Auto Program
The Auto Program function memorizes all channels that are
available over the air or through your cable system and adds them
to the Channel List. If you are using a cable or satellite box, you do
not need to run the Auto Program function.
To start Auto Program, follow these steps:
1. Push MENU
m
ChannelAuto ProgramENTER
E
on your
remote. The Antenna Source screen appears.
2. On the Antenna Source screen, select the source of your TV signal.
Air
If your TV is connected to an antenna choose Air, and then press
ENTER
E
. The TV will automatically start memorizing channels.
Cable
If your TV is connected to a cable outlet, choose Cable, and then
press ENTER
E
. Go to Step 3.
Auto
If you choose Auto, and then press ENTER
E
, the TV will
automatically select the correct Antenna source. Go to Step 3.
3.
buttons to select
the type of digital and analog cable systems you have: STD, HRC,
or IRC. Most systems are STD (Standard). When done, select
Start, and then press ENTER
E
. The TV will start memorizing
channels.
✎ Channel memorization can take up to 45 minutes,
depending on your cable system.
✎ Memorized channels are added to the Added Channels
list. These are the channels you will see when you use the
Channel buttons on your remote.
Clear Scrambled Channel
Auto Program is
completed. This process may take up to 20~30 minutes.
✎ Press the ENTER
E
button to stop the Clear Scrambled
Channel.
✎ This function is only available in Cable mode.
❑ Managing Channels
Channel List
See your list of Added channels, Favorite channels, or channels
you've scheduled for viewing. Add or delete Favorite channels, add
or delete channels from the Added Channels list, schedule channels
or programs for viewing. Watch a channel by selecting the channel
in the All Channels, Added Channels, or Favorite Channels screen,
ENTER
E
button.
Added Channels
6 Air
6-1 * TV #6
7-1 * TV #7
8 Air
9 Air
9-1 * TV #9
10 Air
10-1 * TV #10
11-1 * TV #11
Air
'
Zoom
'
Select
T
Tools Next Program
Channel List Screens icons are listed on the left side.
Select an icon using the / buttons to view each list.
■
All Channels: Shows all currently available channels including
those you deleted from the Added Channels list.
■
Added Channels: Shows all Added Channels. These are the
channels that appear when you press the CH button.
■ *
Favorite Channels: Shows all favorite channels.
■
Programmed: Shows all channels and programs currently
scheduled using Timer Viewing.
✎ Remote control buttons active on the Channel List screen.
x Green (Zoom): Enlarges or shrinks a channel number.
x Yellow (Select): Move the cursor to a channel. Press the Yellow
button to select the channel. A
c
mark appears. Repeat to
select additional channels. Then, open the Tools menu and apply
a function to the channels you selected.
x
T
(Tools): Displays the Channel List Tools menu. (The Tools
menus may differ depending on the situation.)
✎ If you use a cable box or satellite box, you cannot use the
Channel List or the Channel List functions.
Display Icons Used in the Channel List Screens
Icons Meaning
c
A selected channel.
*
A Favorite channel.
)
A reserved program.
(
A program currently being broadcast.
❑ The Channel List Tools Menu
t
The Channel List Tools menu contains most of the functions you can
use on the All Channels, Added Channels, and Favorite Channels
List screens. To view, select a list screen, select a channel, and then
press the TOOLS button.
■
Add / Delete: Delete a channel from or add a channel to the
Added Channels list.
To delete channels from the Added Channels list, follow these
steps:
1. Select one or more channels in the Added Channels list using
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Delete in the Tools menu, and then press the ENTER
E
button.
To add channels to the Added Channels list, follow these steps:
1. Select one or more channels in the All Channels list using the
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Add in the Tools menu, and then press the ENTER
E
button.
✎ All deleted channels will be shown on the All Channels list.
You add channels back to the Added Channels list on the
All Channels list.
✎ A gray-colored channel indicates the channel has been
deleted from the Added Channels list.
✎ The Add menu option only appears for deleted channels.
Picture Reset
■
Picture Reset (Reset Picture Mode/Cancel): Resets the picture
settings to their factory defaults.
Sound Menu
Mode
t
■
Standard: Selects the normal sound mode.
■
Music: Emphasizes music over voices.
■
Movie: Provides the best sound for movies.
■
Clear Voice: Emphasizes voices over other sounds.
Equalizer
Available in Standard sound mode only.
■
Balance L/R: Adjusts the balance between the right and left
speaker.
■
100Hz / 300Hz / 1kHz / 3kHz / 10kHz (Bandwidth Adjustment):
■
Reset
Auto Volume
Automatically adjusts the volume level when you change video
sources or content so the level remains the same.
Speaker Select
If you are listening to the sound track of a broadcast or movie
through an external receiver, you may hear a sound echo caused
by the difference in decoding speed between the TV’s speakers
and the speakers attached to your audio receiver. If this occurs, set
the TV to External Speaker.
✎ When you set Speaker Select to External Speaker, the TV’s
speakers are turned off. You will hear sound through the
external speakers only. When you set Speaker Select to TV
Speaker both the TV’s speakers and the external speakers
are on. You will hear sound through both.
✎ When Speaker Select is set to External Speaker, the
VOLUME and MUTE buttons will not operate and the sound
settings will be limited.
✎ If there is no video signal, both the TV’s speakers and the
external speakers will be mute.
Preferred Language
Digital channels only.
Digital-TV broadcasts can transmit many audio tracks
simultaneously (for example, simultaneous translations of a
program into foreign languages).
✎ You can only select a language from among the ones being
broadcast.
Multi-Track Sound (MTS)
Analog channels only.
■
Mono: Select for channels that are broadcasting in mono or if
■
Stereo: Select for channels that are broadcasting in stereo.
■
SAP: Select to listen to the Separate Audio Program, which is
usually a foreign-language translation.
✎ Depending on the program being broadcast, you can listen
to Mono, Stereo or SAP.
SPDIF Output
The SPDIF (Sony Philips Digital InterFace) outputs an
uncompressed digital audio signal when you connect the digital
audio jack on the back of the TV to a digital audio in jack on a
receiver or home theater.
■
Audio Format: You can select the Digital Audio output (SPDIF)
format. The available Digital Audio output (SPDIF) format may
differ depending on the input source.
■
Audio Delay: Lets you correct timing mismatches between
the audio track and the video when you are watching the TV
and listening to digital audio output from the TV through an
external device such as an AV receiver. When you select Audio
Delay, a slider appears. Use the left and right arrow buttons to
adjust the slider. Press ENTER
E
when done (0ms ~ 250ms).
Visually Impaired
(digital channels only)
Adds a verbal description to the main audio to help the visually
impaired.
Dolby Digital Comp
Sets Dolby Digital compression mode.
HDMI Audio Format
You can select the HDMI Audio format. The available HDMI Audio
format may differ depending on the input source.
Sound Reset
■
Reset All: Resets all sound settings to the factory defaults.
Channel Menu
❑ Memorizing Channels
Plug & Play, the TV memorized
the channels that were available over the air or through your
cable system and added them to the Channel List. The Antenna
and Auto Program functions described below let you re-run the
channel memorization function without having to re-run the Plug
& Play procedure.
Antenna (Air / Cable)
Before your television can memorize the available channels,
you must select your TV's signal source, Air (using an antenna)
or Cable. Select Menu > Channel > Antenna > Air or Cable. After
you have selected the signal source, go on to the Auto Program
function.
✎ Selecting the signal source using the Antenna function
also determines the signal source the TV is tuned to. For
example, if you receive your TV signal over the air, and you
select Cable, you will see only snow. You must select Air to
see a picture.
■
Add to Favorite/Delete from Favorite: Lets you add channels to
and delete channels from your Favorite Channels list.
To add channels to the Favorite Channels list, follow these steps:
1. Select one or more channels in the All Channels list using the
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Add to Favorite in the Tools menu, and then press the
ENTER
E
button.
To delete channels from the Favorite Channels list, follow these
steps:
1. Select one or more channels in the Favorite Channels list
remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Delete from Favorite in the Tools menu, and then press
the ENTER
E
button.
■
Timer Viewing: You can schedule a channel to be displayed
automatically at a set time, even when you are watching
Time
> Clock function to use Timer Viewing.
To schedule a channel, follow these steps:
1. Select a channel in the Added Channels
buttons and the Yellow Select button on your remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Timer Viewing in the Tools menu, and then press the
ENTER
E
button. The Timer Viewing screen appears.
Antenna Channel Repeat
DTV Air 6-1 Once
L
Move
U
Adjust
E
Enter
R
Return
Timer Viewing
Date Start Time
01-01-2016 12 : 01 am
4.
buttons to change the entries. Where numbers
are displayed, you can also enter numbers directly using the
number keypad on your remote.
✎ If you select Everyday or Every Week, the date you
select in the Date field becomes the start date for your
scheduled viewing. For Everyday, the TV will turn on
every day, at the time you selected, starting from that
date. For Every Week, the TV will turn on every week,
on the same day of the week as the start date you
selected, at the time you selected, from that day on. If
you select Once, the TV will turn on once, on the date
and time you selected.
5. Press the ENTER
E
button on your remote when done.
✎ Only Added Channels can be scheduled.
✎ Scheduled programs and channels are displayed in the
Programmed List.
✎
view the digital program list. If you highlight a program in
the list, and then press the ENTER
E
(Schedule) button,
you set Timer Viewing for that program directly.
■
Channel Name Edit: Analog channels only. Lets you assign
select a channel .
■
Select All: Select all the channels in the displayed channel list.
■
Deselect All: Deselect all the selected displayed channels.
✎ You can only select Deselect All when one or more
channels are selected.
■
Auto Program: See Auto Program under Memorizing Channels.
Programmed List (on the Channel List Screen)
The Programmed list displays the channels and programs you
have scheduled for viewing using the Timer Viewing function. You
can view, modify, or delete a show you have scheduled using the
functions on the Programmed List screen Tools menu.
Programmed List Screen Tools Menu
t
■
Change Info: Change the scheduling information for a show or
channel you have scheduled.
To change the information, follow these steps:
1. Select the Programmed List icon on the left side of the
Channel List screen, and then press the ENTER
E
button.
2. On the Programmed List screen, select the show or channel
entry you want to change, and then press the TOOLS button.
The Tools Menu appears.
3. Select Change Info, and then press the ENTER
E
button. The
Timer Viewing screen appears.
4.
buttons to change the entries. Where numbers
are displayed, you can also enter numbers directly using the
number keypad on your remote.
5. Press the ENTER
E
button when done.
■
Cancel Schedules: Cancel a show or channel you have
scheduled.
To cancel a scheduled show or channel, follow these steps:
1. Select the Programmed List icon on the left side of the
Channel List screen, and then press the ENTER
E
button.
2. On the Programmed List screen, select the show or channel
entry you want to cancel, and then press the TOOLS button.
The Tools Menu appears.
3. Select Cancel Schedules, and then press the ENTER
E
button. The Cancel Schedules screen appears.
4. Select OK, and then press the ENTER
E
button.
■
Information: Display the information for a show or channel you
have scheduled. You can also change the schedule Information.
1. Select the Programmed List icon on the left side of the
Channel List screen, and then press the ENTER
E
button.
2. On the Programmed List screen, select the show or channel
entry you want information for, and then press the TOOLS
button. The Tools Menu appears.
3. Select Information, and then press the ENTER
E
button. The
Timer Viewing Info screen appears.
4. Select Change Info, and then press the ENTER
E
button
to change information, or select Close, and then press the
ENTER
E
button to close the Information screen.
■
Select All / Deselect All: You can select or deselect all channels
in the channel list.
❑ Other Channel Menu Functions
Channel Mode (Added Channels/Favorite
Channels)
Lets you select the channel list displayed when you press the
<CH> (Channel) button on your remote. For example, if you
select Favorite Channels, you will only see Favorite channels
when you press the <CH> button.
Fine Tune
Analog channels only.
as this is done automatically during the search and store
manually.
✎ Select the channel, and then select Fine Tune.
✎ Fine tuned channels that have been saved are marked
with an asterisk “*” on the right-hand side of the channel
number in the channel banner.
✎To reset fine-tuning, select the channel, select Fine Tune,
and then select Reset on the Fine Tune screen.
Setup Menu
Plug & Play
Lets you re-run the Plug & Play initial setup procedure. For
instructions, see your Quick Start Guide.
Language
Set the menu language.
✎ Choose between English, Español, and Français.
❑ Setting the Time
Time
✎
The time you set will appear when you press the INFO
button.
■
Clock: Set the clock so you can use the various timer features
of the TV.
✎ If you disconnect the power cord, you have to set the
clock again.
To set the clock, follow these steps:
1. Select Setup >Time > Clock.
2. Press ENTER
E
and select Auto or Manual, and then press
ENTER
E
again.
If you selected Auto:
The TV will automatically download the correct time from a
digital channel.
Select Time Zone, and then press the ENTER
E
button.
Time Zone, and then
press ENTER
E
.
Select DST (Daylight Savings Time), and then press
ENTER
E
. Select On if you want to turn the DST
adjustment on and off manually. Select Off to turn off the
DST adjustment. Press ENTER
E
when done.
✎ The DST and Time Zone functions are only available
when the Clock Mode is set to Auto.
If you selected Manual:
The Clock Set
ENTER
E
.
✎ Available only when Clock Mode is set to Manual.
■
Sleep Timer
t
Automatically shuts off the TV after a preset period of time.
(30, 60, 90, 120, 150 and 180 minutes).
✎ To cancel the Sleep Timer, select Off.
Timer 1 / Timer 2 / Timer 3
Turns the TV on and off automatically at times and days you
✎ You must set the clock first.
■
On Time / Off Time
On Time and Off Time. Use
Activate.
■
Volume: Set the desired loudness.
■
Contents: To select what will be turned on when the timer
Use the
press the ENTER
E
button. The Contents screen appears.
Use the
- TV/USB: Select TV or USB. The USB device must be connected
to your TV before you can select USB.
- Antenna: Displays the current antenna source, Air or Cable.
- Channel: If you have selected TV, select the desired channel.
- Music/Photo: If you have selected USB, follow these steps to
the USB device:
✎ The maximum number of files the TV can display,
including sub folders, in one folder of a USB storage
device is 1000.
✎ The media may not play smoothly if you use a USB device
rated lower than USB 2.0.
1. Music
Photo, and then press the ENTER
E
button. The TV displays a single folder (the Root folder)
and the type or name of the device.
2. Press the ENTER
E
button. A list of folders on the device
appears.
✎ If there are no folders on your device, press the
Yellow select button to select the Root folder, and
then press the RETURN button. The Timer screen
re-appears.
3.
music or photos, and then press the Yellow select button
to select the folder.
4. Press the RETURN button. The Timer screen re-appears.
■
Repeat: Select Once, Everyday, Mon~Fri, Mon~Sat, Sat~Sun or
Manual. If you select Manual, you can select the days you want
day, and then pressing the ENTER
E
button. To unselect a day,
highlight it, and then press the ENTER
E
button.
screen, press either the ENTER
E
or RETURN button.
The On Screen Menus
Your TV has two kinds of menus, the Main menu and the various
Tools menus. The Main menu gives you access to most or all of
the menu options available on your TV. The Tools menus display
depending on the screen you are viewing. A Tools menu symbol
(T) in the lower right side of the screen indicates that a Tools
menu is available.
The Main menu has seven primary categories:
y Picture y Input
y Sound y Application
y Channel y Support
y Setup
To view the Main menu, press the MENU button on your remote. To
view a Tools menu, press the TOOLS button on your remote.
✎ The menu options that appear in the Main menu depend
on the Source you have selected. For example, if you have
selected the HDMI source, the Channel category will not
appear. To see the Channel category, you must first select
TV in the Source List.
The Menu options are presented below, arranged by Main menu
categories. A Tools button symbol
(
t
) next to an option
name indicates the option is also available in one of the Tools
menus.
Picture Menu
Mode
t
Select your preferred picture mode.
✎ When your TV is connected to a PC, you can only select
Entertain and Standard
.
■
Dynamic: Brightens the screen. Suitable for a bright room.
■
Standard: Suitable for normal room brightness.
■
Movie: Darkens the screen, making it less glary. Suitable for
watching movies in a darkened room.
■
Entertain: Sharpens the picture. Suitable for games.
✎ Only available when the TV is connected to a PC.
Backlight / Contrast / Brightness / Sharpness /
Color / Tint (G/R)
■
Backlight: Adjusts the brightness of the screen by adjusting the
brightness of the individual pixels.
■
Contrast: Increases or decreases the contrast between dark and
light areas of the picture.
■
Brightness: Adjusts the brightness of the screen. Not as
effective as Backlight.
■
Sharpness: Sharpens or dulls the edges of objects.
■
Color: Adjusts the color saturation. The higher the Color setting,
the more intense the color. Low settings remove color and the
picture becomes black, white, and gray.
■
Tint (G/R): Adjusts the amount of green and red in the picture.
As you increase the amount of green, the amount of red
decreases and vice versa.
✎ When the TV is connected to a PC, you can only make
changes to Backlight, Contrast, Brightness, and Sharpness.
Picture Options
✎
When the TV is connected to a PC, you can only make
changes to the Color Tone, Size, and HDMI Black Level.
■
Color Tone (Cool / Standard / Warm): Cool makes the picture
bluer (cooler). Warm makes the picture redder (warmer).
✎ Warm is deactivated when the picture mode is set to
Dynamic.
■
Size: Set the size and aspect ratio of the picture on the screen.
Your cable box or satellite receiver may have its own set of
screen sizes as well. However, we highly recommend you use
16:9
Zoom1
top, and bottom are cut off.
Zoom2
and bottom are cut off.
Wide Fit: Enlarges the aspect ratio of the picture so the picture
4:3
gray borders on the right and left of the picture.
✎
The borders displayed on the left, right, and center of the
burn) which is not covered by the warranty.
Screen Fit: Displays the full image without any cut-off when
✎
(1920x1080) or 720p (1280x720) resolution.
✎ You can adjust and store settings for each external device
you have connected to an input on the TV. Picture Sizes
available by Input Source are listed below:
Custom
right, up, and down.
Input Source Picture Size
ATV, AV, Component (480i, 480p) 16:9, Zoom1, Zoom2, 4:3
DTV (1080i, 1080p), Component (1080i,
1080p), HDMI (720p, 1080i, 1080p)
16:9, Wide Fit, 4:3,
Screen Fit
■
Digital Clean View (Off / Low / Medium / High / Auto) : If the
broadcast signal received by your TV is weak, you can activate
the Digital Clean View feature to reduce any static and ghosting
that may appear on the screen.
✎ When the signal is weak, try all the Digital Clean View
options until the TV displays the best picture.
■
HDMI Black Level (Normal / Low) : For HDMI signals, select the
black level to adjust the screen depth. Low make blacks look
darker.
✎ Available only in HDMI mode (RGB signals).
■
Film Mode (Off / Auto1 / Auto2) : Sets the TV to automatically
✎
■
Motion Lighting (Off / On): When on, the TV automatically dims
the screen's backlights when full brightness is not needed -
for example when the TV is displaying dark scenes - to reduce
power consumption. The backlights are returned to full
brightness when the TV displays bright scenes.
Picture Off
The screen is turned off but the sound remains on. Press any
button except the power key or volume button to turn on the
screen.
❑ Other Features
Voice Guide (On/Off)
You can activate voice guides that describe the menu options
aloud to aid the visually impaired.
■
Voice Guide: Enable or disable the Voice Guide feature. Voice Guide
is provided in the current language.
■
Volume: Set the volume of the voice guide.
■
Pitch: Set the pitch of the voice guide.
■
Speed: Set the speed of the voice guide.
Game Mode (On/Off)
When you connect a game console such as a PlayStation™ or Xbox™
to your TV, you can enjoy a more realistic gaming experience by
turning on the Game Mode function.
✎ Precautions and limitations for game mode:
x Before you disconnect the game console and connect another
external device, set Game Mode to Off in the setup menu.
x If you display the TV menu in Game Mode, the screen shakes slightly.
✎ Game Mode is not available when the input source is set to TV.
✎ After connecting the game console, set Game Mode to On. You
Program Rating Lock
The Program Rating Lock feature lets you block programs you've
determined are inappropriate for your children based on the program's
ratings. To access the Program Rating Lock feature and make any
watch a blocked program, you must also enter the same PIN.
✎ Program Rating Lock is not available in HDMI or Component mode.
✎ The default PIN number of a new TV set is “0-0-0-0”. You
can set your own PIN using the Change PIN function.
How It Works
When you access the Program Rating Lock Menu functions for the
screen closes and the Program Rating Lock Menu appears. Every
time you access the Program Rating Lock functions, the PIN screen
will appear and you must enter a PIN.
When the Rating Lock screen appears, select Program Rating Lock,
and then press ENTERE. Select On, and then press the ENTERE
key again. Depending on what type of programs or movies you want
to block, select one of the options on the screen, and then press the
ENTERE button. The options are listed below:
■
TV Parental Guidelines: You can block TV programs based on
their ratings. This function allows you to control what your
children are watching.
■
MPAA Rating: You can block movies based on their MPAA
ratings. The Motion Picture Association of America (MPAA)
has implemented a rating system that provides parents or
appropriate for children.
■
Canadian English: You can block TV programs based on their
Anglophone Canadian ratings.
■
Canadian French: You can block TV programs based on their
French Canadian ratings.
■
Downloadable U.S. Rating: You can use parental restriction
information while watching DTV channels.
Locking/Blocking Programs or Movies
way for each option. Each option displays a grid or table. All the
tables have ratings listed on the left. The TV Parental Guidelines
option also has kinds of content listed across the top: All: Lock all TV
FVVSL:
D: Sexually Suggestive Dialog.
again. When you click a low rating, all the ratings above it will also
display locks. You can also Allow All or Lock All. When done, press
the RETURN button on your remote.
■
Change PIN: Select Change PIN and the Change PIN screen
appears. Choose any 4 digits for your PIN, and then enter
disappears, press the OK button. The TV has memorized your
new PIN.
✎ If you forget the PIN, press the remote-control buttons in
: POWERMUTEPOWER (on)
Caption
(On-Screen Text Dialogue)
■
Caption: You can switch the caption function on or off. If
captions are not available, they will not be displayed on the
screen.
✎ The Caption feature does not work in Component or HDMI
mode.
■
Caption Mode: You can select the desired caption mode.
Default / CC1~CC4 / Text1~Text4: (analog channels only) The
Analog Caption function operates in either analog TV channel
mode or when a signal is supplied from an external device to
the TV. (Depending on the broadcasting signal, the Analog
Caption function may or may not work with digital channels.)
Default / Service1~Service6 / CC1~CC4 / Text1~Text4: (Digital
channels only) The Digital Captions function works with digital
channels.
✎ Service1~6 may not be available in digital caption mode
depending on the broadcast.
■
Digital Caption Options: (Digital channels only)
Size: Options include Default, Small, Standard, Large, and Extra
large. The default is Standard.
Font Style: Options include Default and Styles 0 to 7. The
default is Style 0.
Foreground Color: Options include Default, White, Black, Red,
Green, Blue, Yellow, Magenta, and Cyan. You can change the
color of the letters. The default is White.
Background Color: Options include Default, White, Black, Red,
Green, Blue, Yellow, Magenta, and Cyan. You can change the
background color of the captions. The default is Black.
Window Color: Options include Default, White, Black, Red,
Green, Blue, Yellow, Magenta, Cyan. Default is Black.
Foreground Opacity: This adjusts the opacity of text. Options
include Default, Transparent, Translucent, Solid, and Flashing.
Background Opacity: This adjusts the opacity of the caption
background. Options include Default, Transparent, Translucent,
Solid, and Flashing.
Window Opacity: This refers caption to window background, not
character background. Options include Default, Transparent,
Translucent, Solid, Flashing. Default is Transparent.
Edge Type: Options include No Edge, Raised, Depressed,
Uniform, Drop Shadow. Default is No Edge.
Edge Color: Options include Default, White, Black, Red, Green,
Blue, Yellow, Magenta, Cyan. Default is White.
Return to Default: This option sets Size, Font Style, Foreground
Color, Background Color, Foreground Opacity, and Background
Opacity to its default.
✎ Digital Caption Options are available only when you can
select Default and Service1 ~ Service6 in Caption Mode.
✎ The Foreground and Background cannot be set to the
same color.
Figures and illustrations in this User Manual are provided for reference
only and may differ from actual product appearance. Product design and
IMPORTANT WARRANTY INFORMATION
REGARDING TELEVISION FORMAT VIEWING
✎
See the warranty card for more information on warranty
terms.
ratio of the screen width to height) are primarily designed to view
wide screen format full-motion video. The images displayed on
with the images constantly in motion. Displaying stationary
graphics and images on the screen, such as the dark sidebars on
non-expanded standard format television video and programming,
should be limited to no more than 5% of the total television
viewing time per week.
Additionally, viewing other stationary images and text such as
stock market crawls, video game displays, station logos, web sites,
or computer graphics and patterns, should be limited as described
above for all televisions.
Displaying stationary images that exceed the above guidelines
can cause uneven aging of LED Displays that leave subtle, but
permanent burned-in ghost images in the LED picture. To avoid
this, vary the programming and images, and primarily display full
screen moving images, not stationary patterns or dark bars. On
LED models that offer picture sizing features, use these controls to
view different formats as a full screen picture.
Be careful about the television formats you select and the length of time you
view them. Uneven LED aging as a result of format selection and use, as well
as burned in images, are not covered by your Samsung limited warranty.
STATEMENT
limitations of the original Limited Warranty supplied with
conditions, exclusions and limitations contained herein, SAMSUNG
will additionally provide Warranty Repair Service in the United
States on SAMSUNG products purchased in Canada, and in Canada
on SAMSUNG products purchased in the United States, for the
only.
The above described warranty repairs must be performed by a
SAMSUNG Authorized Service Center. Along with this Statement,
the Original Limited Warranty Statement and a dated Bill of Sale
as Proof of Purchase must be presented to the Service Center.
Transportation to and from the Service Center of TVs 40" or smaller
is the responsibility of the purchaser. Conditions covered are
limited only to manufacturing defects in material or workmanship,
and only those encountered in normal use of the product.
provisions for in-home or on-site services, minimum or maximum
repair times, exchanges or replacements, accessories, options,
upgrades, or consumables.
For the location of a SAMSUNG Authorized Service Center, please
call toll-free:
✎ In the United States: 1-800-SAMSUNG (1-800-726-7864)
✎ In Canada: 1-800-SAMSUNG
Still image warning
image elements (such as TV channel logos, TV shows or movies
screen. The constant display of still pictures can cause ghosting
or image burn-in (image retention) on the LED screen, which will
the recommendations below:
Avoid displaying the same TV channel for long periods.
Always try to display any image in full screen mode. Use the TV's
Picture Options menu to select the optimal screen size.
minimum may speed up the burn-in process.
and screen burn-in. Refer to proper user manual section for
details.
© 2016 Samsung Electronics Co., Ltd. All rights reserved.
Contact SAMSUNG WORLDWIDE
please contact the SAMSUNG customer care center.
Country CANADA U.S.A
Address
Samsung Electronics Canada
Inc. 2050 Derry Road West,
Mississauga, Ontario L5N
0B9 Canada
Samsung Electronics
America, Inc. 85 Challenger
07660
Customer Care
Center
1-800-SAMSUNG (726-7864)
Web Site
support (English)
support (French)
support
LED TV
user manual
-01
- 2 -- 1 -
- 6 -- 5 -
- 3 -
- 7 -
- 4 -
- 8 -
Boot Logo
Enable or disable the display of the Samsung logo when you turn
on the TV.
Eco Solution
■
Energy Saving (Off / Low / Medium / High): Lets you adjust the
brightness of the TV to reduce power consumption.
■
No Signal Power Off (Off / 15 min. / 30 min. / 60 min.): Sets how
received.
✎ Disabled when an attached PC is in power saving mode.
■
Auto Power Off (Off / On): When Auto Power Off is set to On,
the TV will automatically turn off when no user operation is
detected for 4 hours.
Auto Protection Time
■
Auto Protection Time (Off / 2 hours / 4 hours / 8 hours / 10
hours): If the screen remains idle with a still image for a certain
prevent the formation of ghost images on the screen.
Input Menu
Source List
Use to select TV or other external input sources such
receiver connected to the TV.
1. Press the SOURCE button.
2. Select a desired external input source.
■
TV / AV / Component / HDMI1 / HDMI2/DVI
You can only choose external devices that are connected to the
TV. In the Source List, connected inputs are highlighted.
How to use Edit Name
Edit Name lets you associate a device name to an input source,
making it easier to select a source. To access Edit Name, enter the
Input menu, and then select Edit Name. Select the name of the
device from the drop down next to the name of the input jack it is
connected to. For example, if your Blu-ray player is connected to
HDMI 2, select Blu-ray player from the drop down next to HDMI 2.
✎ If you have connected a PC to the HDMI IN 2 (DVI) port with
an HDMI cable, you should select PC mode in Edit Name.
✎ If you have connected a PC to the HDMI IN 2 (DVI) port with
an HDMI to DVI cable, you should select DVI PC mode in Edit
Name.
✎ If you have connected an AV device to the HDMI IN 2 (DVI)
port with an HDMI to DVI cable, you should select DVI mode
in Edit Name.
Application Menu
USB Mass Storage Class (MSC) device.
P
POWER
MEDIA.P
❑ Connecting a USB Device
1. Turn on your TV.
2.
USB jack on the back of the TV. A pop up window
appears.
3. Press the MEDIA.P button on your remote. The Media Play
menu appears.
❑ Using the Media Play Menu
USB
Change Device
E
Enter
R
Return
Media Play
Videos
To open Media Play in the Menu, follow these steps:
1. Press the MENU
Applications on the left, and then press the ENTER
E
button.
2. Media Play (USB), and then
press the ENTER
E
button.
3. Videos, Music,
Photos, Settings), and then press the ENTER
E
button.
✎ Media Play might not work properly with unlicensed
multimedia files.
✎ Read the list below before using Media Play (USB)
x The file system supports FAT16, FAT32, and NTFS.
x Certain types of USB Digital camera and audio devices may not
be compatible with this TV.
x Media Play only supports USB Mass Storage Class (MSC)
devices. MSC is a Mass Storage Class Bulk-Only Transport
device. Examples of MSC are Thumb drives and Flash Card
Readers. Devices should be connected directly to the TV’s USB
port. USB HDD is not supported.
x Before connecting your device to the TV, please back up your
files to prevent file damage or loss of data. SAMSUNG is not
responsible for any data file damage or data loss.
x
be supported.
x Do not disconnect the USB device while it is loading.
x The higher the resolution of the image, the longer it takes to
display on the screen.
x The maximum supported JPEG resolution is 15360 x 8640 pixels.
x
“Not Supported File Format” message appears.
x The TV cannot play MP3 files with DRM that have been
downloaded from a for-pay site. Digital Rights Management
(DRM) is a technology that supports the creation, distribution,
and management of digital content in an integrated and
comprehensive way, including protecting the rights and
interests of content providers, preventing illegal copying of
contents, and managing billing and settlements.
x PTP (Pier to Pier) devices are not supported.
x If an over-power warning message is displayed while you
are connecting or using a USB device, the device may not be
recognized or may malfunction.
P
POWER
MEDIA.P
Loading ...
