INSTRUCTION MANUAL
STICK MIXER
300W
WHSM06SS220~240V
SAFETY INFORMATION
Important Safety Instructions ........................ . . . . . . . . . . . . . 1 - 2
Electrical Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SETUP AND USE
Installation Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Parts and Features .................................... . . . . . . . . . . . . . 4
Stick Mixer Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
CLEANING AND CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 9
CONTENTS
Figures and illustrations in this User Manual are provided
for reference only and may differ from actual product appearance.
Product design and ations may be changed without notice.
© 2023 RVM Australia Pty Ltd. All Rights Reserved
1
IMPORTANT SAFETY INSTRUCTIONS
***WARNING***
1. Read all instructions carefully before using your new stick mixer. Keep these
instructions in a safe place.
2. Always use this stick mixer with a power outlet of the voltage (A.C. only) marked
on the back of the appliance.
3.
DANGER Do not operate stick mixer if:
i) the cord or plug is split, melted or damaged.
ii) the appliance has malfunctioned.
iii) the appliance has been damaged in any manner.
If any of the above incidents occur, return the stick mixer to the nearest authorised
service center for examination, repair or adjustment.
4.
DANGER Do not under any circumstances immerse the power cord, mains
plug or stick mixer body in water or any other liquid.
5.
WARNING Incorrect operation and improper use may damage the stick mixer
or parts thereof, and cause severe personal injury.
6.
WARNING When operating the stick mixer, use handle and buttons only as
outer surfaces may become hot whilst the stick mixer is in use.
7.
WARNING Do not blend hot or boiling foods or liquids as there is a risk of
burns or scalding.
8.
WARNING The stick mixer blades are very sharp, avoid touching them and
handle with care.
9.
WARNING Do not plug the appliance to mains before it is fully assembled.
10.
WARNING Exercise caution when removing the attachments from the
attachments.
stick mixer and ensure the appliance is turned off and unplu
11.
WARNING
WARNING
Keep hands and utensils out of the blending container while
blending to reduce the risk of severe injury. A scraper may be used but must only
be used when the stick mixer is not running.
12. Do not handle the appliance with wet hands.
13.
CAUTION The stick mixer should not be left unattended while in operation.
14.
CAUTION Keep the stick mixer and its cord out of reach of children younger
than 8 years old.
15.
CAUTION It is not recommended to run the stick mixer continuously for more
than 1 minute at a time for light substances. Do not mix dry, thick or heavy
mixtures continuously for more than 15 seconds. Stop the operation and stir the
ingredients before continuing.
DANGER - Immediate hazards
which WILL result in severe
personal injury or death.
DANGER
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death.
WARNING
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury.
CAUTION
2
16.
CAUTION Do not use this stick mixer with any attachment other than the
one supplied.
as this may cause damage to the stick mixer.
17.
CAUTION Do not chop extremely hard food items, such as ice cubes, nutmeg
18. All stick mixers are designed to operate only when the power buttons remain
depressed.
19. Always ensure hands are dry before handling the plug or switching on the
appliance.
Ensure the stick mixer is switched off and unplugged from the power source
20.
prior to cleaning.
21. This stick mixer is not intended for use by persons (including children) with
reduced physical, sensory or metal capabilities or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the stick mixer in a safe way by the person responsible for their safety, and
understand the hazards involved.
22. Children should be supervised not to play with the stick mixer.
Always turn off the power at the power outlet before you insert or remove the
23.
power plug. Remove by grasping the plug - do not pull on the cord.
24. This appliance is intended for non-commercial, indoor use only. Do not use this
appliance for anything other than its intended use.
25. Alwa ys hold the stick mixer
and upright while using it.
26. Always use the appliance on a stable, secure, dry and level surface.
27. This stick mixer is not intended to be operated by means of an external timer or
separate remote-control system.
28. Wait for the stick mixer to cool before moving. Carry only by the handle.
29. Pay close attention when using this appliance near children.
30. Do not place your stick mixer on or near a hot gas e, electric element, heated
oven or any hot surface.
31. Do not place the stick mixer on top of any other appliance.
32. Do not permit the mains supply cord or plug to touch hot objects, or allow the
power cord to lay across the stick mixer body or blades.
33. Do not allow the power cord of this appliance to hang over the edge of a table or
bench top.
34. nding to reduce
the risk of severe injury.
35. This appliance is intended to be used in household and similar applications such
as:
onments;
– farm houses;
– by clients in hotels, motels and other residential type environments;
– bed and breakfast type environments.
36. Do not operate the appliance continuously for longer than one minute as the
appliance may overheat.
37.
Misuse may cause potential injury.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
38. Ensure the unit is unplugged from the power source if left unattended.
© 2023 RVM Australia Pty Ltd. All Rights Reserved
3
POWER SUPPLY CORD
1. Do not attempt to modify the power cord or plug in any way.
2. A short power supply cord is provided to reduce the risk of entanglement or
tripping over.
3. If the power supply cord is too short, do not use an extension cord. Have a
ceman install an outlet near the appliance.
NOTE: Neither Westinghouse nor the retailer can accept any liability for damage
to the product or personal injury resulting due to failure to observe the electrical
connection procedures.
ELECTRICAL REQUIREMENTS
INSTALLATION GUIDE
1. Carefully unpack your electric stick mixer.
2. Carefully remove packaging around the stick mixer and straighten the power
cord. Do not remove warning labels.
3. Wash blender blade attachment and allow to dry before use.
DANGER Do not under any circumstances immerse the power cord, mains plug or
stick mixer body in water or any other liquid.
WARNING The stick mixer blades are very sharp, avoid touching them and handle
with care.
ing attachments.
WARNING Exercise caution when removing the attachments from the stick mixer
NOTE: Westinghouse recommends the use of a resiual current device (RCD) with
a tripping current that does not exceed 30mA in the electrical circuit supplying
power to all appliances.
4
6. Chopper Attachment
7. Whisk Attachment
PARTS AND FEATURES
1. Non-Slip Rubber Cover
2.
3. Blender Attachment
800ml Beaker
1
2
3
4
5
6
7
8
9
4. Masher Attachment
5. Attachment Stand
8. Beaters Attachment
9. Mixer Body
© 2023 RVM Australia Pty Ltd. All Rights Reserved
5
STICK MIXER OPERATION
1. Before st use, the accessories must be cleaned. Wash the attachments with
warm water and mild detergent. Rinse with fresh water and allow to dry. Your
stick mixer is now ready for use.
2. Ensure unit is unplugged from wall power outlet.
3. Whilst holding the stick mixer body upright, insert desired attachment into
mixer body and twist the attachment
4. Ensuring your are not pressing either of the buttons on the front of the
unit, plug the power cord into the power outlet and switch on.
5. Add ingredients into an appropriate mixing container.
6. Press the on/off or turbo button to start the mixer.
7. After use, unplug from the wall power outlet.
8. Whilst holding the stick mixer body upright, twist the attachment clockwise
and lightly pull away from the stick mixer body to remove the attachment.
WARNING The blender and chopper blades are very sharp, avoid touching
them and handle with care.
ing attachments.
WARNING Do not plug the appliance into power before it is fully assembled.
WARNING Exercise caution when removing the attachments from the stick mixer
NOTE: All stick mixers are designed to operate only when the power buttons remain
depressed.
WARNING Do not blend hot or boiling foods or liquids as there is a risk of burns
or scalding.
CAUTION It is not recommended to run the stick mixer continuously for more
than 1 minute at a time for light substances. Do not mix dry, thick or heavy mixtures
continuously for more than 15 seconds. Stop the operation and stir the ingredients
before continuing. Allow the motor to rest for 1 minute between each use.
anti-clockwise until it locks.
NOTE: The non-slip rubber cover can also be used as a lid for the 800ml beaker.
6
CLEANING & CARE
1. After use, unplug from the wall power outlet then twist the attachment
2. Do not use harsh or abrasive cleaning agents. The outside surface of the stick
mixer body may be wiped clean with a soft, damp cloth and dried thoroughly.
If necessary, a mild dishwashing detergent may be applied to the cloth but not
directly applied to the stick mixer.
3. Do not soak or immerse the stick mixer body in water or any other liquid.
4. to remove
most food substances.
5. When washing, non-abrasive cloths and plastic bristle kitchen brushes may be
used to remove stubborn food particles from the accessories. Do not use abrasive
cloths and cleaning materials as they will damage the surface.
6. Ensure all components are dried thoroughly after cleaning, before placing into
storage.
7.
Store in a dry place away from steam and humidity where possible.
DANGER Do not under any circumstances immerse the power cord, mains plug or
stick mixer body in water or any other liquid.
WARNING The blender and chopper blades are very sharp, avoid touching them
and
handle with care.
the stick mixer.
WARNING Exercise caution when removing the blender blade attachment from
clockwise, whilst holding the mixer body upright, and lightly pull away from the
mixer body to remove the attachment.
!"#$%'()
!(+
,(
(
© 2023 RVM Australia Pty Ltd. All Rights Reserved
7
TROUBLESHOOTING
BEFORE CALLING FOR SERVICE
If the stick mixer fails to operate:
1. Check to make sure the stick mixer is plugged in correctly and securely. If it is not,
remove the plug from the outlet, wait 10 seconds and plug it back in securely.
2. Check for a blown or tripped circuit breaker in your home. If these seem to be
working correctly, test another appliance in the same outlet to ensure the outlet
is working correctly.
IF NONE OF THE ABOVE SOLVES THE PROBLEM, DO NOT TRY TO ADJUST OR
REPAIR THE STICK MIXER YOURSELF.
CUSTOMER SERVICE
In the event you believe your stick mixer to be defective, please return it along with
your sales receipt to the place of purchase for resolution.
For any enquiries, please call our service center on: Tel: 1300 883 109
TROUBLESHOOTING
Troubleshoot your problem by using the chart below. If the stick mixer still does not
operate correctly, it may be defective.
TROUBLE POSSIBLE CAUSE
Stick mixer does
not turn on.
Stick mixer is not
plugged in.
Check that stick mixer is
plugged into a working
power outlet and turned on.
POSSIBLE REMEDY
Motor slowing down
and appears to be
struggling while in use.
Foods are too dense
or too much food in
your container.
Reduce quantity
of
food
and
try again.
8
LIMITED WARRANTY
1.
Consumer Law. The to the Consumer under this Warranty are in addition
Nothing in this warranty affects the Consumer’s rights under the Australian
to the rights and remedies of the buyer under any Consumer Guarantees. The
Australian Consumer Law requires that we cat:
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure
and for compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
2. Subject to Clause 1, the Seller warrants that Westinghouse branded products will
be free of manufacturing defects and will perform to the Seller’s ations
subject to the following clauses.
3. The of this Warranty extends only to the owner of the property in which
the Products manufactured or supplied by the Seller are installed and used by the
owner for the duration of the Warranty Period.
4. The Warranty commences on the date of the purchase of the product and
continues for the of the Owner for the Warranty Period. If within the
Warranty Period a manufacturing defect is discovered in the Product, or the
Product fails to perform to the Seller’s ations as a result of some defect in
:noitercsid nwo sti ta lliw relleS eht neht ,tcudorP eht ni pihsnamkrow ro lai
retam
a.) Repair or replace the Product at the cost of the Seller, including but not
limited to labour and travel costs. Goods repaired or replaced under this
Warranty will be warranted for the remaining period of the Warranty.
b.) Refund the purchase price paid by the consumer.
5. The Warranty does not apply to Product that:
a.) Has failed due to excessive wear and tear beyond what is considered to be
reasonable.
b.) Has been misused or neglected.
c.) Has been damaged accidentally or by acts of God including re and !
d.) Has been used or operated contrary to operating or maintenance instructions.
e.) Has been damaged by the Consumer or a third party authorised to act for the
consumer in transit from the Sellers store to the Consumer.
6. In order to make a claim under the Warranty, the Owner must, where possible
return the goods to the Seller’s store at the Owner’s cost. Proof of purchase must
be supplied in all cases.
7. The seller will examine any returned Products and if the Seller determines that
there is an apparent defect through no fault of the Owner, the Seller will:
a.) Make note of the Owner’s contact details including the Owner’s telephone
number which the owner can be contacted during business hours, postal
address and e-mail address.
© 2023 RVM Australia Pty Ltd. All Rights Reserved
9
b.) Make note of the defects reported by the Owner.
c.) Take back the defective goods from the owner and determine within a
reasonable time through dialogue with the Seller whether the goods are
defective.
d.) Advise the owner within a reasonable time frame whether it accepts or
rejects the Product claim.
e.) If the Seller accepts the return of the Product, the Seller must arrange to have
i) The Product repaired or,
ii) Replace the damaged or faulty Product or,
iii) Refund the purchase price.
8. The Seller will not accept any returned Product which has not been returned
strictly in accordance with this Warranty.
9. For the purpose of this Warranty:
a.) Australian Consumer Law means the law as set out in Schedule 2 of the
Competition and Consumer Act 2010 (Cth).
b.) Consumer means the Purchaser of goods from the seller.
c.) Consumer means a Consumer as that term is set out in section 3 of the
Australian Consumer Law.
d.) Consumer Guarantees means the guarantees under the Australian Consumer
Law.
e.) Implied terms means any guarantees, conditions, warranties or other terms
implied by any Australian Commonwealth, State or Territory laws, (excluding
the Australian Consumer Law) or the law of any other jurisdiction.
f.) Owner has the meaning set out in clause 3.
g.) Warranty means this warranty.
h.) Product means the Product/s bought by the Owner from the Seller that fall
under this warranty.
i.) Warranty Period means:
i) In relation to Cast Iron Cookware: 3 Year Limited Warranty.
ii) In relation to Non-Stick Cookware: 3 Year Limited Warranty
iii) In relation to Cooking Utensils: 3 Year Limited Warranty
iv) In relation to Knives/Knife Block Sets: 3 Year Limited Warranty
v) In relation to Stainless Steel Cookware: 10 Year Limited Warranty
vi) In relation to Chopping boards: 1 Year Limited Warranty
vi) In relation to Small Appliances: 1 Year Limited Warranty
14
CUSTOMER SERVICE - AU: 1300 883 109
CUSTOMER SERVICE - NZ: 0508 776 546
info@westinghousesmallappliances.com.au
www.westinghousesmallappliances.com.au
IMPORTED AND DISTRIBUTED BY RVM AUSTRALIA PTY LTD.
11 Tamara Drive, Cockburn Central, WA 6164
MADE IN CHINA
© 2023 RVM AUSTRALIA PTY LTD. ALL RIGHTS RESERVED.
W& ESTINGHOUSE are trademarks of Westinghouse Electric Corporation.
Used under license by RVM AUSTRALIA PTY LTD. ALL RIGHTS RESERVED.
