Models: MRSGK15B / MRAK5WT
MRAK5DR / MRAK5MG
INSTRUCTION MANUAL
Read these instructions carefully before
using this appliance for the rst time.
STORE THESE INSTRUCTIONS CAREFULLY
Ascend Pyramid Kettle
For product hints and tips plus more join us at
facebook.com/MorphyRichardsAUS instagram.com/morphyrichardsau
www.morphyrichards.com.au
2
WARNING
To reduce the risk of fire, electric shock, injury to persons or
damage to property, follow basic precautions including the
following:
WARNING: Avoid spillage on the connector.
WARNING: Misuse can lead to injury.
WARNING: Heating element surface is subject to residual heat
after use.
WARNING: Do not operate kettle on an inclined plane.
WARNING: Do not move kettle while in use.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• Cleaning and user maintenance shall not done by children.
• Keep the appliance and its cord out of reach of children.
• This appliance is intended to be used in household and similar
applications such as: farm houses; by clients in hotels, motels
and other residential type environments; bed and breakfast
type environments. It is not suitable for use in staff kitchen
areas in shops, offices and other working environments.
Location
WARNING: Do not place the appliance on a metal tray or metal
surface while in use.
• Always locate your appliance away from the edge of a
worktop.
IMPORTANT SAFETY INSTRUCTIONS
3
• Ensure that the appliance is used on a firm, flat surface.
• Do not use the appliance outdoors or near water.
Power cable
• Do not let the power cable hang over the edge of a worktop
where a child could reach it.
• Do not let the power cable run across an open space e.g.
between a low socket and a table.
• Do not let the power cable run across a cooker or other hot
area which might damage the cable.
• The power cable should reach from the socket to the base
unit without straining the connections.
• If the power cable is damaged, it must be replaced by the
manufacturer, it’s service agent or similarly qualified person in
order to avoid a hazard.
• It is recommended to not use this appliance with extension
leads and/or power boards.
Personal safety
• WARNING: To protect against fire, electric shock and personal
injury do not immerse cord, plug and appliance in water or
any other liquid.
• WARNING: Do not open the lid whilst the water is boiling.
• Always keep the top of the cordless base dry, especially
around the connection area, disconnect the power supply
before drying. Allow to dry thoroughly before reconnection to
the power supply.
• Do not fill above the MAX mark, otherwise boiling water may
be ejected.
• Always pour hot water slowly and carefully without tipping the
appliance too fast to prevent splashing and spillage.
• Do not hold the switch in the on position or tamper with the
switch to fix it in the on position as this may cause damage to
the switch-off mechanism.
• Unplug from the outlet before cleaning.
4
• Allow to cool before putting on or taking off parts and before
cleaning.
• Do not move the kettle while switched on.
Other safety considerations
• WARNING: The appliance must not be immersed for cleaning.
• WARNING: To prevent damage to the appliance, do not use
alkaline cleaning agents when cleaning. Use a soft cloth and
detergent.
• The use of attachments or tools not recommended or sold by
Morphy Richards, may cause fire, electric shock or injury.
• The kettle is only to be used with the stand provided.
• Do not use the appliance for any use other than to boil water.
• Do not place the appliance on or near a hot gas or electric
burner or in a heated oven.
• The appliance must not be on the base unit when being filled
with water.
• Unplug from the outlet when not in use.
Electrical requirements
• Check that the voltage on the rating label of your appliance
corresponds with your house electricity supply which must be
A.C. (Alternating Current).
Treating scalds
• Run cold water over the affected area immediately. Do not stop
to remove clothing, seek medical advice quickly.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WHISTLE FEATURE
There is a switch on the cordless base of the product that can
switch the whistle on and off as desired. Refer to page 5.
5
Model:
MRSGK15B MRAK5WT MRAK5DR MRAK5MG
Colour:
Black White
Dragon
Red
Mushroom
Grey
Rated Voltage & Frequency: 220-240V~ 50-60Hz
Rated Power: 1850-2200W
Max Capacity: 1.5L
External Dimensions (L x W x H): 220 x 240 x 273mm
Net Weight: 1.42 Kg
PRODUCT OVERVIEW
SPECIFICATIONS
1. Lid
2. Lid knob
3. Spout lter
4. 360° connector
5. Cordless base
unit
6. Cord storage
7. On/off switch
8. Power on neon
9. Water level
indicator
10. Whistle on/off
switch (Depends
upon model)
10
6
BEFORE FIRST USE
1. Remove all packaging materials.
2. Check that all accessories are complete and the appliance is
not damaged.
3. Clean all parts to remove any dust or manufacturing residue.
4. If you are using the kettle for the first time, it is recommended
that you should clean your kettle before use by boiling the
Max capacity of water and then discarding the water twice.
Wipe the surface with a damp cloth.
NOTE: The maximum capacity of this kettle is 1.5L.
FILTER REMOVAL
1. Open the lid.
2. Lift the filter upwards from its holder.
3. To refit the filter, slide it into the side wall guides of the filter
holder until it clicks into place.
WARNING: Unless the filter is fitted correctly, the kettle lid may
not close and lock securely.
USING YOUR KETTLE
1. Wherever possible, fill through the spout, as this helps to free
the filter from limescale build-up. The integrated water level
indicator allows you to easily see the amount of water in the
kettle.
Always ensure that the level of water in the kettle is filled to at
least the minimum level shown on the water gauge.
7
2. Place the kettle on the base unit, ensuring the kettle locates
on to the 360° connector. The 360° connector allows the kettle
to be located at any position. Ideal for left and right handed
users and for convenient positioning on the worktop.
3. Plug in and switch on at the wall socket.
4. Switch the kettle on. The ‘power on’ light will illuminate.
5. Fast boil kettles perform differently, if your kettle is a fast boil
model, it may sound louder during boiling, and switch off
suddenly with no after noise - this is normal.
6. When the water boils the kettle will switch off automatically.
If you are using the kettle for the first time, pour away the
boiled water and refill.
7. Lift the kettle from the base unit by the handle ensuring you
hold the kettle level. To re-boil, switch ON again. If the kettle
has just switched off wait a minute or two before switching it
back on again. If you do not put in enough water, or switch on
the kettle when it is empty, the safety cut-out will switch off
the power automatically. If this happens, refill and wait a few
minutes for the element to cool, then use as normal.
USING YOUR KETTLE
8
WARNING: Always disconnect the plug from the mains and allow
the kettle to cool before cleaning.
CAUTION: To prevent damage to the appliance do not use alkaline
cleaning agents when cleaning, use a soft cloth and a mild
detergent.
Wipe the outside with a damp cloth.
IMPORTANT: Do not use abrasive cleaners on the outside of the
kettle which may scratch the surface.
CLEANING
1. Fill the kettle 3/4 full, boil, then unplug the kettle (remove the
cordless kettle from the base unit) and stand it in an empty sink
or bowl.
2. Add 50gm of citric acid crystals to the water gradually, then
leave the kettle to stand. Do not use a more concentrated
solution.
3. As soon as the effervescence subsides, empty the kettle and
rinse it thoroughly with cold water.
4. Wipe the outside of the kettle thoroughly with a damp cloth to
remove all traces of acid which may damage the finish.
IMPORTANT: Ensure that the electrical connections are completely
dry before using the kettle.
IMPORTANT: As this kettle is fitted with a concealed element it
must be descaled regularly. The frequency of descaling depends
on usage and the hardness of the water in your area.
Excessive scale can cause the kettle to switch off before boiling
and may damage the element invalidating the warranty.
It is essential that regular descaling takes place.
Remove hard scale using a proprietary descaling product
suitable for stainless steel kettles.
Alternatively use citric acid crystals (available from most
pharmacies) as follows.
DESCALING
9
WARRANTY
Please refer to the warranty card in the box for warranty information.
For any troubleshooting advice, please contact the relative Customer
Care Centre below.
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
8 Lakeview Drive, 38 Harris Road, East Tamaki,
Scoresby 3179, Victoria Auckland 2013
Australia New Zealand
Ph: 1300 556 816 Ph: 0800 666 2824
MAINTENANCE
If the unit fails to operate efficiently, is broken or other problems
arise, unplug and do not operate.
Ask for advice by calling your local after sales service agent or
the Customer Care Centre on 1300 556 816 (AU) / 0800 666 2824
(NZ).
10
