MINI KOMPONENTEN SYSTEM
MINI-CHAÎNE
SISTEMA MINI
MINI KOMPONENT SYSTEM
MINI SISTEMI
MINI SYSTEEM
MINI SISTEMA DE COMPONENTES
MINI COMPONENT SYSTEM
MODELL MODELLO
MODÈLE MODEL
MODELO MODELO
MODELL MODEL
CD-ES111H
BEDIENUNGSANLEITUNG MANUALE DI ISTRUZIONI
MODE D’EMPLOI GEBRUIKSAANWIJZING
MANUAL DE MANEJO MANUAL DE OPERAÇÃO
BRUKSANVISNING OPERATION MANUAL
Mini Komponenten System CD-ES111H besteht aus CD-ES111H (Hauptgerät)
und CP-ES111H (Lautsprecher-System).
Mini-chaîne CD-ES111H composée de CD-ES111H (appareil principal) et de CP-
ES111H (enceintes acoustiques).
Sistema mini CD-ES111H que consta de CD-ES111H (aparato principal) y CP-
ES111H (sistema de altavoces).
CD-ES111H mini komponent system bestående av CD-ES111H (huvudenhet) och
CP-ES111H (högtalarsystem).
Mini sistemi CD-ES111H composto da CD-ES111H (apparecchio principale) e
CP-ES111H (sistema di diffusori).
CD-ES111H mini systeem bestaande uit CD-ES111H (hoofdtoestel) en CP-ES111H
(luidsprekersysteem).
CD-ES111H Mini Sistema de Componentes composto de CD-ES111H (unidade
principal) e CP-ES111H (sistema de alto-falante).
CD-ES111H Mini Component System consisting of CD-ES111H (main unit) and
CP-ES111H (speaker system).
Siehe Seiten i bis vi und D-1 bis D-28.
Se reporter aux pages i à vi et F-1 à F-28.
Consulte las páginas i a vi y S-1 a S-28.
DEUTSCH
Favor consultar as páginas i a vi e P-1 a P-28.
PORTUGUÊS
FRANÇAIS
ESPAÑOL
Hänvisa till sidorna i till vi och V-1 till V-28.
Leggere le pagine i a vi e I-1 a I-28.
Raadpleeg de bladzijden i t/m vi en N-1 t/m N-28.
SVENSKA
ITALIANO
NEDERLANDS
Please refer to pages i to vi and E-1 to E-28.
ENGLISH
CD-ES111H(SEEG) TINSZA004SJZZ
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
BESONDERE ANMERKUNGEN
REMARQUES SPÉCIALES
NOTAS ESPECIALES
SÄRSKILDA ANMÄRKNINGAR
NOTE PARTICOLARI
BIJZONDERE OPMERKINGEN
NOTAS ESPECIAIS
SPECIAL NOTES
0203
● Dette udstyr overholder kravene i direktiv nr. 89/336/EEC og
73/23/EEC med tillaeg nr. 93/68/EEC.
● Dette produktet oppfyller betingelsene i direktivene 89/336/
EEC og 73/23/EEC i endringen 93/68/EEC.
● Tämä laite täyttää direktiivien 89/336/EEC ja 73/23/EEC
vaatimukset, joita on muutettu direktiivillä 93/68/EEC.
●
● Bei Einstellung der ON/STAND-BY-Taste auf STAND-BY ist
die Netzspannung immer noch im Gerät vorhanden.
Wenn die ON/STAND-BY-Taste auf STAND-BY eingestellt
wird, kann das Gerät unter Verwendung der Timer-Betriebsart
oder Fernbedienung in Betrieb gesetzt werden.
Warnung:
In diesem Gerät sind keine vom Benutzer wartbaren Teile
vorhanden. Niemals Abdeckungen entfernen, außer wenn Sie
dafür qualifiziert sind. In diesem Gerät sind gefährliche
Spannungen vorhanden. Vor Ausführung von irgendwelchen
Kundendienstarbeiten oder bei längerer Nichtverwendung des
Gerätes stets den Netzstecker aus der Netzsteckdose ziehen.
● Lorsque la touche ON/STAND-BY est mise en STAND-BY,
l’appareil est toujours sous tension.
Lorsque la touche ON/STAND-BY se trouve sur la position
STAND-BY, l’appareil est prêt à fonctionner par la minuterie
ou la télécommande.
Avertissement:
Cet appareil contient des pièces non réparables par
l’utilisateur. Personne non qualifiée n’enlèvera jamais les
couvercles. L’appareil contenant des organes portés à haute
tension, débrancher l’appareil avant toute réparation ou en
période de non-utilisation.
● Dieses Gerät entspricht den Anforderungen der EG-Richtlinien
89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG.
● Ce matériel répond aux exigences contenues dans les direc-
tives 89/336/CEE et 73/23/CEE modifiées par la directive 93/
68/CEE.
● Este aparato satisface las exigencias de las Directivas
89/336/CEE y 73/23/CEE, modificadas por medio de la 93/
68/CEE.
● Denna utrustning uppfyller kraven enligt riktlinjerna 89/336/
EEC och 73/23/EEC så som kompletteras av 93/68/EEC.
● Quest’apparecchio è conforme ai requisiti delle direttive 89/
336/EEC e 73/23/EEC, come emendata dalla direttiva 93/68/
EEC.
● Dichiarazione di conformità
La società SHARP ELECTRONICS EUROPE GmbH dichiara
che il prodotto SHARP MINI SISTEMI CD-ES111H è costruito
in conformità alle prescrizioni del D.M.n˚548 del 28/8/95,
pubblicato sulla G.U.n˚301 del 28/12/95 ed in particolare è
conforme a quanto indicato nell’art. 2, comma 1 dello stesso
decreto.
● Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/
EEG en 73/23/EEG, gewijzigd door 93/68/EEG.
● Este equipamento obedece às exigências das directivas 89/
336/CEE e 73/23/CEE, na sua versão corrigida pela directiva
93/68/CEE.
● This equipment complies with the requirements of Direc-
tives 89/336/EEC and 73/23/EEC as amended by 93/68/
EEC.
i
CD-ES111H
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
CD-ES111H(SEEG) TINSZA004SJZZ
ii
0203
● Wanneer de ON/STAND-BY toets in de STAND-BY stand
staat, loopt er nog steeds stroom (netspanning) in het toestel.
Wanneer de ON/STAND-BY toets in de STAND-BY stand
staat, kan het toestel ingeschakeld worden via de timerfunctie
of de afstandsbediening.
Waarschuwing:
Dit toestel bevat geen door de gebruiker te repareren
onderdelen. Verwijder de behuizing nooit tenzij u deskundig
bent op dit gebied. In het toestel loopt een gevaarlijke span-
ning; haal de stekker altijd uit het stopcontact alvorens
onderhoud uit te voeren of wanneer het toestel voor langere
tijd niet gebruikt wordt.
● Quando o botão ON/STAND-BY estiver ajustado na posição
STAND-BY, a voltagem de alimentação ainda se encontra
presente dentro do aparelho.
Quando o botão ON/STAND-BY estiver ajustado na posição
STAND-BY, o aparelho pode ser colocado em operação
através do modo de programação horária ou pelo controle
remoto.
Advertência:
Neste aparelho não há partes que podem ser consertadas
pelo usuário. Nunca retire a tampa, a menos que você tenha
qualificação para tal. Este aparelho contém voltagens
perigosas. Remova sempre o cabo de alimentação da tomada
antes de efetuar qualquer conserto ou quando deixar o
aparelho muito tempo fora de uso.
● When the ON/STAND-BY button is set at STAND-BY posi-
tion, mains voltage is still present inside the unit.
When the ON/STAND-BY button is set at STAND-BY posi-
tion, the unit may be brought into operation by the timer mode
or remote control.
Warning:
This unit contains no user serviceable parts. Never remove
covers unless qualified to do so. This unit contains danger-
ous voltages, always remove mains plug from the socket be-
fore any service operation and when not in use for a long
period.
● Cuando el botón ON/STAND-BY está puesto en la posición
STAND-BY, todavía hay tensión dentro del aparato.
Cuando el botón ON/STAND-BY está puesto en la posición
STAND-BY, el aparato puede ponerse en funcionamiento
utilizando el modo del temporizador o el controlador remoto.
Advertencia:
Tenga en cuenta que dentro de este aparato no hay piezas
que pueda reparar. No quite nunca las tapas a menos que se
esté cualificado para hacerlo. Este aparato tiene en su inte-
rior tensiones peligrosas.
Desenchufe siempre la clavija de la red del tomacorriente
antes de realizar cualquier servicio de mantenimiento y
cuando no se use el aparato durante un largo período de
tiempo.
● När ON/STAND-BY knappen är i läge STAND-BY, finns
nätspänning i apparaten.
Med ON/STAND-BY knappen i läge STAND-BY kan apparaten
startas med timerfunktion eller fjärrkontrollen.
Varning:
Apparaten innehåller inga delar som kan åtgärdas av kunden.
Höljet får endast öppnas av kvalificerad personal. Apparaten
innehåller farliga spänningar.
Stickkontakten ska därför dras ut från nätuttaget före
reparationsarbeten och bör dras ut om apparaten inte ska
användas på mycket länge.
● Quando il tasto ON/STAND-BY si trova in posizione STAND-
BY, all’interno dell’apparecchio c’è ancora la corrente.
Se il tasto ON/STAND-BY si trova nella posizione STAND-
BY, l’unità può essere accesa con il modo timer o con il
telecomando.
Avvertenza:
L’apparecchio non contiene parti riparabili dall’utente.
Non togliere mai i coperchi, a meno di non essere qualificati
per farlo. All’interno dell’apparecchio ci sono tensioni
pericolose, per cui si deve sempre staccare la spina del cavo
d’alimentazione dalla presa di corrente prima di qualsiasi
intervento di manutenzione e quando non si usa l’apparecchio
per un lungo periodo di tempo.
1
2
3
4
5
6
7
8
9
SHARP TINSZA004SJZZ
10
CD-ES111H
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
CD-ES111H(SEEG) TINSZA004SJZZ
iii
0203
● Når ON/STAND-BY-knappen er sat i STAND-BY positionen,
er der stadig netspaending til stede i apparatet.
Når ON/STAND-BY-knappen er sat i STAND-BY position,
kan apparatet startes v.hj.a. timer-funksionen eller
fjernbetjeningen.
Advarsel:
Apparatet indeholder ingen dele, der kan repareres af
brugeren selv. Fjern aldrig kabinettet med mindre De er
kvalificeret hertil. Apparatet indeholder farlig
strømspaending. Traek altid stikket ud af stikkontakten før
der foretages reparationer, eller hvis apparatet ikke er i
brug i laengere tid.
DENNA APPARAT ÄR ANSLUTEN TILL 230 V
VÄXELSTRÖM NÄR STICKPROPPEN ÄR INSKJUTEN I
VÄGGUTTAGET. FÖR ATT FULLSTÄNDIGT KOPPLA IFRÅN
APPARATEN, V.G. DRAG UT STICKPROPPEN.
● Audio-visuelles Material kann Urheberrechte umfassen, die
ohne Genehmigung des Eigentümers dieser Urheberrechte
nicht aufgenommen werden dürfen. Siehe die entsprechenden
nationalen Gesetze.
● Le matériel audio-visuel peut comporter des oeuvres faisant
l’objet de droits d’auteur qui ne peuvent être enregistrées sans
l’autorisation du possesseur du droit d’auteur, veuillez vous
référer aux réglementations nationales en vigueur.
● El material audiovisual puede consistir en trabajos que tengan
derechos de autor y que no deben grabarse sin la autorización
del poseedor de dichos derechos de autor. Sírvase consultar
las leyes aplicables en su país.
● Audiovisuellt material kan innehålla upphovsrättsarbete som
inte skall mångfaldigas utan tillstånd av copyrightinnehavaren.
Se den tillämpliga lagen i ditt land.
● Il materiale audio-visivo che fosse soggetto a copyright non
può essere registrato senza l’autorizzazione del possessore
del copyright. Si prega di attenersi alle leggi in vigore sul
territorio nazionale.
● Audio-visueel materiaal kan worden beschermd door
auteursrechten, in welk geval het niet mag worden opgenomen
zonder de toestemming van de auteursrechthouder. Zie voor
nadere informatie de betreffende wetten in het land van
gebruik.
● O material audiovisual pode consistir de trabalhos de direitos
autorias que não devem ser gravados sem autorização do
proprietário dos direitos. Favor consultar as leis vigentes em
seu país.
● Audio-visual material may consist of copyrighted works which
must not be recorded without the authority of the owner of the
copyright. Please refer to relevant law in your country.
CD-ES111H
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
CD-ES111H(SEEG) TINSZA004SJZZ
iv
● Advarsel:
Til at forbygge ild og stød risiko, lad vaere med at undsaette
denne indretning for drypning eller overstaenkning. Der må
ikke anbringes nogen genstande fyldt med vand, som for
eksempel vaser, på dette apparat.
● Advarsel:
For å unngå brann eller kortslutning, utsett ikke produktet for
vann eller fuktighet. Gjenstander som inneholder vaeske, feks.
en blomstervase, må ikke plasseres oppå apparatet.
● Varoitus:
Älä vie laitetta sateeseen tai kosteisiin tiloihin. Jos laite on
kostunut, anna sen kuivua ennen kuin käytät sitä
verkkovirralla. Nestettä sisältäviä astioita kuten esim.
kukkamaljakoita ei saa asettaa laitteen päälle.
0203
● Vorsicht:
Das Gerät weder Tropf- noch Spritzwasser aussetzen.
Ansonsten besteht die Gefahr eines Brandes oder
elektrischen Schlages. Es sollten keine mit Flüssigkeiten
gefüllten Gegenstände wie Vasen auf dem Gerät abgestellt
werden.
● Attention:
Pour éviter un incendie ou une secousse électrique, mettre
l’appareil à l’abri de l’eau (éclaboussure, goutte). Ne pas poser
sur l’appareil un récipient contenant du liquide.
● Advertencia:
Para evitar incendios y descargas eléctricas, no exponga
el aparato a goteo o salpicadura de líquidos. No deberán
ponerse encima del aparato objetos que estén llenos de
líquido, como por ejemplo un florero.
● Varning:
Utsätt inte enheten för dropp eller stänk för att förhindra
brand eller elektriska stötar. Inga vätskefyllda föremål
såsom vaser bör placeras på enheten.
● Attenzione:
Per prevenire incendi o scosse elettriche, non fare
gocciolare nessun liquido sull’apparecchio e non bagnarlo.
Non collocarvi sopra nessun oggetto riempito d’acqua, come
per esempio vasi.
● Waarschuwing:
Stel het toestel niet bloot aan druipend of spattend water
om brand en elektrische schokken te voorkomen. Met
vloeistoffen gevulde voorwerpen, zoals vazen, mogen niet
op het toestel geplaatst worden.
● Cuidado:
Para evitar incêndio ou choque elétrico, não exponha este
aparelho a gotejamento ou salpicamento de água. Não
coloque objetos com água como, por exemplo, um vaso de
flores, em cima do aparelho.
● Warning:
To prevent fire or shock hazard, do not expose this appli-
ance to dripping or splashing. No objects filled with liquids,
such as vases, should be placed on the apparatus.
Dieses Produkt ist ein Laserprodukt der Klasse 1.
Ce produit est classifié comme étant un LASER DE CLASSE 1.
Este producto está clasificado como un PRODUCTO LÁSER DE
CLASE 1.
Denna produkt klassificeras som KLASS 1 LASERPRODUKT.
Questo prodotto è classificato come CLASS 1 LASER PRODUCT.
Dit product is geclassificeerd als een KLASSE 1 LASER PRODUCT.
This product is classified as a CLASS 1 LASER PRODUCT.
Este produto é classificado como PRODUTO LASER DE CLASSE 1.
Dette produktet er klassifisert som et KLASSE 1 LASERPRODUKT.
Dette produkt er klassificeret som et KLASSE 1 LASERPRODUKT.
Tämä laite on luokiteltu LUOKAN 1 LASERLAITTEEKSI.
Denna produkt klassificeras som KLASS 1 LASERAPPARAT.
CD-ES111H
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
CD-ES111H(SEEG) TINSZA004SJZZ
v
0203
● VORSICHT
Verwendung von Regelungen oder Einstellungen bzw.
Durchführung von anderen Verfahren als die hierin
angegebenen kann zum Aussetzen gefährlicher Strahlung
führen.
Da der in diesem Compact Disc Player verwendete Laserstrahl
für die Augen schädlich ist, ist das Gehäuse unter keinen
Umständen zu zerlegen.
Wenden Sie sich für Wartungsarbeiten nur an berechtigten
Fachhändler.
● ATTENTION
Respecter les indications données relatives à la manipula-
tion, au réglage et au fonctionnement. En cas de non-respect,
on s’exposera à une radiation dangereuse.
Éviter absolument de démonter l’appareil, qui utilise un rayon
laser nuisible aux yeux. Pour toute réparation, s’adresser à
une personne qualifiée.
● PRECAUCIÓN
El uso de los controles, ajustes o ejecución de procedimientos
distintos de los especificados podría causar la exposición a
radiación peligrosa.
No intente desmontar la caja ya que el haz de láser usado en
este reproductor de discos compactos es perjudicial para los
ojos. Para el servicio de reparación, consulte a una persona
cualificada.
● OBSERVERA
Användning av reglage eller justeringar eller handhavande
på annat sätt än som anges kan leda till farlig bestrålning.
Försök inte ta isär höljet eftersom CD-spelarens laserstråle
är skadlig för ögonen. Överlåt service endast till kvalificerad
personal.
● ATTENZIONE
L’uso dei comandi e l’effettuazione di regolazioni e
procedimenti diversi da quelli specificati nel manuale possono
provocare una pericolosa esposizione alle radiazioni.
Poiché il raggio laser usato in questo giradischi può
danneggiare gli occhi, non smontare l’apparecchio. Per le
riparazioni rivolgersi a personale specializzato.
● LET OP
Gebruik van regelaars, het maken van instellingen, gebruik
of handelingen anders dan in deze gebruiksaanwijzing
vermeld, kan gevaarlijke straling blootleggen.
De laserstraal in deze CD-speler kan de ogen beschadigen,
Probeer derhalve de ombouw niet te verwijderen. Laat
reparaties alleen over aan erkend onderhoudspersoneel.
● CUIDADO
O uso de controles, ajustes ou a execução de procedimentos
além daqueles especificados aqui pode resultar em perigosa
exposição à radiação.
Como os raios laser usados neste player de CD são perigosos
para os olhos, não tente desmontar o aparelho. Solicite o
conserto somente para pessoas especializadas.
● CAUTION
Use of controls, adjustments or performance of procedures
other than those specified herein may result in hazardous ra-
diation exposure.
As the laser beam used in this compact disc player is harmful
to the eyes, do not attempt to disassemble the cabinet. Refer
servicing to qualified personnel only.
CD-ES111H
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
CD-ES111H(SEEG) TINSZA004SJZZ
vi
Eigenschaften der Laserdiode
Material: GaAIAs
Wellenlänge: 780 nm
Emissionsdauer: kontinuierlich
Laser-Ausgang: max. 0,6 mW
Caractéristiques de la diode laser
Matière: GaAIAs
Longueur d’onde: 780 nm
Durée d’émission: ininterrompue
Puissance de sortie laser maximale: 0,6 mW
Características del diodo láser
Material: GaAIAs
Longitud de onda: 780 nm
Duración de emisión : continua
Salida de láser: máx. 0,6 mW
Laserdiodens egenskaper
Material: GaAIAs
Våglängd: 780 nm
Utstrålningsvaraktighet: kontinuerlig
Lasereffekt: max. 0,6 mW
Proprietà del diodo laser
Materiale: GaAIAs
Lunghezza d’onda: 780 nm
Durata di emissione: continua
Uscita massima del laser: 0,6 mW
Laser diode specificaties
Materiaal: GaAIAs
Golflengte: 780 nm
Stralingsduur: doorlopend
Laseruitgang: max. 0,6 mW
Propriedades do diodo laser
Material: GaAlAs
Comprimento de onda: 780 nm
Duração da emissão: contínua
Saída de laser: máx. 0,6 mW
Laser Diode Properties
Material: GaAIAs
Wavelength: 780 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW
0203
VAROITUS! LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ
KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA
ALTISTAA KÄYTTÄJÄN TURVALLISUUSLUOKAN 1
YLITTÄVÄLLE NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE.
VARNING - OM APPARATEN ANVÄNDS PÅ ANNAT SÄTT ÄN
I DENNA BRUKSANVISNING SPECIFICERAS. KAN
ANVÄNDAREN UTSÄTTAS FÖ R OSYNLIG LASER-
STRÅLNING, SOM ÖVERSKRIDER GRÄ NSEN FÖ R
LASERKLASS 1.
ADVERSEL-SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING.
SE IKKE IND I STRÅLEN-HELLER IKKE MED OPTISKE INSTRUMENTER.
VARO! AVATTAESSA OLET ALTTIINA NÄKYVÄLLE JA NÄKYMÄTTÖMÄLLE
LASERSÄTEILYLLE ÄLÄ TUIJOTA SÄTEESEEN ÄLÄKÄ KATSO SITÄ
OPTISEN LAITTEEN LÄPI.
VARNING-SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA
DEL ÄR ÖPPNAD. STIRRA EJ IN I STRÅLEN OCH BETRAKTA EJ
STRÅLEN GENOM OPTISKT INSTRUMENT.
0203
CD-ES111H
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-1
ENGLISH
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
ENGLISH
General Information
Introduction
Thank you for purchasing this SHARP product. To obtain the best
performance from this product, please read this manual carefully. It
will guide you in operating your SHARP product.
Accessories
Please confirm that the following accessories are included.
Note:
Only the above accessories are included.
Contents
Page
General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 5
Preparation for Use
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
Basic Operation
Sound control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
CD Playback
Listening to a CD (CDs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11, 12
Advanced CD playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 14
Radio
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 16
Tape Playback
Listening to a cassette tape (TAPE 1 or TAPE 2) . . . . . . . . . . . 17
Tape Recording
Recording to a cassette tape . . . . . . . . . . . . . . . . . . . . . . 18 - 20
Advanced Features
Timer and sleep operation . . . . . . . . . . . . . . . . . . . . . . . . 21 - 23
Enhancing your system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25, 26
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27, 28
Remote control 1 "AA" size battery (UM/SUM-3,
R6, HP-7 or similar) 2
FM/AM loop aerial 1 AC power lead 1
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-2
ENGLISH
8
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
General Information
Precautions
General
z
Please ensure that the equipment is positioned in a well venti-
lated area and ensure that there is at least 10 cm (4") of free
space along the sides, top and back of the equipment.
z
Use the unit on a firm, level surface free from vibration.
z
Keep the unit away from direct sunlight, strong magnetic fields,
excessive dust, humidity and electronic/electrical equipment
(home computers, facsimiles, etc.) which generate electrical
noise.
z
Do not place anything on top of the unit.
z
Do not expose the unit to moisture, to temperatures higher than
60°C (140°F) or to extremely low temperatures.
z
If your system does not work properly, disconnect the AC power
lead from the wall socket. Plug the AC power lead back in, and
then turn on your system.
z
In case of an electrical storm, unplug the unit for safety.
z
Hold the AC power plug by the head when removing it from the
wall socket, as pulling the lead can damage internal wires.
z
Do not remove the outer cover, as this may result in electric
shock. Refer internal service to your local SHARP service
facility.
z The ventilation should not be impeded by covering the ventilation
openings with items, such as newspapers, tablecloths, curtains,
etc.
z No naked flame sources, such as lighted candles, should be
placed on the apparatus.
z Attention should be drawn to the environmental aspects of bat-
tery disposal.
z
The apparatus is designed for use in moderate climate.
z
This unit should only be used within the range of 5°C - 35°C
(41°F - 95°F).
Warning:
The voltage used must be the same as that specified on this unit.
Using this product with a higher voltage other than that which is
specified is dangerous and may result in a fire or other type of acci-
dent causing damage. SHARP will not be held responsible for any
damage resulting from use of this unit with a voltage other than that
which is specified.
Volume control
The sound level at a given volume setting depends on speaker effi-
ciency, location, and various other factors. It is advisable to avoid
exposure to high volume levels. Do not turn the volume on to full at
switch on and listen to music at moderate levels.
Care of compact discs
Compact discs are fairly resistant to damage, however mistracking
can occur due to an accumulation of dirt on the disc surface. Follow
the guidelines below for maximum enjoyment from your CD collec-
tion and player.
z
Do not write on either side of the disc, particularly the non-label
side from which signals are read. Do not mark this surface.
z
Keep your discs away from direct sunlight, heat, and excessive
moisture.
z
Always hold the CDs by the edges. Fingerprints, dirt, or water on
the CDs can cause noise or mistracking. If a CD is dirty or does
not play properly, clean it with a soft, dry cloth, wiping straight out
from the centre, along the radius.
10 cm (4") 10 cm (4")
10 cm (4")
10 cm (4")
NO YES
Correct
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-3
ENGLISH
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
General Information
Controls and indicators
Front panel
Reference page
1. Disc Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2. Timer Set Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3. Memory/Set Button . . . . . . . . . . . . . . . . . . . . . . . . . 10, 14, 16
4. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5. Clock Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10, 21
6. Timer/Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21, 23
7. Tuning and Time Up Button . . . . . . . . . . . . . . . . . . . . . . 10, 15
8. Tuning and Time Down Button . . . . . . . . . . . . . . . . . . . 10, 15
9. Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
10. Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . . 18, 19
11. Tape 1 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . 17
12. Equaliser Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . 9
13. Extra Bass/Demo Mode Button . . . . . . . . . . . . . . . . . . . . . 8, 9
14. Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . 9
15. Disc Tray Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . 11
16. Disc Skip Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
17. Tape 2 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . 17
18. CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
19. Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
20. CD or Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . 12, 17
21. CD Track Down or Fast Reverse, Tape 2 Rewind,
Tuner Preset Down Button . . . . . . . . . . . . . . . . . . . 12, 16, 17
22. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
23. Video/Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
24. CD Play or Repeat, Tape Play Button . . . . . . . . . . . 11, 13, 17
25. CD Track Up or Fast Forward, Tape 2 Fast Forward,
Tuner Preset Up Button . . . . . . . . . . . . . . . . . . . . . . 12, 16, 17
3
4
5
2
1
6
11
7
8
9
10
12
16
14
15
17
13
22
23
24
25
18
19
20
21
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-4
ENGLISH
8
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
General Information
Display
Reference page
1. Disc Number Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2. CD Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3. Tape Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4. FM Stereo Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5. FM Stereo Receiving Indicator . . . . . . . . . . . . . . . . . . . . . . 15
6. Memory Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7. Extra Bass Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
8. Timer Recording Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 21
9. Timer Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
10. CD Pause Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
11. CD Repeat Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
12. Tape 2 Record Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
13. Sleep Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Rear panel
Reference page
1. Video/Auxiliary (Audio Signal) Input Sockets . . . . . . . . . . 24
2. AC Power Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
3. FM/AM Loop Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4. Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
Speaker system
1. Bass Reflex Ducts
2. Full-Range Speaker
3. Speaker Wire
1
3
4
2
213 4567
8
9
131210 11
3
1
1
2
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-5
ENGLISH
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
General Information
Controls and indicators (continued)
Remote control
Reference page
1. Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . 6
2. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3. CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4. Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5. Memory Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6. Programme Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7. Tuning and Time Down Button . . . . . . . . . . . . . . . . . . . 10, 15
8. CD Track Down or Fast Reverse, Tape 2 Rewind,
Tuner Preset Down Button . . . . . . . . . . . . . . . . . . . 12, 16, 17
9. CD or Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . 12, 17
10. Equaliser Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . 9
11. Disc Number Select Buttons . . . . . . . . . . . . . . . . . . 11, 14, 18
12. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
13. Video/Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
14. CD Random Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
15. CD Track Up or Fast Forward, Tape 2 Fast Forward,
Tuner Preset Up Button . . . . . . . . . . . . . . . . . . . . . . 12, 16, 17
16. Tuning and Time Up Button . . . . . . . . . . . . . . . . . . . . . . 10, 15
17. CD Play or Repeat, Tape Play Button . . . . . . . . . . . 11, 13, 17
18. Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . . 18, 19
19. CD Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
20. Extra Bass Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
21. Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . 9
1
2
3
4
5
6
7
8
9
10
14
12
13
11
17
18
21
20
19
15
16
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-6
ENGLISH
8
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Preparation for Use
Remote control
Battery installation
Precautions for battery use:
z
Replace all old batteries with new ones at the same time.
z
Do not mix old and new batteries.
z
Remove the batteries if the unit is not to be used for long periods
of time. This will prevent potential damage due to battery leak-
age.
Caution:
z
Do not use rechargeable batteries (nickel-cadmium battery, etc.).
z
Installing the batteries incorrectly may cause the unit to malfunc-
tion.
Notes concerning use:
z
Replace the batteries if the operating distance is reduced or if the
operation becomes erratic. Purchase 2 "AA" size batteries (UM/
SUM-3, R6, HP-7 or similar).
z
Periodically clean the transmitter on the remote control and the
sensor on the unit with a soft cloth.
z
Exposing the sensor on the unit to strong light may interfere with
operation. Change the lighting or the direction of the unit.
z
Keep the remote control away from moisture, heat, shock, and
vibrations.
Test of the remote control
Check the remote control after checking all the connections (see
pages 7 - 8).
Point the remote control directly at the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now, you
can enjoy music.
1 Remove the battery cover.
2 Insert the batteries according to the direction indicated in
the battery compartment.
When inserting or removing the batteries, push them towards the
battery terminals.
3 Replace the cover.
0.2 m - 6 m
(8" - 20')
Remote sensor
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-7
ENGLISH
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Preparation for Use
System connections
FM/AM loop aerial connection
Connect the FM/AM loop aerial to the ANTENNA socket.
Position the FM aerial wire and rotate the AM loop aerial for opti-
mum reception. Place the AM loop aerial on a shelf, or attach it to a
stand or a wall.
Notes:
z
Placing the aerial on the stereo system or near the AC power
lead may cause noise pickup. Place the aerial away from the ste-
reo system for better reception.
z Do not connect the attached FM aerial to an external FM aerial.
Otherwise, trouble may occur.
Installing the AM loop aerial:
AM loop aerial
FM aerial
Right speaker
Left speaker
Wall socket
(AC 230 V, 50 Hz)
Black
Red
Make sure to unplug the AC power lead before any connec-
tions.
< Assembling > < Attaching to the wall >
Wall Screws (not supplied)
3
TINSZA004SJZZ
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-8
ENGLISH
8
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Preparation for Use
Speaker connection
Connect the black wire to the minus (-) terminal, and the red wire to
the plus (+) terminal.
Caution:
Note:
The speaker grilles are not removable.
Connecting the AC power lead
After checking all the connections have been made correctly, con-
nect the AC power lead to the AC power input socket, then plug the
AC power lead of this unit into the wall socket. If you plug in the unit
first, the unit will enter the demonstration mode.
Notes:
z
Unplug the AC power lead from the wall socket if the unit will not
be in use for a prolonged period of time.
z
Never use a power lead other than the one supplied. Otherwise, a
malfunction or an accident may occur.
Demonstration mode
To cancel the demonstration mode:
When the unit is in the power stand-by mode (demonstration mode),
press the X-BASS/DEMO button. The unit will enter the low power
consumption mode.
To return to the demonstration mode:
When the unit is in the power stand-by mode, press the X-BASS/
DEMO button again.
Note:
When the power is on, the X-BASS/DEMO button can be used to
select the extra bass mode.
To turn the power on
Press the ON/STAND-BY button to turn the power on.
z
Use speakers with an impedance of 8 ohms
or more, as lower impedance speakers can
damage the unit.
z
Do not mistake the right and the left chan-
nels. The right speaker is the one on the right
side when you face the unit.
z
Do not let the bare speaker wires touch
each other.
z
Do not allow any objects to fall into or to be
placed in the bass reflex ducts.
z Do not stand or sit on the speakers. You may
be injured.
Incorrect
The first time the unit is plugged in, the
unit will enter the demonstration mode.
You will see words scroll.
After use:
Press the ON/STAND-BY button to enter the power stand-by
mode.
4
TINSZA004SJZZ
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-9
ENGLISH
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Basic Operation
Sound control
Volume control
Press the VOLUME (+ or -) button to increase or decrease the vol-
ume.
Bass control
When the power is first turned on, the unit will enter the extra bass
mode which emphasises the bass frequencies, and "X-BASS" will
appear. To cancel the extra bass mode, press the X-BASS/DEMO
(X-BASS) button.
Equaliser
When the EQUALIZER (EQUALIZER MODE) button is pressed, the
current mode setting will be displayed. To change to a different
mode, press the EQUALIZER (EQUALIZER MODE) button repeat-
edly until the desired sound mode appears.
12 29 30 (MAXIMUM)0
.....
X-BASS indicator
FLAT
The sound is not modified.
ROCK
Bass and treble are emphasised.
POPS
Bass and treble are slightly emphasised.
JAZZ
Treble is slightly emphasised.
CLASSIC
Treble is cut a little.
VOCAL
Vocals (midrange tones) are emphasised.
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-10
ENGLISH
8
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Basic Operation
Setting the clock
In this example, the clock is set for the 24-hour (0:00) display.
To confirm the time display:
Note:
The "CLOCK" or time will flash at the push of the CLOCK button
when the AC power supply is restored after a power failure or
unplugging the unit.
Readjust the clock as follows.
To readjust the clock:
Perform "Setting the clock" from step 1. If the "CLOCK" is not flash-
ing in step 1, step 2 (for selecting the 24-hour or 12-hour display) will
be skipped.
To change the 24-hour or 12-hour display:
1 Press the CLOCK button and within 8 seconds, press the
MEMORY/SET button.
2 Within 30 seconds, press the TUNING/TIME ( or ) button
to select 24-hour or 12-hour display and then press the
MEMORY/SET button.
"0:00" The 24-hour display will appear.
(0:00 - 23:59)
"AM 12:00" The 12-hour display will appear.
(AM 12:00 - PM 11:59)
Note that this can only be set when the unit is first installed or it
has been reset. [Refer to "Clearing all the memory (reset)" on
page 26 for details.]
3
Within 30 seconds, press the TUNING/TIME ( or ) button
to adjust the hour and then press the MEMORY/SET button.
z
Press the TUNING/TIME ( or ) button once to advance
the time by 1 hour. Hold it down to advance continuously.
z
When the 12-hour display is selected, "AM" will change au-
tomatically to "PM".
4
Within 30 seconds, press the TUNING/TIME ( or ) button to
adjust the minutes and then press the MEMORY/SET button.
z
Press the TUNING/TIME ( or ) button once to advance
the time by 1 minute. Hold it down to advance continuously.
z
The hour will not advance even if minutes advance from "59"
to "00".
Press the CLOCK button.
The time display will appear for
about 8 seconds.
1 Clear all the programmed contents. [Refer to "Clearing all the
memory (reset)" on page 26 for details.]
2 Perform "Setting the clock" from step 1.
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-11
ENGLISH
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
CD Playback
Listening to a CD (CDs)
This system can also play audio CD-R and CD-RW discs, but cannot
record.
Some audio CD-R and CD-RW discs may not be playable due to the
state of disc or the device that was used for recording.
1 Press the ON/STAND-BY button to turn the power on.
2 Press the CD button.
3 Press the OPEN/CLOSE button to open the disc tray.
4 Place the CD(s) on the disc tray, label side up.
When loading a third disc, press the DISC SKIP button to
turn the disc tray, then place the CD in the open position.
z
CDs can be placed on any open position on the disc tray.
z
Be sure to place 8 cm (3") CDs in the middle of the disc po-
sitions.
5 Press the OPEN/CLOSE button to close the disc tray.
Total number of tracks on the
CD whose number is flashing
Total playing time of the CD
whose number is flashing
6 To select the CD you want to listen to first, press one of the
1 - 3 buttons on the remote control.
7 Press the / button to
start playback.
z
Playback will begin from track 1 on the disc you have select-
ed to play. After that disc finishes playing, the next disc will
automatically start playback.
z
When the last track on the third disc has finished playing, the
CD player will automatically stop.
z
When there is no CD in one of the disc 1 - 3 positions, that
position will be skipped and the next CD will begin to play.
12 cm (5") 8 cm (3")
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-12
ENGLISH
8
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
CD Playback
To interrupt playback:
Press the button on the remote control.
To resume playback from the same point, press the button.
To stop playback:
Press the button.
To remove the CDs:
Whilst in the stop mode, press the OPEN/CLOSE button.
The disc tray will open. Remove the two discs. Then, press the DISC
SKIP button to rotate the disc tray and remove the remaining disc.
Caution:
z Do not place two CDs in one disc tray.
z Do not play discs with special shapes (heart- or octagon-shaped).
It may cause malfunctions.
z Do not push the disc tray whilst it is moving.
z Do not turn the disc tray by hand. This may cause malfunctions.
z If the power fails whilst the tray is open, wait until the power is re-
stored.
z
If the disc tray is stopped with force, the unit will not function. If
this occurs, press the ON/STAND-BY button to enter the power
stand-by mode and then turn the power on again.
z
If TV or radio interference occurs during CD operation, move the
unit away from the TV or radio.
z
If a disc is damaged, dirty, or loaded upside down, the disc will
skip or not play back.
To locate the beginning of a track
Notes:
z
You can locate the beginning of a track on one disc only.
z
You can skip to any track by pressing the or button
repeatedly until the desired track number appears.
To locate the desired portion
Notes:
z
Normal playback will resume when the or button is
released.
z
You can locate the desired portion on one disc only.
z
When the end of the last track is reached during fast forward,
"END" will appear on the display and CD operation will be paused.
When the beginning of the first track is reached during fast re-
verse, the unit will enter the playback mode.
Pause indicator
To move to the beginning of the next track:
Press the button for less than 0.5 seconds during playback.
To restart the track being played:
Press the button for less than 0.5 seconds during playback.
For audible fast forward:
Press and hold down the button during playback.
For audible fast reverse:
Press and hold down the button during playback.
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-13
ENGLISH
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
CD Playback
Advanced CD playback
Starting playback with a desired track
You can play a disc starting with the desired track.
Notes:
z
When the DISC SKIP button is pressed during playback, the next
disc will begin automatically.
z
When one of the 1 - 3 buttons on the remote control is pressed
during playback, the selected disc will begin automatically.
Random play
The tracks on the disc(s) can be played in random order automatically.
To cancel random play:
Press the button.
Notes:
z
The random play will stop automatically when all tracks are played
once. (The same track will not be played back twice.)
z
If you press the button during random play, you can move
to the track selected next by the random operation. On the other
hand, the button does not allow you to move to the previ-
ous track. The beginning of the track being played will be located.
z
In random play, the CD player will select and play tracks automat-
ically. (You cannot select the order of the tracks.)
Repeat play
All tracks on up to 3 discs, or a programmed sequence can be con-
tinuously repeated.
To cancel repeat play:
Press the / button again. " " will go out.
Caution:
After performing repeat play, be sure to press the button. Other-
wise, the disc(s) will play continuously.
1 Whilst in the stop mode, press one of the 1 - 3 buttons
on the remote control or DISC SKIP button to select the de-
sired disc.
2 Press the or button to select the desired
track.
Selected disc number
Selected track number
3 Press the / button to start playback.
Playback of the selected track is started. When the end of the
last track is reached, the next disc will automatically be started.
Press the RANDOM button on the remote control to begin ran-
dom play.
To repeat all tracks on up to 3 discs:
Press the / button twice.
To repeat a desired track:
Perform steps 1 - 4 in the "Programmed play" section on page 14
and then press the / button twice.
To repeat random play:
Press the / button during random play.
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-14
ENGLISH
8
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
CD Playback
Programmed play
You can choose up to 32 selections for playback in the order you like.
Adding tracks to the programme:
If a programme has been previously stored, the "MEMORY" indicator
will be displayed. Then follow steps 1 - 3 to add tracks. The new
tracks will be stored after the last track of the original programme.
Notes:
z Opening the disc tray automatically cancels the programmed se-
quence.
z
Even if you press the ON/STAND-BY button to enter the stand-by
mode or change the function from CD to another, the programmed
selections will not be cleared.
z
During programme operation, random play is not possible.
1 Whilst in the stop mode, press
one of the 1 - 3 buttons on
the remote control to select
the desired disc.
Selected disc number
2 Press the or but-
ton to select the desired track.
Selected track number
3 Press the MEMORY/SET (MEMORY) button to save the
track number.
Playback order
When the track is memorised, "MEMORY" will appear.
4 Repeat steps 1 - 3 for other tracks. Up to 32 tracks can be
programmed.
If you make a mistake, the programmed tracks can be cleared
by pressing the CLEAR button.
5 Press the / button to start playback.
To clear the programmed selections:
Whilst the "MEMORY" indicator is lit, set the
CD to the stop mode and then press the
CLEAR button.
Each time the button is pressed, one track will
be cleared, beginning with the last track pro-
grammed. When all the tracks are cleared,
"MEMORY" will disappear.
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-15
ENGLISH
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Radio
Listening to the radio
Tuning
To receive an FM stereo transmission:
Press the TUNER (BAND) button to display the "ST" indicator.
z " " will appear when an FM broadcast is in stereo.
z If the FM reception is weak, press the TUNER (BAND) button to
extinguish the "ST" indicator. The reception changes to monaural,
and the sound becomes clearer.
1 Press the ON/STAND-BY button to turn the power on.
2 Press the TUNER (BAND) button repeatedly to select the
desired frequency band (FM or AM).
3 Press the TUNING/TIME ( or ) button to tune in to the de-
sired station.
Manual tuning:
Press the TUNING/TIME button as many times as required to
tune in to the desired station.
Auto tuning:
When the TUNING/TIME button is pressed for more than 0.5
seconds, scanning will start automatically and the tuner will
stop at the first receivable broadcast station.
Notes:
z
This can be operated by pressing the TUN. ( or ) button
on the remote control.
z
When radio interference occurs, auto scan tuning may stop
automatically at that point.
z
Auto scan tuning will skip weak signal stations.
z
To stop the auto tuning, press the TUNING/TIME button
again.
FM stereo mode indicator
FM stereo receiving indicator
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-16
ENGLISH
8
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Radio
Memorising a station
You can store 40 AM and FM stations in memory and recall them at
the push of a button. (Preset tuning)
Note:
The backup function protects the memorised stations for a few hours
should there be a power failure or if the AC lead is disconnected.
To recall a memorised station
Press the PRESET ( or ) button for less than 0.5 seconds to se-
lect the desired station.
To scan the preset stations
The stations saved in memory can be scanned automatically. (Preset
memory scan)
To erase entire preset memory
1 Perform steps 1 - 3 in "Tuning" on page 15.
2 Press the MEMORY/SET button to enter the preset tuning
saving mode.
3 Within 30 seconds, press the PRESET ( or ) button to
select the preset channel number.
Store the stations in memory, in order, starting with preset
channel 1.
4 Within 30 seconds, press the MEMORY/SET button to store
that station in memory.
If the "MEMORY" and preset number indicators go out before
the station is memorised, repeat the operation from step 2.
5 Repeat steps 1 - 4 to set other stations, or to change a pre-
set station.
When a new station is stored in memory, the station previously
memorised will be erased.
1 Press and hold down the PRESET ( or ) button.
The preset number will flash and the programmed stations will be
tuned in sequentially, for 5 seconds each.
2 When the desired station is located, release the PRESET ( or
) button.
1 Press the ON/STAND-BY button to enter the stand-by mode.
2 Whilst pressing down the TUNER (BAND) button and the DISC
SKIP button, press the ON/STAND-BY button until "TUNER CL"
appears.
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-17
ENGLISH
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Tape Playback
Listening to a cassette tape (TAPE 1 or TAPE 2)
Before playback:
Playback is possible in the TAPE 1 compartment as well as the TAPE
2 compartment.
To stop playback:
Press the button.
Fast forward/rewind: (TAPE 2 only)
Caution:
z
To remove the cassette, press the button, and then open the
compartment.
z
Before changing from one tape operation to another, press the
button.
z If a power failure occurs during tape operation, the tape head will
remain engaged with the tape and the cassette door will not open.
In this case, wait until the power is restored.
z Even if the button on the remote control is pressed during tape
playback, the unit will not enter the pause mode.
z
For playback, use normal or low-noise tapes for
the best sound. (Metal or CrO tapes are not rec-
ommended.)
z
Do not use C-120 tapes or poor-quality tapes, as
they may cause malfunctions.
z
Before loading a tape into the cassette compartment,
tighten the slack with a pen or a pencil.
1 Press the ON/STAND-BY button to turn the power on.
2 Open the cassette door by pushing the area marked "PUSH
EJECT ".
3 Load a cassette into the TAPE 1
compartment or TAPE 2 compart-
ment with the side to be played
facing toward you.
4 Press the TAPE (1 2) button to select the cassette you
want to listen to.
5 Press the / button to start playback.
1 Press the button, then press the TAPE (1 2) button to select
TAPE 2.
2 To advance the tape, press the button. To rewind it, press
the button.
TAPE 1
TAPE 2
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-18
ENGLISH
8
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Tape Recording
Recording to a cassette tape
Before recording:
z
When recording important selections, make a preliminary test to
ensure that the desired material is properly recorded.
z
SHARP is not liable for damage or loss of your recording arising
from malfunction of this unit.
z
The volume and sound controls can be adjusted with no effect on
the recorded signal (Variable Sound Monitor).
z
For recording, use only normal tapes. Do not use metal or
CrO tapes.
z
Recording can be operated in the TAPE 2 compartment only. The
TAPE 1 compartment is for playback only.
Recording from a CD (CDs)
You can record 3 CDs continuously.
Erase-prevention tab of cassette tapes:
z
When recording on a cassette tape,
make sure that the erase-prevention
tabs are not removed. Cassettes have
removable tabs that prevent accidental
recording or erasing.
z
To protect the recorded sound, remove
the tab after recording. Cover the tab
hole with adhesive tape to record on the
tape without the tab.
1 Press the ON/STAND-BY button to turn the power on.
2 Load a cassette into the TAPE 2 cassette compartment
with the side to be recorded on facing you.
Wind past the leader of the tape, on which recording cannot be
performed.
3 Press the CD button and load the desired disc.
4 Press one of the 1 - 3 buttons on the remote control to
select the disc to be recorded first.
5 Press the REC PAUSE (TAPE-2
) button.
Recording will be paused.
6 Press the / button to start recording.
z
CD playback will start approximately 5 seconds after the
tape starts.
z
Recording is started from the selected CD. When the play-
back of the last disc is finished or the end of the tape is
reached, the CD and the cassette will stop automatically.
Side A
Tab for
side B
Tab for
side A
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-19
ENGLISH
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Tape Recording
Recording to a cassette tape (continued)
To perform programmed recording:
To interrupt recording:
Press the REC PAUSE (TAPE-2 ) button.
z
Recording is paused, but CD playback will continue.
To resume recording, press the / button.
To stop recording:
Press the button.
The CD and tape will stop.
Note:
Whilst recording, OPEN/CLOSE button is deactivated. It is recom-
mended to perform CD recording after closing the disc tray.
Recording from the radio
To interrupt recording:
Press the REC PAUSE (TAPE-2 ) button.
To resume recording, press the / button.
To stop recording:
Press the button.
Note:
If you hear a whistling noise whilst recording an AM station, move the
AM loop aerial.
1 Programme discs and tracks. (See page 14.)
2 Press the REC PAUSE (TAPE-2 ) button.
3 Press the / button.
1 Tune in to the desired station. (See page 15.)
2 Load a cassette into the TAPE 2 cassette compartment
with the side to be recorded on facing you.
Wind past the leader of the tape, on which recording cannot be
performed.
3 Press the REC PAUSE (TAPE-2
) button.
Recording will be paused.
4 Press the / button to start recording.
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-20
ENGLISH
8
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Tape Recording
Dubbing from tape to tape
You can record from TAPE 1 to TAPE 2.
To stop dubbing:
Press the button.
TAPE 1 and TAPE 2 will simultaneously stop.
Erasing recorded tapes
Note:
Make sure that the TAPE 1 is not in use.
1 Press the ON/STAND-BY button to turn the power on.
2 Load a prerecorded cassette
into the TAPE 1 cassette com-
partment. Insert a blank tape
into the TAPE 2 cassette com-
partment.
It is recommended that the recording tape is the same length as
the master tape.
3 Press the TAPE (1 2) button until "TAPE 1" appears on
the display.
4 Press the REC PAUSE (TAPE-2
) button.
Recording will be paused.
5 Press the / button to start dubbing.
1 Load the tape to be erased into the TAPE 2 cassette compart-
ment with the side to be erased facing toward you.
2 Press the TAPE (1 2) button until "TAPE 2" appears on the dis-
play.
3 Press the REC PAUSE (TAPE-2 ) button.
4 Press the / button to start erasing.
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-21
ENGLISH
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Advanced Features
Timer and sleep operation
Timer playback:
The unit turns on and plays the desired source (CD, tuner, tape) at
the preset time.
Timer recording:
The unit turns on and starts recording from the tuner at the preset
time.
Sleep operation:
The radio, compact disc and cassette tape can all be turned off au-
tomatically.
Timer playback or timer recording
Before setting timer:
1 Press the CLOCK button to check that the clock is set to the
correct time. (Refer to page 10.)
2 For timer playback: Load a cassette or discs to be played.
For timer recording: Load a cassette for recording in the TAPE
2 cassette compartment.
1 Press the ON/STAND-BY button to turn the power on.
2 Press the CD, TUNER (BAND) or TAPE (1 2) button to se-
lect the desired function.
To select the timer playback source: CD, TUNER (BAND) or
TAPE.
To select the timer recording source: TUNER (BAND).
When you select the TUNER (BAND), tune into the desired
station.
3 Adjust the volume using the VOLUME buttons.
Do not turn the volume up too high.
4 Press the TIMER/SLEEP button repeatedly to select timer
playback or timer recording and within 8 seconds, press
the MEMORY/SET button.
Display the white " " for timer playback and the red " " for
timer recording.
White Red
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-22
ENGLISH
8
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Advanced Features
To reset or change the timer setting:
Perform "Timer playback or timer recording" from the beginning.
Note:
When performing timer playback or recording using another unit con-
nected to the VIDEO/AUX IN sockets, select "VIDEO/AUX" in step 2.
At this time, only this unit will be turned on or enter the power stand-
by mode automatically. It will enter the power stand-by mode 1 hour
after the playback or recording starts. However, the other unit will
not be turned on or off.
5 Within 30 seconds, press the TUNING/TIME ( or ) button
to specify the hour to start, then press the MEMORY/SET
button.
The illustrations show the timer playback setting.
6 Within 30 seconds, press the TUNING/TIME ( or ) button
to specify the minute to start, then press the MEMORY/SET
button.
z Settings are displayed in order and the unit will enter the tim-
er stand-by mode.
z
Timer set indicator will light up.
To cancel the timer playback/timer recording:
Press the ON/STAND-BY button to turn the power on.
7 When the preset time is reached, playback or recording will
start.
The volume will increase gradually until it reaches the volume
you were listening to before your system entered the timer
stand-by mode.
8 The unit will enter the stand-by mode one hour after the
timer playback or recording starts.
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-23
ENGLISH
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Advanced Features
Timer and sleep operation (continued)
Sleep operation
To cancel the sleep operation:
Press the ON/STAND-BY button whilst the sleep timer is set.
To confirm the remaining sleep time:
Press the TIMER/SLEEP button whilst the sleep timer is set.
The remaining sleep time is displayed for about 8 seconds.
To use timer and sleep operation together
Example: To fall asleep and wake up to the same radio station
You can play back the same source only (the function cannot be
switched).
Caution:
When using the cassette deck, be sure the tape length is long
enough to perform both functions. If you want to sleep and wake up
listening to a tape, and the length of the tape is shorter than the sleep
timer setting, timer playback will not be possible.
1 Play back the desired sound source.
2 Press the TIMER/SLEEP button repeatedly until "SLEEP" is
displayed and then within 8 seconds, press the MEMORY/
SET button.
To change the sleep time:
Whilst the sleep time is displayed, press the TUNING/TIME (
or ) button.
(Maximum: 3 hours - Minimum: 5 minutes)
3 Within 30 seconds, press the MEMORY/SET button.
4 Your system will enter the power stand-by mode automat-
ically after the preset time has elapsed.
The volume will turn down 30 seconds before the sleep opera-
tion finishes.
3:00 2:00 1:30 1:00
0:10
0:15 0:300:05(cancel)
1 Set the sleep time (see left, steps 1 - 3).
2 Whilst the sleep timer is set, set the desired playback time
(steps 4 - 6, pages 21 - 22).
Sleep timer setting Timer playback setting
Sleep operation will
automatically stop.
Timer playback
start time
5 minutes - 3 hours
4
TINSZA004SJZZ
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-24
ENGLISH
8
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
Advanced Features
Enhancing your system
The connection lead is not included. Purchase a commercially avail-
able lead as shown below.
Listening to the playback sounds from VCR,
DVD, etc.
Note:
To prevent noise interference, place the unit away from the televi-
sion.
To record on a tape
Headphones
z
Before plugging in or unplugging the headphones, reduce the vol-
ume.
z
Be sure your headphones have a 3.5 mm (1/8") diameter plug and
are between 16 ohms and 50 ohms impedance. The recommend-
ed impedance is 32 ohms.
z
Plugging in the headphones disconnects the speakers automati-
cally. Adjust the volume using the VOLUME buttons.
VCR, DVD, etc.
To the line
output sockets
Red
RCA lead
(not supplied)
White
Red White
1 Use a connection lead to connect the VCR, DVD, etc. to the
VIDEO/AUX IN sockets.
When using video equipment, connect the audio output to this
unit and the video output to a television.
2 Press the ON/STAND-BY button to turn the power on.
3 Press the VIDEO/AUX button.
4 Play the connected equipment.
1 Insert a cassette in the TAPE 2 cassette compartment.
2 Press the VIDEO/AUX button.
3 Press the REC PAUSE (TAPE-2 ) button.
4 Press the / button.
5 Play the VCR, DVD, etc.
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-25
ENGLISH
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
References
Troubleshooting chart
Many potential problems can be resolved by the owner without call-
ing a service technician.
If something is wrong with this product, check the following before
calling your authorised SHARP dealer or service centre.
General
CD player
Tuner
Cassette deck
Symptom Possible cause
z
The clock is not set to the
correct time.
z
Did a power failure occur? Reset
the clock. (Refer to page 10.)
z
When a button is pressed,
the unit does not respond.
z
Set the unit to the power stand-
by mode and then turn it back on.
z
If the unit still malfunctions, reset
it. (Refer to page 26.)
z
No sound is heard.
z
Is the volume level set to "0"?
z Are the headphones connected?
z
Are the speaker wires discon-
nected?
Symptom Possible cause
z
Playback does not start.
z
Is the disc loaded upside down?
z
Playback stops in the mid-
dle or is not performed
properly.
z
Does the disc satisfy the stan-
dards?
z
Is the disc distorted or
scratched?
z Playback sounds are
skipped, or stopped in the
middle of a track.
z Is the unit located near excessive
vibrations?
z Is the disc very dirty?
z Has condensation formed inside
the unit?
Symptom Possible cause
z
The radio makes unusual
noises continuously.
z
Is the unit placed near the TV or
computer?
z
Is the FM aerial or AM loop aerial
placed properly? Move the aerial
away from the AC power lead if
it's located nearby.
Symptom Possible cause
z
Cannot record.
z
Is the erase-prevention tab re-
moved?
z
Cannot record tracks with
proper sound quality.
z
Is it a normal tape? (You cannot
record on a metal or CrO tape.)
z
Cannot erase completely.
z
Sound skipping.
z
Is there slack in the tape?
z
Is the tape stretched?
z
Cannot hear treble.
z
Are the capstans, pinch rollers,
or heads dirty?
z Sound fluctuation.
z Cannot remove the tape. z If a power failure occurs during
playback, the heads remain en-
gaged with the tape. Do not open
the compartment with great
force.
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-26
ENGLISH
8
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
References
Remote control
If trouble occurs
When this product is subjected to strong external interference (me-
chanical shock, excessive static electricity, abnormal supply voltage
due to lightning, etc.) or if it is operated incorrectly, it may malfunc-
tion.
If such a problem occurs, do the following:
1 Set the unit to the stand-by mode and turn the power on again.
2 If the unit is not restored in the previous operation, unplug and
plug in the unit, and then turn the power on.
Note:
If neither operation above restores the unit, clear all the memory by
resetting it.
Clearing all the memory (reset)
1 Press the ON/STAND-BY button to enter the power stand-by
mode.
2 Whilst pressing down the CLOCK button and the DISC SKIP but-
ton, press the ON/STAND-BY button until "CLEAR" appears.
Caution:
This operation will erase all data stored in memory including clock,
timer settings, tuner preset, and CD programme.
Condensation
Sudden temperature changes, storage or operation in an extremely
humid environment may cause condensation inside the cabinet (CD
pickup, tape heads, etc.) or on the transmitter on the remote control.
Condensation can cause the unit to malfunction. If this happens,
leave the power on with no disc (or cassette) in the unit until normal
playback is possible (about 1 hour). Wipe off any condensation on
the transmitter with a soft cloth before operating the unit.
Before transporting the unit
Symptom Possible cause
z
The remote control does
not operate.
z
Is the AC power lead of the unit
plugged in?
z
Is the battery polarity correct?
z
Are the batteries dead?
z
Is the distance or angle incor-
rect?
z
Does the remote control sensor
receive strong light?
1 Press the ON/STAND-BY button to turn the power on.
2 Press the CD button.
3 Press the OPEN/CLOSE button to open the disc tray.
Remove all CDs inserted in the unit.
4 Press the OPEN/CLOSE button to close the disc tray.
Make sure that "NO DISC" is displayed.
5 Press the ON/STAND-BY button to enter the stand-by mode,
and then unplug the AC power lead from the wall socket.
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-27
ENGLISH
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
References
Maintenance
Cleaning the tape-handling parts
z
Dirty heads, capstans or pinch rollers can cause poor sound and
tape jams. Clean these parts with a cotton swab moistened with
commercial head/pinch roller cleaner or isopropyl alcohol.
z
When cleaning the heads, pinch rollers, etc., unplug the unit which
contains high voltages.
z
After long use, the deck's heads and capstans may become mag-
netised, causing poor sound. Demagnetise these parts once ev-
ery 30 hours of playing/recording time by using a commercial tape
head demagnetiser. Read the demagnetiser's instructions care-
fully before use.
Cleaning the cabinet
Periodically wipe the cabinet with a soft cloth and a diluted soap so-
lution, then with a dry cloth.
Caution:
z
Do not use chemicals for cleaning (petrol, paint thinner, etc.). It
may damage the cabinet finish.
z
Do not apply oil to the inside of the unit. It may cause malfunc-
tions.
Specifications
As part of our policy of continuous improvement, SHARP reserves
the right to make design and specification changes for product im-
provement without prior notice. The performance specification fig-
ures indicated are nominal values of production units. There may be
some deviations from these values in individual units.
General
Amplifier
Playback head Erase head
Capstan Recording/Playback head
Pinch roller
TAPE 1
TAPE 2
B
C
A
D
B
C
E
Power source AC 230 V, 50 Hz
Power
consumption
34 W
Dimensions Width: 270 mm (10-5/8")
Height: 305 mm (12")
Depth: 342 mm (13-1/2")
Weight 5.5 kg (12.1 lbs.)
Output power PMPO: 60 W
MPO: 30 W (15 W + 15 W) (DIN 45 324)
RMS: 20 W (10 W + 10 W) (DIN 45 324)
RMS: 14 W (7 W + 7 W) (DIN 45 500)
Output terminals Speakers: 8 ohms
Headphones: 16 - 50 ohms (recommended:
32 ohms)
Input terminals Video/Auxiliary (audio signal): 500 mV/47 k
ohms
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
E-28
ENGLISH
8
CD-ES111H
03/10/29 CD-ES111H(H)E.fm
TINSZA004SJZZ
References
CD player
Tuner
Cassette deck
Speaker
Type 3-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency range FM: 87.5 - 108 MHz
AM: 522 - 1,620 kHz
Frequency
response
125 - 8,000 Hz (normal tape)
Signal/noise ratio 50 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Wow and flutter 0.5 % (DIN 45 511)
Type Full range speaker system
10 cm (4") woofer
Maximum input
power
20 W
Rated input power 10 W
Impedance 8 ohms
Dimensions Width: 200 mm (7-7/8")
Height: 305 mm (12")
Depth: 175 mm (6-7/8")
Weight 2.5 kg (5.5 lbs.)/each
Downloaded from www.ManualsFile.com manuals search engine
Downloaded From DvDPlayer-Manual.com Sharp Manuals
Downloaded from www.ManualsFile.com manuals search engine
