Refrigerator
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
Free Standing Appliance
DA68-02954H (EN)-03-���.indd 1 2018. 2. 1. �� 3:48
English - 2
Safety information
SAFETY INFORMATION
• Before operating the
appliance, please read this
manual thoroughly and retain
it for your reference.
• Use this appliance only for
its intended purpose as
described in this instruction
manual.
This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory
or mental capabilities, or
lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved.
Children shall not play with
the appliance.
Cleaning and user
maintenance shall not be
made by children without
supervision.
• Warnings and Important
Safety Instructions in this
manual do not cover all
Contents
SAFETY INFORMATION ……………………………………………………………… 2
SETTING UP YOUR FRENCH DOOR REFRIGERATOR ………………………… 17
OPERATING YOUR FRENCH DOOR REFRIGERATOR ………………………… 25
TROUBLESHOOTING ………………………………………………………………… 41
DA68-02954H (EN)-03-���.indd 2 2018. 2. 1. �� 3:48
English - 3
SAFETY INFORMATION
possible conditions and
situations that may occur.
It is your responsibility to use
common sense, caution,
and care when installing,
maintaining, and operating
your appliance.
• Because these following
operating instructions
cover various models, the
characteristics of your
refrigerator may differ slightly
from those described in this
manual.
And not all warning signs
may be applicable.
If you have any questions
or concerns, contact your
nearest service center or find
help and information online
at www.samsung.com.
• It is hazardous for anyone
other than an Authorized
Service Person to service
this appliance. In Queensland
– the authorized Service
Person MUST hold a Gas
Work Authorisation or
Licence for hydrocarbon
refrigerants, to carry out
Servicing or repairs which
involve the removal of
covers. (For Australia only)
Important safety symbols
and precautions:
WARNING
Hazards or unsafe
practices that may result
in severe personal
injury or death.
CAUTION
Hazards or unsafe
practices that may
result in minor personal
injury or property
damage.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions
carefully.
Unplug the power plug
from the wall socket.
Make sure the machine
is grounded to prevent
electric shock.
Call the contact center
for help.
Note.
DA68-02954H (EN)-03-���.indd 3 2018. 2. 1. �� 3:48
English - 4
These warning signs are here
to prevent injury to you and
others.
Please follow them explicitly.
After reading this section,
keep it in a safe place for
future reference.
SEVERE WARNING
SIGNS FOR
TRANSPORTATION
AND SITE
• When transporting
and installing the
appliance,care should be
taken to ensure that no
parts of the refrigerating
circuit are damaged.
• R-600a or R-134a is used as
a refrigerant.
Check the compressor label
on the rear of the appliance
or the rating label inside the
refrigerator to see which
refrigerant is used for your
refrigerator.
• When this product contains
flammable gas (Refrigerant
R-600a), contact your local
authority in regard to safe
disposal of this product.
WARNING
- When transporting and
installing the appliance,
care should be taken to
ensure that no parts of
the refrigerating circuit are
damaged.
SEVERE WARNING
SIGNS FOR
INSTALLATION
• Do not install this
appliance in a humid,
oily or dusty location, in
a location exposed to
direct sunlight and water
(rain drops).
- Deteriorated insulation of
electrical parts may cause an
electric shock or fire.
• Do not install this appliance
near a heater, inflammable
material.
• Do not plug several
appliances into the same
multiple power board.
The refrigerator should
always be plugged into its
own individual electrical
outlet which has a voltage
rating that matched the
rating plate.
WARNING
DA68-02954H (EN)-03-���.indd 4 2018. 2. 1. �� 3:48
English - 5
SAFETY INFORMATION
- This provides the best
performance and also
prevents overloading house
wiring circuits, which could
cause a fire hazard from
overheated wires.
- There is a risk of electric
shock or fire.
• Do not use a cord that
shows cracks or abrasion
damage along its length or at
either end.
• Do not pull or excessively
bend the power cord.
• Do not twist or tie the power
cord.
• Do not hook the power cord
over a metal object, place a
heavy object on the power
cord, insert the power cord
between objects, or push the
power cord into the space
behind the appliance.
• Do not store explosive
substances such as aerosol
cans with a flammable
propellant in this appliance.
• Do not install this appliance
in a location where gas may
leak.
- This may result in an electric
shock or fire.
• The installation or any
service of this appliance
is recommended by a
qualified technician or
service company.
- Failing to do so may result
in an electric shock, fire,
explosion, problems with the
product, or injury.
• This refrigerator must be
properly installed and located
in accordance with the
manual before it is used.
• Do not install the refrigerator
in a damp place or place
where it may come in
contact with water.
- Deteriorated insulation of
electrical parts may cause an
electric shock or fire.
• Connect the power plug in
proper position with the cord
hanging down.
- If you connect the power
plug upside down, wire can
get cut off and a cause fire or
an electric shock.
• Do not use a cord that
shows cracks or abrasion
damage along its length or at
either end.
• Make sure that the power plug
is not squashed or damaged
by the back of the refrigerator.
DA68-02954H (EN)-03-���.indd 5 2018. 2. 1. �� 3:48
English - 6
• When moving the refrigerator,
be careful not to roll over or
damage the power cord.
- This may result in an electric
shock or fire.
• This appliance should be
positioned in such a way that
it is accessible to the power
plug.
- Failing to do so may result in
an electric shock or fire due
to electric leakage.
• Keep the packing materials
out of reach of children.
- There is a risk of death from
suffocation if children put
them on their head.
• This appliance must be
properly grounded.
• Do not ground the appliance
to a gas pipe, plastic water
pipe, or telephone line.
- You must ground the
refrigerator to prevent any
power leakages or electric
shocks caused by current
leakage from the refrigerator.
- This may result in an electric
shock, fire, explosion, or
problems with the product.
• Never plug the power cord
into a socket that is not
grounded correctly and make
sure that it is in accordance
with local and national
codes.
• If the supply cord is
damaged, it must
be replaced by the
manufacturer, its service
agent or similarly
qualified persons in order
to avoid a hazard.
• The fuse on refrigerator
must be changed by a
qualified technician or service
company.
- Failing to do so may result
in electric shock or personal
injury.
CAUTION SIGNS FOR
INSTALLATION
• Keep ventilation
opening in the appliance
enclosure or mounting
structure clear of
obstruction.
• Allow the appliance to stand
for 2 hours before loading
foods after installation and
turning on.
CAUTION
DA68-02954H (EN)-03-���.indd 6 2018. 2. 1. �� 3:48
English - 7
SAFETY INFORMATION
SEVERE WARNING
SIGNS FOR USING
• Do not touch the power
plug with wet hands.
- This may result in an electric
shock.
• Do not store articles on the
top of the appliance.
- When you open or close the
door, the articles may fall and
cause a personal injury and/
or material damage.
• Do not put items filled with
water on the refrigerator.
- If spilled, there is a risk of fire
or electric shock.
• Do not let children hang on
the door.
If not, a serious injury may
occur.
- Risk of children entrapment.
Do not let children enter
inside the refrigerator.
• Do not leave the doors of
the refrigerator open while
the refrigerator is unattended
and do not let children enter
inside the refrigerator.
• Do not allow babies or
children go inside the drawer.
- It can cause death from
suffocation by entrapment or
personal injury.
WARNING
• Do not sit on the Freezer
door.
- The door may be broken and
cause a personal injury.
• To prevent children
entrapment, you must
reinstall the divider using
provided screws after
cleaning or other actions if
you removed the divider from
the drawer.
• Never put fingers or other
objects into the dispenser
hole, ice chute and ice maker
bucket.
- It may cause a personal
injury or material damage.
- Failure to do so may cause
personal injury or material
damage.
• Do not store volatile or
flammable substances such
as benzene, thinner, alcohol,
ether or LP gas in the
refrigerator.
- The storage of any of such
products may cause an
explosion.
• Do not store low
temperature-sensitive
pharmaceutical products,
scientific materials or other
low temperature-sensitive
products in the refrigerator.
DA68-02954H (EN)-03-���.indd 7 2018. 2. 1. �� 3:48
English - 8
- Products that require
strict temperature controls
must not be stored in the
refrigerator.
• Do not place or use electrical
appliance inside the
refrigerator, unless they are of
a type recommended by the
manufacturer.
• Do not use a hair dryer to dry
the inside of the refrigerator.
Do not place a lighted
candle in the refrigerator for
removing bad odors.
- This may result in an electric
shock or fire.
• Do not touch the inside walls
of the freezer or products
stored in the freezer with wet
hands.
- This may cause frostbite.
• Do not use me chanical
devices or any other means
to accelerate the defrosting
process, other than those
recommended by the
manufacturer.
• Do not damage the
refrigerant circuit.
•
This product is intended
only for the storage of food
in a domestic environment.
• Bottles should be stored tightly
together so that they do not fall
out.
• In the event of a gas leak (such
as propane gas, LP gas, etc.),
ventilate immediately without
touching the power plug.
Do not touch the appliance or
power cord.
- Do not use a ventilating fan.
- A spark may result in an
explosion or fire.
• Use only the LED Lamps
provided by manufacturer or
service agent.
• Children should be supervised
to ensure that they do not play
with the appliance.
- Keep fingers out of “pinch point”
areas; clearances between
the doors and cabinet are
necessarily small.
Be careful when you open the
doors when children are in the
area.
• Do not let children hang on the
door.
If not, a serious injury may occur.
• Risk of children entrapment.
Do not let children enter inside
the refrigerator.
• Do not attempt to repair,
disassemble, or modify
the appliance yourself.
DA68-02954H (EN)-03-���.indd 8 2018. 2. 1. �� 3:48
English - 9
SAFETY INFORMATION
- Do not use any fuse (such as
cooper, steel wire, etc.) other
than the standard fuse.
- When repairing or reinstalling
the appliance is required,
contact your nearest service
center.
- Failing to do so may result
in an electric shock, fire,
problems with the product,
or injury.
• If the appliance generates
a strange noise, a burning
or smell or smoke,
unplug the power plug
immediately and contact
your nearest service
center.
- Failing to do so may result in
an electric or fire hazards.
• Pull the power plug out of
the socket before changing
the interior lamps of the
refrigerator
- Otherwise, there is a risk of
electric shock.
• If you experience difficulty
when changing the light,
contact service agent.
• If the products is equipped
with the LED Lamp, do not
disassemble the Lamp Cover
and LED Lamp by yourself.
- Please contact your service
agent.
• If any dust or water is in the
refrigerator, pull out power
plug and contact your
Samsung Electronics service
center.
- There is a risk of fire.
• Plug the power plug into the
wall socket firmly.
Do not use a damaged power
plug, damaged power cord or
loose wall socket.
- This may result in an electric
shock or fire.
• Do not stand on top of the
appliance or place objects
(such as laundry, lighted
candles, lighted cigarettes,
dishes, chemicals, metal
objects, etc.) on the appliance.
- This may result in an electric
shock, fire, problems with the
product, or injury.
• Do not put a container filled
with water on the appliance.
- If spilled, there is a risk of fire
or electric shock.
• Never stare directly at the UV
LED lamp for long periods of
time.
- This may result in eye strain
due to the ultraviolet rays.
DA68-02954H (EN)-03-���.indd 9 2018. 2. 1. �� 3:48
English - 10
CAUTION SIGNS FOR
USING
• To get best performance
from the product,
- Do not place foods too
closely in front of the vents
at the rear of the appliance
as it can obstruct free air
circulation in the refrigerator
compartment.
- Wrap the food up properly or
place it in airtight containers
before putting it into the
refrigerator.
- Do not put any newly
introduced food for freezing
near to already existing food.
• Do not place carbonated
or fizzy drinks in the freezer
compartment.
Do not put bottles or glass
containers in the freezer.
- When the contents freeze,
the glass may break and
cause personal injury and
property damage.
• Do not change or modify
the functionality of the
refrigerator.
- Changes or modifications
may result in a personal injury
and/or property damage.
Any changes or modifications
CAUTION
performed by a 3rd party on
this completed appliance
are neither covered under
Samsung warranty service,
nor is Samsung responsible
for safety issues and
damages that result from 3rd
party modifications.
• Do not block air holes.
- If the air holes are blocked,
especially with a plastic bag,
the refrigerator can be over
cooled.
If this cooling period lasts
too long, the water filter
may break and cause water
leakage.
• Please observe maximum
storage times and expiry
dates of frozen goods.
• Fill the water tank, ice tray,
water cubes only with
potable water.
• Use only the ice-maker
provided with the refrigerator.
• The water supply to this
refrigerator must only be
connected to a potable water
supply only.
• In order to operate the
ice-maker properly, water
pressure of 138 ~ 862kPa
(1.4 ~ 8.8kgf/cm³) is
required.
DA68-02954H (EN)-03-���.indd 10 2018. 2. 1. �� 3:48
English - 11
SAFETY INFORMATION
• If you have a long vacation
or business trip and won’t
use water or ice dispensers,
close the water valve.
- Otherwise, water leakage
may occur.
• Wipe excess moisture from
the inside and leave the
doors open.
- Otherwise, odor and mold
may develop.
• Do not spray volatile material
such as insecticide onto the
surface of the appliance.
- As well as being harmful to
humans, it may also result
in an electric shock, fire or
problems with the product.
• Do not apply strong shock
or excessive force onto the
surface of glass.
- Broken glass may result
in a personal injury and/or
property damage.
• Do not keep vegetable oil in
your refrigerator’s door bins.
The oil can solidify, making
it foul-tasting and difficult to
use. In addition, the open
container can leak and the
leaked oil can cause the door
bin to crack. After opening
an oil container, it is best to
keep the container in a cool
and shaded place such as a
cupboard or pantry.
- Examples of vegetable oil:
olive oil, corn oil, grape-seed
oil, etc.
CAUTION SIGNS
FOR CLEANING AND
MAINTENANCE
•
Do not clean the appliance
by spraying water directly
onto it.
• Do not use benzene, thinner or
alcohol to clean the appliance.
- This may result in
discoloration, deformation,
damage, electric shock or fire.
• Do not use or place any
substances sensitive
to temperature such
as inflammable sprays,
inflammable objects, dry ice,
medicine, or chemicals near the
refrigerator.
Do not keep volatile or
inflammable objects or
substances (benzene, thinner,
propane gas, etc.) in the
refrigerator.
- This refrigerator is for storing
food only.
CAUTION
DA68-02954H (EN)-03-���.indd 11 2018. 2. 1. �� 3:48
English - 12
• This may result in a fire or an
explosion.
• Do not spray cleaning products
directly on the display.
- Printed letters on the display
may come off.
• If any foreign substance such
as water has entered the
appliance, unplug the power
plug and contact your nearest
service center.
- Failing to do so may result in an
electric shock or fire.
• Remove all foreign substances
such as dust or water from
the power plug terminals and
contact points using a dry cloth
on a regular basis.
- Unplug the power plug and
clean it with a dry cloth.
- Failing to do so may result in an
electric shock or fire.
• Never put fingers or other
objects into the dispenser hole
and ice chute.
- It may cause a personal injury or
material damage.
• Before cleaning or
performing maintenance,
unplug the appliance from
the wall socket.
- Failing to do so may result in an
electric shock or fire.
• Use a clean sponge or soft cloth
and a mild detergent in warm
water to clean the refrigerator.
• Do not use abrasive or harsh
cleansers such as window
sprays, scouring cleansers,
flammable fluids, muriatic acid,
cleaning waxes, concentrated
detergents, bleaches, or
cleansers containing petroleum
products on exterior surfaces
(doors and cabinet), plastic
parts, door and interior liners,
and gaskets.
- These can scratch or damage
the material.
• Do not clean glass shelves or
covers with warm water when
they are cold. Glass shelves and
covers may break if exposed to
sudden temperature changes
or impacts such as bumping or
dropping.
DA68-02954H (EN)-03-���.indd 12 2018. 2. 1. �� 3:48
English - 13
SAFETY INFORMATION
SEVERE WARNING
SIGNS FOR
DISPOSAL
• Ensure that none of the
pipes on the back of the
appliance are damaged
prior to disposal.
• R-600a or R-134a is used as
a refrigerant.
Check the compressor label
on the rear of the appliance
or the rating label inside the
refrigerator to see which
refrigerant is used for your
refrigerator.
When this product contains
flammable gas (Refrigerant
R-600a), contact your local
authority in regard to safe
disposal of this product.
Cyclopentane is used as an
insulation blowing gas.
The gases in insulation
material require special
disposal procedure.
Please contact your local
authorities in regard to the
environmentally safe disposal
of this product.
Ensure that none of the
pipes on the back of the
appliances are damaged
prior to disposal.
The pipes shall be broken in
WARNING
the open space.
• When disposing of this or
other refrigerator/s, remove
the door/door seals, door
latch so that children or
animals cannot become
trapped inside.
Leave the shelves in place so
that children may not easily
climb inside.
• Children should be
supervised to ensure that
they do not enter and play
with the appliance.
- If trapped inside, the child
may become injury and
suffocate to death.
• Please dispose of the
packaging material for this
product in an environmentally
friendly manner.
DA68-02954H (EN)-03-���.indd 13 2018. 2. 1. �� 3:48
English - 14
ADDITIONAL TIPS
FOR PROPER USAGE
• In the event of a power failure,
call the local office of your
Electricity Company and ask
how long it is going to last.
- Most power failures that are
corrected within an hour or two
will not affect your refrigerator
temperatures.
However, you should minimize
the number of door openings
while the power is off.
- Should the power failure last
more than 24 hours, remove all
frozen food.
• The appliance might not
operate consistently (possibility
of temperature becoming too
warm in the refrigerator) when
sited for an extended period of
time below the cold end of the
range of temperature for which
the refrigerating appliance is
designed.
• In case of particular foods,
keeping it under refrigeration
can have a bad effect on
preservation due to its
properties.
• Your appliance is frost free,
which means there is no need to
manually defrost your appliance,
as this will be carried out
automatically.
• Temperature rise during
defrosting can comply with ISO
requirements.
But if you want to prevent an
undue rise in the temperature of
the frozen food while defrosting
the appliance, please wrap the
frozen food up in several layers
of newspaper.
Saving Energy Tips
- Install the appliance in a
cool, dry room with adequate
ventilation.
Ensure that it is not exposed
to direct sunlight and never put
it near a direct source of heat
(radiator, for example).
- Not to block any vents and
grilles is recommended for
energy efficiency.
- Allow warm food to cool
down before placing it in the
appliance.
- Put frozen food in the
refrigerator to thaw.
You can then use the low
temperatures of the frozen
products to cool food in the
refrigerator.
DA68-02954H (EN)-03-���.indd 14 2018. 2. 1. �� 3:48
English - 15
SAFETY INFORMATION
- Do not keep the door of the
appliance open for too long
when putting food in or taking
food out.
The shorter time for which the
door is open, the less ice will
form in the freezer.
- Clean the rear of the refrigerator
regularly.
Dust increases energy
consumption.
- Do not set temperature colder
than necessary.
- Ensure sufficient air exhaust at
the refrigerator base and at the
back wall of the refrigerator.
Do not cover air vent openings.
- It is recommended to install the
refrigerator with clearance to the
back and sides.
This will help reduce power
consumption and keep your
energy bills lower.
- For the most efficient use of
energy, please keep the all
inner fittings such as baskets,
drawers, shelves on the position
supplied by manufacturer.
This appliance is intended
to be used in household and
similar applications such as
- staff kitchen areas in shops,
offices and other working
environments;
- farm houses and by
clients in hotels, motels
and other residential type
environments;
- bed and breakfast type
environments;
- catering and similar non-retail
applications.
DA68-02954H (EN)-03-���.indd 15 2018. 2. 1. �� 3:48
English - 16
GETTING READY TO INSTALL
THE REFRIGERATOR
Congratulations on your purchase of this Samsung
French Door Refrigerator.
We hope you enjoy the state-of-art features and
efficiencies that this new appliance offers.
Selecting the best location for the
refrigerator
Choose:
• A location with easy access to a water supply.
• A location without direct exposure to sunlight.
• A location with level (or nearly level) flooring.
• A location with enough space for the
refrigerator doors to open easily.
• A location that allows sufficient space to the
right, left, back, and top for air circulation.
If the refrigerator does not have enough space,
it can cause the bad influence to refrigeration
effi ciency and power consumption.
• A location that allows you to move the
refrigerator easily if it needs maintenance or
service.
• Do not install the refrigerator in locations where
the temperature is over 110°F (43°C) or below
50°F (10°C ).
AA
B
B
C
C
D
D
E
E
Depth “A” 726mm
Width “B” 908mm
Height “C” 1749mm
Overall Height “D” 1777mm
Depth “E” 788mm
1578mm
335mm
125° 125°
50mm
908mm
610mm
122mm
61mm
1125mm
1088mm
• Each measurement based on the design
dimension, so it may differ depending on
the measuring method.
Setting up your French Door
Refrigerator
DA68-02954H (EN)-03-���.indd 16 2018. 2. 1. �� 3:48
English - 17
SETTING UP
When moving your refrigerator
To prevent floor damage, be sure the front
adjusting legs are in the up position (above
the floor).
Refer to “Leveling the Refrigerator” on
page 20.
Flat-blade screw
driver (-)
Control Lever
Flooring
For proper installation, you must place this
refrigerator on a level, hard surface that is the
same height as the rest of the floor.
This surface should be strong enough to support a
fully loaded refrigerator.
To protect the finish of the flooring, cut a large
section of the cardboard carton and place it under
the refrigerator where you are working.
When moving the refrigerator, you need to pull and
push it straight forwards or back.
Do not wiggle it from side to side.
CAUTION
REMOVING THE REFRIGERATOR
DOORS
For some installations, you need to remove the
fridge and freezer drawers so you can move the
refrigerator to its final location.
Do not remove the doors/drawer if you don’t need
to.
If you do not need to remove the refrigerator
doors, go to “Leveling the Refrigerator” on page
20.
If you need to remove the doors. continue below.
Before removing the door/drawer, make sure you
read the following items:
Disconnect power to the refrigerator
before removing the door or drawer.
• Be careful not to drop, damage or
scratch the door / drawer while removing
them.
• Be careful not to injure yourself while removing
the doors / drawer.
• Reattach the door/drawer properly to avoid:
- Moisture from air leakage.
- Uneven door alignment.
- Wasting energy due to improper door seal.
Disassembling the refrigerator doors
Be careful not to drop and scratch the
doors while removing them.
WARNING
WARNING
DA68-02954H (EN)-03-���.indd 17 2018. 2. 1. �� 3:48
English - 18
Required Tools (Not provided)
You need the following tools to complete the
installation of your refrigerator:
Philips
screwdriver (+)
Flat-blade screw
driver (-)
Socket wrench
(13/32”) (10mm)
Pliers
Allen wrench
(3/16”) (5mm)
With the door opened
1. Remove 3 screws holding down the TOP
TABLE (1) and separate the connected wires.
(1)
2. Disconnect two connectors (2) on the left side
door.
To remove the water coupler from the hinge,
twist and pull it from the hinge.
Remove the water line (3) while pressing the
marked part (4) of the water line coupler.
(2)
(3)
(4)
3. Pull and remove the hinge lever (5).
Remove the ground screw (6) attached to the
upper left door hinges with a philips screwdriver
(+). Remove the upper left and right door
hinges (7).
(5)
(7)
(6)
4. Lift the door straight up to remove.
5. Remove the screw (8) attached to the
lower left and right door hinges with a philips
screwdriver (+).
Remove the 2 hex head bolts (9) attached to
the lower left and right door hinges with an allen
wrench (3/16”).
Remove the lower left and right door hinges
(10).
Allen wrench
(10)
(8)
(9)
DA68-02954H (EN)-03-���.indd 18 2018. 2. 1. �� 3:48
English - 19
SETTING UP
REATTACHING THE
REFRIGERATOR DOORS
To reattach the fridge doors after you have moved
the fridge to its final location, assemble the parts in
reverse order.
1. The Water Line must be fully inserted into the
center of the transparent coupler (Type A) or the
Guide Lines (Type B) to prevent water leakage
from the dispenser.
Center of Transparent
coupler
The Guide Lines
Dispenser
Type A Type B
DISASSEMBLE THE FREEZER
DRAWER
1. Take out the upper drawer by lifting it up.
2. Remove the freeze room guard (1) by lifting
the guard up.
(1)
3. Take out the lower basket (2) by lifting the
basket up from the rail system.
(2)
You can scratch the side of the bin if you
twist it left or right when disassembling or
re-assembling it.
4. Press the fixing hook of the rail system.
5. Holding the top of the Freezer Drawer, pull it
out all the way, and then remove it from the rail
system.
Be careful not to scratch or dent the
sliding rail by letting it strike the floor.
Make sure that you mount the freezer
basket in the right position when removing
/ installing the freezer door.
Failing to do so may result in the door not
opening or closing properly.
CAUTION
CAUTION
CAUTION
DA68-02954H (EN)-03-���.indd 19 2018. 2. 1. �� 3:48
English - 20
Putting too much food into the freezer
drawers can prevent the freezer from
closing completely and can cause frost
build-up.
RE-ASSEMBLE THE FREEZER
DRAWER
To reattach the drawer after you have moved the
fridge to its final location, assemble the parts in
reverse order.
CAUTION
LEVELING THE REFRIGERATOR
Make sure the refrigerator is level so that you can
make final adjustments.
Use a level to test if the refrigerator is level both
side to side and back to front.
If the refrigerator is not level, you will not be able
to get the doors perfectly even, which may cause
moisture condensation and increased energy bills.
Below is an example of how to level the refrigerator
if the left side of the refrigerator is lower than the
right side.
How to adjust the level
1. Open the freezer drawer and remove the lower
basket.
2. Insert a flat-blade screwdriver (-) into a notch on
the left control lever, and then turn it counter-
clockwise to level the refrigerator.
(You turn the lever clockwise to lower the
refrigerator and counterclockwise to raise it.)
flat-blade
screwdriver (-)
Control Lever
Both control levers must be touching the
floor to avoid possible personal injury or
property damage because of tipping.
If the right side is lower, perform the same
procedure, but with the right control lever.
It is difficult to remove the cover leg
front from the refrigerator, so we do not
recommend making small adjustments
with the control lever.
Instead, refer to the next page for the best
way to make minor adjustments to the
doors.
CAUTION
DA68-02954H (EN)-03-���.indd 20 2018. 2. 1. �� 3:48
English - 21
SETTING UP
MAKING MINOR ADJUSTMENTS
BETWEEN DOORS
Remember, a leveled refrigerator is necessary for
getting the doors perfectly even.
If you need help, review the previous section on
leveling the refrigerator.
Adjustment part
Fixed part
The left door is fixed.
To make minor adjustments between
doors, adjust only the right door.
1. Pull out the freezer drawer (1) to reveal the
lower hinge (2).
2. Insert a philips screwdriver (+) (3) into the shaft
(4) of the lower hinge.
3. Adjust the height by turning a philips
screwdriver (+) (3) clockwise (
DOWN
) or
counterclockwise (
UP
).
(3)
(1)
(3)
(2)
(4)
When you turn a philips screwdriver (+)
counterclockwise ( ), the door will
move up.
INSTALLING THE WATER
DISPENSER LINE
A water dispenser with a filter is one of the helpful
features on your new refrigerator.
To help promote better health, the water filter
removes unwanted particles from your water.
However, it does not sterilize or destroy
microorganisms.
You may need to purchase a water purifying
system to do that.
In order for the ice maker to operate properly, a
water pressure of 138 ~ 862kPa is required.
Under normal conditions, a 170cc (5.75oz.) cup
can be filled in about 10 seconds.
If the refrigerator is installed in an area with low
water pressure (below 138kPa), you can install a
booster pump to compensate for the low pressure.
After you have connected the water line, make
sure the water storage tank inside the refrigerator
is properly filled.
To do this, press the water dispenser lever until the
water runs from the water outlet.
Water line installation kits are include with
unit. You can find it in freezer drawer.
The new hose-sets supplied with the
appliance are to be used and that old
hose-sets should not be reused.
Parts for water line Installation
Water line fixer and screws Pipe connector
Water line
DA68-02954H (EN)-03-���.indd 21 2018. 2. 1. �� 3:48
English - 22
Connecting to the water supply line
1. First, shut off the main water supply line.
2. Locate the nearest cold, drinking water line.
3. Follow the Water line Installation Instructions in
the installation kit.
CAUTION
The water line must be connected to the
cold water pipe.
If it is connected to the hot water pipe, it
may cause the purifier to malfunction.
Close Main Water
pipe
Close Main
Water pipe
No gap
4. After connecting the water supply to the water
filter, turn your main water supply back on and
dispense about 3L to clear and prime the
water filter.
Connecting the water line to the
refrigerator
1. Remove the cap from the water line on the unit
and insert the compression nut of the water line
into the water line on the unit.
2. Connect the water line on the unit with the
water line in the kit.
3. Tighten the compression nut onto the
compression fitting.
There should be no gaps between (A, B & C).
4. Turn water on and check for any leakage.
Only connect the water line to a drinkable
water source.
If you have to repair or disassemble the
water line, cut off 6.5mm of the plastic
tubing to make sure you get a snug, leak-
free connection.
No gap
Loosen a
Remove cap
Water Line from
Kit
Water Line from
unit
Before being used, the leakage in these
places should be examined.
• Samsung Warranty does not cover WATER
LINE INSTALLATION.
• It will be done at customer’s charge unless the
retail price includes installation cost.
• Please contact Plumber or Authorized Installer
for the installation if needed.
• If Water leakage occurs due to improper
installation, Please contact installer.
CAUTION
DA68-02954H (EN)-03-���.indd 22 2018. 2. 1. �� 3:48
English - 23
SETTING UP
COMPLETING THE SET UP
Now that you have your new refrigerator installed
in place, you are ready to set up and enjoy the
features and functions of the appliance.
By completing the following steps, your refrigerator
should be fully operational.
1. Make sure your refrigerator is in an appropriate
location with reasonable clearance between it
and the wall. Refer to installation instructions in
this manual.
2. Once the refrigerator is plugged in, make sure
the interior light comes on when you open the
doors.
3. Set the Temperature control to the coldest
temperature and wait for an hour.
The freezer will get slightly chilled and the motor
will run smoothly.
Reset the refrigerator and freezer to the
temperatures you want.
4. After you plug the refrigerator in, it will
take a few hours to reach the appropriate
temperature.
You can store food and drinks in the refrigerator
after the temperature is sufficiently cool.
If condensation or water drops appear
on both sides of the fridge door’s central
part, turn the Energy Saver mode off after
removing the condensation.
(See the explanation of the Energy Saver
button in “Using the control panel” on
page 25.)
DA68-02954H (EN)-03-���.indd 23 2018. 2. 1. �� 3:48
English - 24
Operating your French Door
Refrigerator
USING THE CONTROL PANEL
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
( 1 ) Freezer / Power Freeze (3sec)
The Freezer button serves two purposes:
- To set the Freezer to your desired
temperature.
- To turn the Power Freeze function on
and off.
1. To set the Freezer temperature, touch
the Freezer button.
You can set the temperature between
5°F (-15°C) and -8°F (-23°C).
2. Power Freeze function
Touch and hold this button for 3 seconds
to decrease the time needed to freeze
products in the Freezer.
It can be helpful if you need to quickly
freeze easily spoiled items or if the
temperature in the freezer has warmed
dramatically.
(For example, if the door was left open.)
When you use this function, the energy
consumption of the refrigerator will
increase. Remember to turn it off when
you don’t need it and return the freezer to
your original temperature setting.
This icon will light up when you activate
the Power Freeze function. Power Freeze
function generates cool air for 72 hours
continuously and it makes the inside of
the refrigerator cool faster.
When you have enough, just press and
hold the Freeze (Hold 3 sec for Power
Freeze) button again for 3 seconds to
cancel the Power Freeze function.
( 2 ) Alarm / Filter Reset (3sec)
The Alarm button serves two purposes:
- To turn the door open alarm on and off
- To reset the water filter life indicator.
1. Door Alarm Function
If the door alarm is set to On, an alarm
beeps if any refrigerator door is left open
for more than three minutes.
The beeping stops when you close the
door. The door alarm function is pre-set
to On in the factory.
You can turn it off by pressing and then
releasing the Alarm button.
You can turn it back on in the same
fashion.
The icon lights up when the function is
on. When the Door Alarm function is on
and the alarm sound is triggered, the
Door Alarm Icon will blink while the alarm
sounds.
2. Water Filter Life Indicator Function
After you replace the water filter, touch
and hold this button for 3 seconds to
reset the water filter life indicator.
When you reset the water filter life
indicator, the Filter icon on the panel turns
Off. The Filter icon will turn red to let you
know it is time to change the water filter
after six months (about 300 gallons).
Some areas have large amounts of lime
in their water, which causes the water
filter to clog more quickly. If this is the
case in your area, you will have to change
the filter more frequently than every six
months.
DA68-02954H (EN)-03-���.indd 24 2018. 2. 1. �� 3:48
English - 25
OPERATING
( 3 ) Energy Saver
Touching this button turns Energy Saver
mode on and off.
When you turn Energy Saver on, the
Energy Saver icon lights.
Turn Energy Saver off and the icon goes
off.
The Energy Saver function automatically
turns on when power is supplied to the
refrigerator.
If condensation or water drops appear on
the doors, turn the Energy Saver mode
off.
( 4 ) Fridge / Power Cool (3sec)
The Fridge button serves two purposes:
- To set the Fridge to your desired
temperature.
- To turn the Power Cool function on
and off.
1. To set the Fridge temperature, press
the Fridge button.
You can set the temperature between
44°F (7°C) and 34°F (1°C).
2. Power Cool function
Touch and hold this button for 3 seconds
to decrease the time needed to cool
products in the Refrigerator.
It can be helpful if you need to quickly
cool easily spoiled items or if the
temperature in the fridge has warmed
dramatically.
(for example, if the door was left open)
( 5 )
Lighting / °C↔°F (3sec)
The Lighting button serves two purposes:
- To turn the dispenser light on and off
- To switch the temperature units
between ºC and ºF.
1. Light Function
Touching the Lighting button turns on the
Dispenser LED lamp in continuous mode
so that it stays on continuously.
The button also lights up.
If you want the Dispenser lamp to
come on only when some one uses the
dispenser, press the Lighting button to
turn the continuous mode off.
2. To switch the temperature units
between ºC and ºF.
Touch and hold this button for 3 seconds
to select the temperature display you
want.
Each time you press and hold the button,
the ºC and ºF temperature modes
alternate and the ºC or ºF icon lights up,
indicating your selection.
( 6 ) Ice Maker Off
If you don’t want to make more ice, touch
the Ice Maker Off button.
The icon will light up and the Ice-Maker
stops making ice.
We recommend you to stop ice making
if the following occur:
- There is enough ice in the ice bucket.
- You want to save water and energy.
- Water is not being supplied to the
refrigerator.
If the ice maker function is ON, and the
water Line is not connected, there will be
a water valve noise from the back of the
unit.
Press the Ice Maker Off (Control Lock
(3sec)) button for less than 3 seconds
until the Ice Off Indicator ( ) illuminates.
DA68-02954H (EN)-03-���.indd 25 2018. 2. 1. �� 3:48
English - 26
( 7 ) Water
Touch this button to dispense water.
This mode can not be used with the Ice
Type mode simultaneously.
Water mode shuts off when you touch the
Cubed / Crushed Ice button.
To save electricity, the Panel Display turns off
automatically under the following conditions:
When no button has been pressed, when no
doors are open, or when no Dispenser Lever
has been pushed.
However, the icon indicating your cubed or
crushed ice selection, will stay on.
When you press a button, open a door, or push
a Dispenser Lever, the Panel Display will turn
on again.
Except for the Energy Saver, Water, and Cubed
/ Crushed Ice buttons, all function buttons
will become operational after you remove
your finger from the button you are currently
pressing.
( 8 ) Filter
Water filter usage
This icon lights up when you need
to change the filter, usually after the
refrigerator has dispensed about 300
gallons of water (after about 6 months).
The icon will blink red for several seconds
when you open or close the door.
After you install the new water filter, reset
the filter indicator by touching and holding
the Hold 3sec for Filter Reset button for
3seconds.
- If water is not dispensing or
dispensing slowly, you need to replace
the water filter because the water filter
is clogged.
- Some areas have large amounts of
lime in their water, which causes the
water filter to clog more quickly.
( 9 ) Ice Type
Touch this button to select your desired
ice type.
Cubed and crushed ice modes alternate
when you press the button.
This mode can not be used with the
Water mode simultaneously.
(10)
Ice Maker Off /
Control Lock (3sec)
The Ice Maker Off button serves two
purposes:
- To turn the Ice maker on and off
- To turn the Control Lock Function on
and off.
1. Ice Off Function
If you don’t want to make more ice, press
the Ice Maker Off button.
2. Control Lock Function
Touch and hold this button for 3 seconds
to lock the display and the dispenser
buttons so the buttons can not be used.
When Control Lock is on, the refrigerator
does not dispense ice or water, even if
the Dispenser Lever is pressed.
The Control Lock icon lights up to
indicate you’ve activated the Control Lock
function. Press 3 seconds to unlock.
Cooling Off Mode
Cooling Off mode (also called Shop
mode), is designed for use by retailers
when they are displaying refrigerators on
the shop floor.
In Cooling Off mode, the refrigerator’s
fan motor and lights work normally, but
the compressors do not run, and the
refrigerator and freezer do not get cold.
To start Cooling Off mode, touch and hold
the Freezer, Fridge and Alarm buttons for
5seconds during normal operation.
The refrigerator chime sounds and the
temperature display flashes OFF.
To cancel Cooling Off mode, touch
and hold the Freezer, Fridge and Alarm
buttons again for 5seconds.
DA68-02954H (EN)-03-���.indd 26 2018. 2. 1. �� 3:48
English - 27
OPERATING
CHANGING THE WATER FILTER
To reduce risk of water damage to your
property DO NOT use generic brands
of water filters in your SAMSUNG
Refrigerator.
USE ONLY SAMSUNG BRAND
WATER FILTERS. SAMSUNG is not
legally responsible for any damage,
including, but not limited to, property
damage caused by water leakage
from the use of a generic water filter.
(Red)
SAMSUNG Refrigerators are designed to work
ONLY WITH SAMSUNG Water Filters.
The Filter light turns red to let you know when it is
time to change your water filter cartridge.
To give you time to get a new filter, the red light
comes on just before the capacity of the current
filter runs out.
Changing the filter on time provides you with the
freshest, cleanest water from your refrigerator.
1. Shut off the water supply. Then, turn the water
filter (1) about 1/4 turn, counter-clockwise.
2. Pull the water filter (1) from the case filter (2).
(2)
(1)
• To change the water filter more easily,
shut off the water supply valve.
• Sometimes, it is hard to disassemble the water
filter because impurities in the water cause it to
stick. If you are having difficulties, grip the water
filter firmly and pull it hard.
• When you pull the water filter, a little water
can leak from the opening. This is normal.
To minimize the water leaks, keep the filter
cartridge horizontal when you pull it.
• To prevent overflow, empty the water filter tray
(3) and dry around the filter case (2).
WARNING
(2)
(3)
3. Insert the new filter into the filter case (4).
(4)
4. Push the filter, and then turn it clockwise until
it locks.
• If you have trouble inserting the water
filter because of high water pressure,
shut off the water supply valve.
• The locked symbol should be lined up with the
indicator line.
5. Touch and hold the “Alarm / hold 3 sec for
Filter Reset” button (
(Filter Reset)
) for about
3seconds to reset the water filter indicator.
The indicator’s red light will turn off.
6. If you turned off the water supply, turn it back
on.
For a replacement water filter, visit your
local home Improvement center or visit
Samsung’s parts distributor on line at:
http://www.samsungparts.com
Be sure the replacement water filter has
the SAMSUNG logo on the box and on the
water filter.
DA68-02954H (EN)-03-���.indd 27 2018. 2. 1. �� 3:48
English - 28
Removing any residual matter inside the
water supply line after installing the water
filter.
1. Turn ON the the water supply if you turned it off
when you installed the water filter.
2. Run water through the dispenser until the water
runs clear (approx. 6 to 7 minutes).
This will clean the water supply system and
remove air from the lines.
3. Additional flushing may be required in some
households.
4. Open the Refrigerator door and make sure
there are no water leaks coming from the water
filter.
Be sure to flush the dispenser thoroughly,
otherwise water may drip from the
dispenser.
This means that there is still air in the line.
Reverse Osmosis Water Supply
IMPORTANT:
The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet
valve of the refrigerator needs to be between 35
and 120psi. (241 and 827kPa)
If a reverse osmosis water filtration system is
connected to your cold water supply, the water
pressure to the reverse osmosis system needs to
be a minimum of 40 to 60psi. (276 to 414kPa)
If the water pressure to the reverse osmosis
system is less than 40 to 60psi (276 to 414kPa):
• Check if the sediment filter in the reverse
osmosis system is blocked.
Replace the filter if necessary.
• Allow the storage tank on the reverse osmosis
system to refill after heavy usage.
• If your refrigerator has a water filter, it may
further reduce the water pressure when used
in conjunction with a reverse osmosis system.
Remove the water filter.
If you have questions about your water pressure,
call a licensed, qualified plumber.
DA68-02954H (EN)-03-���.indd 28 2018. 2. 1. �� 3:48
English - 29
OPERATING
CONTROLLING THE
TEMPERATURE
Basic temperature of Freezer and
fridge compartments
The basic and recommended temperatures of the
Freezer and Fridge compartments are 0°F and
37°F (or -18°C and 3°C) respectively.
If the temperature of the Freezer and Fridge
compartments are too high or low, adjust the
temperature manually.
Controlling the Freezer temperature
Recommend Temp (Freezer) : 0°F (or -18°C )
The Freezer temperature can be set between -8°F
and 5°F (or between -23°C and -15°C) to suit
your particular needs.
Press the Freezer button repeatedly until the
desired temperature is shown in the temperature
display.
The temperature will change by 1°F (or 1°C) with
each press. See below.
Fahrenheit : 0°F ➞ -1°F ➞ -2°F ➞ -3°F ➞ -4°F
➞ -5°F ➞ -6°F ➞ -7°F ➞ -8°F ➞ 5°F ➞ 4°F ➞
3°F ➞ 2°F ➞ 1°F ➞ 0°F.
Centigrade : -18°C ➞ -19°C ➞ -20°C ➞ -21°C
➞ -22°C ➞ -23°C ➞ -15°C ➞ -16°C ➞ -17°C
➞ -18°C.
Keep in mind that foods such as ice cream may/
melt at 4°F (or -15.5°C).
The temperature display will move sequentially
from -8°F to 5°F (or from -23°C to -15°C).
Controlling the fridge temperature
Recommend Temp (Fridge) : 37°F (or 3°C )
The fridge temperature can be set between 34°F
and 44°F (or between 1°C and 7°C) to suit your
particular needs.
Press the Fridge button repeatedly until the desired
temperature is shown in the temperature display.
The temperature will change by 1°F (or 1°C) with
each press. See below.
Fahrenheit : 37°F ➞ 36°F ➞ 35°F ➞ 34°F ➞
44°F ➞ 43°F ➞ 42°F ➞ 41°F ➞ 40°F ➞ 39°F
➞ 38°F ➞37°F.
Centigrade : 3°C ➞ 2°C ➞ 1°C ➞ 7°C ➞ 6°C
➞ 5°C ➞ 4°C ➞ 3°C.
The temperature control process for the Fridge
works just like the Freezer process.
Press the Fridge button to set your desired
temperature.
After a few seconds, the Fridge will begin adjusting
towards the newly set temperature.
This will be reflected in the digital display.
DA68-02954H (EN)-03-���.indd 29 2018. 2. 1. �� 3:48
English - 30
• The temperature of the Freezer or Fridge
may rise when you open the doors too
frequently, or if a large amount of warm
or hot food is placed inside.
• A rise in temperature may cause the digital
display to blink.
Once the Freezer and Fridge temperature return
to their normal set temperatures, the blinking
will stop.
• If the blinking continues, you may need to
“reset” the Refrigerator.
Try unplugging the appliance, wait for around
10 minutes and then plug the power cord back
in.
• If there is a communication error between the
Display and Main Controller, the Convertible
Display light may blink.
If the blinking continues for a long period of
time, please contact a Samsung Electronics
Service Center.
USING THE COLD WATER
DISPENSER
Push the appropriate ice type button to
select what you want dispensed.
NO ICE
Select this if you want
to turn ice maker off
Using the ice Dispenser
Place a glass underneath the ice
dispenser and push gently against
the dispenser lever with your glass.
Make sure the glass is in line with
the dispenser to prevent the ice
from bouncing out.
• To select water, press the water button on the
display, and then press the dispenser lever.
• To select Ice, press the ICE type button of
your choice on the display, and then press the
dispenser lever.
• If you have selected cubed ice, when you press
the lever, the dispenser may dispense a small
amount of crushed ice first.
• If ice doesn’t come out, pull out the ice bucket
and press the test button located on the right
side of ice maker.
Check the water level
Test button
• Do not press the test button continuously when
the tray is filled with ice or water.
Water may overflow or ice may jam the bucket.
• When you press the Test button, you will hear
the refrigerator chime (ding-dong).
When the chime sounds, release the Test
button.
• The chime sounds automatically again to let
you know the ice maker is working well.
• Replace the ice bucket.
DA68-02954H (EN)-03-���.indd 30 2018. 2. 1. �� 3:48
English - 31
OPERATING
Ice Making
To fill the ice bucket to maximum capacity after
installation, follow these steps:
1. Allow your refrigerator to operate and cool
down for 24 hours (or 1 full day).
- Waiting 24 hours will allow your ice maker to
cool properly.
2. Dispense 4 to 6 ice cubes into a glass.
3. After 8, and then 16 hours, dispense a full glass
of ice.
• To clean the ice bin/bucket, wash with a
mild detergent, rinse well, and then dry it
thoroughly.
Do not use harsh or abrasive cleaners or
solvents.
• When you select Cubed Ice after using the
Crushed Ice mode, a small amount of residual
crushed ice might be produced.
If There is a Power Failure
If a power failure occurs, ice cubes may melt,
and then freeze together when the power comes
back on, preventing the dispenser from working
properly.
To prevent this problem, after a power failure, pull
out the ice bucket and discard the residual ice or
water.
After you dump the ice from the ice bucket, you
should press the dispenser lever once with the
‘Water’ or ‘Ice Type’ function ON.
The ice maker will make new ice faster after you
return the ice bucket to the refrigerator.
CAUTION
If you use all the ice at once, you must
repeat Steps 2 and 3 under Ice Making.
However, only wait 8 hours before
dispensing the first 4 to 6 ice cubes.
This will replenish the ice cubes and
ensure maximum ice production.
Using the ice off Function
When you select the Ice Off mode, remove all ice
cubes from the bucket.
If you leave the ice cubes in the bucket, the ice
cubes may clump together, making it difficult to
remove them.
To remove the ice bucket safely and avoid injury,
hold the bottom of the bucket with one hand and
the side of the bucket with the other.
Then, lift up on the ice bucket, and pull it straight
out.
To put the ice bucket back in, push it firmly straight
back.
If the ice bucket is not pushed firmly into
place, ice in the bucket can melt.
If the bucket does not fit, turn the helix 90 degree
(see the last illustration on the right, below) and try
again.
• Use only the ice maker provided with the
refrigerator.
The water supply to this refrigerator must
only be installed/connected by a suitably
qualified person.
Connect to a potable water supply only.
• To operate the ice maker properly, water
pressure of 20 ~ 125psi is required.
CAUTION
DA68-02954H (EN)-03-���.indd 31 2018. 2. 1. �� 3:48
English - 32
Going on vacation...
If you are going on a long vacation or business trip
and won’t use the water or ice dispensers for a
long time:
• Close the water valve.
Otherwise, water leakage may occur.
• Remove all food and ice in the ice bucket.
• Unplug the refrigerator.
• Wipe excess moisture from inside and leave
the doors open. Otherwise, odor and mold may
develop.
Ice Maker Do’s and Don’ts
• Do not put your fingers, hands or any other
unsuitable objects in the chute or ice-maker
bucket.
- It may result in personal injury or material
damage.
• Never put your finger or any other objects in the
dispenser opening.
- It may cause injury.
• Do not try to disassemble the ice maker.
• Do not wash or spray the ice bucket with water
while it is in the refrigerator.
Remove it to clean it.
When you insert the Ice maker tray, be
sure that the tray is well centered at the
entrance.
Otherwise, the tray may get stuck.
CAUTION
Water clouding phenomenon
All water provided to the refrigerator flows
through the core filter which is an alkaline
water filter.
In the filtering process, the pressure of
the water that has flowed out of the filter
is increased, and the water becomes
saturated with oxygen and nitrogen.
When this water flows out into the air, the
pressure plummets and the oxygen and
nitrogen get supersaturated, which results
in gas bubbles.
The water may temporarily look misty or
cloudy due to these oxygen bubbles.
After a few seconds, the water will look
clear.
Please wait 1 second before removing
the cup after dispensing water to prevent
spills.
Do not pull out the lever dispenser after
dispensing ice or water.
It comes back automatically.
Ice is made in cubes.
When you select “Crushed”, the ice maker
grinds the ice cubes into crushed ice.
DA68-02954H (EN)-03-���.indd 32 2018. 2. 1. �� 3:48
English - 33
OPERATING
PARTS AND FEATURES
Review the illustration below to become more familiar with the parts and features of your refrigerator.
Light
FF Ice-Maker
Foldable-Shelf
Fixed Shelf
Vertical Hinged
Section
Vegetable & Fruit
Drawers
Light
FZ Ice-Maker
(applicable models only)
Ice Bucket
Guard
Door Closer
Slide Shelf
Quick-Space Glass
Shelf
(on some models)
Door Bins
Cool Select
Pantry
PLUS
Auto Pull Out
Drawer
Freezer Drawer Bin
When closing the door, make sure the Vertical Hinged Section is in the correct position to avoid
scratching the other door.
If the Vertical Hinged Section is reversed, put it back to the right position and close the door.
Moisture may appear at times on the Vertical Hinged Section.
The door handle may become loose over time.
If this happens, tighten the bolts found on the inside of the door.
If you close one door with too much force, the other door may open.
When the door opens, the interlock switch automatically turns off the auger motor in the ice
maker for safety reasons.
When the interior or exterior LED lamp has gone out, please contact Samsung Customer
Support.
DA68-02954H (EN)-03-���.indd 33 2018. 2. 1. �� 3:48
English - 34
USING THE COOL SELECT
PANTRY™
The Cool Select Pantry™ is a full-width drawer
with adjustable temperature control.
This pantry can be used for large party trays, deli
items, pizza, beverages, or miscellaneous items.
There is a temperature control which can adjust
the amount of cold air allowed into the pantry.
The control is located on the right side of the
pantry.
• The Pantry has three modes: The Fresh mode,
Chilled mode, and Deli mode.
Fresh mode is the default.
Press the Temp button repeatedly until the
mode you want is lit.
Once you select a mode, the temperature will
change to match the mode you selected.
• The Pantry temperature may change depending
on the number of items inside and where they
are located, the ambient temperature, and how
often the door is opened.
The Pantry Selection Button
1. When you select “Deli”, the temperature of the
pantry will be kept around 41°F (or 5°C).
This feature helps keep food fresh for a long
time.
2. When you select “Fresh”, the temperature of
the pantry will be kept around 38°F (or 3°C).
This feature helps keep food fresh for a longer
time.
3. When you select “Chilled”, the temperature of
the pantry will be kept around 34°F (or 1°C).
This feature also helps keep meat or fish fresh
for a longer time.
The table below lists the Pantry modes and
the kinds of foods that can be stored safely for
each mode.
Deli Fresh Chilled
• Pineapple • cucumbers • steaks
• lemon • apples
• hard
cheeses
• avocado • oranges • cold cuts
• potato • grapes • bacon
• zucchinis • hot dogs
• corn
Fruits and vegetables may be damaged if
you set the Pantry to the Chilled mode.
Do not store lettuce or other leafy produce
in this pantry.
Do not store glass bottles in the Cool
Select Pantry.
If they are freeze, they can break and
cause personal injury.
CAUTION
DA68-02954H (EN)-03-���.indd 34 2018. 2. 1. �� 3:48
English - 35
OPERATING
REMOVING THE REFRIGERATOR
ACCESSORIES
1. Door Bins
• Door Bins (1)
- To remove : Simply lift the bin up and pull
straight out.
- To relocate : Slide it in above the desired
location and push down until it stops.
• Door Bins (2)
- To remove : Take the right side of the bin out
by lifting it at an angle along the guide, and then
take the left side out by pulling it from the door.
- To relocate : Slide it into the original location
and push down until it sticks.
(1)
(2)
Injury may occur if the door bins are not
firmly assembled.
Do not allow children to play with the bins.
Sharp corners of the bins may cause
injury.
Do not adjust a bin full of food.
Remove the food first.
To remove dust from the bins : Remove
the guard and wash the bin in water.
CAUTION
2. Tempered Glass shelves
- To remove : Tilt up the front of the shelf in the
direction shown (1) and lift it up vertically (2).
Pull the shelf out.
- To relocate : Tilt the front of the shelf up and
guide the shelf hooks into the slots at a desired
height. Then lower the front of the shelf so that
the hooks can drop into the slots.
(1)
(2)
The Tempered Glass shelves are heavy.
Use special care when removing them.
After sliding the foldable shelf in and
folding it, the Shelf Front can be removed
for your convenience.
If you use the self without removing the
Shelf Front, be aware the Shelf Front can
separate from the shelf.
3. Vegetable & Fruit Drawers
• Door Bins
Before removing the drawer, please remove door
bins first as below.
CAUTION
CAUTION
DA68-02954H (EN)-03-���.indd 35 2018. 2. 1. �� 3:49
English - 36
To remove
• Simply lift the bin up and pull straight out.
• Tilt up the front of the drawer and pull straight
out, and pull out the drawer after moving
slightly in the direction of the arrow.
To re-install
• Insert the drawer into the frame rails and push
back into place.
• Slide bin in above the desired location and
push down until it stops.
The drawers need to be removed before
the glass shelf above them can be lifted
out.
CAUTION
4. Cool Select Pantry
PLUS
- To remove the pantry : Pull the pantry out to
full extension. Tilt up the front side of the pantry
and pull straight out.
- To relocate the pantry : Push the rails to the
back of the refrigerator. Place the drawer onto
the rails and slide the pantry back until it is in
place.
- To remove the divider : Pull the pantry
completely out to full extension and raise the
front side of the divider to unhook it from the
rear wall of the pantry, then lift the divider out.
- To relocate the divider : Hook the back of the
divider over the rear wall of the pantry and push
the divider down.
Divider
Using the doors
Ensure that the doors close all the way and are
securely sealed.
When the refrigerator door is only partially open, it
will automatically close.
But, the door will stay open when opened more
than the auto close range and you must close it
manually.
DA68-02954H (EN)-03-���.indd 36 2018. 2. 1. �� 3:49
English - 37
OPERATING
REMOVING THE FREEZER
ACCESSORIES
1. Freezer Room Guard
- To remove : Remove the freezer room guard
(1) by lifting the guard up.
- To relocate : Push down until the guard (1)
locks into place.
(1)
2. Ice Bucket
- To remove : Lift the ice bucket (1).
- To relocate : Place the ice bucket into the
Super extended drawer (2).
(2)
(1)
3. Super Extended Drawer
- To remove : Pull the drawer out to full
extension. Tilt up the rear of the drawer and lift
straight out.
- To relocate : Place the drawer onto the rails
(4) by tilting it up.
Lower the drawer into place until it is horizontal
and slide the drawer (3) in.
(3)
(4)
4. Freezer Drawer
- To remove the freezer drawer : Pull the
freezer drawer out fully. Tilt up the rear of the
bin and lift it out to remove.
- To relocate the freezer drawer : Place the bin
into the rail assembly.
You can scratch the side of the bin if you
twist it left or right when disassembling or
re-assembling it.
Do not allow babies or children to climb
into the freezer drawer.
They could damage the refrigerator and
seriously injure themselves.
Do not sit on the freezer door.
The door may break.
Do not remove the divider.
If trapped inside, children may be injured
or suffocate to death.
CAUTION
CAUTION
CAUTION
WARNING
DA68-02954H (EN)-03-���.indd 37 2018. 2. 1. �� 3:49
English - 38
CLEANING THE REFRIGERATOR
Caring for your Samsung French Door Refrigerator
prolongs the life of your appliance and helps keep
the refrigerator free of odor and germs.
Cleaning the Interior
Clean the inside walls and accessories with a mild
detergent and then wipe dry with a soft cloth.
You can remove the drawers and shelves for a
more thorough cleaning.
Just make sure to dry drawers and shelves before
putting them back into place.
Cleaning the Exterior
Wipe the control panel and digital display with a
damp, clean, soft cloth.
Do not spray water directly on the surface of the
refrigerator.
The doors, handles, and cabinet surfaces should
be cleaned with a mild detergent and then wiped
dry with a soft cloth.
To keep your appliance looking its best, polish the
exterior once or twice a year.
Do not spray water directly on the
refrigerator.
Use a clean, damp cloth to clean.
CAUTION
Do not use benzene, thinner, or Clorox for
cleaning.
They may damage the surface of the
appliance and may cause a fire.
You can erase the printed
letters on the display if you
apply stainless cleaner directly
to the area where the letters
are printed.
Cleaning the Ice / Water Dispenser
Wipe the Ice / Water Dispenser with
a clean and soft cloth.
As you use the dispenser’s crushed ice
selection, some residual ice chips may
start to collect in the ice chute.
To prevent that residual ice from melting
and running out of the chute, you should
clean out the residual ice when you see it
start to collect in the ice chute.
CAUTION
CAUTION
CAUTION
DA68-02954H (EN)-03-���.indd 38 2018. 2. 1. �� 3:49
English - 39
OPERATING
Cleaning the Rubber door seals
If the rubber door seals are dirty, the doors may
not close properly, and the refrigerator will not
operate efficiently.
Keep the door seals free of dust or stains by
cleaning the doors with a mild detergent and damp
cloth.
Wipe dry with a clean, soft cloth.
Do not clean the refrigerator with benzene,
thinner, or car detergent.
These substances could cause a fire.
Cleaning the rear side of the
refrigerator
To keep cords and exposed parts free of dust and
dirt accumulation, vacuum the rear side of the
appliance once or twice a year.
(1)
Do not remove the back cover (1).
You could suffer an electric shock.
CAUTION
CAUTION
DA68-02954H (EN)-03-���.indd 39 2018. 2. 1. �� 3:49
English - 40
Troubleshooting
PROBLEM SOLUTION
The refrigerator
does not work at
all or it does not
chill sufficiently.
• Check if the power plug is properly connected.
• Check if the set temperature on the digital display is warmer than the freezer or fridge
inner temperature. If it is, set the freezer or fridge to a colder temperature.
• Is the refrigerator in direct sunlight or located near a heat source?
If so, it may not be able to cool sufficiently. Install it in a location that is out of direct
sunlight and not near a heat source.
• Is the back of the refrigerator too close to the wall, preventing proper ventilation?
If so, it may not be able to cool sufficiently.
Keep it an appropriate distance from the wall.
• Is there too much food inside so that the food is blocking the outlet vent?
To keep the refrigerator at a suitable temperature, do not fill the refrigerator with too
much food.
The food in the
fridge is frozen.
• Check if the set temperature on the digital display is too low.
If so, raise the set temperature inside the refrigerator.
• Is the temperature in the room too low? Set the refrigerator warmer.
• Did you store food with a high moisture content in the coldest part of the refrigerator
or near the cooling outlet vent?
Try moving those items to the other shelves in the fridge instead of keeping them in
the colder areas or bins.
You hear unusual
noise or sounds.
• Check if the refrigerator is level and stable.
• Is the back of the refrigerator too close to the wall, preventing proper ventilation?
• Was anything dropped behind or under the refrigerator?
• If you hear a “ticking” sound from inside the refrigerator, this is normal.
It occurs because various parts contract or expand in response to temperature
changes in the refrigerator interior.
• If it sounds as if something is hitting something else inside the refrigerator, this is
normal. The sound is caused by the compressor operating at high capacity.
The cabinet-door
sealing area of the
appliance is hot
and condensation
is occurring.
• Some heat is normal as anti-condensators are installed in the vertical hinged section
of the refrigerator to prevent condensation.
• Is the refrigerator door ajar?
Condensation can occur when you leave the door open for a long time.
The ice Maker is
not producing ice.
• It may take longer to make ice if it is not sufficiently cool, such as when first installed.
• Is the water line connected and the shut-off valve opened?
• Did you manually stop the ice making function?
• Check if the filter is properly installed. If it is not properly installed, the ice making
function may not work.
You can hear water
bubbling in the
refrigerator.
• This is normal.
The bubbling comes from refrigerant circulating through the refrigerator.
There is a bad
smell in the
refrigerator.
• Check for spoiled food.
• Foods with strong odors (for example, fish) should be tightly covered.
• Clean out the freezer periodically and throw away any spoiled food.
When cleaning the inside of the fridge, store food elsewhere and unplug the
appliance. Wipe with a dry dishcloth after 2-3 hours and then circulate air inside the
refrigerator.
DA68-02954H (EN)-03-���.indd 40 2018. 2. 1. �� 3:49
English - 41
TROUBLESHOOTING
PROBLEM SOLUTION
Frost forms on
the walls of the
freezer.
• Is the air vent blocked?
Remove any obstructions so air can circulate freely.
• Allow sufficient space between the stored foods for efficient air circulation.
• Is the freezer drawer closed properly?
If the freezer drawer is not completely closed or is blocked, humidity from outside
may enter and cause severe frost to form.
The water
dispenser is not
functioning.
• Is the water line connected and the shut-off valve opened?
• Has the water supply line tubing been crushed or kinked?
• Make sure the tubing is free and clear of any obstruction.
• Is the water tank frozen because the fridge temperature is too low?
Try selecting a warmer setting on the Digital display.
• Is the Child Lock on?
• Check if the filter is properly installed.
If it is not properly installed, the water dispenser may not work.
The auto close
system does not
work with the
freezer door.
• Is there an imbalance between the right and left parts of the door?
• Open and close the door smoothly 1~2 times.
After you do this, the auto close system usually works properly again.
• Try opening the door smoothly to avoid unbalancing the right and the left part of the
door.
Condensation or
water drops forms
on vertical mullion
and surroundings,
etc.
• Condensation or water drops may form if the humidity is too high while the
refrigerator is operating.
• If condensation or water drops appears on vertical mullion and surroundings, etc.,
turn the Energy Saver mode off after removing the condensation.
(See the explanation of the Energy Saver button in “Using the control panel” on page
25.)
DA68-02954H (EN)-03-���.indd 41 2018. 2. 1. �� 3:49
Memo
DA68-02954H (EN)-03-���.indd 42 2018. 2. 1. �� 3:49
Memo
DA68-02954H (EN)-03-���.indd 43 2018. 2. 1. �� 3:49
Ambient Room Temperature Limits
This refrigerator is designed to operate in ambient temperatures specified by its temperature class
marked on the rating plate.
Class Symbol
Ambient Temperature range (°C)
IEC 62552 (ISO 15502) ISO 8561
Extended Temperate SN +10 to +32 +10 to +32
Temperate N +16 to +32 +16 to +32
Subtropical ST +16 to +38 +18 to +38
Tropical T +16 to +43 +18 to +43
Internal temperatures may be affected by such factors as the location of the fridge/freezer,
ambient temperature and the frequency with which you open the door.
Adjust the temperature as required to compensate for these factors.
English
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its
electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other
household waste at the end of their working life. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, please separate these items from other types
of waste and recycle them responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or
their local government ofce, for details of where and how they can take these items for
environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product and its electronic accessories should not be mixed with other
commercial wastes for disposal.
DA68-02954H-03
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG
customer care center.
COUNTRY CALL Web site
AUSTRALIA 1300 362 603 www.samsung.com/au/support
COLOMBIA
Bogotá en el 600 12 72
Sin costo en todo el pais 01 8000 112 112
Y desde tu celular #726
www.samsung.com/co/support
IRELAND (EIRE) 0818 717100 www.samsung.com/ie/support
HONG KONG 3698 4698
www.samsung.com/hk/support (Chinese)
www.samsung.com/hk_en/support (English)
INDIA 1800 40 SAMSUNG (1800 40 7267864) (Toll-Free) www.samsung.com/in/support
MALAYSIA
1800-88-9999
+603-7713 7420 (Overseas contact)
www.samsung.com/my/support
NEW ZEALAND
0800 726 786
0800 6 726 786 (Support for Smart Mobile Devices)
www.samsung.com/nz/support
PANAMA 800-0101
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
PHILIPPINES
1-800-10-726-7864 [ PLDT Toll Free ]
1-800-8-726-7864 [ Globe Landline and Mobile ]
02-422-2111 [ Standard Landline ]
www.samsung.com/ph/support
SINGAPORE 1800-SAMSUNG(726-7864) www.samsung.com/sg/support
SOUTH AFRICA 0860 SAMSUNG (726 7864) www.samsung.com/support
UK 0330 SAMSUNG (7267864) www.samsung.com/uk/support
DA68-02954H (EN)-03-���.indd 44 2018. 2. 1. �� 3:49
