STICK MIXER
INSTRUCTION MANUAL
350W
WHSM04SS220~240V
SAFETY INFORMATION
Important Safety Instructions . . . .... . ... . . . . . ... . . . . . 1 - 2
Electrical Requirements . . . .... . ... . . . . . . . . ... . . . ... . . . . 3
SETUP AND USE
Installation Guide . . . .... . . . . . . . . . . . . . . . . . . . ... . . . . . . . . . 3
Parts and Features . . . .... . ... . . . . . . . . . . . . . . ... . . . . . . . . 4
Stick Mixer Operation . . . .... . . . . . . . . . . . . . . . . ... . . . . . . . . 5
Blender Blade Accessory . . . .... . ... . . . . . ... . . . . . . . . . . . 6
CLEANING AND CARE . . . .... . ... . . . . . ... . . . . . . . . 8
TROUBLESHOOTING . . . .... . ... . . . . . . . . ... . . . ... . . 9
WARRANTY . . . .... . ... . . . . . . . . . . . . . . ... . . . . . . . 10 - 11
CONTENTS
Figures and illustrations in this User Manual are provided for
reference only and may differ from actual product appearance.
Product design and specifications may be changed without notice.
Whisk Accessory . . . .... . ... . . . . . . . . . . . . . . ... . . . . . . . . . . 7
© 2021 RVM Australia Pty Ltd. All Rights Reserved
1
IMPORTANT SAFETY INSTRUCTIONS
***WARNING***
Keep hair, hands, fingers and other body parts away from the blade & accessories
whilst the stick mixer whilst in operation. Avoid contact with all moving parts.
1. Read all instructions carefully before using your new stick mixer. Save these
instructions.
2. Always use this stick mixer with a power outlet of the voltage (AC only) marked
on the back of the appliance.
3.
Do not operate stick mixer if:
i) the cord or plug is split, melted or damaged
ii) the appliance has malfunctioned
iii) the appliance has been damaged in any manner
If any of the above incidents occur, return the stick mixer to the nearest authorized
service center for examination, repair or adjustment.
4.
Do not under any circumstances immerse the power cord, mains plus or stick
mixer body in water or any other liquid.
5. Incorrect operation and
improper use may damage the stick mixer or parts
thereof, and cause severe personal injury.
6.
When operating the stick mixer, use handle and buttons only as outer surfaces
may become hot whilst the stick mixer is in use.
7. Do not blend hot or boiling foods or liquids as there is a risk of burns or
scalding.
8. The stick mixer blades are very sharp, avoid touching them and handle with
care.
9. Do not plug the appliance into mains power before it is fully assembled.
10.
Exercise caution when removing the attachments from the stick mixer and
ensure the appliance is turned off and unplugged whilst fitting attachments.
11. Keep hands and utensils out of the blending container while blending to
reduce the risk of severe injury. A scraper may be used but must only be used
when the stick mixer is not running.
12. Do not handle the appliance with wet hands.
13.
14.
The stick mixer should not be left unattended while in operation.
Unplug the appliance from mains before cleaning, immediately after use, when
moving it to storage and when not in use.
15.
Keep the stick mixer and its cord out of reach of children.
16. It is not recommended to run the stick mixer continuously for more than 1 minute
17. Do not use this stick mixer with any attachments other than the ones supplied.
18. The whisk is not designed for mixing dough or other dense foods, and doing so will
cause damage to the whisk and or the stick mixer itself.
at a time for light substances. Do not mix dry, thick
or heavy mixtures
continuously for more than 15 seconds. Stop operation and stir the ingredients
before continuing. Allow the motor to rest for 1 minute between each use. Do not
operate the stick mixer without a workload as this may damage the appliance.
2
19. The stick mixer and its accessories are not microwave-safe.
20.
All stick mixers are designed to operate only when the power buttons remain
depressed.
21. Alw
22. For added safety, electrical appliances should be connected to a power outlet
that is protected by a residual current device (RCD), also often referred to as a
‘Safety Switch’. Your switchboard may already incorporate an RCD. If unsure,
call an electrician for verification and fitting if necessary.
ays ensure hands are dry before handling the plug or switching on the
appliance.
23. This stick mixer is not intended for use by persons (including children) with
reduced physical, sensory or metal capabilities or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the stick mixer in a safe way by the person responsible for their safety, and
understand the hazards involved.
24. Children should be supervised not to play with the stick mixer.
Always turn the power off at the power outlet before inserting or removing the
25.
power plug. Remove by grasping the plug - do not pull on the power cord.
26. This appliance is intended for non-commercial, indoors use only. Do not use this
appliance for anything other than its intended use.
27. Hold the stick mixer firmly and upright while using it.
28. Always use the appliance on a stable, secure, dry and level surface.
29. This stick mixer is not intended to be operated by means of an external timer or
separate remote-control system.
30. Wait for the stick mixer to cool before moving. Carry only by the handle.
31. Close supervision is necessary when any appliance is used by or near children.
32.
Do not place your stick mixer on or near a hot gas flame, electric element, heated
oven or any hot surface.
33. Do not place the stick mixer on top of any other appliance.
34. Do not permit the mains supply cord or plug to touch hot objects, or allow the
power cord to lay across the stick mixer body or blades.
35. Do not allow the power cord of this appliance to hang over the edge of a table or
bench top.
36. Do not use harsh or abrasive cleaning agents or any sharp instruments for
cleaning the appliance. When the appliance is cool to touch, the outside surface
may be wiped clean with a soft, damp cloth and then dried thoroughly. If
necessary, a mild dishwashing detergent may be applied to the cloth but not
directly applied to the stick mixer.
37. This appliance is intended to be used in household and similar applications such
as: staff kitchen areas in shops, offices and other working environments; farm
houses; by clients in hotels, motels and other residential type environments;
bed and breakfast type environments.
IMPORTANT SAFETY INSTRUCTIONS
© 2021 RVM Australia Pty Ltd. All Rights Reserved
3
ELECTRICAL REQUIREMENTS
POWER SUPPLY CORD
1. Do not attempt to modify the power cord or plug in any way.
2. A short power supply cord is provided to reduce the risk of becoming entangled
in or tripping over a longer cord.
3. If the power supply cord is too short, do not use an extension cord. Have a
qualified electrician or serviceman install an outlet near the appliance.
NOTE: Neither Westinghouse nor the retailer can accept any liability for damage
to the product or personal injury resulting due to failure to observe the electrical
connection procedures.
INSTALLATION GUIDE
1. Carefully unpack your electric stick mixer.
2. Carefully remove packaging around the stick mixer and straighten the power
cord. Do not remove warning labels.
3. Wash blade attachment, whisk attachment and beaker before use.
DANGER Do not under any circumstances immerse the power cord, mains plug or
stick mixer body in water or any other liquid.
WARNING The stick mixer blades are very sharp, avoid touching them and handle
with care.
WARNING Exercise caution when removing the attachments from the stick mixer
and ensure the appliance is turned off and unplugged whilst fitting attachments.
4
1. Easy select variable speed control
dial.
2. Pressure operated “I” speed
button.
3. Pressure operated “II” speed
button.
4. Stick mixer motor body.
5. Easy release mechanism for all
accessories.
6. Blender Blade attachment.
7. Whisk holster.
8. Whisk attachment
9. Beaker.
PARTS AND FEATURES
1
2
3
4
5
6
7
8
DESCRIPTION:
9
© 2021 RVM Australia Pty Ltd. All Rights Reserved
5
STICK MIXER OPERATION
1. Before first use, the blender blade, whisk and beaker accessories must be cleaned.
Wash the accessories with warm water and mild detergent. Rinse with fresh
water and dry thoroughly. Your stick mixer is now ready for use.
2. Ensure unit is unplugged from wall power outlet.
3. Insert required attachment into stick mixer body until it locks.
4. Ensuring your fingers are not pressing either of the buttons on the front of the
unit, plug the power cord into the power outlet and switch on.
5. Add ingredients into the beaker or other approved mixing container.
6. Set speed to 1 on the stick mixer using the variable speed dial on the top of the
unit. It is recommended to start all processing at a low speed and increase the
speed during the processing. Insert the stick mixer accessory into the beaker or
mixing container and press the “I” button to start the stick mixer at the variable
speed or alternatively, use the “II” button to operate the unit at max speed.
7. After use, unplug from the wall power outlet.
8.
Press the easy release buttons either side of the stick mixer body simultaneously
to release attachment.
and ensure the appliance is turned off and unplugged whilst fitting attachments.
WARNING The stick mixer blades are very sharp, avoid touching them and
handle with care.
WARNING Do not plug the appliance into mains before it is fully assembled.
WARNING Exercise caution when removing the attachments from the stick mixer
NOTE: All stick mixers are designed to operate only when the power buttons remain
depressed.
6
BLENDER BLADE ACCESSORY
HOW TO USE THE BLENDER BLADE ACCESSORY:
PUSH PUSH
PUSH
The blender blade attachment is perfectly suited for preparing dips, sauces, soups,
mayonnaise and baby food. The blender blade also works well for mixing and making
milkshakes.
1. Ensure stick mixer is unplugged from the wall power outlet.
2. Insert the blender blade attachment onto the body of the stick mixer until it locks.
(see image 1 and 2 - above)
3. Ensuring your fingers are not depressing either of the buttons on the front of the
unit, plug the power cord into the power outlet and switch on.
4. Insert the blender blade attachment in the beaker or container being used, then
press the “I” (variable speed) or “II” button to begin operation.
NOTE: When using, ensure the mixer is used in a vertical up and down motion. Do not
use at a heavily tilted angle as this will flick contents outwards and away from your
mixing container.
5. Setting the variable speed control to 1 speed is recommended to start processing
at low speed.
6. Once blending has been completed, unplug
from the wall socket
then press the
release buttons either side of the stick mixer body simultaneously to release the
blender blade attachment.
NOTE: We recommend using the supplied beaker whilst using the blender blade
attachment.
WARNING The stick mixer blades are very sharp, avoid touching them and
handle with care.
WARNING Do not blend hot or boiling foods or liquids as there is a risk of burns
or scalding.
CAUTION It is not recommended to run the stick mixer continuously for more
than 1 minute at a time for light substances. Do not mix dry, thick or heavy mixtures
continuously for more than 15 seconds. Stop the operation and stir the ingredients
before continuing. Allow the motor to rest for 1 minute between each use.
NOTE: All stick mixers are designed to operate only when the power buttons remain
depressed.
1. 2. 3. 4.
PUSH PUSH
PUSH
WHISK ACCESSORY
HOW TO USE THE WHISK ACCESSORY:
The whisk is designed for whipping cream and beating egg whites.
1. Ensure stick mixer unit is unplugged from the wall power outlet.
2. Insert the whisk attachment into the whisk holster.
3. Slot the whisk attachment into the stick mixer body until it locks.
4. Ensuring your fingers are not depressing either of the buttons on the front of the
unit, plug the power cord into the power outlet and switch on.
5. Set the variable speed control to 1 for low speed or 5 for the highest speed.
Insert the whisk attachment in the beaker or container being used, then press 6.
the “I” (variable speed) or “II” button to begin operation.
7. After use, unplug from the wall power outlet then press the release buttons on
either side of the stick mixer body simultaneously to release the whisk accessory.
8.
Pull the whisk attachment out of the whisk holster for cleaning.
CAUTION The whisk is not designed for mixing dough or other dense foods, and
doing so will cause damage to the stick mixer.
CAUTION The measuring beaker and chopping bowl are not microwave safe.
NOTE: All stick mixers are designed to operate only when the power buttons remain
depressed.
1. 2. 3.
© 2021 RVM Australia Pty Ltd. All Rights Reserved
7
8
CLEANING & CARE
1. After use, unplug from the wall power outlet then press the release buttons on
either side of the stick mixer body simultaneously to release the attachment.
2. Do not use harsh or abrasive cleaning agents. The outside surface of the stick
mixer body may be wiped clean with a soft, damp cloth and dried thoroughly.
If necessary, a mild dishwashing detergent may be applied to the cloth but not
directly applied to the stick mixer.
3. Do not expose or immerse the stick mixer body in water or any other liquid.
4. Rinsing the accessories in warm water will assist in the removal of most
substances. The appliance and accessories are not dishwasher safe.
5. When washing, non-abrasive cloths and plastic bristle kitchen brushes may be
used to remove stubborn food particles from the accessories. Do not use abrasive
cloths and cleaning materials as they will damage the surface.
6. Ensure all accessories are dried thoroughly after cleaning and before
placing
into storag
e.
7. Store in a dry place away from steam and humidity where possible.
DANGER Do not under any circumstances immerse the power cord, mains plug or
stick mixer body in water or any other liquid.
WARNING The stick mixer blades are very sharp, avoid touching them and handle
with care.
WARNING Exercise caution when removing the attachments from the stick mixer
© 2021 RVM Australia Pty Ltd. All Rights Reserved
9
TROUBLESHOOTING
BEFORE CALLING FOR SERVICE
If the stick mixer fails to operate:
1. Check to make sure the stick mixer is plugged in correctly and securely. If it is not,
remove the plug from the outlet, wait 10 seconds and plug it back in securely.
2. Check for a blown or tripped circuit breaker in your home. If these seem to be
working correctly, test another appliance in the same outlet to ensure the outlet
is working correctly.
IF NONE OF THE ABOVE SOLVES THE PROBLEM, DO NOT TRY TO ADJUST OR
REPAIR THE STICK MIXER YOURSELF.
CUSTOMER SERVICE
In the event you believe your stick mixer to be defective, please return it along with
your sales receipt to the place of purchase for resolution.
For any enquiries, please call our service center on: Tel: 1300 883 109
TROUBLESHOOTING
Troubleshoot your problem by using the chart below. If the stick mixer still does not
operate correctly, it may be defective.
TROUBLE POSSIBLE CAUSE
Stick mixer does
not turn on.
Stick mixer is not
plugged in.
Check that stick mixer is
plugged into a working
power outlet and turned
on.
POSSIBLE REMEDY
Blender blade
not turning.
Possibly too much food
in the beaker or mixing
bowl.
Reduce quantity of food
in the beaker or mixing
bowl and try again.
Motor slowing down
and appears to be
struggling while in use.
Foods are too dense
or too much food in
the beaker or mixing
bowl.
Reduce quantity of food
and try again. Adjust speed
level and try again.
10
LIMITED WARRANTY
1.
Consumer law. The benefits to the Consumer under this Warranty are in addition
Nothing in this warranty affects the Consumer’s rights under the Australian
to the rights and remedies of the buyer under any Consumer Guarantees. The
Australian Consumer Law requires that we confirm that:
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure
and for compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
2. Subject to Clause 1, the Seller warrants that Westinghouse branded products will
be free of manufacturing defects and will perform to the Seller’s specifications
subject to the following clauses.
3. The benefit of this Warranty extends only to the owner
of the property in which
the Products manufactured or supplied by the Seller are installed and used by the
owner for the duration of the Warranty Period.
4. The Warranty commences on the date of the purchase of the product and
continues for the benefit of the Owner for the Warranty Period. If within the
Warranty Period a manufacturing defect is discovered in the Product, or the
Product fails to perform to the Seller’s specifications as a result of some defect in
:noitercsid nwo sti ta lliw relleS eht neht ,tcudorP eht ni pihsnamkrow ro lairetam
a.) Repair or replace the Product at the cost of the Seller, including but not
limited to labour and travel costs. Goods repaired or replaced under this
Warranty will be warranted for the remaining period of the
Warranty.
b.) Refund the purchase price paid by the consumer.
5. The Warranty does not apply to Product that :
a.) Has failed due to excessive wear and tear beyond what is considered to be
reasonable.
b.) Has been misused or neglected.
c.) Has been damaged accidentally or by acts of God including fire and flooding.
d.) Has been used or operated contrary to operating or maintenance instructions.
e.) Has been damaged by the Consumer or a third party authorised to act for the
consumer in transit from the Sellers store to the Consumer.
6. In order to make a claim under the Warranty, the Owner must, where possible
return the goods to the Seller’s store at the Owner’s cost. Proof of purchase must
be supplied in all cases.
7. The seller will examine any returned Products and if the Seller determines that
there is an apparent defect through no fault of the Owner, the Seller will:
a.) Make note of the Owner’s contact details including the Owner’
s telephone
number which the owner can be contacted during business hours, postal
address and e-mail address.
© 2021 RVM Australia Pty Ltd. All Rights Reserved
11
b.) Make note of the defects reported by the Owner.
c.) Take back the defective goods from the owner and determine within a
reasonable time through dialogue with the Seller whether the goods are
defective.
d.) Advise the owner within a reasonable time frame whether it accepts or
rejects the Product claim.
e.) If the Seller accepts the return of the Product, the Seller must arrange to have
i) The Product repaired or,
ii) Replace the damaged or faulty Product or,
iii) Refund the purchase price.
8. The Seller will not accept any returned Product which has not been returned
strictly in accordance with this Warranty.
9. For the purpose of this Warranty:
a.) Australian Consumer Law means the law as set out in Schedule 2 of the
Competition and Consumer Act 2010 (Cth).
b.) Consumer means the Purchaser of goods from the seller.
c.) Consumer means a Consumer as that term is set out in section 3 of the
Australian Consumer Law.
d.) Consumer Guarantees means the guarantees under the Austr
alian Consumer
Law.
e.) Implied terms means any guarantees, conditions, warranties or other terms
implied by any Australian Commonwealth, State or Territory laws, (excluding
the Australian Consumer Law) or the law of any other jurisdiction.
f.) Owner has the meaning set out in clause 3.
g.) Warranty means this warranty.
h.) Product means the Product/s bought by the Owner from the Seller that fall
under this warranty.
i.) Warranty Period means:
i) In relation to Cast Iron Cookware: 3 Year Limited Warranty.
ii) In relation to Non-Stick Cookware: 3 Year Limited Warranty
iii) In relation to Cooking Utensils: 3 Year Limited Warranty
iv) In relation to Knives/Knife Block Sets: 3 Year Limited Warranty
v) In relation to Stainless Steel Cookware: 10 Year Limited Warranty
vi) In relation to Chopping boards: 1 Year Limited Warranty
vi) In relation to Small Appliances: 1 Year Limited Warranty
14
220~240V
CUSTOMER SERVICE - AU: 1300 883 109
CUSTOMER SERVICE - NZ: 0508 776 546
info@westinghousesmallappliances.com.au
info@westinghousesmallappliances.co.nz
www.westinghousesmallappliances.com.au
IMPORTED AND DISTRIBUTED BY RVM AUSTRALIA PTY LTD.
11 Tamara Drive, Cockburn Central, WA 6164
MADE IN CHINA
© 2021 RVM AUSTRALIA PTY LTD. ALL RIGHTS RESERVED.
, WESTINGHOUSE, and INNOVATION YOU CAN BE SURE OF
are trademarks of Westinghouse Electric Corporation.
Used under license by RVM AUSTRALIA PTY LTD. ALL RIGHTS RESERVED.
