SSM 9310WH
EN
SANDWICH MAKER WITH
REMOVABLE PLATES
Translation of the original manual
SSM 9310WH
A
1
2
3
4
5
6
7
- 1 -
06/2023
2023, .
EN Sandwich Maker with Removable Plates
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
• This appliance may be used by children 8 years of age
and older and by persons with physical, sensory or mental
impairments or by inexperienced persons, if they are
properly supervised or have been informed about how to
use of the product in asafe manner and understand the
potential dangers.
• Children must not play with the appliance.
• If the power cord is damaged, have it replaced in
aprofessional service centre in order to prevent
adangerous situation. It is forbidden to use the appliance
with the power cord damaged.
• Cleaning and maintenance performed by the user must
not be performed by children unless they are older than
8years of age and under supervision.
• Children younger than 8 years of age must be kept away
from the appliance and its power cord.
• Surfaces that come into contact withfood should be
cleaned regularly. Follow the instructions in the Cleaning
and Maintenance chapter.
• This appliance is not designed to be controlled using
aprogrammed device, external timer switch or remote
control.
- 2 -
06/2023
2023, .
Caution: Hot surface
The temperature of accessible surfaces may
be higher if the appliance is in operation. Such
surfaces can become hot during use. Do not touch
hot surface. This could cause skin burns. Use the
handles to open and close the appliance.
• Before connecting the appliance to apower socket check that the technical specifications on the appliance'srating label match the electrical voltage
in the socket.
• Connect the appliance only to aproperly grounded socket.
• This product is designed for household use only. Do not use this appliance for commercial purposes.
• Do not use the appliance in industrial surroundings or outdoors.
• Do not use the appliance for any other purposes than those intended.
• Do not place the appliance on or near an electric or gas stove or other sources of heat.
• Do not place the appliance at the edge of aworkbench or on an unstable surface. The appliance must be located on astable and even surface.
• This appliance is supplied with three pairs of removable baking plates. Only use the same pair of baking plates at any one time. Ensure that the
baking plates are properly inserted in the appliance before turning it on.
• When the appliance is connected to the mains socket, the cooking surfaces and the outer casing of the appliance are heated. Do not touch hot
surface. To close and open the top baking plate use the thermally insulated handle and for removing the finished meal use awooden or heat
resistant plastic spatula.
• Allow adequate air circulation around the appliance when in use. Do not place any objects on the heated surface of the appliance.
• Food may catch on fire during the cooking process, therefore check the sandwich maker regularly. If you notice smoke, disconnect the power plug
from the socket and extinguish the fire.
• Always turn off the appliance and disconnect it from the power socket if you leave it without supervision or if you will not be using it and before
changing the baking plates or cleaning it.
• Allow the appliance to fully cool down before changing the baking plates, moving, cleaning or storing it.
• Clean the grilling surfaces after each use, see the chapter Maintenance and cleaning.
• To avoid any injury by electrical shock, do not clean the appliance under running water and do not submerge in water or any liquid.
• Ensure that the power cord does not come into contact with water or moisture or aheated surface.
• Do not disconnect the appliance from the power socket by pulling on the power cord. This could damage the power cord or the power socket.
Disconnect the cord from the power socket by gently pulling the plug of the power cord.
• To avoid the danger of injury by electrical shock, do not repair the appliance yourself or make any adjustments to it. Have all repairs or adjustments
of the appliance performed at an authorised service centre. Tampering with the appliance during the warranty period may void the warranty.
- 3 -
06/2023
2023, .
DESCRIPTION OF THE APPLIANCE
A1 Red indicator light – indicates
the connection to themains
socket
A2 Green indicator light –
indicates heating of the baking
plates
A3 Thermally insulated handles
A4 Lock for easy locking
andunlocking of handles
A5 Removable grilling plates
A6 Removable waffle plates
A7 Removable plates for toasting
sandwiches
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEFORE FIRST USE
• Before first use, remove the appliance and its accessories form the
packaging and remove all promotional labels and tags. Check that
neither the appliance nor any of its components is damaged.
• Wipe the baking surfaces of the removable plates with aslightly damp
cloth and then wipe them dry with adry cloth.
• We recommended you allow the sandwich maker to run empty for
5–7 minutes before first use for each pair of baking plates, so that any
odours present are removed from the plates.
Note:
When first turned on there may be light smoke emitted.
This is due to the heating of internal components and it will
pass in amoment.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
REPLACING THE BAKING PLATES
Unplug the sandwich maker from the power outlet and allow it to cool
before replacing the baking plates.
1. Removing the baking plates: Move lock towards the handle to
release the bottom baking plate and then remove it. In the same way
release and remove the top plate.
2. Inserting the baking plates: Slide the bottom edge of the baking
plate under the left or right hinge. Fold the plate down and push in
towards the casing of the sandwich maker until you hear an audible
click. Now the plate is secured in the correct position by locks. In the
same way attach the top plate. Always use plate of the same type.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
USING THE SANDWICH MAKER
1. Select asuitable type of plate for the type of food that you wish to
prepare and insert it into the sandwich maker. Coat the baking plates
with alittle butter or cooking oil.
2. Connect the sandwich maker to apower socket. Both indicator
lights on the top panel will light up. The red indicator light indicates
connection to apower source. Green indicator light indicates heating
of the baking plates.
3. Close the sandwich maker, for faster heating of the baking plates.
4. Prepare the food you wish to cook before the plates heat up.
5. When the baking plates are heated to the set temperature, the green
indicator light is turned off.
Note:
The heating indicator light turns on and off. This shows that
the set temperature of baking plates is maintained.
6. Open the sandwich maker and place the prepared food on the
bottom plate. Using the handle, close and press the upper baking
plate toward the lower one. Secure the handle with the lock.
Note:
If you insert too much food or pieces that are too large into
the sandwich maker, then it will not be possible to close it.
In such acase it will be necessary to remove some of the
food or to cut the food into smaller pieces. Do not force the
sandwich maker shut, as this may damage it.
7. After 2 to 3 minutes release the lock, open the top plate and remove
the finished meal or continue cooking if necessary. To remove the
meal use awooden or heat-resistant plastic spatula. Do not use
afork, aknife or anything else made of metal. This may damage the
non-stick coating.
8. Before inserting further food into the sandwich maker close it and
wait until the green indicator light turns off.
9. After finishing using the sandwich maker, disconnect it from the
power socket.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLEANING AND MAINTENANCE
• Before cleaning, unplug the power cord from the mains socket and
allow the appliance to cool down.
• Do not use abrasive cleaning agents, solvents, or any substances to
clean any parts of the appliance that could damage the surface of
the appliance. No part of this appliance is intended to be washed in
adishwasher or under running water.
Warning:
To prevent the risk of electric shock, do not submerge
the appliance, plug or power cord in water or any
other liquid.
• Clean the non-stick surface of the baking plates after each use. This
will prevent abuild-up of burnt pieces of food residue. To clean, use
amoist, soft cloth. If some burnt food residue is left on the baking
plates, sprinkle with water and mild dish detergent. Wipe clean
afterwards with aclean, moist cloth.
• The baking plates are easier to clean if lukewarm.
• Wipe outer surface of the sandwich maker with asoft wet cloth and
dry completely off.
Storage
• If you will not be using the appliance for an extended period of
time, unplug the plug from the mains socket, allow the appliance to
cool down and clean it according to the instructions in the chapter
“Cleaning and Maintenance”.
• Before storing, ensure that the appliance and all accessories are
thoroughly clean and dry.
• Store the appliance in adry, clean, and well-ventilated place away
from extreme temperatures and out of the reach of children or pets.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TECHNICAL SPECIFICATIONS
Sandwich Maker with Removable Plates
Rated voltage range ............................................................................. 220−240 V~
Rated frequency ........................................................................................ 50−60 Hz
Rated power input ............................................................................................. 750 W
We reserve the right to change the text and technical specifications.
EN
Sandwich Maker with Removable Plates
User manual
- 4 -
06/2023
2023, .
INSTRUCTIONS AND INFORMATION ON DISPOSING OF USED
PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your
municipality.
DISPOSING OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on the products or accompanying documents
indicates that used electrical and electronic products
should not be disposed of with regular municipal waste.
For proper disposal and recycling, take these products to
designated collection points. Or in some European Union
states or other European countries the products can be
returned to the local retailer when buying an equivalent
new product. Disposing of this product correctly helps save
valuable natural resources and prevents damage to the environment by
improper waste disposal. Ask your local authorities or collection facility for
more details. In accordance with national regulations penalties may be
imposed for the incorrect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic devices, ask your retailer or
supplier for the necessary information.
Disposal in other countries outside the European Union
This symbol is valid in the European Union. If you wish to dispose of this
product, request the necessary information about the correct disposal
method from the local council or from your retailer.
This product complies with all the essential requirements of
the EU directives that apply to it.
FAST ČR, a.s.
U Sanitasu 1621
CZ -251 01 Říčany
www.sencor.eu
