48-22-1903
FASTBACK™ FLIP UTILITY KNIFE with Blade Storage
Apr. 2016
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 --------------- Belt Clip (1)
2 --------------- M2.5 x 0.45 Phillips P1 Screw (1)
3 --------------- M2 x 0.4 Flat Hd. Phillips Screw (4)
4 14-46-0114 Belt Clip/Screw Service Kit (Contains all the above) (1)
54-49-3117
REVISED BULLETIN
SERVICE PARTS LIST
BULLETIN NO.
WIRING INSTRUCTION
DATE
CATALOG NO.
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
SERIAL
NUMBER
EXAMPLE:
Component Parts (Small #) Are Included
When Ordering The Assembly (Large #).
0
00
48-22-1906
FASTBACK™ COMPACT FLIP UTILITY KNIFE
REVISED BULLETIN
WIRING INSTRUCTION
DATE
CATALOG NO.
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
SERIAL
NUMBER
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 --------------- Belt Clip (1)
2 --------------- Belt Clip Screw (1)
3 --------------- M2 x 0.4 Flat Hd. Phillips Screw (4)
4 14-46-0113 Belt Clip/Screw Service Kit (Contains all the above) (1)
MILWAUKEE TOOL
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
1
2
3 (4x)
Blade Clamp Cover
NOTE:
Apply a drop of non-permanent thread locking sealant
(Loctite
®
222 or the equivalent) to the threads of each
screw prior to installation. Fastener heads #3 must be
subflush to the blade holder cover.
1 2
3
4
1
2
3 (4x)
Blade Clamp Cover
NOTE:
Apply a drop of non-permanent thread locking sealant
(Loctite
®
222 or the equivalent) to the threads of
each screw prior to installation. Fastener
heads #3 must be subflush to the blade
holder cover.
1 2
3
4
