Adapting to Your Environment
Ice Makers
•
Wine
•
Refrigerators
•
Beverage Centers
Sapphire Series 3
24" Solid Door Refrigerator
24" Beverage Center
24" Wine Cellar
Operator’s Manual
SR243SS Indoor & Outdoor Model
SBCR243SS Indoor & Outdoor Model
SW243SZSS Indoor & Outdoor Model
Congratulations on your new SAPPHIRE Series 3 Refrigerator. To ensure proper operation, please
read this Operator’s Manual carefully before using this product. Keep this manual in a safe place for
future reference.
!
WARNING
California Proposition 65
Certain components in this product and its related accessories contain chemicals
known to the state of California to cause cancer, birth defects or other reproductive harm.
PRODUCT REGISTRATION INFORMATION
Please record your model’s information. You will need to know this information whenever you call to request information or ser-
vice. The model’s information appears on a serial number plate.
Model Number:
Serial Number:
You can register your appliance at:
SapphireAppliance.com
Or
Fill out the provided Warranty Registration Card and mail in.
Your Serial Tag is located on the top, inside of your Sapphire
appliance. We recommend using your cellphone to take a picture of
the Serial Tag so you can record the Model and Serial numbers
here and for any future reference.
Indoor/Outdoor Refrigerator
Indoor/Outdoor Beverage Center
Refrigerator
Indoor/Outdoor Wine Refrigerator
1
© 2021 SAPPHIRE
TABLE OF CONTENTS
SAFTEY ............................................................................................................................................... 3
SAFETY DEFINITIONS ...................................................................................................................... 3
SAFETY PRECAUTIONS .................................................................................................................. 3
SPECIFICATIONS ..............................................................................................................................6
SAPPHIRE SERIES 3 24-INCH INDOOR/OUTDOOR REFRIGERATOR ........................................... 6
INSTALLING THE UNIT ..................................................................................................................... 9
REQUIRED CABINET OPENING .....................................................................................................11
BUILT-IN CABINET DIMENSIONS ...................................................................................................11
SAPPHIRE 24-Inch Indoor Cabinet Dimensions .......................................................................... 11
ELECTRICAL CONNECTION ............................................................................................................. 12
AVOIDING USE OF EXTENSION CORDS ........................................................................................ 12
LEVELING THE UNIT ......................................................................................................................... 13
REVERSING THE DOOR .................................................................................................................. 14
ANTI-TIP SYSTEM ............................................................................................................................ 15
OPERATING THE UNIT .................................................................................................................... 16
USING THE CONTROLS .................................................................................................................. 16
Turning the Unit On ...................................................................................................................... 17
Turning the Unit Off ...................................................................................................................... 17
SAPPHIRE Beverage Center Operator’s Manual
Setting Temperature..................................................................................................................... 17
Changing Temperature Units........................................................................................................ 18
Temperature Display Mode........................................................................................................... 18
Fast/Quick Cooling........................................................................................................................ 18
Lighting Control............................................................................................................................. 19
Auto Defrost..................................................................................................................................19
SAPPHIRE SERIES 3 24-INCH INDOOR/OUTDOOR BEVERAGE CENTER/REFRIGERATOR ...... 7
SAPPHIRE SERIES 3 24-INCH INDOOR/OUTDOOR WINE REFRIGERATOR ...
............................. 8
TABLE OF CONTENTS
2
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
Operator’s Manual
Sabbath Mode .............................................................................................................................. 20
Door Open Alert............................................................................................................................ 20
Sensor Error Alert..........................................................................................................................20
High Temperature Error Alert. ....................................................................................................... 21
Low Temperature Alert................................................................................................................... 21
Firmware Version Display............................................................................................................... 21
EXPECTING NORMAL SOUNDS ...................................................................................................... 22
DEALING WITH POWER FAILURE ................................................................................................... 22
CARE AND MAINTENANCE .............................................................................................................. 23
CLEANING AND MAINTAINING THE UNIT ....................................................................................... 23
Cleaning the Unit’s Exterior ........................................................................................................... 23
Cleaning the Unit’s Interior ............................................................................................................ 23
Winterizing ..................................................................................................................................... 24
Start-Up After Long-Term Storage................................................................................................... 24
Cleaning the Condenser ................................................................................................................ 25
TROUBLESHOOTING ........................................................................................................................ 26
DISPOSING THE UNIT ....................................................................................................................... 2
7
WARRANTY ........................................................................................................................................ 2
8
Screen Lock..................................................................................................................................19
Lighting Control............................................................................................................................. 20
3
© 2021 SAPPHIRE
SAFETY
1
SAFETY DEFINITIONS
The words DANGER, WARNING, CAUTION and NOTICE are used throughout this manual to highlight important
information. Be certain that the meanings of these alerts are known to all who operate and install the appliance.
!
DANGER
Indicates a hazardous situation that, if not avoided, will result in death or serious injury.
!
WARNING
Indicates a hazardous situation that, if not avoided, could result in death or serious injury.
!
CAUTION
Indicates a hazardous situation that, if not avoided, could result in minor or moderate injury.
NOTICE
Indicates a situation that can cause damage to the appliance and/or the environment, or cause the appliance
to operate improperly.
SAFETY PRECAUTIONS
POWER CORD PRECAUTIONS
electrician replace the power cord.
• Never lift, carry or drag the appliance by the power cord.
• Do not use the appliance if the power cord is damaged. If the power cord is damaged, have a qualified
• Never unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull straight out
• Do not connect or disconnect the electric plug when your hands are wet.
from the outlet.
SAPPHIRE Beverage Center Operator’s Manual
SAFETY
4
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
INSTALLING PRECAUTIONS
• Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
• To avoid a hazard due to instability of the appliance, the appliance must be installed in accordance with
the instructions.
MOVING PRECAUTIONS
• When moving the appliance, do not turn it upside-down and do not unlevel it more than
45 degrees.
• Do not move the appliance without emptying it and securing the door in the closed position.
OTHER PRECAUTIONS
• To ensure proper ventilation for the appliance, keep obstructions away from the front of the unit.
• Keep fingers out of the “pinch point” areas. Clearance between the door and cabinet are necessarily small.
Be careful closing the door when children are in the area.
• Do not touch the evaporator with your hand when the appliance is operating.
• Do not attempt to repair or replace any part of your appliance unless this manual specifically recommends
it. Have a qualified technician perform all other service on the unit.
• Children 8 years of age and older and people with reduced physical, sensory or mental capabilities or lack
of experience and knowledge can use this appliance if they have been given supervision or instruction
concerning use of the appliance in a safe way and they understand the hazards involved.
• Never allow children to operate, play with or crawl inside the appliance.
• Never allow children to clean and maintain the appliance without supervision.
• Do not use the appliance other than for its intended purpose.
• Do not touch the condenser surfaces. They are sharp and can be easily damaged.
• Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of
the type recommended by the manufacturer.
CLEANING AND MAINTENANCE PRECAUTIONS
• Never clean the appliance parts with flammable fluids. Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this appliance or any other appliances. The fumes can create a fire
hazard or explosion.
• Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may transmit taste
to the food, or damage or discolor the interior.
• If the appliance will not be used for a long time, thoroughly clean it before the next use. Carefully follow
any instructions provided for cleaning or the use of sanitizing solution. Do not leave any solution inside
the appliance after cleaning.
SAFETY
5
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
• Do not use mechanical devices or other means to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
THE MANUFACTURER DISCLAIMS ANY RESPONSIBILITY IF THE ABOVE INSTRUCTIONS ARE NOT
FOLLOWED.
6
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
SPECIFICATIONS
2
SAPPHIRE SERIES 3 24-INCH INDOOR/OUTDOOR
PREMIUM REFRIGERATOR
FEATURES
24-INCH INDOOR/OUTDOOR
REFRIGERATOR
Electrical Requirement 115V/60Hz
Maximum Amp Fuse
15 amp
Net Capacity
5.5 cu-ft (156 L)
Temperature Setting 34°- 65°F (1°- 18°C)
7
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
SAPPHIRE SERIES 3 24-INCH INDOOR/OUTDOOR
PREMIUM BEVERAGE CENTER/REFRIGERATOR
FEATURES
24-INCH INDOOR/OUTDOOR
BEVERAGE CENTER/REFRIGERATOR
Electrical Requirement 115V/60Hz
Maximum Amp Fuse
15 amp
Net Capacity
5.5 cu-ft (156 L)
Temperature Setting 34°- 65°F (1°- 18°C)
SPECIFICATIONS
8
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
SAPPHIRE SERIES 3 24-INCH INDOOR/OUTDOOR
PREMIUM SINGLE ZONE WINE REFRIGERATOR
FEATURES
24-INCH INDOOR/OUTDOOR SINGLE
ZONE WINE REFRIGERATOR
Electrical Requirement 115V/60Hz
Maximum Amp Fuse
15 amp
Net Capacity
5.5 cu-ft (156 L)
Temperature Setting
38°- 65°F (3°- 18°C)
SPECIFICATIONS
9
© 2021 SAPPHIRE
INSTALLING
THE UNIT
3
!
WARNING
Fire/Explosion Hazard
DO NOT install in spaces containing gasoline engines, fuel tanks or fuel line fi ttings. This device
does not meet federal requirement for ignition protection.
IMPORTANT:
Electrical Tips
• This appliance must be installed with all electrical connections in accordance with state and local codes.
• This unit requires a standard electrical supply properly grounded in accordance with National Electrical
Code and local codes and ordinances.
• The fuse (or circuit breaker) size should be 15 amperes for 110V.
• The manufacturer recommends that you provide a separate circuit that services only your appliance. Use
receptacles that cannot be turned off by a switch or pull chain.
• Plug the appliance into a grounded three-prong outlet. Do not remove the grounding prong, do not use an
adapter, and do not use an extension cord.
• Do not kink, pinch or damage the power supply cord between the appliance and wall or cabinet.
• Before connecting the appliance to the power source, let it stand upright for approximately 4 hours.
Following this step will reduce the possibility of a malfunction in the cooling system brought on by
handling during transportation.
• Make sure to install the unit on a level surface.
Tips on Moving and Setting up the Unit
!
CAUTION
Tip Hazard
Be sure to use caution when working around an uninstalled unit. The unit is capable of tipping
over if it is not installed and properly anchored.
• Use two or more people to move and install the appliance. Failure to do so can result in back or other
injury.
• Remove the packing materials and clean the appliance before using it.
SAPPHIRE Beverage Center Operator’s Manual
INSTALLING THE UNIT
10
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
• Never keep the appliance next to ovens, grills or other high-heat resources.
• Keep the appliance on a hard, level surface that can support the unit when the unit is full. Keep the
appliance level to help ensure it works properly. You may need to make several adjustments to level the
unit. If necessary, adjust the height of the appliance by turning the feet. See “Leveling the Unit” on page
12.
• To ensure proper service access and ventilation, all SAPPHIRE units should not have the grill openings
covered. There are no additional requirements for venting at the top, side or rear of the unit.
• These units are to be installed under a counter. Follow the recommended spacing dimensions listed in
this manual. Place the electrical supply in the recommended location.
Factors affecting the Unit
INSTALLING THE UNIT
© 2021 SAPPHIRE
11
REQUIRED CABINET OPENING
!
WARNING
Fire/Explosion Hazard
DO NOT install in spaces containing gasoline engines, fuel tanks or fuel line fi ttings. This
device does not meet federal requirement for ignition protection. Failure to comply could
result in injury or death.
A built-in installation will allow you to install the appliance under a counter or in a kitchen cabinet if you
respect the required clearance space around the appliance. The appliance must be located to allow
clearance for the electrical connection in the rear of the unit.
BUILT-IN CABINET DIMENSIONS
A built-in unit is designed for zero clearance at the top and each side of the unit. The unit uses fan-forced
condenser cooling, which requires air circulation through the lower section of the unit.
NOTE: To ensure proper service access and ventilation, all SAPPHIRE units should not have the grill openings
covered. There
covered. There are no additional requirements for venting at the top, side or rear of the unit.
SAPPHIRE 24-INCH INDOOR CABINET DIMENSIONS
Recommended location for electrical connection in either adjacent cabinet.
24.00"
(610 mm)
7.00"
(177 mm)
(864 mm)
"
"
"
"
SAPPHIRE Beverage Center Operator’s Manual
INSTALLING THE UNIT
© 2021 SAPPHIRE
12
ELECTRICAL CONNECTION
Do not, under any circumstance, cut or remove the third (ground) prong from the power cord.
For personal safety, you must properly ground this appliance. The power cord of this appliance features
a three-prong grounding plug that mates with a standard three-prong grounding wall outlet to minimize
the possibility of electric shock hazard from the appliance. Have a qualifi ed electrician check the wall
outlet and circuit to make sure the outlet is properly grounded. It is your responsibility and obligation to
have a standard two-prong wall outlet replaced with a properly grounded three-prong wall outlet.
Always plug the appliance into its own individual electrical outlet. The voltage rating of the outlet must
match the rating label on the appliance. This match provides the best performance and also prevents
overloading the electrical circuits, which could cause a fi re hazard from overheated wires.
Never unplug your appliance by pulling on the power cord. Always grip the plug fi rmly and pull straight
out from the outlet.
Repair or replace immediately all power cords that have become frayed or damaged. Do not use a cord
that shows cracks or abrasion damage along its length or at either end.
When moving the appliance, take care not to damage the power cord.
If the supply cord suff ers damage, have the manufacturer, its service agent, or similarly qualifi ed persons
replace the supply cord to avoid a hazard.
AVOIDING USE OF EXTENSION CORDS
Because of potential safety hazards under certain conditions, the manufacturer strongly recommends
that you do not use an extension cord with this appliance.
SAPPHIRE Beverage Center Operator’s Manual
INSTALLING THE UNIT
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
13
LEVELING THE UNIT
The appliance requires leveling before it can work properly. If necessary, raise or lower the unit by
turning the four leveling feet on the bottom. The manufacturer recommends using a carpenter’s level to
check the appliance.
NOTICE
It is extremely important that the appliance is level for optimum performance.
Adjust all four leveling feet evenly so that the top of the appliance is at the desired installation height and
is level.
1. On a level surface, place a carpenter’s level on top of the appliance to see if it is level from front to
back and side to side.
2. Adjust the height of the leveling feet as follows:
• Turn the leveling feet to the right to lower that side of the appliance.
• Turn the leveling feet to the left to raise that side of the appliance.
INSTALLING THE UNIT
14
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
REVERSING THE DOOR
This appliance has the capability of the door opening from either the left or right side. The appliance is
delivered to you with the door opening from the left side. Follow these instructions should you desire to
reverse the opening direction:
1. Check that the power cord is unplugged
2. Unscrew the hinge axis
3. Remove the door 4. Unscrew the top left hinge
5. Install it to the bottom right.
6. Unscrew the bottom left hinge
7. Install it to the top right
INSTALLING THE UNIT
15
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
ANTI-TIP SYSTEM
1. On built-in installations, once the appliance is in place and leveled, secure the two anti-tip brackets
underneath the countertop using the two provided screws.
2. If the brackets for the anti-tip system cannot be secured above the appliance and no wood is
available, relocate the brackets for the anti-tip system to the side of the appliance for securing into
an adjacent cabinet.
8. Unscrew the door limiter from
the bottom of the door
9. Rotate the door, install the
limiter to the bottom (used to be
top)
10. Insert the door to the bottom
hinge
11. Recover the top hinge
12. Completed
Accessories: door close assist
mechanism
16
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
OPERATING
THE UNIT
4
USING THE CONTROLS
The control panel is located at the top of the appliance.
NOTE: You have 10 seconds to make a control change before the display reverts to the
default screen.
power on/off
display
to scroll menu options
light on/off
Control Details - Buttons/Display
light on (6 hours)
unit temperature
Control Details - Backlit Features
under maintenance
screen lock
auto defrost
quick cool
INSTALLING THE UNIT
TURNING THE UNIT ON
Press the ON/OFF button
OPERATING THE UNIT
17
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
Press the power button once
TURNING THE UNIT OFF
Press and hold the ON/OFF button for 3 seconds
Press the power button and hold for
3 seconds
SETTING THE TEMPERATURE
Press
the UP or DOWN arrow and the temperature will start flashing, then press the UP or DOWN arrow again to
increase or decrease the temperature setting. The desired temperature will be auto saved after 10 seconds.
Press the UP or DOWN arrow to set the temperature
OPERATING THE UNIT
18
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
CHANGING TEMPERATURE UNITS
Press and hold the UP or DOWN arrows for at least 3 seconds to change the displaying temperature units
between Fahrenheit and Celsius. When the temperature units convert, the Celsius and Fahrenheit indicator will
switch accordinglly.
Press and hold the UP or DOWN arrows for at least 3 seconds
TEMPERATURE DISPLAY MODE
Press and hold the UP and DOWN arrows for at least 6 seconds to switch the Panel Display Temperature
from the setting temp to the Real Time Temperature of the cabinet. The refresh rate of the real time
temperature is 1 mintue.
Press and hold the UP or DOWN arrows for at least 6 seconds
FAST/QUICK COOLING MODE
Press and hold the UP arrow and POWER button for at least 3 seconds to engage Fast/Quick cooling
mode. The unit will keep cooling and ignore the defrosting stop till reach the coolest temperature setting.
Press and hold the UP arrow and POWER button for at least 3 seconds
OPERATING THE UNIT
19
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
LIGHTING CONTROL
Press the LIGHT button to switch the light on/off when the door is open. Press and hold the LIGHT button for
over 6 seconds to start the LIGHT ON mode. Press the LIGHT button again to end the LIGHT ON function. In
LIGHT ON mode, the light will keep lit for 6 hours, with or without door open.
Press and hold the LIGHT button for at least 6 seconds
AUTO DEFROST MODE
Auto Defrost is automatic and requires no user interaction. The Defrost indicator icon will light up and the
compressor will stop for 30 mintutes every 6 hours of system running until the defrost is complete.
No user interaction is required
SCREEN LOCK MODE
Press and hold LIGHT and POWER buttons for over 3 seconds to lock/unlock the screen.
Press and hold the POWER button and LIGHT button for at least 3 seconds
OPERATING THE UNIT
20
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
SABBATH MODE
Press and hold the UP arrow and POWER button for at least 6 seconds to enter and also to exit SABBATH
MODE. This will shut off the screen display, the operating sounds, and the light will remain off while the unit
still running automaticly according to the previous setting.
Press and hold the UP arrow and POWER button for at least 6 seconds
DOOR OPEN ALERT
Display will show dr with 1Hz alarm sounds. The threshold of the door opening check is 5 minutes. Press
any button or close the door to stop the alarm.
Press any button to stop the alarm
SENSOR ERROR ALERT
Self-diagnosis fInds the Temperature Sensor Error. The Error will display and flash with 3
alarm sounds every 30 seconds, meanwhile the system will running intermittently. Press
any button or close the door to stop the alarm.
Press any button to stop the alarm
OPERATING THE UNIT
21
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
HIGH TEMPERATURE ALERT
When the actual temperature is higher than the setting temperature, for a certain value over a fixed time,
the alarm will sound and display the HI error code. The system will continue running in this stage. Press any
button or close the door to stop the alarm.
Press any button to stop the alarm
LOW TEMPERATURE ALERT
When the system detects the temperature lower than O.5℉ over PM minutes, the LOW TEMPERATURE
ALERT will activate. The system will stop running in this stage. Press any button or close the door to
stop the alarm.
Press any button to stop the alarm
FIRMWARE VERSION DISPLAY
Self-diagnosis fInds the Temperature Sensor Error. The Error will display and flash with 3
alarm sounds every 30 seconds, meanwhile the system will running intermittently. Press
any button or close the door to stop the alarm.
Press and hold the DOWN arrow and the POWER BUTTON to display the current
firmware verson.
OPERATING THE UNIT
22
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
EXPECTING NORMAL SOUNDS
Your new appliance may make sounds that are not familiar to you. Hard surfaces like the floor and walls can make
the sounds seem louder than they actually are. The following describes the kinds of sounds that might be new to
you and the source of those sounds:
• Rattling noises may come from the flow of the refrigerant. Items stored on top of the appliance can also make
noises.
• The high-efficiency compressor may make a pulsating or high-pitched sound.
• You may hear the sound of the condenser fan forcing air over the condenser.
DEALING WITH POWER FAILURE
Most power failures are corrected within a few hours and should not aff ect the temperature of your appliance if
you minimize the number of times you open the appliance door. If the power is going to be off for a longer period
of time, take the proper steps to disconnect your appliance.
!
WARNING
Failure to unplug the appliance could result in electrical shock or personal injury.
NOTE: When the appliance is operating, the evaporator is the only component that is cold.
23
© 2021 SAPPHIRE
CARE AND MAINTENANCE
5
!
WARNING
Electrical Shock Hazard
Always disconnect power at the source before working on the unit. Failure to unplug the appliance
could result in electrical shock or personal injury.
• Do not touch the power plug when your hands are wet.
• Never unplug the unit by pulling on the cord. Grasp the plug and pull it out firmly.
CLEANING AND MAINTAINING THE UNIT
Perform periodic cleaning and proper maintenance to ensure efficiency top performance and long life. The
maintenance intervals listed in this manual are based on normal conditions. You may want to shorten the
intervals if you have pets or other special considerations.
Periodically vacuum dust and dirt from the condenser, which is located behind the grill at the bottom front of the
unit.
CLEANING THE UNIT’S EXTERIOR
Clean the door and cabinet with a mild detergent and warm-water solution, such as 1 oz. (28 g) of dish-washing
liquid mixed with 2 gallons of warm water. Do not use solvent-based or abrasive cleaners. Use a soft sponge and
rinse the unit with clean water. Wipe the unit with a soft, clean towel to prevent water spotting.
Clean stainless steel with a mild detergent, a warm-water solution and a damp cloth. Never use an abrasive
cleaning agent.
CLEANING THE UNIT’S INTERIOR
When necessary, thoroughly clean the inside of the unit with mild soap and water. Do not use electrical heating
devices or sharp or pointed tools when defrosting the unit.
When cleaning, leave the unit turned off and leave the door open. Leaving the door open allows air to dry the
inside of the cabinet, reducing the chance for mildew and damage to the mold mechanism’s components.
SAPPHIRE Beverage Center Operator’s Manual
CARE AND MAINTENANCE
24
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
EXTENDED PERIODS OF NON-USE
!
WARNING
Electrical Shock Hazard
Always disconnect power at the source before working on the unit.
Winterizing
If the outdoor refrigerator will be exposed to temperatures of 38°F (3.3°C) or less, perform below steps to
winterize your refrigerator that will keep it in good condition while facing the winter elements. It is important to
clean and dry this appliance to prevent severe mold and mildew growth from engulfing the fridge's interior.
1. Turn the unit OFF by pressing the POWER button on the controller.
2. Remove all food and drink contents from the refrigerator.
3. Unplug the unit from the power outlet. It is also recommended that the power to the outlet be turned-off if
the circuit is not required for other items during the Winter season.
4. Place all cords in a small bag or tie them together with a piece of scrap cloth.
5. If necessary, move the unit so you can gain access to the rear of the product.
6. Remove the front toe kick, and use a brush and vacuum to clean dirt and debris from beneath the unit.
Thoroughly clean the toe kick and re-install on the unit.
7. Remove the rear access cover, and use a brush and vacuum to clean dirt and debris from the machine
compartment.
8. Check if the plastic defrost drain pan located upon the compressor contains water, use a sponge to
remove as much water as possible.
9. Thoroughly clean the rear access cover and re-install on the unit.
10. Clean the exterior and interior of refrigerator thoroughly. Wipe down and dry the refrigerator with rags
or paper towels after it has been cleaned. Ensure all water has been removed from the unit.
11. Leave the refrigerator door open to prevent formation of mold and mildew. Open door a minimum of
2" (50 mm) to provide the necessary ventilation.
12. Kindly advise no cover on the unit, as this can trap condensation. If you are concerned about
exposure to the elements, use a synthetic cover that will not hold moisture to protect the appliance,
though the door should remain open as much as possible.
13. After completion of the above, you may choose to store the unit indoors, although this is not required.
NOTICE
Never pull on the power cord to unplug the appliance from the electrical outlet. Grasp the plug of the power
cord and pull it out fi rmly.
Start-Up After Long-Term Storage:
1. If stored outside, it is recommended that the unit again be thoroughly inspected per the storage
instructions above to address any dirt or debris from the weather and/or animals/insects.
2. Connect the unit to electrical power.
3. Turn unit on and confirm your desired control settings.
4. Allow 24-hrs for the unit to stabilize before loading contents.
CARE AND MAINTENANCE
25
© 2021 SAPPHIRE
CLEANING THE CONDENSER
!
WARNING
Electrical Shock Hazard
Always disconnect the power at the source before working on the unit.
!
CAUTION
Sharp Object Hazard
DO NOT touch the condenser surface. The condenser has sharp edges and can be easily damaged.
A dirty or clogged condenser prevents proper air flow and causes higher-than-recommended operating
temperatures that may lead to component failure. Clean the condenser or have it cleaned at least once every six
months.
1. Unplug the appliance or disconnect power.
2. Remove the two screws under the front of the unit. Gently pull on the grill and remove it.
3. Remove dirt and lint from the condenser and the unit compartment with the brush attachment of a vacuum
cleaner.
4. Position the grill on the unit and secure it with two screws.
5. Plug in the appliance or reconnect power.
SAPPHIRE Beverage Center Operator’s Manual
26
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
TROUBLESHOOTING
6
PROBLEM POSSIBLE CAUSES SOLUTIONS
• The appliance does not operate. • Power failure.
• Appliance not plugged in.
• House fuse blown or circuit
breaker tripped.
• Plug in the appliance.
• Replace blown fuse or reset circuit
breaker.
• The appliance is not cold enough. • Door is opened too often.
• Door does not close completely.
• Door seal does not seal properly.
• Front bottom grill does not have
suffi cient ventilation.
• Appliance too close to a heat
source.
• Do not open door too frequently.
• See “The Door Does Not Close
Properly” below.
• Be sure door seal is properly
seated in groove.
• Grills must be completely
unobstructed.
• Keep appliance away from heat
sources.
• The appliance turns on and off
frequently.
• Large amount of contents has
been added.
• Door is open too often.
• Door does not close completely.
• Door seal not sealing properly.
• Reduce amount of content added
at a time.
• Do not open door too frequently.
• See “The Door Does Not Close
Properly” below.
• Be sure door seal is properly
seated in groove.
• The door does not close properly. • Appliance not level.
• Door was reversed and not
properly installed.
• The shelves are out of position.
• Be sure appliance is installed on
hard level surface.
• Verify door is properly installed.
• Verify shelves are properly
installed.
• Noise during operation. • Feet are not leveled.
• Certain sounds are normal.
• Level the feet. See “Leveling the
Unit” on page 12.
• See “Expecting Normal Sounds”
on page 21.
• The compressor works abnormally
with a buzzing noise.
• The voltage is lower than
recommended.
• Stop the appliance and do not
restart until the voltage is normal.
27
© 2021 SAPPHIRE
DISPOSING
THE UNIT
7
This symbol on the product or its packaging indicates that you cannot treat this product as normal domestic
trash; you must hand it in to a collection point for recycling electric and electronic appliances. Your
contribution to the correct disposal of this product protects the environment.
Contact your local municipal authority if you need more information about recycling this product.
!
DANGER
Always remove the door and keep the shelves in place when discarding this appliance so children
may not become entrapped.
SAPPHIRE Beverage Center Operator’s Manual
28
© 2021 SAPPHIRE
SAPPHIRE Beverage Center Operator’s Manual
WARRANTY
LIMITED WARRANTY COVERAGE
The Legacy Companies, warrants to the original purchaser of its SAPPHIRE products that they will be free
from defects in materials and workmanship for the following time periods from the date of purchase shown
on the sales receipt:
Two (2) year Parts & On-site Labor
Five (5) years Compressor Warranty (Parts only)
WARRANTY EXCLUSIONS
NO CONSEQUENTIAL DAMAGES: SAPPHIRE and The Legacy Companies are not responsible for any
economic loss or special, indirect or consequential damages including without limitation; loss of revenue
and loss or damage arising from food or product spoilage claims.
WARRANTY IS NOT TRANSFERABLE: This warranty is not transferable or assignable and applies only to
the original verifi ed purchaser.
NO IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR PARTICULAR SERVICE: There
are no other warranties statutory, express, or implied. This Limited Warranty is the exclusive warranty and
made in lieu of all other warranties including any implied warranties or any warranties of merchantability or
fi tness for a particular purpose.
FILING WARRANTY CLAIMS: All warranty claims for SAPPHIRE products must be made directly through
The Legacy Company’s Technical Service Department. All claims should include: model and serial number,
proof of purchase, date of installation, location purchased, and all pertinent information supporting the
existence of the claim.
IMPROPER ELECTRICAL AND WATER CONNECTIONS: SAPPHIRE and The Legacy Companies are
not responsible for the repair or replacement of any failed or damaged components resulting from electrical
power failure, the use of extension cords, low voltage or voltage spikes to the unit. Likewise, repair or
replacement attributable to low water pressure, high water pressure or contaminated water are not covered
by this Limited Warranty.
IMPROPER USAGE: Neither SAPPHIRE nor The Legacy Companies assumes liability for parts or labor
coverage for component failure or other damages resulting from improper usage or installation or failure to
clean and/or maintain the product as set forth in the Owner’s Manual provided with each unit.
WARRANTY
29
© 2021 SAPPHIRE
CONSUMABLES: This warranty does not include consumable parts such as water fi lters and light bulbs.
ADJUSTMENTS & CALIBRATIONS: Adjustments including calibrations, leveling, tightening of fasteners,
or utility connections normally associated with the original installation are the responsibility of the dealer,
installer or the end user and not the responsibility of SAPPHIRE or The Legacy Companies and will not be
considered warranty issues for this Limited Warranty.
CONSEQUENTIAL DAMAGES: This warranty does not cover any defect due to, or resulting from, ordinary
wear and tear, handling, abuse, misuse, or harsh chemical action, nor shall it extend to any product from
which the serial number has been removed or altered, or modifi cations made by unauthorized service
personnel or damage by fl ood, fi re, earthquake or other Acts of God.
OUTSIDE U.S. & CANADA: This warranty does not apply to, and SAPPHIRE and The Legacy Companies
are not responsible for any warranty claims made on products sold or used outside of the United States and
Canada or any territories of the United States of America.
ALL REPAIRS AND SERVICE MUST BE MADE BY A SAPPHIRE AUTHORIZED TECHNICIAN.
Customer Service: 1.866.754.6672
SAPPHIRE Appliances | The Legacy Companies
3355 Enterprise Avenue, Suite 160, Weston, FL 33331
[email protected] | SapphireAppliances.com
SAPPHIRE Beverage Center Operator’s Manual
SapphireAppliances.com | 866.754.6672
SAPPHIRE Appliances | The Legacy Companies
3355 Enterprise Avenue, Suite 160, Weston, FL 33331
The Beautiful & Adaptable
Sapphire-bellied Hummingbird
Lepidopyga lilliae
© 2021
“Sapphie”
Rev 4 041723
BP/N BCS3REF 4-23
