Use and Care Manual
Electric Cooktop
2
2022 Electrolux Home Products, Inc. All rights reserved. Printed in China
THANK YOU FOR CHOOSING OUR APPLIANCE!
For Customer Care support and webshop, or to downlad an extended version of this manual, visit:
ElectroluxAppliances.com
WELCOME TO ELECTROLUX!
Welcome to Electrolux!.......................... 2
Important Safety Instructions..................... 3
Before Setting Surface Controls................... 8
Setting Surface Controls .........................12
Care and Cleaning .............................14
Before You Call.................................16
Warranty ......................................17
This manual is your resource for the use and care of your product. Please read it before using your appliance.
Keep it handy for quick reference. If something doesn’t seem right, the troubleshooting section will help you with
common issues.
FAQs, helpful tips and videos, cleaning products, and kitchen and home accessories are available at www.elec-
trolux.com.
We are here for you! Visit our website, chat with an agent, or call us if you need help. We may be able to help you
avoid a service visit. If you do need service, we can get that started for you.
Let’s make it official! Be sure to register your product.
Keep your product info here so it’s easy to find.
Model Number:
Serial Number:
Purchase Date:
Serial Plate Location
3
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using this appli-
ance.
This manual contains important safety sym-
bols and instructions. Please pay attention
to these symbols and follow all instructions
given.
Do not attempt to install or operate your
appliance until you have read the safety pre-
cautions in this manual. Safety items through-
out this manual are labeled with a WARNING
or CAUTION statement based on the risk
type.
Warnings and important instructions appear-
ing in this guide are not meant to cover all
possible conditions and situations that may
occur. Common sense, caution, and care
must be exercised with installing, maintaining,
or operating your appliance.
DEFINITIONS
This is the safety alert symbol. It is used to
alert you to potential personal injury hazards.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
WARNING
Indicates a potentially hazardous situation
which, if not avoided, may result in death or
serious injury.
CAUTION
Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderate injury.
IMPORTANT
Indicates installation, operation, mainte-
nance, or valuable information that is not
hazard related.
NOTE
Indicates a short, informal reference – some-
thing written down to assist the memory or
for future reference.
4
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT INSTRUCTIONS FOR UNPACK-
ING AND INSTALLATION
IMPORTANT - Read and follow the below
instructions and precautions for unpacking,
installing, and servicing your appliance
:
Remove all tape and packaging before using
the appliance. Destroy the carton and plastic
bags after unpacking the appliance. Never
allow children to play with packaging materi-
al. Do not remove the wiring label and other
literature attached to the appliance. Do not
remove model/ serial number plate.
Cold temperatures can damage the elec-
tronic control. When using this appliance for
the first time, or when the appliance has not
been used for an extended period of time, be
sure the appliance has been in temperatures
above 32ºF (0ºC) for at least 3 hours before
turning on the power to the appliance.
All materials used in construction of cabinets,
enclosures, and supports surrounding the
product must have a temperature rating
above 194°F (90°C).
Never modify or alter the construction of the
appliance by removing the leveling legs, pan-
els, wire covers, anti-tip brackets/screws, or
any other part of the appliance.
Be sure to have an appropriate foam-type
fire extinguisher available, visible, and easily
accessible located near the appliance.
GROUNDING INSTRUCTIONS
WARNING
Avoid fire hazard or electrical shock. Failure
to follow this warning may cause serious
injury, fire, or death.
Avoid fire hazard or electrical shock. Do not
use an adapter plug, use an extension cord,
or remove grounding prong from the pow-
er cord. Failure to follow this warning may
cause serious injury, fire, or death.
Proper Installation—Be sure your appliance is
properly installed and grounded by a qual-
ified technician. In the United States, install
in accordance with the National Fuel Gas
Code ANSI Z223.1/NPFA No. 54, latest edition
and National Electrical Code NFPA No. 70
latest edition, and local electrical code re-
quirements. In Canada, install in accordance
with CAN/CGA B149.1 and CAN/CGA B149.2
and CSA Standard C22.1, Canadian Electrical
code, Part 1-latest editions and local electri-
cal code requirements. Install only per instal-
lation instructions provided in the literature
package for this appliance.
For personal safety, this appliance must be
properly grounded. For maximum safety, the
power cord must be securely connected to
an electrical outlet or junction box that is the
correct voltage, is correctly polarized and
properly grounded, and protected by a circuit
breaker in accordance with local codes.
It is the personal responsibility of the consum-
er to have the appropriate outlet or junction
box with the correct, properly grounded wall
receptacle installed by a qualified electrician.
It is the responsibility and obligation of the
consumer to contact a qualified installer to
assure that the electrical installation is ad-
equate and is in conformance with all local
codes and ordinances.
See the installation instructions packaged
with this appliance for complete installation
5
IMPORTANT SAFETY INSTRUCTIONS
and grounding instructions.
IMPORTANT INSTRUCTIONS FOR USING THE
APPLIANCE
WARNING
Storage In or On Appliance—Flammable
materials should not be stored in an oven
or microwave, near surface burners or ele-
ments, or in the storage or warmer drawer
(if equipped). This includes paper, plastic,
and cloth items, such as cookbooks, plas-
ticware, and towels, as well as flammable
liquids. Do not store explosives, such as
aerosol cans, on or near the appliance.
Do not leave children alone - Children
should not be left alone or unattended in
the area where appliance is in use. They
should never be allowed to sit or stand on
any part of the appliance.
Do not store items of interest to children in
the cabinets above the appliance or on the
backguards of ranges. Children climbing on
or near the appliance to reach items could
be seriously injured.
Do not allow children to climb or play
around the appliance.
Never cover any slots, holes, or passages
with any materials, such as aluminum foil or
aftermarket liners. Aluminum foil and other
liners may trap heat, causing a fire hazard.
WARNING
Never use your appliance as a space heat-
er to heat or warm the room. Doing so may
result in carbon monoxide poisoning and
overheating of the appliance.
CAUTION
When heating fat or grease, watch it closely.
Grease may catch fire if it becomes too hot.
Do not use water or flour on grease fires.
Smother fire or flame or use a dry chemical
or foam-type extinguisher. Cover the fire with
a pan lid or use baking soda.
Use dry potholders. Moist or damp pot-
holders on hot surfaces may result in burns
from steam. Do not let potholders touch hot
cooking areas. Do not use towels or other
bulky cloths.
Do not heat unopened food containers -
Build up of pressure may cause container to
burst and result in injury.
Wear proper apparel - Loose-fitting or
hanging garments should never be worn
while using the appliance. Do not let cloth-
ing or other flammable materials contact hot
surfaces.
Do not touch surface burners or elements,
areas near these burners or elements, in-
terior surfaces of the oven, or the warmer
drawer (if equipped). Surface burners and
elements may be hot even though they ap-
pear cool. Areas near surface burners and
elements may become hot enough to cause
burns. During and after use, do not touch,
or let clothing or other flammable materials
touch these areas until they are cool. These
areas may include the cooktop and surfaces
facing the cooktop.
6
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
Do not attempt to operate the appliance
during a power failure. If the power fails,
always turn off the appliance. If the ap-
pliance is not turned off and the power
resumes, electric surface elements may
resume operation when power is restored.
Once the power resumes, reset the clock (if
equipped).
IMPORTANT INSTRUCTIONS FOR USING
YOUR RADIANT COOKTOP
Know which knob or key controls each sur-
face heating area. Place cookware with food
on the cooking area before turning it on. Turn
the cooking area off before removing the
cookware.
Cookware handles should be turned inward
and not extend over adjacent surface ele-
ments — To reduce the risk of burns, ignition of
flammable materials, and spillage due to un-
intentional contact with the utensil, the handle
of the cookware should be positioned so that
it is turned inward, and does not extend over
other cooking areas.
Use proper pan size - This appliance is
equipped with one or more surface units of
different sizes. Select cookware with flat bot-
toms that match the surface unit size. Using
the proper cookware on the cooking area will
improve efficiency.
Glazed cooking utensils— Only certain types
of glass, glass/ceramic, ceramic, earthen-
ware, or other glazed utensils are suitable for
cooktop service without breaking due to the
sudden change in temperature. Check the
manufacturer’s recommendations for cooktop
use.
Improper cookware may break due to sud-
den changes in temperature. Check the cook-
ware manufacturer’s recommendations for
cooktop use.
Never leave surface elements unattended.
Boilovers may cause smoking and greasy
spills that may ignite. A pan that has boiled
dry could be damaged and may damage the
cooktop.
Do not use a searing grill meant for use with
a broiler pan on the cooktop. The searing grill
is not designed for use on the cooktop. Doing
so may result in a fire.
When you are flaming foods under a ventilat-
ing hood, turn on the fan.
IMPORTANT INSTRUCTIONS FOR GLASS
AND CERAMIC COOKTOPS
Do not clean or operate a broken cooktop.
If the cooktop should break, cleaning solu-
tions and spillovers may penetrate the broken
cooktop and create a risk of electric shock.
Contact a qualified technician immediately.
Clean cooktop glass with caution. If a wet
sponge or cloth is used to wipe spills on a hot
cooking area, be careful to avoid a steam
burn. Some cleaners can produce harmful
fumes if applied to a hot surface.
Avoid scratching the cooktop glass with
sharp objects.
7
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT INSTRUCTIONS FOR CLEANING
YOUR APPLIANCE
CAUTION
Before manually cleaning any part of the
appliance, be sure all controls are turned off
and the appliance is cool. Cleaning a hot
appliance can cause burns.
Clean the appliance regularly to keep all
parts free of grease that could catch fire. Do
not allow grease to accumulate. Greasy de-
posits in the fan could catch fire.
Always follow the manufacturer’s recom-
mended directions for use of kitchen cleaners
and aerosols. Be aware that excess residue
from cleaners and aerosols may ignite caus-
ing damage and injury.
Clean ventilating hoods frequently - Grease
should not be allowed to accumulate on
hood or filter. Follow the manufacturer’s in-
structions for cleaning vent hoods
IMPORTANT INSTRUCTIONS FOR SERVICE
AND MAINTENANCE
Do not repair or replace any part of the
appliance unless specifically recommended
in the manuals. All other servicing should be
done only by a qualified technician. This re-
duces the risk of personal injury and damage
to the appliance.
Always contact your dealer, distributor, ser-
vice agent, or manufacturer about problems
or conditions you do not understand.
Ask your dealer to recommend a qualified
technician and an authorized repair service.
Know how to disconnect the power to the
appliance at the circuit breaker or fuse box in
case of an emergency.
WARNING
California Residents: for cancer and re-
productive harm information, visit www.
P65Warnings.ca.gov
8
BEFORE SETTING SURFACE CONTROLS
Using Proper Cookware
The size and type of cookware used will influence the
heat setting needed for best cooking results. Be sure
to follow the recommendations for using proper cook-
ware as illustrated in Figure 1 and Figure 2.
Check for flatness by
rotating a ruler across the
bottom of the cookware
(see Figure 1). Cookware
should have flat bottoms
that make good contact
with the entire surface
heating element (see
Figure 2).
Figure 1: Testing cookware
• Flat bottom and straight
sides.
•Tight fitting lids.
• Weight of handle does
not tilt pan. Pan is well
balanced
.
• Pan sizes match the
amount of food to be
prepared and the size
of the surface element.
• Made of material that
conducts heat well.
•Easy to clean.
•Always match pot
diameter to element
size.
• Curved and warped pans.
• Cookware larger than
cooking area marked on
cooktop by more than
one-half inch or 12mm.
•Heavy handle tilts pan.
• Pan is smaller than the
heating area marked on
cooktop.
Figure 2: Proper cookware
Cookware Material Types
The cookware material determines how evenly and
quickly heat is transferred from the surface element to
the pan bottom. The most popular materials available
are:
• Aluminum - Excellent heat conductor. Some types
of food will cause it to darken (Anodized aluminum
cookware resists staining and pitting). If aluminum
pans slide across the ceramic cooktop, they may
leave metal marks which will resemble scratches.
Remove these marks immediately.
• Copper - Excellent heat conductor but discolors
easily (see Aluminum).
• Stainless - Slow heat conductor with uneven cook-
ing results. Is durable, easy to clean and resists
staining.
• Cast Iron - A slow heat conductor that will retain
heat very well. Cooks evenly once cooking tem-
perature is reached. If cast iron pans slide across
the ceramic cooktop, they may leave metal marks
which will resemble scratches. Remove these marks
immediately.
• Porcelain - enamel on metal - Heating character-
istics will vary depending on base material. Por-
celain-enamel coating must be smooth to avoid
scratching ceramic cooktops
• Glass - Slow heat conductor. Not recommend-
ed for ceramic cooktop surfaces because it may
scratch the glass.
IMPORTANT
Do not place empty aluminum, glass, or porcelain
enamel coated cookware on the ceramic cooktop.
The melting point of cookware made with these ma-
terials may be reached quickly, especially if left emp-
ty, and they may bond to the ceramic cooktop. If the
cookware melts it will damage the cooktop. Follow all
the cookware manufacturer’s recommendations for
use and care of cookware.
9
BEFORE SETTING SURFACE CONTROLS
About the Ceramic Glass Cooktop
The ceramic glass cooktop has heating elements
below a smooth glass surface. The designs on the
ceramic cooktop outline the areas of the surface ele-
ments underneath. Always match the pan size with the
diameter of the element outline on the cooktop. Only
flat-bottomed cookware should be used.
Prior to using your cooktop for the first time, apply a
ceramic cooktop cleaning cream (available in most
hardware, grocery and department stores) to the
ceramic surface. Clean and buff with a clean paper
towel. This will make cleaning easier when soiled from
cooking. Cooktop cleaning creams leave a protec-
tive finish on the glass to help prevent scratches and
abrasions.
The type and size of cookware, the number of surface
elements in use, and their settings will all affect the
amount of heat that will spread to areas beyond the
surface elements. The areas surrounding the elements
may become hot enough to cause burns.
IMPORTANT
• The cooktop should not be used as a cutting
board or work surface.
• Dropping heavy or hard objects on the cooktop
may crack it.
• Placing food directly on the smoothtop surface
(without a cooking utensil) is not recommended,
as difficult cleaning will result, and foods may
smoke and cause potential fire hazard.
• Always lift cookware before moving on the
ceramic glass cooktop. Any cookware that has
a rough or dirty bottom can scratch the ceramic
cooktop. Always start with clean cookware.
NOTE
White glass cooktops only - Due to the high intensity
of heat generated by the surface elements, the glass
surface may discolor when the element is turned off.
This is normal and the glass will return to its original
white color after it has completely cooled down.
About the Radiant Surface Elements
The element temperature rises gradually and evenly.
As the temperature rises, the element will glow red. To
maintain the selected setting the element will cycle on
and off. The heating element retains enough heat to
provide a uniform and consistent heat during the off
cycle.
For efficient cooking, turn the element off several min-
utes before cooking is complete. This will allow residual
heat to complete the cooking process.
CAUTION
• Surface elements may appear to have cooled
after they have been turned off. The element sur-
face may still be hot, and burns may occur if the
element or surrounding area is touched before it
has cooled to a safe temperature.
• Do not place flammable items such as plastic
salt and pepper shakers, spoon holders, or plas-
tic wrapping on top of the range when it is in use.
These items could melt or ignite. Potholders, tow-
els, or wooden spoons could catch fire if placed
too close to the surface elements.
• Do not allow aluminum foil, or any material that
can melt, to make contact with the ceramic glass
cooktop. If these items melt on the cooktop, they
will damage the ceramic cooktop.
NOTE
Radiant elements have a limiter that allows the ele-
ment to cycle on and off, even at the HI setting. This
helps to prevent damage to the ceramic smooth top.
Cycling at the HI setting is normal and can occur if
the cookware is too small for the radiant element or if
the cookware bottom is not flat.
Be sure to read detailed instructions for ceramic glass
cooktop cleaning in the “Care and Cleaning” section
and “Before You Call” checklist section of this Use
and Care Manual.
10
BEFORE SETTING SURFACE CONTROLS
Hot Surface Indicator Lights
The HOT SURFACE indicator is present at the bottom
of the cooktop.
Figure 3: Hot Surface Indicator
The HOT SURFACE indicator light will turn on when
the element is switched on and will remain on after the
burner is turned off until the surface has cooled to a
safe temperature.
A glowing light will appear on the sections of hot
surface indicator representing the location of the hot
burner.
Figure 4: Hot Surface Indicator Light
Types of ceramic cooktop elements
The circles on the ceramic glass cooktop outline the
size and type of element underneath. The elements on
your cooktop depend on the model.
• A single radiant element has one circle.
• A dual radiant element (some models) has two
circles. The dual radiant element may be set using
only the smaller inner element or both inner and
outer elements may be set to heat together for a
larger surface.
• Dual elements allow more flexibility with the size of
cookware.
Figure 5: Single and Dual Element
Locations of the Radiant Surface Elements
Your cooktop is equipped with radiant surface radiant
elements with different wattage ratings. The ability to
heat food quicker and in larger volumes increases as
the element wattage increases.
Figure 6: 24” 4-zone Front-Control Cooktop
11
SETTING SURFACE CONTROLS
Single radiant surface elements (all models)
To operate the single radiant element:
1. Place correctly sized cookware on surface ele-
ment.
2. Push in and turn the surface control knob in either
direction (Figure 7) to the desired setting (refer to
the “Suggested radiant surface element settings” in
Table 1).
3. When cooking is complete, turn the radiant surface
element OFF before removing the cookware.
Start most cooking operations on a higher setting and
then turn to a lower setting to finish cooking. The sur-
face control knobs do not have to be set exactly on a
particular spot. Use the graphics provided as a guide
and adjust the control knob as needed (see Figure 7).
A glowing red surface heating area extending beyond
the bottom edge of the cookware indicates the cook-
ware is too small for the surface heating area.
IMPORTANT
Do not allow aluminum foil or ANY material that can
melt to make contact with the ceramic glass cooktop.
If these items melt on the cooktop, they will damage
the ceramic cooktop.
OFF
LO
HI
2
6
3
5
4
Figure 7: Single element knob
CAUTION
• Radiant surface elements may appear to have
cooled after they have been turned off. The glass
surface may still be hot and burns may occur if
the glass surface is touched before it has cooled
sufficiently.
• Do not place flammable items such as plastic salt
and pepper shakers, spoon holders, or plastic
wrappings on top of the range when it is in use.
These items could melt or ignite. Potholders, tow-
els, or wooden spoons could catch fire if placed
too close to the surface elements.
NOTE
• The size and type of utensil used, and the amount
and type of food being cooked will influence the
setting needed for best cooking results.
• The indicator lights will turn on when one or more
elements are turned ON. A quick glance at these
indicator lights when finished cooking is an easy
check to be sure all control knobs are turned
OFF. The Hot Surface indicator light will remain
on AFTER the control knob is turned to the “OFF”
position and will stay on until the heating surface
area has cooled sufficiently..
Suggested radiant surface element settings
The suggested settings found in Table 1 below are
based on cooking with medium-weight aluminum pans
with lids. Settings may vary when using other types of
pans.
Settings Type of Cooking
High (HI - 9) Start most foods, bring water
to a boil, pan broiling
Medium High (7 - 8) Continue a rapid boil, fry,
deep fat fry
Medium (5 - 6) Maintain a slow boil, thicken
sauces and gravies or steam
vegetables
Medium Low (2 - 4) Keep foods cooking, poach,
stew
Low (1) Low temperature cooking
Low (LO) Keep warm, melt
Table 1: Suggested radiant surface element settings
12
SETTING SURFACE CONTROLS
Dual radiant surface elements (some mod-
els)
To operate a dual radiant element:
1. Place correctly sized cookware on the surface
element.
2. Push in and turn the surface control knob clock-
wise to begin heating both the inner and outer
elements. If only the inner element is needed
for smaller cookware, push in and turn the knob
counter-clockwise (see Figure 8).
3. When cooking is complete, turn the knob to OFF
before removing the cookware.
Start most cooking operations on a higher setting and
then turn to a lower setting to finish cooking. The sur-
face control knobs do not have to be set exactly on a
particular mark. Use the marks as a guide and adjust
the control knob as needed.
A glowing red surface heating area extending beyond
the bottom edge of the cookware indicates the cook-
ware is too small for the surface heating area.
You may switch from either single or dual element
setting at any time during cooking. See “Suggested
radiant surface element settings” on page 11.
CAUTION
• Radiant surface elements may appear to have
cooled after they have been turned off. The glass
surface may still be hot and burns may occur if
the glass surface is touched before it has cooled
sufficiently.
• Do not place flammable items such as plastic
salt and pepper shakers, spoon holders or plastic
wrappings on top of the range when it is in use.
These items could melt or ignite. Potholders, tow-
els or wooden spoons could catch fire if placed
too close to the surface elements.
IMPORTANT
Do not allow aluminum foil or ANY material that can
melt to make contact with the ceramic glass cooktop.
If these items melt on the cooktop, they will damage
the ceramic cooktop.
Figure 8: Dual element knob settings
NOTE
• The size and type of utensil used and the amount
and type of food being cooked will influence the
setting needed for best cooking results.
• The indicator lights will turn on when one or more
elements are turned ON. A quick glance at these
indicator lights when finished cooking is an easy
check to be sure all control knobs are turned
OFF. The Hot Surface indicator light will remain
on AFTER the control knob is turned to the “OFF”
position and will stay on until the heating surface
area has cooled sufficiently.
13
SETTING SURFACE CONTROLS
Home Canning
Be sure to read and observe all the following points
when home canning with your appliance. Check with
the USDA (United States Department of Agriculture)
Website and be sure to read all the information they
have available as well as follow their recommenda-
tions for home canning procedures.
• Use only a completely flat bottom canner with no
ridges that radiate from the bottom center when
home canning. Heat is spread more evenly when
the bottom surface is flat. Use a straight-edge to
check canner bottom.
• Make sure the diameter of the canner does not ex-
ceed 1 inch beyond the surface element markings
or burner.
• It is recommended to use smaller diameter canners
on electric coil and ceramic glass cooktops and to
center canners on the burner grates.
• Start with hot tap water to bring water to boil more
quickly.
• Use the highest heat setting when first bringing the
water to a boil. Once boiling is achieved, reduce
heat to lowest possible setting to maintain that
boil.
• Use tested recipes and follow instructions careful-
ly. Check with your local Cooperative Agricultural
Extension Service or a manufacturer of glass jars
for the latest canning information.
• It is best to can small amounts and light loads.
• Do not leave water bath or pressure canners on
high heat for an extended amount of time.
14
Cooktop Maintenance
Consistent and proper cleaning is essential to main-
taining your ceramic glass cooktop.
Prior to using your cooktop for the first time, apply a
ceramic cooktop cleaning cream (available in most
hardware, grocery, and department stores) to the
ceramic surface. Clean and buff with a clean paper
towel. This will make cleaning easier when soiled from
cooking. Cooktop cleaning creams leave a protec-
tive finish on the glass to help prevent scratches and
abrasions.
Sliding pans on the cooktop can cause metal mark-
ings on the cooktop surface. These marks should be
removed immediately after the cooktop has cooled
using cooktop cleaning cream. Metal marks can be-
come permanent if not removed prior to future use.
Cookware with rough bottoms can mark or scratch the
cooktop surface.
Do not:
• Slide anything metal or glass across the cooktop.
• Use cookware with dirt or dirt build up on the bot-
tom; always use clean cookware.
• Use your cooktop as a cutting board or work sur-
face in the kitchen.
• Drop heavy or hard objects on the ceramic glass
cooktop; they may cause it to crack.
Figure 9: Cooktop Care
CARE AND CLEANING
CAUTION
• Before cleaning any part of the appliance, be
sure all controls are turned off and the appliance
is cool.
• If ammonia or appliance cleaners are used,
they must be removed and the appliance must
be thoroughly rinsed before operating. Follow
manufacturer’s instructions and provide adequate
ventilation.
Figure 10: Use cleaners with caution
IMPORTANT
Damage to the ceramic glass cooktop may occur
if you use an abrasive type cleaning pad. Only use
cleaning products that have been specifically de-
signed for ceramic glass cooktops.
15
CARE AND CLEANING
Cooktop Cleaning
WARNING
Do not use a cooktop cleaner on a hot cooktop.
The fumes can be hazardous to your health, and can
chemically damage the ceramic-glass surface.
CAUTION
Before cleaning the cooktop, be sure the controls
are turned to OFF and the cooktop is cool. The glass
surface could be hot from contact with hot cookware,
and burns may occur if the glass surface is touched
before it has cooled sufficiently.
For light to moderate soil:
Apply a few drops of cooktop cleaning cream direct-
ly to the cooktop. Use a clean paper towel to clean
the entire cooktop surface. Make sure the cooktop is
cleaned thoroughly, leaving no residue. Do not use
the towel you use to clean the cooktop for any other
purpose.
WARNING
Never cover any slots, holes, or passages with mate-
rials such as aluminum foil. Aluminum foil linings may
trap heat, causing a fire hazard
For heavy soil:
Apply a few drops of cooktop cleaning cream di-
rectly to the soiled area. Rub the soiled area using
a non-abrasive cleaning tool, applying pressure as
needed. Do not use the pad you use to clean the
cooktop for any other purpose.
If soils remain, carefully scrape soils with a metal razor
blade scraper, holding scraper at a 30 degree angle
to the surface. Remove loosened soils with cooktop
cleaning cream and buff the surface clean.
30°
IMPORTANT
Aluminum foil - Use of aluminum foil on a hot cook-
top can damage the cooktop. Do not use thin alumi-
num cooking utensils or allow aluminum foil to touch
the cooking zones under any circumstances.
Figure 11: Cooktop Cleaning
16
Solutions to Common Problems:
Before you call for service, review the following list. It may save you time and expense. Possible solutions are pro-
vided with the problem listed.
Problem Solution
Entire appliance does not
operate.
Appliance not connected. Make sure power cord is plugged properly into outlet.
Check your fuse box or breaker box to make sure the circuit is active.
Electrical power outage. Check house lights to be sure. Call your local electric
company for service outage information.
Cooktop Problems
Surface element is too hot
or not hot enough.
Incorrect surface control setting. Adjust power level setting.
Surface element does
not heat or does not heat
evenly.
Be sure the correct surface control knob is turned on for the element needed.
Cookware is light weight or warped. Use only flat, evenly balanced, medium or
heavy-weight cookware. Flat pans heat better than warped pans. Cookware ma-
terials and weight of the material affect heating. Heavy and medium-weight pans
heat evenly.
Because lightweight pans heat unevenly, foods may burn easily.
Areas of discoloration with
metallic sheen on cooktop
surface.
Mineral deposits from water and food. Remove them using cooktop cleaning creme
applied to the ceramic surface. Buff with a non-abrasive cloth or sponge.
Scratches or abrasions on
cooktop surface.
Coarse particles such as salt or hardened soils between cooktop and utensils can
cause scratches. Be sure the cooktop surface and bottoms of utensils are clean
before use. Small scratches do not affect cooking and will become less visible with
time.
Cleaning materials not recommended for ceramic-glass cooktop have been used.
Apply cooktop cleaning creme to the ceramic surface. Buff with a non-abrasive
cloth or sponge.
Cookware with a rough bottom was used. Use smooth, flat-bottomed cookware.
Metal marks on the cook-
top.
Sliding or scraping of metal utensils on cooktop surface. Do not slide metal utensils
on the cooktop surface. Apply cooktop cleaning creme to the ceramic surface. Buff
with a non-abrasive cloth or sponge. For more information, see “Cooktop Mainte-
nance” on page 14.
Brown streaks or specks
on cooktop surface.
Boil overs are cooked onto the surface. When cooktop is cool, use a razor blade
scraper to remove soil. For more information see “Cooktop Maintenance” on page
14.
BEFORE YOU CALL
17
USA
1.800.944.9044
Electrolux Home Products,
Inc.
10200 David Taylor Drive
Charlotte, NC 28262
Canada
1.800.265.8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
WARRANTY
Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux
will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or work-
manship when such appliance is installed, used and maintained in accordance with the provided instructions.
Exclusions
This warranty does not cover the following:
Products with original serial numbers that have been removed, altered or cannot be readily determined.
Product that has been transferred from its original owner to another party or removed outside the USA or Canada.
Rust on the interior or exterior of the unit.
Products purchased “as-is” are not covered by this warranty.
Food loss due to any refrigerator or freezer failures.
Products used in a commercial setting.
Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances not in ordinary
household use or used other than in accordance with the provided instructions.
Service calls to correct the installation of your appliance or to instruct you how to use your appliance.
Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which are not a
part of the appliance when it is shipped from the factory.
Service calls to repair or replace appliance light bulbs, air filters, water filters, other consumables, or knobs, handles, or
other cosmetic parts.
Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip charges, or mile-
age expense for service calls to remote areas, including the state of Alaska.
Damages to the finish of appliance or home incurred during installation, including but not limited to floors, cabinets, walls,
etc.
Damages caused by: services performed by unauthorized service companies; use of parts other than genuine Electrolux
parts or parts obtained from persons other than authorized service companies; or external causes such as abuse, mis-
use, inadequate power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR OR REPLACE-
MENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT
NOT LESS THAN ONE YEAR. ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS
PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR
ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR
EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE
OTHER RIGHTS THAT VARY FROM STATE TO STATE.
If You Need Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period should
service be required. If service is performed, it is in your best interest to obtain and keep all receipts. Service under this
warranty must be obtained by contacting Electrolux at the addresses or phone numbers below.
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Electrolux Major Appliances
North America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada Corp.
Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for service and parts under
this warranty must be performed by Electrolux or an authorized service company. Product features or specifications as described
or illustrated are subject to change without notice.
