• Image shown may differ from your projector.
• Your projector’s OSD (On Screen Display) may differ slightly from
that shown in this manual.
NOTE
4
SAFETYPRECAUTIONS
SAFETYPRECAUTIONS
Please take note of the safety instructions to prevent any potential accident
or misuse of the projector.
• Safety precautions are given in two forms, i.e., WARNING and CAUTION
as detailed below.
WARNING Failure to follow the instructions may cause serious
injury and even death.
CAUTION Failure to follow the instructions may cause personal
injury or product damage.
• Read the owner's manual carefully and keep it on hand.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with
arrowhead symbol, within
an equilateral triangle, is
intended to alert the user to the
presence of uninsulated dangerous
voltage within the product’s
enclosure that may be of sufcient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point
within an equilateral
triangle is intended to alert
the user to the presence of
important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
WARNING/CAUTION
– TO REDUCE THE RISK
OF FIRE AND ELECTRIC
SHOCK, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR
MOISTURE.
Readtheseinstructions.
Keeptheseinstructions.
Heedallwarnings.
Followallinstructions.
IndoorInstallation
WARNING
• Do not use the projector outside
and do not expose the product
to any humidity or water.
– Since the product is not
waterproof, this may result in
a re or electric shock.
• Do not place the projector in
direct sunlight or near heat
sources such as radiators, res,
stoves, etc.
– This may result in re.
• Do not place flammable
materials such as aerosols near
the projector.
– This may result in re.
• Do not allow children to cling to
or climb up to the projector.
– This may cause the projector
to fall, causing injury or death.
5
SAFETYPRECAUTIONS
• Do not install the product in a
place with no ventilation (e.g.,
on a bookshelf or in a closet) or
on a carpet or cushion.
– This may result in re due
to the increase in internal
temperature.
• Do not place the product close
to sources of steam, oil or oil
mist, such as humidiers and
kitchen counters.
– Failure to do so may result
in re, electric shock, or
corrosion.
• Do not install the product onto
a wall or ceiling that is close to
sources of oil or oil mist.
– The product may be
damaged and fall, resulting in
serious injury.
• Do not place the projector where
it might be exposed to dust.
– This may result in re.
• Do not use the projector in a
damp place such as a bathroom
where it is likely to get wet.
– This may result in re or
electric shock.
• Do not allow a tablecloth or
curtain to block the air vent.
– This may result in re due to
the increase in the internal
temperature.
• Ensure good ventilation around
the projector. The distance
between the projector and the
wall should be at least 30 cm.
– This will prevent re due to
the increase in the internal
temperature.
CAUTION
• When placing the projector on a
table or shelf, be careful not to
put it near the edge.
– The projector could fall due
to balance problems, which
may cause personal injury or
damage to the product. Make
sure to use the projector
cabinet or stand that ts the
projector.
• When moving the projector,
make sure to switch it off and
remove the power plug and
cords.
– The power cord may be
damaged, resulting in re or
electric shock.
• Do not place the projector on
an unstable or vibrating surface
such as a wobbly shelf or a
slope.
– It may fall and cause injury.
• Be careful not to tip the projector
over when connecting external
devices to the projector.
– This may cause personal
injury or damage to the
projector.
6
SAFETYPRECAUTIONS
Power
WARNING
• DISCONNECTING THE
DEVICE FROM THE MAIN
POWER
– The Power plug is the
disconnecting device. In case
of an emergency, the Power
Plug must remain readily
accessible.
• The grounding wire should be
connected.
– Ensure that you connect the
grounding cable to avoid
electric shock. If it is not
possible to ground the unit,
have a qualified electrician
install a separate circuit
breaker.
Do not try to ground the
projector by connecting it to
telephone wires, lightning
rods or gas pipes.
• The power plug should be
inserted fully into the power
outlet.
– An unstable connection may
cause a fire.
• Do not place heavy objects on
the power cord.
– This may result in re or
electric shock.
• Never touch the power plug with
wet hands.
– This may result in electric
shock.
• Do not plug too many devices
into one multi-power outlet.
– This may result in re due to
the power outlet overheating.
• Keep the AC adapter, power
plug, and the used power outlet
clean from dust or foreign
materials building up.
– This may result in re.
• If there is any smoke or a
burning smell from the projector
or AC adapter, stop using the
product immediately. Disconnect
the power cord from the power
outlet, and then contact the
customer service center.
– This may result in re.
• To turn off the main power,
remove the power plug, which
should be positioned so it is
easy to access for operation.
CAUTION
• Always grab the plug to remove
the AC adapter or power cord.
– Otherwise, this may result
in a re or may damage the
product.
• Refrain from constantly bending
the power cord of the AC
adapter.
– If the power cord is bent
excessively for a long period
of time, the cord may break
inside. This may result in a
re or electric shock.
• Ensure the power cord and plug
are not damaged, modied,
severely bent, twisted, pulled,
sandwiched or hot. Do not use
the product if the power outlet
is loose.
– This may result in re or
electric shock.
7
SAFETYPRECAUTIONS
• Keep the power cord away from
heating devices.
– The wire's sheath may melt,
which may result in re or
electric shock.
• Place the projector where
people will not trip over or step
on the power cord to protect the
power cord and plug from any
damage.
– This may result in re or
electric shock.
• Do not turn the projector on or
off by plugging in the power plug
or unplugging it from the power
outlet. (Do not use the power
plug as a switch.)
– This may result in electric
shock or damage to the
product.
• Do not insert a conductor
into the other side of the wall
outlet while the power plug is
inserted into the wall outlet.
In addition, do not touch the
power plug immediately after it
is disconnected from the wall
outlet.
– This may result in electric
shock.
• Only use the official power cord
provided by LG Electronics. Do
not use other power cords.
– This may result in re or
electric shock.
• If any water or foreign materials
have gone into the AC adapter,
power cord, or the interior of the
projector, turn off the projector
by pressing the power button.
Remove all the cables, and then
contact the customer service
center.
– This may result in re or
electric shock.
• The surface of the AC adapter is
hot. Keep the AC adapter out of
the reach of children and avoid
touching it during use.
• Never disassemble the power
supply devices (AC adapter/
power cord, etc.).
– This may damage the power
cord and result in a re or
electric shock.
• Connect the AC adapter and the
power cord firmly.
– Not doing so may result in a
product failure or re.
• Do not place heavy objects
or put pressure on the power
cord and AC adapter and avoid
damage.
– This may result in a re or
may damage the product.
• Always use the AC adapter
provided or any AC adapters
approved and certified by LG
Electronics.
– Any other AC adapter
connected may result in the
screen ickering.
8
SAFETYPRECAUTIONS
WheninUse
WARNING
• Do not place anything containing
liquid on top of the projector
such as a vase, ower pot,
cup, cosmetics, or medicine; or
ornaments, candles, etc.
– This may result in re or
electric shock, or cause injury
due to falling.
• In the event that there is a
heavy impact or the cabinet is
damaged, switch it off, unplug
it from the power outlet and
contact an authorized service
center.
– This may result in electric
shock.
• Do not insert pieces of metal
such as coins, hairpins or metal
debris, nor flammable materials
such as paper or matches into
the projector.
– This is to prevent electric
shock or re.
• Make sure that a child does not
swallow the batteries when you
replace the old remote control
batteries with new ones. Keep
batteries out of reach of children.
– If a child swallows a battery,
consult a doctor immediately.
• Never open any cover on the
projector.
– There is a high risk of electric
shock.
• Do not look directly into the lens
when the projector is in use.
– The bright light may damage
your eyes.
• When the lamp is on or has just
been turned off, avoid touching
the air vent or lamp, because
these will be very hot.
• If there is a gas leak in the
room with the projector, do not
touch the projector or power
outlet. Open the windows for
ventilation.
– Sparks may cause re or burns.
• Unplug the power cord from the
outlet during a lightning storm.
– This will prevent shock or
damage to the projector.
• Do not use the projector near
electronic devices that generate
a strong magnetic eld.
• Do not put the plastic package
used to pack the projector
around your head.
– This may cause suffocation.
• Do not keep your hand on the
projector for a long time when it
is running.
• When you play a game by
connecting a game console to
a projector, it is recommended
that you maintain a distance
of more than four times the
diagonal length of the screen.
– Make sure that the connecting
cable is long enough.
Otherwise, the product may
fall causing personal injury or
damage to the product.
• Do not place the projector or its
remote control with battery in
an extremely high temperature
environment.
– This may result in re.
• Do not use 3D glasses if you do
not watch 3D.
9
SAFETYPRECAUTIONS
CAUTION
• Do not place heavy objects on
the projector.
– It may fall down and cause
personal injury.
• Be careful not to allow any
impact to the lens during
transport.
• Do not touch the lens of the
projector.
– The lens may be damaged.
• Do not use any sharp tools on
the projector such as a knife
or hammer, because this may
damage the casing.
• In the event that no image
appears on the screen or no
sound is heard, stop using
the projector. Switch off the
projector, unplug it from the
power outlet and contact our
service center.
– This may result in re or
electric shock.
• Do not drop anything onto the
projector or allow anything to
bang into the projector.
– This may cause damage
to the projector or personal
injury.
• It is recommended that you
maintain a distance of at least
5-7 times the diagonal length of
the screen.
– If you watch the screen at
a close distance for a long
time, your eye sight may
become worse.
• Do not block the light beam
emitted from the projector using
a book or other object.
– Lengthy exposure to the
projector beam may result in
re. In addition, the lens may be
overheated and damaged by
the reected heat. Disable the
AV function to stop projection
temporarily or turn off the power.
• Do not start the projector with
the volume turned up high.
– High volume may damage
hearing.
• Do not use high voltage electrical
equipment near the projector,
(e.g., a bug zapper.). This may
result in product malfunction.
Cleaning
WARNING
• Do not spray the projector with
water when cleaning. Make sure
water does not flow into the
projector.
– This may result in re or
electric shock.
• When there is smoke or a
strange smell coming out from
the projector or a foreign object
falls into the projector, please
switch it off and unplug it from
the power outlet and contact our
service center.
– Otherwise, this may result in
re or electric shock.
• Use air spray, a soft cloth or
a cotton swab moistened with
a lens cleaning chemical or
alcohol to remove dust or stains
on the front projection lens.
10
SAFETYPRECAUTIONS
CAUTION
• Contact your seller or our service
center once a year to clean the
internal parts of the projector.
– If you do not clean the
projector for a long period of
time, dust will accumulate,
which may result in re or
damage to the projector.
• When cleaning plastic parts such
as the projector case, unplug the
power rst and wipe with a soft
cloth. Do not spray with water
or wipe with a wet cloth. Never
use glass cleaner, automobile or
industrial shiner, abrasives, wax,
benzene, or alcohol as these can
damage the projector.
– This can result in re, electric
shock or cause damage to
the product (deformation and
corrosion).
• Do not wipe the optical system
(lens, mirror) right after the
product has been turned off
or while the product is being
operated. When cleaning each
part of the product, remove the
power cord and wipe gently
with a soft cloth. Do not spray
with water or wipe with a wet
cloth. Do not use detergents,
automobile or industrial polish,
abrasive substances, wax,
benzene, alcohol, water, etc. on
the product's main unit or optical
system (lens, mirror) as this may
damage the product.
– This can result in re, electric
shock or cause damage to
the product (deformation and
corrosion).
• Remove the plug from the outlet
before cleaning the product.
– Otherwise, this may result in
electric shock.
Others
WARNING
• Some users may experience
a seizure or other abnormal
symptoms when they are
exposed to a flashing light or
particular patterns from a video
game.
• When you go out, place the
projector out of reach of
animals, and remove the power
plug from the wall outlet.
– Using a damaged power cord
may result in short circuit
or re.
• Do not use the projector near
highprecision electronic devices
or those that transmit weak
radio signals.
– This may affect the operation
of the product, causing an
accident.
• Only a qualified technician
can disassemble or modify
the projector. For diagnosis,
adjustment, or repair, contact
your seller or our service center.
– This may result in re or
electric shock.
• Do not stare directly into lens
when in operation, eye damage
can occur.
• No user serviceable parts
inside unit. High voltage parts
can cause shock and even
electrocution.
11
SAFETYPRECAUTIONS
• Proper ventilation required, do
not block airow around unit.
Doing so can cause injury and
internal overheating.
• Do not touch the lens; doing so
can result in burns or damage
to lens. Lens and unit may be
HOT during and immediately
after use. Use caution when
handling unit, allowing for proper
cool down.
• Only use a grounded electrical
outlet.
• Do not insert anything into or
cover up the exhaust vents.
– This may result in re or
electric shock.
• Follow all maintenance
guidelines for optimal use;
service only at an authorized
service center.
• Keep the batteries and remote
out of reach of children.
– This will prevent personal
injury or damage to the
product.
CAUTION
• Do not mix new batteries with
old
ones.
– Burst or leaking batteries may
result in damage or injury.
• Be sure to unplug if the projector
is not
to be used for a long
period.
– Accumulated dust may result
in re or electric shock due to
overheating, ignition, or poor
insulation.
• Only use the specified type of
battery.
– Burst or leaking batteries may
result in damage or injury.
• Make sure you use the same
type of battery when replacing.
– In the case of a battery
contact failure, the battery
may drain quickly or the
remote control may not work
properly.
• Dispose of used batteries
properly.
– This may result in explosion
or re. The correct method of
disposal may vary depending
on your country or region.
Dispose of the battery pack
as instructed.
• Do not throw or disassemble the
battery.
– This may result in re or
explosion due to damage to
the battery.
12
SAFETYPRECAUTIONS
• Store batteries away from
metallic objects,
such as keys
and paper clips.
– Excess current may cause a
rapid increase in temperature,
resulting in re or burns.
• Do not store the batteries near
any
heat source, such as a
heater.
– This may result in re or
damage to the product.
• Do not store batteries at
temperatures
higher than 60 °C
(140 °F) or in high humidity.
– This may result in explosion
or re.
• Make sure that the battery is
installed
correctly.
– This prevent explosion or re.
• Incorrect battery replacement
may
cause re.
Antenna
WARNING
• If you are using an outdoor
antenna, please install it away
from electrical wires to make
sure it does not touch any
nearby wires even when it falls
down due to heavy wind.
• Failure to do so may cause
electric shock or physical injury.
CAUTION
• To prevent any water flowing
into the product, install a drip
loop in the outdoor antenna wire
where it comes indoors.
• Raindrops flowing into the
product may cause fire or
electric shock.
Antennagroundingaccording
totheNationalElectricalCode,
ANSI/NFPA70
Antenna Lead in Wire
Grounding Conductor
(NEC Section 810-21)
Antenna Discharge Unit
(NEC Section 810-20)
Power Service
GroundingElectrode
System (NEC Art
250, Part H)
NEC:NationalElectricalCode
Ground Clamp
Electric Service
Equipment
Ground Clamp
13
SAFETYPRECAUTIONS
ForUSA
NOTE TO CABLE/TV INSTALLER
This reminder is provided to
call the CATV system installer’s
attention to Article 820 - 40 of the
National Electric Code (USA).
The code provides guidelines
for proper grounding and, in
particular, species that the cable
ground shall be connected to the
grounding system of the building,
as close to the point of the cable
entry as practical.
RiskGroup2
CAUTION Possibly hazardous
optical radiation emitted from this
product. Do not stare at operating
lamp. May be harmful to the eye.
14
CONTENTS
CONTENTS
LICENSES 2
SAFETYPRECAUTIONS 4
PREPARATION 18
Accessories 18
OptionalExtras 19
PartsandComponents 20
– Main Unit 20
– Side 21
– Back 22
UsingtheJoystickButton 23
– Basic functions 23
– Adjusting the menu 24
ProjectorStatusIndicators 24
Installation 25
– Installation Precautions 25
– Projection Distance per
Screen Size 26
– Kensington Security System
27
MAGICREMOTECONTROL
28
– To Register the Magic
Remote Control 30
– To Re-register the Magic
Remote Control 30
– Using the Magic Remote
Control 31
USINGTHEPROJECTOR32
ConnectingtheAntennaor
Cable 32
WatchingProjector 33
– Initial Setup 33
– Focus of the Screen Image
36
– Watching With the Projector
36
ToSetChannel 37
– To View Program Information
37
– To Set Favorite Channels 37
– To Use Favorite 38
– To Set Auto Tuning 38
– To Set Channels Manually 38
– To Edit Channels 38
AdditionalOptions 39
– To adjust Aspect Ratio 39
– Using the Edge Adj (4 Corner
Keystone) Function 40
– Changing Input Device 41
– To Use SIMPLINK 43
UsingtheQuickMenu 45
ToSetSound 46
– To Set Sound Output 46
– Using the Multi Audio 48
15
CONTENTS
ENTERTAINMENT 49
TouseSmartFeatures 49
– To use Home Screen 49
– To use MY APPS 50
– To edit items in MY APPS 50
ToConnectNetwork 51
– One-click Network
Connection 51
– To Connect to a Network
Through Set Expert 51
– To Use the Wi-Fi Direct
Function 52
– Tips for Network Settings 53
3DFUNCTION 54
WhileWatching3D 54
RequirementsforWatching3D
Images 57
– Using the DLP-LINK (DLP-
Ready) Type Glasses 58
Toview3Dimages 58
– Supported 3D Mode 59
SMARTSHARE 60
BeforeUsing 60
– Connecting a USB Device 60
– Removing a USB Device 60
TouseSmartShare™ 62
– Watching the Videos 63
– Viewing the Photos 65
– Listening to Music 66
– Viewing Files 67
– To Set SmartShare™
Related Functions 68
TouseSCREENSHARE
(Miracast™/Intel’sWiDi
Function) 71
– To Use the Miracast™ /
Intel’s WiDi Function 71
ToUseaPremiumService 73
– To Use Paid Content 74
– To Reset Premium 75
ToUseLGSmartWorld 76
– To Sign Up With LG Smart
World 77
– To Install An App On Your
Projector 77
– To Manage My Information 78
ToUseSearchFunction 79
16
CONTENTS
ToUsetheVoiceRecognition
Function 80
– Using this Function Through
Search 80
– Using this Function on the
Internet 80
ToUseVoiceMateFunction 82
– What Is Voice Mate? 82
– How to Use Voice Mate? 83
– What Are Other Functions of
Voice Mate? 83
SeeAvatar 84
– Using the Avatar 84
WhatIsOnNow? 85
– To Use On Now 85
ToUseInternet 88
FrequentlyAskedQuestions
forProjector 89
USINGADVANCED
FUNCTIONS 94
ToUseScreenRemote 94
– To Use Screen Remote 94
– To Control a Device
Connected to the Projector
Using the Screen Remote 95
ToUsetheUniversalControl
function 95
ToUseaUSBInputDeviceOn
aProjector 97
– To Use a USB Wired/wireless
Mouse 97
– To Use a USB Wired/wireless
Keyboard 97
CUSTOMIZINGSETTINGS
98
SETTINGS 98
PICTURESettings 99
SOUNDSettings 106
CHANNELSettings 109
TIMESettings 110
LOCKSettings 111
OPTIONSettings 115
NETWORKSettings 120
SUPPORT 122
17
CONTENTS
CONNECTINGDEVICES124
ConnectingtoHDReceiver,
DVD,orVCRPlayer,External
Devices 125
– HDMI Connection 125
– HDMI to DVI Connection 126
– AV Connection 126
– Component Connection 127
ConnectingaPC 128
– HDMI Connection 128
– HDMI to DVI Connection 128
ConnectingaLaptop 129
– HDMI Connection 129
ConnectingHeadphones 130
ConnectingaDigitalAmp 131
UsingtheMirroringFunction
ofaMobilePhone 132
– MHL Connection 132
MAINTENANCE 133
Cleaning 133
– Cleaning the Lens 133
– Cleaning the Projector Case
133
INFORMATION 134
ToUpdateProjectorSoftware
134
BeforeReportingaProblem,
ChecktheFollowing: 135
– General 135
– Picture 135
– Sound 136
– PC Connection Problem 138
– Problems Replaying Movies
in My Media 139
SPECIFICATIONS 140
SYMBOLS 145
18
PREPARATION
PREPARATION
The pictures may differ slightly from the actual product.
Accessories
Accessories included with the projector are show below.
Accessories are subject to change without prior notice.
New accessories may be added or old ones removed.
Magic Remote Control
Two AA Batteries
Owner's Manual Composite Gender
Power cord AC-DC Adaptor
• When connecting an HDMI or USB
cable, or connecting a USB flash drive
to the HDMI or USB port, use a product
that has a width of 18 mm or less and
a height of 10 mm or less. If the USB
cable or USB flash drive does not fit
the USB ports of the projector, use an
extension cable that supports USB 2.0.
• When connecting two USB devices at the same time, each one should
have bezels less than 8.5 mm thick.
• Use a certified cable with the HDMI logo attached.
• If you do not use a certified HDMI cable, the screen may not display or a
connection error may occur. (Recommended HDMI cable types)
– High-Speed HDMI
®
/™ Cable
– High-Speed HDMI
®
/™ Cable with Ethernet
19
PREPARATION
OptionalExtras
To purchase optional accessories, visit an electronics store or online
shopping site or contact the retail store where you purchased the product.
Optional accessories are subject to change without prior notice.
Projection Screen HDMI Cable RF Cable
Video Cable Audio Cable Optical Cable
LG Audio Device MHL Cable
3D glasses
(DLP-LINK or DLP
Ready Type)
Component Gender
20
PREPARATION
PartsandComponents
This projector is manufactured using high-precision technology. You may,
however, see tiny black dots and/or bright colored dots (red, blue, or
green) that continuously appear on the projector screen. This is a normal
result of the manufacturing process and does not indicate a malfunction.
MainUnit
Bottom of the Projector
Adjustable leg
3)
IR Reciver
Lens
2)
Vent
1)
Speaker
Joystick Button
Speaker
Focus Ring
Vent
1)
Vent
1)
Mirror
2)
1) Due to the high temperature of vent area, do not get close to the vent area.
2) Do not touch the lens and mirror when using the projector. The lens may be
damaged.
3) Turn the adjustable leg left or right to adjust the angle.
21
PREPARATION
Side
6 742 31 5
No. Description
1
(Headphone Port)
2
COMPONENT IN Port
3
AV IN Port
4
OPTICAL DIGITAL AUDIO OUT Port
5
(USB port)
6
LAN Port
7
Port
22
PREPARATION
Back
1 2 3
No. Description
1
Port
2
DC IN Port
3
Port
23
PREPARATION
UsingtheJoystickButton
You can operate the projector by pressing the button or moving the joystick
left, right, up, or down.
Basicfunctions
PowerOn When the projector is turned off, place
your nger on the joystick button,
press it once, and release it.
PowerOff When the projector is turned on, place
your nger on the joystick button,
press it once for a few seconds, and
release it. (However, if the Menu
button is on the screen, pressing and
holding the joystick button will let you
exit the Menu.)
Volume
Control
Place your nger over the joystick
button and move it left or right, you
can adjust the volume level.
Channels
Control
Place your nger over the joystick
button and move it up or down, you
can scroll through the saved channels.
• Place your finger over the joystick button and move it up, down, left,
or right. Be careful not to press the joystick button. If you press the
joystick button first, you may not be able to adjust the volume level
and/or scroll through saved channels.
NOTE
24
PREPARATION
Adjustingthemenu
When the projector is turned on, press the joystick button one time.
You can adjust the menu items ( , , , ) moving the joystick
button left, right, up, or down. Move to the desired menu item, and then
press the joystick button once to select it.
Close
Projectoroff
Turns the power off.
InputList Changes the input source.
Close
Clears on-screen displays and
returns to projector viewing.
Settings Displays the Settings menu.
ProjectorStatusIndicators
LED Power
Indicator
LED Power
Indicator
LEDPowerIndicator
Red
Power standby state
Off
The projector is operating with the power on.
25
PREPARATION
Installation
InstallationPrecautions
• Place the projector in a well-
ventilated environment.
– To prevent internal
overheating, install the
projector in a well-ventilated
place. Do not place anything
near the projector. That may
block its air vents. If the
air vents are blocked, the
internal temperature of the
projector will increase.
– Do not place the projector
on a carpet or rug. If the
projector's inlet vent is on
the bottom, be careful not to
block the vent and always
use the projector on a solid,
level surface.
– Be sure to prevent foreign
objects such as paper debris
from entering the projector.
– Leave an adequate open
area (30 cm or more) around
the projector.
• Do not place the projector in a
hot, cool, or humid environment.
• Do not place the projector in a
place where it will easily attract
dust.
– This may result in re.
• Never open any cover on the
projector. There is a high risk of
electric shock.
• The projector is manufactured
using high-precision technology.
You may, however, see
tiny black dots and/or bright
colored dots (red, blue or
green) that continuously
appear on the projector screen.
This is a normal result of the
manufacturing process and
does not indicate a malfunction.
• The remote control may not
work in an environment where
a lamp equipped with electronic
ballasts or a three-wavelength
fluorescent lamp is installed.
Replace the lamp with an
international standard lamp
for the remote control to work
normally.
• To install to the ceiling, attach
the ceiling-type bracket to
the projector with M4 x 8 mm
screws.
26
PREPARATION
ProjectionDistanceperScreenSize
1 Place the projector on a sturdy, level surface, together with the PC or
audio/video source.
2 Place the projector an appropriate distance away from the screen. The
distance between the projector and the screen determines the actual
size of the image.
3 Position the projector so that the lens is at a right angle to the screen.
If the projector is not at a right angle, the projected image will look
distorted. To correct the distortion, use the Edge Adj function.
(See page 40.)
4 Connect the power cord of the projector and the connected device to
the wall outlet.
Ratioofupwardprojection:125%
A
B
C
D
C
D
X
Y
ScreenSize[mm] 1524 1778 2032 2286 2540
HorizontalSize(X)x
VerticalSize(Y)[mm]
1328 x
747
1550 x
872
1771 x
996
1992 x
1121
2214 x
1245
A[mm] 414 482 550 618 686
B[mm] 105 173 241 309 377
C[mm] 149 181 213 245 276
D[mm] 241 273 304 336 368
The projection distance may vary depending on the installation conditions.
•If the projected image looks distorted or bent, check to see if the
screen is installed properly.
NOTE
27
PREPARATION
KensingtonSecuritySystem
• This projector has a Kensington Security Standard connector as an
anti-theft mechanism. Connect a Kensington Security System cable as
shown below.
• For more information on installation and use of the Kensington Security
System, refer to the user’s guide provided with the Kensington Security
System.
• The Kensington Security System is an optional accessory.
• What is Kensington?
Kensington is a company that provides safety systems for laptops and
other electronic devices. Website: http://www.kensington.com
28
MAGICREMOTECONTROL
MAGICREMOTECONTROL
If the battery low message appears while using the
Projector, replace the batteries.
As shown in the gure, press the top of the battery
cover and slide it down the cover. Insert two new and
identical batteries (1.5 V, AA type) with + and - poles
pointing in the correct direction in the remote control.
2
1
•Do not mix new batteries with old ones.
NOTE
(POWER)
Turns the Projector on or off.
(Up/Down/Left/Right)
Press the up, down, left or right button to scroll
the menu.
If you press
buttons while the
pointer is in use, the pointer will disappear from
the screen and Magic Remote will operate like
a general remote control. To display the pointer
on the screen again, shake Magic Remote to the
left and right.
(BACK)
Returns to the previous screen.
(Home)
Accesses the Home menu.
Wheel(OK)
Press the center of the Wheel button to select a
menu. You can change channels by using the
Wheel button.
29
MAGICREMOTECONTROL
(EXITtoLIVE)
Switches among broadcast (antenna) and
various inputs.
(Voicerecognition)
Network connection is required to use the voice
recognition function.
1. Press the voice recognition button.
2. Speak when the voice display window
appears on the left of the Projector screen.
* Use the Magic Remote no further than
10 cm from your face.
* The voice recognition may fail when you
speak too fast or too slowly.
* The recognition rate may vary depending
on the user’s characteristics (voice,
pronunciation, intonation, and speed)
and the environment (noise and Projector
volume).
Coloredbuttons
These access special functions in some menus.
VOL
Adjusts the volume level.
/INPUT
Displays the Screen Remote.
* Pressing and holding the
/INPUT
button will
display a menu to select an external device that
is connected to the Projector.
Used for viewing 3D video.
(MUTE)
Mutes all sounds.
* By pressing and holding the button, video
descriptions function will be enabled.
* SAP(Secondary Audio Program) Feature can
also be enabled by pressing the button.
CH
Scrolls through the saved channels.
30
MAGICREMOTECONTROL
1
2
1
Displayed when you press
the Wheel(OK) button
on the magic remote control.
Check program information.
2
If you point and hold the
pointer at the bottom left of
the screen while watching
projector, the MYAPPS
icon is displayed. Clicking
the icon displays the MY
APPS menu.
ToRegistertheMagicRemoteControl
To use the Magic Remote control, register it with your projector rst.
1 Put batteries into the Magic Remote and turn the Projector on.
2 Point the Magic Remote at your projector and press the Wheel
(OK) on the remote control.
• If the projector fails to register the Magic Remote, try again after turning
the projector off and back on.
ToRe-registertheMagicRemoteControl
1 Press the (Home) and (BACK) buttons at the same time, for
ve seconds, to unpair the Magic Remote with your projector.
2 Press the Wheel(OK) button towards the projector to re-register
the magic remote control.
• Pressing and holding the (EXITtoLIVE) button will let you cancel
and re-register Magic Remote at once.
31
MAGICREMOTECONTROL
UsingtheMagicRemoteControl
• Shake the magic remote control lightly when
there is no pointer displayed on the screen. A
pointer will be displayed on the screen.
– The pointer disappears if the remote control
is not used for a certain period of time.
• When you move the pointer signal transmitter
up/down/left/right while pointing it toward the
projector, the pointer moves.
– If the pointer is not working properly, do not
move the magic remote control for about
10 seconds, and then try again.
• If you press the navigation button while moving the pointer on the
screen, the pointer disappears, and the magic remote control works as a
common remote control.
• Use within an effective distance of 10 meters. Using the remote control
from greater distances or when obstructions block the sight line may
cause malfunctions.
• Electronic devices nearby may cause communication interference.
Devices such as microwave ovens and wireless LANs use the same
frequency range (2.4 GHz) as the Magic Remote Control and may cause
interference.
• Take care not to bang it against other hard objects such as furniture or
the floor.
32
USINGTHEPROJECTOR
USINGTHEPROJECTOR
ConnectingtheAntennaorCable
To watch TV using an indoor/outdoor
antenna, connect a wall terminal
and the antenna port of the Projector
using an RF cable (75 Ω).
You can watch terrestrial or cable
(analog, digital) TV. (The RF cable is
sold separately.)
• Make sure not to bend the copper wire of
the RF cable (75 Ω). Turn the input jack to
the right to fasten it.
• Ensure you use a standard coaxial cable
(75 Ω, sold separately) when connecting to
the projector input.
• For better image quality in locations where
signal strength is low, purchase and install a
signal amplifier (booster).
• A signal splitter is required if you want to use two or more
projectors through one antenna.
• If you have any problems when installing the antenna, please
consult a suitable retailer or the store where you purchased the
antenna.
NOTE
Copper wire
33
USINGTHEPROJECTOR
WatchingProjector
InitialSetup
The menu screen display in this owner's manual is an example to help
users understand how to operate the product and may look different from
the actual screen.
• The illustration of the menu may differ from the actual screen on the
product.
1 Connect the power cord correctly.
2 After waiting for a moment, press the POWER button on the remote
control or the joystick button.
3 When you turn on the projector for the rst time, a setting screen
appears as shown below. Here, you can specify the items required for
watching the projector more easily.
– Storemode is used when displaying the product in-store. The
picture mode is automatically reset after a certain period of time. You
can select Home to use the product at home.
34
USINGTHEPROJECTOR
35
USINGTHEPROJECTOR
– The initial settings are completed when you select the settings
above.
– ZIPCode : This feature is available in certain countries only.
• For AutoTuning while using the projector, go to (Home) →
SETTINGS → CHANNEL and select AutoTuning.
• To change the mode while using the projector, go to
(Home) →
SETTINGS → OPTION and select ModeSetting.
NOTE
36
USINGTHEPROJECTOR
FocusoftheScreenImage
When an image appears on the screen, check if it is in focus and ts the
screen properly.
Focus Ring
• To adjust the focus of the image, rotate the focus ring.
• Make sure the product does not move when adjusting the focus.
WatchingWiththeProjector
1 When in standby mode, press the POWER button to turn the projector
on.
2 Select the (Home) → INPUTLIST and select the input signal you
want.
3 Control the projector using the following buttons while watching
projector.
Button Description
CH Changes the TV channel.
VOL
Adjusts the volume level.
(MUTE)
Mutes the sound from the projector.
4 To turn the projector off, press the POWER button.
37
USINGTHEPROJECTOR
ToSetChannel
Image shown may differ from your projector.
ToViewProgramInformation
Displays information on current program and / or current time, etc.
1 Move the pointer of the Magic Remote control to the top of the projector
screen.
2 Click the activated channel banner area.
3 The program details will be displayed at the bottom of the projector
screen.
1 23
Description
1
Program name
2
Current time
3
Detail information on program (for digital broadcast)
ToSetFavoriteChannels
(Home) → SETTINGS → CHANNEL → ChannelEdit
1 Move to the desired channel on Wheel(OK) button. Channel is
selected.
2 Press SetasFavorite.
3 Select the desired Favorite channel group.
4 Select OK. Favorite is set.
38
USINGTHEPROJECTOR
ToUseFavorite
(Home) → MYAPPS → Ch.List
Channel list will appear. Select the desired preset favorite channel from
Favorite List A to D.
ToSetAutoTuning
(Home) → SETTINGS → CHANNEL → AutoTuning
Automatically tunes the channels.
• Channels are not registered properly unless the antenna / cable is
connected correctly.
• AutoTuning only sets channels that are currently broadcasting.
• If LockSystem is turned on, a pop-up window will appear asking for
password.
ToSetChannelsManually
(Home) → SETTINGS → CHANNEL → ManualTuning
Adjusts channels manually and saves the results.
For digital broadcasting, signal strength, etc. can be checked.
ToEditChannels
(Home) → SETTINGS → CHANNEL → ChannelEdit
Edits the saved channels
Set your selected channel as favorite, block / unblock, and Add / Delete.
39
USINGTHEPROJECTOR
AdditionalOptions
ToadjustAspectRatio
Select (Home) → SETTINGS → PICTURE → AspectRatio.
Selects the screen aspect ratio.
Menu Description
16:9 Resizes images to t the screen width.
JustScan
Displays video images in the original size without
removing parts of the edge of the image.
• In DTV / HDMI / Component (over 720p) mode, Just
Scan is available.
SetBy
Program
Depending on the input signal, screen aspect ratio
changes to 4:3 or 16:9.
4:3
Resizes images to the previous standard 4:3.
Zoom
Resizes the image to t the screen width. The top and
bottom parts of the image may be cut off.
Cinema
Zoom1
Formats an image to the cinema scope ratio (2.35:1) and
zooms in on the ratio.
•While viewing an external device, these cases may result in image
burn :
– a video with stationary caption (such as network name)
– 4:3 aspect ratio mode for an extended period.
Take caution when using these functions.
•Available picture size may differ depending on the input signal.
•The screen aspect ratios on HDMI-PC input are available in 4:3 and
16:9 only.
NOTE
40
USINGTHEPROJECTOR
UsingtheEdgeAdj(4CornerKeystone)Function
EdgeAdj (4 Corner Keystone) adjusts the horizontal and vertical sides of
the projected image if the projector is at an angle and not perpendicular to
the screen. This feature ensures the shape of the projected image is not
distorted.
Use this feature only when the projector cannot be set up at the optimal
angle. EdgeAdj may result in a loss of image quality.
1 Go to (Home) → SETTINGS → OPTION → EdgeAdj.
2 The value range of EdgeAdj is as follows.
– Top Left (H: 0 to 100, V: 0 to 100)
– Top Right (H: -100 to 0, V: 0 to 100)
– Bottom Left (H: 0 to 100, V: -100 to 0)
– Bottom Right (H: -100 to 0, V:-100 to 0)
3 Press
the
Wheel(OK)
button.
•When using AutoKeystone(Vertical), the current value set for
EdgeAdj is changed to the value that has been set with Auto
Keystone(Vertical).
NOTE
41
USINGTHEPROJECTOR
ChangingInputDevice
Toselectanexternalinput
Selects external input.
• Select (Home) → INPUTLIST or press the INPUT button on the
remote control to display the input selection screen.
– Connected inputs are displayed rst. However, AV is always
activated.
• Select an input signal using the remote control's INPUT button to
connect the projector to the desired input. You can use the or
button to switch among all the input modes.
1
2
3 4 5
Description
1
Selects speaker.
2
Selects input.
3
Edits the name of external device connected to external
terminal.
4
Sets SIMPLINK.
5
Sets UniversalRemoteControl.
• This feature is available in certain countries only.
42
USINGTHEPROJECTOR
SelectinganInputLabel
Displays which devices are connected to which input ports.
1 Select (Home) → INPUTLISTor press the INPUT button on the
remote control to display the input selection screen.
2 Press the red button.
3 Press the
or
button to go to the desired input and press the
Wheel(OK)
button.
4 Press the
, , , or
button to select a device name.
43
USINGTHEPROJECTOR
ToUseSIMPLINK
SIMPLINK is a feature that enables you to control and manage various
multimedia devices conveniently using the projector remote control only via
the SIMPLINK menu.
1 Connect the projector's HDMI terminal with the SIMPLINK device's
HDMI output terminal using an HDMI cable. For home theater units
with a SIMPLINK function, connect HDMI terminals as above, and
use an optical cable to connect OpticalDigitalAudioOut from the
projector to Optical Digital Audio In of the SIMPLINK device.
2 Select (Home) → MYAPPS→ SIMPLINK. SIMPLINK menu
window appears.
3 Select SIMPLINKSetting on SIMPLINK menu window. SIMPLINK
setup window appears.
4 SIMPLINK to On in SIMPLINK setup window.
5 Close SIMPLINK setup window.
6 Select the device to control from (Home) → MYAPPS→
SIMPLINK.
• This function only works on devices with the SIMPLINK logo
( ). Verify that the external device has a SIMPLINK logo.
• To use the SIMPLINK function, you need to use a high-speed HDMI
®
cable (with CEC, or Consumer Electronics Control, feature added).
High-speed HDMI
®
cables have pin 13 connected for information
exchange between devices.
• Turn on or select the media of a device with home theater features to
see the speaker switch to ExternalSpeaker.
• To use the Listen via External Speaker function, connect an optical
cable (Purchase separately) or HDMI-ARC-enabled device via the
HDMI-ARC port.
• Switching to external input causes devices operating with SIMPLINK
to stop.
• Use of a third-party device with HDMI-CEC features may cause
malfunctions.
• Connect with an Optical cable (sold separately) to use External
Speaker.
NOTE
44
USINGTHEPROJECTOR
ExplanationofSIMPLINKFeatures
Menu Description
DirectPlay
Plays the multimedia device on the projector
instantly.
Select
multimedia
device
Selects the desired device via the SIMPLINK menu
to control it from the projector screen instantly.
Discplayback
Manages the multimedia device with the projector
remote control.
Poweroffall
devices
If the AutoPower function is set to On in the
SIMPLINKsettings, turning the projector off will
turn the power off on all SIMPLINK-connected
devices.
SyncPoweron
If the AutoPower function is set to On in the
SIMPLINKsettings, turning on a SIMPLINK device
will turn the projector on.
Speaker
Selects speaker either on the home theater unit or
the projector.
45
USINGTHEPROJECTOR
UsingtheQuickMenu
You can customize frequently used menus.
1 Select (Home) → MYAPPS→ QuickMenu.
2 Press the or
button to select a menu and press Wheel(OK)
button
.
Menu Description
AspectRatio Resizes the picture.
PictureMode Changes the picture mode.
SoundMode Sets the sound mode.
SleepTimer
Sets the projector to be turned off at the specied
time.
Caption Sets whether to display captions.
MultiAudio
Sets MONO or STEREO, or a language for a
bilingual broadcast (digital signal).
SAP Changes the MTS sound (analog signal).
EnergySaving
Reduces power consumption by adjusting peak
screen brightness.
AVMode
Sets the genre.
Mode
Off
You can watch using the settings in the
video/audio menu.
Sport Optimizes video/ audio settings for sports.
Cinema
Change to optimal video/ audio settings
for movies.
Game
Change to optimal video/audio settings
for games.
Del/Add Can delete or add channels.
USBDevice
Allows you to remove a connected USB device in a
safe manner.
3 Press the , , , or button to scroll through the following
menus.
46
USINGTHEPROJECTOR
ToSetSound
ToSetSoundOutput
Touseprojector’sspeakers
Sound is output through the projector speaker.
• (Home) → SETTINGS → SOUND → SoundOut → Projector
Speaker
TouseExternalSpeaker
Sound is output through the speaker connected to the optical or HDMI
(ARC) port.
SIMPLINK is supported.
• (Home) → SETTINGS → SOUND → SoundOut → External
Speaker(Optical/HDMIARC)
TouseDigitalSoundOut
Sets up Digital Sound Output.
• (Home) → SETTINGS → SOUND → SoundOut → External
Speaker(Optical/HDMIARC) → DigitalSoundOut
Item SoundInput DigitalSoundOutput
Auto
MPEG PCM
Dolby Digital Dolby Digital
Dolby Digital Plus Dolby Digital
HE-AAC Dolby Digital
PCM All PCM
47
USINGTHEPROJECTOR
ToconnectanduseanLGaudiodevice
LG audio device allows you to enjoy rich powerful sound easily.
• (Home) → SETTINGS → SOUND → SoundOut → LGSound
Sync(Optical)
Connect an LG audio device with the logo to the OPTICAL
DIGITALAUDIOOUTPUT port.
ToConnectandUseaBluetoothdevice
Sound output is through the Bluetooth device.
• (Home) → SETTINGS → SOUND → SoundOut → Bluetooth
• The devices that can be connected are:LG BTS1, LG HBS-700,
LG HBS-730, LG HBS-800 (Product availability may vary by country.)
• For wireless connection, if the device fails to connect. Check the device
power to connect and if the LG Audio device is in a proper operating
condition.
• If two or more devices are detected, the first detected device is
connected first. To view more detected devices to connect, press the
ShowMore button.
• Products from other manufacturers may not be compatible.
ToConnectandUseaHeadphone
Sound output is through the headphone.
• (Home) → SETTINGS → SOUND → SoundOut → Headphone
• If you connect headphones while the projector is powered on, it
automatically detects the headphones and sounds through them.
48
USINGTHEPROJECTOR
UsingtheMultiAudio
Multi Audio means stereo and multiple language broadcast from the
channel provider.
• (Home) → MYAPPS→ QuickMenu → MultiAudio
Inthecaseofdigitalbroadcast
Multiple languages can be selected depending on the multi-language
signals from the TV station.
• For default language, select at (Home) → SETTINGS → OPTION
→ Language → AudioLanguage.
Inthecaseofanalogbroadcast
Item Description
Mono
Left and right speakers produce sound, and the
sound mode is mono.
Select this menu to listen in Mono mode regardless
of broadcast state. This can be set for a stereo
broadcast signal. Select Mono in poor reception
areas (e.g., areas with weak or erratic signals) or
when multi audio reception is not clear.
Stereo
The sound mode is in stereo when the sound comes
out of both left and right speakers.
Mainlanguage
/Sublanguage
If the station broadcasts a multi-language signal,
different languages may be selected.
49
ENTERTAINMENT
ENTERTAINMENT
TouseSmartFeatures
TouseHomeScreen
• Press the (Home) button on the remote control.
With all projector features on one screen, everyone can access a wealth of
content and applications conveniently via the quick and easy-to-use menu,
arranged by themes such as Live TV, MY APPS, etc.
1 3
2
Movie Weather News Sports UCC
Picture Map Game Music SNS
Description
1
RECENT LIST
2
Sign in
3
MY APPS
50
ENTERTAINMENT
TouseMYAPPS
• (Home) → MYAPPS
• Select MYAPPS at the lower right of the home screen.
• Check pre-installed apps and apps you have downloaded.
ToedititemsinMYAPPS
• Select (Home) → MYAPPS → (Edit).
• On the MYAPPS page, select (Edit) at the top of the screen to
move or delete apps. Please note that system apps can be moved, but
cannot be deleted.
• Changes orders / deletes items by dragging the app icons if your device
has a Magic Remote Control.
• The illustration of the menu may differ from the actual screen on the
product. (Depending on country.)
51
ENTERTAINMENT
ToConnectNetwork
A wireless or wired network connection is required to use smart features.
When connected to the network, you can use premium content, LG Smart
World, Contents Sharing and more.
One-clickNetworkConnection
Connects easily to a wired/wireless network.
• (Home) → SETTINGS → NETWORK → NetworkConnection to
connect to an available network automatically. Follow the prompts on the
projector.
ToConnecttoaNetworkThroughSetExpert
For use in special circumstances such as in ofces (in cases where a static
IP is used).
• Select (Home) → SETTINGS → NETWORK → Network
Connection → StartConnection (→ OtherNetworkList) → Manual
Setup.
1 Select a NetworkConnection, either Wired or Wireless.
2 When connecting via Wi-Fi, use the one of the following network
connection methods.
Item Description
APList Connects to the network selected from the AP List.
EntertheSSID Connects to the wireless AP typed in.
WPS-PBC
Connects easily when the button of a wireless AP
supporting PBC is pressed.
WPS-PIN
Connects easily when the PIN of the wireless AP
that you wish to connect to is entered in to the AP
website.
52
ENTERTAINMENT
ToUsetheWi-FiDirectFunction
Wi-Fi Direct is a function that allows your projector to connect with a Wi-Fi
Direct device without Internet connection. With SmartShare™, you can
watch the les stored on a device connected via Wi-Fi Direct.
• Select (Home) → SETTINGS → NETWORK → Wi-FiDirect.
1 Set Wi-FiDirect to On. (If you do not use it, please change it to Off.)
2 Enable the Wi-Fi Direct settings on the device to which you want to
connect.
3 A list of devices that can be connected to the projector is displayed.
4 Select a device to connect.
5 Select Yes when the connection request message appears.
6 If the device that you want to connect accepts the request, Wi-Fi
Direct is connected.
53
ENTERTAINMENT
TipsforNetworkSettings
• Use a standard LAN cable (Cat5 or higher with RJ45 connector,
10 Base-T or 100 Base TX LAN port).
• Resetting your modem can cause network connection problems. To
resolve the problem, turn the power off, disconnect and reconnect, and
then turn the power back on.
• LG Electronics is not responsible for any network connection problems
or any faults, malfunctions and errors caused by an network connection.
• A network connection may not work properly depending on the Internet
service provider.
• A DSL modem is required for a DSL service; a cable modem is required
for a cable service. Only a limited number of network connections
may be available, and projector network setting may not be available
depending on your contract with your Internet Service Provider (ISP.)
(If only one device is allowed per line and the PC is already connected,
other devices cannot be used.)
• Wireless networks can be subject to interference from other devices
operating at a frequency of 2.4 GHz (wireless phones, Bluetooth
devices, or microwave ovens). There may also be interference from
devices with a frequency of 5 GHz, same as other Wi-Fi devices.
• The surrounding wireless environment can cause the wireless network
service to run slowly.
• If you do not turn off the entire local home network, network traffic may
occur on some devices.
• For an AP connection, an access point device that supports wireless
connection is required and the wireless connection feature must
be enabled on the device. Contact your service provider regarding
availability of wireless connection on your access point.
• Check the SSID and security settings of the AP for AP connection. Refer
to the appropriate documentation for SSID and security settings of the
AP.
• Invalid settings on network devices (wired/wireless line sharer, hub)
can cause the projector to run slowly or not operate properly. Install
the devices correctly according to the appropriate manual and set the
network.
• Connection method may differ according to the AP manufacturer.
54
3DFUNCTION
3DFUNCTION
3D technology uses different video frames for each eye to add depth to the
video.
WhileWatching3D
WARNING
• If you view 3D video or images too closely for a long period of time, you
may experience eyestrain.
• If you watch the projector or game screen for a long time with 3D
glasses on, you may experience dizziness or eye fatigue.
• People with chronic diseases (epilepsy, cardiovascular disease, blood
pressure-related diseases, etc.), pregnant women, and people with
serious motion sickness should avoid watching 3D video.
• People with stereo blindness, or with stereopsis problems, should also
avoid watching 3D video content. It may cause double vision or visual
discomfort.
• People with strabismus, amblyopia, or astigmatism may have difficulty
perceiving video depth and may be fatigued easily due to double vision
or other ailments. It is recommended to rest more frequently than other
viewers.
• Because 3D can be perceived as real, some viewers may be surprised
or overexcited.
• Do not watch 3D images near fragile objects or any objects that can be
knocked over easily.
• Take care not to injure yourself as you may subconsciously try to move
away from the life-like 3D images.
55
3DFUNCTION
• Warningaboutphotosensitivityseizures
– Some users may experience a seizure or other abnormal symptoms
when they are exposed to a ashing light or particular patterns from
a video game. If anyone in your family has a history of epilepsy or
has ever experienced any kind of seizure, please consult your doctor
before viewing 3D images.
If you experience one of the following symptoms while watching a 3D
video, stop watching the 3D video immediately and take a rest.
– Dizziness, switched eyesight, twitching of the eye or facial muscles,
involuntary movements, cramp, loss of consciousness, confusion,
loss of sense of direction, or nausea. If the symptom does not
disappear, please consult your doctor.
• You can reduce the risk of photosensitive seizures by taking the
following preventive measures.
– Take a rest of 5 to 15 mins. for every 1 hour of viewing.
– If vision varies between each eye, correct the variation before
beginning to watch a 3D video.
– Ensure that the 3D video is directly in front of you, at eye level.
– You should stop watching if you experience a headache, fatigue, or
dizziness.
– Do not view 3D images for a long period of time when you are tired
or ill.
CAUTION
• Extra special care is required for children watching a 3D video.
WhenWatching3DVideo
• Prevent children of 5 years or younger from watching a 3D video. It may
impair the development of their eyes.
• Children 10 years old or younger are still developing their eyesight and
may have an excessive tendency to touch or jump at the screen. Adult
guidance and supervision is recommended.
• Since the distance between the eyes is narrower for children than in
adults, children tend to notice a greater difference in the images seen by
each eye. Therefore, even while watching the same 3D video, children
may have a greater depth perception than adults.
• Children under 19 years old or younger may respond with sensitivity to
the light stimuli of 3D content. Excessive viewing when fatigued is not
recommended.
56
3DFUNCTION
• Elderly viewers may have a reduced depth perception than younger
viewers. Avoid watching video nearer than the recommended distance.
• Watch 3D images within the optimum viewing angle and distance.
• If you are outside the viewing angle or distance, you may not be able to
see 3D images. You cannot view 3D images when you are lying down.
• You may see left and right images overlapped during projector
initialization after it is powered on. It may take some time for
optimization.
• It may take some time for the 3D image to look normal after you turn
your eyes away from the screen and look back at the 3D image.
• It may flicker slightly while watching 3D images under a 3 wavelength
lamp fluorescent light (50 Hz to 60 Hz) or near windows. If so, it is
recommended to block the sun light with a curtain and to dim the lights.
• The 3D glasses must be DLP-LINK (DLP Ready) type.
• You may not be able to watch 3D properly if there is an obstacle
between the projector and 3D glasses.
• Install the 3D projector as far as possible from other devices.
• If a future 3D broadcasting format that is not supported by this projector
becomes the standard, an additional device such as a set-top box may
be required.
Pleasecheckthefollowingwhenusing3Dglasses.
• Do not use 3D glasses as ordinary glasses, sunglasses, or protective
goggles.
– If you do so, this may cause injury.
• Do not store 3D glasses in very hot or very cold conditions. If you do,
this may cause them to become distorted. Do not use distorted glasses.
• Do not drop 3D glasses or allow them to come into contact with other
objects.
– This may cause product malfunction.
• The lenses of 3D glasses are easily scratched. Use a soft clean cloth
when cleaning them.
• Foreign particles on the cloth may cause scratches.
• Do not scratch the surface of the 3D glasses' lenses with sharp objects
or wipe them with chemicals. If the lenses get scratched, images may
not look normal when viewing 3D.
57
3DFUNCTION
RequirementsforWatching3DImages
* Optimum viewing angle: Top/Bottom/Left/Right 9°
Recommended viewing distance: 3 m to 5 m
Recommended screen size: 101 cm
* Watching 3D videos should be done in dark room environments only.
• The pairing with the DLP-LINK glasses is affected by the intensity of
light reflected from the screen. Therefore, the pairing with DLP-LINK
glasses may not work properly if the light reflected from the screen is
not bright enough, such as when the surrounding area is bright, the
screen is big, or the maximum energy saving mode is enabled.
• Some menus may not work while playing a 3D video.
• You can only watch a 3D video properly when the 3D video format
option has been selected on the projector.
NOTE
58
3DFUNCTION
UsingtheDLP-LINK(DLP-Ready)TypeGlasses
1 While watching 3D images from the projector, press buttons on the
glasses.
2 When you press the button, the glasses icker while synchronizing with
the 3D images. (The ickering is a unique operation method of DLP-
LINK type glasses. It may be different depending on the glasses type.)
3 If the glasses icker or problems occur while watching 3D, rst turn
the lights off to make the room darker. Contact your projector seller for
queries about the glasses.
Toview3Dimages
3D imaging is a technology that utilizes the slight difference in left/
right eyes to make the images on the projector appear just like real-life
3-dimensional space.
1 Play a 3D-image title or tune to a 3D channel.
2 Press the 3D button to activate 3D.
3 Turn on the 3D glasses and put them on.
4 While viewing 3D images, press the 3D button on the remote control to
end 3D image viewing.
* Depending on the input signal, the available 3D type may differ.
59
3DFUNCTION
Supported3DMode
Signal
Resolution
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Supported3D
Formats
HDMI
720p
1280 x
720
89.9 /
90
59.94 /
60
Frame Packing
45 60
Side by side
(half), Top and
Bottom
1080i
1920 x
1080
33.7 60
Side by side
(half), Top and
Bottom
1080p
1920 x
1080
53.95 /
54
23.98 /
24
Frame Packing
67.5 60
Side by side
(half), Top
and Bottom,
Single Frame
Sequential
27 24
Side by side
(half), Top and
Bottom
33.7 30
Side by side
(half), Top and
Bottom
USB 1080p
1920 x
1080
33.75 30
Side by side,
Top and
Bottom, MPO,
JPS (Photo)
60
SMARTSHARE
SMARTSHARE
Smartshare is the name of contents sharing and usage function that
includes USB Connection, SCREEN SHARE (Miracast™, Intel’s WiDi),
Contents Sharing and others.
BeforeUsing
ConnectingaUSBDevice
Connect a USB device (external
HDD, USB memory) to the USB port
of projector to enjoy the content les
stored in the USB device with your
projector. You cannot write or delete
data in the USB device. Connect a
USB ash drive as shown below.
USB ash
Drive
RemovingaUSBDevice
1 Select (Home) → MYAPPS→ QuickMenu.
2 Use the or button to move to USBDevice and press the
Wheel(OK) button.
3 Select a USB to remove. Wait for conrmation that the USB device has
stopped before removing the USB.
• If detached early, an error may occur on the projector or the USB
storage device.
• Once a USB device has been selected for removal, it can no longer
be read. Remove the USB storage device and then re-connect it.
NOTE
61
SMARTSHARE
TipsforusingaUSBdevice
• If the USB storage device has a built-in auto recognition program or uses
its own driver, it may not work.
• Some USB storage devices may not work or may work incorrectly.
• If you use a USB extension cable, the USB device may not be
recognized or may not work properly.
• Use only USB storage devices formatted with the Windows FAT32 or
NTFS file system.
• For external USB HDDs, it is recommended that you use devices with a
rated voltage of less than 5 V and a rated current of less than 500 mA.
• It is recommended to use a USB hub or hard disk drive with power
supplied. (If the power supplied is not enough, the USB storage device
may not be detected properly.)
• It is recommended that you use USB flash drives of 32 GB or less and
USB HDDs of 2 TB or less.
• If a USB HDD with power-saving function does not work properly, turn
the power off and on. For more information, refer to the user manual of
the USB HDD.
• Data in USB storage device can be damaged so be sure to back
up important files to other devices. Data maintenance is the user's
responsibility and the manufacturer is not responsible for data loss.
62
SMARTSHARE
TouseSmartShare™
1 Press the (Home) button on the magic remote control.
2 Select SMARTSHARE™.
You can watch the photo, music, video, and document on the projector by
connecting a USB or home network (Contents Sharing). The photo, music,
video, and document les of all devices connected to the projector are
displayed. (For the document les, only those in the devices connected via
USB are displayed.)
000 001 002 003 004
005 006 007 008 009
010 011
2
1
Description
1
Displays photo/music/video les on all devices connected to the
Projector.
2
Shows how to connect PC, smartphone/device, and USB.
63
SMARTSHARE
WatchingtheVideos
In the Videos, you can watch movies stored on the connected USB
device.
Controls playback and sets options while viewing videos.
Playingvideo-warning
• Some subtitles created by users may not work properly.
• The video and subtitle files should be placed in the same folder. For
subtitles to display correctly, the video and subtitle files must have the
same name.
• Subtitles on an NAS (Network Attached Storage) device may not be
supported depending on the manufacturer and model.
• We do not support any stream that contains GMC (Global Motion
Compensation) or Qpel (Quarterpel Motion Estimation).
• Only H.264 / AVC profile level 4.1 and lower is supported.
• The file size limit is dependent on the encoding environment.
• It works only the above version of Window Media Audio V2.
• It’s not supported AAC Main Profile.
• Video files created by some encoders may not be played back.
• Video files in formats other than the ones specified here may not be
played back.
• Playback of video files stored on the USB device that do not support
High Speed may not work properly.
• The projector supports DTS audio codec when the USB / HDMI video
file playback.
64
SMARTSHARE
Tocontrolvideoplayback
You can control playback using the following buttons.
Shows the current playing position.
Use the or button to move forward or backward.
Item Description
Resumes normal playback.
Pauses the video player.
Displays in slow motion.
Whenever this button is pressed, the playback speed is
increased or decreased by one unit.
Plays the previous/next le.
3D Switches to the 3D screen.
Option Sets the option.
65
SMARTSHARE
ViewingthePhotos
You can view photos stored on a connected device.
Tocontrolphotoview
You can control playback using the following buttons.
Item Description
,
Selects the previous or next photo.
If no picture is selected, all photos in the current folder are
displayed in a slide show. If some photos are selected,
those photos are displayed in a slide show.
• Set
SlideShowSpeed in the Option → SetPhotoView.
menu.
• When the 3D photos are displayed in a slide show, the
SlideShowEffect may not work.
You can listen to music while viewing full-size photos.
• Set BGM in the Option → SetPhotoView. menu.
3D Switches to the 3D screen.
Rotates photos.
• Rotates a photo 90°, 180°, 270°, 360° clockwise.
• Photos cannot be rotated if their width is greater than the
height of the maximum supported resolution.
Enlarges or reduces the photo.
Use the Up/Down/Left/Right buttons to select a page and
press the Wheel(OK) button.
Option A setting popup window will appear.
66
SMARTSHARE
ListeningtoMusic
You can play audio les stored on the connected device.
Tocontrolmusicplayback
You can control playback using the following buttons.
Changes the playing position.
Item Description
Plays the previous/next le.
Pauses the music player.
Resumes normal playback.
Sets the repeat playback.
Sets the random playback.
Plays music with the projector screen turned off.
Sets Option for the music list.
• If you use the USB device, time information will be not shown on screen.
67
SMARTSHARE
ViewingFiles
You can see document les stored on a connected device.
SupportedFileFormats
XLS, XLSX, DOC, DOCX, PPT, PPTX, TXT, PDF, HWP
Microsoft Ofce 97/2000/2002/2003/2007 version
Adobe PDF 1.0/1.1/1.2/1.3/1.4 version
Hangul 2007 version
• File Viewer realigns a document, so it may look different from what is
displayed on a PC.
• For documents that include images, the resolution may look lower during
the realigning process.
• If the document is large or has many pages, it may take longer to load.
• Unsupported fonts may be replaced by other fonts.
• The file viewer may not open for Office documents that contain many
high resolution images. In that case, reduce the image file size, save it
on a USB storage device and run the file viewer again or connect your
PC to the projector and open the file on your PC.
BrowsingFileViewer
You can control playback using the following buttons.
• Press the CH button to move to the previous or next page.
• Press the VOL button to zoom in or zoom out.
– Press the Wheel(OK) button.
– Press the Up/Down/Left/Right buttons to move to GoPage or
Zoom.
Item Description
GoPage Moves to the page you specify.
Zoom Enlarges or reduces the document.
Option Sets Option for File Viewer.
List Returns to a list.
68
SMARTSHARE
ToSetSmartShare™RelatedFunctions
Select (Home) → SMARTSHARE™ → Settings.
Changes settings related to SmartShare™ content playback.
AdvancedSetting
Item Description
MyProjector
Name
Changes the name that appears when searching for
the projector from other devices.
NetworkStatus Checks the network connection.
Wi-FiDirect
Allows use of wireless connection functions such as
Wi-Fi Direct and WiDi.
AutoPlayon
Receive
Choosing whether to ask before playing the content
that is shared by other devices.
DivX(R)VOD
Registers or releases DivX.
Checks DivX Registration Code for playing DivX-
protected videos. Register at http://vod.divx.com.
Uses Registration Code to rent or purchase movies
at www.divx.com/vod.
• Rented / purchased DivX files cannot be played
if the DivX Registration Code of a different device
is used. Use only the DivX Registration Code
granted to this device.
• Converted files not conforming to the DivX Codec
Standard may not play or may produce abnormal
images and sound.
DeleteHistory
• To delete contents history, press DeleteHistory button. Use the
contents at Recent menu.
SmartShare™supportingfile
• Maximum data transfer rate: 20 Mbps (Mega bit per second)
• External subtitle formats supported: *.smi, *.srt, *.sub (MicroDVD,
SubViewer 1.0/2.0), *.ass, *.ssa, *.txt (TMPlayer), *.psb (PowerDivX),
*.dcs (DLP Cinema)
• Internal subtitle formats supported: XSUB (supports internal subtitles
generated from DivX6)
69
SMARTSHARE
VideoSupportedCodec
Maximum resolution: 1920 x 1080 @ 30p
Extension Codec
.asf
.wmv
Video
VC-1 Advanced Prole, VC-1 Simple and Main
Prole
Audio WMA Standard, WMA 9 Professional
.divx
.avi
Video
DivX3.11, DivX4, DivX5, DivX6, XViD, H.264/
AVC, Motion Jpeg, MPEG-4 Part 2
Audio
MPEG-1 Layer I, II, MPEG-1 Layer III (MP3),
Dolby Digital, Dolby Digital Plus, LPCM,
ADPCM, DTS
.mp4
.m4v
.mov
Video H.264/AVC, MPEG-4 Part 2
Audio AAC , MPEG-1 Layer III (MP3)
.3gp
.3g2
Video H.264/AVC, MPEG-4 Part 2
Audio AAC, AMR-NB, AMR-WB
.mkv
Video H.264/AVC
Audio HE-AAC, Dolby Digital
.ts,.trp,
.tp,.mts,
.m2ts
Video H.264/AVC, MPEG-2, VC-1
Audio
MPEG-1 Layer I, II, MPEG-1 Layer III (MP3),
Dolby Digital, Dolby Digital Plus, AAC
.vob
Video MPEG-1, MPEG-2
Audio Dolby Digital, MPEG-1 Layer I, II, DVD-LPCM
.mpg
.mpeg
Video MPEG-1, MPEG-2
Audio
MPEG-1 Layer I, II, MPEG-1 Layer III (MP3),
AAC
AudioFile
Filetype Item Info
mp3
Bitrate 32 Kbps to 320 Kbps
Samplefreq. 16 kHz to 48 kHz
Support MPEG1, MPEG2, Layer2, Layer3
70
SMARTSHARE
Availablephotofile
Filetype Item Info
2D
(jpeg,jpg,jpe)
JPEG
Minimum: 64 x 64
Maximum:
– Normal Type: 15360 (W) x 8640 (H)
– Progressive Type: 1920 (W) x 1440 (H)
3D(jps)
JPS
Minimum: 64 x 64
Maximum:
– Normal Type: 15360 (W) x 8640 (H)
3D(mpo) MPO
4:3 size: 3648 x 2736
2592 x 1944
2048 x 1536
3:2 size: 3648 x 2432
71
SMARTSHARE
TouseSCREENSHARE
(Miracast™/Intel’sWiDiFunction)
ToUsetheMiracast™/Intel’sWiDiFunction
You can view the screen of a device with Miracast™ and Intel’s WiDi
technologies on your projector. Contact the device manufacturer to nd out
if the device supports this function.
• Select (Home) → SETTINGS → NETWORK → Miracast™/Intel’s
WiDi.
1 Set Miracast™/Intel’sWiDi to On. (If you do not use it, please
change it to Off.)
2 Enable theMiracast™/Intel’sWiDi settings on the device that you
want to connect to.
3 A list of devices that can be connected to the projector is displayed.
4 Select a device to connect.
5 Select Yes, when the connection request message appears.
6 If the device that you want to connect accepts the request, Miracast™
/Intel’sWiDi is connected.
• When Wi-FiDirect is set to Off, if you set Miracast™/Intel’sWiDi to
On, Wi-FiDirect is automatically set to On.
• When you set the Miracast™/Intel’sWiDi function to Off, Wi-Fi Direct
returns to the previous setting.
72
SMARTSHARE
• It is recommended to connect a laptop using Intel’sWiDi within
close range.
• Though Intel’sWiDi can be connected without a wireless router,
it is recommended to connect the wireless router first for optimal
performance.
• You may not connect your projector to a non-LG Electronics device
even when it is detected.
• It is recommended you to connect a device to a 5 GHz router.
• The response rate may vary depending on the user’s environment.
• For more information on the device you want to connect to, refer to
its owner’s manual.
NOTE
73
SMARTSHARE
ToUseaPremiumService
• (Home) → PREMIUM
• This service gives you easy access to a wide variety of content, such
as video, news, and UCC, at any time, as long as you are connected
to the network. Premium content includes specialized country-specific
services taking regional cultural sensitivities into account as well as
global content.
WEB Movie Map SNS Play
NEWS Comic
Entertainment
Information TV
74
SMARTSHARE
ToUsePaidContent
Some Premium Content is provided as for-fee services. To purchase for-
fee services, use either LG Electronics’ proprietary billing system or that of
each content provider.
If you are using the LG billing system, you can purchase paid content after
signing up for LG Projector.
You can sign up for on the sign-up screen on your projector or the LG
website (www.lgappstv.com). You can then sign into both the projector and
the website with a single ID.
1 Click SignIn button in upper right corner of Home screen to sign in.
2 Move to the desired premium service. (For some premium services,
separate sign-in is required after signing up for the premium service.)
3 After checking the content’s pricing and service information, click the
Purchase button. (There may be limitations on the available period
and number of times depending on content.)
4 Once the purchasing process is completed, view the paid content by
clicking the Buy button.
5 Select your ID on upper menu of Home screen and check history of
purchases from MyPage → Paymentinquiry. It is also available on
My Page → Purchase History of web site (www.lgappstv.com).
75
SMARTSHARE
ToResetPremium
• (Home) → PREMIUM → Option → InitializationofPremium
• Premium list, Premium information, country setting, and user sign-in
information will be reset. When an error occurs during Premium update,
a reset will fix the problem.
• Content on offer by service providers are subject to change to
enhance their service quality or deletion without any prior notice.
Refer to the web site of each content provider for questions,
troubleshooting, or latest information about Content. LG Electronics
does not take any legal responsibility for content services and
related information including discontinuation of service by the service
provider.
• The quality of premium service may be affected by Internet
connections. For any questions related to Internet speed or any
other service problems, contact the Internet service provider.
• For best service quality, subscribe to an Internet service of 4.0 Mbps
(1.5 Mbps or faster). Contact the ISP (Internet service provider) for
any problems related to Internet speed.
• Content providers may make available content that is unsuitable for
minors. Parental discretion is advised.
NOTE
76
SMARTSHARE
ToUseLGSmartWorld
• Select (Home) → MYAPPS→ LGSmartWorld.
LG Smart World is a projector application service available through
Projector Service. You can download and enjoy many different apps (for
fee or free) including education, entertainment, life, and news.
App 1 App 8 App 15
App 2 App 9 App 16
App 3 App 10 App 17
App 4 App 11 App 18
App 5 App 12 App 19
App 6 App 13 App 20
App 7 App 14 App 21
2
1
Description
1
Sign in.
When you sign in, ID is displayed.
When you select the ID, you can select MyPage and SignOut.
2
Select the app to install.
77
SMARTSHARE
ToSignUpWithLGSmartWorld
• (Home) → SignIn
Sign up is required to download and run apps.
1 Select SignUp and agree to Legal Notice.
2 Enter ID and password.
3 In Conrm Password box, enter password again.
4 Select Wheel(OK)
button
to complete sign-up process.
• You can sign up for membership on either your projector or the
website (www.lgappstv.com).
• After signing up for membership, log into your projector and our
website with the same ID.
• You can sign in to up to five projectors with a single ID.
• The website (www.lgappstv.com) is not available in some countries.
NOTE
ToInstallAnAppOnYourProjector
• (Home) → MYAPPS→ LGSmartWorld
Sign up is required to download and run apps.
1 Click the SignIn button at the top of the home screen to log in.
2 Select the LGSmartWorld card.
3 Select an app you want from the list.
4 Check the details of the app, then select the Install or Buy button.
5 Check that you have the functions or projector accessories required to
install the app, then select the Wheel(OK)
button
.
6 For paid apps, payment and purchase authentication is required.
7 Select Run once installation is complete to run the app immediately.
If you do not want to run immediately, select Close. If you want to run
the app later, select MyApps to check the list of apps installed on
projector.
78
SMARTSHARE
• You can purchase apps via PC or Projector, but you must use the
Projector to install and run them.
• If you have insufficient storage space on your Projector, you can
download apps to a USB storage device connected through the
Projector's terminal for USB apps. Apps stored on USB can be run /
deleted / moved from the MyAPPS screen.
• A USB Flash Drive containing apps cannot be used for other data.
(For USB Apps Only)
NOTE
ToManageMyInformation
• (Home) → MYAPPS→ LGSmartWorld
1 Sign in.
2 Select the currently signed-in ID at the top of the screen.
3 Select MyPage.
4 Manages by examining Member Information, My Purchased Apps List,
and Projector Installed Apps List.
Item Description
My
Information
Shows basic information about the ID currently signed
in. To change your member information,
visit www.lgappstv.com on your PC
Payment
Inquiry
Shows Payment History of the signed-in ID.
Purchased
Apps
Shows My Purchased Apps List for the signed-in ID.
You can delete / re-install the purchased apps.
79
SMARTSHARE
ToUseSearchFunction
• (Home) → MYAPPS→ Search
• You can search apps and contents using the Search function of LG
Projector. When you enter keywords using the input device, such as
the remote control, you can find apps of LG Smart World and some
contents of the Premium service. Links are also provided to go for web
search. If you are using SmartShare
TM
, you can also search contents of
SmartShare
TM
. The Search categories and content types vary depending
on the country and will be kept updating.
1
2
3
Description
1
Enter search terms.
2
Category of search results
3
Search results
80
SMARTSHARE
ToUsetheVoiceRecognitionFunction
UsingthisFunctionThroughSearch
1 Go to (Home) → MYAPPS→ Search. Select the voice
recognition icon on the left of the text eld.
2 Speak slowly and clearly after the voice recognition window appears.
3 After the voice recognition is completed, the Similar List window
pops up. If the popup window does not have the results you want,
press Retry to try again. Select the most similar result, then it will be
displayed in the text eld. Press the Search button to get the result you
want.
UsingthisFunctionontheInternet
1 Go to (Home) → INTERNET. Move the Magic Remote Control
pointer in the text eld on a website to open the virtual keyboard.
2 Select the voice recognition icon on the left of the text eld on the
virtual keyboard.
3 Speak slowly and clearly after the voice recognition window appears.
4 After the voice recognition is completed, the Similar List window
pops up. If the pop-up window does not have the results you want,
press Retry to try again. Select the most similar result, then it will be
displayed on the text eld. Press the Search button on the website to
get the result you want.
81
SMARTSHARE
• The website (www.lgappstv.com) is not available in some countries.
• While the recognised result is in the text field, if you retry the voice
recognition function, the previous result will be replaced with the new
one.
• You can use Voice Search when you press the
on the Magic
remote control even if QWERTY keyboard is shown on your screen.
• Check the network connection before using the voice recognition
function.
• It is recommended to use the remote control no further than 10 cm
from your face.
• The voice recognition may fail if you speak too fast or too slowly.
• The recognition rate may vary depending on the user's
characteristics (voice, pronunciation, intonation, and speed) and the
environment (noise and projector volume).
• To change the voice recognition language, go to
(Home) →
SETTINGS→ OPTION→ Language→ VoiceRecognition
Language.
• You can set Avatar to On / Off in
(Home) → SETTINGS→
OPTION→ SeeAvatar.
NOTE
82
SMARTSHARE
ToUseVoiceMateFunction
WhatIsVoiceMate?
Voice Mate allows you to search desirable programs and content with your
voice and adjust the projector.
1 Press the voice recognition button on the magic remote control.
2 When the Voice Display bar is activated on the left of the screen, say
what you want to watch.
3 Press the Wheel(OK) button with the Voice Search standby to see
the supported language in the voice guide.
83
SMARTSHARE
HowtoUseVoiceMate?
• To use all the functions and services of Voice Mate, you need to set
Smart Wizard and Time. Set up the network, region, auto tuning, and
universal remote control through the Smart Wizard.
• In order to use Voice Mate, you must set up the network, time, region,
and tuning.
• Set the language of your country to use Voice Mate.
• You can change the language for Voice Search in (Home)
→ SETTINGS → OPTION → Language → VoiceRecognition
Language.
• You can turn the avatar On/Off in (Home) → SETTINGS →
OPTION → SeeAvatar.
• Point the universal remote control towards the set-top box when you use
Voice Mate with it.
• When speaking a command, hold the remote within 10 cm of your face.
• The voice search may fail when you speak too fast or too slow.
• The recognition rate of Voice Mate may vary depending on the user’s
characteristics (voice, pronunciation, intonation, and speed) and the
environment (noise and projector volume).
• If your voice is not recognized properly, Voice Mate may function in an
unwanted manner.
WhatAreOtherFunctionsofVoiceMate?
You can access various projector features using Voice Mate.
Item Description
Channel
You can tune TV channels and search channel
information.
Recommendation
andSearch
You can recommend and search TV programs
and content les.
Informationand
Internet
You can also search other information such as
today’s weather.
• Available functions may vary depending on the country.
• For more supported examples, see the voice user guide.
84
SMARTSHARE
SeeAvatar
UsingtheAvatar
• (Home) → SETTINGS→ OPTION→ SeeAvatar
You can use the avatar when you use voice recognition. You can check
the voice recognition status via the message from the avatar and it helps
you to enter your speech correctly.
• If you set
SeeAvatar to On, the avatar is activated on the bottom right
of the screen.
• The voice recognition is still supported, even if
SeeAvatar is set to Off.
• The speech balloon guide of
SeeAvatar may vary depending on voice
recognition features, languages, and models.
85
SMARTSHARE
WhatIsOnNow?
On Now allows you to select and watch recommended programs currently
available on your projector. The Favorite function allows you to select and
watch recommended content related to the program you are watching.
• This feature is available in certain countries only.
ToUseOnNow
ToseeinMiniview
1 (Home) → MYAPPS → OnNow
21
Description
1
Refreshes all list items and moves to the beginning of the screen
simultaneously.
2
Moves to Full View.
86
SMARTSHARE
ToSeeinFullView
• (Home) → MYAPPS → OnNow → More
1
2
5
3
4
Description
1
Sign in
2
Search
3
Refreshes all the list items and moves the screen up
simultaneously.
4
Move to Mini view
5
Sets the options.
87
SMARTSHARE
• For TV channels, you need to complete AutoTuning to use this service
properly.
• If you move to a different region, you need to set the region to your
current location in order to use this service.
• The digital EPG (Electronic Program Guide) information which the TV
receives may be different from the programs on the On Now TV list
which uses an external EPG (Electronic Program Guide).
• You can control a connected set-top box tuner with the Magic Remote
Control.
• An internet connection is required to use OnNow.
• The channels in the On Now TV list are provided from the Service
Operator. If the Service Operator changes them without notice, the
actual TV channels may differ.
• The channel names of Service Operator on the On Now TV list are
provided from an external EPG (Electronic Program Guide), so each
name refers a Service Operator but may not match.
• The program thumbnail image on the On Now TV list is the
representative image of the program, and it may be different from the
image of the actual TV program schedule.
• If the channel information on the On Now TV list is different from the
actual TV channel, set the channel menu in the OnNow Settings.
• The On Now function recommends content based on real-time ratings,
and certain content with low ratings may not be displayed.
• A scrambled channel may be displayed occasionally, depending on the
TV signal type.
• The On Now function may not work with some set-top box models.
• If you experience problems with settings or operation, please tell us the
name of your set-top box model on our website (http://www.lgappstv.
com/ur_support) so that we can take action to provide appropriate
support.
88
SMARTSHARE
ToUseInternet
• (Home) → INTERNET
• Types URL manually on projector or visits websites added to favorite.
2
1
3
Description
1
Types in the web address.
2
Chooses when you open several web browsers.
3
Add the current page to favorites.
• Internet supports up to Flash 11 but does not support platform-
dependent technology like ActiveX.
• Internet only works with a pre-installed plug-in.
• Internet may not play any media file format other than the following:
JPEG / PNG / GIF
• Internet will be forcibly closed when there is insufficient memory.
• For the Internet, fonts installed on the projector are used and may not be
displayed normally depending upon the content played.
• Internet does not support file and font download.
• Internet is made for projector so it may function differently than browsers
made for PC.
• Internet is a projector browser and may not work properly when playing
some content files.
89
SMARTSHARE
FrequentlyAskedQuestionsforProjector
Sign up is required to use LG Smart World.
You can sign up on either your projector or the LG website
(www.lgappstv.com). Free apps are available immediately after signing up.
You can purchase paid apps using your credit card registered with the
website or credits. Paid apps can also be purchased through carrier billing.
Problem Solution
Whenentering
menu,theInitializing
messagealways
appears.
• The Initializing message shows you how
long it takes to reboot the microprocessor
and hardware, set up network
communications, and communications
with SDP (device authentication and basic
information download). It takes about 20
seconds and this is a normal process.
Thereisnocontent
shownonthe
Premiumcard.
• Content may not be shown after changing
the country setting on projector. Change to
desired country in
(Home) → SETTINGS → OPTION →
ServiceCountrySetting
Whileusinginternet
features,thereis
ablankspaceon
someWebpages.
• The internet of the Projector supports up to
Flash 11 and may not replay any file format
other than the following: JPEG, PNG, GIF
Internetcloses
automaticallywhen
visitingwebsite.
• If memory is insufficient because of large
volume of image information in the web
page, the browser may be forced to close.
Ialreadysignedup
onprojector.Do
Ineedtosignup
againatwebsite
(www.lgappstv.com)?
• If you sign up on your projector, no
additional sign-up on the LG website
(www.lgappstv.com) is required.
• After signing up on the projector, you can
sign into the website by using the same ID
and password and entering the additional
information to complete the email verification
process.
90
SMARTSHARE
Problem Solution
Caneachfamily
memberusea
differentIDwitha
singleprojector?
• It is possible to register and use more than
one ID on one projector.
• To check the ID registered with Projector
from (Home) → SignIn → IDList.
• You can check the list of apps purchased
by each ID. However, you can see all apps
installed by each ID in
(Home) → SignIn → MyPage.
WhatshouldIdoifI
forgetmyID?
• After signing up on a PC, use the Forgot
ID? feature on web site (www.lgappstv.com)
when needed.
• After signing up on projector, check it from
(Home) → SignIn → FindID.
Ipurchasedanapp
fromtheLGwebsite
(www.lgappstv.com).
HowcanIuseiton
theprojector?
• To check purchased apps from the
projector, sign in and open the Purchased
Apps menu.
• Select the ID at the top of Home and check
the app in MyPage → Purchasedapps.
CanIseehistoryof
mypurchasedapps?
• Select the ID at the top of Home and check
the app in MyPage → Purchasedapps.
• Sign in to website (www.lgappstv.com) and
then select MyPage → PurchaseHistory.
Ideletedapaid
app.DoIhaveto
purchaseagainto
downloadit?
• If a purchased app is accidentally deleted, you
can download and reinstall it without having to
buy it again, as long as it is still in service.
• Select the ID at the top of Home and re-
download apps in MyPage → Purchased
apps. (Previously owned apps may not be
re-downloaded or run, depending upon the
software version.)
91
SMARTSHARE
Problem Solution
CanIuseappsfrom
LGProjector’sLG
SmartWorldonboth
aprojectoranda
PC?
• Please check if the projector model supports
LG Smart World.
• The apps provided from LG Projector's LG
Smart World can be used only on an LG
Projector.
• Apps may be purchased from the website
(www. lgappstv.com) but cannot be used on
a PC or Mac. Use care when purchasing.
HowcanIcheckthe
IDcurrentlysigned
inontheprojector?
• Select the ID at the top of Home and check
the currently signed-in ID in MyPage → My
Information.
Iinstalledanappon
theprojector.Where
canIcheckthe
installedapp?
• Select (Home) → MYAPPS. All paid
and free apps installed on Projector are
displayed.
Thereisadifference
betweentheappsize
shownonthescreen
andtheactualapp
sizeinstalledon
projector.
• The app size shown in the screen includes
the additional space needed for installing
apps so it may be different from actually
installed app size.
Iforgotmy
passwordonthe
projector.What
shouldIdo?
• If you only provide the ID and password
when signing up on your projector, you
cannot recover your password when it is
lost. Create a new ID and sign up with the
ID.
• If you provide other information than the
ID and password when signing up on your
projector or the LG website
(www.lgappstv.com), you can recover your
password on the website.
92
SMARTSHARE
Problem Solution
DoIneedtostore
paymentinformation
inwebsiteto
purchasepaidapps?
• The following payment methods are
available to purchase paid apps on your
projector: credit card, credits, and carrier
billing.
• To purchase paid apps using your credit
card or credits, you should have a credit
card registered with the LG website
(www.lgappstv.com) or have enough credits.
Paid apps can also be purchased through
carrier billing if your credit card details are
not registered with the website or you do
have enough credits. If you purchase paid
apps on the website, the following payment
methods are available: credit card or credits.
CanIcancelan
appthatIhave
purchased?
• As a member, you cannot demand refund
just because you changed your mind after
purchase.
• If there is a defect in the product or a
problem of using the product, which is
not your fault, you can ask for a refund.
However, the valid reason for refund must
be provided.
ShouldIuseonlyan
emailaddressfor
myID?
• For new sign-up members, the ID format
has changed from a combination of
alphanumerics to your email address.
• You can only use an email address for your
ID when signing up.
DoIneedtochange
myIDformattothe
emailaddress?
• For new sign-up members, the ID format
has changed from a combination of
numbers and alphabets to the email
address.
• If you are already a member, you can still
use your existing ID or change it to the email
address.
93
SMARTSHARE
Problem Solution
WhatistheLG
account?
• The LG account allows you to sign into all
of the LG Smart service with a single ID
and password. You can use the following
services with your LG account:
LG Projector, LG Smart World (excluding
some countries), LG Smart ThinQ, and LG
Smart air conditioning, etc.
Additional information may be required
depending on the service.
94
USINGADVANCEDFUNCTIONS
USINGADVANCEDFUNCTIONS
ToUseScreenRemote
• This feature is available in certain countries only.
ToUseScreenRemote
Press the button on the magic remote control.
Select a button on the screen remote displayed on the screen using the
magic remote control.
• The type of buttons on the screen remote varies depending on the
region or the type of a connected device.
• Image shown may differ from your projector.
Exits the Screen
Remote
Moves the
position of the
Screen Remote
to left or right
TV operation
buttons
Change
Device tab
95
USINGADVANCEDFUNCTIONS
ToControlaDeviceConnectedtotheProjectorUsing
theScreenRemote
You can control a device connected via SIMPLINK or MHL using the
Screen Remote.
1 Check if the device is connected to the Projector.
2 After pressing the button on the magic remote control, select
the device you want to control in the Change Device tab. The screen
remote that can control the device appears.
– This may not work with some buttons.
ToUsetheUniversalControlfunction
• This feature is available in certain countries only.
With the Magic Remote control, you can control a set-top box, Blu-ray
player, home theater system, etc.
1 Check if a device you want to set is connected to your projector.
2 After pressing the button on the Magic Remote control, select
the icon of a device you want in the change device tab.
If there is no device you want, press the on the tab, and select the
external device you want. Once the setup is complete, the name of the
selected device is displayed in the Change Device tab.
3 When you select a device you want in the Change Device tab, the
Screen Remote that can control the device appears on the screen.
To see more control buttons, select at the bottom of the Screen
Remote.
96
USINGADVANCEDFUNCTIONS
TochangeorcleartheUniversalControlsettings
1 After pressing the button on the magic remote control, select the
(TV/input selection) button.
2 Select ChangeSetting or CancelSetting at the bottom of the device
to be changed.
• When change setting, check if the power of the device to be changed is
turned on.
• You can set one device per type.
• With the screen remote, you can only control the devices of a brand or
manufacturer that you can select in the setup screen.
• If you connect to a network before setting the universal remote control,
update for the latest manufacturer list is available.
• Some buttons may not work depending on the external device model.
• Place the device near the projector for seamless operation.
• If the device is in a drawer, open the drawer.
• Go to (Home) → MYAPPS → UniversalControl or (Home) →
INPUTLIST → SettheUniversalControl and add, delete, or change
a device.
• Please be advised that the channel tuning feature may not work properly
if you have already manually assigned channel numbers that differ from
the original set-top box channel numbers.
97
USINGADVANCEDFUNCTIONS
ToUseaUSBInputDeviceOnaProjector
ToUseaUSBWired/wirelessMouse
Connect your mouse to the USB port. Use the mouse to move the pointer
on the Projector screen and select the menu you want.
Mouse MagicRemoteControl
LeftButton OK Button on Magic Remote Control
WheelButton Wheel Button on Magic Remote Control
• The right mouse button and any special buttons will not work with the
Projector.
• The usability of a wireless USB mouse and keyboard may be affected by
the radio frequency environment and the distance.
ToUseaUSBWired/wirelessKeyboard
Connect your keyboard to the USB port. You can enter text with the
keyboard when using the search function and the Internet.
• Text cannot be entered on some screens.
• It is recommended to use a product which is tested for compatibility with
the LG Projector.
LOGITECH K200, LOGITECH K400, MICROSOFT Comfort Curve
2000, MICROSOFT MS800, and LG Electronics ST-800
• You can change the input language by pressing the language switch key
(or the right Alt key) on your keyboard.
98
CUSTOMIZINGSETTINGS
CUSTOMIZINGSETTINGS
SETTINGS
1 Press the (Home) button and select SETTINGS.
2 Use the or button to select the desired item and press the
Wheel(OK) button.
3 Use the , , , or button to set up the desired item and press
the Wheel(OK) button.
4 Press the button when completed.
Menu Description
PICTURE Adjusts the image quality for optimal viewing.
SOUND Adjusts the sound quality and volume level.
CHANNEL Sets up or edits a channel.
TIME Sets the time and time-related features.
LOCK Locks or unlocks a channel or a program.
OPTION Customizes the general settings.
NETWORK Sets the network.
SUPPORT Shows the projector information.
99
CUSTOMIZINGSETTINGS
PICTURESettings
1 Press the (Home) button
and select SETTINGS.
2 Use the or buttons to
select PICTURE and press the
Wheel(OK) button.
3 Use the , , , or
button to set up the desired item
and press the Wheel(OK)
button.
– To return to the previous
menu, press the button.
The available picture settings are described as follows.
Menu Description
EnergySaving
Reduces power consumption by adjusting peak
screen brightness.
MODE
Minimum/
Medium/
Maximum
Applies the pre-set
EnergySaving
mode.
– If EnergySaving is set to
Minimum and the ambient
temperature is 35 °C or higher,
EnergySaving will be disabled.
100
CUSTOMIZINGSETTINGS
Menu Description
PictureMode
Selects the picture mode optimized for the viewing
environment or the program. You can also
customize advanced options for each mode.
MODE
Vivid
Maximizes the visual effect of video.
Heightens contrast, brightness, and
sharpness to display vivid images.
Standard
Displays images in standard levels of
contrast, brightness, and sharpness.
Cinema Optimizes the image for a movie.
Sport
Optimised picture mode for sport.
The pitch and kits are presented
in vibrant colors, with crystal-clear
images even for fast movements.
Game
Optimizes the image for playing
games on fast-moving screens.
Expert1/
Expert2
Menu for adjusting picture quality
that allows experts and amateurs to
enjoy the best projector viewing.
– Expert mode is for picture tuning
professionals to control and ne-
tune using a specic image. For
normal images, the effects may
not be dramatic.
Contrast
Adjusts the difference between bright and dark
regions of the screen.
Brightness Adjusts the overall screen brightness.
Sharpness
Adjusts the sharpness of the borders between
bright and dark. Horizontal and Vertical Sharpness
are available only in Expert1/Expert2.
Color Adjusts the colors on the screen darker or lighter.
Tint Adjusts the red/green color balance.
Advanced
Control(Expert
Control)
Customizes the advanced settings.
101
CUSTOMIZINGSETTINGS
Menu Description
PictureOption Sets optional settings.
PictureReset
Resets values customized by the user.
Each picture mode is reset. Select the picture mode
you wish to reset.
3D You can set the 3D mode On or Off.
3DSettings
Adjusts various aspects of 3D imaging.
Mode
3DMode
Provides the appropriate 3D depth.
• 3DDepth: Adjust 3D depth
between the foreground object(s)
and the background.
• 3DViewpoint: 3D image can be
made closer or farther from user.
3DSound
Zooming
Provides 3D-optimized sound.
3DPattern
Recognition
This will activate and deactivate 3D
mode automatically based on the
input.
Normal
ImageView
This will down-convert a 3D signal
to 2D.
3DImage
Correction
Switches the left/right images of 3D
video.
AspectRatio
Resizes the picture.
PictureWizard
III
Use the remote control and follow the instructions
of the Picture Wizard to calibrate and adjust for
optimum picture quality without expensive pattern
devices or help from a specialist. Follow the
instructions to obtain the optimum picture quality.
102
CUSTOMIZINGSETTINGS
AdvancedControl
Menu Description
Dynamic
Contrast
Adjusts contrast and color to the optimal level according
to the screen’s brightness.
Dynamic
Color
Adjusts colors for more natural-looking colors.
Color
Gamut
Selects the range of colors that can be expressed.
• Standard: Displays the original colors of an input
signal regardless of the display features.
• Wide: Makes use of the display's rich colors.
Preferred
Color
SkinColor
Skin color spectrum can be separately
set to implement the skin color as
dened by the user.
GrassColor
Natural color spectrum (meadows, hills,
etc.) can be set separately.
SkyColor Sky color is set separately.
Super
Resolution
Provides a crystal-clear picture by improving the details
in areas where the picture is blurry or unclear.
Gamma
Sets the gradation curve according to the output of the
picture signal in relation to the input signal.
103
CUSTOMIZINGSETTINGS
ExpertControl
Menu Description
Dynamic
Contrast
Adjusts contrast and color to the optimal level
according to the screen’s brightness.
Super
Resolution
Provides a crystal-clear picture by improving the
details in areas where the picture is blurry or unclear.
ColorGamut
Selects the range of colors that can be expressed.
• Standard: Displays the original colors of an input
signal regardless of the display features.
• Wide: Makes use of the display's rich colors.
Edge
Enhancer
Shows clearer and distinctive yet natural edges of
the video.
ColorFilter
Filters a specic color spectrum in RGB colors to
ne-tune color saturation and hue accurately.
ExpertPattern Patterns used for expert adjustment.
Gamma
Sets the gradation curve according to the output of
the picture signal in relation to the input signal.
104
CUSTOMIZINGSETTINGS
Menu Description
WhiteBalance
Adjusts white balance. Detailed adjustment is
possible as shown below.
a. Method2Points
– Pattern Inner,Outer
– PointsLow,High
– Red/Green/Blue The adjustment range for
each color is from -50 to +50.
– Applytoallinputs The values of the White
Balance is applied to all the input modes.
b.Method20PointIRE
– PatternInner,Outer
– IRE(InstituteofRadioEngineers) is the unit
indicating the size of a video signal and can
be set to 5,10,15, ... 100.You can ne-tune for
each setting as shown below.
– Red/Green/Blue The adjustment range is -50
to +50.
– Applytoallinputs The values of the White
Balance is applied to all the input modes.
Color
Management
System
Adjusts Red/Green/Blue/Cyan/Magenta/Yellow
colors. Allows an expert to adjust the tint using a test
pattern. Six colors (Red/Green/Blue/Cyan/Magenta/
Yellow) can be selectively adjusted without affecting
other colors. You may not see colors change on a
normal picture even after adjustment.
– SaturationRed/Green/Blue/Cyan/Magenta/
Yellow,
TintRed/Green/Blue/Cyan/Magenta/Yellow,
LuminanceRed/Green/Blue/Cyan/Magenta/
Yellow:
The adjustment range is -30 to +30 each.
* Depending on input signal or other picture settings, the range of detailed
items for adjustment may differ.
105
CUSTOMIZINGSETTINGS
PictureOption
Menu Description
NoiseReduction Reduces screen noise in the video.
MPEGNoise
Reduction
Eliminates noise generated while creating digital
picture signals.
BlackLevel
Adjusts the brightness or darkness of the screen
to suit the black level of the picture input using the
degree of darkness (black level) of the screen.
RealCinema Optimizes the screen for movie viewing.
TruMotion
Corrects images to display smoother motion
sequences.
Mode
Smooth De-Judder value is set to 3.
Clear De-Judder value is set to 7.
User
De-Judder can be set manually.
• De-Judder This function adjusts
juddering of the screen.
Off De-Judder value is set to 0.
Color
Temperature
Adjusts the overall color of the screen to suit your
preference.
Select Warm, Natural, Cool, or Medium.
* If the video signal is 60 Hz, TruMotion may not work.
106
CUSTOMIZINGSETTINGS
SOUNDSettings
1 Press the (Home) button
and select SETTINGS.
2 Use the or buttons to
select SOUND and press the
Wheel(OK) button.
3 Use the , , , or
button to set up the desired item
and press the Wheel(OK)
button.
– To return to the previous
menu, press the button.
The available sound settings are described as follows.
Menu Description
Smart
Sound
Mode
Provides the optimized sound adjusted for each content
type.
• If the SmartSoundMode function is enabled, Sound
Mode, VirtualSurroundPlus and ClearVoicell are
automatically adjusted.
Sound
Mode
Sets the sound mode.
Mode
Standard Suitable for all types of video.
News/Music
/Cinema/
Sport/Game
Sets audio optimized for a specic genre.
UserSetting
Adjusts volume level.
• 100Hz/ 300Hz/ 1kHz/ 3kHz/
10kHz: Sets EQ by manual
adjustment of sound bands.
• Reset: Resets the equalizer value
changed by the user.
107
CUSTOMIZINGSETTINGS
Menu Description
Virtual
Surround
Plus
Provides realistic 5.1 channel stereo sound from two
speakers.
• If ClearVoicell is set to On, VirtualSurroundplus
will not be chosen.
Clear
VoiceII
Boosts voice clarity.
Volume
Mode
Sets various modes for volume control.
Mode
AutoVolume
Sets AutoVolume to On. The volume
varies from channel to channel and
program to program. When clicking
through the channels, the volume is
adjusted automatically to maintain the
same level.
SoundOut
Sets the audio output of the projector.
Mode
Projector
Speaker
Sound is output through the projector
speaker.
External
Speaker
(Optical/
HDMIARC)
Sound is output through the speaker
connected to the optical port. SIMPLINK
is supported.
• DigitalSoundOut Sets up Digital
Sound Output.
LGSound
Sync
(Optical)
Sound is output through an LG audio
device connected to the OPTICAL
DIGITALAUDIOOUTPUT port.
Bluetooth
Sound output is through the Bluetooth
device.
Headphone
Sound is output through headphones.
• Headphones are detected and
connected automatically when the
projector is on.
108
CUSTOMIZINGSETTINGS
Menu Description
AVSync.
Adjust
Synchronizes video and audio directly when they do
not match. If you set AVSync.Adjust to ON, you can
adjust the sound output (projector speaker, SPDIF, or
Bluetooth) to the screen image.
Mode
Projector
Speaker
Adjusts the synchronization of the
sound from the projector's internal
speakers.
The + and - buttons allow the viewer to
synchronize the audio with the video.
External
Speaker
Adjusts how the sound is synced to
external speakers, such as an external
speaker connected to the digital audio
output port, LG audio device, projector
speaker, SPDIF, and headphone.
The + and - buttons allow the viewer to
synchronize the audio with the video.
Bluetooth
Adjusts the synchronization between the
video and the Bluetooth device sound.
– This feature is only available when a
Bluetooth device is connected.
– Audio sync may vary by
manufacturer.
– When playing video and music from
a connected USB drive, AVSync.
Adjust can also be adjusted using
the SetAudio. menu.
Bypass
Outputs broadcasting signals or the
audio of an external device without
audio delay. Audio may be output
before video as it takes time to process
video input into the projector.
Sound
Option
Setting
Balance Adjusts left/right audio balance.
109
CUSTOMIZINGSETTINGS
CHANNELSettings
1 Press the (Home) button
and select SETTINGS.
2 Use the or button to select
CHANNEL and press the
Wheel(OK) button.
3 Use the , , , or
button to set up the desired item
and press the Wheel(OK)
button.
– To return to the previous
menu, press the button.
The available channel settings are described as follows.
Menu Description
Auto
Tuning
Remembers a channel which is currently broadcasting.
You should use this function when you move to another
house or move the projector to other place. It must be used
while the antenna is connected and there are channel
broadcasting signals.
• Channels are not registered properly unless the antenna/
cable is connected correctly.
• AutoTuning finds only programs that are currently
broadcasting.
• If LockSystem is turned on, a pop-up window will
appear asking for password.
Manual
Tuning
Adjusts programs manually and saves the results.
For digital broadcasting, signal strength, and signal quality
can be checked.
Channel
Edit
Edits the saved channels.
Set as favorite channel, block/unblock channel, delete
channel etc., of the selected channel.
110
CUSTOMIZINGSETTINGS
TIMESettings
1 Press the (Home) button
and select SETTINGS.
2 Use the or button to select
TIME and press the Wheel
(OK) button.
3 Use the , , , or
button to set up the desired item
and press the Wheel(OK)
button.
– To return to the previous
menu, press the button.
The available time settings are described as follows.
Menu Description
Clock
Checks or changes the time while watching projector.
Mode
Auto
Synchronizes the projector clock to the digital
time information sent by the TV station.
Manual
Sets the time and date manually if the auto
setup does not correspond to the current
time.
OffTime/
OnTime
Sets On/Off time. Select Off on Repeat to discontinue
OnTime/OffTime.
• To use OnTime/OffTime, set the current time
correctly.
• Even when the OnTime function is on, the projector
will turn off automatically in 120 minutes when no
button is pressed within that time.
Sleep
Timer
Turns off the projector after a preset number of minutes.
To cancel the SleepTimer, select Off.
AutoOff
If there is no input signal or button press, the projector
automatically turns off after the preset time has elapsed.
Automatic
Standby
If you do not press any button on the projector or
remote control for a certain period, the projector will
automatically turns off.
111
CUSTOMIZINGSETTINGS
LOCKSettings
• The illustration of the menu may differ from the actual screen on the
product. (Depending on country.)
1 Press the (Home) button
and select SETTINGS.
2 Use the or button to select
LOCK and press the Wheel
(OK) button.
– To enter the LOCK menu,
enter the preset 4-digit
password. The initial
password is set as 0000.
3 Use the , , , or
button to set up the desired item
and press the Wheel(OK)
button.
– To return to the previous
menu, press the button.
The available lock settings are described as follows.
Menu Description
Set
Password
Sets or changes projector password.
• The initial password is set as 0000.
Lock
System
Permits only specic programs by blocking channels or
external input.
Select the LockSystem to On.
• This feature is available in certain countries only.
Item
Block
Channel
Blocks the programs that contain
inappropriate contents for children.
The programs can be selected but
the screen is blank and the audio is
muted. To watch a locked program,
enter the password.
112
CUSTOMIZINGSETTINGS
Menu Description
Lock
System
MovieRating
Blocks the movies that are only
broadcast on the TV and contain
inappropriate contents, based on the
Motion Picture Association of America
(MPAA) rating.
• G (General audiences) All ages
admitted
• PG (Parental guidance suggested)
Some material may not be suitable
for children
• PG-13 (Patents strongly cautioned)
Some material may be inappropriate
for children under 13
• R (Restricted) Under 17 requires
accompanying parent or adult
guardian
• NC-17 No one 17 and under
admitted.
• X Adults only
TVRating-
Children
Blocks the children’s TV programs that
parents do not want their children to
watch. To block other TV programs,
you should set the TV Rating-General
feature.
• Age TV-Y (All children, including
children from ages 2-6), TV-Y7
(Directed to older children, suitable
for children age 6 and above)
• FantasyViolence TY-Y7 (Directed
to older children - Fantasy violence,
suitable for children age 6 and
above, containing more intense or
combative fantasy violence)
113
CUSTOMIZINGSETTINGS
Menu Description
Lock
System
TVRating-
General
Blocks the TV programs that you want
based on the ratings by using the
Parental Control Function (V-Chip).
The V-Chip electronically reads TV
program ratings and allows parents to
block program that are unsuitable for
children.
• Age TV-G (General audience,
suitable for all ages) TV-PG
(Parental guidance suggested,
containing material that are
unsuitable for younger children)
TV-14 (Parents strongly cautioned,
containing material that are
unsuitable for children age 14 and
under) TV-MA (Mature audience
only, unsuitable for children age
• Dialogue (suggestive dialogue)
TV-PG or TV-14
• Language (coarse language)
TV-PG, TV-14, or TV-MA
• Sex (sexual situation) TV-PG,
TV-14, or TV-MA
• Violence TV-PG, TV-14, or TV-MA
Downloadable
Rating
This function operates only when TV
has received Region 5 Rating data.
The name of the rating option may
differ.
InputBlock Block the input sources.
Application
Lock
Lock the application.
114
CUSTOMIZINGSETTINGS
Menu Description
Lock
System
TVRating-
English
Selecting Canadian English rating
system.
• This feature is available in certain
countries only.
• E : Exempt
• C : Children
• C8+ : Children eight years and older
• G : General programming, suitable
for all audiences
• PG : Parental Guidance
• 14+ : Viewers 14 years and older
• 18+ : Adult programming
• BlockingOff : Permits all programs
TVRating-
French
Selecting Canadian French rating
system.
• This feature is available in certain
countries only.
• E : Exempt
• G : General
• 8ans+ : General-Not convenient for
little children
• 13ans+ : Not convenient for children
of 13 years and younger
• 16ans+ : Not convenient for children
of 16 years and younger
• 18ans+ : This programs is only for
adults
• BlockingOff : Permits all programs
115
CUSTOMIZINGSETTINGS
OPTIONSettings
• The illustration of the menu may differ from the actual screen on the
product. (Depending on country.)
1 Press the (Home) button
and select SETTINGS.
2 Use the or button to select
OPTION and press the
Wheel(OK) button.
3 Use the , , , or
button to set up the desired item
and press the Wheel(OK)
button.
– To return to the previous
menu, press the button.
The available option settings are described as follows.
Menu Description
Language
Selects MenuLanguage, AudioLanguage and Voice
RecognitionLanguage displayed on the screen.
Item
Menu
Language
Selects a screen menu language.
Audio
Language
Selects the desired language when
watching digital broadcasting containing
several audio languages. (In digital
mode only)
Voice
Recognition
Language
Select the language to make voice
search.
116
CUSTOMIZINGSETTINGS
Menu Description
Service
Country
Setting
You can change the country setting of your smart
projector. The premium service and LG Smart World
that are available for the country you selected will be
provided.
• If a network is disconnected while setting the service
country, it may not be set properly.
Item
Auto
Setting
A service country is automatically set for
your smart projector.
Manual
Setting
A service country can be set manually
for your smart projector.
ZIPCode
You can check the information of area when network is
connected.
• This feature is available in certain countries only.
• This function sets your area as the ZIP Code.
• You can check the information of area when network
is connected.
Caption
View subtitles when the TV station provides subtitled
programing. Program subtitles work only on digital/
analog broadcasts or external input.
Change Caption to On and select caption setting.
Mode
CC1-4 (Closed Captioning) / Text1-4
Displays the audio portion of a TV
program as text on the TV screen. CC1
is the most common mode in use.
Field 1 data channels: two Captions
(CC1, CC2), two Text (Text1, Text2).
Field 2 data channels: two Captions
(CC3, CC4), two Text (Text3, Text4).
Service1-6
This is only available for the digital
broadcasting system.
117
CUSTOMIZINGSETTINGS
Menu Description
Caption
Digital
Option
Set up the size and color of the subtitles
on DigitalOption. Please select Setby
Program or Custom.
Select Custom to adjust minute options
such as the subtitles’ size and color.
Item
Size Selects the word size.
Font
Selects a typeface for
the text.
TextColor
Selects a color for the
text.
Text
Opacity
Adjusts the opacity for
the text color.
BgColor
Selects a color for the
background color.
BgOpacity
Adjusts the opacity for
the background color.
EdgeType Selects an edge type.
EdgeColor
Selects a color for the
edges.
Window
Color
Selects a color for the
window color.
Window
Opacity
Adjust the opacity for the
window color.
Setthe
Universal
Control
With the magic remote control, you can control a set-top
box, Bluray player, home theater system, etc.
• This feature is available in certain countries only.
118
CUSTOMIZINGSETTINGS
Menu Description
Pointer
Sets the speed and shape of the pointer that appears
on the projector screen.
Speed Sets the moving speed of the pointer.
Shape
Selects a pointer shape from various
options.
Size Chooses the size of the pointer.
Alignment
Set to On. If there is any misalignment
between the pointer and the actual
direction the remote control indicates,
move the Magic Remote control left
and right to realign. The pointer will
automatically realign to the center,
making it easier to control.
• If it is set to Off, the alignment
function will not work even when you
move the magic remote control left
and right.
PJTMode
This function turns the projected image upside down or
ips horizontal.
Auto
Keystone
(Vertical)
AutoKeystone(Vertical) provides a rectangular screen
image by automatically adjusting the keystone number
when there is a trapezoidal screen image caused by
tilting of the projector.
When using AutoKeystone(Vertical), the current
value set for EdgeAdj is changed to the value that has
been set with AutoKeystone(Vertical).
Item
On
Automatically adjusts the keystone
number.
Off Manually adjusts the keystone number.
EdgeAdj
To prevent the screen image from becoming
trapezoidal, EdgeAdj adjusts the top and bottom width
of the image if the projector is not set at a right angle to
the screen.
119
CUSTOMIZINGSETTINGS
Menu Description
AutoPower
Makes the projector turn on automatically when the
power code is connected to the projector.
Item
On
When the power code is connected to
the projector, it turns on automatically.
Off
When the power code is connected to
the projector, it goes into standby mode.
High
Altitude
If the projector is used at an altitude higher than
1200 meters, turn this on.
Otherwise, the projector may overheat or its protection
function may be activated. If this happens, turn the
projector off and then on again after waiting for several
minutes.
AutoInput
Search
Automatically searches for and displays the input signal
type when it is received. It is available only with external
inputs (HDMI, AV, and Component).
Balloon
Help
Enables/disables the balloon help.
Control
DeviceList
Displays the list of control devices connected to the
projector.
SeeAvatar Turns the Avatar function on or off.
Initial
Setting
Deletes all optional settings and returns to initial default
mode. Once initialization is complete, the projector will
turn off and on by itself.
• If LockSystem is activated, a pop-up password
prompt will appear.
• Do not turn off the power during initialization.
Mode
Setting
Selects Standard or Store. For use at home, select
Standard. Store is a mode used for store display.
120
CUSTOMIZINGSETTINGS
NETWORKSettings
1 Press the (Home) button
and select SETTINGS.
2 Use the or button to select
NETWORK and press the
Wheel(OK) button.
3 Use the , , , or
button to set up the desired item
and press the Wheel(OK)
button.
– To return to the previous
menu, press the button.
The available network settings are described as follows.
Menu Description
Network
Connection
Connects a network.
Network
Status
Displays the connection status of the network.
121
CUSTOMIZINGSETTINGS
Menu Description
SoftAP
This function allows you to change a wired Internet
connection to your projector to Wi-Fi, allowing you to
connect various external devices or to use wireless
Internet.
SoftAP Sets to On/Off.
Security
Key
Sets the Wi-Fi security number.
• You can set the security key with a
combination of English letters and
numbers between 8 and 64 characters
long.
• The default setting is LG123456.
• To enable the SoftAPfunction, your projector must
be turned on and have a wired Internet connection.
• Up to four external devices can be connected.
• If the SoftAP function is enabled, the Wi-FiDirect
and Miracast
TM
functions become unavailable. You
must set the SoftAP function to Off to use the Wi-Fi
Direct and Miracast
TM
functions.
Wi-FiDirect
Wi-FiDirect is a function that allows your projector
to connect with a Wi-Fi Direct device without Internet
connection.
Miracast
TM
/
Intel'sWiDi
The Miracast
TM
allows you to enjoy video and audio
from a portable device through the projector wirelessly.
Intel'sWiDi allows you to view a laptop screen through
the projector without a cable.
My
Projector
Name
Changes the name that appears when searching for the
projector from other devices.
122
CUSTOMIZINGSETTINGS
SUPPORT
• The illustration of the menu may differ from the actual screen on the
product. (Depending on country.)
1 Press the (Home) button
and select SETTINGS.
2 Use the or button to select
SUPPORT and press the
Wheel(OK) button.
3 Use the , , , or
button to set up the desired item
and press the Wheel(OK)
button.
– To return to the previous
menu, press the button.
The available support settings are described as follows.
Menu Description
Software
Update
Updates to the latest software.
PictureTest Check whether a video signal is properly displayed.
SoundTest Check whether an audio signal is properly output.
3DPicture
Test
Check whether an 3D picture signal is properly output.
123
CUSTOMIZINGSETTINGS
Menu Description
Product/
ServiceInfo.
Shows the product/service information.
LGRemote
Projector
Service
Remotely solve any question following an update by
contacting the Service Center staff by phone.
Initialization
ofApp
If problems occur after updates, try initializing the
system.
• During initialization, the projector will restart
automatically.
Legal
Documents
You can check the contents of LegalDocuments and
you can make a choice whether to agree or withdraw
your consent to LegalDocuments.
Self
Diagnosis
Troubleshoots functional problems that can arise while
using the product.
124
CONNECTINGDEVICES
CONNECTINGDEVICES
You can connect various external devices to the projector.
Computer/Notebook
DigitalDevice
Headphone
USB
MobilePhone
Video/DVD
LGAudioDevice
Games
Console
HDMI - Page 125
Composite (AV) - Page 126
Component - Page 127
USB Device - Page 60
Headphone - Page 130
Digital Amp - Page 131
Mobile Phone (MHL) - Page 132
125
CONNECTINGDEVICES
ConnectingtoHD
Receiver,DVD,or
VCRPlayer,External
Devices
Connect an HD receiver, DVD,
VCR player, or external devices
to the projector and select an
appropriate input mode.
HDMIConnection
With an HDMI cable, you can enjoy
high quality picture and sound.
Using a HDMI cable, connect the
port of the projector
to the HDMI output port of the
device to connect. Both video and
audio are output at the same time.
You can also use the .
Press the INPUT button on the
remote control to select HDMI.
You can connect with any HDMI
input port.
Optional Extras
ARC(AudioReturnChannel)
• External audio devices that
support SIMPLINK and ARC
must be connected using
port.
• When connected with a
high-speed HDMI
®
cable,
external audio devices
that support ARC output
or SPDIF work with the
SIMPLINK function without
the need for an additional
optical audio cable.
NOTE
126
CONNECTINGDEVICES
HDMItoDVIConnection
Using an HDMI to DVI cable,
connect the projector's
port to the DVI OUT
port.
To output audio, use an audio
cable for connection.
You can also
use the .
Press the
INPUT
button on the
remote control to select HDMI.
You can connect with any HDMI
input port.
DVI OUTAUDIO OUT
Optional
Extras
Not
provided
AVConnection
Connect the output ports of an
external device and the AVIN
ports of the projector using an AV
cable. Press the INPUT button on
the remote control to select AV.
Check whether cables of the same
color are connected properly.
Accessories
Not
provided
Red Red
Red
White
White
White
Yellow Yellow
Yellow
127
CONNECTINGDEVICES
ComponentConnection
You can enjoy a video by
connecting the component port
of an external device to the
COMPONENTIN port of the
projector. Press the INPUT button
on the remote control to select
Component. Check whether
cables of the same color are
connected properly.
A)
Optional
Extras
Accessories
Not
provided
Not
provided
Red
Red
Red
Red
Red
Red
Blue
Blue
Blue
Green
Green
Green
White
Yellow
White
White
B)
VIDEO OUT
Accessories
Not
provided
Not
provided
Red
Yellow
Red
Red
Red
Blue
Blue
White
Green
Green
White
128
CONNECTINGDEVICES
ConnectingaPC
The projector supports Plug and
Play. Your PC will automatically
detect the projector and requires
no driver installation.
HDMIConnection
Using an HDMI cable, connect the
port of the projector to
the HDMI output port of your PC.
Both video and audio are output at
the same time.
You can also use
the .
Press the INPUT button on the
remote control to select HDMI.
You can connect with any HDMI
input port.
Optional Extras
HDMItoDVIConnection
Using an HDMI to DVI cable,
connect the projector's
port to the DVI OUT
port.
To output audio, use an audio
cable for connection.
You can also
use the .
Press the
INPUT
button on the
remote control to select HDMI. You
can connect with any HDMI input
port.
DVI OUTAUDIO OUT
Optional
Extras
Not
provided
129
CONNECTINGDEVICES
• It is recommended to use
an HDMI connection for the
best image quality.
• Depending on the graphics
card, DOS mode video may
not work if a HDMI to DVI
Cable is in use.
• In PC mode, there may be
noise associated with the
resolution, vertical pattern,
contrast, or brightness. If
noise is present, change
the PC output to another
resolution, change the
refresh rate to another rate
or adjust the brightness and
contrast on the PICTURE
menu until the picture is
clear.
• The synchronization input
form for Horizontal and
Vertical frequencies is
separate.
• Depending on the graphics
card, some resolution
settings may not allow the
image to be positioned on
the screen properly.
• If you are using DVI out from
a PC, you have to connect
analog audio separately.
• When using the HDMI/DVI
cable, Single link only is
supported.
NOTE
ConnectingaLaptop
You can connect the projector to a
laptop to use various functions.
HDMIConnection
Using an HDMI cable, connect the
port of the projector
to the HDMI output port of your
laptop. Both video and audio are
output at the same time.
You can
also use the .
Press the INPUT button on the
remote control to select HDMI.
You can connect with any HDMI
input port.
Optional Extras
130
CONNECTINGDEVICES
The table below shows examples
of switching the output. For
more information, refer to the
ExternalOutput, Connectingto
anExternalMonitor, or similar
sections of the owner's manual of
your computer.
Brand
Switching
Output
NEC [Fn]+[F3]
Panasonic [Fn]+[F3]
Toshiba [Fn]+[F5]
IBM
[Fn]+[F7]
Sony [Fn]+[F7]
Fujitsu
[Fn]+[F10]
LG [Fn]+[F7]
Samsung [Fn]+[F4]
Macintosh
Adjust the control
panel to enable
mirroring after
start-up.
Connecting
Headphones
You can listen to the audio through
a headphone.
Not provided
131
CONNECTINGDEVICES
ConnectingaDigital
Amp
Using an optical cable, connect
the digital audio input port of
a digital amp to the OPTICAL
DIGITALAUDIOOUT port of the
projector. The output of an amp
with a digital converter must be set
to the desired audio format. When
using a HDMI cable to connect a
home theater or when connecting
an optical output to an external
audio device, set SoundOut
to ExternalSpeaker(Optical/
HDMIARC) as shown below.
If a projector, home theater, or
the speaker of an external audio
device is operating at the same
time, there will be an echo.
Optional Extras
• Refer to the user manual of
the audio device to connect.
• When connecting this
product to other devices,
make sure to turn off and
unplug all the devices.
• The audio output of this
product has wide-ranging
audio bandwidth, so the
receiver volume must
be adjusted properly.
Speakers can be damaged
by unexpected high
frequencies.
• Connecting the OPTICAL
DIGITALAUDIOOUT port
of the projector to the digital
audio input port of a digital
amp and the audio input port
of the projector to the analog
audio output port of the
digital amp can cause sound
oscillation due to the closed
loop. Remove one of the two
connections to prevent this.
(This also applies to home
theater devices.)
NOTE
132
CONNECTINGDEVICES
UsingtheMirroringFunctionofaMobile
Phone
MHLConnection
The Mobile High-denition Link (MHL) is an interface that can connect a
mobile phone to the projector and play video and audio from the mobile
phone through the projector.
This only applies to products with a HDMI input that supports MHL.
(To nd out whether your device is MHL-certied, please contact your
device manufacturer.)
For MHL support, check the port.
Use a dedicated cable for MHL.
Optional Extras
• When you connect a mobile phone to the port, you
can see the mobile phone screen through a projector.
– This only applies to mobile phones that support MHL.
– You can use the remote control for some applications.
• Disconnect the MHL cable from the projector when:
– The MHL function is disabled.
– Your mobile device is fully charged in standby mode.
NOTE
133
MAINTENANCE
MAINTENANCE
Clean your Projector to keep it in optimal condition.
Cleaning
CleaningtheLens
If there is any dust or staining on the lens surface, you must clean the lens.
Use an air spray or a cleaning cloth to clean the lens.
To remove dust or stains, use an air spray or apply a small amount of
cleaning agent onto a swab or soft cloth to lightly rub the lens.
Please be aware that liquid may ow into the lens if the product is sprayed
directly onto the lens.
CleaningtheProjectorCase
To clean the projector case, rst unplug the power cord.
To remove dust or stains, use only a dry, lint-free, nonabrasive cloth to
polish the lens.
Do not use alcohol, benzene, thinners, or other chemicals, which may
damage the case.
134
INFORMATION
INFORMATION
ToUpdateProjectorSoftware
Uses Software Update to check and obtain the latest version.
It is also possible to check manually for available updates.
1 Press the (Home) button and select SETTINGS.
2 Select SUPPORT and go to SoftwareUpdate.
Item Description
SoftwareUpdate
Set it to On.
If an update is available, a prompt will appear to
perform the update.
AutomaticUpdate
Mode
If an update is available, the update
automatically starts without prompting.
CheckUpdate
Version
Checks the latest update version installed. When
a new update is available, the download process
can be performed manually.
• When the update starts, the update progress window appears for a short
time and disappears.
• The latest version can be obtained via an Internet connection.
• If software is not updated, certain functions may not work properly.
135
INFORMATION
BeforeReportingaProblem,Checkthe
Following:
If the following symptoms occur, please carry out the checks and
adjustments described below. There may be no malfunction.
General
Problem Solution
Cannotviewcertain
programs.
• Adjust the location or orientation of the
antenna.
• Save the programs you wish to view
later using AutoTuning or Channel
Edit.
Thereisadelayafterthe
projectorisswitchedon
beforetheimageisfully
visible.
• This is not a problem. Image noise that
may occur when the projector is first
switched is being cleaned up.
(Home) → SETTINGS → SUPPORT → PictureTest
First run a Picture Test to verify that the image signal output is normal.
If there is no problem with the test image, check external device
connections and broadcast signals.
Problem Solution
Imagesfromprevious
programorother
programslingeror
thescreendisplays
annoyinglines.
• Adjust the orientation of the antenna
to the TV transmitter, or refer to the
manual for instructions on connecting
the antenna.
Vibratinghorizontal/
verticallinesand
shnetpatternsappear
momentarily.
• Such a problem may happen when
there is strong electronic interference.
Turn off other electronic devices such as
mobile phones, power tools, and other
small electrical appliances.
136
INFORMATION
Problem Solution
Thescreendisplay
freezesordoesnotwork
properlyduringadigital
broadcast.
• This may occur in case of a weak
signal or unstable reception. Adjust
the antenna orientation and cable
connections.
• If the signal strength or quality is low
on ManualTuning, check with the TV
station or administration office.
Digitalbroadcasting
isnotavailableeven
thoughthecableis
connected.
• Check with the cable operator providing
your subscription and/or signal.
(Depending upon your subscription,
digital broadcasting may not be
supported.)
Thedisplayisinactive
orunclearwhen
connectedtoanHDMI
®
source.
• Check the HDMI
®
cable specifications.
If your HDMI
®
cable is not genuine,
images may fade in and out or not be
displayed properly.
• Ensure that all cables are securely
connected. When connections are not
secure, images may not be properly
displayed.
Doesnotworkwitha
USBstoragedevice.
• Verify that the USB device and cable is
version 2.0 or higher.
Sound
(Home) → SETTINGS → SUPPORT → SoundTest
First run a Sound Test to verify that the sound signal output is normal.
If there is no problem with the test sound, check connected external
devices and the broadcast signal.
Problem Solution
Screendisplayisonbut
thereisnosound.
• Check other TV programs.
• Check if the audio output settings for the
projector are configured correctly.
137
INFORMATION
Problem Solution
Forananalogue
broadcast,stereoisnot
clearorsoundcomes
fromonespeakeronly.
• In a poor reception area (areas with
weak or unstable signals) or if multi
audio is not stable, select Mono on
MultiAudio.
• Adjust the balance using the navigation
button.
TVsoundisnotin
syncwiththeimageor
thesoundbreaksup
occasionally.
• If the issue affects a specific TV program
only, it may be caused by problems with
the broadcast signal for the individual
station. Check with the TV station or
your cable operator.
Thevolumechanges
whenIchangeprogram.
• Volume can vary from program to
program.
• Set AutoVolume to On.
Oncertainprograms,
thereisnosoundatall,
oronlythebackground
musiccanbeheard
(incaseofaprograms
createdforoverseas
viewers).
• In Language, set Language → Audio
Language to the language of your
choice. Even if you change the language
on MultiAudio, you can go back to
the default setup once you turn off the
power or change the program.
Thereisnosoundwhen
connectedtoHDMI/
USB.
• Verify that the HDMI
®
cable is high
speed.
• Check if the USB device and cable is
version 2.0 or higher.
• Use only regular music (*mp3) files.
138
INFORMATION
PCConnectionProblem
Problem Solution
Thescreendisplay
doesnotcomeon
afterconnectingto
thecomputer.
• Verify that the computer and the projector
are securely connected.
• Turn the projector off and back on using the
remote control.
• Restart the PC with the projector on.
• Check whether the resolution is correctly
set for PC input.
• Reconnect the HDMI cable.
Thereisnosound
afterconnectingthe
computerwiththe
HDMIcable.
• Check with manufacturer of your video
card to ensure it supports HDMI voice
output. (Video cards in DVI format require
connection of a separate sound cable.)
Whenconnectedto
thecomputer,the
displayispartially
cutofforshiftsto
oneside.
• Set the resolution to support PC input. (If
this does not work, reboot the computer.)
139
INFORMATION
ProblemsReplayingMoviesinMyMedia
Problem Solution
Icannotviewtheles
ontheMovieList.
• Check whether the file on the USB storage
device can be read on a computer.
• Check whether the file extension is
supported.
Thisleisinvalid.
messageappears
ortheimagedisplay
isnotnormaleven
thoughthesound
isOK.
• Make sure that the file replays normally on
the computer’s video player. (Check for
damaged files.)
• Check whether the resolution is supported
by the computer.
• Verify that the video/audio codec is
supported.
• Verify that the frame rate is supported.
Audionotsupported.
messageappears
orthesoundisnot
normaleventhough
theimagedisplayis
OK.
• Make sure that the file replays normally on
the computer’s video player. (Check for
damaged files.)
• Check if the audio codec is supported by
the computer.
• Verify that the bit rate is supported.
• Verify that the sample rate is supported.
Subtitlesarenot
displayed.
• Make sure that the file replays normally on
the computer’s video player. (Check for
damaged files.)
• Check if the video file has the same name
as the subtitle file.
• Make sure that the video and subtitle files
are in the same folder.
• Verify that the subtitle file format is
supported.
• Verify that the subtitle language is
supported. (Subtitle files can be opened in
Notepad to check the language.)
• Image shown may differ from your projector.
• For information on requesting service, refer to the following menu.
(Home) → SETTINGS → SUPPORT → Product/ServiceInfo.
140
SPECIFICATIONS
SPECIFICATIONS
MODELS PF1000U(PF1000U-NA)
Resolution(Pixel) 1920 (Horizontal) × 1080 (Vertical)
AspectRatio
16:9 (Horizontal:Vertical)
Panelsize(mm) 11.896
Projection
Distance
(Videosize)
0.413 m to 0.686 m (152.4 cm to 254 cm)
RatioofUpward
Projection
125 %
Workingrangeof
theremotecontrol
6 m
Power AC 100 - 240 V, 50 Hz/ 60 Hz
Power
consumption
100 W
AC-DCAdaptor
19 V 5.79 A
(Adaptor Input 100 - 240 V @ 50/60 Hz)
AudioOutput 3 W + 3 W
Receptiontype NTSC-M, ATSC
Reception
channels
VHF 02 to 13, UHF 14 to 69, CATV 01 to 158,
DTV 02 to 69, CADTV 01 to 158
ExternalAntenna
Impedance
75 Ω
Height(mm) 127.6 (without foot) / 128.8 (with foot)
Width(mm) 131.4
Depth(mm) 309 (without tuner) / 318 (with tuner)
Weight(kg) 1.9
USBDevice
5 V, 0.5 A (Max.)
141
SPECIFICATIONS
MODELS PF1000U(PF1000U-NA)
Environment
condition
Temperature
Operation 0 °C to 40 °C
Storage -20 °C to 60 °C
Relativehumidity
Operation 0 % to 80 %
Storage 0 % to 85 %
* Use only power supplies listed in the user instructions.
* Contents in this manual may be changed without prior notice due to
upgrade of product functions.
HDMI(DTV)SupportedMode
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
720 x 480p
31.47 60
31.47 59.94
31.50 60.00
1280 x 720p
44.96 59.94
45.00 60.00
1920 x 1080i
33.72 59.94
33.75 60.00
1920 x 1080p
26.97 23.976
27.000 24.000
33.71 29.97
33.75 30.00
67.432 59.939
67.500 60
142
SPECIFICATIONS
SupportedHDMI(PC)Modes
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
640 x 350 31.468 70.09
720 x 400 31.469 70.08
640 x 480 31.469 59.94
800 x 600 37.879 60.31
1024 x 768 48.363 60.00
1152 x 864 54.348 60.053
1360 x 768 47.712 60.015
1280 x 1024 63.981 60.020
1920 x 1080 67.5 60
• If an invalid signal is input into the projector, it will not be displayed
properly on the screen or a message such as NoSignal or Invalid
Format will be displayed.
• The projector supports the DDC1/2B type as the Plug and Play function
(Auto-recognition of PC monitor).
• 1920 x 1080 is recommended as the best picture quality in the PC
mode.
143
SPECIFICATIONS
ComponentSupportedMode
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
720 x 480i
15.73 59.94
15.75 60.00
720 x 480p
31.47 59.94
31.50 60.00
1280 x 720p
44.96 59.94
45.00 60.00
1920 x 1080i
33.72 59.94
33.75 60.00
1920 x 1080p
26.97 23.976
27.00 24.00
33.71 29.97
33.75 30.00
67.432 59.94
67.500 60.00
ComponentPortConnectingInformation
Componentportsonthe
Projector
Y P
B
P
R
VideooutputportsonDVD
player
Y P
B
P
R
Y B-Y R-Y
Y Cb Cr
Y Pb Pr
144
SPECIFICATIONS
OpenSourceSoftwareNoticeInformation
To obtain the source code under GPL, LGPL, MPL, and other open source
licenses, that is contained in this product, please visit
http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty
disclaimers and copyright notices are available for download.
LG Electronics will also provide open source code to you on CD-ROM for a
charge covering the cost of performing such distribution (such as the cost
of media, shipping, and handling) upon email request to
[email protected]. This offer is valid for three (3) years from the date
on which you purchased the product.
145
SYMBOLS
SYMBOLS
Refers to alternating current(AC).
Refers to direct current(DC).
Refers to class II equipment.
Refers to stand-by.
Refers to “ON” (power).
Refers to dangerous voltage.
The model and serial numbers of the projector are
located on the back or on the side of the projector.
Record them below should you ever need service.
MODEL
SERIAL
