal Shoot more images.
See Memory Cards, Estimated Capacities and Image Data
Sizes (Estimated) (p. 282).
COPY
82
This camera records images as either JPEG images or RAW images.
JPEG image (/////)
When pictures are taken as JPEG images, the images are processed
inside the camera for optimum image quality, and also compressed to
allow a larger number of images to be stored on the memory card.
However, the compression process is irreversible, meaning that the
original image data cannot be recovered once it has been compressed.
See Changing the Recording Pixels (Still Images) and Changing the
Compression (Still Images) (pp. 80, 81).
RAW image ( )
RAW data is the data output by the imaging element and converted to
digital data which is recorded as is. This results in images with almost
no deterioration in image quality and a higher quality than JPEG
images. Using the supplied software (Digital Photo Professional), you
can broadly adjust images without deterioration in image quality. Using
the software’s image processing functions, you can take the adjusted
image data and convert it a JPEG, TIFF or other type of image in line
with your intended use.
You cannot use direct print or make print (DPOF) settings with images
taken with , however.
Changing the Image Type
Available Shooting Modes p. 300
When downloading RAW images and simultaneously recorded
JPEG images, be sure to use the supplied software.
COPY
83
Commonly Used Shooting Functions
1
Select .
1. Press the button.
2. Use the or button to select
and the or to select .
3. Press the button.
COPY
84
Simultaneously Recording RAW and JPEG
Images
1
Select [Record + ].
1. Press the MENU button.
2. In the menu, use the or
button to select [Record + ].
2
Make settings.
1. Use the or button to select
[On] or [Off].
2. Press the MENU button.
On
Two images, a RAW image ( ) and a JPEG image ( /
Large, Fine), will be recorded with each shot. Since a image
is also recorded, you can print the image, or view it on a
computer, without using the supplied software. Both images are
saved with the same file number to the same folder, and can be
distinguished by their file extension. images end with “.CR2”,
while images end with “.JPG”.
Off Only RAW images are recorded.
COPY
85
Commonly Used Shooting Functions
The lens-shift type image stabilizer function allows you to minimize the
camera shake effect (blurred images) when you shoot distant subjects
that have been magnified or when you shoot in dark conditions without
a flash.
* If you are using a converter lens (sold separately) and the [Converter] setting is
enabled, the icons that appear will differ (p. 263).
Setting the Image Stabilizer Function
Available Shooting Modes p. 300
Options
Display on the
LCD monitor*
Summary
Off
–
Continuous
Since IS mode runs continuously, you can
check the effect it has on image blur on the
LCD monitor. This makes it easier to
compose images and focus on subjects.
Shoot Only
This mode is only activated when the shutter
button is pressed. When set to [Continuous],
some blurring may be noticeable depending
on the subjects, however in Shoot Only
mode, subjects can be taken without concern
for any unnatural movement that may appear
on the LCD monitor.
Panning
This option only stabilizes the effect of up
and down camera motions on the image.
This option is recommended for shooting
objects moving horizontally.
1
Select [IS Mode].
1. Press the MENU button.
2. In the menu, use the or
button to select [IS Mode].
COPY
86
2
Make settings.
1. Use the or button to select the
image stabilizer settings.
2. Press the MENU button.
z Camera shake may not be fully corrected when shooting
with slow shutter speeds, such as with evening shots. Use
the Auto ISO Shift (p. 88), or attach the camera using a
tripod to shoot. When you shoot with the camera attached to
a tripod, we recommend you set [IS Mode] to [Off].
z If camera shake is too strong, it may not be fully corrected.
z Hold the camera horizontally while [Panning] (stabilization
does not work when the camera is held vertically).
z If you shoot a movie after setting [IS Mode] to [Shoot Only]
or [Panning], the setting will change to [Continuous].
COPY
87
Commonly Used Shooting Functions
Raise the ISO speed to use a fast shutter speed when you wish to
reduce the effects of camera shake or avoid blurry subjects, or to turn
the flash off when shooting in a dark area.
Adjusting the ISO Speed
Available Shooting Modes p. 300
1
Select an ISO Speed.
1. Select an ISO speed turning the ISO
speed dial.
• When selecting a settable ISO speed, the
ISO speed lamp will light orange.
• If you select an ISO speed that cannot be
set, the ISO speed lamp turns off and the
ISO speed is automatically set to ( in mode).
• When you select (Auto) or (High ISO Auto), the camera
sets the optimal ISO speed for the light level when shooting. As
the ISO speed will automatically be raised in dark places,
shutter speed will increase, reducing camera shake and subject
blurring.
• Select to put priority on image quality.
• When you select , the camera also detects motion and sets
the optimum ISO speed. As the shutter speed becomes even
faster*, camera shake and blurred photos caused by subject
movement will be reduced even more than when shooting the
same scene in .
* Noise may increase in the captured image compared to ISO AUTO.
z You can set the ISO speed to (p. 94).
z The camera automatically applies noise reduction
processing when you shoot at a high ISO speed.
z If the camera is set at or , the ISO speed automatically
set by the camera will be displayed when pressing the
shutter button halfway or in playback information.
COPY
88
When the camera shake warning icon ( ) appears during shooting,
this function allows you to increase ISO speed and to shoot at a shutter
speed which minimizes the effects of camera shake by pressing the
button.
Reducing Camera Shake When Shooting
(Auto ISO Shift)
Available Shooting Modes p. 300
z In , or mode, it will not function when the flash
fires.
z Depending on shooting conditions, the camera shake
warning icon ( ) may continue to display even if the ISO
speed is increased.
1
Select [Auto ISO Shift].
1. Press the MENU button.
2. In the menu, use the or
button to select [Auto ISO Shift].
2
Make settings.
1. Use the or button to select
[On].
2. Press the MENU button.
COPY
89
Commonly Used Shooting Functions
3
Press the shutter button
halfway.
• When is displayed, the button
lights in blue.
4
Press and hold the shutter
button halfway, then press
the button.
• The ISO speed after adjustment is
displayed.
• While pressing the shutter button
halfway, pressing the button
again will return the ISO speed to its original condition.
• When the AE lock (p. 134) is activated after the ISO speed is
raised, the ISO speed will not return to its original setting even if
you release the shutter button (at this time, the button turns
off).
5
Press the shutter button fully to shoot.
COPY
90
Shooting Using the Mode Dial
The camera automatically selects settings.
: Auto (p. 17)
Image zone
When a shooting mode appropriate for the shooting conditions is selected,
the camera automatically adjusts settings for optimal shooting (p. 91).
: Special Scene (p. 91)
: Portrait : Landscape
: Night Scene : Sports
: Night Snapshot : Kids&Pets
: Indoor : Sunset
: Foliage : Snow
: Beach : Fireworks
: Aquarium : Underwater
: ISO 3200 : Color Accent
: Color Swap
: Stitch Assist (p. 102)
: Movie (pp. 24, 104)
Creative Zone
You can freely select camera settings such as the shutter speed and
aperture value to suit your shooting purposes.
: Program AE (p. 95)
: Setting the Shutter Speed (p. 96)
: Setting the Aperture (p. 98)
: Manually Setting the Shutter Speed and Aperture (p. 100)
, : Saving Custom Settings (p. 109)
Mode Dial
Creative zone
Image zone
COPY
91
Shooting Using the Mode Dial
When a shooting mode appropriate for the shooting conditions is
selected, the camera automatically adjusts settings for optimal
shooting.
Shooting Modes for Specific Scenes
Available Shooting Modes p. 300
1
Set the mode dial to .
2
Select the scene mode.
1. Use the control dial to select the
scene mode.
Portrait
Produces a soft effect when photographing people.
Landscape
Optimized for shooting landscape scenes which
contain both near and far subjects.
COPY
92
Night Scene
Allows you to capture people against the backdrop
of an evening sky or night scene. The flash is
directed at the person and the shutter speed is slow,
so both the person and the background can be
beautifully shot. Be sure to set the flash to
before shooting.
Sports
Shoots continuous images with autofocus. Well
suited for shooting moving subjects.
Night Snapshot
Allows you to take snapshots of people against
twilight or night backgrounds by reducing the effects
of camera shake when firmly holding the camera,
even without using a tripod.
Kids&Pets
Allows you to capture subjects that move around,
such as children and pets, without missing photo
opportunities.
Indoor
Prevents camera shake and maintains the subject’s
true color when shooting under fluorescent or
tungsten lighting.
Sunset
Allows you to shoot sunsets in vivid colors.
COPY
93
Shooting Using the Mode Dial
Foliage
Shoots trees and leaves - such as new growth,
autumn leaves or blossoms - in vivid colors.
Snow
Shoots without a blue tinge and without making
people appear dark against a snowy background.
Beach
Shoots without making people appear dark near
water or sand where reflected sunlight is strong.
Fireworks
Captures fireworks in the sky sharply and at optimal
exposure.
Aquarium
Selects the optimal ISO speed and white balance to
capture fish and other items in an indoor aquarium.
Underwater
Appropriate for shooting images with Waterproof
Case WP-DC28 (sold separately). This mode uses
an optimal white balance setting to reduce bluish
tones and record images with a natural hue. The
flash is also reduced as much as possible for the
shooting circumstances.
COPY
94
ISO 3200
Selects the highest possible ISO speed (3200, twice
the ISO 1600 speed) and increases the shutter
speed to minimize blurring of moving subjects and
camera shake, even in low light conditions.
Recording pixels are fixed at (1600 × 1200).
Color Accent
Use this option to have only the color specified in
the LCD monitor remain and to transform all others
to black and white (p. 149).
Color Swap
Use this option to transform a color specified in the
LCD monitor into another (p. 151).
z The shutter speed is slow in or mode. Always use a
tripod to avoid camera shake.
z In , , , , , , or mode, the ISO speed
may increase and cause noise in the image depending on
the scene being shot.
z With , image noise may be prominent.
To shoot underwater, install the camera in Waterproof Case
WP-DC28 (sold separately). We recommend you use it for rain,
shooting at ski resorts or beaches.
COPY
95
Shooting Using the Mode Dial
The camera automatically sets the shutter speed and aperture value to
match the brightness of the scene. You can set the ISO speed,
exposure compensation and white balance.
Program AE
Available Shooting Modes p. 300
1
Set the mode dial to .
2
Shoot.
z When a correct exposure cannot be obtained, the shutter
speed and aperture values are shown in red on the LCD
monitor when the button is pressed halfway. Use the
following shooting methods to obtain the correct exposure
and make them show in white.
- Use the flash (p. 73)
- Adjust the ISO Speed (p. 87)
- Use the Auto ISO Shift (p. 88)
- Change the metering method (p. 141)
- Set the ND filter to [On] (p. 140)
z You can change the combinations of shutter speeds and
aperture values without altering the exposure (p. 135).
COPY
96
When you set the shutter speed, the camera automatically selects an
aperture value to match the brightness.
Faster shutter speeds allow you to catch an instantaneous image of a
moving subject, while slower speeds create a flowing effect and allow
you to shoot without a flash in dark areas.
Setting the Shutter Speed
Available Shooting Modes p. 300
1
Set the mode dial to .
2
Configure the shutter speed.
1. Use the control dial to change the
shutter speed.
• When using the control dial, the
bar will be displayed and the shutter
speed can be changed.
3
Shoot.
• If the aperture value is shown in red, the image is underexposed
(insufficient light) or overexposed (too much light). Use the
control dial to adjust the shutter speed until the aperture value
shows in white (you can also use the Safety Shift (p. 97)).
Shutter speed
bar
COPY
97
Shooting Using the Mode Dial
The nature of CCDs is such that noise in the recorded image
increases at slow shutter speeds. This camera, however,
applies special processing to images shot at shutter speeds
slower than 1.3 seconds to eliminate the noise, thereby
producing high-quality images. (However, a certain amount of
processing time may be required before the next image can be
shot.)
z The shutter speed, zoom and aperture value have the
following relationship.
z The fastest shutter speed for flash synchronization is 1/500
second*. Therefore, even if the shutter speed is preset to a
speed higher than 1/500 second, the camera automatically
resets the shutter speed to 1/500 second during shooting.
* When using an external flash, see pp. 266, 267.
Shutter Speed Display
z The following shutter speeds can be set. 1/160 indicates
1/160 second. Also, 0"3 indicates 0.3 second and 2"
indicates 2 seconds.
z You can change the combinations of shutter speeds and
aperture values without altering the exposure (p. 135).
Safety Shift
With and modes, if [Safety Shift] is turned [On] (p. 55) in the
menu, the shutter speed or aperture value is automatically
adjusted for the correct exposure when it cannot be otherwise
obtained. Safety Shift is disabled when the flash is enabled.
Aperture Value
Shutter Speed (seconds)
Maximum Wide Angle
f/2.8 – 3.5 15 – 1/2000
f/4.0 – 5.0 15 – 1/2500
f/5.6 – 8.0 15 – 1/4000
Maximum Telephoto
f/4.5 – 5.6 15 – 1/2000
f/6.3 – 8.0 15 – 1/2500
15" 13" 10" 8" 6" 5" 4" 3"2 2"5 2" 1"6 1"3 1" 0"8 0"6 0"5 0"4 0"3
1/4 1/5 1/6 1/8 1/10 1/13 1/15 1/20 1/25 1/30 1/40 1/50 1/60
1/80 1/100 1/125 1/160 1/200 1/250 1/320 1/400 1/500 1/640
1/800 1/1000 1/1250 1/1600 1/2000 1/2500 1/3200 1/4000
COPY
98
The aperture adjusts the amount of light entering through the lens.
When you set the aperture value, the camera automatically selects a
shutter speed to match the brightness.
Selecting a lower aperture value (opening the aperture) allows you to
blur the background and create a beautiful portrait.
A higher aperture value (closing the aperture) brings the entire range
from foreground to background into focus. The larger the aperture
value, the greater the range of the image brought into clear focus.
Setting the Aperture
Available Shooting Modes p. 300
1
Set the mode dial to .
2
Configure the aperture
setting.
1. Use the control dial to change the
aperture value.
• When using the control dial, the
bar will be displayed and the aperture
value can be changed.
3
Shoot.
• If the shutter speed is shown in red when the shutter button is
pressed halfway, the image is underexposed (insufficient light)
or overexposed (too much light). Use the control dial to adjust
the aperture value until the shutter speed shows in white (you
can also use the Safety Shift (p. 97)).
Aperture value
bar
COPY
99
Shooting Using the Mode Dial
Some aperture values may not be available with certain zoom
positions (p. 97).
z The maximum shutter speed with synchronized flash is 1/500
second*. Therefore, even if an aperture value is preset, the
aperture value may automatically be reset to match the
synchronized flash speed.
* When using an external flash, see p. 266, 267.
Aperture Value Display
z The larger the aperture value, the smaller the lens opening,
allowing less light to enter the camera.
z You can change the combinations of aperture values and
shutter speeds without altering the exposure (p. 135).
F2.8 F3.2 F3.5 F4.0 F4.5 F5.0 F5.6 F6.3 F7.1 F8.0
COPY
100
You can manually set the shutter speed and aperture to shoot images.
Manually Setting the Shutter Speed
and Aperture
Available Shooting Modes p. 300
1
Set the mode dial to .
2
Configure the shutter speed and aperture
setting.
1. Press the button to select the shutter speed or aperture
value.
2. Use the control dial to change the shutter speed or aperture
value.
• When using the control dial, the bar or bar will be
displayed and the aperture value can be changed.
COPY
101
Shooting Using the Mode Dial
3
Shoot.
• The current exposure level appears
on the right side of the exposure level
indicator, while the correct exposure
level appears in the center on the left
side of the indicator (if the difference
is more than ±2 stops, the current
exposure level appears in red on the
LCD monitor).
• When you press the shutter button
halfway, the difference between the
correct exposure* and the selected exposure appears on the
LCD monitor. If the difference is more than ±2 stops, “–2” or “+2”
appears in red.
* The correct exposure is calculated by measuring the brightness according to
the selected metering method.
• When you press the button, the shutter speed or aperture
value will automatically shift to obtain the correct exposure
(except when the icon and icon are selected). When the
shutter speed is selected, the aperture value will change. When
the aperture is selected, the shutter speed will change. In
addition, if you press the button after you adjusted the
exposure compensation (p. 137), the exposure will shift to the
adjusted value. The exposure compensation value appears as a
green line on the exposure level indicator.
z If the zoom is adjusted after these values are set, the
aperture value or the shutter speed may change in
accordance with the zoom position (p. 97).
z The brightness of the LCD monitor matches the selected
shutter speed and aperture value. When you select a fast
shutter speed or shoot a subject in a dark place, set the flash
to (Flash on) or attach an externally mounted flash, the
image will always be bright.
Current Exposure Level
Correct Exposure Level
Exposure Level Indicator
Exposure compensation value
(green line)
COPY
102
Stitch Assist can be used to shoot overlapping images that can later be
merged (stitched) to create one panoramic image on a computer.
Shooting Panoramic Images
(Stitch Assist)
Available Shooting Modes p. 300
1
Set the mode dial to .
The overlapping seams of several
adjacent images can be joined
into a single panoramic image.
COPY
103
Shooting Using the Mode Dial
2
Select the shooting
direction.
1. Use the control dial to select a
shooting direction.
You can select from the following five
shooting directions.
• Left to right horizontally
• Right to left horizontally
• Bottom to top vertically
• Top to bottom vertically
• Clockwise starting at the top left shooting 4 images.
3
Shoot the first frame of the
sequence.
• The exposure and white balance are
set and locked with the first image.
4
Compose the second image so that it overlaps
a portion of the first and shoot.
• You can press the , , or button to return to the
previously recorded image to retake the shot (When shooting
clockwise, you can retake the entire image.).
• Minor discrepancies in the overlapping portions can be
corrected when the images are stitched together.
5
Repeat the procedure for additional images.
• A sequence may contain up to 26 images (except when
shooting clockwise).
6
Press the button after the last shot.
COPY
104
The maximum size for a single movie is 4 GB*, and shooting will
continue until your memory card is full. Actual maximum recording
times vary depending on your memory card (p. 283).
The following movie modes are available.
* Even if the file size has not reached 4 GB, the recording stops when the recording
time reaches one hour. Depending on memory card capacity and data write speed,
recording may stop before the file size reaches 4 GB or the recording time reaches
one hour.
z You cannot display the images on a TV when shooting in
Stitch Assist mode.
z The settings for the first image are applied to the second
image onward.
Use PhotoStitch, a supplied software program, to merge the
images on a computer.
Movie Shooting
Available Shooting Modes p. 300
Standard
The digital zoom can (p. 71) be used while
shooting in this mode.
p. 24
Color Accent
You can have only the specified color remain and
change all others into black and white.
p. 149
Color Swap
You can change the specified color into a different
color.
p. 151
1
Set the mode dial to .
COPY
105
Shooting Using the Mode Dial
2
Select a movie mode.
1. Use the control dial to select a movie
mode.
• See Changing Colors (p. 148) for the
procedures for using and .
3
Shoot.
• Pressing the shutter button halfway automatically sets the
exposure, focus and white balance settings.
• Pressing the shutter button fully starts recording video and
sound simultaneously.
• During shooting, the recording time and [zRec] appear on the
LCD monitor.
• Pressing the shutter button fully again stops recording.
Recording will stop automatically under the following
circumstances.
- When the maximum recording time or maximum recording
capacity is reached
- When the built-in memory or memory card becomes full
z You are recommended to use a memory card that has been
formatted in your camera to shoot movies (pp. 16, 220).
z Be careful of the following while recording.
- Try not to touch the microphone (p. 42).
- If you press a button, the sound of the button being
pressed will also be recorded.
- The camera will automatically adjust the exposure and
white balance to suit the shooting conditions during
recording. Please note, however, that the sounds made by
the camera while automatically adjusting the exposure
may also be recorded.
z The focus and optical zoom settings remain fixed for
subsequent frames at the values selected for the first frame.
COPY
106
z Adjust the zoom setting before shooting. The combined
digital and optical zoom factor will display on the LCD
monitor. When the zoom factor displays in blue, the image
will deteriorate.
z You can perform the following operations before shooting the
movie.
- AF lock: If you press the MF button, auto focus will be fixed
at the current state. The icon and MF indicator appear
on the LCD monitor, and you can confirm the distance
between the subject and lens. You can cancel by pressing
the MF button again.
- Manual focus (p. 130)
- AE lock and exposure shift: this is effective on ski slopes
and the beach when the contrast is too strong between the
subject and background or where there are both light and
dark areas in the scene and it is desirable to adjust the
exposure.
1 Press the button.
The exposure will lock (AE lock) and the exposure shift
bar will appear in the LCD monitor.
2. Use the control dial to adjust the exposure.
Press the button again to release the setting. Also,
the setting will be canceled if you press the MENU button
or change the white balance, My Colors or shooting
mode settings.
COPY
107
Shooting Using the Mode Dial
Changing Movie Recording Pixels
1
Select the recording
pixels.
1. Press the button.
2. Use the or button to select
and the or button to
change the option.
3. Press the button.
Recording Pixels Frame Rates
640 × 480 30 frames/sec.
320 × 240 30 frames/sec.
z See Memory Cards, Estimated Capacities and Image Data
Sizes (Estimated) (p. 282).
z Frame rates indicate the number of frames recorded or
played back each second.
COPY
108
The microphone level (sound recording level) of the movie, sound
memos (p. 194) and sound recorder (p. 195) and wind filter setting
(p. 195) can be changed.
Setting the Recording Functions
Available Shooting Modes p. 300
1
Select [Audio].
1. Press the MENU button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Audio].
4. Press the button.
2
Set the microphone level.
1. Use the or button to select
[Mic Level].
2. Use the or button to select
[Auto] or [Manual].
• When in [Manual] mode, press the
button, then set the sound recording level (recording volume)
with the or button. displays in the LCD monitor.
3
Set the wind filter.
1. Use the or button to select
[Wind Filter].
2. Use the or button to select [On]
or [Off].
3. Press the MENU button.
• Recommended to set to [On] when the wind is strong.
• When set to [On], displays in the LCD monitor.
COPY
109
Shooting Using the Mode Dial
You can save frequently used shooting modes and various shooting
settings to the (Custom) mode. When necessary, you can then
shoot images with previously saved settings by simply turning the
mode dial to or . Settings that are not retained when the
shooting mode is changed or when the power is turned off (such as
continuous shooting or self-timer) are also retained.
z When in [Auto] mode, if the recording volume becomes too
loud, it automatically prevents distortion of sound.
z Wind filter suppresses noise when the wind is strong.
However, unnatural sound will result when used to record in
locations with no wind.
Saving Custom Settings
Available Shooting Modes p. 300
1
Switch to the shooting mode you wish to save
and make the settings.
• Functions which can be saved in or .
- Shooting mode ( , , , )
- Items which can be set in , , and modes (pp. 95
– 101)
- Rec. menu settings
- Zoom location
- Manual focus location
- My Menu settings
• To change some of the settings saved in or (other than
shooting mode), select or , and set again.
2
Select [Save Settings].
1. Press the MENU button.
2. In the menu, use the or
button to select [Save Settings].
3. Press the button.
COPY
110
3
Register.
1. Use the or button to select
[] or [ ].
2. Press the button.
3. Press the MENU button.
z The ISO speed setting and the exposure compensation
cannot be saved. When shooting with / , set the ISO
speed with the ISO speed dial and the exposure
compensation with the exposure compensation dial.
z The setting contents do not influence other shooting modes.
z Saved settings can be reset (p. 227).
COPY
111
Various Shooting Methods
The camera shoots continuously while the shutter button is held down.
* The focus position of first image is fixed.
You can also use the control dial to select shooting modes or FUNC.
menu options. See p. 43.
Continuous Shooting
Available Shooting Modes p. 300
Focus
while
shooting
Display on
the LCD
monitor
Continuous
Approx. 1.3
images/sec.
You can shoot
continuously at a short
shooting interval.
Fixed* Recorded
Continuous
Shooting AF
Approx. 0.7
images/sec.
The camera will continue
to record successive
images and focus while the
shutter button is held down
(except in manual focus
mode).
Auto focus Subject
right before
shooting
Continuous
Shooting LV
(Live View)
Approx. 0.7
images/sec.
You can shoot
continuously with a
manually set focus position
while confirming the
subject.
Fixed* Subject
right before
shooting
1
Press the button.
1. Use the or button to select
, or .
Various Shooting Methods
COPY
112
To Cancel Continuous Shooting:
Follow procedure 1 to select .
2
Shoot.
• The camera will continue to record successive images while the
shutter button is held down.
Recording will cease when the shutter button is released.
z When in , will be the default setting. cannot be
set.
z In and manual focus modes, will not display ( can
be selected).
z AF frame will be set to [Center] in mode (p. 121).
z Rec. Review (p. 18) will not be displayed in and
modes.
z Cannot be set while in the focus bracketing shooting mode
or AEB shooting mode.
z The interval between shots lengthens when the built-in
memory of the camera fills.
z If the built-in flash is used, the interval between shots
lengthens because the flash must charge.
COPY
113
Various Shooting Methods
You can make detailed built-in flash and external flash* settings to fit
the shooting conditions.
* See Setting the Externally Mounted Flash (p. 268).
Built-in Flash Settings
Setting the Flash
Available Shooting Modes p. 300
Menu Item Summary Note
Flash Mode When set to [Manual], you can
control the flash output in the
or shooting mode.
–
Flash Exp.
Comp
Flash exposure compensation can
be adjusted in the range of –2 to +2
stops in 1/3-stop increments. You
can combine the flash exposure
compensation with the camera’s
exposure compensation function
for balanced exposure of the
background when shooting with a
flash.
In or
shooting mode, set
[Flash Mode] to
[Auto] in advance.
Flash Output The flash output can be controlled
in three steps, up to FULL, when
shooting.
In or
shooting mode,
please set [Flash
Mode] to [Manual].
Shutter Sync. You can switch the timing at which
the flash fires.
–
1st-curtain The flash fires right after the shutter
opens, regardless of the shutter
speed. Usually, the 1st-curtain is
used when shooting.
2nd-curtain The flash fires right before the
shutter closes. Compared with the
1st-curtain, the flash fires later and
allows you to shoot images in
which, for example, a car’s taillights
seem to trail off behind.
COPY
114
Slow Synchro The flash timing is adjusted to slow
shutter speeds. This reduces the
chance that only the background
will appear dark when a night scene
or an interior shot is taken.
Using Slow Synchro
increases the
chances for camera
shake. Use of a tripod
is recommended.
Red-Eye
Corr.
Automatically searches for and
corrects red eyes in the image
when the flash fires.
–
Red-Eye
Lamp
This feature reduces the effect of
light reflecting back from the eyes
and making them appear red.
The red-eye
reduction lamp lights
green before the flash
fires.
Safety FE The camera automatically changes
the shutter speed or aperture value
when the flash fires to avoid
overexposing and blowing out the
highlights in the scene.
In or
shooting mode, set
[Flash Mode] to
[Auto] in advance.
About Red-Eye Correction
z When [Red-Eye Corr.] is set to [On], only the corrected
image is recorded to the memory card.
z If the area around the eyes is red, for example from using
red eye shadow, that area may also be corrected. If this
happens, set [Red-Eye Corr.] to [Off].
z Red eyes may not be automatically detected or may not be
fully corrected on some images. In either case, you can
correct images with [Red-Eye Correction] in the menu
(p. 182).
Menu Item Summary Note
COPY
115
Various Shooting Methods
Displaying and Setting [Flash Control]
1
Select [Flash Control].
1. Press the MENU button.
2. In the menu, use the or
button to select [Flash Control].
3. Press the button.
• [Flash Control] can also be displayed
by the following methods.
- Press the button for more than one second.
- When changing the flash mode, press the MENU button
(p. 73).
2
Make settings.
1. Use the or button to select the
option.
2. Use the or button to make the
setting.
3. Press the MENU button.
3
Press the MENU button.
You can also set [Flash Exp. Comp] and [Flash Output] in the
FUNC. menu (p. 54).
Example in Av mode
COPY
116
You can zoom the display of the AF frame to check focus when
shooting or right after taking a shot.
Zooming the AF Frame and Shooting
When [AF Frame] is set to other than [AiAF], the AF frame area can be
zoomed to check focus while shooting. When you want to capture
people’s expressions, set [AF Frame] to [Face Detect]. When you want
to check the focus while shooting in macro mode, set [AF Frame] to
[Center] or [FlexiZone].
Checking the Focus and People’s
Expressions
Available Shooting Modes p. 300
1
Select [AF-Point Zoom].
1. Press the MENU button.
2. In the menu, use the or
button to select [AF-Point Zoom].
2
Make settings.
1. Use the or button to select
[On].
2. Press the MENU button.
COPY
117
Various Shooting Methods
3
Press the shutter button halfway.
• Pressing the shutter button halfway zooms a section of the
display according to the following AF Frame mode settings
(p. 121).
[Face Detect] : The face detected as the main subject will appear
zoomed.
[Center] : The center of the image will appear zoomed in
the LCD monitor.
[FlexiZone] : The area within the AF frame will appear
zoomed.
4
Press the shutter button fully to shoot.
The AF frame cannot be zoomed under the following
circumstances:
- When [AF Frame] is set to [Face Detect] and a face is not
detected, or when the face is extremely large in relation to
the overall composition.
- When the camera cannot focus.
- When the digital zoom is in use.
- When a TV is being used as the display.
- When [Servo AF] (p. 127) is set to [On].
COPY
118
Checking Focus Right After Shooting (Focus
Check)
Allows you to check the focus of an image taken. It is also easy to
check people’s expressions and look for closed eyes when shooting
because a frame the size of the face displays when Face Select and
Track (p. 121) or AF frame mode is set to [Face Detect] (p. 121).
You are recommended to set [Review] to [Hold] in the menu in
advance.
1
Select [Review Info].
1. Press the MENU button.
2. In the menu, use the or
button to select [Review Info].
2
Make settings.
1. Use the or button to select
[Focus Check].
2. Press the MENU button.
COPY
119
Various Shooting Methods
To Cancel the Focus Check:
Press the shutter button halfway.
3
Shoot.
• The recorded image will be displayed.
• Frames are displayed as follows.
• The orange frame can be shown at a different magnification,
moved or switched to a different frame (p. 162).
z Pressing the button while the image is displayed will
erase the image (p. 20).
z You can check the focus even during playback mode
(p. 161).
Orange frame contents
Frame color Content
Orange Displays the area of the image shown at the bottom
right.
White Indicates the AF frames or the positions of faces that
were used for focusing when shooting.
COPY
120
You can set the AF mode.
Switching between Focus Settings
Available Shooting Modes p. 300
Continuous
The camera is continually focusing on whatever it is aimed at
even when the shutter button is not pressed, allowing you to
shoot without missing opportunities.
Single
The camera only focuses when the shutter button is pressed
halfway, conserving battery power.
1
Select [AF Mode].
1. Press the MENU button.
2. In the menu, use the or
button to select [AF Mode].
2
Make settings.
1. Use the or button to select AF
mode.
2. Press the MENU button.
This will be set when the AF frame mode is set to [Face Detect],
[FlexiZone] or [Center]. This will be fixed to [Single] when the
AF frame mode is set to [AiAF] (p. 121).
COPY
121
Various Shooting Methods
The AF frame indicates the area of the composition on which the
camera focuses.
Selecting an AF Frame Mode
Available Shooting Modes p. 300
Face Detect
The camera detects a face and sets the focus,
exposure*
1
and white balance*
2
. In addition, the
camera meters the subject so that the face is
correctly illuminated when the flash fires.
*1 Only in evaluative metering mode (p. 141)
*2 Only in (p. 143)
AiAF
The camera automatically selects between 9 AF
frames to focus on according to the shooting
conditions. You can change the AF frame size
(p. 124).
Center
The AF frame will be fixed to center. This is
recommended when the target subject is at the
center of the composition.
FlexiZone
The AF frame can be moved manually to the
desired area (FlexiZone). This is convenient for
making sure the focus is exactly where you want it.
You can change the AF frame size (p. 124).
1
Select an AF frame mode.
1. Press the button.
2. Press the button to select an AF
frame mode.
• The AF frame mode changes with
each press of the button.
3. Press the button.
• You can also select the AF frame mode in [AF Frame] in the
menu (p. 55).
• See Changing the AF Frame Size (p. 124).
• See Moving the AF Frame (p. 123).
Example when [AiAF] is
selected
COPY
122
z If the LCD monitor display is turned off, the focus setting will
change as follows (only [AiAF] and [Center] are available).
- [Face Detect] will change to [AiAF].
- [FlexiZone] will change to [Center].
z The AF frame appears as follows when the shutter button is
pressed halfway.
- Green: In focus
- Yellow: Focusing difficulty ([Center] or [FlexiZone] option)
- No AF frame: Focusing difficulty ([Face Detect] or [AiAF]
option)
Face Detect Feature
z When the camera detects faces, AF frames will be displayed on a
maximum of three faces. At this point, the frame the camera
judges to be the main subject appears in white while the others
appear in gray. When the shutter button is pressed halfway and
the camera focuses, up to 9 green AF frames may appear. You
can also select the person you wish to focus on (p. 125).
z If the white frame fails to appear and only gray frames appear, or if
a face is not detected, the focusing method will change as follows.
- When [Single] is selected, images will be shot in [AiAF] mode.
(When [Servo AF] is set to [On], images will be shot in [Center]
mode.)
- When [Continuous] is selected, images will be shot in [Center]
mode.
z The camera may mistakenly identify non-human subjects as a
face.
z In certain cases, faces may not be detected.
Examples:
- If faces are at the edge of the screen, or appear extremely small,
large, dark or bright, relative to the overall composition.
- Faces turned to the side or at a diagonal, or faces with a portion
hidden.
COPY
123
Various Shooting Methods
Moving the AF Frame ([AiAF] or [FlexiZone]
Selected)
The AF frame can be moved manually allowing you to focus precisely
on the desired area of your subject. You can move the AF frame when
[AiAF] is selected as the metering mode and the AF frame is set to
small.
1
Press the button.
• The AF frame will display in green.
2
Move the AF frame using the control dial and
press the button.
• You can move the AF frame to the position you wish to set using
the , , or button.
• The AF frame will move back to its original position (center), if
you hold down the button.
• When the camera detects faces selecting [AiAF], each press of
the MENU button moves the AF frame to a different face
position.
z When the [Spot AE Point] is selected as the metering mode,
you can use the selected Spot AE Point as the AF frame
(p. 141).
z Selection cannot be made while in the manual focus mode
(p. 130).
z If you turn off the camera or the lens retracts in playback
mode (p. 44), the AF frame returns to the center position.
COPY
124
Changing the AF Frame Size ([AiAF] or [FlexiZone]
selected)
You can change the size of the AF frame to match the size of the
subject. When the subject you are aiming at is small, or when you want
to focus on a particular area of the subject, you can restrict the area
that is focused on by making the AF frame smaller.
1
Press the button.
• The AF frame will display in green.
2
Press the DISP. button.
• Each time you press the DISP. button,
the AF frame settings will switch
between normal and small.
• When the camera has difficulty
focusing on the subject when you
press the shutter button halfway, the
AF frame will display in yellow.
• Pressing the button (or the
FUNC./SET button) completes the
setting.
• When you set the AF frame to small in
AiAF mode, the LCD monitor display
will appear as shown right.
The AF frame size is set to normal when the digital zoom,
digital tele-converter or manual focus is used.
Normal
Examples:
When [AiAF] is selected
Small
COPY
125
Various Shooting Methods
Once the focus is fixed to a subject’s face, the frame can be set to
follow the subject within a certain range. The AF frame mode is set to
[Face Detect] in advance (p. 121).
Selecting a Subject to Focus On
(Face Select and Track)
Available Shooting Modes p. 300
1
Select a face to focus on.
1. Press the button while faces are detected by the camera.
• The camera enters face select
mode, and the face frame ( ) of
the main subject displays in white.
Even if the subject moves, the
frame will follow the subject within a
certain range.
• The face frame will not display
when a face is not detected.
2.
Select the person you wish to focus on.
• When several faces have been
detected, pressing the or
button or turning the control dial will
move the face frame to another
subject.
• Holding down the DISP. button for
more than 1 second will display
face frames (up to 35) of all the
detected faces (green: face of main
subject, white: detected faces).
3. Press the button again.
• The camera exits face designation
mode, and the face frame ( ) of
the main subject will change to white (the frame will continue
to follow the subject within a certain range).
• Pressing the button will release the face designation mode.
Face Frame
Face Frame
COPY
126
2
Press the shutter button halfway.
• The face frame ( ) of main subject will change into .
• If the camera has difficulty focusing, the face frame will display
in yellow.
3
Press the shutter button all the way to shoot.
In the following cases, the face select mode will be canceled.
- When turning the power back on
- When switching to another shooting mode
- When using the digital zoom or digital tele-converter
- When the MENU button is pressed to display the menu
- When a selected face cannot be tracked for several seconds
- When the display is turned off
COPY
127
Various Shooting Methods
With Servo AF, the focus remains on a subject for as long as the
shutter button is pressed halfway, so you do not miss opportunities to
capture a moving subject.
Shooting with Servo AF
Available Shooting Modes p. 300
1
Select [Servo AF].
1. Press the MENU button.
2. In the menu, use the or
button to select [Servo AF].
2
Make settings.
1. Use the or button to select
[On].
2. Press the MENU button.
3
Press the shutter button halfway.
• [Face Detect]: Focus remains on the main subject marked with
the blue AF frame for as long as the shutter button is pressed
halfway.
• [Center], [FlexiZone]: Focus remains on the blue AF frame for
as long as the shutter button is pressed halfway.
4
Press the shutter button all the way to shoot.
This option is not available in the following situations.
- When AF frame mode is set to [AiAF]
- When is selected
- When MF is set
COPY
128
It may be difficult to focus on the following types of subjects.
• Subjects with extremely low contrast to the surroundings
• Scenes with a mixture of near and far subjects
• Subjects with extremely bright objects at the center of the
composition
• Subjects that are moving quickly
• Subjects through glass
Shooting with the Focus Lock
Shooting with the AF Lock
Shooting Hard-to-Focus Subjects
(Focus Lock, AF Lock, Manual Focus, Safety MF)
Available Shooting Modes p. 300
1
Aim the camera so that an object at the same
focal distance as the main subject is centered
in the viewfinder or in the AF frame displayed
on the LCD monitor.
2
Keep the shutter button pressed halfway while
you recompose the image.
3
Press the shutter button fully to shoot the
image.
1
Turn on the LCD monitor.
2
Aim the camera so that an object at the same
focal distance as the main subject is centered
in the AF frame.
COPY
129
Various Shooting Methods
To Release the AF Lock:
Press the MF button.
3
Press and hold the shutter button halfway and
press the MF button.
• and MF Indicator will be displayed to confirm the distance
from the subject.
4
Re-aim the camera to compose the shot as
desired and shoot.
When [Servo AF] (p. 127) is set to [On], AF lock cannot be
used.
z In mode, you cannot enable AF lock using the method
on p. 128. Instead, you can use AF lock by registering to
[Set Shortcut button] (p. 155).
z The AF frame does not appear in the and modes, so
be sure to point the camera at the subject on which you want
to focus.
z When shooting with focus lock or AF lock using the LCD
monitor, you can simplify shooting by setting [AF Frame] to
[FlexiZone] or [Center] (p. 121) so that only one AF frame is
active.
z The AF lock is convenient because you can let go of the
shutter button to compose the image. Moreover, the AF lock
is still effective after the picture is taken, allowing you to
capture a second image with the same focus.
z When you shoot a subject through glass, try to shoot as
close to the glass as possible to reduce the chances of light
reflecting back off the glass.
COPY
130
Shooting in Manual Focus Mode
The focus can be manually set.
1
Turn on the LCD monitor.
2
Press the MF button to
display .
• The MF indicator is displayed.
• When the menu’s [MF-Point
Zoom] is set to [On], the portion of the
image in the AF frame will appear
magnified*. When the AF mode
(p. 120) is set to [Continuous], turning
the control dial will display the portion magnified. The magnified
position will differ depending on the AF Frame Mode (p. 121)
setting.
- When set to [FlexiZone], the location of the AF frame
displayed immediately prior to setting the manual focus will
display magnified.
- When set to other than [AiAF], the center of the LCD monitor is
magnified.
* Can also be set so that the image displayed is not magnified (p. 56). Also
when using , digital zoom, Digital Tele-Converter or while displaying the
image on a TV, the display magnification is not available.
• With each press of the button, the settings that can be
configured with the control dial in each shooting mode will
change as follows.
MF Indicato
r
mode/
mode/
Metering mode/
Shutter speed/Metering mode/
Aperture value/Metering mode/
Shutter speed/Aperture value/Metering mode/
COPY
131
Various Shooting Methods
To Cancel the Manual Focus:
Press the MF button.
Using the Manual Focus in Combination with the
Auto Focus (Safety MF)
First, manual focus is used to roughly focus, then from that focus
position the camera automatically focuses more accurately. You can
use the following two methods.
Setting by the Button
Setting the Safety MF
3
Use the control dial and adjust the focus.
• The MF indicator shows approximate figures. Use them as a
shooting guideline only.
You cannot change the AF frame setting while focusing
manually. Cancel the manual focus mode, then change the AF
frame setting.
1
Focus the camera with the manual focus, then
press the button.
• The camera beeps and focuses to a more accurate focusing
point.
1
Select [Safety MF].
1. Press the MENU button.
2. In the menu, use the or
button to select [Safety MF].
COPY
132
2
Make settings.
1. Use the or button to select
[On].
2. Press the MENU button.
3
Focus the camera with the manual focus, then
press the shutter button halfway.
• The camera focuses to a more accurate focusing point.
4
To shoot, press the shutter button all the way
down (press fully).
COPY
133
Various Shooting Methods
The camera automatically takes three shots: one at the manual focus
position, and one each with focus positions preset farther and nearer.
The three shots are taken at the same interval as continuous shooting
(p. 111).
The farther and nearer focus positions can be set in three steps: large,
medium and small.
To Cancel the Focus-BKT Mode:
Select (BKT-Off) in Step 1.
Focus Bracketing (Focus-BKT Mode)
Available Shooting Modes p. 300
The Focus-BKT mode is not available when shooting with the
flash on. Only one image at the manual focus position will be
recorded.
1
Select the Focus-BKT.
1. Press the button.
2. Use the or button to select
and use the or button to select
.
3. Press the DISP. button.
2
Make settings.
1. Set the amount of focus position
offset with the or button to
select.
2. Press the button.
• Press the button to broaden or the
button to narrow the focusing distance from the center.
3
Shoot the image with manual focus (p. 130).
COPY
134
You can set the exposure and focus separately. This is effective when
the contrast is too strong between the subject and background or when
a subject is backlit.
To Release the AE Lock:
Operate a button other than the button or the control dial.
Locking the Exposure Setting (AE Lock)
Available Shooting Modes p. 300
Be sure to set the flash to so that the flash does not fire.
When the flash fires, the FE lock will be used (p. 136).
1
Turn on the LCD monitor.
2
Aim the camera at the subject on which you
wish to lock the exposure.
3
Press the shutter button halfway and press the
button.
• The exposure setting will lock and will display.
4
Re-aim the camera to compose the shot as
desired and shoot.
z In movie mode, AE lock can also be set/canceled (p. 106).
z After locking the AE, you can change the ISO speed with
exposure fixed.
COPY
135
Various Shooting Methods
Changing the Shutter Speed and Aperture Value
Combination
The automatically selected combinations of shutter speeds and
aperture values can be freely changed without altering the exposure
to shoot images (Program Shift).
1
Aim the camera at the subject on which you
wish to lock the exposure.
2
Press the shutter button
halfway and press the
button.
• The exposure setting will lock, and
will appear on the LCD monitor.
3
Use the control dial to change shutter speed
and aperture value combinations.
4
Recompose the image and shoot.
• The setting will cancel after the shot is taken.
bar bar
COPY
136
You can lock the flash exposure so that the exposure settings are
correctly set regardless of the composition of your subject.
To Release the FE Lock:
Operate a button other than the button or the control dial.
Locking the Flash Exposure Setting
(FE Lock)
Available Shooting Modes p. 300
1
Turn on the LCD monitor.
2
Press the button and select (flash on).
• If you are using an externally mounted flash, please refer to its
manual for setting instructions.
3
Aim the camera at the subject on which you
wish to lock the exposure.
4
Press and hold the shutter button halfway and
press the button.
• The flash will pre-fire and the exposure setting will be locked.
• will display in the LCD monitor.
5
Re-aim the camera to compose the shot as
desired and shoot.
The FE lock cannot be used when [Flash Mode] in the [Flash
Control] menu is set to [Manual].
COPY
137
Various Shooting Methods
Adjust the exposure compensation to a positive value to avoid making
the subject too dark when it is backlit or shot against a bright
background. Adjust the exposure compensation to a negative value to
avoid making the subject too bright in night shots or when shot against
a dark background.
To Cancel the Exposure Compensation:
Follow Step 1 to restore the compensation value to [0].
Adjusting the Exposure Compensation
Available Shooting Modes p. 300
1
Adjust the exposure
compensation.
1. Use the exposure compensation dial
to adjust the exposure
compensation.
• If exposure compensation is available
in a shooting mode, the exposure
compensation lamp will light orange.
• The exposure compensation bar and
the compensation results will display in the LCD monitor.
• When shooting in AEB mode (p. 139), the compensation range
for AEB shooting is displayed.
In movie mode, the exposure shift can be set/canceled (p. 106).
Compensation range
during AEB mode
Exposure compensation ba
r
COPY
138
When shooting scenes in which faces or subjects appear darkened,
you can set the camera to automatically detect faces and dark areas
and compensate brightness levels while shooting.
Shooting while Brightening Dark Areas
(i-Contrast)
Available Shooting Modes p. 300
1
Select [i-Contrast].
1. Press the MENU button.
2. In the menu, use the or
button to select [i-Contrast].
2
Make settings.
1. Use the or button to select
[Auto].
2. Press the MENU button.
When is selected, [i-Contrast] cannot be set.
z Depending on the scene being shot, the compensation
results may not be as expected.
z You can use the [i-Contrast] setting in the Play menu to apply
brightness compensation to images already captured
(p. 187).
COPY
139
Various Shooting Methods
In this mode, the camera automatically changes the exposure within a
set range to take three shots at the same interval as continuous
shooting (p. 111). The images are shot in the following order: Standard
exposure, underexposure and overexposure.
To Cancel the AEB Mode:
Select in Step 1.
Auto Exposure Bracketing (AEB Mode)
Available Shooting Modes p. 300
1
Select AEB.
1. Press the button.
2. Use the or button to select
and use the or button to
select .
3. Press the DISP. button.
2
Adjust the compensation
range.
1. Adjust the compensation range with
the or button.
2. Press the button.
• The compensation range can be set
as wide as 2 levels lower and 2 levels
higher, in 1/3 increments, than the
standard exposure value (the
compensated exposure value if exposure adjustment was
performed) at the center point. If exposure adjustment (p. 137)
is already done, setting can be done with the adjusted value as
the center point.
The AEB mode is not available when shooting with the flash
on. Only one standard exposure image will be recorded.
Standard
exposure
Compensation range
COPY
140
The ND filter reduces light intensity to 1/8 (3 stops) of the actual level,
allowing for slower shutter speeds and smaller aperture values.
To Cancel the ND Filter:
Select .
Using the ND Filter
Available Shooting Modes p. 300
Always use a tripod to prevent camera shake in this mode.
1
Select .
1. Press the button.
2. Use the or button to select
and use the or button to
select .
3. Press the button.
COPY
141
Various Shooting Methods
Switching between Metering Modes
Available Shooting Modes p. 300
Evaluative
Appropriate for standard shooting conditions,
including backlit scenes. The camera divides
images into several zones for metering. It
evaluates complex lighting conditions, such as the
position of the subject, the brightness, the direct
light, and the backlighting, and adjusts the settings
to the correct exposure for the main subject.
Center Weighted
Avg.
Averages the light metered from the entire frame,
but gives greater weight to the subject matter at the
center.
Spot AE Point
Meters the area within the spot AE point frame.
Use this mode when there is a large divergence in
brightness between the subject and surroundings.
Center
Locks the spot metering frame to the center of the
LCD monitor.
AF Point
Move the spot AE point to the same position as the
selected AF frame. Can be set only in [FlexiZone]
(p. 121).
1
Change the metering mode.
1. Press the button.
2. Turn the control dial to select the
metering mode.
• With each press of the button, the settings that can be
configured with the control dial in each shooting mode will
change as follows.
Shutter speed/Metering mode
Aperture value/Metering mode
Shutter speed/Aperture value/Metering mode
COPY
142
Moving the Spot AE Point to the AF Frame/
Centering the Spot AE Point
1
Select [FlexiZone].
1. Press the MENU button.
2. In the menu, use the or
button to select [AF Frame].
3. Use the or button to select
[FlexiZone].
2
Select [Spot AE Point].
1. Use the or button to select
[Spot AE Point].
3
Make settings.
1. Use the or button to select
[Center] or [AF Point].
2. Press the MENU button.
• When [Spot AE Point] is set to
[Center], the spot AE point frame
appears at the center of the LCD monitor.
• When [AF Point] is set, it appears inside the selected AF
frame.
COPY
143
Various Shooting Methods
Normally, the (Auto) white balance setting selects an optimal white
balance. When the setting cannot produce natural looking colors,
change the white balance using a setting appropriate for the light
source.
Adjusting the Tone (White Balance)
Available Shooting Modes p. 300
Auto Settings are automatically set by the camera.
Day Light For recording outdoors on a bright day.
Cloudy
For recording under overcast, shady or twilight
skies.
Tungsten
For recording under tungsten and bulb-type 3-
wavelength fluorescent lighting.
Fluorescent
For recording under warm-white, cool-white or
warmwhite (3-wavelength) fluorescent lighting.
Fluorescent H
For recording under daylight fluorescent, or daylight
fluorescent-type 3-wavelength fluorescent lighting.
Flash When using the flash (cannot be set in mode).
Underwater
Appropriate for shooting images with the
Waterproof Case WP-DC28 (sold separately). This
mode yields image data in the optimal white
balance to record images with natural hues by
reducing the bluish tone.
Custom
For recording with the optimal white balance data
memorized in the camera from a white-colored
object, such as white paper or cloth.
1
Select a white balance
setting.
1. Press the button.
2. Use the or button to select
button to select or button to
change the option.
3. Press the button.
COPY
144
The white balance setting cannot be adjusted when or
is selected for My Colors.
Using the Custom White Balance
Take a custom white balance (Custom 1) or (Custom 2)
reading for the following situations that are difficult for the (Auto)
setting to detect correctly.
• Shooting subjects of monotone color (such as sky, sea or forest)
• Shooting with a particular source of light (such as a mercury-vapor
lamp)
• Shooting close-ups (Macro)
1
Select .
1. Press the button.
2. Use the or button to select
and use the or button to
select or .
2
Aim the camera at a piece
of white paper or cloth and
press the DISP. button.
• Ensure that the LCD monitor is
completely filled with the white
image. Please note, however, that
the center frame will not display
when the digital zoom is used or when is displayed.
• You can also use the optical viewfinder to take a custom
white balance reading.
3
Press the button.
COPY
145
Various Shooting Methods
z You are recommended to set the shooting mode to and
the exposure compensation setting to [±0] before setting a
custom white balance. The correct white balance may not
be obtained when the exposure setting is incorrect (image
appears completely black or white).
z When taking a white balance data reading at close range
while using flash, you may not be able to obtain proper
exposure. After obtaining the white balance data, be sure
to check whether the proper color balance was obtained. If
not, increase the distance between the camera and the
white paper or cloth that you wish to use as the standard,
and take the white balance data reading again.
z Shoot with the same settings as when reading the white
balance data. If the settings differ, the optimal white
balance may not be set. In particular, the following should
not be changed.
- ISO Speed
-Flash:
Setting the flash to or is recommended. If the
flash fires when reading the white balance data with the
flash set to , make sure that you also use the flash
when you shoot.
z Since the white balance data cannot be read in Stitch
Assist mode, preset the white balance in another shooting
mode beforehand.
z The white balance data is retained even after the camera
power is turned off.
COPY
146
You can change the look of an image when it is shot.
* If the image contains colors that are the same as human skin, those colors will also
be changed. You may not obtain the expected results depending on the skin color.
Shooting in a My Colors Mode
Available Shooting Modes p. 300
My Colors Off Records normally with this setting.
Vivid
Emphasizes the contrast and color saturation to
record bold colors.
Neutral
Tones down the contrast and color saturation to record
neutral hues.
Sepia Records in sepia tones.
B/W Records in black and white.
Positive Film
Use this option to make blue, green or red colors
more intense like the Vivid Blue, Vivid Green or Vivid
Red effects. It can produce intense natural-appearing
colors like those obtained with positive film.
Lighter Skin* Use this option to make skin tones lighter.
Darker Skin* Use this option to make skin tones darker.
Vivid Blue
Emphasize blue tints. Use to make blue subjects,
such as the sky or ocean, more vivid.
Vivid Green
Emphasize green tints. Use to make green subjects,
such as mountains, new growth, flowers and lawns,
more vivid.
Vivid Red
Emphasize red tints. Use to make red subjects, such
as flowers or cars, more vivid.
Custom Color
Use this option to adjust the contrast, sharpness or
saturation settings or the color balance between red,
green, blue and skin tones*. It can be used to make
subtle adjustments, such as making blue colors more
vivid or face colors brighter.
When the recording pixels is set to , the My Colors cannot
be set.
COPY
147
Various Shooting Methods
//////////
(Setting the Custom Color Mode)
1
Select a My Colors setting.
1. Press the button.
2. Use the or button to select
and the or button to change
the option.
3. Press the button.
1
Select .
1. Press the button.
2. Use the or button to select
and choose with the or
button.
2
Adjust the setting.
1. Press the DISP. button.
2. Use the or button to select
[Contrast], [Sharpness], [Saturation],
[Red], [Green], [Blue] or [Skin Tone].
3. Use the or button to adjust the
setting.
• The adjustment results show in the LCD monitor.
• If you press the DISP. button, you will return to the screen
where you can select a My Colors mode.
4. Press the button.
• Return to the shooting screen to shoot.
Select an item Adjust
COPY
148
You can easily change the colors in an image or movie, allowing you to
enjoy producing various effects. Depending on the shooting conditions,
however, the images may appear rough, or you may not get the
expected color. Before photographing important subjects, we
recommend taking trial shots and checking the results. By setting the
[Save Original] function (p. 153) to [On] when shooting stills, you can
also record both the altered image and the original, unaltered image.
Changing the Colors and Shooting
Available Shooting Modes p. 300
Color Accent
Use this option to have only the color specified in
the LCD monitor remain and to transform all others
to black and white.
Color Swap
Use this option to transform a color specified in the
LCD monitor into another. The specified color can
only be swapped into one other color, and multiple
colors cannot be chosen.
Depending on the scene being shot, the ISO speed may
increase, increasing the amount of noise in the image.
COPY
149
Various Shooting Methods
Shooting with Color Accent Mode
1
Select or .
Still image:
1. Set the mode dial to .
2. Use the control dial to select .
Movie:
1. Set the mode dial to .
2. Use the control dial to select .
2
Press the DISP. button.
• The camera will switch to color input
mode, and the display will alternate
between the original image and the
Color Accent image (using the
previously set color).
3
Aim the camera so that the color you wish to
retain appears at the center of the LCD
monitor and press the button.
• Only one color can be specified.
• You can use the or button or the control dial to specify
the range of the colors that are retained.
–5: Only takes the color that you want to retain.
+5: Also takes colors close to the one that you want to retain.
4
Press the DISP. button to complete the setting,
then shoot.
Still image:
Movie:
COPY
150
z The default Color Accent is green.
z You may not obtain the expected results after color input
mode if you use the flash.
z The specified Color Accent and color range retained even if
the camera’s power is turned off.
COPY
151
Various Shooting Methods
Shooting with Color Swap Mode
1
Select or .
Still image:
1. Set the mode dial to .
2. Use the control dial to select .
Movie:
1. Set the mode dial to .
2. Use the control dial to select .
Original Color
(Before Swapping)
Desired Color
(After Swapping)
Still image:
Movie:
COPY
152
2
Press the DISP. button.
• The camera will switch to color input
mode, and the display will alternate
between the original image and the
color swap image (using the
previously set color).
3
Aim the camera so that the original color
appears at the center of the LCD monitor and
press the button.
• Only one color can be specified.
• You can use the or button or the control dial to specify
the range of colors that are changed.
–5: Only takes the color that you want to swap.
+5: Also takes colors close to the one that you want to swap.
4
Aim the camera so that the desired color
appears at the center of the LCD monitor and
press the button.
• Only one color can be specified.
5
Press the DISP. button to complete the setting,
then shoot.
z The default setting for Color Swap changes green into white.
z You may not obtain the expected results if you use the flash.
z The colors and color range specified in the Color Swap mode
are retained even if the camera’s power is turned off.
COPY
153
Various Shooting Methods
Saving Original Images
Not only can you save images with altered colors when shooting still
images with the Color Accent or Color Swap modes, but you can
also choose to save the original images (before the color change).
1
Select [Save Original].
1. Press the MENU button.
2. In the menu, use the or
button to select [Save Original].
2
Make settings.
1. Use the or button to select
[On] or [Off].
2. Press the MENU button.
If [Save Original] is set to [On]
- The transformed image is reviewed in the LCD monitor
after shooting in the Color Accent or Color Swap mode. If
you erase the image at this point, the original image is
erased along with the transformed image. Exercise
adequate caution before deleting a file.
- Since two images are recorded with each shot, the number
of shots remaining is approximately half the number
displayed when this function is set to [Off].
- The images are numbered consecutively. The original
images are assigned the lower number and the
transformed color accent or color swap images the next
number.
COPY
154
If you set Auto Category to [On], images are automatically sorted into
preset categories as they are recorded.
Categorizing Images Automatically
(Auto Category)
Available Shooting Modes p. 300
People
For images shot in , or mode, or images with
faces detected when in face select mode or [AF Frame] is
set to [Face Detect].
Scenery For images shot in , , or mode.
Events For images shot in , , , , , or mode.
1
Select [Auto Category].
1. Press the MENU button.
2. In the menu, use the or
button to select [Auto Category].
2
Make settings.
1. Use the or button to select [On]
or [Off].
2. Press the MENU button.
Movies are not automatically categorized, but they can be
categorized using the My Category function (p. 165).
COPY
155
Various Shooting Methods
You can register a function that you often use when shooting with the
button.
To Cancel the Shortcut Button:
Select in Step 2.
Registering Functions to the Button
Available Shooting Modes p. 300
Menu Item Page Menu Item Page
Not Assigned – Red-Eye Corr. p. 113
ND Filter p. 140 Digital Tele-converter p. 72
White Balance p. 143 i-Contrast p. 138
Custom WB1, 2
(White Balance)
p. 144
AF Lock p. 128
Display Off p. 156
1
Select [Set Shortcut
button].
1. Press the MENU button.
2. In the menu, use the or
button to select [Set Shortcut button].
3. Press the button.
2
Make settings.
1. Use the , , or button to
select the function you wish to
register.
2. Press the button.
3. Press the MENU button.
• If displays to the icon’s lower right, you can register the
function, but you cannot use it with some shooting modes or
settings even if you press the button.
COPY
156
Using the Button
1
Press the button.
• , , : Each time that the button is pressed, the
settings of the registered functions are switched.
• , : The corresponding setup screen is displayed.
• , : Each press of the button records the white balance
data. Ensure that the white paper or cloth is positioned so it
appears at the center of the LCD monitor and then press the
button. After using this function once, the white balance
setting changes to or .
• : Each press of the button sets AF lock.
• : Pressing the button turns off the LCD monitor. The
display turns on again by pressing any button other than the
power button or changing the camera orientation.
COPY
157
Various Shooting Methods
You can quickly access commonly used menu items from a single
screen by registering them in My Menu. You can also configure My
Menu to appear immediately after pressing the MENU button in
shooting mode.
Setting My Menu
Available Shooting Modes p. 300
1
Select [My Menu settings].
1. Press the MENU button.
2. Use the or button to select the
menu.
3. Use the or button to select [My
Menu settings].
4. Press the button.
2
Select the menu items to
register.
1. Use the or button to select
[Select items].
2. Press the button.
3. Use the or button to select the
menu item you wish to register.
4. Press the button.
• Up to five menu items can be
registered.
• To cancel registration, press
FUNC./SET again to remove the
3
mark.
• You can register a menu item even if it appears gray.
However, you may not be able to use the item depending on
the shooting mode.
5. Press the MENU button.
COPY
158
3
Change the order in which
menu items are displayed.
1. Use the or button to select
[Sort].
2. Press the button.
3. Use the or button to select a
menu item to move.
4. Press the button.
5. Use the or button to move the
menu item.
6. Press the FUNC./SET button.
7. Press the MENU button.
4
Set a default view.
1. Use the or button to select
[Set default view].
2. Use the or button to select
[Yes].
• [Yes]: When pressing the MENU
button, [My Menu] will be displayed.
• [No]: When pressing the MENU button, [Rec. Menu] will be
displayed.
COPY
159
Playback/Erasing
To Cancel the Magnified Display:
Press the zoom lever toward . (You can also cancel it immediately
by pressing the MENU button.)
In playback mode, you can select images with the control dial.
Turning it counterclockwise selects the previous image while turning
it clockwise selects the next image. Please also see Viewing Still
Images (p. 19).
Viewing Magnified Images
1
Press the zoom lever
toward .
• A magnified portion of the image will
display.
• Images can be magnified up to a
factor of approximately 10x.
2
Use the , , or button to move around
the image.
• If you use the control dial while in the magnified display mode,
the camera will switch to the previous or next image at the same
level of magnification.
• You can change the magnification level with the zoom lever.
and index playback images cannot be magnified.
Approximate location
of the displayed area
Playback/Erasing
COPY
160
To Return to Single Image Playback:
Press the zoom lever toward .
Viewing Images in Sets of Nine
(Index Playback)
1
Press the zoom lever
toward .
• Up to nine images can be viewed at
once in index playback.
• Use the , , or button or
control dial to change the image
selection.
Switching between Sets of Nine Images
The jump bar will display if you press the button while in index
playback and you can switch the display between sets of nine
images.
• Pressing the zoom lever toward also
switches the display.
• Use the or button or control dial to
move to the previous or next set of 9
images.
• Hold the FUNC./SET button down and
press the or button to jump to the
first or last set.
To Return to Single Image Playback:
Press the button.
Selected Image
Movie
Jump Bar
COPY
161
Playback/Erasing
Focus Check display allows you to check the focus of images taken.
Moreover, as you can change the display size and switch images, you
can easily check facial expressions and whether a subject’s eyes are
closed.
Displaying the Focus Check
Checking the Focus and People’s
Expressions (Focus Check Display)
1
Press the DISP. button
several times until the
Focus Check displays.
• Frames are displayed on the image as follows.
• The orange frames allow you to change the display
magnification, move the display position, and switch between
display frames (p. 162).
Frame color Description
Orange Displays an area of the image at bottom right of the
LCD monitor.
White Displays on detected faces or locations the camera
focuses on.
Gray Displays frames in positions where faces were
detected during playback.
COPY
162
Changing the Display Magnification and Display
Position
To Cancel Changing the Display Size and Display Position:
Press the MENU button.
Switching Frames
2
Press the zoom lever
toward .
• Bottom right of the screen will be
displayed prominently and the display
size and display position can be
changed.
3
Change the setting.
• You can change the display size by
pressing the zoom lever.
• You can change the display position
by using the , , or button.
• If the number of focused AF frames or
detected faces is 1 or 0, the orange
frame returns to its original position when you press the FUNC./
SET button. (If you zoomed in or out on a detected face, the
size of the frame will revert to the original face size.)
2
Press the button.
• If there are multiple focused AF
frames or detected faces, the orange
frame changes its position when you
press the FUNC./SET button. (If you
zoomed in or out on a detected face,
the size of the frame will revert to the
original face size.)
COPY
163
Playback/Erasing
When you have many images recorded onto a memory card, it is
handy to use the search keys below to jump over images to find the
object of your search.
Jumping to Images
Jump Shot Date Jumps to the first image of each shooting date.
Jump to My
Category
Jumps to the first image of each folder sorted by
the Auto Category (p. 154) or My Category
(p. 165) functions.
Jump to Folder Displays the first image in each folder.
Jump to Movie Jumps to a movie.
Jump 10 images Jumps over 10 images at a time.
Jump 100 images Jumps over 100 images at a time.
1
In single image playback mode, press the
button.
• The camera will switch to jump search mode.
2
Use the or button to
select a search key.
• The screen sample will vary slightly
according to the search key.
• You can show/hide image
information using the DISP. button.
Image Information
COPY
164
3
Display the Images.
, , Selected
1. Use the or button to select
date, category or folder for playback.
• You can check the target image by
using the control dial.
• If you select when an image has
not been assigned to any category,
you will only be able to select
(none) as a search key.
2. Press the button.
• The camera will switch to defined playback mode and display a
blue frame. You can limit playback to the images corresponding
to the search key.
• Press the button to cancel defined playback mode.
, , Selected
1. Press the or button.
• Pressing the MENU button cancels
the setting.
• Press the FUNC./SET button to switch
the camera to defined playback mode
when is selected.
The defined playback mode will be canceled under the
following circumstances.
- Changing categories (while using My Category to define
images)
- When you press the FUNC./SET button while specifying a
range of images, and the first or last image is displayed
- When displaying images not supported in defined playback
(except when selecting images in a range)
- When newly saving images that have effects added or edited
- When images are deleted using [Erase] from the menu
Select the search key
COPY
165
Playback/Erasing
You can organize images into prepared categories. Category
information recorded with the [Auto Category] function (p. 154) can be
edited. You can also organize one image into multiple categories. The
following operations can be performed if the images are sorted into
categories.
• Image searches (p. 163) • Slide Show (p. 177) • Protect (p. 197)
• Erase (p. 202) • Configure print settings (p. 207)
Category Selection Methods
Organizing Images by Category
(
My Category)
People My Category 1 – 3
Scenery To Do
Events
Select For viewing and selecting images singly.
Select Range
For picking a first and last image and selecting all the
images in the range.
1
Select [My Category].
1. Press the MENU button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Choose a selection method.
1. Use the or button to choose a
selection method.
2. Press the button.
COPY
166
[Select]
[Select Range]
3
Categorize the images.
1. Use the or button to select
images to categorize.
2. Use the or button to select a
category.
3. Press the button.
• Pressing the FUNC./SET button again cancels the setting.
• This also can be set in the index playback mode.
• Press the MENU button to complete the setting.
3
Select the first image.
• You can use the control dial to select
the first or last image.
1. Press the button.
2. Use the or button to select the
first image in the range to categorize.
3. Press the button.
COPY
167
Playback/Erasing
4
Select the last image.
1. Use the button to select [Last
image].
2. Press the button.
3. Use the or button to select the
last image in the range to categorize.
4. Press the button.
• An image with a lower number than
the first image cannot be selected as
the last image.
• Up to 500 images can be selected.
5
Select a category.
1. Press the button.
2. Use the or button to select a
category.
6
Make settings.
1. Press the button to select [Select].
2. Press the button.
• The screen will return to the selection
method screen.
• Selecting [Deselect] cancels
categorization of the selected range.
COPY
168
You can trim a required portion of a recorded image and save it as a
new image file.
Trimming a Portion of an Image
1
Select [Trimming].
1. Press the MENU button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Select an image.
1. Use the or button to select an
image for trimming.
2. Press the button.
• The trimming frame (the area of the
image which can be trimmed) is
displayed in green.
Trimming Frame
Image After Trimming
COPY
169
Playback/Erasing
3
Adjust the trimming frame.
• You can change the size of the
trimming frame using the zoom lever.
However, the resolution of the saved
image will differ according to the size
of the trimmed image.
• You can change the position of the
trimming frame using the , ,
or button.
• Press the DISP. button to change the vertical/horizontal
orientation of the trimming frame.
• If a face is detected, a gray frame appears around the face
displayed in the top left screen. Trimming can be performed
around this gray frame. If multiple frames are displayed, you can
switch between frames by turning the control dial.
4
Save the image.
1. Press the button.
2. Use the or button to select
[OK].
3. Press the button.
• The trimmed image will be saved in a
new file.
• If you wish to continue trimming of another image, repeat
operations from Step 2.
5
Display the saved image.
1. Press the MENU button.
2. Use the or button to select
[Yes].
3. Press the button.
• Selecting [No] returns to the Play
menu.
Resolution After Trimming
COPY
170
z , , or images, and images recorded in
cannot be trimmed.
z Some images shot with another camera cannot be trimmed.
z The aspect ratio for images which can be trimmed will be
fixed to 4:3 (or 3:4 if the image is vertically oriented).
z The resolution of a trimmed image will be less than before
trimming.
COPY
171
Playback/Erasing
Viewing Movies
1
Display a movie.
1. Use the or button to select a
movie.
2. Press the button.
• Images with a icon are movies.
2
Play the movie.
1. Use the or button to
select .
2. Press the button.
• The movie will pause if you press
the FUNC./SET button during
playback. It will resume when you
press the button again.
• When playback ends, the movie
stops at the last frame displayed.
Press the FUNC./SET button to
display the movie control panel.
• You can switch between showing/hiding the playback progress bar
by pressing the DISP. button while playing a movie.
• If playback was halted partway through in the prior viewing
session, playback will resume from the last frame displayed.
Volume Level
(Adjust it with the
or
button)
Movie Control Panel
Playback Progress Bar
Time movie was shot
COPY
172
Operating the Movie Control Panel
* Printing is possible only from printers that support (PictBridge) connections. For
details, refer to the operating instructions for your printer.
Exit Ends playback and returns to single image playback.
Print
An icon will display when a printer is connected*.See
the Direct Print User Guide for details.
Play Starts playback.
Slow Motion
You can use the button to slow down or the
button to speed up playback.
First Frame Displays the first frame.
Previous
Frame
Rewinds if the FUNC./SET button is held down.
Next Frame Fast Forwards if the FUNC./SET button is held down.
Last Frame Displays the last frame.
Edit Switches to the movie editing mode (p. 173).
z Movies cannot be played in the index playback mode.
z You may experience frame dropping and audio breakup
when playing back a movie on a computer with insufficient
system resources.
z Use the television’s controls to adjust the volume when
playing a movie on a TV set (p. 228).
z The sound cannot be played in slow motion playback.
COPY
173
Playback/Erasing
You can delete portions of recorded movies.
Editing Movies
Movies 1 second or longer before editing can be edited in 1-
second increments, but those that are protected or less than 1
second long cannot be edited.
1
Select [Edit].
1. In the movie control panel, use the
or button to select .
2. Press the button.
• The movie editing panel and the movie
editing bar will display.
2
Edit the movie.
1. Use the or button to select
(Cut Beginning) or (Cut End).
2. Use the or button to specify the
cut point ( ).
• While moving the cut point using the
or button, is displayed at
each 1 second interval, allowing you
to cut the movie at the indicated point.
• Even if you specify the cut point at a position other than ,
selecting will delete the beginning portion of the movie up to
the point just before your specified cut point, and selecting
will delete the latter portion of the movie from the point
just after your specified cut point. The edited movie will be
saved.
• To check a temporarily edited movie, select (Play) and press
the FUNC./SET button.
• To continue editing, repeat Step 2.
•
Selecting
(Exit) cancels the edit and restores the movie
control panel.
Movie Editing Bar
Movie Editing Panel
COPY
174
3
Select [Save].
1. Use the or button to select .
2. Press the button.
4
Save the file.
1. Use the , , or button to
select [New File] or [Overwrite].
2. Press the button.
• [New File] saves the edited movie
under a new file name. The pre-edit
data is left unchanged. Note, if you press the FUNC./SET button
while saving the movie, saving is canceled.
• [Overwrite] saves the edited movie with its original name. The
pre-edit data is lost.
• When there is not enough space left on the memory card, only
[Overwrite] can be selected.
Depending on the movie’s file size, it may take some time to
save an edited movie. If the battery runs out of charge partway
through, edited movie clips cannot be saved. When editing
movies, it is recommended to use a fully charged battery or the
separately sold AC Adapter Kit ACK-DC50 (p. 258).
COPY
175
Playback/Erasing
Images can be rotated clockwise 90° or 270° in the display.
Rotating
Images in the Display
1
Select [Rotate].
1. Press the MENU button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Rotate the image.
1. Use the or button to select an image to rotate.
2. Press the button.
• Cycle through the 90°/270°/original orientations with each press
of the FUNC./SET button.
• This also can be set in the index playback mode.
When images are downloaded to a computer, the orientation of
images rotated by the camera will depend upon the software
used to download the images.
The orientation is recorded in the image.
Original 90° 270°
COPY
176
You can select the transition effect displayed when switching between
images.
Playback with Transition Effects
No transition effect.
The displayed image darkens and the next image gradually brightens
until it is displayed.
Press the button to have the previous image display from the left
and the button to have the next image display from the right.
1
Select [Transition].
1. Press the MENU button.
2. In the menu, use the or
button to select .
2
Make settings.
1. Use the or button to select a
transition effect.
2. Press the MENU button.
COPY
177
Playback/Erasing
Automated playback of memory card images.
Image settings for slide shows are based on the Digital Print Order Format (DPOF)
standard (p. 207).
Automated Playback (Slide Shows)
All Images Plays all images on a memory card in order.
Date Plays images bearing a specified date in order.
My Category
Plays the images in the selected category in order.
Folder Plays images in a specified folder in order.
Movies Plays movie files only, in order.
Stills Plays still images only, in order.
–
Custom
1 – 3
Plays the images selected for each slide show,
Custom 1, Custom 2 or Custom 3, in order (p. 180).
1
Select [Slide Show].
1. Press the MENU button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Select a playback method.
1. Press the button.
2. Use the or button to select the
slide show type.
• , , : Press the FUNC./SET
button to select a date, category or
folder to be played back (p. 179).
• – : Press the FUNC./SET button to select the images to
be played back (p. 180).
• If you want to add a transition effect to play back images, use
the button to select [Effect] and choose the type of effect
with the or button (p. 178).
COPY
178
To Stop the Slide Show:
Press the MENU button.
Transition Effects
You can select the transition effect used when one image is replaced
by another.
3
Start the slide show.
1. Press the button.
2. Use the or button to select
[Start].
3. Press the button.
• The following functions are available
during slide shows.
- Pausing/resuming: Press the FUNC./SET button.
- Fast forwarding/rewinding: Press the or button (continue
to hold the button to switch between images more rapidly).
No transition effect.
The new image gradually brightens as it moves upward from the bottom.
The new image first appears in a cross shape and gradually expands
to display the full image.
Portions of the new image move horizontally, then the image expands
to display the full image.
In single image playback mode, you can start a slide show from
the current image displayed by holding the FUNC./SET button
while you press the button.
COPY
179
Playback/Erasing
Select a date/category/folder to play back ( ,
, )
1
Select a playback method.
1. Use the or button to select
, or .
2. Press the button.
2
Select images to play
back.
1. Use the or button to select a
date/category/folder to playback.
2. Press the button.
•A 3 will appear on selected
images.
• To cancel the selection: Press the FUNC./SET button again.
• Multiple selections can be made for the date/category/folder.
• The images will play back in the order of selection (except
when selecting category).
• You can check the images for each date/category/folder by
using the or button.
• Pressing the MENU button completes the setting.
COPY
180
Selecting Images for Playback ( – )
Select only the images that you wish to play back and save them as
a slide show (Custom 1, 2 or 3). Up to 998 images can be selected.
They will be played back in their order of selection.
1
Select a playback method.
1. Use the or button to select
, or .
• Only the icon will display at
first.
2. Press the button.
• When you set , the icon will change to and will
display. and will change in the same way when they
are set.
2
Select images to play
back.
1. Use the or button to select
images to play back.
2. Press the button.
•A 3 will appear on selected
images.
• To cancel the selection: Press the
FUNC./SET button again.
• You can also select images in the index playback mode.
• Pressing the MENU button completes the setting.
Number indicating
the selection order
Check mark
indicating selection
COPY
181
Playback/Erasing
Adjusting the Play Time and Repeat Settings
• Play Time
Sets the duration that each image displays. Choose between 3 –
10 seconds, 15 seconds and 30 seconds. Displaying time can vary
slightly depending on the image.
•Repeat
Sets whether the slide show stops when all the slides have been
displayed or continues until stopped.
1
Select [Set up].
1. Use the or button to select
[Set up].
2. Press the button.
2
Configure the setting.
1. Use the or button to select
[Play Time] or [Repeat].
2. Use the or button to select a
setting.
3. Press the MENU button.
Selecting All Images
1. After selecting – in Step 1, use the button to
select [Mark all] and press the FUNC./SET button.
2. Use the button to select [Mark all], press the FUNC./
SET button.
3. Use the button to select [OK] and press the FUNC./
SET button.
To deselect all images, select [Reset].
COPY
182
You can correct red eyes in recorded images.
Red-Eye Correction Function
Red eyes may not be automatically detected in some images
or the results may not turn out as you intended. We
recommend that you use [New File] to save corrected images.
Examples:
- Faces near the screen edges or faces that appear extremely
small, large, dark or bright in relation to the overall image.
- Faces turned to the side or at a diagonal, or faces with a
portion hidden.
1
Select [Red-Eye Correction].
1. Press the MENU button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Select an image.
1. Use the or button to select the
image you wish to correct red eyes.
2. Press the button.
• A frame will automatically display
where red-eye is detected.
• If red-eye is not automatically detected, select [Add Frame] with
the , , or button and press FUNC./SET button
(p. 185).
• To cancel the correction frame, select [Remove Frame] and
press the FUNC./SET button (p. 186).
COPY
183
Playback/Erasing
3
Correct the image.
1. Use the , , or button to
select [Start].
2. Press the button.
4
Save the image.
1. Use the , , or button to
select [New File] or [Overwrite].
2. Press the button.
• [New File]: Saved as new file with a
new name. The uncorrected image is
stored. The new image is stored as the last file.
• [Overwrite]: Saved with the same file name as the uncorrected
image. The uncorrected image is erased.
• When [New File] is selected, proceed to Step 5.
• If you wish to continue correcting another image, repeat
operations from Step 2.
5
Display the saved image.
1. Press the MENU button.
2. Use the or button to select
[Yes].
3. Press the button.
• Selecting [No] returns to the Play
menu.
COPY
184
z Red-eye correction cannot be performed on and RAW
images. When shooting in [Record + ], red-eye
correction can be performed on the JPEG image, but the
original image cannot be overwritten.
z Overwriting cannot be performed on protected images.
z When there is not enough space left on the memory card,
red-eye correction cannot be performed.
z Although you can apply red-eye correction any number of
times to an image, the image quality will gradually deteriorate
with each application.
z Since the correction frame will not appear automatically on
images that have already been corrected once with the Red-
Eye Correction function, use the [Add Frame] option to
correct them.
COPY
185
Playback/Erasing
Add Correction Frame
1
Select [Add Frame].
1. Use the , , or button to
select [Add Frame].
2. Press the button.
• A green frame will display.
2
Adjust the position of the
correction frame.
1. Use the , , or button to
move the frame.
• Size of the frame can be changed
with the zoom lever.
3
Add additional correction frames.
1. Press the button.
• A correction frame is added and the frame color changes to
white.
• If you wish to add additional frames, adjust the position and
press the FUNC./SET button.
• Up to 35 frames can be added.
• To end the adding of correction frames, press the MENU
button.
To correctly perform red-eye correction, take note of the
following (refer to the image in Step 2):
- Adjust the correction frame size so that it only surrounds
the red-eye portion to be corrected.
- When there are several subjects with red-eye, be sure to
add one correction frame per subject.
COPY
186
Removing Correction Frames
1
Select [Remove Frame].
1. Use the , , or button to
select [Remove Frame].
2. Press the button.
2
Select a frame you wish to
remove.
1. Use the or button to select a
frame to remove.
• The selected frame will appear in
green.
3
Delete the frame.
1. Press the button.
• The selected frame will disappear.
• To continue deleting frames, repeat operations from Step 2.
• When you finish deleting frames, press the MENU button.
COPY
187
Playback/Erasing
You can automatically detect and brighten dark areas in an image, and
then save it as a new image.
Brightening Dark Areas (i-Contrast)
1
Select [i-Contrast].
1. Press the MENU button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Select the image to
brighten.
1. Use the or button to select an
image.
2. Press the button.
3
Select the brightness
compensation level.
1. Use the or button to select the
option.
2. Press the button.
• If you are not satisfied with the results
of [Auto], select [Low], [Medium], or [High].
COPY
188
4
Save the image.
1. Use the or button to select
[OK].
2. Press the button.
• If you wish to continue compensating
of another image, repeat operations
from Step 2.
5
Display the saved image.
1. Press the MENU button.
2. Use the or button to select
[Yes].
3. Press the button.
• Selecting [No] returns to the Play
menu.
z Depending on the image, the picture quality may drop and
the compensation results may not be as expected.
z You can perform brightness compensation an unlimited
number of times, but the picture quality may drop.
z You cannot perform brightness compensation on RAW
images.
COPY
189
Playback/Erasing
You can add effects to recorded images (stills only) using the My
Colors function. The following selection of My Colors effects is
available. For details, see p. 146.
Adding Effects with the My Colors
Function
Vivid Lighter Skin Tone
Neutral Darker Skin Tone
Sepia Vivid Blue
B/W Vivid Green
Positive Film Vivid Red
1
Select [My Colors].
1. Press the MENU button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Select an image.
1. Use the or button to select an
image.
2. Press the button.
COPY
190
3
Select a My Colors type.
1. Use the or button to select the
My Colors type.
• The displayed image will reflect the
My Colors effect.
• You can press the zoom lever
toward to check the image at a
higher magnification. While the image is zoomed, you can
press the FUNC./SET button to switch between the image
transformed with the My Colors effect and the original non-
transformed image.
2. Press the button.
4
Save the image.
1. Use the or button to select
[OK].
2. Press the button.
• The newly saved image transformed
with the My Colors effect will be the
last one in the list.
• To continue adding effects to other images, repeat the
procedures from Step 2 onward.
5
Display the saved image.
1. Press the MENU button.
2. Use the or button to select
[Yes].
3. Press the button.
• Selecting [No] returns to the Play
menu.
COPY
191
Playback/Erasing
z You cannot add effects to RAW images using the My Colors
function.
z When there is not enough space left on the memory card,
the My Colors effects cannot be added.
z Although My Colors effects can be added any number of
times to an image, the image quality will gradually deteriorate
with each application and the intended colors may not be
achieved.
z Color in images taken using My Colors (p. 146) in shooting
mode and images edited with the My Colors function in
playback mode may differ slightly.
COPY
192
You can resave images that were recorded at high recording pixel
settings at lower settings.
Resizing Images
1600 × 1200 pixels
640 × 480 pixels
320 × 240 pixels
1
Select [Resize].
1. Press the MENU button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Select an image.
1. Use the or button to select an
image to resize.
2. Press the button.
• You cannot select the images that
cannot be resized by pressing the
FUNC./SET button.
3
Select a resolution.
1. Use the or button to select a
resolution.
2. Press the button.
• If a resolution cannot be selected due
to a lack of free space on the memory
card, will display.
COPY
193
Playback/Erasing
4
Save the image.
1. Use the or button to select
[OK].
2. Press the button.
• The resized image will be saved in a
new file. The original image will
remain.
• If you wish to continue resizing of another image, repeat
operations from Step 2.
5
Display the saved image.
1. Press the MENU button.
2. Use the or button to select
[Yes].
3. Press the button.
• Selecting [No] returns to the Play
menu.
and images shot in or mode cannot be resized.
COPY
194
In playback mode, you can attach sound memos (up to 1 min.) to an
image. The sound data is saved in the WAVE format.
Sound Memo Panel
Use the or button to select and press the FUNC./SET button.
Attaching Sound Memos to Images
1
Press the button while playing back images.
• The sound memo control panel will display.
2
Record.
1. Use the or button to select .
2. Press the button.
• The elapsed time and the remaining
time display.
• Pressing the FUNC./SET button
pauses the recording. Pressing it
again resumes recording.
• Up to 1 minute of recordings can be
added to any one image.
• The sound mode can be changed
(p. 108).
• Press the button to stop the recording session.
Exit Returns to the playback screen.
Record Starts recording.
Pause Pauses recording or playback.
Play Begins playback.
Erase
Erases sound memos. (Select [Erase] and in the
confirmation screen press the FUNC./SET button.)
z You cannot attach sound memos to .
z Sound memos for protected images cannot be erased.
Volume
(Adjust it with the or
button)
Elapsed Time/
Remaining Time
Sound Memo Panel
COPY
195
Playback/Erasing
You can record sound only, without images, for up to two hours at one
time.
Sound-Only Recording (Sound Recorder)
1
Select [Sound Recorder].
1. Press the MENU button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Record a sound.
1. Use the or button to select .
2. Press the button.
• Recording time will be displayed.
• Use the or button to change
the sample rate. Sound quality will
improve in the order of [11.025kHz],
[22.050kHz], [44.100kHz], but the
recorded file size will also increase
respectively.
• When pressing the FUNC./SET button, recording will pause.
Pressing the button once again will resume recording.
• Pressing the shutter button halfway will stop sound recording
and switch the camera to shooting mode.
• The sound mode can be changed (p. 108).
Sampling Rate
Sound Control Panel
Available Recording Time
COPY
196
Sound Recorder Panel
Use the or button to select an option and press the FUNC./SET
button.
Exit Returns to the menu screen.
Record Starts recording.
Pause Stops recording, playback.
Play
Use the or button to select a sound to play and
press the FUNC./SET button.
Rewind
Holding down the FUNC./SET button rewinds. The sound
cannot be heard while rewinding.
Fast
Forward
Holding down the FUNC./SET button fast forwards. The
sound cannot be heard while fast forwarding.
Erase
Use the , , or button to select [Erase] or
[Erase all] in the confirmation screen and press the
FUNC./SET button.
Protect
Protects against accidental erasure. Use the or
button to select a sound and the FUNC./SET button to
select/deselect protection.
Volume You can use the or button to adjust the volume.
Make sure [Audio] settings are correct (p. 108) before
recording.
z See Sound Recorder Data Rates and Recording Durations
(Estimated) (p. 283).
z When the memory cards fills, recording will automatically
stop.
z If you press and hold the button during playback, the
screen in Step 2 will display (briefly pressing the button will
bring up the sound memo panel (p. 194)).
COPY
197
Playback/Erasing
You can protect important images and movies from accidental erasure.
Protecting Images
Select You can configure the protection settings for each
image singly while viewing them.
Select Range You can select a first and last image and protect
all the images in the range.
Select by Date You can protect the images from a specified date.
Select by Category You can protect the images in a specified
category.
Select by Folder You can protect the images in a specified folder.
All Images You can protect all the images on a memory card.
1
Select [Protect].
1. Press the MENU button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Choose a selection method.
1. Use the or button to choose a
selection method.
• Pressing the MENU button returns
to the prior screen.
2. Press the button.
COPY
198
[Select]
[Select Range]
3
Protect the image.
1. Use the or button to select an
image to protect.
2. Press the button.
• Pressing the FUNC./SET button again
cancels the setting.
• To continue protecting other images,
repeat the procedure.
• You can also protect images in the index playback mode.
• Press the MENU button to complete the setting.
3
Select the first image.
• You can use the control dial to select
the first or last image.
1. Press the button.
2. Use the or button to select the
first image in the range to protect.
3. Press the button.
Protection Icon
COPY
199
Playback/Erasing
4
Select the last image.
1. Use the button to switch to
selecting the last image.
2. Press the button.
3. Use the or button to select the
last image in the range.
4. Press the button.
• An image with a lower number than
the first image cannot be selected as
the last image.
• Up to 500 images can be selected.
5
Protect the images.
1. Press the button to select
[Protect].
2. Press the button.
• The screen will return to the selection
method screen.
• Selecting [Unlock] cancels selection of the protected image.
COPY
200
[Select by Date]/[Select by Category]/[Select by Folder]
3
Select the images.
1. Use the or button to select a
date/category/folder to protect.
2. Press the button.
•A 3 will appear on selected images.
• Pressing the FUNC./SET button
again cancels the setting.
• If a portion of the images are already protected, appears
gray.
• You can select multiple dates, categories or folders.
• Use the or button to confirm each date, category or
folder image.
3. Press the MENU button.
4
Protect the images.
1. Use the or button to select
[Protect].
2. Press the button.
• Returns to the selection method
screen.
• Selecting [Unlock] removes protection for the selected images.
• Selecting [Stop] cancels protection settings for the current
selection.
COPY
201
Playback/Erasing
[All Images]
3
Protect the images.
1. Use the or button to select
[Protect].
2. Press the button.
• Returns to the selection method
screen.
• Selecting [Unlock] removes protection for all the images.
• Selecting [Stop] cancels protection settings for the current
selection.
You may cancel the operation by pressing the FUNC./SET
button during [Protect] mode.
COPY
202
You can erase images from a memory card.
Erasing Images
z Note that erased images cannot be recovered. Exercise
adequate caution before erasing an image.
z Protected images cannot be erased with this function.
Select Erase images after selecting them one at a time.
Select Range For picking a first and last image and erasing all
the images in the range.
Select by Date Erases images corresponding to the selected
date.
Select by Category Erases images in the selected category.
Select by Folder Erases images in the selected folder.
All Images Erases all images on a memory card.
1
Select [Erase].
1. Press the MENU button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Select an erasure method.
1. Use the or button to select an
erasure method.
• Pressing the MENU button returns
to the prior screen.
2. Press the button.
COPY
203
Playback/Erasing
[Select]
3
Select the image.
1. Use the or button to select an
image to erase.
2. Press the button.
• Pressing the FUNC./SET button
again deselects the setting.
• This also can be set in the index
playback mode.
3. Press the MENU button.
4
Erase the image.
1. Use the or button to select
[OK].
2. Press the button.
• Selecting [Stop] cancels selection of
the image you are about to erase and
returns to Step 2.
COPY
204
[Select Range]
3
Select the first image.
• You can use the control dial to select
the first or last image.
1. Press the button.
2. Use the or button to select the
first image in the range to erase.
3. Press the button.
4
Select the last image.
1. Use the button to switch to
selecting the last image.
2. Press the button.
3. Use the or button to select the
last image in the range.
4. Press the button.
• An image with a lower number than
the first image cannot be selected as
the last image.
• Up to 500 images can be selected.
COPY
205
Playback/Erasing
[Select by Date]/[Select by Category]/[Select by Folder]
5
Erase the images.
1. Press the button to select [Erase].
2. Press the button.
• Pressing the MENU button cancels
selection of the image you are about
to erase and returns to Step 2.
3
Select the images.
1. Use the or button to select a
date/category/folder to erase.
2. Press the button.
•A 3 will appear on selected images.
• Pressing the FUNC./SET button
again cancels the setting.
• You can select multiple dates, categories or folders.
• Use the or button to confirm each date, category or
folder image.
3. Press the MENU button.
4
Erase the images.
1. Use the or button to select
[OK].
2. Press the button.
• Selecting [Stop] cancels selection of
the image you are about to erase and
returns to Step 2.
COPY
206
[All Images]
3
Erase the images.
1. Use the or button to select
[OK].
2. Press the button.
• Selecting [Cancel] cancels selection
of the image you are about to erase
and returns to Step 2.
z Pressing the FUNC./SET button while erasing is in progress
cancels the procedure.
z Please format the memory card when you want to erase not
only image data but also all the data contained on the
memory card (pp. 16, 220).
COPY
207
Print Settings/Transfer Settings
You can select images on a memory card for printing and specify the
number of print copies in advance using the camera. The settings used
on the camera comply with the Digital Print Order Format (DPOF)
standards. This is extremely convenient for printing on a direct print
compatible printer, or for sending the images to a photo developing
service that supports DPOF.
Setting the Print Style
After setting the print style, select the images for printing. The following
settings can be selected.
* Default setting
You can also use the control dial to select images and perform
various operations. See p. 43.
Setting the DPOF Print Settings
z The specified print settings are also applied to the Print List
(p. 23).
z The output of some printers or photo developing services
may not reflect the specified print settings.
z Print settings cannot be set for and .
z The icon may display for a memory card with print
settings set by a different DPOF-compliant camera. These
settings will be overwritten by those set by your camera.
Print
Type
Standard* Prints one image per page.
Index
Prints the selected images together at a
reduced size in an index format.
Both
Prints the images in both the standard and
index formats.
Date (On/Off
*
) Adds the date to the print.
File No. (On/Off
*
) Adds the file number to the print.
Clear DPOF data (On
*
/Off) Clears all print settings after the images print.
Print Settings/Transfer Settings
COPY
208
1
Select [Print Settings].
1. Press the button.
2. Press the MENU button.
3. Use the or button to select the
menu.
4. Use the or button to select
[Print Settings].
5. Press the button.
2
Make settings.
1. Use the or button to select an
option.
2. Use the or button to specify the
settings.
3. Press the MENU button.
z The Date and File No. settings change according to the Print
Type as follows.
- [Index]:
[Date] and [File No.] cannot be set to [On] at the same time.
- [Standard] or [Both]:
[Date] and [File No.] can be set to [On] at the same time,
however, the printable information may vary between
printers.
z Dates print in the style specified in [Date/Time] in the
menu (p. 60).
COPY
209
Print Settings/Transfer Settings
Single Images
Select Images & Qty.
Configures print settings for single images as you
view them.
Select Range
For picking a first and last image and printing all the
images in the range.
Select by Date
Configures print settings for images corresponding
to the selected date.
Select by Category
Configures print settings for images in the selected
category.
Select by Folder
Configures print settings for images in the selected
folder.
Select All Images Configures print settings for all images.
Clear All Selections Removes all print settings from images.
Only one copy will be printed for each selected image. With the
[Select Images & Qty.] option, you can only set the number of
copies to print when the [Print Type] option is set to [Standard]
or [Both] (p. 207).
1
Choose a selection method.
1. Press the button.
2. Press the MENU button.
3. Use the or button to select the
menu.
4. Use the or button to choose a
selection method.
5. Press the button.
COPY
210
[Select Images & Qty.]
2
Select the images.
Selection methods differ depending on the Print Type settings
(p. 207).
Standard ( )/Both ( )
1. Use the or button to select the
images.
2. Press the button.
3. Use the or button to select the
number of print copies (up to 99).
4. Press the MENU button.
Index ( )
1. Use the or button to select the
images.
2. Select and deselect with the
button.
3. Press the MENU button.
• This also can be set in the index
playback mode.
Number of Print Copies
Index Print Selection
COPY
211
Print Settings/Transfer Settings
[Select Range]
2
Select the first image.
• You can use the control dial to select
the first or last image.
1. Press the button.
2. Use the or button to select the
first image in the print range.
3. Press the button.
3
Select the last image.
1. Use the button to switch to
selecting the last image.
2. Press the button.
3. Use the or button to select the
last image in the range.
4. Press the button.
• An image with a lower number than
the first image cannot be selected as
the last image.
• Up to 500 images can be selected.
COPY
212
[Select by Date]/[Select by Category]/[Select by Folder]
4
Configure the print settings.
1. Press the button to select [Order].
2. Press the button.
• The screen will return to the selection
method screen.
• Pressing the MENU button cancels
the print settings for the selected range of images.
2
Select the images.
1. Use the or button to select a
date/category/folder to print.
2. Press the button.
•A
3 will appear on selected
images.
• Pressing the FUNC./SET button
again cancels the setting.
• You can select multiple dates, categories or folders.
• Use the or button to confirm each date, category or
folder image.
3. Press the MENU button.
3
Configure the print settings.
1. Use the or button to select
[OK].
2. Press the button.
• The screen will return to the selection
method screen.
• Selecting [Stop] cancels print settings of the selected image.
COPY
213
Print Settings/Transfer Settings
[Select All Images]
[Clear All Selections]
2
Configure the print settings.
1. Use the or button to select
[OK].
2. Press the button.
• The screen will return to the selection
method screen.
• Selecting [Cancel] cancels print settings of the selected image.
2
Deselect the images.
1. Use the or button to select
[OK].
2. Press the button.
• The screen will return to the selection
method screen.
• Selecting [Cancel] cancels the operation.
z Images are printed in order according to the file number.
z A maximum of 998 images can be selected.
z When the camera is connected to a printer, the button
will light blue. At this time, printing will begin after performing
the following.
1. Press the button.
2. Confirm that [Print] is selected, then press the FUNC./SET
button.
COPY
214
You can use the camera to specify settings for images before
downloading to a computer. Refer to the Software Starter Guide for
instructions on how to transfer images to your computer. The settings
used on the camera comply with the DPOF standards.
Setting the DPOF Transfer Settings
The icon may display for a memory card with transfer
settings set by a different DPOF-compliant camera. These
settings will be overwritten by those set by your camera.
1
Select [Transfer Order].
1. Press the button.
2. Press the MENU button.
3. In the menu, use the or
button to select .
4. Press the button.
2
Select an order method.
1. Use the or button to select an
order method.
Order : Select single images.
Mark all : Select all the images on a
memory card.
2. Press the button.
• Selecting [Reset] cancels all transfer order settings.
COPY
215
Print Settings/Transfer Settings
Single Images
Mark all
3
Select an image to transfer.
1. Use the or button to select an
image to transfer.
2. Press the button.
• Pressing the FUNC./SET button
again deselects the setting.
• This also can be set in the index
playback mode.
3. Press the MENU button several times.
3
Transfer images.
1. Use the or button to select
[OK].
2. Press the button.
3. Press the MENU button several
times.
z Images are transferred in order according to the file number.
z A maximum of 998 images can be selected.
Transfer Selection
COPY
216
Configuring the Camera
This camera is equipped with a power saving function, which can
automatically turn off the power or LCD monitor.
Power Saving Function
Auto Power Down When set to [On], the power will shut off in the
following circumstances. Press the power button again
to restore power.
Shooting mode: Approximately 3 minutes after the last
control is accessed on the camera.
Playback mode or when connected to a printer:
Approximately 5 minutes after the last control is
accessed on the camera.
Display Off In shooting mode, the LCD monitor automatically turns
off after the selected time if no control is accessed,
regardless of the [Auto Power Down] setting. Press
any button other than the power button or change the
camera orientation to turn the LCD monitor back on.
1
Select [Power Saving].
1. Press the MENU button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Power Saving].
4. Press the button.
2
Make settings.
1. Use the or button to select an
option.
2. Use the or button to make
settings.
3. Press the MENU button.
COPY
217
Configuring the Camera
When traveling abroad, you can record images with local dates and
times simply by switching the time zone setting if you pre-register the
destination time zones. You can enjoy the convenience of not having
to switch the Date/Time settings.
Setting the Home/World Time Zones
3
Press the MENU button.
The power saving function will not activate during a slide show
or while the camera is connected to a computer.
Setting the World Clock
1
Select [Time Zone].
1. Press the MENU button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Time Zone].
4. Press the button.
2
Select (Home).
1. Use the or button to select
.
2. Press the button.
• When using for the first time, confirm
that the screen to the right appears,
then press the FUNC./SET button.
COPY
218
Switching to the Destination Time Zone
3
Select an area as home.
1. Use the or button to select a
home time zone.
2. Press the button.
• To set the daylight saving option, use
the or button to display .
The time will advance by 1 hour.
4
Select (World).
1. Use the button to select .
2. Press the button.
5
Select a destination area.
1. Use the or button to select a
destination time zone.
2. Press the button.
• As in Step 3, you can set daylight
saving time.
1
Select [Time Zone].
1. Press the MENU button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Time Zone].
4. Press the button.
Time Difference from
the Home Time Zone
COPY
219
Configuring the Camera
2
Select (World).
1. Use the or button to select .
2. Press the MENU button twice.
• To change the destination time zone,
use the FUNC./SET button.
• When you switch to the destination
time zone, will display on the LCD monitor.
If you do not select a home time zone beforehand, you cannot
configure the destination time.
If you change the date and time when the World option is
selected, the Home date and time will also change
automatically.
COPY
220
We recommend you select [Low Level Format] when you think that the
recording/reading speed of a memory card has dropped.
Low Level Formatting Memory Cards
Please note that formatting (initializing) a memory card erases
all data (including protected images (p. 197) and sound data
recorded with the sound recorder (p. 195)).
1
Select [Format].
1. Press the MENU button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Format].
4. Press the button.
2
Make settings.
1. Use the button to select [Low
Level Format].
2. Use the or button to add a
check mark.
3. Use the , , or button to
select [OK].
4. Press the button.
• You can stop formatting a memory card by pressing the FUNC./
SET button. You can still use a memory card without problem
when formatting is halted, but its data will be erased.
• A low level format may require 2 to 3 minutes with some
memory cards.
Displays when sound
data recorded with the
sound recorder is present.
COPY
221
Configuring the Camera
The images you shoot are automatically assigned file numbers. You
can select how the file number is assigned.
Resetting the File Number
Continuous
A number one higher than the last one recorded is assigned
to the next image. This is convenient for managing all your
images together on a computer because you avoid file name
duplication when changing folders or memory cards.*
* When a blank memory card is used. If a memory card with recorded
data is used, the 7-digit number for the last recorded folder and
image is compared with the last one on the memory card, and the
larger of the two is utilized as the basis for new images.
Auto Reset
The image and folder number are reset to the starting value
(100-0001).* This is convenient for managing images on a
folder-by-folder basis.
* When a blank memory card is used. If a memory card with recorded
data is used, the number following the 7-digit number for the last
recorded folder and image on the memory card is utilized as the
basis for new images.
1
Select [File Numbering].
1. Press the MENU button.
2. Use the or button to select the
menu.
3. Use the or button to select
[File Numbering].
2
Make settings.
1. Use the or button to select a
file numbering setting.
2. Press the MENU button.
COPY
222
File and Folder Numbers
Recorded images are assigned consecutive file numbers starting with
0001 and ranging up to 9999, while folders are assigned numbers
starting with 100 and ranging up to 999. Up to 2000 images can be
saved into a single folder.
• Images may be saved to a new folder when there is insufficient free space even if the
total number of images in a folder is less than 2000 because the following types of
images are always saved together into the same folder.
- Images from continuous shooting
- Self-timer images (Custom and FaceSelf-Timer)
- Movies
- Stitch Assist mode images
- Focus Bracketing
- AEB shooting
- Still images shot in Color Accent/Color Swap mode with the [Save Original] category
set to [On].
• Images cannot be played back when the folder numbers are duplicated or image
numbers are duplicated within folders.
• Please refer to the Software Starter Guide for information regarding folder structures
or image types.
New Folder Created Memory Card Exchanged for Another
Continuous
Memory Card 1
Memory Card 1 Memory Card 2
Auto Reset
Memory Card 1 Memory Card 1 Memory Card 2
COPY
223
Configuring the Camera
You can create a new folder at any time and the recorded images will
be automatically saved to that folder.
Creating a Folder the Next Time You Shoot
Creating an Image Destination (Folder)
Create New
Folder
Creates a new folder the next time you shoot images. To
create an additional folder, insert the check mark again.
Auto Create
You can also specify a date and time if you wish to create a
new folder using a shooting time after the specified date and
time.
1
Select [Create Folder].
1. Press the MENU button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Create Folder].
4. Press the button.
2
Make settings.
1. Use the or button to check
mark [Create New Folder].
2. Press the MENU button.
• will be displayed on the LCD
monitor when shooting. The symbol
will disappear from the screen when a new folder is created.
COPY
224
Setting the Day or Time for Automatic Folder
Creation
1
Select [Create Folder].
1. Press the MENU button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Create Folder].
4. Press the button.
2
Make settings.
1. Use the or button to select
[Auto Create] and the or button
to select a creation date.
2. Use the or button to select
[Time] and the or button to
select a time.
3. Press the MENU button.
• displays when the specified time arrives. The symbol will
cease to display after the new folder is created.
Up to 2000 images can be saved into one folder. A new folder
will automatically be created when you record more than that
number even if you are not creating new folders.
COPY
225
Configuring the Camera
Your camera is equipped with an Intelligent Orientation sensor that
detects the orientation of an image shot with the camera held
vertically and automatically rotates it to the correct orientation when
viewing it in the LCD monitor.
Setting the Auto Rotate Function
1
Select [Auto Rotate].
1. Press the MENU button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Auto Rotate].
2
Make settings.
1. Use the or button to select [On]
or [Off].
2. Press the MENU button.
• When the Auto Rotate function is set
to [On] and the LCD monitor is set to
the detailed display mode in the shooting mode, (normal),
(right end is down) or (left end is down) will appear in the
display.
z This function may not operate correctly when the camera is
pointed straight up or down. Check that the arrow is
pointing in the right direction and if it is not, then set the Auto
Rotate function to [Off].
z Even if the Auto Rotate function is set to [On], the orientation
of images downloaded to a computer will depend upon the
software used to download the images.
COPY
226
When the camera is held vertically to shoot, the Intelligent
Orientation sensor judges the upper end to be “up” and the
lower end to be “down”. It then regulates the optimal white
balance, exposure and focus for vertical photography. This
function operates regardless of the on/off status of the Auto
Rotate function.
COPY
227
Configuring the Camera
Resetting Settings to Their Default
Values
1
Select [Reset All].
1. Press the MENU button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Reset All].
4. Press the button.
2
Make settings.
1. Use the or button to select
[OK].
2. Press the button.
z When returning the / registration contents to the
default setting, turn the mode dial to or to operate.
z Settings cannot be reset when the camera is connected to a
computer or to a printer.
z The following cannot be reset.
- The shooting mode
- The [Time Zone], [Date/Time], [Language] and [Video
System] options in the menu (p. 60)
- ISO speed
- Exposure compensation
- White balance data recorded with the custom white
balance function (p. 144)
- Colors specified in the [Color Accent] (p. 149) or [Color
Swap] (p. 151) mode
- Newly added My Camera settings (p. 231)
COPY
228
Connecting to a TV
You can use the supplied AV cable to shoot or playback images using
a TV.
Shooting/Playback Using a TV
1
Turn off the camera and the TV.
2
Connect the AV cable to the
camera’s A/V OUT terminal.
• Open the terminal cover, and plug the
AV cable in all the way.
3
Plug the other ends of the
AV cable to the VIDEO IN
and AUDIO IN jacks on the
TV.
4
Turn on the TV and switch it to Video mode.
5
Turn on the camera.
VIDEO
Yellow
Black
AUDIO
COPY
229
Connecting to a TV
z The video output signal can be switched (NTSC or PAL) to
accommodate different regional standards (p. 61). The
default setting varies between regions.
- NTSC: Japan, U.S.A., Canada, Taiwan and others
- PAL: Europe, Asia (excluding Taiwan), Oceania and others
z If the video system is set incorrectly, the camera output may
not display properly.
COPY
230
Customizing the Camera (My Camera Settings)
My Camera allows you to customize the start-up image and start-up,
operation, self-timer and shutter sounds. You can change and register
these settings, enabling you to customize the camera to suit your own
tastes.
You can also use the control dial to select images and perform
various operations. See p. 43.
Changing My Camera Settings
1
Select a menu item.
1. Press the MENU button.
2. Use the or button to select the
menu.
3. Use the or button to select
menu item.
2
Make settings.
1. Use the or button to select
contents you wish to set.
2. Press the MENU button.
• Select [Theme] in sub step 3 of Step 1
to set all to the same settings.
When [Shutter Sound] is set to or , a shutter sound
matching the shutter speed will play.
COPY
231
Customizing the Camera (My Camera Settings)
Images recorded onto the memory card and newly recorded sounds
can be added as My Camera settings to the menu items. You can
also use the supplied software to upload your computer’s images and
sounds to the camera.
Registering My Camera Settings
A computer is required to restore the My Camera settings to the
defaults. Use the supplied software (ZoomBrowser EX/
ImageBrowser) to restore the default settings to the camera.
1
Select the menu item.
1. Press the button.
2. Press the MENU button.
3. Use the or button to select the
menu.
4. Use the or button to select the
menu item you wish to register.
2
Select .
1. Use the or button to select .
2. Press the DISP. button.
3
Make settings.
[Start-up Image]
1. Use the or button to select
image to register.
2. Press the button.
COPY
232
[Start-up Sound]/[Operation Sound]/
[Self-timer Sound]/[Shutter Sound]
1. Use the or button to select
(Record).
2. Press the button.
3. After recording, use the or
button to select (Register).
4. Press the button.
• Recording will automatically stop when the recording time
elapses.
• To play it, select (Play).
• To exit instead of registering, select (Exit).
4
Register the setting.
1. Use the or button to select
[OK].
2. Press the button.
• To cancel registering, select [Cancel].
z The following cannot be registered as My Camera settings.
-Movies
- Sounds recorded with the sound memo function (p. 194)
- Sounds recorded with the Sound Recorder (p. 195)
z The prior setting is erased when a new My Camera setting is
added.
See the supplied Software Starter Guide for more information
on creating and adding to the My Camera data.
COPY
233
Troubleshooting
• Camera (p. 233)
• When the power is turned on (p. 234)
• LCD monitor (p. 234)
• Shooting (p. 236)
• Shooting movies (p. 241)
• Playback (p. 241)
• Battery/Battery Charger (p. 242)
• TV monitor output (p. 243)
• Printing with a direct print compatible printer (p. 243)
Camera
Camera will not operate.
Power is not turned on. z Press the power button (p. 42).
Memory card/battery
cover is open.
z Confirm that the memory card/battery
cover is securely closed (p. 12).
Battery charge insufficient
to operate camera
(“Change the battery
pack” message displays).
z Insert a fully charged battery into the
camera (p. 11).
z Use the AC Adapter Kit ACK-DC50
(sold separately) (pp. 37, 258).
Poor contact between
camera and battery
terminals.
z Polish the terminals with a soft cotton
swab before charging or using the
battery (p. 254).
Sounds come from the camera interior.
The camera’s horizontal/
vertical orientation was
changed.
z The camera’s orientation mechanism
is operating. There is no malfunction.
Troubleshooting
COPY
234
When the power is turned on
“Card locked!” message appears.
The SD memory card’s or
SDHC memory card’s
write protect tab is set to
“Write protect”.
z When recording to, erasing from or
formatting the memory card, slide the
write protect tab upward (p. 256).
The Date/Time menu appears.
The built-in rechargeable
lithium battery charge is
low.
z Recharge the built-in battery
immediately (p. 10).
LCD monitor
Nothing displays.
The LCD monitor is set not
to display.
z Press the DISP. button to turn on the
LCD monitor (p. 63).
[Power Saving] is set to
[Display Off].
z Press any button other than the power
button or change the camera
orientation to turn the LCD monitor
back on (p. 216).
Camera screen is black at start-up.
Incompatible image has
been selected as the
startup image in the My
Camera settings.
z Change the start-up image in the My
Camera settings (p. 230) or use the
supplied software program
ZoomBrowser EX or ImageBrowser to
restore the default settings. See
ZoomBrowser EX/ ImageBrowser
Software User Guide (PDF).
COPY
235
Troubleshooting
The display darkens.
The image in the LCD
monitor will darken in
strong sunlight or bright
light.
z This is a normal occurrence in devices
containing CCDs and does not
constitute a malfunction. This image
will not be recorded when shooting
still photos, but it will be recorded
when shooting movies.
Display flickers.
Display flickers when shot
under fluorescent lighting.
z This is not a camera malfunction
(flickering recorded in movies, but not
in still images).
A bar of light (purplish red) appears on the LCD
monitor.
Sometimes appears when
shooting a bright subject,
such as the sun or other
light source.
z This is a normal occurrence in devices
containing CCDs and does not
constitute a malfunction. This bar of
light will not be recorded when
shooting still photos, but it will be
recorded when shooting movies.
z Setting the ND Filter on may reduce
this bar of light (p. 140).
appears.
A slow shutter speed has
likely been selected
because of insufficient
lighting.
z Set the IS Mode to any setting other
than [Off] (p. 85).
z Raise the ISO speed (p. 87).
z Use the Auto ISO Shift (p. 88).
z Set the flash to any setting other than
(flash off) (p. 73).
z Set the self-timer and secure the
camera to something, such as a tripod
(p. 75).
z If you have an externally mounted
flash, attach it (p. 265).
COPY
236
appears.
This displays when using
a memory card that has
print settings or transfer
settings set by other
DPOF-compliant
cameras.
z These settings will be overwritten by
those set by your camera (pp. 177,
207, 214).
Noise displays./Subject’s movements are
irregular.
Camera automatically
lightened the image
displayed on the LCD
monitor to make it easier
to see when shooting in a
dark area (p. 65).
z There is no effect on the recorded
image.
Shooting
Camera will not record.
Camera is in playback
mode.
z Switch to the shooting mode (p. 44).
Camera is connected to a
computer/printer mode.
z Switch to the shooting mode after
disconnecting the interface cable in
connecting to a computer/printer
mode.
Flash is charging. z When the flash is charged, the
indicator will light orange. Shooting is
now possible (p. 45).
Memory card is full. z Insert a new memory card (p. 11).
z If required, download the images to a
computer and erase them from the
memory card to make space.
COPY
237
Troubleshooting
Memory card is not
formatted correctly.
z Format the memory card (pp. 16,
220).
z If reformatting does not work, the
memory card logic circuits may be
damaged. Consult the nearest Canon
Customer Support Help Desk.
SD memory card or SDHC
memory card is write
protected.
z Slide the write protect tab upward
(p. 256).
Image Seen in Viewfinder vs. Recorded Image.
Usually the recorded
image contains more of
the scene than is seen in
the viewfinder.
z Confirm the actual image size with the
LCD monitor. Use the LCD monitor
when taking close-up shots (p. 74).
Image is blurred or out of focus.
The camera moves when
the shutter button is
pressed.
z Confirm the procedures in
“ appears” (p. 235).
AF-assist Beam is set to
[Off].
z In dark places where it is difficult for
the camera to focus, the AF-assist
Beam will emit to assist focusing. As
the AF-assist Beam will not function
when turned off, set it [On] to activate
it (p. 56). Take care not to obstruct the
AF-assist Beam with your hand when
used.
Subject is out of focal
range.
z Shoot with the subject at the correct
focusing distance (p. 276).
z The camera may be set to an
unintended function (such as macro or
manual focus). Cancel the setting.
The subject is hard to
focus on.
z Use the focus lock, AF lock or manual
focus to shoot (p. 128).
COPY
238
Subject in recorded image is too dark.
Insufficient light for
shooting.
z Set the built-in flash to (Flash on)
(p. 73).
z Use a high-output externally mounted
flash.
z Set [ND Filter] to [Off] (p. 140).
The subject is
underexposed because
the surroundings are too
bright.
z Set the exposure compensation to a
positive (+) setting (p. 137).
z Use the AE lock or spot metering
functions (p. 141).
Subject is too far away for
flash to reach.
z Shoot within correct flash range of the
subject when using the built-in flash
(p. 277).
z Raise the ISO speed and then shoot
(p. 87).
Subject in recorded image is too bright, or image
flashes white.
Subject is too close,
making the flash too
strong.
z Shoot within correct flash range of the
subject when using the built-in flash
(p. 277).
z Adjust [Flash Exp. Comp] or [Flash
Output] in the [Flash Control] menu
(p. 113).
z Set the safety FE to [On] (p. 114).
The subject is
overexposed because the
surroundings are too dark.
z Set the exposure compensation to a
negative (–) setting (p. 137).
z Use the AE lock or spot metering
functions (p. 141).
z Set [ND Filter] to [On] (p. 140).
Too much light is shining
directly into the camera, or
is being reflected off the
subject.
z Change the shooting angle.
Flash is set to (Flash
on).
z Push down the flash to (Flash off)
(p. 73).
COPY
239
Troubleshooting
Image contains noise.
ISO speed is too high. z Higher ISO speeds and (High ISO
Auto) setting may increase image
noise. For higher image quality, use
as low an ISO speed as possible
(p. 87).
z In , , , , , , ,
and modes in the mode, or
when using the Auto ISO Shift, the
ISO speed increases and noise can
appear.
White dots appear on the image.
Light from the flash has
reflected off dust particles
or insects in the air. This is
particularly noticeable
when shooting using the
wide angle or when you
increase the aperture
value in the aperture
priority mode.
z This is a phenomenon that occurs
with digital cameras and does not
constitute a malfunction.
COPY
240
Eyes appear red.
Light is reflected back
from the eyes when the
flash is used in dark
areas.
z Shoot with [Red-Eye Lamp] in the
[Flash Control] menu set to [On]
(p. 113). For this mode to be effective,
the subject must be looking right at
the red-eye reduction lamp. Try
asking them to look directly at the
lamp. Even better results can be
obtained by increasing the lighting in
indoor settings or approaching closer
to the subject.
z Set the [Red Eye Corr.] in the [Flash
Control] menu to [On] (p. 113) and
then shoot. The camera will
automatically correct red eyes while
shooting and record the image to the
card.
z You can correct red eyes in recorded
images using the [Red-Eye
Correction] in the Playback menu
(p. 182).
Continuous shooting slows down.
The memory card’s
performance has dropped.
z To enhance the continuous shooting
performance, you are recommended
to low level format the memory card in
the camera after you save all its
images to your computer (p. 220).
Recording images to memory card takes a long time.
Memory card was
formatted in another
device.
z Use a memory card formatted in your
camera (pp. 16, 220).
Lens will not retract.
Memory card/battery
cover was opened with
power on.
z After closing the memory card/battery
cover, turn the power on then back off.
COPY
241
Troubleshooting
Shooting movies
The recording time may not display properly or
shooting may stop unexpectedly.
The following types of
memory cards are used.
- Slow recording cards.
- Cards formatted on a
different camera or a
computer.
- Cards which have had
images recorded and
erased repeatedly.
z Although the recording time may not
display properly during shooting, the
movie will be recorded correctly on
the memory card. Recording time will
display properly if you format the
memory card in this camera
(excluding slow recording memory
cards) (pp. 16, 220).
“!” displayed on the LCD monitor in red and
shooting automatically stopped.
There is insufficient free
space in the camera’s
built-in memory.
z Try the following procedures.
- Format the card with a low level
format before filming (p. 220).
- Lower the recording pixels (p. 107).
Zoom does not operate.
Zoom lever was pressed
while shooting in movie
mode.
z Operate the zoom before shooting in
movie mode (p. 69). Note the digital
zoom is available while shooting (only
in Standard movie mode).
Playback
Cannot play back.
You attempted to play
back images shot with
another camera or images
edited with a computer.
z Computer images that cannot be
played back may play back if they are
added to the camera using the
supplied software program
ZoomBrowser EX or ImageBrowser.
See ZoomBrowser EX/ImageBrowser
Software User Guide (PDF).
COPY
242
File name was changed
with a computer or file
location was changed.
z Set the file name or location on the file
format/structure of the camera (refer
to the Software Starter Guide for
details).
Images cannot be edited.
Some images shot with another camera cannot be edited.
Movies do not play back correctly.
Movies recorded with high recording pixels may momentarily stop
playing if played on slow reading memory cards.
Images shot with this camera may not play back properly on other
cameras.
Reading images from memory card is slow.
Memory card was
formatted in another
device.
z Use a memory card formatted in your
camera (pp. 16, 220).
Battery/Battery Charger
Battery consumed quickly.
Battery is not being used
to its full capacity.
z See Battery (p. 254).
Battery life exceeded if
battery loses its charge
quickly at normal
temperature (23 °C/73 °F).
z Replace the battery with a new one
(p. 11).
Battery will not charge.
Battery life exceeded. z Replace the battery with a new one
(p. 11).
COPY
243
Troubleshooting
TV monitor output
Image is distorted or not showing on TV monitor.
Incorrect video system
setting.
z Set the video system to the
appropriate setting, NTSC or PAL, for
your TV (p. 61
).
Shooting in Stitch Assist
mode.
z The output will not appear on a TV in
Stitch Assist mode. Shoot in a
different shooting mode (p. 102).
Printing with a direct print compatible
printer
Cannot print.
The camera and printer
are not properly
connected.
z Securely connect the camera and
printer with the specified cable.
The printer power is not
turned on.
z Turn on the printer power.
The print connection
method is not correct.
z Select [Print Method] and select [Auto]
(p. 61).
COPY
244
List of Messages
The following messages may appear on the LCD monitor during
shooting or playback.
Please refer to the Direct Print User Guide for the messages that
display during a printer connection.
Busy...
Image is being recorded onto the memory card, red eye correction is
being processed.
Resetting all the camera and menu settings to default.
No memory card
You turned on the camera without a memory card installed, or with a
memory card installed in the wrong orientation (p. 11).
Card locked!
The SD memory card or SDHC memory card is write protected
(p. 256).
Cannot record!
You attempted to shoot an image without a memory card installed,
with a memory card installed in the wrong orientation, or attempted
to attach a sound memo to a movie.
Memory card error
The memory card may be malfunctioning. By formatting the
malfunctioning memory card with the camera, you may be able to
continue using it (pp. 16, 220). However, if this error message
continues to appear, contact your Canon Customer Support Help
Desk as there may be a problem with the camera.
Memory card full
Memory card is full of images and no more can be recorded or
saved. In addition, no more image settings, or sounds or sound
memos can be recorded.
COPY
245
List of Messages
Naming error!
The file name could not be created because there is an image with
the same name as the folder that the camera is attempting to create,
or the highest possible file number has already been reached. In the
Set up menu, set [File Numbering] to [Auto Reset]; alternatively,
save all the images you wish to retain onto a computer, then
reformat the memory card. Please note that formatting will erase all
the existing images and other data.
Change the battery pack.
Battery charge is insufficient to operate the camera. Replace it at
once with a charged one or recharge the battery. Also refer to
Battery (p. 254).
No image.
No images recorded on memory card.
Image too large.
You attempted to play back an image larger than 5616 × 3744 pixels
or with a large data size.
Incompatible JPEG
You attempted to play back an incompatible JPEG image (edited
with a computer, etc.).
RAW
You attempted to play back a different type of RAW image.
Unidentified Image
You attempted to play back an image with corrupted data, an image
with a recording type specific to another manufacturer’s camera, or
an image that has been downloaded to a computer and altered.
Cannot magnify!
You attempted to magnify an image recorded in a different camera
or data type, an image edited with a computer, or a movie.
Cannot rotate
You attempted to rotate the image shot with a different camera or
data type, or an image edited with a computer.
COPY
246
Incompatible WAVE
A sound memo cannot be added to this image since the data type of
the existing sound memo is incorrect. In addition, sound cannot be
played back.
Cannot register this image!
You attempted to register an image recorded in a different camera,
a RAW image or a movie as a start-up image.
Cannot modify image
You attempted to add My Colors effects, apply red-eye correction,
resize, or apply brightness correction to a movie, RAW image, or
image taken with another camera. Or you attempted to resize an
image already resized to or an image shot in . Or, you
attempted to trim an image recorded using , or a or
image.
Cannot assign to category
You attempted to categorize an image recorded in a different
camera.
Cannot Modify
Cannot apply red-eye correction as no red-eye is detected.
Cannot transfer!
When transferring images to your computer using the Direct
Transfer menu, an image with corrupted data, an image taken with a
different camera or data type. You may have also attempted to
select a movie or a RAW image when [Wallpaper] was selected in
the Direct Transfer menu.
Protected!
You attempted to erase or edit a protected image, movie or sound
memo.
Too many marks
Too many images have been marked with print settings, transfer
settings or slide show image settings. Cannot process any more.
Cannot complete!
Could not save a part of the print, transfer or slide show settings.
COPY
247
List of Messages
Unselectable image
You attempted to set the print settings for a non-JPEG image.
Cannot select
In selecting the image range for categorizing via the My Category
function, protecting images, erasing images or specifying print
settings, you selected a starting image with a file number higher
than the last image or a last image with a file number lower than the
starting image. Or, you specified more than 500 images.
Communication error
The computer was unable to download the image due to the large
amount of images (approx. 1000) stored on the memory card. Use a
USB card reader or a PCMCIA card adapter to download the
images.
Lens error, restart camera
An error was detected while the lens was in motion, and the power
has been automatically turned off. This error can occur if you hold
the lens while it is in motion or you operate it in a location with
excessive dust or sand in the air. Try turning the power back on, and
resume shooting or playback. If this message continues to display,
contact your Canon Customer Support Help Desk as there may be a
problem with the lens.
Exx
(xx: number) Camera detected an error. Turn the power off and then
back on, then shoot or play back. A problem exists if the error code
reappears. Note the number and contact your Canon Customer
Support Help Desk. If an error code displays directly after taking a
picture, the shot may not have been recorded. Check image in
playback mode.
COPY
248
Appendix
z Before using the camera, please ensure that you read the safety
precautions described below and in the “Safety Precautions” section.
Always ensure that the camera is operated correctly.
z The safety precautions noted on the following pages are intended to
instruct you in the safe and correct operation of the camera and its
accessories to prevent injuries or damage to yourself, other persons
and equipment.
z Equipment refers to the camera, battery charger or compact power
adapter (sold separately).
z Battery refers to the battery pack.
Safety Precautions
Warnings
Equipment
z Do not point the camera at bright light sources (the sun in
bright clear skies, etc.).
• Doing so could damage the camera’s CCD.
• Doing so can damage your eyesight.
z Store this equipment out of the reach of children and infants.
• Neck strap: Placement of the strap around the child’s neck could
result in asphyxiation.
• Memory card: It may be swallowed accidentally. If this occurs,
contact a doctor immediately.
COPY
249
Appendix
z Do not attempt to disassemble or alter any part of the
equipment that is not expressly described in this guide.
z To avoid the risk of high-voltage electrical shock, do not touch
the flash portion of the camera if it has been damaged.
z Stop operating the equipment immediately if it emits smoke or
noxious fumes.
z Do not allow the equipment to come into contact with, or
become immersed in, water or other liquids. If the exterior
comes into contact with liquids or salt air, wipe it dry with a
soft, absorbent cloth.
Continued use of the equipment may result in fire or electrical shock.
Immediately turn the camera power off and remove the camera
battery or unplug the battery charger or compact power adapter from
the power outlet. Please consult your camera distributor or the closest
Canon Customer Support Help Desk.
z Do not use substances containing alcohol, benzine, thinners
or other flammable substances to clean or maintain the
equipment.
z Do not cut, damage, alter or place heavy items on the power
cord.
z Use only recommended power accessories.
z Remove the power cord on a regular periodic basis and wipe
away the dust and dirt that collects on the plug, the exterior of
the power outlet and the surrounding area.
z Do not handle the power cord if your hands are wet.
Continued use of the equipment may result in fire or electrical shock.
COPY
250
Battery
z Do not place the battery near a heat source or expose it to
direct flame or heat.
z The battery should not be immersed in water or sea water.
z Do not attempt to disassemble, alter or apply heat to the
battery.
z Avoid dropping or subjecting the battery to severe impacts
that could damage the casing.
z Use only recommended battery and accessories.
Failure to follow these precautions may cause explosions or leaks,
resulting in fire, injury and damage to the surroundings. In the event
that a battery leaks and the eyes, mouth, skin or clothing contact these
substances, immediately flush with water and seek medical
assistance.
z Disconnect the battery charger and compact power adapter
from both the camera and the power outlet after recharging or
when not in use to avoid fire and other hazards.
z Do not place anything, such as tablecloths, carpets, bedding or
cushions, on top of the battery charger while it is charging.
Leaving the units plugged in for a long period of time may cause them
to overheat and distort, resulting in fire.
z Use only the specified battery charger to charge the battery.
z The battery charger and compact power adapter are designed
for exclusive use with your camera. Do not use it with other
products or batteries.
There is a risk of overheating and distortion which could result in fire or
electrical shock.
z Before you discard a battery, cover the terminals with tape or
other insulators to prevent direct contact with other objects.
Contact with the metallic components of other materials in waste
containers may lead to fire or explosions.
COPY
251
Appendix
Others
z Do not trigger the flash in close proximity to human or animal
eyes. Exposure to the intense light produced by the flash may
damage eyesight.
In particular, remain at least one meter (39 inches) away from infants
when using the flash.
z Keep objects that are sensitive to magnetic fields (such as
credit cards) away from the speaker of the camera.
Such items may lose data or stop working.
z When using the optional Tele Converter or Conversion Lens
Adapter, be sure to attach them firmly.
If the lens becomes loose and falls off, it may crack, and the shards of
glass may lead to cuts.
COPY
252
Cautions
Equipment
z Do not get the camera caught on other objects or subject it to
strong impacts or shocks when wearing or holding it by the
neck strap.
z Be careful not to bump or strongly push the end of the lens.
The above-mentioned could lead to injury or damage the equipment.
z Be careful not to allow dust or sand into the camera when
using it at a beach or place with strong winds.
Such conditions could lead to damage.
z Do not store the equipment in humid or dusty areas.
z During shooting, do not allow metal objects (such as pins or
keys) or dirt to contact the charger terminals or plug.
Such conditions could lead to fire, electrical shock or other damage.
z Avoid using, placing or storing the equipment in places
subject to strong sunlight or high temperatures, such as the
dashboard or trunk (boot) of a car.
z Do not use the equipment in a manner that exceeds the rated
capacity of the electrical outlet or wiring accessories. Also, do
not use the equipment if the cable or plug is damaged, or if the
plug is not fully inserted into the power outlet.
z Do not use in locations with poor ventilation.
The above-mentioned can cause leakage, overheating or explosion,
resulting in fire, burns or other injuries. High temperatures may also
cause deformation of the casing.
z When not using the camera for extended periods of time,
remove the battery from the camera or battery charger and
store the equipment in a safe place.
If the battery is are left inside the camera, damage caused by leakage
may occur.
z Do not connect compact power adapters or battery chargers to
devices such as electrical transformers for foreign travel
because it may lead to malfunctions, excessive heat
generation, fire, electric shock or injury.
COPY
253
Appendix
Flash
z Do not operate the flash with dirt, dust or other items stuck to
the surface of the flash.
z Be careful not to cover the flash with your fingers or clothing
when shooting.
The flash may be damaged and emit smoke or noise. The resulting
heat build-up could damage the flash.
z Do not touch the surface of the flash after taking several
pictures in rapid succession.
Doing so could result in burns.
COPY
254
Preventing Malfunctions
Camera
Avoid Strong Magnetic Fields
z Never place the camera in close proximity to electric motors or
other equipment generating strong electromagnetic fields.
Exposure to strong magnetic fields may cause malfunctions or corrupt
image data.
Avoid Condensation Related Problems
z When moving the equipment rapidly from cold to hot
temperatures, you can avoid condensation by placing the
equipment in an airtight, resealable plastic bag and letting it
adjust to temperature changes slowly before removing it from
the bag.
If condensation forms on the camera, remove the memory card and
battery, and set the camera aside in room temperature to allow the
condensation to naturally evaporate before using the camera again.
Battery
z Keep the battery terminals clean at all times.
Dirty terminals may cause poor contact between the battery and
camera. Polish the terminals with a soft cotton swab before charging
or using the battery.
z At low temperatures, battery performance may be reduced and
the low battery icon (blinks red) may appear earlier than
usual.
Under these conditions, restore the battery performance by warming it
in a pocket immediately before use.
z Do not put the battery into a pocket together with metallic
items such as a key ring.
The battery may be short circuiting.
COPY
255
Appendix
z Do not allow any metal objects such as key rings to touch the
( ) and ( ) terminals (Fig. A). To carry the battery or store it
during periods of disuse, always replace the terminal cover
(Fig.B).
These conditions can damage the battery. You may be able to check
the charge state depending upon how the terminal cover is attached
(Fig. C, D).
z You are recommended to use it in the camera until it is
depleted and to store it in an indoor location with low relative
humidity and between the temperatures of 0 – 30 °C (32 –
86 °F).
Storing a fully charged battery for long periods of time (about one
year) may shorten its life cycle or affect its performance. If you do not
use the battery for long periods of time, charge it fully and discharge it
in the camera about once a year before returning it to storage.
z Since this is a lithium-ion battery, you need not deplete it
before recharging.
z You are advised to charge the battery on the day of use, or one
day before, to ensure a full charge.
Even charged batteries continue to discharge naturally.
Fig. C
Fully Charged Battery
Fig. D
Used Battery
Attach it so the is
visible.
Attach in the opposite
way of Fig. C.
Fig. A Fig. B
COPY
256
z It takes approximately 2 hours 20 minutes to fully charge the
battery from a depleted state (based on Canon’s testing
standards).
• Charging it within a temperature range of 5 – 40 °C (41 – 104 °F) is
recommended.
• Charge times may vary according to the ambient temperature and
the battery’s charge state.
z If the performance of the battery diminishes substantially even
when it is fully charged, its life has been exceeded and it
should be replaced.
Memory Card
z SD Memory Card or SDHC Memory Card Write Protect Tab
z Memory cards are high-precision electronic devices. Do not
bend them, apply force to them, or subject them to shocks or
vibration.
z Do not attempt to disassemble or alter the memory card.
z Do not allow dirt, water or foreign objects to contact the
terminals on the back of the memory card. Do not touch the
terminals with your hands or metal objects.
z Do not peel away the original label on the memory card or
cover it with another label or sticker.
z When writing on the memory card, do not use a pencil or
ballpoint pen. Only use a soft point pen (e.g. felt-tip pen).
Slide the
tab up.
Slide the tab down
(you can protect
the images and
other data on the
memory card).
Write Protect Tab
Writing/Erasing Possible
Writing/Erasing Impossible
COPY
257
Appendix
z Do not use or store memory cards in the following locations.
• Locations subject to dust or sand
• Locations subject to high humidity and high temperatures
z Since some or all of the data recorded on the memory card
may be corrupted or erased by electrical noise, static
electricity, camera or memory card malfunction, making a
backup copy of important data is recommended.
z Please note that formatting (initializing) a memory card erases
all data, including protected images.
z You are recommended to use memory cards that have been
formatted in your camera.
• When the camera is malfunctioning, a corrupted memory card might
be the cause. Reformatting the memory card may solve the problem.
• Memory cards formatted in other cameras, computers, or peripheral
devices may not operate correctly in this camera. When that
happens, reformat the memory card with this camera.
z If formatting in the camera does not work properly, turn the
camera off and re-insert the memory card. Then turn the
camera back on and format again.
z Be careful when transferring or disposing of a memory card.
Formatting or erasing the data on a memory card merely
changes the file management information on the memory card
and does not ensure that its contents are completely deleted.
When disposing of a memory card, take precautions, such as
physically destroying the memory card, to prevent personal
information leaks.
LCD Monitor
z Do not sit in a chair with the camera in your pocket.
Doing so may cause malfunction or damage the LCD monitor.
z When putting the camera in your bag, ensure that hard objects
do not come into contact with the LCD monitor.
If this occurs, it may cause malfunction or damage the LCD monitor.
z Do not attach accessories to the strap.
Doing so may cause malfunction or damage the LCD monitor.
COPY
258
It is best to power the camera with AC Adapter Kit ACK-DC50 (sold
separately) when you are using it for long periods of time or connecting
it to a computer.
Using the AC Adapter (Sold Separately)
Turn the camera power off before connecting or disconnecting
the AC adapter.
1
Connect the power
cord to the compact
power adapter first
and then plug the
other end into the
power outlet.
2
Connect the DC plug of
the compact power
adapter cable to the DC
Coupler terminal.
3
Open the memory card/
battery cover, then insert the
DC Coupler until it is locked.
Compact Power
Adapter
CA-PS700
DC Coupler
DR-50
Battery lock
COPY
259
Appendix
4
Press and hold the
DC Coupler cable
cover using the
cable, then close the
memory card/battery
cover.
• Always disconnect the
compact power adapter
from the power supply after
use.
DC Coupler
Cable Cover
COPY
260
When attaching the Tele-converter TC-DC58D (each sold separately)
you also need the Conversion Lens Adapter LA-DC58K.
Tele-converter TC-DC58D
This lens is used for taking telephoto shots. The lens changes the focal
length of the camera body’s lens by a factor of 1.4x (the thread
diameter is 58 mm).
Using the Lenses (Sold Separately)
z When attaching the tele-converter, be sure to screw it on
securely. If they come loose, they may fall from the lens
adapter, posing risk of injury from shattered glass.
z Never look into the sun or into strong light through the tele-
converter as this can result in blindness or impairment of
vision.
z If the built-in flash is used with the lens hood attached, the
outer edges of shot images (especially the lower right) may
be darkened.
z When using the tele-converter, set the camera near the
maximum telephoto. At other zoom settings, the image will
appear as if its corners have been cut off.
z If you use the viewfinder for shooting, a portion of the view
will be blocked by these attachments. Please use the LCD
monitor.
It is not possible to attach a lens hood or filter to the tele-
converter.
COPY
261
Appendix
Conversion Lens Adapter LA-DC58K
This is a lens adapter required for attaching the teleconverter. The
adapter can be taken apart into a front and back component, but be
sure to use the adapter in its conjoined state when attaching the tele-
converter.
Attaching a Lens
1
Be sure that the camera is turned off.
2
Press the ring release button (a) and hold it
down, and turn the ring in the direction of the
arrow (b).
3
When the { mark on the ring and the z mark
on the camera are aligned, lift off the ring.
Ring
Ring Release Button
COPY
262
4
Align the z mark on the conversion lens adapter
with the z mark on the camera, and turn the
adapter in the direction of the arrows until
locked.
• The conversion lens adapter can be taken apart into a front and
back component, but be sure to use the adapter in its conjoined
state. Also, make sure that the front and back components are
firmly attached to each other before attaching the adapter to the
camera.
• To remove the conversion lens adapter, turn the adapter in the
opposite direction with holding down the ring release button.
5
Set the lens on the adapter,
and turn it in the indicated
direction to attach it
securely.
z Completely remove all dust and dirt from conversion lenses
with a lens blower brush before use. The camera may focus
on any dirt that remains.
z Be careful when handling the lenses since it is easy to get
finger prints on them.
z Be careful not to drop the camera or adapter when removing
the ring.
z When using these lens attachments, you should not shoot
images in mode. It will not be possible to use the
PhotoStitch software from your computer to accurately stitch
the images together.
COPY
263
Appendix
Converter Settings
Set up when shooting using the [IS Mode] (p. 85) by attaching the
Tele-converter TC-DC58D, sold separately.
The Icons on the LCD Monitor
1
Select [Converter].
1. Press the MENU button.
2. In the menu, use the or
button to select [Converter].
2
Make settings.
1. Use the or button to select
[TC-DC58D].
2. Press the MENU button.
[Converter] setting
[IS Mode] setting
[Continuous] [Shoot Only] [Panning] [Off]
None
TC-DC58D
When you remove the converter from the camera, return the
converter setting to [Off].
COPY
264
Changing the Ring Color
You can change the color of the ring using the separately sold Ring
Accessory Kit RAK-DC2.
1
Be sure that the camera is turned off.
2
Press the ring release button (a) and hold it
down, and turn the ring in the direction of the
arrow (b).
3
When the { mark on the ring and the z mark
on the camera are aligned, lift off the ring.
4
Align the { mark on the ring with the z mark
on the camera, and then turn the ring in the
direction of the arrow.
Ring
Ring Release Button
COPY
265
Appendix
You can make your flash photography even clearer and more natural
appearing with the use of a separately sold externally mounted flash.
The camera’s auto exposure function will operate with a Canon
Speedlite 220EX, 430EX II, 580EX II, Macro Ring Lite MR-14EX and
Macro Twin Lite MT-24EX (except with the mode or when [Flash
Mode] is set to [Manual]). Other flashes may fire manually or not fire at
all.
Please check the manual for your flash.
You are recommended to set the white balance to .
* Certain functions noted in the manuals for the Canon Speedlite 220EX, 430EX II,
580EX II, Macro Ring Lite MR-14EX and Macro Twin Lite MT-24EX cannot be
performed when mounted on this camera. Please read this guide before using one of
these flashes on the camera.
Attaching the Externally Mounted Flash
Using an Externally Mounted Flash (Sold
Separately)
Available Shooting Modes p. 300
z Since the camera’s auto exposure function will trigger an
externally mounted flash when shooting in or
mode, settings cannot be changed.
z When using Canon mounted flashes other than the
Speedlite EX series, automatic red-eye correction is not
available.
1
Attach the flash to the
camera’s hot shoe.
COPY
266
2
Turn the external flash on and turn the camera
on.
• (red) appears on the LCD monitor.
3
Turn the mode dial to the desired mode.
z Speedlite 220EX*
• The maximum flash synchro shutter speed is 1/250 second.
• The flash will automatically adjust its output when [Flash
Mode] is set to [Auto].
• When [Flash Mode] is set to [Auto] the flash exposure
compensation can be adjusted. When [Flash Mode] is set to
[Manual], the flash output can be adjusted (p. 113).
• In mode or when [Flash Mode] is set to [Manual], the
output of an externally mounted flash can be adjusted in the
flash output adjustment screen (p. 113). For the optimum
aperture values and ISO speeds for the distance to the
subject, refer to the guide number listed in the flash’s user
guide (adjustment can be made on the camera only).
You can also adjust the flash output even when the camera is
set to the E-TTL automatic flash exposure compensation
mode by changing the flash exposure compensation setting.
* You can also use the 380EX, 420EX, 430EX, 550EX and 580EX.
COPY
267
Appendix
z Speedlite 430EX II and 580EX II
• The maximum flash synchro shutter speed is 1/250 second.
• The flash will automatically adjust its output when [Flash
Mode] is set to [Auto].
• When [Flash Mode] is set to [Auto] the flash exposure
compensation can be adjusted. When [Flash Mode] is set to
[Manual], the flash output can be adjusted (p. 113).
• In mode or when [Flash Mode] is set to [Manual], the
output of an externally mounted flash can be adjusted in the
flash output adjustment screen (p. 113). You can also adjust
the flash output from the flash (the flash setting overrides the
camera setting when both are set). For the optimum aperture
values and ISO speeds for the distance to the subject, refer to
the guide number listed in the flash’s user guide.
You can also adjust the flash output even when the camera is
set to the E-TTL automatic flash exposure compensation
mode by changing the flash exposure compensation setting.
• In mode, you can set the flash output with the camera
even if the flash unit is set to E-TTL automatic flash exposure
compensation. [E-TTL] will display on the flash, but the flash
will fire manually.
z Other Canon Flashes (other than Speedlite EX series,
Macro Ring Lite MR-14EX and Macro Twin Lite MT-24EX)
• Since other flashes fire at full strength, set the shutter speed
and aperture accordingly.
4
Press the shutter button halfway.
• The flash is charged when its pilot lamp lights up.
5
Press the shutter button all the way to shoot
the image.
COPY
268
Setting the Externally Mounted Flash
1
Display the Flash Settings
screen.
1. Hold the button down for more
than one second.
• Before making flash settings, mount
the external flash and turn the flash
on.
• You can also set in [Flash Control] in the menu.
COPY
269
Appendix
2
Make settings.
1. Use the or button to select the items you wish to set.
2. Use the or button to set the item.
3. Press the MENU button.
• The available settings will vary depending on the flash in use.
For details on settings, refer to the user guide included with your
flash or Speedlite Transmitter.
Speedlite 220EX, Macro Ring Lite MR-14EX and Macro Twin Lite
MT-24EX Settings
* : Default setting.
: Settings are retained even when the camera power is turned off.
1) This can be set when [Flash Mode] is set to [Auto].
2) This can be set when [Flash Mode] is set to [Manual].
Item Options
Shooting mode
Flash Mode
Auto
{* {* {*
–
Manual
{ { {{*
Flash Exp.Comp
1)
–3 to +3
{ { {
–
Flash Output
2)
1/64 to 1/1 (in 1/3 steps)
{ { { {
Shutter Sync.
1st-curtain
{* {* {* {*
2nd-curtain
{ { { {
Slow Synchro
On
{{* {{*
Off
{*
–
{*
–
Red-Eye Corr.
On
{ { { {
Off
{* {* {* {*
Red-Eye Lamp
On
{* {* {* {*
Off
{ { { {
Safety FE
1)
On
{* {* {*
–
Off
{ { {{*
COPY
270
Speedlite 430EX II/580EX II Settings
*
:
Default setting.
: Settings are retained even when the camera power is turned off.
1) The settings from the flash are applied when you turn on the camera.
2) This can be set when [Flash Mode] is set to [Auto].
3) This can be set when [Flash Mode] is set to [Manual].
4) When using Speedlite 430EX II, 1/64 will be set.
5) Only [On] and [Off] can be set with the camera, and further settings are made
with the flash (cannot be set with Speedlite 430EX II).
6) [Slow Synchro], [Safety FE], [Red-Eye Corr.] and [Red-Eye Lamp] can also be
returned to their default values using [Reset All] in the camera’s menu
(p. 227).
Item Options
Shooting mode
Flash Mode
1)
Auto
{* {* {*
–
Manual
{ { {{*
Flash Exp.
Comp
1) 2)
–3 to +3
{ { {
–
Flash Output
1) 3)
1/128
4)
to 1/1 (in 1/3 steps)
{ { { {
Shutter Sync.
1)
1st-curtain
{* {* {* {*
2nd-curtain
{ { { {
Hi-speed
{ { { {
Slow Synchro
On
{{* {{*
Off
{*
–
{*
–
Wireless Func.
1) 5)
On
{ { { {
Off
{* {* {* {*
Red-Eye Corr.
On
{ { { {
Off
{* {* {* {*
Red-Eye Lamp
On
{* {* {* {*
Off
{ { { {
Safety FE
2)
On
{* {* {*
–
Off
{ { {{*
Clear Flash
Settings
6)
Resets the settings to
their default values.
{{{{
COPY
271
Appendix
z [Flash Control] will not display when the flash is turned off.
Before making flash settings, turn the flash on.
z When an external flash is mounted, you cannot make built-in
flash settings.
z When adjusting flash exposure compensation with the
camera, set the external flash’s exposure compensation to
[+0].
z If the external flash has been set to stroboscopic flash, the
flash’s set up menu cannot be selected (580EX II only).
z When [Wireless Func.] is set to [On], [Shutter Sync.] cannot
be set to [2nd-curtain]. Even if you set [Shutter Sync.] to
[2nd-curtain] with the camera, it will change to [1st-curtain].
z For continuous shooting, the flash can be in quick flash
mode (pilot lamp lit green). In this case, light emission may
be smaller than with full flash (pilot lamp lit red).
z The focus bracketing mode and the AEB mode cannot be
used for flash photography. If the flash fires, only one image
gets recorded.
z Flashes (especially high-voltage flashes) or flash
accessories made by other manufacturers may override
certain camera functions or cause a camera malfunction.
z The following functions can be used with a Speedlite 220EX,
430EX II or 580EX II*.
- Auto Exposure (Use the E-TTL mode with a 430EX II or
580EX II)
- FE Lock (Not available in mode or when [Flash Mode] is
[Manual])
- Shutter Sync. (1st-curtain/2nd-curtain) (2nd-curtain priority
with Speedlite 430EX II)
- Slow Synchro
-Flash Exp. Comp
- Auto Zoom (Not available with the 220EX)
- Manual flash
- High-speed sync
* You can also use 380EX, 420EX, 430EX, 550EX and 580EX.
COPY
272
High-Power Flash HF-DC1
This flash is used to supplement the camera’s built-in flash when the
subject is too far away for proper illumination. Use the following
procedures to affix the camera and High-Power Flash to the supporting
bracket.
Please read the instructions accompanying the flash along with this
explanation.
Using a Supplementary Flash (Sold
Separately)
z The High-Power Flash will not fire under the following
circumstances.
- When shooting in mode
- When [Shutter Sync.] is on [2nd-curtain]
- When [Flash Mode] is on [Manual] (p. 113)
z The flash charge time will lengthen as the battery charge
gets weaker. Always set the power/mode switch to off when
you finish using the flash.
z Be careful not to touch the flash window or sensor windows
with your fingers while the flash is in use.
Tripod Sockets
Bracket
(Comes with the flash)
COPY
273
Appendix
Batteries
z Charge becomes Severely Limited
If the battery usage time has considerably diminished, wipe the battery
terminals well with a dry cloth. The terminals may be dirty from
fingerprints.
z Usage in Cold Temperatures
Get a spare generic lithium battery (CR123A or DL123). You are
recommended to place the spare battery in your pocket to warm it up
before switching it for the battery in the flash.
z Non-Use over Extended Periods
Leaving batteries in the High-Power Flash could allow the battery fluid
to leak, damaging the product. Remove the batteries from the High-
Power Flash and store them in a cool, dry place.
z The flash may fire if another flash is being used in close
proximity.
z The High-Power Flash may not fire outdoors in daylight or
when there are no reflective items.
z For continuous shooting, although the flash fires for the first
shot, it does not fire for subsequent shots.
z Fasten the attachment screws securely so that they do not
loosen. Failure to do so may lead to the dropping of the
camera and flash resulting in damage to both.
z Before attaching the bracket to the flash, check that the
lithium battery (CR123A or DL123) is installed.
z To illuminate the subjects properly, install the flash so that it
is up against the side of the camera and parallel with the
camera’s front panel.
z A tripod can be used even when the flash is attached.
COPY
274
By using the RS60-E3 Remote Switch (sold separately), you can avoid
any camera shake that may occur when you press the shutter button.
The remote switch is also useful when using slow shutter speeds.
Be sure to stabilize the camera by using a tripod, for example, when
using the remote switch. Also, be sure to read the operating
instructions supplied with the remote switch before use.
Using the Remote Switch (Sold Separately)
1
Make sure the camera is turned off.
2
Connect the remote switch.
1. Open the terminal cover.
2. Insert the remote switch’s plug.
3
Press the release button on
the remote switch to shoot.
Bulb photographs cannot be taken with this camera.
COPY
275
Appendix
Camera Body
Gently wipe dirt off the camera body with a soft cloth or eyeglass lens
wiper.
Lens
First use a lens blower brush to remove dust and dirt, then remove any
remaining dirt by wiping the lens lightly with a soft cloth.
Viewfinder and LCD Monitor
Use a lens blower brush to remove dust and dirt. If necessary, gently
wipe with a soft cloth or an eyeglass lens wiper to remove stubborn
dirt.
Camera Care and Maintenance
Never use thinners, benzine, detergents or water to clean the
camera. These substances may distort or damage the
equipment.
Never use organic solvents on the camera body or lens. If dirt
remains, contact the closest Canon Customer Support Help
Desk as listed on the separate customer support list supplied
with your camera.
Never rub or press strongly on the LCD monitor. These actions
may damage it or lead to other problems.
COPY
276
All data is based on Canon’s standard testing methods. Product
specifications and appearance are subject to change without notice, at
our sole discretion.
PowerShot G10 (W): Max. wide angle (T): Max. telephoto
Specifications
Camera Effective Pixels : Approx. 14.7 million
Image Sensor : 1/1.7-inch type CCD (Total number of pixels:
Approx. 15.0 million pixels)
Lens : 6.1 (W) – 30.5 (T) mm
(35mm film equivalent: 28 (W) – 140 (T) mm)
f/2.8 (W) – f/4.5 (T)
Digital Zoom : Approx. 4.0x (Up to approx. 20x in combination
with the optical zoom)
Optical Viewfinder : Real-image zoom viewfinder
Picture coverage approx. 77% (representative
value)
Eyepoint: 15 mm (0.59 in.)
Dioptric adjustment: –3.0 to +1.0 m
–1
(dpt)
LCD Monitor : 3.0-inch type, TFT color LCD (Pure Color LCD
II), 461,000 dots, picture coverage 100%
AF System : TTL autofocus (continuous/single)
AF lock and manual focus are available
AF frame mode: Face Detect*
1
*
2
/
AiAF (9-point)*
3
/Center/FlexiZone*
3
*1 AF frame can be moved and fixed to specified face.
*2 If no face is detected, AiAF (9-point) is used.
*3 AF frame size can be selected.
Focusing Range
(From the end of the
lens)
: Normal: 50 cm (1.6 ft.) – infinity
Macro: 1 – 50 cm (W) (0.39 in. – 1.6 ft. (W))/
30 – 50 cm (T) (12 in. – 1.6 ft. (T))
Manual focus: 1 cm (0.39 in.) – infinity (W)/
30 cm (12 in.) – infinity (T)
Sports mode: 1 m (3.3 ft.) – infinity (W)/
2 m (6.6 ft.) – infinity (T)
Kids&Pets: 1 m (3.3 ft.) – infinity
COPY
277
Appendix
Shutter : Mechanical shutter + electronic shutter
Shutter Speeds : 1/60 – 1/4000 sec.
15 – 1/4000 sec. (Total shutter speed range)
• Slow shutter speeds of 1.3 sec. or slower
operate with noise reduction.
Image Stabilization : Lens-shift type
Continuous/Shoot Only*/Panning*/Off
* Still images only.
Metering System :
Evaluative*, Center-weighted average or Spot**
* Facial brightness is also evaluated in Face Detect
AF.
** Fixed to center/AF-point
Exposure Compensation
: ±2 stops in 1/3-stop increments
ISO Speed
(Standard Output
Sensitivity,
Recommended
Exposure Index)
: Auto*, High ISO Auto*, ISO 80/100/200/400/
800/1600
* Camera automatically sets the optimal speed.
ND Filter (built-in) : Light intensity reduction: 3 stops (Intensity
becomes 1/8 of actual level)
White Balance : Auto*, Day Light, Cloudy, Tungsten,
Fluorescent, Fluorescent H, Flash, Underwater,
Custom 1 or Custom 2
* The colors of faces are evaluated in Face Detect AF.
Built-in Flash : Auto, on, off
Flash output compensation (±2.0 stops in 1/3-
stop increments), Red-Eye Correction, Red-Eye
Reduction, flash output settings (3 steps), FE
Lock, Slow Synchro, 2nd-curtain Synchro and
Safety FE are available.
• Facial brightness is also evaluated in Face
Detect AF.
Built-in Flash Range : 30 cm – 4.6 m (12 in – 15 ft.) (W)/50 cm – 2.8 m
(1.6 – 9.2 ft.) (T)
• Brightness of image periphery may reduce
depending on shooting distance.
COPY
278
External Flash : Flash output compensation (±2.0 stops in 1/3-
stop increments), Red-Eye Correction, Red-eye
Reduction, flash output settings (19 levels*), FE
Lock, Slow Synchro, 2nd-curtain Synchro, High-
Speed Sync, Safety FE and wireless flash (On/
Off only) are available.
* 22 levels with 580EX II
Terminals for External
Flash
: Hot shoe flash-sync contacts
Use of the following external flashes is
recommended:
Canon Speedlite 220EX, 430EX II, 580EX II,
Macro Ring Lite MR-14EX and Macro Twin Lite
MT-24EX.
Shooting Modes : Auto
Creative zone:
Program, Shutter-speed priority,
Aperture priority, Manual,
Custom 1, Custom 2
Image zone:
Special Scene*, Stitch Assist, Movie**
* Portrait, Landscape, Night Scene, Sports, Night
Snapshot, Kids&Pets, Indoor, Sunset, Foliage, Snow,
Beach, Fireworks, Aquarium, Underwater, ISO 3200,
Color Accent and Color Swap.
** Standard, Color Accent and Color Swap.
Continuous Shooting :
Approx. 1.3 shots/sec.
Approx. 0.7 shots/sec. (Continuous Shooting AF)
Approx. 0.7 shots/sec. (Continuous Shooting LV)
• Under the conditions where the flash does not
fire automatically.
Self-timer : Self-timer: Approx. 10-sec./approx. 2-sec. delay,
custom or FaceSelf-timer
Remote Shooting (PC) : Shooting possible when connected to a
computer using supplied software.
Remote Switch : Connecting possible (RS60-E3)
Recording Media : SD memory card/SDHC memory card/
MultiMediaCard/MMCplus card/HC MMCplus
card
COPY
279
Appendix
File Format : Design rule for camera file system and DPOF
compliant
Data Type :
:
:
Still images: Exif 2.2 (JPEG)*/RAW (CR2)**
Movies: MOV (Image data: H.264; Audio data:
Linear PCM (monaural))
Sound Memo and Sound Recorder: WAVE
(monaural)
* This digital camera supports Exif 2.2 (also called “Exif
Print”). Exif Print is a standard for enhancing the
communication between digital cameras and printers.
By connecting to an Exif Print-compliant printer, the
camera’s image data at the time of shooting is used
and optimized, yielding extremely high quality prints.
** Use Digital Photo Professional to process these files.
Compression : Superfine, Fine, Normal
Number of
Recording
Pixels
(Still images)
: Large : 4416 × 3312 pixels
Medium 1 : 3456 × 2592 pixels
Medium 2 : 2592 × 1944 pixels
Medium 3 : 1600 × 1200 pixels
Small : 640 × 1480 pixels
Widescreen : 4416 × 2480 pixels
RAW : 4416 × 3312 pixels
(Movies) : Standard, Color Accent and Color Swap
: 640 × 480 pixels (30 frames/sec.)
: 320 × 240 pixels (30 frames/sec.)
Recording can continue until the memory card is
full (can record up to a maximum of 4 GB* at
one time)
* Even if the file size has not reached 4 GB, the
recording is stopped when the recording time reaches
one hour. Depending on memory card capacity and
data write speed, recording may stop before the file
size reaches 4 GB or the recording time reaches one
hour.
COPY
280
Audio : Quantization Bit Rate: 16 bit
Sampling Rate
Sound Memos: 11.025 kHz
Movies: 44.100 kHz
Sound Recorder: 11.025 kHz/22.050 kHz/
44.100 kHz
Playback Modes : Single (histogram displayable), Index (9
images), Magnified (approx. 2x to 10x max.),
Resume Playback, Image Inspection Tool,
Jump, My Category, Trimming, Movie Playback
(editing/slowmotion playback possible), Rotate,
Slide Show, Red-Eye Correction, i-Contrast, My
Colors, Resize, Sound Memos (recording/
playback up to 1 min.), Sound Recorder (up to 2
hours sound-only recording/playback possible)
or Protect.
Direct Print : PictBridge compliant, and Canon Direct Print
and Bubble Jet Direct compatible
My Camera Settings : Start-up image, start-up sound, operation
sound, self-timer sound, and shutter sound.
Interface : Hi-Speed USB (mini-B)
Audio/Video output (NTSC or PAL selectable,
monaural audio)
Communication
Settings
:MTP, PTP
Power Source : Battery Pack NB-7L (Rechargeable lithium-ion
battery)
AC Adapter Kit ACK-DC50
Operating
Temperatures
: 0 – 40 °C (32 – 104 °F)
Operating Humidity : 10 – 90%
Dimensions
(excluding protrusions)
: 109.1 × 77.7 × 45.9 mm (4.30 × 3.06 × 1.81 in.)
Weight
(camera body only)
: Approx. 350 g (12.3 oz.)
COPY
281
Appendix
Battery Capacity (Battery Pack NB-7L (Fully
charged))
z The actual figures will vary according to the shooting conditions and
settings.
z Movie data is excluded.
z At low temperatures, the battery performance may diminish and the
low battery icon may appear very rapidly. In these circumstances,
the performance can be improved by warming the battery in a pocket
before use.
Test Conditions
Number of Images Shot
Playback Time
LCD Monitor On
Playback Time
(Based on the CIPA
standard)
LCD Monitor Off
Approx. 400 images Approx. 1000 images Approx. 10 hours
Shooting: Normal temperature (23 °C ±2 °C/73 °F ±3.6 °F), normal
relative humidity (50% ±20%), alternating wide angle end
and telephoto end shots at 30 second intervals with the flash
fired once every two shots and the camera power turned off
after every tenth shot. Power is left off for a sufficient amount
of time*, then the power is turned back on and the testing
procedure is repeated.
* Until the battery returns to normal temperature
Playback:Normal temperature (23 °C ±2 °C/73 °F ±3.6 °F), normal
relative humidity (50% ±20%), continuous playback at 3
seconds per image.
See Battery (p. 254).
COPY
282
Memory Cards, Estimated Capacities and Image
Data Sizes (Estimated)
Still Image
This reflects standard shooting criteria established by Canon. Actual results may vary
according to the subject and shooting conditions.
Recording Pixels
Compression
Capacity 2 GB 8 GB
(Large)
4416 × 3312 pixels
6348 306 1227
3759 516 2063
1797 1059 4234
(Medium 1)
3456 × 2592 pixels
3888 499 1996
2302 841 3364
1100 1707 6822
(Medium 2)
2592 × 1944 pixels
2503 767 3069
1395 1365 5457
695 2672 10679
(Medium 3)
1600 × 1200 pixels
1002 1862 7442
558 3235 12927
278 6146 24562
(Small)
640 × 480 pixels
249 6830 27291
150 10245 40937
84 15368 61406
(Widescreen)
4416 × 2480 pixels
4753 409 1637
2814 690 2759
1345 1396 5581
(RAW)
4416 × 3312 pixels
– 18793 94 378
+
4416 × 3312 pixels
– 22552 79 318
COPY
283
Appendix
Movie ( (Standard), (Color Accent), (Color Swap))
The figures indicate the maximum continuous recording time.
Depending on the memory card, recording may stop even if the max. clip length has not
been reached. Use of SD Speed Class 4 or higher memory cards is recommended.
Sound Recorder Data Rates and Recording
Durations (Estimated)
Battery Pack NB-7L
Recording Pixels/
Frame Rate
Capacity 2 GB
8 GB
640 × 480 pixels
30 frames/sec.
1316 KB 23 min. 49 sec.
1 hr. 35 min.
11 sec.
320 × 240 pixels
30 frames/sec.
394 KB
1 hr. 13 min.
10 sec.
4 hrs. 52 min
24 sec.
Sound Size
2 GB 8 GB
11.025 kHz 22 KB/sec. 25 hrs. 22 min. 35 sec. 101 hrs. 23 min. 47 sec.
22.050 kHz 44 KB/sec. 12 hrs. 41 min. 18 sec. 50 hrs. 41 min. 53 sec.
44.100 kHz 88 KB/sec. 6 hrs. 20 min. 39 sec. 25 hrs. 20 min. 57 sec.
Type Rechargeable lithium-ion battery
Nominal Voltage 7.4 V DC
Typical Capacity 1050 mAh (min.)
Battery Life
(Charge Cycles)
Approx. 300 times
Operating
Temperatures
0 – 40 °C (32 – 104 °F)
Dimensions 32.5 × 45.4 × 17.7 mm (1.28 × 1.79 × 0.70 in.)
Weight Approx. 47 g (1.7 oz.)
USA and Canada only:
The Lithium ion/polymer battery that powers the product
is recyclable.
Please call 1-800-8-BATTERY for information on how to
recycle this battery.
COPY
284
Battery Charger CB-2LZ/CB-2LZE
Compact Power Adapter CA-PS700
(Included with the separately sold AC Adapter Kit ACK-DC50)
Rated Input 100 – 240 V AC (50/60 Hz)
0.14 A (100 V) – 0.08 A (240 V)
14 VA (100 V) – 19.2 VA (240 V)
Rated Output 8.4 V DC, 0.70 A
Charging Time Approx. 2 hrs. 20 min. (for Battery Pack NB-7L)
Operating
Temperatures
0 – 40 °C (32 – 104 °F)
Dimensions 92.5 × 27.0 × 62.0 mm (3.64 × 1.06 × 2.44 in.)
Weight Approx. 92 g (3.2 oz.) (CB-2LZ)
Approx. 85 g (3.0 oz.) (CB-2LZE) (excluding the
power cord)
Rated Input 100 – 240 V AC (50/ 60 Hz)
Rated Output 7.4 V DC, 2.0 A
Operating
Temperatures
0 – 40 °C (32 – 104 °F)
Dimensions 112.0 × 29.0 × 45.0 mm (4.41 × 1.14 × 1.77 in.)
(body only)
Weight Approx. 185 g (6.53 oz.) (excluding power cord)
When connecting to and using a household power outlet, use only AC
Adapter Kit ACK-DC50 (rated input: 100 – 240 V AC 50/60 Hz, rated
output: 7.4 V DC). Using anything else can cause fire, overheating, or
electrical shock.
COPY
285
Appendix
Tele-converter TC-DC58D (Sold Separately)
Conversion Lens Adapter LA-DC58K (Sold
Separately)
(T): Max. telephoto
*1 When mounted on PowerShot G10 (Max. telephoto)
*2 From front of the mounted conversion lens during normal shooting.
*3 Conversion Lens Adapter LA-DC58K is required when mounted on PowerShot G10.
Bracket BKT-DC1 (Sold Separately)
Magnification 1.4x
Focal Length
*
1
196 mm (35mm film equivalent)
Focusing Range
*
1
55 cm (1.8 ft.) – infinity (T)
*
2
Thread Diameter
58 mm standard filter thread
Dimensions
Diameter × Length
69.0 × 41.2 mm (2.72 × 1.62 in.)
Weight Approx. 140 g (4.94 oz.)
Thread Diameter 58 mm standard filter thread
Dimensions
Diameter × Length
63.8 × 51.6 mm (2.51 × 2.03 in.)
Weigh Approx. 30 g (1.06 oz.)
Dimensions 220.0 × 32.0 × 19.0 mm (8.66 × 1.26 × 0.75 in.)
Weight Approx. 90 g (3.2 oz.)
COPY
Index
286
Index
Numerics
3:2 Guide ..................................66
A
AE Lock) .................................134
AEB Mode ...............................139
AF Assist Beam ........................40
AF Frame ..........................49, 121
AF Lock ...................................128
AF Mode .................................120
AF-assist Beam .........................56
AF-Point Zoom ........................116
Aperture Value ............97, 98, 100
Aquarium ...................................93
Audio .......................................108
Auto Category .........................154
Auto ISO Shift ...........................88
Auto Mode .................................17
Auto Rotate .............................225
Av ..............................................98
B
Battery
Battery Capacity .................281
Battery Charge Indicator .......50
Charging ...............................10
Installing ................................11
Beach ........................................93
Bracket ....................................290
C
C1 ...........................................109
C2 ...........................................109
Camera Shake Warning ....49, 235
Category
Auto Category ..................... 154
My Category ....................... 165
Clock Display ............................ 46
Color Accent ..................... 94, 149
Color Swap ....................... 94, 151
Components Guide ................... 40
Compression ............................ 81
Computer
Connecting ........................... 29
Downloading Images ............ 28
System Requirements .......... 27
Continuous Shooting .............. 111
Control Dial ............................... 43
Create Folder .......................... 223
Custom Display ........................ 66
Custom Settings ..................... 109
D
Date/Time ................................. 14
Digital Photo Professional
.......................................... 82, 279
Digital Tele-Converter ............... 69
Digital Zoom ............................. 69
Direct Print Compatible Printer . 38
Direct Transfer .......................... 31
Display Language ..................... 15
Distance Units .......................... 60
DPOF Print Settings ............... 207
DPOF Transfer Settings ......... 214
E
Erase ...................................... 202
Erasing ..................................... 20
Externally Mounted Flash ....... 265
COPY
Index
287
F
Face Detect .............................121
Face Select and Track ............125
FE Lock ...................................136
File Numbering ........................221
Fireworks ..................................93
Flash
Flash Exp. Comp ................113
Settings ...............................113
Shooting ................................73
Focus ......................118, 121, 161
Focus Check .....................64, 118
Focus Check Display ..............161
Focus Lock ..............................128
Focus Settings ........................120
Focus-BKT Mode ....................133
Foliage ......................................93
Frame Rate .............................107
FUNC. Menu .............................54
Functions Available in Each
Shooting Mode ........................300
G
Grid Lines ..................................66
H
High-Power Flash ...................272
Histogram Function ...................52
I
i-Contrast ........................138, 187
Image Stabilizer ........................85
Image Type ...............................82
Index Playback ........................160
Indicator ..............................42, 45
Indoor ........................................92
ISO 3200 ...................................94
ISO Speed ................................87
J
Jump ....................................... 163
K
Kids&Pets ................................. 92
L
Landscape ................................ 91
LCD Monitor Brightness ........... 65
Lens
Conversion Lens Adapter ... 261
Tele-converter .................... 260
Lens Retract ............................. 60
Lense ...................................... 260
List of Messages ..................... 244
M
M ............................................. 100
Macro ........................................ 74
Manual Focus ......................... 130
Memory Card
Estimated Capacities .......... 282
Format .......................... 16, 220
Menu
Play Menu ............................. 57
Print Menu ............................ 58
Rec. Menu ............................ 55
Set up Menu ......................... 59
Setting .................................. 47
Metering Mode ........................ 141
MF-Point Zoom ................. 56, 130
Microphone ............................... 24
Microphone Level ................... 108
Mode Dial ................................. 90
Movie
Editing ................................. 173
Shooting ....................... 24, 104
Viewing ......................... 26, 171
Mute .......................................... 59
COPY
Index
288
My Camera Settings ...............230
Changing ............................230
Registering ..........................231
My Category ............................165
My Colors ................................146
My Colors (Playback) ..............189
My Menu .................................157
N
ND Filter ..................................140
Neck Strap ................................13
Night Display .............................65
Night Scene ..............................92
Night Snapshot .........................92
O
Optional Accessory ...................36
Overexposure Warning .............52
P
P ................................................95
Playback Button ........................44
Portrait ......................................91
Power Saving ....................60, 216
Power Source
AC Adapter Kit ....................258
Press Fully ................................18
Press Halfway .....................17, 25
Print List ....................................23
Print Method ..............................61
Print/Share Button .....................42
Printing ......................................21
Program AE ..............................95
Protect .....................................197
R
RAW ..........................................82
Rec. Review ..............................18
Recording Functions ...............108
Recording Pixels ............... 80, 107
Red-Eye Corr. (Shooting) ....... 114
Red-Eye Correction (Playback)
................................................ 182
Red-Eye Lamp ........................ 114
Registering Settings ............... 155
Reset All ................................. 227
Resize ..................................... 192
Resume .............................. 19, 57
Resume Playback ..................... 19
Review ...................................... 56
Review Info ............................. 118
Rotate ..................................... 175
S
Safety FE ................................ 114
Safety MF ............................... 131
Safety Shift ............................... 97
Safety Zoom ............................. 70
Self-Timer ................................. 75
Servo AF ................................. 127
Shooting Mode ......................... 90
Shortcut Button ....................... 155
Shutter Button ..................... 17, 24
Shutter Speed ........................... 96
Slide Shows ............................ 177
Snow ......................................... 93
Sound Memo .......................... 194
Sound Recorder ..................... 195
Sports ....................................... 92
Stitch Assist ............................ 102
Sunset ...................................... 92
System Map .............................. 34
T
Telephoto ............................ 68, 69
The LCD Monitor Display ......... 63
Time and Date
Clock Display ........................ 46
Time Zone .............................. 217
COPY
Index
289
Transition ................................176
Trimming .................................168
Tv ..............................................96
TV Set .....................................228
U
Underwater ...............................93
V
Video System ............................61
Volume ......................................59
W
White Balance .........................143
Wide Angle ................................68
Wind Filter ...............................108
World Clock .............................217
COPY
290
Addendum
Addendum
The Conversion Lens Adapter LA-DC58K, Off Camera Shoe Cord OC-
E3, and Bracket BKT-DC1 (all sold separately) are required to attach
the Macro Ring Lite MR-14EX or Macro Twin Lite MT-24EX to the
camera. Please read the instructions accompanying the flash and Off
Camera Shoe Cord along with this explanation.
Attaching an Externally Mounted Flash
(for Macro Ring Lite MR-14EX or Macro
Twin Lite MT-24EX)
1
Detach the front component of the conversion
lens adapter from the back component.
• The LA-DC58K can be separated into front and back
components. Normally, both components are used in their
attached state. However, only the back component is attached
to the camera when attaching the Macro Ring Lite MR-14EX or
Macro Twin Lite MT-24EX.
2
Be sure that the camera is turned off.
Back Component
Attach
Front Component
Detach
Attach to camera
COPY
291
Addendum
3
Press the ring release button (a) and hold it
down, and turn the ring in the direction of the
arrow (b).
4
When the { mark on the ring and the z mark
on the camera are aligned, lift off the ring.
5
Align the z mark on the conversion lens
adapter with the z mark on the camera, and
turn the adapter in the direction of the arrows
until locked.
• To remove the conversion lens adapter, turn the adapter in the
opposite direction while holding down the ring release button.
Ring
Ring Release Button
COPY
292
Addendum
6
Attach the Off Camera Shoe Cord to the
bracket.
• Slide the bracket screw to the outer end of the bracket, and
secure the screw into the tripod socket on the Off Camera Shoe
Cord. Be sure to attach the cord and bracket as shown.
7
Attach the camera to the bracket.
• Slide the bracket screw to the outer end of the bracket, and
secure the screw into the tripod socket on the bottom of the
camera. Be sure to attach the camera so that the lens faces as
shown.
COPY
293
Addendum
8
Attach the camera connection component of
the Off Camera Shoe Cord to the hot shoe on
the top of the camera.
9
Attach the controller for the Macro Ring Lite or
Macro Twin Lite to the flash connection
component of the Off Camera Shoe Cord.
COPY
294
Addendum
10
Attach the Macro Ring Lite or Macro Twin Lite
to the conversion lens adapter.
Macro Ring Lite MR-14EX
• Press and hold the release buttons on both sides of Macro Ring
Lite MR-14EX and fit it onto the conversion lens adapter.
Macro Twin Lite MT-24EX
• Attach the flash heads to their respective flash head mounts.
• Press and hold the release button on the top of the external ring
and fit it onto the conversion lens adapter.
• You can also attach a tripod and shoot. If the flash heads
contact the tripod or bracket, adjust the direction of the camera.
Release Buttons
Tripod Socket
Flash Heads
Release Button
COPY
295
Addendum
11
Turn the mode dial to the desired mode.
• The maximum flash synchro shutter speed is 1/250 second.
• The flash will automatically adjust its output when [Flash Mode]
is set to [Auto].
• When [Flash Mode] is set to [Auto] the flash exposure
compensation can be adjusted. When [Flash Mode] is set to
[Manual], the flash output can be adjusted (p. 113).
• When exposure compensation settings are selected on both the
camera and the flash (when in E-TTL mode), the settings on the
flash takes precedence and the camera setting is overridden.
• In mode or when [Flash Mode] is set to [Manual], the output
of an externally mounted flash can be adjusted in the flash
output adjustment screen (p. 113). For the optimum aperture
values and ISO speeds for the distance to the subject, refer to
the guide number listed in the flash’s user guide (the flash’s
setting takes precedence). When making adjustments using the
flash-side controls, set the flash to manual mode. You can also
adjust the flash output even when the camera is set to the E-
TTL automatic flash exposure compensation mode by changing
the flash exposure compensation setting.
12
Press the button, use the or button to
select macro mode, and then set [ND Filter] to
[On].
• Macro mode (p. 74)
• ND filter (p. 140)
13
Configure the externally mounted flash
(p. 268).
• The items that can be configured are the same as those for
Speedlite 220EX.
Be sure that the cords from the Off Camera Shoe Cord, Macro
Ring Lite or Macro Twin Lite do not obstruct or interfere with
the flash.
COPY
296
Addendum
z When you are using Macro Ring Lite MR-14EX or Macro
Twin Lite MT-24EX, you can shoot in E-TTL automatic flash
exposure compensation mode just by setting the camera’s
shooting mode to , or . You are recommended to
set the aperture in or mode for full-fledged macro
flash photography.
z The following functions can be used with Macro Ring Lite
MR-14EX or Macro Twin Lite MT-24EX mounted.
- E-TTL Automatic Flash Exposure Compensation
- FE Lock
- Shutter Sync. (1st-curtain/2nd-curtain) (The flash’s 2nd-
curtain setting takes precedence.)
- Slow Synchro
-Flash Exp. Comp
z When exposure compensation settings are selected on both
the camera and the Macro Ring Lite MR-14EX or Macro Twin
Lite MT-24EX, the flash’s settings takes precedence (when
in E-TTL mode) and the camera setting is overridden.
COPY
297
Canadian Radio Interference Regulations
This Class B digital apparatus complies with Canadian ICES-003.
Réglementation canadienne sur les interférences radio
Cet appareil numérique de la classe B est conforme à la norme NMB-003
du Canada.
FCC Notice
(Digital Camera, Model PC1305 Systems)
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions;
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits
for Class B digital devices, pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The cable with the ferrite core provided with the digital camera must be
used with this equipment in order to comply with Class B limits in Subpart
B of Part 15 of the FCC rules.
Do not make any changes or modifications to the equipment unless
otherwise specified in the manual. If such changes or modifications should
be made, you could be required to stop operation of the equipment.
Canon U.S.A., Inc.
One Canon Plaza, Lake Success, NY 11042, U.S.A.
Tel No. (516) 328-5600
COPY
298
Battery Charger CB-2LZ
This product is not intended to be serviced. Should the product
cease to function in its intended manner, it should be returned to
the manufacturer or be discarded.
This power unit is intended to be correctly orientated in a vertical or
floor mount position.
IMPORTANT SAFETY INSTRUCTIONS-SAVE THESE
INSTRUCTIONS.
DANGER-TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS.
For connection to a supply not in the U.S.A., use an attachment
plug adapter of the proper configuration for the power outlet.
This battery charger is for exclusive use with Battery Pack NB-7L
(1.05 Ah). There is a danger of explosion if other battery packs are
used.
COPY
299
Trademark Acknowledgments
• The SDHC logo is a trademark.
About MPEG-4 Licensing
“This product is licensed under AT&T patents for the MPEG-4 standard and may be
used for encoding MPEG-4 compliant video and/or decoding MPEG-4 compliant video
that was encoded only (1) for a personal and non-commercial purpose or (2) by a video
provider licensed under the AT&T patents to provide MPEG-4 compliant video.
No license is granted or implied for any other use for MPEG-4 standard.”
* Notice displayed in English as required.
Disclaimer
• While every effort has been made to ensure that the information
contained in this guide is accurate and complete, no liability can be
accepted for any errors or omissions.
• Canon reserves the right to change the specifications of the
hardware and software described herein at anytime without prior
notice.
• No part of this guide may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language in any
form, by any means, without the prior written permission of Canon.
• Canon makes no warranties for damages resulting from corrupted
or lost data due to a mistaken operation or malfunction of the
camera, the software, SD memory cards (SD cards), personal
computers, peripheral devices, or use of non-Canon SD cards.
COPY
Functions Available in Each Shooting Mode
300
Functions Available in Each Shooting Mode
Only functions with settings that change with the shooting mode are
listed here.
Shooting Mode
Function
Exposure Compensation (
p. 137
)
–
{ { {
–
ISO Speed (
p. 87
)
Auto
1)
–
{{{{
High ISO Auto
–––
{{
ISO 80 – 1600
{{{{
–
White Balance (
p. 143
)
Auto
1)
{ { { { {
Flash
{ { { {
–
Other than Auto and Flash
{ { { {
–
Drive Mode (
pp. 111, 75
)
Single Shot
{{{{{
Continuous
{{{{
–
Continuous AF
3)
{{{{
–
FaceSelf-Timer
{{{{{
Self-Timer
{{{{{
My Colors (
p. 146
)
{ { { {
–
Bracketing (
pp. 133, 139
)
AE
–
{{{
–
Focusing
{{{{
–
Flash Exposure Compensation (
p. 113
)
–
{ { {
–
Built-in Flash Output Control (
p. 113
)
{{{
––
External Flash Output Control (
p. 268
)
{ { { {
–
Metering System (
p. 141
)
Evaluative
{{{{{
Center-weighted Average
{{{{
–
Spot
{{{{
–
ND Filter (On) (
p. 140
)
{ { { {
–
Number of Recording Pixels (still
images) (
p. 80
)
L/M1/M2/M3/S/W
{{{{{
RAW
{{{{
–
Compression (still images) (
p. 81
)
{ { { { {
Compression (movies) (
p. 107
)
640 × 480, 30 fps
–––––––
320 × 240, 30 fps
–––––––
Av/Tv Setting (
pp. 98, 96
)
{ {
6)
{
7)
– –
Program Shift (
p. 135
)
–
{{{
–
AE/FE Lock (still images) (
pp. 134, 136
)
–
{ { {
–
Standard Exposure Setting in Manual Mode (
p. 100
)
{
––––
AE Lock, Exposure Shift (movies) (
p. 106
)
– – – – – – –
Shooting Zone (
p. 74
)
Normal
{{{{{
Macro
{{{{{
Manual Focus (
p. 130
)
{ { { {
–
COPY
Functions Available in Each Shooting Mode
301
{ { { { { { { { { { { { { {
– –
{
– –
{{{{{{{{{{{{{{{
2)
{{{{
–––––––––––––––––––
–––––––––––––––––––
{ { { { { { { { { { { { { { { { { { {
– – – – – – – – – – – – – – – –
{
– –
– – – – – – – – – – – – – – – –
{ {
–
{{{{{{{{{{{{{{{{{{{
{{
–
{{{{{{{{{{{{
––––
{{{{{{{{{{{{{{{
––––
{{
–
{{{{{{{{
–
{{{
––––
{{
–
{{{{{{{{{{{{{{{{
– – – – – – – – – – – – – – – –
{ {
–
–––––––––––––––––––
–––––––––––––––––––
– – – – – – – – – – – – – – – – – – –
–––––––––––––––––––
– – – – – – – – – – – – – – – – – – –
{{{{{{{{{{{{{{{{{{{
–––––––––––––––––––
–––––––––––––––––––
– – – – – – – – – – – – – – – – –
{ {
{{{{{{{{{{{{{{{
4)
{{
5)
––
–––––––––––––––––––
{ { { { { { { { { { { { { { { { {
– –
–––––––––––––––––
{{
–––––––––––––––––
{{
– – – – – – – – – – – – – – – – – – –
–––––––––––––––––––
– – – – – – – – – – – – – – – – – – –
–––––––––––––––––––
– – – – – – – – – – – – – – – – –
{
–
{{{{{{{{{{{{{{{{{{{
{
––
{
–
{{
–
{{{
–
{{{{{{{
{ {
–
{ { { { { { { {
–
{ { { {
–
{ {
COPY
Functions Available in Each Shooting Mode
302
AF Frame Size (
p. 124
)
Standard
{{{{{
Small
{{{{
–
Face Select and Track (
p. 125
)
Off
{ { { { {
On
{ { { { {
Flash (
p. 73
)
Auto
–––
{{
On
{{{{
–
Off
{{{{{
External
{{{{{
LCD Monitor Setting (
p. 63
)
Off
{ { { { {
No Information
{ { { { {
Information View
{ { { { {
Stitch Direction Selection (Right, Left, Top, Bottom, 2 × 2) (
p. 102
)
–––––––
AF Frame (
p. 121
)
Face Detect
{ { { { {
AiAF (9-point)
{ { { { {
Center
– – – – – –
{
FlexiZone
{ { { {
–
AF-Point Zoom (
p. 116
)
{{{{{
Servo AF (
p. 127
)
{ { { { {
AF Mode
8)
(
p. 120
)
Continuous
{{{{{
Single
{{{{{
Digital Zoom
9)
(
p. 69
)
Standard
{ { { { {
Digital Tele-converter
{ { { { {
Built-in Flash Control (
p. 113
)
Flash Output
Auto
–
{{{{
Manual
{{{
––
Red-Eye Correction
{{{{{
Red-Eye Lamp
{{{{{
Flash Exp. Comp
–
{{{
–
Flash Output
{{{
––
Shutter Sync. (1st curtain, 2nd curtain)
{{{{
–
Slow Synchro
{
10)
{{
10)
{
–
Safety FE
–
{{{
–
i-Contrast (
p. 138
)
{ { { { {
Drive Setting (
p. 75
)
FaceSelf-timer
{{{{{
Self-timer
{{{{{
Custom Timer
{{{{{
Spot AE Point (
p. 142
)
Center
{ { { {
–
AF Point
{ { { {
–
Safety Shift (
p. 97
)
–
{{
––
Auto ISO Shift (
p. 88
)
–
{
–
{ {
MF-Point Zoom (
p. 130
)
{{{{
–
Safety MF (
p. 131
)
{ { { {
–
Shooting Mode
Function
COPY
Functions Available in Each Shooting Mode
303
{{{{{{{{{{{{{{{{{{{
–––––––––––––––––––
{ {
–
{ { { { { { { {
–
{ { { {
–
{ {
{ {
–
{ { { { { { { {
–
{ { { {
– – –
{{
–
{{{{{{{{
––
{
–
{
–––
{{
–
{{{{{{{{
–
{{
–
{{
––
{{{{{{{{{{{{{{{{{
––
{{
–
{{{{{{{{
–
{{
–
{
–––
{ {
–
{ { { { { { { { { { { {
– – – –
{ { { { { { { { { { { { { { { { { { {
{ { { { { { { { { { { { { { {
–
{ {
–
––––––––––––––––
{
––
{ {
–
{ { { { { { { {
–
{ { { {
– – –
{ {
–
{ { { { { { { {
–
{ { { {
–
{ {
{ { { { { { { { { { { { { { { { {
– –
– – – – – – – – – – – – – – – – – – –
{{
–
{{{{{{{{{{{{{
–––
{ { { { { { { { { { {
–
{ { { { {
– –
{{{{
–
{{{{{{
–
{{{{{
––
{{
–
{{{{{{{{{{{{{{{{
{ { { { { { { { { { { { { {
– – –
{
–
{ { { { { { { { { { { { { {
– – – – –
{{
–
{{{{{{{{
–
{{
–
{{
––
–––––––––––––––––––
{{
–
{{{{{{{{
–
{{
–––––
{{
–
{{{{{{{{
–
{{
–
{{
––
–––––––––––––––––––
–––––––––––––––––––
–––––––––––––––––––
–
{
10)
–
{
10)
––
{
10)
{
10)
––––––––
{
––
–––––––––––––––––––
– – – – – – – – – – – – – – – – – – –
{{
–
{{{{{{{{
–
{{{
––––
{{
–
{{{{{{{{{{{{{{{{
{{
–
{{{{{{{{{{{{
––––
– – – – – – – – – – – – – – – – – – –
– – – – – – – – – – – – – – – – – – –
–––––––––––––––––––
– – – – – – – – – – – – – – – – – – –
{{
–
{{{{{{{{
–
{{{{
–––
{ {
–
{ { { { { { { {
–
{ { { {
–
{ {
COPY
Functions Available in Each Shooting Mode
304
{ :Setting available or optimum value is automatically set by the camera. As a rule,
with Stitch Assist, only the first image is available.
:Setting available (depending on the shooting mode saved in Custom mode)
:Selectable only, no settings available.
– :Not available.
1) Set to optimum value depending on each shooting mode.
2) Fix to ISO 3200.
3) Set to Continuous Shooting LV when Manual Focus or Fireworks is selected.
4) Fix to M3 (1600 × 1200)
5) is not available.
6) Only Av (Aperture Value) can be set.
7) Only Tv (Shutter Speed) can be set.
8) Single is only available when AiAF (9-points) is selected.
9) and are not available.
10) Always set to on.
11) Available when the flash fires.
AF-assist Beam (
p. 56
)
{{{{{
Review (Rec. review) (
p. 56
)
{ { { { {
Review Info (
p. 56
)
Off
{{{{{
Detailed/Focus Check
{{{{{
Save Original (
p. 153
)
– – – – – – –
Auto Category (
p. 154
)
{{{{{
IS Mode (
p. 85
)
Continuous
{ { { { {
Shoot Only/Panning
{ { { { {
Converter (
p. 263
)
{{{{{
Record RAW+L, Fine (JPEG) (
p. 84
)
{ { { {
–
Custom Display (
p. 66
)
Shooting Info.
{{{{{
Grid Lines
{{{{{
3:2 Guide
{{{{{
Histogram
{{{{
Registering settings to the Shortcut button (
p. 155
)
{ { { { {
Custom Settings (Saved in the C1/C2) (
p. 109
)
{{{{{{
–
Shooting Mode
Function
COPY
Functions Available in Each Shooting Mode
305
{{
–
{{{{{{{{
–
{
11)
{{{{{{
{ { { { { { { { { { { { { { { { {
– –
{{{{{{{{{{{{{{{{{
––
{{{{{{{{{{{{{{{{
–––
– – – – – – – – – – – – – – –
{
– – –
{{{{{{{{{{{{{{{{{{{
{ { { { { { { { { { { { { { { { { { {
{ { { { { { { { { { { { { { { { {
– –
{{{{{{{{{{{{{{{{{{{
– – – – – – – – – – – – – – – – – – –
{{{{{{{{{{{{{{{{{{{
{{{{{{{{{{{{{{{{ {{
{{{{{{{{{{{{{{{{
{ { { { { { { { { { { { { { { { { { {
–––––––––––––––––––
COPY
Camera User Guide
Camera User Guide
CDI-E407-020 XXXXXX PRINTED IN JAPAN
ENGLISH
DIGITAL CAMERA
Ensure that you read the Safety Precautions (pp. 248 – 257).
Getting Started
p. 9
© CANON INC. 2008
COPY
