SKS7176GD / SKS7170GG
SKS7177CH / SKS7178BK
EN
SMART BLUETOOTH KITCHEN
SCALE
Translation of the original manual
SKS7176GD / SKS7170GG
SKS7177CH / SKS7178BK
A
UNIT
3
4
5
6
1
2
B
1
2
3
4
5
6
7
- 1 -
02/2025
2025, .
EN
Smart Bluetooth Kitchen Scale
User Manual
Important Safety Instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
• This appliance is designed for household use. Do not use it for commercial purposes, forweighing animals or forother purposes for which it is not
intended.
• This appliance may be used by children and by persons with physical, sensory or mental impairments or by inexperienced persons, if they are
properly supervised.
• Children must be supervised to ensure that they do not play with the appliance.
• Do not use the appliance outdoors, place it on unstable surfaces, on an electric or gas stove, in the vicinity of an open flame or other sources of heat.
• Do not expose the appliance to direct sunlight or high humidity and do not use it in excessively dusty environments.
• In use, it must be ensured that the appliance is placed on an even, smooth, hard andstable surface. Otherwise, inaccuracies in weighing may occur.
• If the maximum weighing capacity is exceeded, remove the ingredient or object ofexcessive weight from the weighing area to avoid possible
damage to the appliance.
• Do not use the appliance to support various items. When storing, it must be ensured that no objects are placed on the appliance.
• Always use new batteries of the same type. Never combine old andnew batteries or batteries of various types. Never put batteries in afire, short-
circuit or damage them in any way. Dispose of them in an environmentally friendly manner at the end of their lifespan. Never dispose of batteries in
municipal waste.
• If you will not be using the appliance for an extended period of time, remove the batteries. If the battery were to leak into the interior of the appliance,
the appliance could be damaged.
• Do not use rechargeable batteries to power this appliance.
• Keep batteries out of the reach of children, because they may present adanger intheir presence. If the child swallows the battery, immediately seek
medical help.
• Keep the appliance clean. When cleaning, follow the instructions in the chapter “Cleaning and maintenance”. Do not immerse the appliance in water
or other liquids or rinse it under running water.
• Do not repair or modify the appliance yourself. All repairs should be carried out by an authorised service centre. Tampering with the appliance may
result in the loss of your legal rights regarding faulty performance or warranty for quality.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EXPLANATION OF SYMBOLS PLACED ON THE PRODUCT OR INTHE ACCOMPANYING DOCUMENTATION
The product meets all the basic requirements of the applicable EU directives.
This symbol on products or original documents means that used electric or electronic products must not be added to ordinary municipal
waste.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SMART BLUETOOTH KITCHEN SCALE
- 2 -
02/2025
2025, .
• Thank you for purchasing our SENCOR product; we hope it will serve
to your satisfaction.
• Prior to using this appliance, please read the user manual thoroughly,
even in cases when you are already familiar with the use of similar
types of appliances. Use the appliance only as described in this
user manual. Keep the manual for future reference. If you pass the
appliance on to another person, ensure that this user manual is
included.
• Carefully unpack the appliance and make sure not to discard any part
of the packaging material until you have found all its components. It
is recommended to keep the original packaging, packing material,
receipt and confirmation of the extent of the seller'sliability or warranty
certificate at least for the duration of the legal right of defective
performance or quality guarantee. When transporting the appliance,
we recommend packaging it again in the original box provided by the
manufacturer.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE APPLIANCE
A1 Weighing andmeasuring area
A2 Button for switching weighing
andmeasuring units (on the
bottom)
A3 TARA button
A4 button toswitch the scale
on/off
A5 Display
A6 Battery compartment (on the
bottom)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE DISPLAY
B1 Tara function icon (weighing)
B2 Zero value icon
B3 Negative sign
Shown in TARA mode after
removing the food container
from thescale
B4 Display of the unit:
lb:oz = Imperial weight unit
g = Metric weight unit
B5 Weight weighing icon
B6 Bluetooth icon
B7 Weight indication
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PURPOSE OF USE
The kitchen scale is designed to be used for weighing food andsmall
items up to 8000 g.
Thanks to the connection with the Sencor Food application on your
smartphone, you get not only weight data, but also the energy
andnutritional value of the weighted food inagiven amount.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEFORE FIRST USE
• Take the kitchen scale out of the packaging andremove all packaging
materials, advertising labels or protective foils.
• Wipe the kitchen scale with asoft cloth slightly dampened in warm
water. Wipe with adry cloth.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
POWER SUPPLY AND BATTERY REPLACEMENT
The scale is powered by alkaline batteries (2×1.5VAAA). The batteries
are included andare already inserted in the battery compartment at the
bottom of the scale. Inorder to protect against discharge anddamage to
the scale, they are protected with insulating tape and this tape must be
removed before using the scale.
As soon as the display shows “Lo”, both batteries need to be replaced
with new ones. Open the battery compartment cover andremove the
discharged batteries. Insert new batteries of the same type. Observe
the correct polarity, which is shown on the bottom of the battery
compartment, and fit the cover.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CHOICE OF WEIGHT UNITS
The scale allows you to switch between metric andAnglo-American units
using the UNIT button on the bottom of the scale. Dependingon the set
mode, icons of metric units (g) or Anglo-American units (lb:oz) will appear
on the display.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TURNING THE SCALE ON/OFF
• Press the button to turn the scale on. Wait until “0” is shown on
the display.
• Long press the button to switch off the scale.
• The scale automatically turns off after afew minutes of inactivity.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
WEIGHING
• Place the scale on aflat and stable surface. Touch the weighing area
to switch the scale on. Wait until “0” is shown on the display.
• Place the ingredients to be weighed in the centre of the area. The
display will show its weight.
Note:
We recommend not to put the ingredients directly on the
scale, but to use afood foil, abowl or another container. If
you will be weighing ingredients in abowl, press the TARA
button to reset the weight of the bowl on the scale.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TARA FUNCTION
The TARA function is used when you want to gradually weigh several
ingredients in one container without removing the container from the
scale. This function will automatically subtract the weight of the container
from the total weight of the ingredients.
1. Place the empty container on the scale. The display will show its
weight. Pressing the TARA button will reset the value and the “T”
symbol lights up.
2. Put the first food into the container. The display will show its weight.
Pressing the TARA button will reset the value and the “T” symbol
lights up. The weight of the first food is stored in the memory and the
scale is ready forfurther weighing.
3. Put the second food in the container. The display will show its
weight. Press the TARA button to display the sum of the weight of
the first and second ingredient. Pressing TARA again saves the sum
to memory and resets the display to zero. The “T” symbol remains
lit.
4. Add more ingredients in the same way up to the maximum weight
capacity (8000 g).
5. Once you remove thefood container from thescale, anegative value
will appear on the display.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ERROR MESSAGES
Display What to do
Lo Batteries are flat. Replace the batteries. More information in
chapter POWER SUPPLY AND BATTERY REPLACEMENT.
Err You have exceeded the maximum weighing capacity of the
scale (8000 g).
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EN
Smart Bluetooth Kitchen Scale
User Manual
- 3 -
02/2025
2025, .
CONNECTING THESCALE AND YOUR SMART DEVICE
• The scale is equipped with Bluetooth wireless technology, which in
conjunction with the free Sencor FOOD app installed on your smart
device offers direct access to arich and regularly updated database of
foods and their nutritional values.
• The Sencor FOOD app was developed in collaboration with the
creators of the Calorie Tables / Dine4Fit app and is designed for
smartphones running iOS (version 13 and above) or Android (version
5 and above). When using the app, the phone must be connected to
theinternet.
• The connection of the scale to thephone takes place automatically
after starting the application. To pair, it is sufficient for the Bluetooth
function to be turned on on the smart device. If the app does not find
the scale, it will actively prompt you to try to reconnect the scale.
• When the scale is paired with the application, the Bluetooth icon is
lit on the display. When the scale is not paired with the app or the
connection has been broken, the Bluetooth icon will be extinguished.
Note:
The scale can only connect toone mobile device at atime.
If you have problems with pairing, make sure that there
is no other device withinreach that is actually actively
connected to thescale.
The app offers three weighing modes:
1. “On the Scale” Mode
Displays the weight of the currently weighed item. After you tell
the scale what food you weigh using the “Search Food” field, it will
display the nutritional values of the food in relation to the current
weight.
2. “Recipes” mode
In this section you will find recipes that we have prepared for you.
The recipes are compiled using SENCOR food processors. The recipe
will guide you through the preparation and help you to record the
actually weighted weights of the individual ingredients in the List tab.
3. “List” Mode
It allows you to determine the aggregate nutritional value of more
food. This mode is useful, for example, when preparing adish
according to arecipe. Gradually add the food to the scale, using
the “Search Food” field to enter what food it is. Once you have
determined the weight andtype of food, use the “+ Add food to list”
button to add it to the total nutritional sum. Use the /TARA button
on the scale for adding to weight as needed during weighing. The
scale continuously shows the total weight of the ingredients and
calculates the weights of the individual nutritional components (for
example, how many grams of carbohydrates the weighed food
contains in total) throughout the weighing in the “List” mode.
Entering/Searching for aWeighed Food
You can find asummary of the nutritional values of aweighed food by
entering the name of the food in the “Search Food” status bar. Click on the
status bar and the cursor andkeyboard will appear. Enter the name of the
food or akeyword, the application will search for the relevant food or alist of
foods withakeyword, andselecting afood will display its nutritional values.
You can find the nutritional summary more quickly, practically
andaccurately by scanning aunique EAN barcode from the food
packaging. Click on the barcode icon to the right of the “Search Food”
status bar and scan the barcode. Asummary of nutritional values is
displayed.
Note:
If you didn't allow the app to use the camera and video
recording feature when you installed the app (or when
adjusting the settings), enable the feature. Otherwise it will
not be possible to scan the barcodes.
Note:
The Sencor FOOD app is linked tothe Calorie Tables app.
At the end of the weighing, you can enter your food into
your diet in the Calorie Tables with one click and keep
along-term overview of your food intake (ATTENTION:
Some advanced features of the Calorie Tables app may be
subject to afee).
Possible Problems with theApp andTheir Solutions
The app does not search for the weighted food item.
• Please check your current internet connection.
Bluetooth connection failed.
• Check that only one device is connected to the scale.
• Check that the Bluetooth version on your device is 4.0 andlater.
The data from the scale cannot be displayed in the application.
• Check that you have enabled the Bluetooth feature on your phone/
tablet.
• Check that you are within therange of the Bluetooth signal.
• Check that the batteries in the scale are not dead. Replace the
batteries with new ones.
• Restart the app.
• Reset the operating system and the Bluetooth connection.
If you are near other devices transmitting in the same frequency band as
Bluetooth (Wi-Fi router, DAB radio, microwave oven, other smart phone,
etc.), interference may occur. Try moving the scale or smart device to
adifferent location.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
- 4 -
02/2025
2025, .
CLEANING AND MAINTENANCE
• Use asoft sponge slightly dampened in warm water to clean the
scale. Wipe dry with aclean cloth.
• Do not use wire cloths, abrasive cleaners, thinners, etc. for cleaning.
Otherwise the surface may be damaged.
• Do not immerse the scale in water or other liquid or rinse it under
running water. The outer body of the appliance is not intended to be
washed in adishwasher.
• Never dry the scale over aheat source such as astove, electric or gas
stove, etc.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
STORAGE
• After finishing using the scale, store it in asuitable place out of the
reach of children. Keep the stored deep fryer away from extreme
temperatures, direct sunlight and excessive humidity and do not store
it in an overly dusty environment.
• If you will not be using the scale for an extended period of time,
remove the batteries.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TECHNICAL SPECIFICATIONS
Power source .........................................................................2× 1.5 VAAA batteries
Weight capacity (maximum load capacity) ....................................8 kg / 17.6 lb
Weighing accuracy .....................................................................................1 g / 0.1 oz
Choice of units ................................................................................................... g / lb:oz
SENCOR hereby declares that the radio device type SKS7176GD /
SKS7170GG / SKS7177CH / SKS7178BK conforms to the 2014/53/EU
directive. The full text of the EU Declaration of Conformity is available at:
www.sencor.eu.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTRUCTIONS AND INFORMATION ON DISPOSAL OF USED
PACKAGING MATERIAL
Dispose of used packaging material at the location designated by the
municipality for waste disposal.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
Used electrical andelectronic products must not be added to ordinary
municipal waste. For proper disposal and recycling of these products,
deliver them to designated collection points. Alternatively, in some
European Union states or other European countries the products can be
returned to the local retailer when buying an equivalent new product. By
properly disposing of this product, you help preserve valuable natural
resources and contribute to preventing potential negative impacts on the
environment and human health resulting from improper waste disposal.
For more details, contact your local authority or nearest collection point.
Fines may be imposed for improper disposal of this type of waste as per
national regulations.
For Business Entities in European Union States
To dispose of electric or electronic equipment, request necessary
information from your retailer or supplier.
Disposal in Other Countries Outside the European Union
To dispose of this product elsewhere, request necessary information on
the correct disposal method from local authorities or your retailer.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changes to text and technical parameters are reserved.
FAST ČR, a.s.
U Sanitasu 1621
CZ-251 01 Říčany
www.sencor.com
info@sencor.cz
