User Manual

This is the main product document for model 27EA33V.

The file format is pdf, 28 pages, you can download this manual here .

background
www.lg.com
OWNER’S MANUAL
LED LCD MONITOR
27EA33V
Please read this manual carefully before operating
your set and retain it for future reference.
LED LCD MONITOR MODEL
ENGLISH
background
2
ENG
ENGLISH
TABLE OF CONTENTS
CONTENTS
3 ASSEMBLINGANDPREPAR-
ING
3 Unpacking
4 Partsandbuttons
5 SettinguptheMonitorset
5 - AttachingtheStandBase
6 - DetachingtheStandBase
7 - Mountingonatable
7 - Usingthecableholder
9 - Mountingonawall
10 USINGTHEMONITORSET
10 ConnectingtoaPC
10 - D-SUBconnection
10 - DVI-Dconnection
10 - HDMIconnection
12 CUSTOMIZINGSETTINGS
13 CustomizingSettings
13 - MenuSettings
14 -PICTURE
15 -COLOR
16 -DISPLAY
16 -VOLUME
17 -OTHERS
18 MYKEYSetting
19 FUNC.Setting
19 -PICTUREMODE
20 -SUPERENERGYSAVING
21 -DUALDISPLAY
21 -DUALWEB
22 -MYKEYSETTING
23 TROUBLESHOOTING
25 SPECIFICATIONS
25 27EA33V
26 PresetModes(Resolution)
26 Indicator
27 PROPERPOSTURE
27 ProperpostureforusingtheMonitorset.
background
3
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLINGANDPREPARING
Unpacking
Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal
dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct
andaccessories.
Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.
Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.
Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.
Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade
ofproductfunctions.
CAUTION
NOTE
StandBody StandBase
CD(Owner'sManual)/
Card
D-SUBCable
DVI-DCable
(Thiscableisnotincluded
inallcountries.)
(Dependingonthecountry) (Dependingonthecountry)
PowerCord AC-DCAdapter AC-DCAdapter
or
TwoScrews
background
4
ENG
ENGLISH
ASSEMBLING AND PREPARING
Partsandbuttons
PowerIndicator
LightingOn:Turnedon
LightingOff:Turnedoff
Connectionpanel(Seep.10)
Button(Seep.12)
(PowerButton)
background
5
ENG
ENGLISH
ASSEMBLING AND PREPARING
Attachthe
StandBody
tothemonitorset.
Usetwoscrewstofixthe
StandBody
and
monitorset.
Attachthe
StandBase
.
Tightenthescrewtotherightwithacoin.
SettinguptheMonitorset
AttachingtheStandBase
1
PlacetheMonitorsetwiththescreenside
downonaflatandcushionedsurface.
Layafoammatorsoftprotectivecloth
onthesurfacetoprotectthescreenfrom
damage.
CAUTION
StandBase
StandBody
StandBody
1
2
3
4
2
background
6
ENG
ENGLISH
ASSEMBLING AND PREPARING
Thisillustrationdepictsthegeneralmodelof
connection.Yourmonitormaydifferfromthe
itemsshowninthepicture.
Donotcarrytheproductupsidedownholding
onlythestandbase.Theproductmayfall
andgetdamagedorinjureyourfoot.
CAUTION
DetachingtheStandBase
1
PlacetheMonitorsetwiththescreenside
downonaflatandcushionedsurface.
StandBase
StandBody
StandBody
Turnthescrewtotheleftwithacoin.
Pulloutthe
StandBase
fromthe
Stand
Body
.
Removetwoscrewsandpulloutthe
Stand
Body
fromthemonitorset.
1
2
3
2
background
7
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mountingonatable
1
LiftandtilttheMonitorsetintoitsupright
positiononatable.
Leavea10cm(minimum)spacefromthewall
forproperventilation.
Usingthecableholder
2
ConnecttheAC-DCAdapterandPowerCord
toawalloutlet.
3
Press (Power)buttononthebottomswitch
paneltoturnthepoweron.
10 cm
10 cm
10 cm
10 cm
Unplugthepowercordbeforemovingthe
Monitortoanotherlocation.Otherwiseelectric
shockmayoccur.
CAUTION
Cableholder
or
background
8
ENG
ENGLISH
ASSEMBLING AND PREPARING
UsingtheKensingtonsecuritysystem
TheKensingtonsecuritysystemconnectoris
locatedatthebackoftheMonitorset.Formore
informationofinstallationandusing,refertothe
manualsuppliedwiththeKensingtonsecurity
systemorvisit
http://www.kensington.com
.
ConnecttheKensingtonsecuritysystemcable
betweentheMonitorsetandatable.
TheKensingtonsecuritysystemisoptional.
Youcanobtainitfrommostelectronicsstores.
NOTE
Whenyouadjusttheangle,donotholdthe
bottomoftheMonitorsetframeasshownon
thefollowingillustration,asmayinjureyour
fingers.
Donottouchorpressthescreenwhen
adjustingtheangleofthemonitor.
Donotholdthissetlikebelowpicture.Monitor
screencandetachfromstandbaseandinjure
yourbody.
WARNING
Tiltfrom+20to-5degreesupordowntoadjust
theangleoftheMonitorsettosuityourview.
NOTE
Front Rear
background
9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mountingonawall
Forproperventilation,allowaclearanceof10cm
oneachsideandfromthewall.Detailed
instructionsareavailablefromyourdealer,seethe
optionalTiltWallMountingBracketInstallationand
SetupGuide.
IfyouintendtomounttheMonitorsettoawall,
attachWallmountinginterface(optionalparts)to
thebackoftheset.
WhenyouinstalltheMonitorsetusingawall
mountinginterface(optionalparts),attachit
carefullysoitwillnotdrop.
1
Please,Usethescrewandwallmountinterface
inaccordancewithVESAStandards.
2
Ifyouusescrewlongerthanstandard,the
monitormightbedamagedinternally.
3
Ifyouuseimproperscrew,theproductmightbe
damagedanddropfrommountedposition.In
thiscase,LGElectronicsisnotresponsiblefor
it.
4
VESAcompatible.
5
PleaseuseVESAstandardasbelow.
784.8mm(30.9inch)andunder
*WallMountPadThickness:2.6mm
*Screw:Φ4.0mmxPitch0.7mmx
Length10mm
787.4mm(31.0inch)andabove
*PleaseuseVESAstandardwallmountpad
andscrews.
10 cm
10 cm
10 cm
10 cm
Disconnectthepowercordfirst,andthen
moveorinstalltheMonitorset.Otherwise
electricshockmayoccur.
IfyouinstalltheMonitorsetonaceilingor
slantedwall,itmayfallandresultinsevere
injury.
UseonlyanauthorizedLGwallmount
andcontactthelocaldealerorqualified
personnel.
Donotovertightenthescrewsasthismay
causedamagetotheMonitorsetandvoid
yourwarranty.
Useonlyscrewsandwallmountsthat
meettheVESAstandard.Anydamages
orinjuriesbymisuseorusinganimproper
accessoryarenotcoveredbythewarranty.
UsethescrewsthatarelistedontheVESA
standardscrewspecifications.
Thewallmountkitwillincludeaninstallation
manualandnecessaryparts.
Thewallmountbracketisoptional.Youcan
obtainadditionalaccessoriesfromyourlocal
dealer.
Thelengthofscrewsmaydifferdepending
onthewallmount.Besuretousetheproper
length.
Formoreinformation,refertothe
instructionssuppliedwiththewallmount.
CAUTION
NOTE
Model
27EA33V
VESA(AxB)
100x100
Standardscrew
M4
Numberofscrews
4
background
10
ENG
ENGLISH
USING THE MONITOR SET
USINGTHEMONITORSET
ConnectingtoaPC
YourMonitorsetsupportsPlug&Play*.
*Plug&Play:APCrecognizesaconnected
devicethatusersconnecttoaPCandturn
on,withoutdeviceconfigurationoruser
intervention.
D-SUBconnection
TransmitsanalogvideofromyourPCtothe
Monitorset.ConnectthePCandtheMonitorset
withthesuppliedD-sub15pinsignalcableas
showninthefollowingillustrations.
Macadapter
ForAppleMacintoshuse,aseparateplug
adapterisneededtochangethe15pin
highdensity(3row)D-SUBVGAconnector
onthesuppliedcabletoa15pin2row
connector.
WhenusingaD-Subsignalinputcable
connectorforMacintosh
IfyouuseHDMIPC,itcancausecompatibility
problem.
NOTE
NOTE
DVI-Dconnection
TransmitsadigitalvideosignalfromyourPCto
theMonitorset.ConnectthePCandtheMonitor
setwithaDVIcableasshowninthefollowing
illustrations.
HDMIconnection
Transmitsthedigitalvideoandaudiosignalsfrom
yourPCorA/VtotheMonitorset.ConnectthePC
orA/VandtheMonitorsetwiththeHDMIcableas
showninthefollowingillustrations.
background
11
ENG
ENGLISH
USING THE MONITOR SET
WhenyouwanttousetwoPCinourMonitor,
pleaseconnectthesignalcable(D-SUB/
DVI-D/HDMI)respectivelyinMonitorset.
IfyouturntheMonitorsetonwhileitiscold,
thescreenmayflicker.Thisisnormal.
Somered,green,orbluespotsmayappear
onthescreen.Thisisnormal.
"SelfImageSetting"Function.
Thisfunctionprovidestheuserwithoptimal
displaysettings.Whentheuserconnects
themonitorforthefirsttime,thisfunction
automaticallyadjuststhedisplaytooptimal
settingsforindividualinputsignals.(Only
supportedinAnalogMode)
‘AUTO’Function.
Whenyouencounterproblemssuchas
blurryscreen,blurredletters,screenflicker
ortiltedscreenwhileusingthedeviceor
afterchangingscreenresolution,pressthe
AUTOfunctionbuttontoimproveresolution.
(OnlysupportedinAnalogMode)
NOTE NOTE
Connectthesignal
inputcableandtighten
itbyturningthescrews
clockwise.
Donotpressthescreenwithyourfingerfor
alongtimeasthismayresultintemporary
distortiononthescreen.
Avoiddisplayingafixedimageonthe
screenforalongperiodoftimetoprevent
imageburn.Useascreensaverifpossible.
CAUTION
SelfImageSettingFunction
Pressthepowerbuttononthebottompanelto
turnthepoweron.Whenmonitorpoweristurned
on,the"
SelfImageSetting
"Functionisexecuted
automatically.(OnlysupportedinAnalogMode)
background
12
ENG
ENGLISH
CUSTOMIZING SETTINGS
CUSTOMIZINGSETTINGS
1
PressthedesiredbuttononthebottomoftheMonitorset.
2
ChangethevalueofthemenuitembypressingthebuttonsonthebottomoftheMonitorset.
Toreturntotheuppermenuorsetothermenuitems,usetheuparrow( )button.
3
Select
EXIT
toleavetheOSDmenu.
MENU
MY KEY
AUTO
INPUT
EXIT
FUNC.
MonitorsetButtons
Button Description
Accessesthemainmenus.(Seep.13)
OSDLOCKED/
UNLOCKED
Thisfunctionallowsyoutolockthecurrentcontrolsettings,so
thattheycannotbeinadvertentlychanged.
PressandholdtheMENUbuttonforseveralseconds.
Themessage"OSDLOCKED"shouldappear.
YoucanunlocktheOSDcontrolsatanytimebypushing
theMENUbuttonforseveralseconds.Themessage"OSD
UNLOCKED"shouldappear.
UsethisbuttontoenterMYKEYmenu.Formoreinformation.(Seep.18)
UsethisbuttontoenterPICTUREMODE,SUPERENERGYSAVING,DUALDISPLAY,
DUALWEB,MYKEYSETTINGmenus.(Seep.19)
Whenadjustingyourdisplaysettings,alwayspresstheAUTObuttonontheMONITOR
SETUPOSD.(OnlysupportedinAnalogMode)
Thebestdisplaymode
1920x1080
Youcanchoosetheinputsignal.
• Whentwoinputsignalsareconnected,youcanselecttheinputsignal(D-SUB/DVI/
HDMI)youwant.
• Whenonlyonesignalisconnected,itisautomaticallydetected.Thedefaultsettingis
D-SUB.
EXIT
ExittheOSD(OnScreenDisplay).
(PowerButton)
Turnsthepoweronoroff.
PowerIndicator
Thepowerindicatorstaysredifthedisplayisrunningproperly
(OnMode).IfthedisplayisinSleepMode,thepowerindicator
blinksred.
background
13
ENG
ENGLISH
CUSTOMIZING SETTINGS
CustomizingSettings
MenuSettings
1
Press
MENU
buttononthebottomoftheMonitorset
todisplaythe
MENU
OSD.
2
Settheoptionsbypressingthe◄or►or▼
buttons.
3
Selectthe"
NEXTMENU
"buttontoenterthemore
optionsettings.
4
Select
EXIT
toleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,
usetheuparrow( )button.
Eachoptionisexplainedbelow.
MENU>NEXTMENU Analog Digital HDMI Description
SHARPNESS ● ● ●
Toadjusttheclearnessofthescreen.
BLACKLEVEL ●
Tosetoffsetlevel
OVERSCAN ●
Toimprovetheclarityandstabilityofthescreen
RESPONSETIME ● ● ●
Tosettheresponsetimeofdisplayedpicture.
COLOR GAMMA
● ● ●
Tocustomizethecolorofthescreen
COLORTEMP
DISPLAY HORIZONTAL
●
Toadjustthepositionofthescreen
VERTICAL
CLOCK
●
Toimprovetheclarityandstabilityofthescreen
PHASE
VOLUME
●
Toadjustthevolume
OTHERS LANGUAGE
● ● ●
Tocustomizethescreenstatusforauser'soperating
environment
POWERINDICATOR
Analog:
D-SUB(Analogsignal)input.
Digital:
DVI-D(Digitalsignal)input.
HDMI:
HDMI(Digitalsignal)input.
MENU Analog Digital HDMI Description
BRIGHTNESS
● ● ●
Toadjustthebrightness,contrastofthescreen
CONTRAST ● ● ●
WIDE/ORIGINAL
● ● ●
WIDE
Switchtofullscreenmodeaccordingtoinputimagesignal.
ORIGINAL
Changetheinputimagesignalratiotooriginal.
*ThisfunctionworksonlyifinputresolutionislowerthanMonitorsetratio
(16:9).
RESET
● ● ●
Restoreallfactorydefaultsettings.Pressthe
◄
,
►
buttonstoreset
immediately.
DUAL
WEB
DUAL
WEB
background
14
ENG
ENGLISH
CUSTOMIZING SETTINGS
1
Press
MENU
buttononthebottomoftheMonitorset
todisplaythe
MENU
OSD.
2
Selectthe"
NEXTMENU
"buttontoenterthemore
optionsettings.
3
Enterto
bypressingthe▼button.
4
Settheoptionsbypressingthe◄or►or▼
buttons.
5
Select
EXIT
toleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,
usetheuparrow( )button.
Eachoptionisexplainedbelow.
MENU>NEXTMENU>PICTURE Description
SHARPNESS
Toadjusttheclearnessofthescreen.
BLACKLEVEL
Youcansettheoffsetlevel.Ifyouselect'HIGH',thescreenwillbebrightandif
youselect‘LOW’,thescreenwillbedark.(onlyforHDMIinput)
*Offset?Asthecriteriaforvideosignal,itisthedarkestscreenthemonitorcan
show.
OVERSCAN
ToselecttherangeofoutputimageforDTVtiminginHDMIinput.(onlyforHDMI
input)RecommendoverscanfunctiontoturnonwhenconnectAVequipment.
RESPONSETIME
Youcansetaresponsetimefordisplayedpicturesbasedonthespeedofthe
screen.Foranormalenvironment,itisrecommendedthatyouuse'NORMAL'.
Forafast-movingpicture,itisrecommendedthatyouuse'FAST'.
DUAL
WEB
background
15
ENG
ENGLISH
CUSTOMIZING SETTINGS
COLOR
1
Press
MENU
buttononthebottomoftheMonitorset
todisplaythe
MENU
OSD.
2
Selectthe"
NEXTMENU
"buttontoenterthemore
optionsettings.
3
Select
COLOR
bypressingthe►button.
4
Enterto
COLOR
bypressingthe▼button.
5
Settheoptionsbypressingthe◄or►or▼
buttons.
6
Select
EXIT
toleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,
usetheuparrow( )button.
Eachoptionisexplainedbelow.
DUAL
WEB
MENU>NEXTMENU>COLOR Description
GAMMA
Setyourowngammavalue.:GAMMA0,GAMMA1,GAMMA2onthemonitor,
highgammavaluesdisplaywhitishimagesandlowgammavaluesdisplay
blackishimages.
COLORTEMP CUSTOM
•RED:
Setyourownredcolorlevels.
•GREEN:
Setyourowngreencolorlevels.
•BLUE:
Setyourownbluecolorlevels.
Selectthescreencolor.
WARM:
Setthescreentowarmcolortemperature(morered).
MEDIUM:
Setthescreentomediumcolortemperature.
COOL:
Setthescreentocoolcolortemperature(moreblue).
background
16
ENG
ENGLISH
CUSTOMIZING SETTINGS
DISPLAY
1
Press
MENU
buttononthebottomoftheMonitorset
todisplaythe
MENU
OSD.
2
Selectthe"
NEXTMENU
"buttontoenterthemore
optionsettings.
3
Select
DISPLAY
bypressingthe►button.
4
Enterto
DISPLAY
bypressingthe▼button.
5
Settheoptionsbypressingthe◄or►or▼
buttons.
6
Select
EXIT
toleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,
usetheuparrow( )button.
Eachoptionisexplainedbelow.
VOLUME
1
Press
MENU
buttononthebottomoftheMonitorset
todisplaythe
MENU
OSD.
2
Selectthe"
NEXTMENU
"buttontoenterthemore
optionsettings.
3
Select
VOLUME
bypressingthe►button.
4
Enterto
VOLUME
bypressingthe▼button.
5
Settheoptionsbypressingthe◄or►buttons.
6
Select
EXIT
toleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,
usetheuparrow( )button.
Eachoptionisexplainedbelow.
MENU>NEXTMENU>DISPLAY Description
HORIZONTAL
Tomoveimageleftandright.
VERTICAL
Tomoveimageupanddown.
CLOCK
Tominimizeanyverticalbarsorstripesvisibleonthescreenbackground.The
horizontalscreensizewillalsochange.
PHASE
Toadjustthefocusofthedisplay.Thisitemallowsyoutoremoveanyhorizontal
noiseandclearorsharpentheimageofcharacters.
MENU>NEXTMENU>VOLUME Description
VOLUME
Toadjustthevolumeofheadphone/earphone.(OnlyforHDMIinput)
DUAL
WEB
DUAL
WEB
background
17
ENG
ENGLISH
CUSTOMIZING SETTINGS
OTHERS
1
Press
MENU
buttononthebottomoftheMonitorset
todisplaythe
MENU
OSD.
2
Selectthe"
NEXTMENU
"buttontoenterthemore
optionsettings.
3
Select
OTHERS
bypressingthe►button.
4
Enterto
OTHERS
bypressingthe▼button.
5
Settheoptionsbypressingthe◄or►or▼
buttons.
6
Select
EXIT
toleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,
usetheuparrow( )button.
Eachoptionisexplainedbelow.
MENU>NEXTMENU>OTHERS Description
LANGUAGE
Tochoosethelanguageinwhichthecontrolnamesaredisplayed.
POWER
INDICATOR
Usethisfunctiontosetthepowerindicatoronthebottomsideofthemonitorto
ONorOFF.IfyousetOFF,itwillgooff.
IfyousetONatanytime,thepowerindicatorwillautomaticallybeturnedon.
DUAL
WEB
background
18
ENG
ENGLISH
CUSTOMIZING SETTINGS
MYKEYSetting
1
Press
MYKEY
buttononthebottomoftheMonitor
settodisplaythe
MYKEY
OSD.
2
Settheoptionsbypressingthe◄or►or▼buttons.
3
Select
EXIT
toleavetheOSDmenu.
MYKEY Description
MYKEYSETTING
MYKEYisshortkey.YoucanselectoneofFUNC.(PICTUREMODE,SUPER
ENERGYSAVING,DUALDISPLAY,DUALWEB)asyourfavoritefeature.
BACK
SelectBACKtoreturnMYKEYmenu.
Eachoptionisexplainedbelow.
DUAL
WEB
background
19
ENG
ENGLISH
CUSTOMIZING SETTINGS
FUNC.Setting
PICTUREMODE
1
Press
FUNC.
buttonon thebottomoftheMonitorset
todisplaythe
FUNC.
OSD. 
2
Enterto
PICTUREMODE
bypressingthe▼button.
3
Settheoptionsbypressingthe◄or►buttons.
4
Select
EXIT
toleavetheOSDmenu.Toreturntothe
uppermenuorsetothermenuitems,usetheup
arrow( )button.
PICTUREMODE Description
CUSTOM
Itisamodethattheusercanadjusteachelement.ItcanadjustthecolormodeoftheMainMenu.
TEXT
Itisamodethatthescreenisadjustedtothebestforthetextworks.
Itisamodethatthescreenisadjustedtothebesttoviewpictures.
CINEMA
Itisamodethatthescreenisadjustedtothebesttoviewthevideos.
GAME
Itisamodethatthescreenisadjustedtothebesttoplayagame.
Eachoptionisexplainedbelow.
PICTUREMODE Description
CUSTOM
Itisamodethattheusercanadjusteachelement.ItcanadjustthecolormodeoftheMainMenu.
VIVID1
Adjuststhevideoimagefortheretailenvironmentbyenhancingthecontrast,brightness,Colour,
andsharpness.
VIVID2
STANDARD
Adjuststheimageforthenormalenvironment.
CINEMA
Itisamodethatthescreenisadjustedtothebesttoviewthevideos.
DUAL
WEB
DUAL
WEB
AVMODE
PCMODE
background
20
ENG
ENGLISH
CUSTOMIZING SETTINGS
Eachoptionisexplainedbelow.
SUPERENERGYSAVING Description
ON
EnablesSUPERENERGYSAVINGyoucansaveenergywiththisenergy-efficientfunction
OFF
DisablesSUPERENERGYSAVING.
RESET
ResetsthevaluesoftotalenergyconsumptionreductionandCO2emissionreduction
estimates.
TOTALPOWERREDUCTION
:Howmuchpowerissavedwhileusingthemonitor.
TOTALCO2REDUCTION
:ChangetheTOTALPOWERREDUCTIONtoCO2.
SAVINGDATA(W/h)
685mm(27inch)
SUPERSAVING
8W/h
SavingDatadependsonthePanel.So,thosevaluesshouldbedifferentfromeachpanelandpanel
vendor.
LGcalculatedthesevaluesbyusing
“broadcastvideosignal”
(includingbroadcastvideo:IEC62087)
SUPERSAVINGreferstohowmuchpowercanbesavedusingtheSUPERENERGYSAVING
function.
NOTE
SUPERENERGYSAVING
1
Press
FUNC.
buttononthebottomoftheMonitorsetto
displaythe
FUNC.
OSD.
2
Select
SUPERENERGYSAVING
bypressingthe►
button.
3
Enterto
SUPERENERGYSAVING
bypressingthe▼
button.
4
Settheoptionsbypressingthe◄or►or▼buttons.
5
Select
EXIT
toleavetheOSDmenu.Toreturntothe
uppermenuorsetothermenuitems,usetheuparrow
( )button.
DUAL
WEB
background
21
ENG
ENGLISH
CUSTOMIZING SETTINGS
NOTE
Whenmonitorgoestopowersavingmodewithpcsavingoption->Pressinganybutton->OSD
appearandusershouldpressdualbutton->Usercanbringbacktonormalmode.
DUALDISPLAY
1
Press
FUNC.
buttononthebottomoftheMonitorset
todisplaythe
FUNC.
OSD.
2
Select
DUALDISPLAY
bypressingthe►button.
3
Enterto
DUALDISPLAY
bypressingthe▼button.
4
Settheoptionsbypressingthe◄or►buttons.
5
Select
EXIT
toleavetheOSDmenu.Toreturntothe
uppermenuorsetothermenuitems,usetheup
arrow( )button.
*Beforeusingbelowfunctions,pleaseinstallDUALSMARTSOLUTIONprogramme.
Eachoptionisexplainedbelow.
DUALDISPLAY Description
CLONE
ByselectingCLONE,usercanusesecondarymonitorasdonemodeofprimary
monitor.
EXTENDED
ByselectingEXTENDED,usercanusesecondarymonitorasextendedmodeof
primarymonitor.
OFF
IfselectOFF,DUALDISPLAYisoff.
DUALWEB
1
Press
FUNC.
buttononthebottomoftheMonitorset
todisplaythe
FUNC.
OSD.
2
Select
DUALWEB
bypressingthe►button.
3
Enterto
DUALWEB
bypressingthe▼button.
4
Settheoptionsbypressingthe◄or►buttons.
5
Select
EXIT
toleavetheOSDmenu.Toreturntothe
uppermenuorsetothermenuitems,usetheup
arrow( )button.
*Beforeusingbelowfunctions,pleaseinstallDUALSMARTSOLUTIONprogramme.
Eachoptionisexplainedbelow.
DUALWEB Description
ON
Helpusertobrowsewebefficientlybydividinginhalf.Helptoarrangeandmove
windowsonscreen.Helpusertocontroldividedwindowsratio.
OFF
IfselectOFF,DUALWEBisoff.
DUAL
WEB
DUAL
WEB
background
22
ENG
ENGLISH
CUSTOMIZING SETTINGS
Eachoptionisexplainedbelow.
MYKEYSETTING
1
Press
FUNC.
buttononthebottomoftheMonitor
settodisplaythe
FUNC.
OSD.
2
Select
MYKEYSETTING
bypressingthe►button.
3
Enterto
MYKEYSETTING
bypressingthe▼
button.
4
Settheoptionsbypressingthe◄or►buttons.
5
Select
EXIT
toleavetheOSDmenu.Toreturnto
theuppermenuorsetothermenuitems,use
theuparrow ( )button.
MYKEYSETTING Description
PICTUREMODE
PICTUREMODEadjusttheMonitorsetforthebestpictureappearance.
SUPERENERGYSAVING
EnablesSUPERENERGYSAVINGyoucansaveenergywiththisenergy-effcient
function.
DUALDISPLAY
UsercanuseCLONEorEXTENDEDinanothermonitor.
DUALWEB
Helpusertobrowsewebefficientlybydividinginhalfandsomeotherconveniencein
browsingdualpages.
DUAL
WEB
background
23
ENG
ENGLISH
TROUBLESHOOTING
TROUBLESHOOTING
Checkthefollowingbeforecallingforservice.
Noimageappears
Isthepowercordofthedisplay
connected?
Checkandseeifthepowercordisconnectedproperlytothepower
outlet.
Isthepowerindicatorlighton?
PressthePowerbutton.
Isthepoweronandthepower
indicatorRed?
Adjustthebrightnessandthecontrast.
Isthepowerindicatorflickering?
Ifthedisplayisinpowersavingmode,trymovingthemouseor
pressinganykeyonthekeyboardtobringupthescreen.
TrytoturnonthePC.
Doyouseean"OUTOFRANGE"
messageonthescreen?
ThismessageappearswhenthesignalfromthePC(videocard)is
outofhorizontalorverticalfrequencyrangeofthedisplay.Seethe
'Specifications'sectionofthismanualandconfigureyourdisplay
again.
Doyouseea"NOSIGNAL"
messageonthescreen?
Whenthemonitorison"No-Signal"in5minutes,themonitorgoesto
DPMmode.
Doyouseea"OSDLOCKED"messageonthescreen?
Doyousee“OSDLOCKED”when
youpushMENUbutton?
Youcansecurethecurrentcontrolsettings,sothattheycannotbe
inadvertentlychanged.YoucanunlocktheOSDcontrolsatanytime
bypushingtheMENUbuttonforseveralseconds:themessage“OSD
UNLOCKED”willappear.
Displayimageisincorrect
DisplayPositionisincorrect.
Pressthe
AUTO
buttontoautomaticallyadjustyourdisplayimageto
theidealsetting.
Onthescreenbackground,vertical
barsorstripesarevisible.
Pressthe
AUTO
buttontoautomaticallyadjustyourdisplayimageto
theidealsetting.
Anyhorizontalnoiseappearingin
anyimageorcharactersarenot
clearlyportrayed.
Pressthe
AUTO
buttontoautomaticallyadjustyourdisplayimageto
theidealsetting.
Check
ControlPanel►Display►Settings
andadjustthedisplay
totherecommendedresolutionoradjustthedisplayimagetotheideal
setting.Setthecolorsettinghigherthan24bits(truecolor).
DUAL
WEB
background
24
ENG
ENGLISH
TROUBLESHOOTING
Displayimageisincorrect
Thescreencolorismonoor
abnormal.
Checkifthesignalcableisproperlyconnectedanduseascrewdriver
tofastenifnecessary.
Makesurethevideocardisproperlyinsertedintheslot.
Setthecolorsettinghigherthan24bits(truecolor)at
ControlPanel
►
Settings
.
Thescreenblinks.
Checkifthescreenissettointerlacemodeandifyes,changeittothe
recommendresolution.
Doyouseean"Unrecognizedmonitor,Plug&Play(VESADDC)monitorfound"message?
Haveyouinstalledthedisplay
driver?
BesuretoinstallthedisplaydriverfromthedisplaydriverCD(or
diskette)thatcomeswithyourdisplay.Or,youcanalsodownloadthe
driverfromourwebsite:http://www.lg.com.
MakesuretocheckifthevideocardsupportsPlug&Playfunction.
Check
ControlPanel►Display►Settings
andseeifthefrequencyortheresolutionwere
changed.Ifyes,readjustthevideocardtotherecommendresolution.
Iftherecommendedresolution(optimalresolution)isnotselected,lettersmaybeblurredandthe
screenmaybedimmed,truncatedorbiased.Makesuretoselecttherecommendresolution.
ThesettingmethodcandifferbycomputerandO/S(OperationSystem),andresolutionmentioned
abovemaynotbesupportedbythevideocardperformance.Inthiscase,pleaseasktothecomputer
orthevideocardmanufacturer.
CAUTION
background
25
ENG
ENGLISH
SPECIFICATIONS
Display ScreenType
68.5cm(27inch)FlatPanelActivematrix-TFTLCDAnti-
Glarecoating
Visiblediagonalsize:68.5cm
PixelPitch
0.311mmx0.311mm(PixelPitch)
SyncInput HorizontalFrequency
30kHzto83kHz(Automatic)
VerticalFrequency
56Hzto75Hz(D-SUB,DVI-D)
56Hzto61Hz(HDMI)
InputForm
SeparateSync.Digital
VideoInput SignalInput
15pinD-SUBConnector/DVI-DConnector(Digital)
HDMIConnector
InputForm
RGBAnalog(0.7Vp-p/75ohm),Digital
Resolution Max
D-SUB(Analog):1920x1080@60Hz
DVI/HDMI(Digital):1920x1080@60Hz
Recommend
VESA1920x1080@60Hz
Plug&Play
DDC2B(Analog,Digital,HDMI)
Power
Consumption
OnMode:30W(Typ.)
SleepMode≤0.3W
OffMode≤0.3W
PowerInput
19V 1.6A
AC-DCAdapter
TypeADS-40SG-19-319032G,manufacturedbySHENZHENHONORELECTRONIC
orADS-40FSG-1919032GPG-1,manufacturedbySHENZHENHONORELECTRONIC
orADS-40FSG-1919032GPBR-1,manufacturedbySHENZHENHONORELECTRONIC
orADS-40FSG-1919032GPI-1,manufacturedbySHENZHENHONORELECTRONIC
orADS-40FSG-1919032GPCU-1,manufacturedbySHENZHENHONORELECTRONIC
OUTPUT:
19V 1.7A
Dimensions
(WidthxHeightx
Depth)
WithStand
64.1cmx45.9cmx20.3cm
WithoutStand
64.1cmx39cmx4.7cm
Weight
4.7kg
TiltRange
-5°to20°
Environmental
conditions
OperatingTemperature
OperatingHumidity
10°Cto35°C
10%to80%
StorageTemperature
StorageHumidity
-20°Cto60°C
5%to90%non-Condensing
StandBase
Attached(),Detached(O)
Powercord
Wall-outlettype
Productspecificationsshownabovemaybechangedwithoutpriornoticeduetoupgradeofproduct
functions.
SPECIFICATIONS
27EA33V
background
26
ENG
ENGLISH
SPECIFICATIONS
PresetModes(Resolution)
DisplayModes(Resolution)
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
Polarity(H/V)
720x400 31.468 70 -/+
640x480 31.469 60 -/-
640x480 37.500 75 -/-
800x600 37.879 60 +/+
800x600 46.875 75 +/+
1024x768 48.363 60 -/-
1024x768 60.023 75 +/+
1152x864 67.500 75 +/+
1280x1024 63.981 60 +/+
1280x1024 79.976 75 +/+
1680x1050 65.290 60 -/+
1920x1080 67.500 60 +/+ RecommendMode
HDMITIMING
DisplayModes(Resolution) HorizontalFrequency(kHz) VerticalFrequency(Hz)
480P 31.50 60
576P 31.25 50
720P 37.50 50
720P 45.00 60
1080i 28.12 50
1080i 33.75 60
1080P 56.25 50
1080P 67.50 60 RecommendMode
Indicator
Mode LEDColor
OnMode Red
SleepMode BlinkingRed
OffMode Off
27EA33V
background
27
ENG
ENGLISH
PROPER POSTURE
ProperpostureforusingtheMonitorset.
PROPERPOSTURE
Adjustthe
Monitorsetand
yourpostureto
allowyoutoview
imagesatthe
optimalviewing
angle.
Placeyourhands
gentlyonthe
keyboard,keeping
yourarmsbentat
theelbowsand
horizontallyoutright.
Adjustthelocationofthe
Monitorsettoavoidit
reflectinglight.
background
Make sure to read the Safety Precautions before
using the product.
Keep the Owner’s Manual (CD) in an accessible
place for future reference.
The model and serial number of the SET is
located on the back and one side of the SET.
Record it below should you ever need service.
MODEL
SERIAL

Specifications

Indexed Terms: Monitor, Slim Design

LG Electronics 27EA33V Questions and Answers

Find answers or ask new question.
Questions and Answers

Related Products

No image
LG Electronics 27EA53VQ-P 27" Class Slim IPS LED Monitor (27.0" diagonal)
2020-04-08 2 docs
No image
LG Electronics 27EA53V-P 27" Class Slim IPS LED Monitor (27.0" diagonal)
2020-03-09 1 docs
No image
LG Electronics 27EA73LM-P 27" Class Slim IPS LED Monitor with MHL (27.0" diagonal)
2020-01-15 2 docs
Product LG Electronics 22MP57VQ image
LG Electronics 22MP57VQ Lg Ips Monitor
2021-04-27 1 docs
Product LG Electronics 22MP58VQ image
LG Electronics 22MP58VQ Lg Ips Monitor
2021-04-19 1 docs
Product LG Electronics 24MB35D image
LG Electronics 24MB35D Lg Ips Monitor
2021-02-01 2 docs
