PORTAFILTER COFFEE MACHINE

Translation of the original manual

SES 4020SS

3 4 5

- 1 -

07/2023

2023, .

EN Portafilter Coffee Machine

Important Safety Instructions

READ CAREFULLY AND STORE FOR FUTURE USE.

• This appliance may be used by children 8 years of age

and older and by persons with physical, sensory or mental

impairments or by inexperienced persons, if they are

properly supervised or have been informed about how to

use of the product in asafe manner and understand the

potential dangers.

• Children must not play with the appliance.

• Cleaning and maintenance performed by the user must

not be performed by unsupervised children.

• Keep the appliance and its power cord out of reach of

children younger than 8 years of age.

• If the power cord is damaged, have it replaced in

aprofessional service centre in order to prevent

adangerous situation. It is forbidden to use the appliance

with the power cord damaged.

• This appliance is intended for use in the home.

The appliance is also designed for personal non-

commercial use in areas that include, but are not limited to

the following:

– kitchenettes in stores, offices and other workplaces;

– agricultural farms;

– for guests in hotels, motels and other accommodation

facilities;

- 2 -

07/2023

2023, .

– bed and breakfast establishments.

• The appliance must not be immersed in water during

cleaning.

WARNING:

The filling hole must not be opened during use.

WARNING:

Avoid spilling on the plug.

Always clean the parts of the appliance that come into

contact with food with clean warm water and alittle neutral

dishwashing liquid, rinse them with clean water and wipe

dry.

WARNING:

The outer surface of the appliance heats up during

use and may be hot for some time after use. Be very

careful.

The appliance must not be placed in acabinet when in use.

Electrical Safety

• Before connecting the appliance to apower outlet, make sure that its nominal voltage indicated on the rating plate matches the electrical voltage of

the socket.

• Connect the appliance only to aproperly grounded socket. For safety reasons, we don’t recommend using adaptor plugs or extension cords.

• Do not place the appliance on windowsills, sink drain trays or unstable surfaces. Always place the appliance on astable, flat and dry surface.

• Do not place the appliance on an electric or gas stove or near an open flame.

• Never use the appliance in the immediate vicinity of abath, shower or swimming pool.

• Use the appliance only for the purpose for which it has been designed.

• Only use the appliance with the original accessories supplied with it.

• During operation, aclear space of at least 15 cm must be left around and above the appliance to ensure sufficient air circulation.

• Only use the top surface of the appliance for warming cups. Do not use it to store items.

• Fill the water tank with clean, cold water. Do not pour hot water or other liquids into it or place any objects inside it.

• Before turning on the appliance, make sure that:

– the drip tray with grid is installed in its place;

– the water tank is filled with asufficient amount of water and is properly installed in its position;

- 3 -

07/2023

2023, .

Safety in Use

• The water level must not exceed the maximum mark.

• Before you begin brewing coffee, check that the portafilter is properly attached to the brew head. Pressure is created in theportafilter during the

coffee brewing process, so do not move it during operation. Otherwise adangerous situation could arise.

• Take extra care when operating the appliance to avoid scalding with hot water or steam.

• When using the appliance, check the water level in the water tank regularly. If the water level falls below the minimum mark, refill the water tank.

Before adding water, first turn the appliance off and disconnect it from the power socket.

• The appliance is equipped with abuilt-in thermal fuse that shuts it off when the pump is idling to prevent damage. If such asituation occurs, unplug

the power cord and allow the appliance to cool down for at least 30 minutes. Then you can use it again.

• Always turn the appliance off and disconnect from the power socket if it’sto be unused or left unattended, before disassembling or assembling,

before filling the hopper or before moving or cleaning. Allow the appliance to fully cool down before cleaning or moving.

• Do not move the appliance with acup of coffee placed on the drip tray grid or with cups placed on the surface designed to warm them up.

• Keep the appliance and its accessories in clean condition.

• • Perform the cleaning and maintenance in accordance with the instructions in chapter Cleaning and maintenance. Never wash the appliance under

running water or submerge it in water or another liquid.

• Ensure that the power cord does not come into contact with ahot surface or that the power cord plug is not spilled.

• Unplug the appliance from the power socket by pulling the plug, not the power cord. Otherwise, damage to the power cord or the socket may occur.

• To avoid the danger of injury by electrical shock, do not repair or modify the appliance yourself. Have all repairs or adjustments performed at an

authorised service centre. By tampering with the appliance, you expose yourself to the risk of losing your legal rights regarding faulty performance

or warranty for quality.

- 4 -

07/2023

2023, .

• Thank you for purchasing our SENCOR product; we hope you will be

satisfied with it.

• Before using this appliance, please familiarise yourself with the

user’smanual, even if you are already familiar with using similar

types of appliances. Use the appliance only as described in this

user'smanual. Keep the manual for future reference.

• We recommend to keep the original packaging, packaging materials,

receipt, and proof of the seller'sliability or warranty certificate for

aminimum of the duration of statutory right of faulty performance or

warranty of quality. When transporting the appliance, we recommend

packaging it again in the original box provided by the manufacturer.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DESCRIPTION OF THE COFFEE MACHINE

A1 Cup warming plate

A2 Control panel

A3 Brew head

A4 Portafilter

A5 Coffee machine body

A6 Drip tray grid

A7 Drip tray

A8 Water tank lid

A9 Water tank

A10 Steam / hot water dispenser

control

A11 Steam nozzle

A12 Steam nozzle attachment

A13 Baskets (for 1 and2 cups)

A14 Coffee measuring scoop

withtamper

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DESCRIPTION OF THE CONTROL PANEL

button for brewing 1 cup

of coffee

button for brewing 2 cups

of coffee

power on/off button

button for manual coffee

dispensing

steam dispenser button

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BEFORE FIRST USE

• Before first use, remove the appliance and its accessories form the

packaging and remove all promotional labels and tags. Check that

neither the appliance nor any of its components is damaged.

• Place the coffee machine on aflat, dry and clean surface. Make

sure there is aclear space around the coffee machine, at least

35cm above it and 15 cm on the sides. Wipe the outer surface of the

appliance with aslightly dampened sponge and then wipe dry.

• Remove the water tank from the appliance. Rinse it with clean water

and asmall amount of neutral dishwashing detergent. Then rinse

thoroughly with clean water, dry and put back into the machine.

• Remove the removable drip tray with grid, wipe with adampened

sponge, dry and put back into the base of the appliance.

• Wash the portafilter, coffee measuring scoop and stainless steel

baskets under clean running water with alittle kitchen detergent. Then

rinse with clean water and dry.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PREPARING BEFORE USE

Drip Tray

• The drip tray with agrid catches drops of brewed coffee when

the portafilter is removed, hot water drained from the boiler after

frothing to avoid burning the coffee, and any spilled milk during

frothing. Therefore, make sure that both parts are correctly installed

andinserted into the appliance.

• We recommend emptying the appliance andwashing the drip tray

after each use. When washing, follow the instructions in the chapter

“Cleaning and maintenance”.

Note:

The drip tray is equipped with afill indicator. It is

afloat. When the liquid level in the drip tray pushes it

up, the drip tray must be emptied.

Filling the Water Tank

• Open the lid of the water tank. Hold the water tank by the grip

andremove it upwards. Fill it with cold drinking water up to the max

water level mark, put it back in and fold the grip into the water tank.

Then close the lid of the water tank. The water tank must be properly

seated in its place so that water can be pumped fromit to the boiler.

Note:

The water that you pour into the water tank should

ideally be at room temperature (approximately 25°C).

Water that is too cold can adversely affect the final

taste of the coffee drink. Do not leave the remaining

water in the water tank for more than one day. For

brewing quality fresh coffee, it is necessary to use

fresh water. Otherwise, the final taste of the coffee

drink may be adversely affected.

Warning:

The maximum capacity of the water tank is 1.4 l.

Do not overfill it. Never fill the water tank with warm,

hot or sparkling water or liquids such as milk. Do not

fill the water tank when it is inserted in the appliance.

There is arisk of spilling the appliance or overfilling

the water tank.

Inserting and Removing the Basket

• Insert the selected stainless steel basket in the portafilter and push

firmly.

• To remove the basket from theportafilter, press the button on the

handle of the portafilter and the basket will be released. Then you can

take it out.

Filling the Basket andTamping the Coffee

• Place the portafilter on aflat surface and pour an appropriate amount

of ground coffee into basket. Abasket for one cup of coffee is filled with

one level measuring scoop of ground coffee. Abasket for two cups

of coffee is filled with twice the amount of coffee. One aligned scoop

is equivalent to about 7 g of ground coffee. Spread the coffee inthe

basket evenly andsqueeze it with the flat end of the measuring scoop.

• Clean the edges of the basket thoroughly of any ground coffee

residue.

Note:

Use only ground coffee designed for use in espresso

machines. Do not use ground coffee intended for use

in aFrench press, drip machine, etc.

Portafilter Installation and Removal

• Place the portafilter underneath the brew head so that the grip is

pointing to the left and aligned with the “

” icon on the brew head.

To attach the portafilter to the brew head, turn the grips to the right to

the position indicated by the “ ” icon.

• To remove the portafilter from the brew head, turn the grip clockwise

to the “

” icon. Remove it from the brew head and move it above

arubbish bin. Turn the portafilter so that the basket with the spent

coffee points downwards. Use acoffee spoon to remove the coffee

grounds. Avoid contact with the surface of the basket or portafilter as it

may still be heated. Before taking the basket out of theportafilter, cool

it under cold running water. Then rinse the basket and the portafilter

under clean running water and dry them thoroughly.

Portafilter Coffee Machine

User’sManual

- 5 -

07/2023

2023, .

Cup Warming

• As soon as you switch the appliance on with the

button, the cup

warming area starts heating automatically. Place empty coffee cups

(upside down) on to area A7 and allow them to warm up.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

USING THE COFFEE MACHINE

• Place the coffee machine on aflat, dry and clean surface at

asufficient distance from the from the power socket. Ensure there is

enough space around it for manipulation, at least 15 cm around the

entire coffee machine.

• Make sure that the water tank is refilled with fresh water and that the

bean hopper has an adequate amount of coffee beans and that the

appliance is properly assembled.

• Connect the power cord plug to apower socket.

Turning on the Coffee Machine, Rinsing and Preheating

1. Place acup or bowl under the coffee spout.

2. Press the button

to turn the appliance on. The button will light up

and the

, and buttons will flash, indicating that the coffee

machine is starting to preheat.

3. As soon as the buttons light up, the machine is ready for use.

4. Press the

button and the coffee machine will start pumping water

into the internal system for about 30 seconds. Allow the water to

draw in and flow out through the spout. This will clean andheat the

inner circuit andthe coffee spout. Pour the water out of the cup or

bowl and repeat the process about three times.

5. Direct the steam nozzle into the cup or bowl. Carefully turn the

steam / hot water dispenser control until water starts flowing through

the steam nozzle. Let the water flow for about 30 seconds, then turn

the control to the centre position.

6. Now the coffee machine is ready for use.

• The brew button will not function until the coffee machine is

sufficiently preheated.

• If the cup or bowl is already too full, press the

button while the

machine is dispensing water and the water dispensing will stop. You

can empty the cup or bowl.

Warning:

Be careful during flushing as the water discharged

through the spout andsteam nozzle is very hot and

improper handling can cause scalding.

Note:

The sound of the pump is heard during coffee

brewing, steam dispensing and rinsing. This is

normal.

Note:

The maximum operation time of the

button is

120 seconds. After that, the coffee machine stops

automatically.

Coffee Preparation

• The appliance is supplied with 2 stainless steel baskets: abasket for

1 cup of coffee and abasket for 2 cups of coffee.

• The 1-cup basket is suitable for making 1 espresso, regular cappuccino

or latte macchiato.

• The 2-cup basket is suitable for making adouble espresso,

2 espressos, strong cappuccino or latte macchiato.

1. Insert the 1-cup or 2-cup basket in the portafilter, fill the coffee

andinsert the handle in the brew head.

2. Make sure the coffee machine is preheated.

3. Place acup or mug under the portafilter.

4. Press the

(1 cup preparation) or (2 cup preparation) button.

The pressed button will light up.

5. First, the coffee is brewed by releasing a small amount of water into

the basket to swell the ground coffee in the basket. After awhile, the

full extraction of the coffee is started.

6. When the preset coffee amount has been poured into the cup, the

dispensing will stop automatically.

7. Remove the portafilter from the brew head andclean it according

to the instructions inthe “Cleaning andMaintenance” section. We

recommend waiting about 5 seconds before removing the portafilter

from the brew head. This will naturally release the pressure and

make it easier to remove the portafilter.

Dispensing Hot Water

Hot water can be used toheat cups, prepare tea, etc.

1. Place acup under the steam nozzle.

2. When the coffee machine is preheated, press the

or button

and the pump will start pumping water.

3. Atthis point, turn the steam / hot water dispenser control to the

position and hot water will start flowing out of the steam

nozzle.

4. Once the desired amount of hot water has flowed into the cup, press

the

or button again and turn the steam / hot water control to

the centre position.

Milk Frothing

1. Prepare cooled semi-skimmed or whole milk and acontainer in

which to whisk the milk. Whisking causes the milk to froth, so fill the

container to no more than ⅓ of its capacity.

2. Adjust the nozzle to aposition where you can whisk the milk

comfortably.

3. Make sure the steam / hot water dispenser control is set to the

OFF position. Press the button

and wait for the button light to

come on. This signals that the water in the boiler has reached the

optimum temperature for steam production. This is higher than the

temperature for coffee extraction.

4. Set the steam / hot water dispenser control to the

position

and let the steam escape for about 10 to 15 seconds to clean

the steam nozzle and remove any excess water that may have

accumulated during heating. Then turn the control to the OFF

position.

5. Place the container withmilk underneath the nozzle. Insert the

nozzle just below the milk level and set the OFF control to

The nozzle will start releasing steam.

6. Hold the container slightly tilted to ensure that the nozzle remains

constantly submerged just under the surface of the milk. The milk

will circulate in the container, it will heat up and increase in volume.

Milk froth will start to form on the surface of the milk.

7. When the bottom of the container is heated to the point where it

is hot to the touch, stop whisking by turning the control to OFF.

When steam stops being created, remove the container. Using

aswirling motion, whip the froth into the heated milk.

Warning:

During whisking, the nozzle must always be

immersed. Otherwise hot milk may splash out.

8. Pour the frothed milk into freshly brewed coffee and use aspoon

to add the milk froth. The recommended milk-to-coffee ratio for

making cappuccino coffee is ⅓ espresso, ⅓ warm milk and ⅓ milk

froth. To make alatte macchiato, use ⅓ espresso, ⅔ warm milk and

approximately 1 cm of milk froth.

9. After using the hot steam function, allow the coffee machine to

cool down for about 5 minutes or drain the rest of the hot water

from the boiler to prevent the coffee from boiling with water heated

to atemperature that is too high. In this case, use the hot water

dispensing function as described above.

10. After use, clean the nozzle and attachment according to the

instructions in the Cleaning and Maintenance chapter.

- 6 -

07/2023

2023, .

Automatic Shut-off of the Coffee Machine

The coffee machine will automatically turn off after about 25 minutes of

inactivity.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CLEANING AND MAINTENANCE

Before cleaning, unplug the power cord from the mains socket and allow

the appliance to cool down.

Do not use abrasive cleaning agents, solvents, or any substances to clean

any parts of the appliance that could damage the surface of the appliance.

None of the components of this appliance are dishwasher safe.

Warning:

To prevent the risk of electric shock, do not submerge

the appliance, plug or power cord in water or any

other liquid.

Baskets, Portafilter and Brew Head

The basket and portafilter should be cleaned properly after each use.

1. Remove the portafilter with the used coffee from the brew head.

Dispose of the coffee grounds in the compost heap or in regular

municipal waste. If the coffee grounds are difficult to remove from

the basket, use atable knife or spoon.

2. Remove the basket from theportafilter using the button on the

portafilter.

Warning:

Take extra care as the coffee grounds, basket and

portafilter are very hot after use. There is arisk of

burns.

3. Rinse the basket and portafilter under warm running water and wipe

them dry with aclean cloth. Place them on the heating surface so

that they are preheated and ready for use.

4. Remove ground coffee remains from the brew head using adamp

cloth.

Drip Tray

• The drip tray should be emptied and washed after each use of the

appliance.

• First remove the grid from the drip tray and then remove the water.

Wash the tray and grid in warm water with the addition of neutral

dishwashing detergent. Then rinse both parts under running water,

wipe dry and return to their place.

Steam Nozzle and Steam Nozzle Attachment

• It is necessary to clean the nozzle and the attachment thoroughly

after every use.

• Take off the attachment, rinse under running water and wipe dry.

• Clean the nozzle thoroughly using adamp cloth. If there is dried milk

residue on the nozzle, immerse it in acontainer of hot water for afew

minutes to soak it off. If the dried milk residue has blocked the steam

spout hole, clean it with aneedle. Finally, clean the nozzle with damp

cloth, wipe dry andput the attachment on it.

Outer Case

Wipe the outer surface of the appliance using alightly damp cloth and

wipe dry.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DESCALING

Mineral deposits from water can accumulate in the internal circuit of the

coffee machine with regular use. It is anatural process. Therefore, regular

descaling is necessary. Mineral deposits can adversely affect the taste of

the coffee being brewed.

1. Turn off the coffee machine and disconnect the power cord from the

power socket.

2. Allow the coffee machine to cool down completely.

3. Remove the water tank and drip tray. Empty them.

4. Fill the water tank with asolution of water and descaling agent.

Use adescaling agent suitable for espresso-type machines and

follow the instructions given in the descaling agent'saccompanying

documentation.

5. Insert the water tank anddrip tray into the coffee machine.

6. Place abowl under the brewing head.

7. Insert the power plug into apower socket.

8. Switch on the coffee machine andallow it to preheat.

9. Press the

button andlet the heated solution flow through the

head. Repeat the process until about half of the solution in the

watertank has flowed through.

10. Then point the steam nozzle into the container and slowly turn the

steam / hot water dispenser control until water starts to flow. Allow

the water to drain until the water tank is empty.

11. If the bowl is full, interrupt the descaling process and pour

out the water. Place the empty bowl again under the head

andcontinuedescaling.

12. When the water tank is empty, remove it andrinse with clean water.

13. Pour clean water into the water tank andinsert it back into the coffee

machine.

14. Now repeat the whole process again withclean water. This removes

limescale and descaling agent residue.

Warning:

Always be careful when handling the bowl. The

descaling solution is heated to ahigh temperature

andthere is arisk of scalding if not handled correctly.

Storage

• If you will not be using the appliance for an extended period of

time, unplug the plug from the mains socket, allow the appliance to

cool down and clean it according to the instructions in the chapter

“Cleaning and Maintenance”.

• Before storing, ensure that the appliance and all accessories are

thoroughly clean and dry.

• Store the appliance in adry, clean, and well-ventilated place away

from extreme temperatures and out of the reach of children or pets.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TROUBLESHOOTING

Problem Cause Solution

Coffee machine

cannot be turned

on.

The power cord plug is

incorrectly inserted in

the power socket.

Connect the power plug

to the power socket

properly.

Water is leaking out

the bottom of the

coffee machine.

The drip tray is full. Carefully remove the

tray andempty it.

The coffee machine is

not working properly.

Contact an authorised

service centre.

Removing the water

tank from the machine

may cause asmall

amount of water to drip.

This is anormal

occurrence. There was

aleak from the water

outlet when removing

the water tank.

- 7 -

07/2023

2023, .

Problem Cause Solution

The water is

coming out ofthe

portafilter.

The remains of the

ground coffee remained

on the edge of the

portafilter.

Before inserting the

portafilter into the brew

head, wipe the edge of

the portafilter to remove

any ground coffee

residue.

The portafilter is not

installed correctly in the

brew head.

Remove the portafilter

and reinsert it into the

brew head.

The frothing of the milk

has just ended or steam

is being generated or

the steam button is not

reset due to excessive

temperature.

Allow the coffee

machine to cool down.

The brewed coffee

smells of acid

(vinegar).

You have not rinsed

with clean water after

descaling.

Perform the descaling

correctly.

The ground coffee

is stored inawarm

andhumid environment

for along time andhas

spoiled.

Store ground coffee in

adry andcool place as

recommended by the

manufacturer. Ideally,

use freshly ground

coffee.

There is no steam. The steam button light

has not yet come on

and therefore no steam

can be formed.

Wait for the steam

button light to turn

green.

The milk frothing

container is too large

or does not have

asuitable shape.

Use ahigher container

withstraight walls.

You're using skim milk. Toachieve froth, it is

necessary to use semi-

skimmed or whole milk.

The steam nozzle is

dirty or blocked.

Clean the nozzle.

The metal parts of

the tank are rusted.

You have used the

wrong descaling agent

or have not followed

the instructions of the

manufacturer.

Use adescaling agent

suitable for espresso-

type machines and

follow the instructions

given in the descaling

agent'saccompanying

documentation.

Note:

If the problem is not listed in the table or if the

problem persists, turn off the coffee machine,

disconnect it from the power source, and contact an

authorised service centre.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TECHNICAL SPECIFICATIONS

Rated voltage range .............................................................................220−240 V~

Rated frequency ........................................................................................ 50−60 Hz

Rated power input ............................................................................................1050W

Noise level ........................................................................................................75 dB(A)

The declared noise emission level of the appliance is 75 dB(A), which

represents alevel Aof acoustic power with respect to areference acoustic

power of 1 pW.

We reserve the right to change the text and technical specifications.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INSTRUCTIONS AND INFORMATION ON DISPOSAL OF USED

PACKAGING MATERIAL

Dispose of used packaging material at asite designated for waste in your

municipality.

DISPOSING OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT

This symbol on the products or accompanying documents

indicates that used electrical and electronic products

should not be disposed of with regular municipal waste.

For proper disposal and recycling, take these products to

designated collection points. Or in some European Union

states or other European countries the products can be

returned to the local retailer when buying an equivalent

new product. Disposing of this product correctly helps save

valuable natural resources and prevents damage to the environment by

improper waste disposal. Ask your local authorities or collection facility for

more details. In accordance with national regulations penalties may be

imposed for the incorrect disposal of this type of waste.

For Business Entities in European Union States

If you want to dispose of electric or electronic devices, ask your retailer or

supplier for the necessary information.

Disposal in Other Countries Outside the European Union

This symbol is valid in the European Union. If you wish to dispose of this

product, request the necessary information about the correct disposal

method from the local council or from your retailer.

This product complies with all the essential requirements of

the EU directives that apply to it.

FAST ČR, a.s.

U Sanitasu 1621

CZ-251 01 Říčany

Sencor SES 4020SS Espresso/ Cappuccino Maker

Product's Documents

User Manual

Specifications

Sencor SES 4020SS Questions and Answers
