REVISED BULLETIN
SERVICE PARTS LIST
MILWAUKEE ELECTRIC TOOL CORPORATION
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
BULLETIN NO.
STARTING
SERIAL NO.
WIRING INSTRUCTION
DATE
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
CATALOG NO.
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 14-38-2352 Lens / Screw Assembly (1)
2 --------------- Lens Assembly (1)
3 --------------- M3 x 8mm Pan Hd. T-10 Screw (4)
4 12-20-2352 Service Nameplate (1)
54-06-2365
CORDLESS M18™ LED STICK LIGHT
2352-20
G21A
June 2014
0
00
EXAMPLE:
Component Parts (Small #) Are Included
When Ordering The Assembly (Large #).
FIG. NOTES
3 Care must be used when securing fasteners in tool. To prevent
stripping do not over tighten. It is not recommended to use power
tools, hand tighten only. Torque screws #4 to 5-7 in/lbs (6-8 kg/cm).
Torque screws #10 to 3-4 in/lbs (3.5-4.5 kg/cm).
4 A clean, dry surface is essential for proper performance for
any adhesive system. The area intended for application of
any adhesive label or nameplate must be prepared by
cleaning with isopropyl alcohol. The solvent is to be applied
with a clean, lint free applicator and the surface allowed to
dry before applying the label or nameplate.
2 3 (4x)
1
2
3
4
