OWNER’S MANUAL
Please read the instruction carefully and keep for future reference.
Information may be updated from time to time so please refer to
the website for the latest version of the manual.
Garbage Disposal
Model: GD 075
Equator Appliances undertakes to the consumer-owner to repair or, at
our option, to replace any part of this product which proves to be
defective in workmanship or material under normal personal, family or
household use, in USA and Canada, for a period of one year from the
date of original purchase. For commercial use, the product is warranted
for a period of 90 Days. During this period, we will provide all labor and
parts necessary to correct such defect, free of charge, if the appliance
has been Installed and operated in accordance with the written
instructions with the appliance. Ready access to the appliance, for
service, is the responsibility of the consumer-owner. Services would be
provided from Monday to Friday between normal business hours.
In no event shall Equator Appliances be liable for incidental or
consequential damages or for damages resulting from external
causes such as abuse, misuse, incorrect voltage or acts of God.
This warranty does not cover service calls which do not involve
defective workmanship or materials covered by this warranty.
Accordingly, diagnosis and repair costs for a service call which
does not involve defective workmanship or materials will be the
responsibility of the consumer-owner.
Warranty
Exclusions
Most work is covered. The defining factor is, has the machine
malfunctioned (Equator Appliances is responsible) or has the
customer omitted or done something to cause the machine to
malfunction (customer is responsible). Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you.
Call: 1-800-776-3538
Email: [email protected]
Web: www.ApplianceDesk.com
Business hours: 9:00 am to 5:00 pm weekdays
For Service:
This warranty is given by:
Equator Appliances
10222 Georgibelle Drive, Suite 200
Houston, Texas 77043-5249
Since it is a responsibility of the consumer-owner to establish
the warranty period by verifying the original purchase date,
Equator Appliances recommends that a receipt, delivery slip or
some other appropriate payment record be kept for that purpose.
This warranty gives you specific legal rights, and you may also
have other rights which vary from State to State.
WARRANTY SERVICE
GENERAL
Chat-AI
1. Scan Chat-AI
Open Smart Phone
Open Camera
Click the Link
2. Register online at ApplianceDesk.com/Warranty
3. Chat-AI is also used to obtain Product Information,
Manuals and Updates
Ensure the power cord of the garbage disposer enters the
enclosure through a watertight fitting or is sealed in place.
Ensure the garbage disposer has a strain relief, independent
of the seal, and which reduces the risk of flexing or movement
of the seal.
Ensure the face of the receptacle is flush with or extends
beyond a nonconductive surrounding surface or extends
at least 0.015 inches (0.38 mm) beyond a conductive
surrounding surface.
Ensure that the strain relief can withstand for 1 minute,
without displacement, a direct pull of 35 lbs. applied to
the cord.
Safety
1
Save these instructions.
Lower Mounting Ring
Dishwasher Inlet
Water Outlet
Water Outlet Ring
Cable Connector
Wire Nuts
Parts Included:
Disposer
Stopper
Sink Flange
Rubber Gasket
Paper Gasket
Metal Gasket
Mounting Ring
1 1/2" Screws
Snap Ring
ss304
Rubber Ring
Water Outler Ring
“L” Tube
Screws
Tools and Materials (not included)
Plumbers putty
Wrench
Use: paste the
wrench holder onto
the inner wall
Shockproof ring
Splash Guard
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
Power Cord
(3 Prong)
2
15-20mm
H
1
2
Loosen the three screws
on the mounting assembly,
get them out about
0.6 - 0.8 inch (15-20mm).
Use a flat head screw to
take out the snap ring (I),
then separate the paper
gasket (E), metal gasket (F),
and mounting ring (G) from
the assembly.
Installation Instructions
H
H
E
F
G
I
I
3
WARNING: Before installation disconnect the power supply.
！
3
Plumbers putty
4
Take out the paper gasket (E)
and put it aside, put the
gasket (D) onto the sink
flange (C), then press it
firmly onto the sink drain
as shown.
Evenly apply 1/2" thick rope
of plumber's putty around
sink flange (C).
Put the disposer on top
of the sink flange (C) to
hold it in place, use a
towel to prevent
scratching the sink.
C
D
C
I
4
5
6
Tighten the three
mounting screws (H)
evenly and firmly
against the flange.
C
E
F
G
I
I
Insert paper gasket (E),
metal gasket (F), and
mounting ring (G).
Press snap ring (I)
firmly in place.
G
H
5
！
Turn disposer onto side and
insert screwdriver into
dishwasher inlet.
Install the rubber ring (K)
onto the tube (L), then
secure the tube to
disposer with screws.
7
8
Stop and read
If you do not need to attach the dishwasher,
Please skip steps 8, 9, 17.
A
K
M
L
N
O
A
6
CAUTION: DISHWASHER CONNECTION ONLY.
Knock out drain plug and
remove plug from inside of
disposer.
9
Turn the garbage disposal
upside down. Remove the
wiring cover.
10
A
7
Install the cable connector
on wiring cover.
Fixed and tightening its
position, make the power
cord pass through the
cable connector.
Pull it out from wiring
holes, proper length.
This disposer requires a
switch (15 amp minimum
rating) with a marked "Off"
position (wired to disconnect
all ungrounded supply
conductors) installed within
sight of the disposer sink
opening, except if using an
air switch or batch feed
accessory or batch
feed disposer.
11
12
NO
WARNING: . Danger of electric shock due to poor grounding
！
8
Push the wiring into the wiring hole.
Do not move the winder board.
Push the wiring into the inter layer
between the cardboard and the
bottom cover.
Fix and lock the wiring cover.
13
a
b
Connect the cable to the
corresponding terminal of
the machine.
a Remove the green ground screw.
b Connect the ground wire with a
lock washer and tighten the
green ground screw.
14
9
！
WARNING: Danger of electric shock due to poor
grounding. Avoid letting the power cord interface touch
water, and prevent excessive bending or moving of the
power cord, causing danger or damage.
Hang disposer by
aligning 3 mounting
tabs with slide-up
ramps on
mounting ring.
Use the wrench (J) to
secure the mounting
ring tightly.
16
15
WARNING: . Falling Hazard
G
A
J
10
！
Place dishwasher tube
into dishwasher Inlet.
Secure with hose clamp.
You may need to trim
hose clamp.
Discharge tube to
ensure proper fit.
Make sure anti-vibration
tailpipe mount is straight.
18
17
A
L
11
Test for leaks
after Installation:
Fill 2/3 of the sink with
tap water, turn on the
disposer and then
release the water.
Check for leaks on
connections spots (1)
and (2) as indicated
on the picture.
19
An accessory can be installed on the garbage disposer which
will automatically turn it on using an air switch.
An Air Switch is a push button installed on the countertop or
sink to control the operation of the garbage disposer.
To order contact Customer Service.
12
Air Switch Kit
(GDAS-01)
Top View
Side View
1. Air Switch
2. Air Tube
3. Power Box
4. Power Cord
3
1
4
2
Before using the garbage disposer, ensure that it has been
installed correctly under the sink with the required
electrical connection.
Use the garbage disposer to discard only organic items, such as
fruit and vegetable debris:
1. Turn on the faucet and let the water run in the sink.
2. Press the switch for the garbage disposer.
3. Put the food debris into the garbage disposer opening, a small
quantity at a time.
4. After a few minutes, when the debris has been cleared, turn off
the switch and then the faucet.
Do Not put the following types of items through the
garbage disposer:
Glass, metal
Paper, plastic
Large bones, thick chunks of food
Operation
DO NOT PUT YOUR HANDS INTO THE GARBAGE
DISPOSER OPENING.
If a utensil has accidentally gone into the garbage disposer
opening or if the drain is clogged, turn off the power and call a
technician to fix the problem.
When not in use, place a sink strainer over the garbage
disposer opening.
13
WARNING: This product contains chemicals known to the State of
California to cause cancer and birth defects or other reproductive harm.
Technical Specifications
Model
Grinding Chamber Capacity
Electrical
RPM
Horse Power
Net Weight (lbs)
Product Dimensions (HxWxD)
GD 075
1 Quart (1000 ml)
120V / 60Hz
1700 RPM
3/4 HP
17.2
12.2 x 7.1 x 7.1 (inch)
California Proposition 65
14
360° Clean Rinse: Every time the disposer is used, water
needs to be run through it. The grinding disc utilizes centrifugal
force and the combination of water to create a scrubbing action
for self-cleaning.
Auto Shut off: The disposer automatically shuts off after
running for 25 minutes to prevent it from being left on
accidentally.
Manual Reset: The reset button is located at the bottom of the
disposer and is red in color.
