User Guide
Quality, Design and Innovation
home.liebherr.com/fridge-manuals
Contents
1 General safety instructions.................................. 3
2 Appliance at a glance............................................ 4
2.1 Scope of delivery.......................................................... 4
2.2 Overview of appliances and equipment................... 4
2.3 SmartDevice.................................................................. 4
2.4 Appliance range of use............................................... 5
2.5 Conformity..................................................................... 5
2.6 SVHC substances according to REACH regulation. 5
2.7 EPREL database........................................................... 5
2.8 Spare parts.................................................................... 5
3 Functionality of the Touch display....................... 5
3.1 Navigation and symbol explanation......................... 5
3.2 Menus............................................................................. 6
3.3 Sleep mode................................................................... 6
4 Putting into operation........................................... 7
4.1 Switching on appliance (first use)............................ 7
4.2 Starting the IceMaker for the first time*................. 7
5 Storage.................................................................. 7
5.1 Information regarding storage................................... 7
5.2 Fridge compartment.................................................... 7
5.3 EasyFresh..................................................................... 7
5.4 Freezer compartment.................................................. 8
5.5 Storage times............................................................... 8
6 Saving energy........................................................ 8
7 Controls................................................................. 9
7.1 Controls and displays.................................................. 9
7.1.1 Status display..............................................................9
7.1.2 Display symbols.......................................................... 9
7.2 Appliance functions..................................................... 9
7.2.1 Notes on the appliance functions............................9
Switching the appliance off and on........................9
Switching temperature zone off and on................ 9
WiFi............................................................................ 10
Temperature.............................................................. 11
Temperature unit...................................................... 11
SuperCool.................................................................. 11
PowerCool ................................................................ 12
SuperFrost.................................................................12
Start defrosting cycle*............................................13
PartyMode ................................................................ 13
HolidayMode............................................................. 14
SabbathMode............................................................14
E-Saver ......................................................................15
IceMaker *................................................................. 15
MaxIce*......................................................................16
TubeClean *...............................................................16
CleaningMode*......................................................... 16
Display brightness................................................... 17
Door alarm................................................................. 17
Input lock...................................................................18
Device information.................................................. 18
Software....................................................................18
Reminder................................................................... 18
Demo mode............................................................... 19
Resetting to factory settings................................ 20
7.3 Messages...................................................................... 20
7.3.1 Overview of warnings.............................................. 20
7.3.2 Ending warnings.......................................................20
7.3.3 Overview of reminders............................................. 21
7.3.4 Ending reminders...................................................... 21
8 Features................................................................. 22
8.1 Door rack....................................................................... 22
8.2 Shelves.......................................................................... 23
8.3 Dividing shelf*.............................................................. 23
8.4 VarioSafe *.................................................................... 24
8.5 Space for baking tray.................................................. 26
8.6 Drawers.......................................................................... 26
8.7 Compartment lid for EasyFresh Safe........................ 27
8.8 Glass shelves................................................................ 28
8.9 IceMaker*...................................................................... 28
8.10 VarioSpace.................................................................... 29
8.11 Bottle holder................................................................. 29
8.12 Flexible ice compartment divider*............................ 29
8.13 FlexCube*...................................................................... 30
9 Maintenance.......................................................... 30
9.1 FreshAir carbon filter................................................... 30
9.2 Disassembling / assembling pull-out systems...... 31
9.3 Compartment lid for EasyFresh Safe........................ 31
9.4 Defrosting the appliance............................................ 31
9.5 Cleaning the appliance............................................... 32
10 Customer help....................................................... 33
10.1 Technical specifications............................................. 33
10.2 Operating noises.......................................................... 33
10.3 Technical fault.............................................................. 34
10.4 Customer Service......................................................... 35
10.5 Model plate................................................................... 35
11 Shutting down....................................................... 35
12 Disposal................................................................. 35
12.1 Preparing appliance for disposal.............................. 35
12.2 Disposing of the appliance in an environmentally
friendly manner............................................................ 35
The manufacturer is continually working on the further
development of all types and models. Please be aware that
we reserve the right to make changes to the shape, equip‐
ment and technology.
2 * Depending on model and options
Symbol Explanation
Read instructions
Please read the information in these instruc‐
tions carefully to understand all of the benefits
of your new appliance.
Additional information on the Internet
The digital manual with additional informa‐
tion and in other languages can be found
via the QR code on the front of the
manual or by entering the service number at
home.liebherr.com/fridge-manuals.
The service number can be found on the serial
tag:
Fig.Example illustration
Check appliance
Check all parts for transport damage. If you
have any complaints, please contact your
agent or customer service.
Differences
These instructions apply to a range of models,
so differences are possible. Sections that
apply to certain models only are marked with
an asterisk (*).
Instructions and results
Instructions are marked with a .
Results are marked with a .
Videos
Videos about the appliances are available on
the YouTube channels of Liebherr-Hausgeräte.
Open source licences:
The appliance contains software components that use
open source licences. Information on the open source
licences used can be found here: home.liebherr.com/
open-source-licences
These operating instructions apply to:
IC(N)..
51..
IC(N)S.. 51..
IKG 51Ve03
IKGN 51Vc03
IKGN 51Ve03
IKGNS 51Vd03
IKGS 51Vd02
IKGS 51Ve03
IKGN. 1783
Note
If your appliance has an N in its appliance designation, it is
a NoFrost appliance.*
1 General safety instructions
Please keep these operating instructions in a safe place so
you can refer back to them at any time.
If you pass the appliance on, please hand these operating
instructions to the next user.
Read these operating instructions carefully before use to
ensure safe and correct use of the appliance. Follow the
instructions, safety instructions and warning messages
included at all times. They are important for ensuring you
can operate and install the appliance safely and without any
problems.
Danger for the user:
-
This device can be used by children and people with
impaired physical, sensory or mental abilities or with a
lack of experience and knowledge provided that they are
supervised or have received instruction in the safe use of
this device, and about the resulting hazards.
Children must not play with this appliance. Cleaning and
user maintenance work must not be carried out by chil‐
dren without adult supervision. Children aged between
3 and 8 are allowed to load and unload the appliance.
Children below the age of 3 must be kept away from the
appliance unless they are under continuous adult super‐
vision.
-
The socket must be easily accessible so that the appli‐
ance can be disconnected quickly from the electricity in
an emergency. It must not be located in the area behind
the appliance.
-
When disconnecting the appliance from the supply,
always take hold of the plug. Do not pull the cable.
-
In the event of a fault pull out the mains plug or deacti‐
vate the fuse.
-
Do not damage the mains power cable. Do not operate
the appliance with a defective mains power cable.
-
Only customer service or other specially trained staff
may repair or perform other operations on the appliance.
-
Only install, connect and dispose of the appliance
according to the instructions.
-
Only use the appliance when is installed.
Fire hazard:
-
The coolant used (information on the model plate) is
ecofriendly but also flammable. Any leaking coolant may
ignite.
•
Do not damage the refrigerant circuit pipes.
•
Do not handle ignition sources inside the appliance.
•
Do not use electrical appliances inside the appliance
(e.g. steam cleaners, heaters, ice cream makers, etc.).
•
If the refrigerant leaks: remove any naked flames or
ignition sources from the vicinity of the leakage point.
Properly air the room. Inform customer services.
-
Do not store explosives or sprays using combustible
propellants such as butane, propane, pentane, etc. in the
appliance. To identify these spray cans, look for the list of
contents printed on the can, or a flame symbol. Gases
possibly escaping may ignite due to electrical compo‐
nents.
-
Keep burning candles, lamps and other items with naked
flames away from the appliance so that they do not set
the appliance on fire.
-
Please be sure to store alcoholic drinks or other pack‐
aging containing alcohol in tightly closed containers.
Any alcohol that leaks out may be ignited by electrical
components.
Danger of tipping and falling:
-
Do not misuse the plinth, drawers, doors etc. as a step or
for support. This applies particularly to children.
Danger of food poisoning:
-
Do not consume food which has been stored too long.
General safety instructions
* Depending on model and options 3
Danger of frostbite, numbness and pain:
-
Avoid prolonged skin contact with cold surfaces or refri‐
gerated/frozen goods or take protective measures, e.g
wear gloves.
Danger of injury and damage:
-
Hot steam can lead to injury. Do not use electrical
heating or steam cleaning equipment, open flames or
defrosting sprays to defrost.
-
Do not use sharp implements to remove the ice.
Risk of crushing:
-
Do not hold the hinge when opening and closing the door.
Fingers may get caught.
Symbols on the appliance:
This symbol may be located on the
compressor. It relates to the oil in the
compressor and makes reference to the
risk that: Swallowing or inhaling can be
fatal. This advice is only relevant to recy‐
cling. There is no danger in normal opera‐
tion.
This symbol is located on the compressor
and indicates the danger of flammable
materials. Do not remove the sticker.
This or a similar sticker may be located
on the rear of the appliance. This sticker
indicates that there are vacuum insulation
panels (VIP) or perlite panels in the door
and/or housing. This advice is only relevant
to recycling. Do not remove the sticker.
Please note the warning messages and other specific
advice in the other chapters:
DANGER
indicates an immediately
hazardous situation which will
lead to death or serious injuries if
it is not avoided.
WARNING indicates a hazardous situation
which may lead to death or serious
injuries if it is not avoided.
CAUTION indicates a hazardous situation
which may lead to minor or
moderate injuries if it is not
avoided.
NOTICE indicates a hazardous situation
which may lead to damage to
property if it is not avoided.
Note indicates useful instructions and
tips.
2 Appliance at a glance
2.1 Scope of delivery
Check all parts for transport damage. Contact your
dealer or customer service in the event of complaints.
(see 10.4 Customer Service)
Your new appliance comes with the following parts:
-
Built-in appliance
-
Features (depending on the model)
-
Installation materials (depending on the model)
-
“Quick Start Guide”
-
“Installation Guide”
-
Service Brochure
2.2 Overview of appliances and equip‐
ment
Fig. 1 Example illustration
Temperature range
(A)
Fridge compartment (C) Freezer compartment
(B) EasyFresh
(D) Coldest zone
Equipment
(1)
Controls (9) Drain hole
(2) Fan with FreshAir acti‐
vated charcoal filter
(10) EasyFresh safe
(3) Divisible storage shelf* (11) Freezer drawer
(4) Storage shelf (12) IceMaker*
(5) VarioSafe* (13) VarioSpace
(6) IceMaker water tank* (14) Type plate
(7) Space for baking tray (15) Door shelf
(8) Lid for EasyFresh safe (16) Bottle holder
Note
► Shelves, drawers and baskets are arranged for optimum
energy efficiency when the appliance is delivered.
Changing how the shelves, for example, are inserted in
the fridge compartment does not have any impact on
energy consumption.
2.3 SmartDevice
SmartDevice is the networking solution for your fridge-
freezer.
If your appliance SmartDevice-enabled or compatible, you
can quickly and easily connect your appliance to your
WiFi. With the SmartDevice app, you can operate your appli‐
Appliance at a glance
4 * Depending on model and options
ance from a mobile device. Additional functions and setting
options are available in the SmartDevice SmartDevice app.
SmartDevice-
compatible appli‐
ance:
Your appliance is compatible for use
with the SmartDeviceBox. You must
first purchase and install the Smart‐
DeviceBox. In order to connect your
appliance to the WiFi, you need to
download the SmartDevice app.
More information
about SmartDe‐
vice:
smartdevice.liebherr.com
Purchasing the
SmartDeviceBox
in the Liebherr-
Hausgeräte store:
home.liebherr.com/shop/de/deu/
smartdevicebox.html
Downloading the
SmartDevice app:
After installing and configuring the
SmartDevice, you can connect your
appliance to the WiFi using the
SmartDevice app and the WiFi appli‐
ance function (seeWiFi) .
Note
The SmartDevice function is not available in the following
countries: Russia, Belarus, Kazakhstan.
You cannot use the SmartDeviceBox.
2.4 Appliance range of use
Intended use
The appliance is only suitable for cooling food products in
a domestic or household-like environment. This includes, for
example, use:
-
in staff kitchens, bed and breakfast establishments,
-
by guests in country houses, hotels, motels and other
accommodation,
-
for catering and similar services in the wholesale trade.
All other types of use are not permitted.
Foreseeable misuse
The following applications are expressly forbidden:
-
Storing and refrigerating medicines, blood plasma, labo‐
ratory preparations or similar substances and products
based on the Medical Device Directive 2007/47/EC
-
Use in areas at risk of explosions
Misusing the appliance may lead to damage to the goods
stored or they may spoil.
Climate classifications
Depending on the climate classification the appliance is
designed to operate in restricted ambient temperatures. The
climate classification applying to your appliance is printed
on the rating plate.
Note
► Keep to the specified ambient temperatures in order to
guarantee that the appliance works properly.
Climate clas‐
sification
for ambient temperatures of
SN 10°C to 32°C
N 16°C to 32°C
ST 16°C to 38°C
T 16°C to 43°C
SN-ST 10°C to 38°C
SN-T 10°C to 43°C
2.5 Conformity
The refrigerant circuit has been tested for leaks. When
installed, the appliance complies with the applicable safety
regulations and with the corresponding directives.
The full text of the EU Declaration of Conformity is available
on the following website: www.Liebherr.com
2.6 SVHC substances according to
REACH regulation
You can check whether your appliance contains SVHC
substances according to REACH regulation at the following
link: home.liebherr.com/de/deu/de/liebherr-erleben/nach‐
haltigkeit/umwelt/scip/scip.html
2.7 EPREL database
Details about energy labelling and ecodesign requirements
will be available on the European product database (EPREL)
from 1st March 2021. You can access the product database
at the following link: https://eprel.ec.europa.eu/ You will be
asked to enter the model ID. You can find the model ID on
the nameplate.
2.8 Spare parts
The spare parts availability for functional parts and stock‐
able parts of the equipment is 15 years.
3 Functionality of the Touch
display
You operate your appliance using the Touch display. You
select appliance functions in the Touch display (hereafter
referred to as display) by tapping them. If you do not
perform any action on the display for 10 seconds, the
display either jumps back to the higher-level menu or
directly to the status display.
3.1 Navigation and symbol explanation
In the illustrations, different symbols are used to navigate
the display. The following table describes these symbols.
Symbol
Description
Press the Next navigation
arrow:
Navigates to the next option in
the menu.
Functionality of the Touch display
* Depending on model and options 5
Symbol Description
Press the Back navigation
arrow:
Jumps back one option in the
menu.
Press the navigation arrow
several times in succession:
Navigates in the menu to the
desired function.
Press the Confirm symbol:
Activates/deactivates function.
Opens submenu.
Press the Confirm symbol
together with the back icon:
Jumps back one menu level.
Arrow with clock:
It takes more than 10 seconds
for the following message to
appear in the display.
Arrow with a time indication:
It takes the specified amount of
time until the following message
appears in the display.
“Open Settings menu” symbol:
Navigates to the Settings menu
and opens the settings menu.
If necessary: Navigate to the
desired function in the Settings
menu.
(see 3.2.1 Opening the Settings
menu)
“Open Advanced menu” symbol:
Navigates to the Advanced menu
and opens the advanced menu.
If necessary: Navigate to the
desired function in the Advanced
menu.
(see 3.2.2 Opening the Advanced
menu)
No action for
10seconds
If you do not perform any action
on the display for 10 seconds,
the display either jumps back to
the higher-level menu or directly
to the status display.
Opening door and
closing it again
If you open the door and immedi‐
ately close it again, the display
jumps directly back to the status
display.
Note: Illustrations of the display are shown in the English
version.
3.2 Menus
The appliance functions can be found in various menus.
Menu
Description
Main menu When you switch the appliance on, you are
automatically in the main menu.
From here you can navigate to the most
important appliance functions, to the
Settings menu and to the Advanced menu.
Settings
menu
The Settings menu contains additional
appliance functions for setting up your
appliance.
(see 3.2.1 Opening the Settings menu)
Advanced
menu
The advanced menu contains special appli‐
ance functions for setting up your appli‐
ance. Access to the Advanced menu is
protected by the numerical code 151.
(see 3.2.2 Opening the Advanced menu)
3.2.1 Opening the Settings menu
Fig. 2 Example illustration
► Carry out action steps according to the illustration.
▷ Settings menu is open.
► If necessary: Navigate to the desired function.
3.2.2 Opening the Advanced menu
Fig.3
Fig. 4 Example illustration, access with numerical code 151
► Carry out action steps according to the illustration.
▷ The expanded menu is open.
► If necessary: Navigate to the desired function.
3.3 Sleep mode
If you do not touch the display for 1 minute, the display
switches to sleep mode. In sleep mode, the display bright‐
ness is dimmed.
Functionality of the Touch display
6 * Depending on model and options
3.3.1 Ending sleep mode
► Press any navigation key.
▷ Sleep mode is ended.
4 Putting into operation
4.1 Switching on appliance (first use)
Make sure that the following requirements are fulfilled:
❑
The appliance is properly installed and connected
according to the installation instructions.
❑
All adhesive strips, adhesive and protective films and
transport locks are removed from inside and on the appli‐
ance.
❑
All marketing leaflets are removed from the drawers.
❑
You are familiar with the functionality of the Touch
display. (see3 Functionality of the Touch display)
Switch on the appliance using the Touch display:
► If the display is in sleep mode: Press the confirmation
symbol.
► Carry out action steps according to the illustration.
Fig. 5 Example illustration
▷ Status display appears.
▷ The appliance cools to the temperature set at the factory.
▷ The appliance starts in demo mode (status display with
DEMO appears): If the appliance starts in demo mode,
you can deactivate demo mode within the next 5 minutes.
(seeDemo mode)
More information:
-
Start the IceMaker for the first time. (see 4.2 Starting the
IceMaker for the first time*) *
-
Start the SmartDevice for the first time. (see 2.3 Smart‐
Device) and (seeWiFi)
Note
The manufacturer recommends:
► Stock with food: Wait for around 6 hours until the set
temperature is reached.
► Store frozen foods at -18°C or colder.
► Observe the notes on storing food. (see 5.1 Information
regarding storage)
Note
Accessories can be purchased from the Liebherr-
Hausgeräte store at home.liebherr.com/shop/de/deu/
zubehor.html.
4.2 Starting the IceMaker for the first
time*
If your appliance is equipped with IceMaker, you must clean
the IceMaker before using it for the first time.
Make sure that the following requirements are fulfilled:
❑
The appliance is properly installed and connected.
►
Clean the IceMaker and water tank. (see 9.5.4 Cleaning
the IceMaker*) *
► Fill the water tank. (see 8.9.1 Fill the water tank*) *
5 Storage
5.1 Information regarding storage
WARNING
Fire hazard from electrical appliances!
If you use electrical appliances in the food area of your
appliance, they can cause a fire.
► Do not use electrical appliances in the food area of the
appliance unless recommended by the manufacturer.
Note
The energy consumption increases and the cooling power
goes down if ventilation is not sufficient.
► Always keep air slots clear.
Observe the following specifications for storage:
-
Keep the air vents on the fan free.*
-
In the freezer compartment: Package food properly.
-
Package or cover foods that readily take on or give off
odours or taste in closed containers.
-
Package raw meat or fish in clean, closed containers.
This will prevent meat or fish from touching or dripping
onto other food.
-
Keep liquids in closed containers.
-
Leave space between goods to ensure good air circula‐
tion.
-
Store food according to the instructions on the pack‐
aging.
-
Always observe the best-before date indicated on the
packaging.
Note
Failure to follow these guidelines can lead to foodstuffs
spoiling.
5.2 Fridge compartment
The air circulation in the appliance creates different temper‐
ature zones. You will find the different temperature zones in
the appliance and equipment overview. (see 2.2 Overview of
appliances and equipment)
5.2.1 Arranging your food properly
► Upper area and door: Store butter, cheese, tinned food
and tubes.
► Coldest temperature zone: Store perishable foods such
as pre-cooked meals, meat and lunch meats.
► Bottom shelf: Store raw meat or fish.
5.3 EasyFresh
EasyFresh is great for non-packaged foods, such as fruit
and vegetables.
The humidity inside the drawer depends on the humidity
content of the food inside it, and the frequency at which it
is opened. The humidity can be regulated. (see 8.7 Compart‐
ment lid for EasyFresh Safe)
5.3.1 Arranging your food properly
► Store unpackaged fruit and vegetables.
If the humidity is too high:
Putting into operation
* Depending on model and options 7
► Regulate the humidity.
5.4 Freezer compartment
Here, a dry, frosty storage climate is created at -18 °C. The
frosty storage climate is suitable for storing frozen food for
several months, for making ice cubes or freezing fresh food.
5.4.1 Freezing food
Freezing quantity
The maximum amount of fresh food that you can
freeze within 24 hours is specified on the type plate
(see 10.5 Model plate) under “Freezing capacity ... kg/24h”.
To ensure that food quickly freezes through, adhere to the
following quantities per package:
-
Fruit and vegetables up to 1 kg
-
Meat up to 2.5 kg
Freezing food using SuperFrost
Depending on the quantity to be frozen, you can activate
SuperFrost before freezing in order to achieve lower freezing
temperatures. (see SuperFrost)
Appliance without NoFrost:*
► Activate SuperFrost if the amount of food you have to
freeze is more than approx. 1 kg.*
Appliance with NoFrost:*
► Activate SuperFrost if the amount of food you have to
freeze is more than approx. 2 kg.*
The time at which you activate SuperFrost depends on the
amount of food you have to freeze:
Freezing quan‐
tity
Time at which you should activate
SuperFrost
Small amount of
food to freeze
Activate SuperFrost about 6 hours
before freezing.
You can place the food in the freezer
as soon as the appliance automatically
deactivates SuperFrost.
Maximum
amount of food
to freeze
Activate SuperFrost about 24 hours
before freezing.
You can place the food in the freezer
as soon as the appliance automatically
deactivates SuperFrost.
Arranging your food properly
CAUTION
Risk of injury due to broken glass!
Bottles and cans containing drinks may burst when being
frozen. This applies particularly to sparkling drinks.
► Do not freeze bottles and cans containing drinks!
Freezing quantity Arranging your food properly
Small amount of
food to freeze
Distribute packaged groceries
throughout all drawers.
If possible, place groceries at the back
of the drawer near the rear wall.
Maximum amount
of food to freeze
Distribute packaged groceries
throughout all drawers.
If possible, place groceries at the back
of the drawer near the rear wall.
5.4.2 Defrosting food
WARNING
Risk of food poisoning!
► Do not re-freeze thawed food.
► Use defrosted foodstuff as soon as possible.
You can defrost food in several ways:
-
In the fridge compartment
-
In the microwave
-
In the oven/fan-assisted oven
-
At room temperature
► Take out only as much food as necessary.
5.5 Storage times
Refer to the specified storage times as a guide.
In the case of foods with a minimum shelf life, the date
indicated on the packaging still applies.
5.5.1 Fridge section
Always follow the best-before date stated on the packaging.
5.5.2 Freezer compartment
Recommended storage period for various types of food
Ice cream at -18°C 2 to 6 months
Sausages, ham at -18°C 2 to 3 months
Bread, baked goods at -18°C 2 to 6 months
Game, pork at -18°C 6 to 9 months
Fatty fish at -18°C 2 to 6 months
Lean fish at -18°C 6 to 8 months
Cheese at -18°C 2 to 6 months
Poultry, beef at -18°C 6 to 12 months
Vegetables, fruit at -18°C 6 to 12 months
6 Saving energy
-
Pay attention to good ventilation. Do not cover ventilation
holes or grids.
-
Always keep the fan air slits clear.
-
Do not install the appliance in direct sunlight or near
radiators or similar sources of heat.
-
If the appliance is installed directly next to an oven,
the energy consumption may increase slightly. This is
dependent on the service life and usage intensity of the
oven.
-
Energy consumption depends on the installation condi‐
tions, e.g. the ambient temperature (see 2.4 Appliance
range of use) . A warmer ambient temperature can
increase the energy consumption.
-
Open the appliance for as short a time as possible.
-
The lower the temperature is set the higher the energy
consumption.
-
Sort your food: home.liebherr.com/food.
-
Keep all food properly packed and covered. This prevents
frost from forming.
-
Only take food out for as long as necessary so that it
doesn’t warm up too much.
-
Inserting warm food: allow to cool down to room temper‐
ature first.
-
Thaw frozen food in the refrigerator.
Saving energy
8 * Depending on model and options
-
If there is a thick layer of frost in the appliance: defrost
the appliance.*
-
For longer periods of absence, use HolidayMode
(seeHolidayMode) .
7 Controls
7.1 Controls and displays
7.1.1 Status display
Fig.6
(1)
Temperature display of
the fridge section
(2) Freezer compartment
temperature display
The Status display shows the set temperature and is the
home display. From there, you can navigate to the options
and settings.
7.1.2 Display symbols
Display symbols provide information on the current appli‐
ance status:
Symbol
Appliance status
Standby
The appliance or temperature zone
is switched off.
Flashing number
Appliance is working. Temperature
flashes until the set value is
reached.
Flashing symbol
Appliance is working. Setting is
made.
Bar grows steadily
Function is activated.
7.2 Appliance functions
7.2.1 Notes on the appliance functions
The appliance functions are set at the factory so that your
appliance is fully functional.
Before you alter, activate or deactivate the device functions,
make sure that the following requirements are met:
❑
You have read and understood the descriptions of how
the display works. (see 3 Functionality of the Touch
display)
❑
You have familiarised yourself with the operating and
display elements of your appliance.
Switching the appliance off and on
Use this function to switch the entire appliance off and on.
Switching off the appliance
When you switch the appliance off, then the previously
saved settings are saved.
Make sure that the following requirements are fulfilled:
❑
Handling instructions (see 11 Shutting down) are carried
out.
Fig.7
Fig.8
► Carry out action steps according to the illustration.
▷ Appliance is switched off.
▷ The standby symbol appears in the display.
▷ Display turns black.
Switching on the appliance
If the display is in sleep mode:
► Press any navigation key.
Fig. 9 Example illustration
► Carry out action steps according to the illustration.
When the appliance starts in demo mode:
► Deactivating demo mode. (see Deactivating demo mode)
▷ The appliance is switched on.
▷ Previous settings are restored.
▷ The appliance cools to the target temperature set.
Switching temperature zone off and on
You can switch temperature zones of the appliance off inde‐
pendently.
Application:
-
Cleaning
-
Defrosting
Switching the fridge compartment off
Make sure that the following requirements are fulfilled:
❑
Refrigerator compartment has been emptied.
Controls
* Depending on model and options 9
Fig. 10 Example illustration
► Carry out action steps according to the illustration.
▷ Refrigerator compartment is switched off.
Switching the fridge compartment on
Fig. 11 Example illustration
► Carry out action steps according to the illustration.
▷ Refrigerator compartment is switched on.
▷ The appliance cools to the last set temperature.
WiFi
Use this function to connect your appliance to WiFi. You can
then operate it via the SmartDevice app on a mobile device.
You can also use this function to disconnect or reset the
WiFi connection.
To connect your device to WiFi, you need the SmartDevi‐
ceBox.
More information on the SmartDevice: (see 2.3 SmartDevice)
Note
The SmartDevice function is not available in the following
countries: Russia, Belarus, Kazakhstan.
You cannot use the SmartDeviceBox.
Establishing the WiFi connection for the first time
Make sure that the following requirements are fulfilled:
❑
You have purchased and inserted a SmartDeviceBox.
(see 2.3 SmartDevice)
❑
You have installed the SmartDevice app (see
apps.home.liebherr.com).
❑
Registration in the SmartDevice app is completed.
Fig.12
Fig.13
► Carry out action steps according to the illustration.
▷ Connection is established.
Disconnecting from the WiFi
Fig. 14
Fig. 15
► Carry out action steps according to the illustration.
▷ There is no connection.
Resetting the WiFi connection
Fig. 16
Fig.17
► Carry out action steps according to the illustration.
▷ WiFi connection and other WiFi settings are reset to
factory settings.
Controls
10 * Depending on model and options
Showing information about the WiFi connection
Fig. 18
Fig. 19
► Carry out action steps according to the illustration.
Temperature
Use this function to set the temperature.
The temperature depends on the following factors:
-
Frequency of door opening
-
Duration of door opening
-
Room temperature of the installation site
-
Type, temperature and quantity of food
Temperature zone
Factory-set
temperature
Recommended
setting
Fridge section
5°C 4°C
Freezer section
-18°C -18°C
Setting the temperature in the fridge section
Fig. 20 Example illustration
► Carry out action steps according to the illustration.
▷ Temperature is set.
Setting the temperature in the freezer section
Fig. 21 Example illustration
► Carry out action steps according to the illustration.
▷ Temperature is set.
Temperature unit
Use this function to set the temperature unit. You can set
degrees Celsius or degrees Fahrenheit as the temperature
unit.
Setting the temperature unit
Fig.22
Fig. 23 Example illustration: Switch from degreesCelsius
to degrees Fahrenheit.
► Carry out action steps according to the illustration.
▷ The temperature unit is set.
SuperCool
You can use this function to activate or deactivate Super‐
Cool. If SuperCool is activated, then the appliance increases
the cooling capacity. It allows you to achieve lower cooling
temperatures. You can activate SuperCool when you would
like to cool a large quantity of food quickly.
Controls
* Depending on model and options 11
If the function is active, the appliance operates at higher
power. As a result, the appliance's operating noise may be
temporarily louder and energy consumption will increase.
Activating SuperCool
Time for activation of the function:
-
When you would like to store fresh food in the fridge
section: Activate the function when inserting food.
Fig. 24
Fig.25
► Carry out action steps according to the illustration.
▷ SuperCool is activated.
Deactivating SuperCool
SuperCool is deactivated automatically after 18 hours.
However, you can also deactivate SuperCool manually at
any time:
Fig. 26
Fig.27
► Carry out action steps according to the illustration.
▷ SuperCool is deactivated.
▷ The appliance continues to run in normal mode.
▷ The appliance cools to the temperature set previously.
PowerCool
You can use this function to activate or deactivate Power‐
Cool. PowerCool ensures optimised temperature layers for
cooling your food.
The function applies to the fridge section.
Application:
-
At higher room temperatures (as of approx.35°C)
-
At high humidity, e.g. on summer days
-
When storing moist food, in order to prevent condensate
forming in the interior
Note
The fan may also run even if the function is deactivated.
It therefore ensures even temperature distribution in the
appliance.
If the function is active, the device operates at higher
power. As a result, the device's operating noise may be
temporarily louder and energy consumption will increase.
Activating PowerCool
Fig.28
Fig.29
► Carry out action steps according to the illustration.
▷ PowerCool is activated.
Deactivating PowerCool
Fig.30
Fig.31
► Carry out action steps according to the illustration.
▷ PowerCool is deactivated.
SuperFrost
You can use this function to activate or deactivate
SuperFrost. If SuperFrost is activated, then the appliance
increases the freezing capacity. It allows you to achieve
lower freezing temperatures.
Application:
-
Quickly freeze fresh food through to the core.
This ensures that the nutrition, appearance and taste of
frozen food is maintained.
-
Increase the cold reserve in stored frozen food before
defrosting the appliance.
If the function is active, the appliance operates at higher
power. As a result, the appliance's operating noise may be
temporarily louder and energy consumption will increase.
Activating SuperFrost
Make sure that the following requirements are fulfilled:
❑
Freezing quantity and time for activation of SuperFrost
are taken into account. (see Freezing food using
SuperFrost)
Controls
12 * Depending on model and options
Fig.32
Fig.33
► Carry out action steps according to the illustration.
▷ SuperFrost is activated.
Deactivating SuperFrost
SuperFrost is automatically deactivated after 56 to 72 hours
depending on the quantity of the food inserted. However,
you can also deactivate SuperFrost manually at any time:
Fig.34
Fig.35
► Carry out action steps according to the illustration.
▷ SuperFrost is deactivated.
▷ The appliance continues to run in normal mode.
▷ The appliance cools to the temperature set previously.
Start defrosting cycle*
Use this function to start the automatic defrosting cycle
manually if it does not start automatically in the event of a
fault.
This function applies to NoFrost devices.*
Starting defrosting cycle
Fig.36
Fig.37
► Carry out action steps according to the illustration.
▷ Defrosting cycle has started: Icon flashes until defrosting
cycle is automatically completed.
▷ When defrosting cycle is finished: The device continues
to run in normal mode.
Cancelling defrosting cycle
The defrosting cycle will be stopped automatically. However,
you can also cancel the defrosting cycle at any time during
the defrosting process:
Fig.38
► Carry out action steps according to the illustration.
▷ Defrosting cycle is cancelled.
▷ The device continues to run in normal mode.
PartyMode
You can use this function to activate or deactivate Party‐
Mode. PartyMode activates various functions that are useful
for a party.
PartyMode activates the following functions:
-
SuperCool (seeSuperCool)
-
SuperFrost (see SuperFrost)
-
IceMaker (see IceMaker *) and MaxIce (see MaxIce*) *
You can adjust all listed functions individually and flexibly.
When you deactivate PartyMode, all changes are discarded.
If the function is active, the device operates at higher
power. As a result, the device's operating noise may be
temporarily louder and energy consumption will increase.
Activating PartyMode
Make sure that the following requirements are fulfilled:
❑
The IceMaker has been started. (see 4.2 Starting the
IceMaker for the first time*) *
Fig. 39
Fig.40
► Carry out action steps according to the illustration.
▷ PartyMode and the associated functions are activated.
▷ The current temperature flashes until the target tempera‐
ture is reached.
Deactivating PartyMode
The PartyMode is automatically deactivated after
24 seconds. However, you can also deactivate PartyMode
manually at any time:
Fig. 41
Controls
* Depending on model and options 13
Fig. 42
► Carry out action steps according to the illustration.
▷ PartyMode is deactivated.
▷ The appliance cools to the temperature set previously:
The current temperature flashes until the target tempera‐
ture is reached.
HolidayMode
You can use this function to activate or deactivate Holiday‐
Mode. If you activate HolidayMode, the fridge section is set
to 15 °C. This saves you energy during longer periods of
absence and prevents bad odours and growth of mould.
Appliance status when HolidayMode is active
Fridge section cools to 15°C.
EasyFresh cools to 15°C.
The set temperature is maintained in the freezer section.
PartyMode is deactivated.
SuperCool is deactivated.
PowerCool is deactivated.
Activating HolidayMode
► Empty the fridge section completely.
► Empty EasyFresh completely.
Fig.43
Fig.44
► Carry out action steps according to the illustration.
▷ HolidayMode is activated.
▷ Temperature display shows HolidayMode symbol.
Deactivating HolidayMode
Fig.45
Fig.46
► Carry out action steps according to the illustration.
▷ HolidayMode is deactivated.
▷ The appliance cools to the temperature set previously.
SabbathMode
You can use this function to activate or deactivate
SabbathMode. If you activate this function, some electronic
functions are switched off. As a result, your device meets
the religious requirements for Jewish holidays such as
Sabbath and complies with STAR-K Kosher certification.
Device status when SabbathMode is active
The status display shows SabbathMode permanently.
All functions on the display are locked except for the
Deactivate SabbathMode function.
Active functions remain active.
The display remains bright when you close the door.
The interior lighting is deactivated.
Reminders are not implemented. The set time interval
stops.
Reminders and warnings are not displayed.
There is no door alarm.
There is no temperature alarm.
The IceMaker is switched off.*
The defrosting cycle operates only for the specified time,
without considering the appliance consumption.
After a power failure, the appliance returns to
SabbathMode.
Device status
Note
This appliance has certification from the “Institute for
Science and Halacha”. (www.machonhalacha.co.il)
You can find a list of STAR-K-certified appliances at
www.star-k.org/appliances.
Activating SabbathMode
WARNING
Danger of food poisoning from spoiled food!
If you have SabbathMode activated and a power failure
occurs, no message appears in the status display about the
power failure. Once the power is restored, the appliance
continues to operate in SabbathMode. The power failure
may mean that food spoils and the consumption of this food
could lead to food poisoning.
After a power failure:
► Do not consume food that was frozen and has thawed
out.
Fig. 47
Controls
14 * Depending on model and options
Fig.48
► Carry out action steps according to the illustration.
▷ SabbathMode is activated.
▷ The status display shows SabbathMode permanently.
Deactivating SabbathMode
The SabbathMode is automatically deactivated after
80 hours. However, you can also deactivate SabbathMode
manually at any time:
Fig. 49
► Carry out action steps according to the illustration.
▷ SabbathMode is deactivated.
E-Saver
You can use this function to activate or deactivate Energy
saving mode. If energy saving mode is activated, the energy
consumption decreases and the temperature in the device
increases. The food remains fresh, but the shelf life is short‐
ened.
Temperature zone
Recommended
setting (see Setting
the temperature in
the fridge section)
Temperature
with active E-
Saver
Fridge section
4°C 7°C
Freezer section
-18°C -16°C
Temperatures
Activating E-Saver
Fig.50
Fig.51
► Carry out action steps according to the illustration.
▷ Energy saving mode is activated.
Deactivating E-Saver
Fig.52
Fig.53
► Carry out action steps according to the illustration.
▷ Energy saving mode is deactivated.
IceMaker *
You can activate or deactivate ice cube production with this
function.
More information on the number
of ice cubes:
(see 10.1 Technical
specifications)
More information on increasing
the number of ice cubes:
(see MaxIce*)
More information on cleaning the
lines of the IceMaker:
(see TubeClean *)
If the function is active, the device operates at higher
power. As a result, the device's operating noise may be
temporarily louder and energy consumption will increase.
Activating IceMaker
Make sure that the following requirements are fulfilled:
❑
IceMaker is put into operation. (see 8.9 IceMaker*)
❑
Water tank is filled. (see 8.9.1 Fill the water tank*) *
Fig.54
Fig.55
► Carry out action steps according to the illustration.
▷ IceMaker is activated. It can take up to 24 hours for the
IceMaker to produce the first ice cubes.
Deactivating IceMaker
Make sure that the following requirements are fulfilled:*
❑
Water tank is empty. (see 8.9 IceMaker*)
Controls
* Depending on model and options 15
Fig.56
Fig.57
► Carry out action steps according to the illustration.
▷ IceMaker is deactivated.
▷ If ice cubes are currently being made, the system
completes the process.
▷ The IceMaker goes off automatically.
MaxIce*
Use this function to increase the amount of ice cubes
produced by the IceMaker. MaxIce is automatically deacti‐
vated after 48 hours. However, you can also deactivate
MaxIce manually at any time: (see Deactivating MaxIce) .
More information on the
number of ice cubes:
(see 10.1 Technical specifi‐
cations)
Activating MaxIce
If you activate MaxIce and have not previously activated
the IceMaker (see IceMaker *) function, then by pressing
MaxIce you can also automatically activate the IceMaker
function.
If you have not yet activated the IceMaker function, make
sure that the following requirements are met:
❑
IceMaker is put into operation. (see 8.9 IceMaker*)
❑
Water tank is filled. (see 8.9.1 Fill the water tank*) *
Fig.58
Fig. 59
► Carry out action steps according to the illustration.
▷ MaxIce is activated.
▷ If you have not activated the IceMaker function before:
IceMaker is activated.
Deactivating MaxIce
If you deactivate MaxIce, then the IceMaker function is still
activated.
Fig.60
Fig.61
► Carry out action steps according to the illustration.
▷ MaxIce is deactivated.
TubeClean *
You can use this function to activate or deactivate Tube‐
Clean. If TubeClean is activated, it cleans the IceMaker lines.
Activating TubeClean
Make sure that the following requirements are fulfilled:
❑
IceMaker cleaning is prepared. (see 9.5.4 Cleaning the
IceMaker*)
❑
Empty container with a capacity of 1.5 l and with a
maximum height of 10cm is ready.
► Place the container in the drawer under the IceMaker.
Fig. 62
Fig.63
► Carry out action steps according to the illustration.
▷ TubeClean is activated.
▷ The cleaning process has started: Icon flashes until
the cleaning process is automatically completed after
60 minutes.
▷ When the cleaning process is complete: The device
continues to run in normal mode.
Deactivating TubeClean
TubeClean is automatically ended after 60 minutes.
However, TubeClean can also be deactivated at any time
during the cleaning process:
Fig.64
► Carry out action steps according to the illustration.
▷ TubeClean is deactivated: Cleaning process is aborted.
▷ The device continues to run in normal mode.
CleaningMode*
You can use this function to activate or deactivate Cleaning‐
Mode. CleaningMode enables the appliance to be cleaned
conveniently.
This setting applies to the fridge section.
Controls
16 * Depending on model and options
Application:
-
Clean the fridge section. (see 9.5Cleaning the appliance)
Device status when CleaningMode is active
The status display shows CleaningMode permanently.
The fridge section is switched off.
Interior lighting is activated.
The reminders and warnings are not displayed. No signal
tone sounds.
Device status
Activating CleaningMode
Fig.65
Fig.66
► Carry out action steps according to the illustration.
▷ CleaningMode is activated.
▷ The status display shows CleaningMode permanently.
Deactivating CleaningMode
CleaningMode is deactivated automatically after
60 minutes. However, you can also deactivate Cleaning‐
Mode manually at any time:
Fig. 67
► Carry out action steps according to the illustration.
▷ CleaningMode is deactivated.
▷ The appliance cools to the temperature set previously.
Display brightness
Use this function to set the display brightness in stages.
You can select the following brightness levels:
-
40%
-
60%
-
80%
-
100 % (pre-setting)
Setting the brightness
Fig.68
Fig. 69 Example illustration: Switch from 80 % to 60%.
► Carry out action steps according to the illustration.
▷ The brightness is set.
Door alarm
Use this function to activate or deactivate the door alarm.
The door alarm sounds if the door is open for too long. The
door alarm is activated on delivery. You can set how long
the door may be open before the door alarm sounds.
The following values can be set:
-
1 minute
-
2 minutes
-
3 minutes
-
Off
Setting the door alarm
Fig.70
Fig. 71 Example illustration: Change door alarm from
1 minute to 3 minutes.
► Carry out action steps according to the illustration.
▷ The door alarm is set.
Deactivating the door alarm
Fig.73
Controls
* Depending on model and options 17
Fig. 74
► Carry out action steps according to the illustration.
▷ The door alarm is deactivated.
Input lock
You can use this function to activate or deactivate the input
lock. The input lock prevents the appliance being operated
accidentally, e.g. by children.
Application:
-
Avoid unintentional modification of functions.
-
Avoid unintentional switching off of the device.
-
Avoid unintentional temperature setting.
Activating the input lock
If you activate the input lock, you can continue to navigate
in the menus but you cannot select or change other func‐
tions.
Fig.75
3s
Displ. Lock
Displ. Lock
Fig. 76
► Carry out action steps according to the illustration.
▷ Input lock is activated.
Deactivating the input lock
Fig.77
3s
Displ. Lock
Displ. Lock
Fig.78
► Carry out action steps according to the illustration.
▷ Input lock is deactivated.
Device information
Use this function to indicate the model name, index, serial
number and service number of your device. You will need
the device information when you contact customer service.
(see 10.4 Customer Service)
This function also opens the Advanced menu. (see 3 Func‐
tionality of the Touch display)
Indicating the device information
Fig.79
Fig.80
► Carry out action steps according to the illustration.
▷ Display indicates device information.
Software
Use this function to indicate the software version of your
device.
Indicating the software version
Fig.81
Fig.82
► Carry out action steps according to the illustration.
▷ Display indicates software version.
Reminder
Use this function to activate or deactivate the reminders.
The function is activated on delivery.
If the function is activated, the following reminders will
appear:
-
Replace the FreshAir activated carbon filter (see Replace
the FreshAir activated carbon filter)
Activating the reminder
Fig.83
Controls
18 * Depending on model and options
Fig.84
► Carry out action steps according to the illustration.
▷ Reminder is activated.
Deactivating the reminder
Fig.85
Fig.86
► Carry out action steps according to the illustration.
▷ Reminder is deactivated.
Demo mode
Demo mode is a special feature for dealers who want to
demonstrate appliance features. If you activate demo mode,
all refrigeration functions are deactivated.
If you switch on your appliance and “Demo” appears in the
status display, then demo mode is already activated.
If you activate and then deactivate demo mode, the appli‐
ance will be reset to factory defaults. (see Resetting to
factory settings)
Activating demo mode
Fig. 87
Fig.88
► Carry out action steps according to the illustration.
▷ Demo mode is activated.
▷ Appliance is switched off.
► Switch on the appliance. (see 4.1 Switching on appliance
(first use))
▷ “DEMO” appears in the status display.
Deactivating demo mode
Fig.89
Controls
* Depending on model and options 19
Fig.90
► Carry out action steps according to the illustration.
▷ Demo mode is deactivated.
▷ Appliance is switched off.
► Switch on the appliance. (see 4.1 Switching on appliance
(first use))
▷ Appliance is reset to factory settings.
Resetting to factory settings
Use this function to reset all settings to factory defaults.
All settings you have made so far are reset to their original
settings.
Performing a reset
Fig. 91
Fig.92
► Carry out action steps according to the illustration.
▷ Device is reset.
▷ Device is switched off.
► Restart the device. (see 4.1 Switching on appliance (first
use))
7.3 Messages
There are two categories of messages:
Category
Importance
Warning Warnings appear in the event of a door alarm or
malfunction.
Simple warnings can be cancelled by yourself.
In the event of serious malfunctions, you must
contact customer service. (see 10.4 Customer
Service)
Reminder Reminders remind you of general processes.
You can carry out these operations to end the
message.
7.3.1 Overview of warnings
Behaviour of the appliance in the event of warnings:
-
Warning appears on the display.
-
The alarm tone sounds at an ever-increasing volume.
-
The interior lighting pulsates for some warnings.
Message
Cause Exit the
message
Door alarm
The message appears
if the door is open for
too long.
Carry out action
steps (see Door
alarm) .
Message Cause Exit the
message
Power outage
alarm
The message appears
if the freezing temper‐
ature has risen due to
a power failure.
Carry out action
steps
(see Power
outage alarm) .
Temperature
alarm
The message appears
if the freezing temper‐
ature does not corre‐
spond to the set
temperature.
Carry out action
steps
(see Tempera‐
ture alarm) .
Error
The message appears
if there is an appliance
error. A component of
the appliance has a
fault.
Carry out action
steps
(see Error) .
7.3.2 Ending warnings
Door alarm
Fig. 93 Example illustration
► Carry out action steps according to the illustration.
-or-
► Close the door.
▷ The display returns to the status indicator.
You can set how long the door may be open before the door
alarm sounds. (see Setting the door alarm)
Power outage alarm
When the power failure has ended, the appliance will auto‐
matically cool down to the previously set target tempera‐
ture without you having to confirm the message. However,
for the message to disappear from the display, you must
confirm it.
Fig. 94 Example illustration
► Press the confirmation symbol.
▷ Warmest freezing temperature is displayed.
▷ If the freezing temperature was below -9 °C: Food can
still be consumed.
If the freezing temperature has risen above -9°C:
► Check the food.
► Press the confirmation symbol.
▷ The display returns to the status indicator: Current
temperature and target temperature are displayed.
Controls
20 * Depending on model and options
Temperature alarm
Temperature differences can be caused by:
-
You have put in warm, fresh food.
-
Too much warm air has got in while you were sorting out
the freezer or removing items.
-
There has been a longer power failure.
-
The appliance is faulty.
► Eliminate causes.
▷ The appliance cools to the target temperature set previ‐
ously.
Fig. 95 Example illustration
► Press the confirmation symbol.
▷ Warmest freezing temperature is displayed.
▷ If the freezing temperature was below -9 °C: Food can
still be consumed.
If the freezing temperature has risen above -9°C:
► Check the food.
► Press the confirmation symbol.
▷ The display returns to the status indicator: Current
temperature and target temperature are displayed.
Error
Fig. 96 Example illustration
► Press the confirmation symbol.
▷ Error code is displayed.
► Note the error code.
► Press the confirmation symbol.
▷ The display returns to the status indicator.
► Contact Customer Service. (see 10.4 Customer Service)
7.3.3 Overview of reminders
Behaviour of the appliance during reminders:
-
Reminder appears on the display.
-
Alarm tone sounds.
-
The interior lighting pulsates for some reminders.
The following reminders can be deactivated (see Deacti‐
vating the reminder) :
-
Replace the FreshAir activated carbon filter
Message
Cause Exit the message
*
Fill the water
tank*
The message
appears if the
IceMaker is acti‐
vated but there is
not enough water in
the water tank.*
Carry out action
steps (see Fill the
water tank*) .*
*
Insert the
IceMaker
drawer*
The message
appears if the
IceMaker is acti‐
vated but the
IceMaker drawer is
open.*
Carry out action
steps (see Insert
the IceMaker
drawer*) .*
Replace the
FreshAir acti‐
vated carbon
filter
The message
appears when the
FreshAir activated
carbon filter needs
to be replaced.
Carry out
action steps
(see Replace the
FreshAir activated
carbon filter) .
7.3.4 Ending reminders
Fill the water tank*
Fig. 97 Example illustration
► Press the confirmation symbol.
► Fill the water tank.
-or-
► Deactivate IceMaker. (see IceMaker *)
▷ When the water tank is full and the IceMaker is activated:
IceMaker produces ice cubes.
Fig.98
If you have filled the water tank and the reminder
persists:
► Check whether the float Fig.98(1) is jammed.
If the float is jammed:
► Empty the water tank.
► Move the float with a thin tool, e. g. a cotton bud.
If you have checked the float and the reminder persists:
► Contact Customer Service. (see 10.4 Customer Service)
Controls
* Depending on model and options 21
Insert the IceMaker drawer*
Fig. 99 Example illustration
► Press the confirmation symbol.
► Insert the IceMaker drawer.
-or-
► Deactivate IceMaker. (see IceMaker *)
▷ If IceMaker drawer is inserted and IceMaker is activated:
IceMaker produces ice cubes.
Replace the FreshAir activated carbon filter
Liebherr recommends: Replace the FreshAir activated
carbon filter every 6 months.
Note
FreshAir activated charcoal filters can be purchased
from the Liebherr-Hausgeräte store at home.liebherr.com/
shop/de/deu/zubehor.html.
Fig. 100 Example illustration
► Press the confirmation symbol.
► Replace the activated carbon filter. (see 9.1 FreshAir
carbon filter)
▷ Activated carbon filter ensures optimum air quality in the
cooling unit.
▷ Reminder appears again after 6 months.
If you no longer wish to receive this reminder, you can deac‐
tivate it. (see Deactivating the reminder)
8 Features
8.1 Door rack
Door racks are suitable for storing drinks and food. You can
move door racks for your own individual use and take them
apart for cleaning. However, Liebherr recommends using the
door racks in the position in the door as delivered from the
factory.
Fig. 101 Example illustration, Door rack
(1)
Shelf
Fig. 102 Example illustration, Door rack with bottle holder
(1) Shelf (2) Bottle holder
The following table shows examples of what can be stored
in each door rack. Do not exceed the maximum loading
weight of the door.
Door rack
Food
Door rack (see Fig. 101) Butter, cheese, tinned food,
tubes
Door rack with bottle
holder (see Fig. 102)
Bottles
The sliding bottle holder
secures the bottles in the
door rack.
8.1.1 Removing the door rack
Fig. 103 Example illustration
► Push the door rack upwards.
► Pull the door rack forward.
8.1.2 Inserting the door rack
Fig. 104 Example illustration
► Slide in the door rack.
► Press the door rack down.
8.1.3 Removing the bottle holder
Features
22 * Depending on model and options
Fig. 105
► Slide the bottle holder to the side as far as the recess.
► Remove the bottle holder forwards.
8.1.4 Inserting the bottle holder
Fig. 106
► Insert the bottle holder in the recess.
► Push the bottle holder to the desired position to the side.
8.2 Shelves
8.2.1 Adjusting/removing the shelves
The shelves are prevented from being pulled out acciden‐
tally by pull out stops.
Fig. 107
► Lift the shelf and pull forward.
▷ Line up the side runner.
► Adjust the height of the shelf: Lift or lower it to the
desired height and slide it in.
-or-
Fig. 108
► Remove the shelf completely: Pull it out to the front.
► Easier removal: Set the shelf at an angle.
► Insert the shelf again: Slide it in all the way.
▷ The pull-out stoppers point downwards.
▷ The pull-out stoppers are behind the front support.
You can also remove the shelf above the EasyFresh
compartments.
Fig. 109
Removing the shelf:
If the IceMaker (see 8.9 IceMaker*) has been removed:*
► Lift the shelf at the front and back.*
► Lift the shelf at the front and back.*
► Pull it out towards you.
Do not store any goods on the compartment cover below!
Inserting the shelf:
► Place the shelf at an angle, sloping down towards the
back.
▷ The pull-out stoppers point downwards.
► Slide the shelf into place.
8.2.2 Dismantling the shelves
The shelves can be dismantled for cleaning.
Fig. 110
► Dismantling the shelf.
8.3 Dividing shelf*
8.3.1 Using the dividing shelf
The shelves are prevented from being pulled out acciden‐
tally by pull out stops.
Fig.111
► Push the dividing shelf underneath as shown.
Fig.112
Adjusting the height:
► Pull the glass panels out Fig.112(1) from the front, one at
a time.
► Release the support rails and click in at the height you
want.
► Slide in the glass panels one at a time.
▷ Flat pull-out stoppers at the front, right behind the
support rails.
▷ High pull-out stoppers at the back.
Using both shelves:
► Hold the glass panel with one hand and pull it to the
front.
▷ The glass panel Fig.112(1) and trim strip are at the front.
Features
* Depending on model and options 23
▷ The stops Fig.112(3) point down.
8.4 VarioSafe *
The VarioSafe offers space in the refrigerator compartment
for small groceries, packages, tubes and jars, for example.
Fig.113
(1)
VarioSafe drawer (3) Recesses on the left and
right side panel
(2) Side panels with ribs
for VarioSafe drawer
(4) Stop edge
8.4.1 Inserting the VarioSafe
Fig. 114
► Insert the VarioSafe into the fridge section at an angle
Fig. 114 (1) until the recesses in the side Fig. 114 (2) of the
VarioSafe are at the level of the support rib in the fridge
section.
Fig. 115
► Set VarioSafe straight. Fig. 115(1)
► Lift VarioSafe at the front. Fig. 115(2)
Fig. 116
► Lift VarioSafe up toward the front.
► Push VarioSafe in to the rear.
► Lower VarioSafe.
▷ VarioSafe audibly engages.
▷ VarioSafe is inserted.
8.4.2 Repositioning the VarioSafe
You can move the VarioSafe as a whole in the refrigerator
compartment.
Fig.117
► Lift VarioSafe at the front.
Fig. 118
Features
24 * Depending on model and options
► Pull VarioSafe forwards until the recesses in the side of
the VarioSafe are at the level of the support rib in the
refrigerator compartment. Fig. 118(1)
► Move VarioSafe up or down in the refrigerator compart‐
ment until the desired height is reached. Fig. 118(2)
Fig. 119
► Lift VarioSafe at the front.
► Push VarioSafe in to the rear.
▷ VarioSafe audibly engages.
▷ VarioSafe is offset in height.
8.4.3 Moving the VarioSafe drawer
You can use the VarioSafe drawer at two different heights.
If you would like to store taller foodstuffs in the VarioSafe
drawer, slide the VarioSafe drawer in on the bottom rib. If
you would like to store smaller foodstuffs in the VarioSafe
drawer, slide the VarioSafe drawer in on the top rib.
Fig.120
► Pull out the VarioSafe drawer as far as it will go.
► Lift the VarioSafe drawer up at the front.
► Remove the VarioSafe drawer to the front.
Fig.121
► Lift the VarioSafe drawer up at the front.
► Place the VarioSafe drawer behind the stoppers on
desired rib Fig.121(1) or Fig.121(2).
▷
VarioSafe drawer is offset in height.
8.4.4 Removing the VarioSafe
You can remove the VarioSafe as a whole.
Fig.122
► Lift VarioSafe at the front.
Fig.123
► Pull VarioSafe forwards Fig. 123 (1) until the recesses in
the side of the VarioSafe are at the level of the support
rib in the fridge section. Fig.123(2)
Fig. 124
► Set VarioSafe in refrigerator compartment at an angle.
Fig. 124(1)
► Take VarioSafe out to the front. Fig. 124(2)
▷ VarioSafe is removed.
Features
* Depending on model and options 25
8.4.5 Disassembling the VarioSafe
You can disassemble the VarioSafe into its individual parts if
you want to clean the VarioSafe or if you need to install or
remove parts.
Fig.125
► Remove VarioSafe as a whole. (see 8.4.4 Removing the
VarioSafe )
► Disassemble VarioSafe according to the illustration.
8.5 Space for baking tray
There is space for a baking tray Fig.1(7) above the drawers.
Fig. 126
Ensure that the following conditions are met:
❑
Max. baking tray dimensions are adhered to
(see 10.1 Technical specifications) .
❑
Baking tray is cooled to room temperature.
❑
The lowest door rack is set at least one position higher.
With the door open to 90°:
► Slide the baking tray onto the lower side runners.
8.6 Drawers
You can remove the drawers for cleaning.
You can remove the drawers to use VarioSpace.
The way to remove/insert the drawers varies depending
on the pull-out system. Your appliance can contain various
pull-out systems.
For appliances with NoFrost:*
Note
The energy consumption increases and the cooling power
goes down if ventilation is not sufficient.*
► Leave the bottom drawer in the appliance!*
► Always leave the fan air vents clear on the back wall!*
For appliances without NoFrost:*
Note
The energy consumption increases and the cooling power
goes down if ventilation is not sufficient.*
► Always leave the fan air vents clear on the back wall!*
8.6.1 Drawer on appliance base or glass shelf
The drawer runs directly on the appliance base or on a glass
shelf. There are no rails.
When you remove the drawers, you can use the glass
shelves below them as storage shelves.
Removing drawer
Fig.127
► Remove drawer as shown in the illustration.
Inserting drawer
Fig.128
► Insert drawer as shown in the illustration.
8.6.2 Drawer on rails
Removing drawer
Fig.129
► Remove drawer as shown in the illustration.
Inserting drawer
Fig.130
► Insert drawer as shown in the illustration.
Features
26 * Depending on model and options
8.6.3 Drawer on telescopic rails
The drawer runs on extendible rails (telescopic rails). There
are fully extendible telescopic rails and telescopic rails with
partial pull-out. Drawers which are fully extendible can be
pulled out fully from the appliance. Drawers with partial
pull-out cannot be removed fully from the appliance. The
system in your appliance depends on the type of appliance.
Fully extendible*
If you have fully extendible rails, there is a clamp located at
the back on the left and right of the rail.
Removing drawer
Fig.131
► Pull out drawer as far as it will go.
► Lift left clamp and simultaneously pull drawer forwards
on the left. Fig.131(1)
► Lift right clamp and simultaneously pull drawer forwards
on the right. Fig.131(2)
► Remove drawer to the front. Fig.131(3)
► Slide rails in.
Inserting drawer
Fig.132
► Slide rails in.
► Place drawer on rails.
► Slide in drawer to the back.
▷ Drawer latches in audibly at the back.
Partial pull-out fridge compartment*
Removing drawer
Fig.133
► Pull out drawer half-way. Fig.133(1)
► Push the drawer down at the front. Fig.133(2)
► Push the left rail in by about 2cm. Fig.133(3)
► Push the right rail in by about 2cm. Fig.133(4)
► Remove drawer to the front. Fig.133(5)
Fig.134
If the rails are not yet fully inserted after removing the
drawer:
► Push rails in completely.
Inserting drawer
Fig.135
► Slide rails in.
► Place drawer on rails.
► Slide in drawer to the back.
8.7 Compartment lid for EasyFresh Safe
The compartment lid ensures constant levels of humidity.
The compartment lid is directly on the drawer and can be
covered by shelves or additional drawers.
Fig. 136 Example illustration, compartment lid for EasyFresh
Safe
(1)
EasyFresh Safe (3) Shelf
(2) Compartment lid for
EasyFresh Safe
8.7.1 Reducing the air humidity in the drawer
Fig.137
► Pull out the drawer Fig.137(1).
► Grasp the recessed grip Fig. 137 (2) on the compartment
lid and pull the compartment lid forwards at the same
time.
▷ When the drawer is closed, there is a small gap between
the compartment lid and the drawer.
Features
* Depending on model and options 27
8.7.2 Increasing the air humidity in the drawer
Fig.138
► Pull out the drawer Fig.138(1).
► Grasp the recessed grip Fig. 138 (2) on the compartment
lid and push the compartment lid backwards at the same
time.
▷ When the drawer is closed, the compartment lid seals
with the drawer.
8.8 Glass shelves
You can remove the glass shelves under the drawers for
cleaning.
You can remove the glass shelves under the drawers to use
VarioSpace.
8.8.1 Removing / inserting the glass shelf
Make sure that the following requirements are fulfilled:
❑
Glass shelf under the drawer: The drawer has been
removed. (see8.6 Drawers)
Removing glass shelf
Fig. 139 Example illustration, glass shelf
► Lift the glass shelf forwards.
► Remove the glass shelf forwards.
Inserting glass shelf
Fig. 140 Example illustration, glass shelf
► Place the glass shelf at an angle behind the stoppers.
► Lower glass shelf.
► Slide in glass shelf to the back.
8.9 IceMaker*
The IceMaker produces ice cubes with the water tank in the
fridge section. The water tank can also be used to provide
cooled drinking water.*
The IceMaker will produce ice cubes for household use only.
Ensure that the following conditions are met:
-
The IceMaker is clean. (see9 Maintenance)
-
The water tank is clean. (see9 Maintenance) *
-
IceMaker drawer is cleaned.
-
IceMaker drawer is fully inserted.
8.9.1 Fill the water tank*
WARNING
Unclean water!
Contaminants.
► Only fill the water tank with potable water.
► If you are not using the IceMaker: Empty the water tank.
(see 9.5.4 Cleaning the IceMaker*)
NOTICE
Sugar-content liquids!
Damage to IceMaker.
► Only fill with cold drinking water.
Note
Using filtered, decarbonised water ensures the best-tasting
drinking water for your ice cubes.
This water quality can be achieved using a table water filter
of the kind available in trade retail outlets.
► Always fill the water tank only with filtered, decarbonised
drinking water.
The water for the IceMaker is supplied via a water tank.
(see2Appliance at a glance)
If the water tank is empty, the following reminder is shown
on the display:
(see 7.3.3 Overview of reminders)
Fig. 141
► Pull the water tank towards you and out.
► Remove the lid.
► Fill with drinking water.
► Put the lid on.
► Insert the water tank into the brackets and slide in all the
way.
Features
28 * Depending on model and options
8.9.2 Producing ice cubes
The volume depends on the freezing temperature. The
colder the temperature, the more ice cubes the system can
produce in a certain time period.
After the IceMaker is turned on for the first time, it can take
up to 24 hours for the first ice cubes to be made.
► Activate the IceMaker function.
► Producing many ice cubes: Activate the MaxIce function.
► To make a high number of ice cubes: Move the divider in
the IceMaker drawer or remove it completely.*
► Distribute the ice cubes evenly in the drawer to increase
the capacity.
► Closing the drawer: IceMaker starts making ice cubes
again automatically.
Note
When a certain level is reached in the IceMaker drawer, it
stops producing ice cubes. The IceMaker does not fill the
drawer all the way to the top.
8.9.3 Using the drawer with the IceMaker deac‐
tivated
If you deactivate the IceMaker, then you can use the entire
IceMaker drawer as a freezer drawer.
► Deactivate IceMaker. (see Deactivating IceMaker )
Fig. 142
► Place food in drawer.
If you put food in the left side of the drawer:
► Watch out for the IceMaker Fig. 142(1).
8.10 VarioSpace
Fig. 143
You can remove drawers and glass panels from your appli‐
ance. This provides more room for large food items such as
poultry, joints of meat, large game, and tall baked products.
You can then freeze these items whole for later preparation.
► Note the weight limits on the drawers and glass panels
(see 10.1 Technical specifications) .
8.11 Bottle holder
8.11.1 Using the bottle holder
Fig. 144
► Push the bottle holder onto the bottles.
▷ The bottles are prevented from falling over.
8.12 Flexible ice compartment divider*
The IceMaker’s ice cube drawer has a flexible ice compart‐
ment divider. This allows you to store larger quantities of ice
cubes or additional food items as needed. You can move or
remove the ice compartment divider.
8.12.1 Moving in the flexible ice compartment
divider
Fig. 145 Example illustration of the ice compartment
divider
► Move the ice compartment divider to the desired position.
8.12.2 Removing the flexible ice compartment
divider
Make sure that the following requirements are fulfilled:
❑
Ice cube drawer is removed. (see8.6 Drawers)
Fig. 146
► Lift the rear part of the ice compartment divider.
Fig. 146(1)
► Remove the ice compartment divider upwards. Fig. 146(2)
Features
* Depending on model and options 29
8.12.3 Putting in the flexible ice compartment
divider
Make sure that the following requirements are fulfilled:
❑
Ice cube drawer is removed. (see8.6 Drawers)
Fig. 147
► Insert the front part of the ice compartment divider.
Fig. 147(1)
► Lower the rear part of the ice compartment divider to the
drawer bottom. Fig. 147(2)
8.13 FlexCube*
The FlexCube has different sized openings, so you can store
small items such as tubes, open yoghurt pots or quail
eggs in it. The FlexCube fits into all Liebherr door racks,
for example. If necessary, you can also set up several Flex‐
Cubes next to each other.
Fig. 148 Example illustration
Note
These accessories can be purchased from the Liebherr-
Hausgeräte shop at home.liebherr.com/shop/de/deu/
zubehor.html.
8.13.1 Using the FlexCube
Fig. 149 Example illustration
► Insert the FlexCube in the door rack.
-or-
Fig. 150 Example illustration
► Place FlexCube on shelf.
► Sort small parts into the FlexCube for storage.
9 Maintenance
9.1 FreshAir carbon filter
The FreshAir carbon filter is in the compartment above the
fan.
It guarantees the best air quality.
❑
Replace the carbon filter every 6 months.
When the reminder is set, a message on the display
prompts you to change it.
❑
The carbon filter can be disposed of with the regular
household waste.
Note
FreshAir activated charcoal filters can be purchased
from the Liebherr-Hausgeräte store at home.liebherr.com/
shop/de/deu/zubehor.html.
9.1.1 Removing the FreshAir carbon filter
Fig. 151
► Pull out the compartment Fig. 151(1).
► Remove the carbon filter Fig. 151(2).
Maintenance
30 * Depending on model and options
9.1.2 Inserting the FreshAir carbon filter
Fig. 152
► Insert the carbon filter as shown in the diagram
Fig. 152(1).
▷ The carbon filter clicks into place.
If the carbon filter is pointing downwards:
► Push the compartment in Fig. 152(2).
▷ The carbon filter is now ready for use.
9.2 Disassembling / assembling pull-
out systems
9.2.1 Notes on disassembly
You can disassemble some of the pull-out systems for
cleaning. Your appliance can contain a variety of pull-out
systems.
The following pull-out systems can be disassembled or
cannot be disassembled:
Pull-out system
can be disassembled/
cannot be disassembled
Drawer on appliance base or
glass shelf
cannot be disassembled
Drawer on rails cannot be disassembled
Fully extendible* cannot be disassembled*
Fridge section partial pull-out* cannot be disassembled*
9.3 Compartment lid for EasyFresh Safe
You can remove the compartment lid for cleaning.
9.3.1 Removing the compartment lid
Ensure that the following requirements are met:
❑
The shelf directly above the drawer has been removed.
(see8.2 Shelves)
❑
The drawer directly below the compartment lid has been
removed. (see8.6 Drawers)
Fig. 153
► Push the compartment lid backwards.
► Lift the compartment lid forwards.
► Remove the compartment lid forwards and upwards at an
angle.
9.3.2 Inserting the compartment lid
Fig. 154
If the THIS SIDE UP lettering is at the top:
► Insert the rear retaining parts into the relevant rear open‐
ings.
► Push the compartment lid backwards.
► Lower the compartment lid forwards and engage the
front retaining parts into the openings.
► Move the compartment lid into the required position.
9.4 Defrosting the appliance
WARNING
Improper defrosting of the appliance!*
Injuries and damage.
► Do not use mechanical equipment or other methods to
speed up the defrosting process other than those recom‐
mended by the manufacturer.
► Do not use electrical heating or steam-cleaning appli‐
ances, naked flames or defroster sprays to defrost.
► Do not use sharp objects to remove ice.
9.4.1 Defrosting the fridge compartment
Defrosting is performed automatically. The water from the
thawing process drains through the outlet and evaporates.
Water drops or a thin layer of frost or ice can form on the
back wall; this is a completely normal part of the applian‐
ce’s function. This must not be removed.
A layer of frost or ice can from briefly due to the energy-
optimised control of the device.*
A layer of frost or ice can from briefly due to the energy-
optimised control of the device.*
► Clean the drain opening at regular intervals.
(see 9.5Cleaning the appliance)
9.4.2 Defrosting the freezer compartment with
NoFrost*
Defrosting is performed automatically with the NoFrost
system. The moisture is deposited on the evaporator, is peri‐
odically defrosted and evaporates.
The appliance does not have to be defrosted.
9.4.3 Defrosting the freezer compartment
manually*
A layer of frost or ice forms after prolonged use.
Maintenance
* Depending on model and options 31
The following factors promote the formation of frost or ice:
- The appliance is opened frequently.
- Hot food is put in.
One day before defrosting:
► Activate SuperFrost. (see 7.2Appliance functions)
▷ Frozen goods have a “residual coldness”.
► Switch the appliance off.
► Pull the mains plug out of the socket or switch the fuse
off.
► Wrap the frozen produce in newspaper or blankets and
store in a cool place.
► Place a pan of hot water (not
boiling) on the middle shelf.
▷ This speeds up the defrosting process.
► Leave the appliance door open during defrosting.
► Remove loosened pieces of ice.
► Make sure that there is no melted ice water in the
cabinet.
► Soak up the melted ice water with a sponge or cloth
several times as necessary.
► Clean the appliance. (see 9.5Cleaning the appliance)
9.5 Cleaning the appliance
9.5.1 Ready
WARNING
Danger of electric shock!
► Remove the refrigerator connector or interrupt the power
supply.
WARNING
Risk of fire
► Do not damage the refrigeration circuit.
► Empty the appliance.
► Remove mains connector.
-or-
► Activate CleaningMode. (see CleaningMode*) *
9.5.2 Cleaning the interior
NOTICE
Improper cleaning!
Damage to the appliance.
► Only use soft cleaning cloths and ph-neutral all-purpose
cleaners.
► Do not uses abrasive sponges or steel wool which may
cause scratches.
► Do not use any sharp or abrasive cleaning agents, nor
any that contain sand, chloride or acid.
► Plastic surfaces: clean by hand with a soft clean cloth,
lukewarm water and a little detergent.
► Metal surfaces: clean by hand with a soft clean cloth,
lukewarm water and a little detergent.
► Drain hole: remove deposits using a thin item (for
example a cotton bud).
9.5.3 Clean the components
NOTICE
Improper cleaning!
Damage to the appliance.
► Only use soft cleaning cloths and ph-neutral all-purpose
cleaners.
► Do not uses abrasive sponges or steel wool which may
cause scratches.
► Do not use any sharp or abrasive cleaning agents, nor
any that contain sand, chloride or acid.
Clean with a soft, clean cloth, lukewarm water and some
detergent:
- Door rack
- Shelf
- Dividing shelf*
- VarioSafe*
- Compartment lid for EasyFresh Safe
- Drawer
Please note: Do not remove the magnet on the drawer.
The magnet ensures the functionality of the IceMaker.*
- Flexible ice compartment divider in the IceMaker's ice
cube drawer*
Clean with a damp cloth:
- Retractable rails
Please note: The grease in the tracks is used for lubrica‐
tion and must not be removed!
Wash in the dishwasher up to 60°C:
- Bottle rack
- Holder of the dividing shelf
- IceMaker water tank and water tank lid*
- Ice cube tray*
- Ice cube scoop*
- FlexCube*
► To disassemble components: see the relevant section.
► Clean the components.
9.5.4 Cleaning the IceMaker*
There are various options for cleaning the IceMaker.
Cleaning is required in the following cases:
❑
Initial operation
❑
With water tank:*
If out of use for more than 48 hours.*
Ensure that the following conditions are met:
❑
Water tank is clean and has been filled. (see 8.9.1 Fill the
water tank*) *
❑
IceMaker drawer is emptied.
❑
IceMaker drawer is in place.
❑
The IceMaker is activated.
First use or after a long period of non-use
Clean the IceMaker with the TubeClean function.
► Put an empty 1.5 l vessel (max. height 10 cm) in the
drawer under the IceMaker.
► Activate the TubeClean function.
▷ The rinse process is prepared (max. 60 min.): Symbol
flashes.
▷ Water pipes are rinsed: Symbol flashes.
▷ Rinsing process is complete: Function turns off automati‐
cally.
► Remove the IceMaker drawer and remove the container.
► Clean the IceMaker drawer with warm water and a little
detergent.
► Push the IceMaker drawer in.
▷ The system starts making ice cubes automatically.
Without a water filter
Maintenance
32 * Depending on model and options
► Dispose of any ice cubes that were made 24 hours after
the first ice cubes.
If cleaning is required
Clean the IceMaker by hand.
► Remove the IceMaker drawer and clean with warm water
and a little detergent.
► Push the IceMaker drawer in.
▷ The system starts making ice cubes automatically.
9.5.5 After cleaning
► Wipe the appliance and the components dry.
► Connect and switch on the appliance.
► Activate SuperFrost (see 7.2Appliance functions) .
The temperature is cold enough:
► Place the food inside.
► Repeat cleaning regularly.
10 Customer help
10.1 Technical specifications
Temperature range
Cooling 2°C to 9°C
Freeze -26°C to -15°C
Maximum ice cube quantity / 24 hours
Freezer compart‐
ment
see type plate under “Freezing
capacity …/ 24 h”
Maximum component capacity
Features Appliance
width
550 mm
(see instal‐
lation
instruc‐
tions,
appliance
dimen‐
sions)
Appliance
width
600 mm
(see
installa‐
tion
instruc‐
tions,
appliance
dimen‐
sions)
Appliance
width
700 mm
(see instal‐
lation
instruc‐
tions, appli‐
ance
dimen‐
sions)
Drawer on glass
shelf
(see 8.6.1 Drawer
on appliance base
or glass shelf)
12 kg 15 kg --
Maximum size baking tray
Width 466mm
Depth 386mm
Height 50mm
Ice cube production with IceMaker*
Ice cube produc‐
tion / 24 hours
At a temperature of -18 °C: 1.2 kg of
ice cubes
maximum ice
cube produc‐
tion / 24 hours
With the MaxIce function on: 1.5 kg of
ice cubes
Lighting
Class
1
Light source
This product contains one or more energy
efficiency class F light sources.
LED
1
The appliance may contain light sources with different
energy efficiency classes. The lowest energy efficiency class
is indicated.
10.2 Operating noises
The appliance makes different noises when it is on.
-
At higher temperatures the appliance uses less energy
but works for longer. It is quieter.
-
At lower temperatures the food is cooled faster. It is
louder.
Examples:
•
Functions on (see 7.2Appliance functions)
•
Fan running
•
Food recently added
•
High ambient temperature
•
Door open for a while
Noise
Possible cause Type of noise
Bubbling and
splashing
Coolant flowing
into the cooling
circuit.
Normal operating
noise
Hissing Coolant sprays
into the cooling
circuit.
Normal operating
noise
Humming The appliance
is cooling. The
volume depends
on the cooling
output.
Normal operating
noise
Suction noises* Soft-closing door
is being opened
and closed.*
Normal operating
noise*
Humming and
rustling
The fan is running. Normal operating
noise
Clicking Components are
switched on and
off.
Normal switching
noise
Rattling or
humming
Valves or flaps are
working.
The water tank
pump is on.*
Normal switching
noise
Noise Possible
cause
Type of noise Lifting
Vibration Improper
installation
Defective
noise
Check the
installation.
Level the
appliance.
Rattling Components,
items inside
the appliance
Defective
noise
Secure
components.
Leave
enough
space
between the
items.
Customer help
* Depending on model and options 33
10.3 Technical fault
Your appliance is designed and built to ensure it works reli‐
ably and has a long service life. In the unlikely event that
a fault occurs during operation, please check whether it is
due to an operating error. If so, you will be charged for the
callout and repair costs even if it falls within the warranty
period.
You can fix the following faults yourself.
10.3.1 Appliance function
Defect Cause Remedy
The appliance is
not working.
→ The appliance is not switched on. ► Switch the appliance on.
→ The power plug is not properly
plugged into the socket.
► Check the power plug.
→ There is something wrong with the
power outlet fuse.
► Check the fuse.
→ Power cut ► Keep the appliance closed.
► Safeguarding food: Place cold packs on top of food or
use another freezer if the power cut lasts longer.
► Do not re-freeze defrosted food,
→ The IEC socket is not plugged into
the appliance correctly.
► Check the IEC socket.
Temperature is not
cold enough.
→ The appliance door is not closed
properly.
► Close the appliance door.
→ Not enough ventilation. ► Keep ventilation grille clear, and clean it.
→ The ambient temperature is too
high.
► Problem solution: (see2.4 Appliance range of use)
→ The appliance was opened too
many times or for too long.
► Wait to see if the required temperature corrects itself.
If not, contact Customer Service. (see 10.4 Customer
Service)
→ Too much fresh food was placed
inside without SuperFrost.
► Solution: (see SuperFrost)
→ The temperature is set incorrectly. ► Turn down the temperature and check after 24 hours.
→ The appliance is too close to a heat
source (oven, radiator, etc).
► Move the appliance or the heat source.
→ The appliance was not correctly
installed in the recess.
► Check if the appliance was installed correctly and that
the door closes properly.
The door seal is
defective or needs
to be replaced for
another reason.
→ The door seal can be replaced. It
can be replaced without the need
for special tools.
► Contact Customer Service. (see 10.4 Customer Service)
The appliance
builds up too much
ice or condensa‐
tion.
→ The door seal may have slipped out
of its groove.
► Check that the door seal is well fitted in the groove.
10.3.2 Features
Defect Cause Remedy
The IceMaker is
not producing ice
cubes.*
→ The IceMaker is not on. ► Activate the IceMaker.
→ The drawer of the IceMakers is not
connected properly.
► Push the drawer in correctly.
→ The water tank is not pushed in
properly.
► Push the water tank in.*
→ There is not enough water in the
water tank.
► Fill the water tank.*
→ The appliance is not switched on. ► Switch the appliance on.
Customer help
34 * Depending on model and options
Defect Cause Remedy
The internal light
does not come on.
→ The door was open for longer than
15 minutes.
► Interior lighting switches off automatically after
about 15 minutes when the door is open.
→ The LED interior light is faulty or
the lid is damaged.
► Contact Customer Service. (see 10.4 Customer Service)
10.4 Customer Service
First check whether you can rectify the fault yourself
(see 10 Customer help) . If you cannot rectify the problem,
contact Customer Service.
You can find the address in the enclosed brochure “Liebherr-
Service” or at home.liebherr.com/service.
WARNING
Unprofessional repair!
Injuries.
► Have any repairs and action - not expressly specified -
on the appliance and mains cable carried out by service
personnel only. (see9 Maintenance)
► A damaged mains cable may only be replaced by the
manufacturer, the manufacturer’s Customer Service or a
similarly qualified person.
► In the case of appliances with an IEC connector, the
change may be made by the customer.
10.4.1 Contacting Customer Service
Make sure that the following appliance information is avail‐
able:
❑
Appliance name (model and index)
❑
Service no. (Service)
❑
Serial no. (S no.)
► Call up the appliance information via the display.
(see Device information)
-or-
► Refer to the type plate for appliance information.
(see 10.5 Model plate)
► Note down the appliance information.
► Notify customer service: Report errors and the appliance
information.
▷ This will help us to provide you with a faster, more accu‐
rate service.
► Follow further instructions from Customer Service.
10.5 Model plate
The model plate is behind the drawers on the inside of the
appliance.
Fig. 155
(1)
Appliance description (3) Serial no.
(2) Service no.
► Note the data on the model plate.
11 Shutting down
► Empty the appliance.
► Deactivate IceMaker. (see Deactivating IceMaker ) *
► Switch off appliance. (see Switching the appliance off
and on)
► Pull the mains plug out of the socket.
► Remove the IEC socket if required: Pull the IEC socket out
of the appliance plug and move it to the left and right at
the same time.
► Clean appliance. (see 9.5Cleaning the appliance)
► Leave the door open, so that no unpleasant odours arise.
12 Disposal
12.1 Preparing appliance for disposal
Liebherr uses batteries in some of its appli‐
ances. In the EU, for environmental reasons,
legislation obliges the end user to remove
these batteries before disposing of old appli‐
ances. If your appliance contains batteries, a
corresponding notice is attached.
Lamps If you can remove the lamps yourself without
destroying them, also remove these before
disposal.
► Take the appliance out of operation.
► If possible: remove lamps without destroying them.
12.2 Disposing of the appliance in an
environmentally friendly manner
The appliance still contains
valuable materials and must
be disposed of separately from
unsorted municipal waste.
Dispose of batteries separately
from the old appliance. To do
this, you can return the batteries
free of charge to retailers as
well as recycling centres and
collection centres for recyclable
materials.
Lamps Dispose of removed lamps
via the respective collection
systems.
Shutting down
* Depending on model and options 35
For Germany: You can dispose of the appli‐
ance free of charge via the
class 1 collection containers
at the local recycling and
recyclable material collection
centres. When purchasing a new
fridge/freezer, if the sales area
> 400 m
2
, retailers will also take
back the old appliance free of
charge.
WARNING
Leaking coolant and oil!
Fire. The coolant contained in the appliance is eco-friendly,
but also flammable. The oil contained in the appliance
is flammable. Escaping coolant and oil can ignite if the
concentration is high enough and in contact with an
external heat source.
► Do not damage the pipelines of the coolant circuit and
the compressor.
►
Observe the notes on transporting the appliance.
► Transport the appliance without damaging it.
► Dispose of batteries, lamps and the appliance according
to the above specifications.
Disposal
36 * Depending on model and options
Disposal
* Depending on model and options 37
home.liebherr.com/fridge-manuals
Integrated fridge/freezer
Issue date:20250722
Part number index:7088443-00
Liebherr-Hausgeräte GmbH
Memminger Straße 77-79
88416Ochsenhausen
Deutschland
