BRUSHLESS
DUAL PORT BACKPACK BLOWER
80V
LITHIUM
®
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s Date Code in the back of
the manual near the assembly diagram (or month and year of purchase if product has no number). Keep
this manual and the receipt in a safe and dry place for future reference. 25i
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1‑800‑444‑3353 as soon as possible.
Copyright
©
2025 by Harbor Freight Tools
®
. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-800-444-3353. Item 70822
SaFety OperatiOn MaintenanceSetup
table of contents
Safety ......................................................... 2
Specifications ............................................. 6
Setup .......................................................... 7
Operation ................................................... 10
Maintenance .............................................. 12
Parts List and Diagram .............................. 14
Warranty .................................................... 16
®
WarninG SyMBOLS anD DeFinitiOnS
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
iMpOrtant SaFety inFOrMatiOn
General tool Safety Warnings
read all safety warnings, instructions, illustrations and specifications provided with this tool.
Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “tool” in the warnings refers to your mains-operated (corded) tool or battery-operated (cordless) tool.
1. Work area safety
a. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b. Do not operate tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Tools create
sparks which may ignite the dust or fumes.
c. Keep children and bystanders away
while operating a tool. Distractions
can cause you to lose control.
Page 3For technical questions, please call 1-800-444-3353.Item 70822
SaFetyOperatiOnMaintenance Setup
2. electrical safety
a. tool plugs must match the outlet. never
modify the plug in any way. Do not use
any adapter plugs with earthed (grounded)
tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
b. avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric shock
if your body is earthed or grounded.
c. Do not expose tools to rain or wet
conditions. Water entering a tool will
increase the risk of electric shock.
d. Do not abuse the cord. never use the cord
for carrying, pulling or unplugging the tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e. When operating a tool outdoors, use
an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor
use reduces the risk of electric shock.
f. if operating a tool in a damp location is
unavoidable, use a ground fault circuit
interrupter (GFci) protected supply. Use of
a GFCI reduces the risk of electric shock.
3. personal safety
a. Stay alert, watch what you are doing and use
common sense when operating a tool. Do not
use a tool while you are tired or under the
influence of drugs, alcohol or medication.
A moment of inattention while operating
tools may result in serious personal injury.
b. use personal protective equipment. always
wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c. prevent unintentional starting. ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying tools with
your finger on the switch or energizing tools
that have the switch on invites accidents.
d. remove any adjusting key or wrench
before turning the tool on. A wrench
or a key left attached to a rotating part of
the tool may result in personal injury.
e. Do not overreach. Keep proper footing and
balance at all times. This enables better
control of the tool in unexpected situations.
f. Dress properly. Do not wear loose clothing
or jewelry. Keep your hair, clothing
and gloves away from moving parts.
Loose clothes, jewelry or long hair
can be caught in moving parts.
g. if devices are provided for the connection
of dust extraction and collection
facilities, ensure these are connected
and properly used. Use of dust collection
can reduce dust-related hazards.
h. Do not let familiarity gained from frequent
use of tools allow you to become
complacent and ignore tool safety
principles. A careless action can cause
severe injury within a fraction of a second.
i. Only use safety equipment that has been
approved by an appropriate standards agency.
Unapproved safety equipment may not provide
adequate protection. Eye protection must be
ANSI‑approved and breathing protection
must be NIOSH‑approved for the
specific hazards in the work area.
j. Do not leave the tool unattended when the
Battery Pack is connected. Turn off the tool,
and remove the Battery Pack before leaving.
k. This product is not a toy.
Keep it out of reach of children.
l. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
m. The warnings, precautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions and situations
that may occur. It must be understood by the
operator that common sense and caution are
factors which cannot be built into this product,
but must be supplied by the operator.
4. tool use and care
a. Do not force the tool. use the correct
tool for your application. The correct
tool will do the job better and safer at
the rate for which it was designed.
b. Do not use the tool if the switch does
not turn it on and off. Any tool that
cannot be controlled with the switch is
dangerous and must be repaired.
c. Disconnect the plug from the power
source and/or remove the battery pack, if
detachable, from the tool before making
any adjustments, changing accessories, or
storing tools. Such preventive safety measures
reduce the risk of starting the tool accidentally.
d. Store idle tools out of the reach of children
and do not allow persons unfamiliar
with the tool or these instructions to
operate the tool. Tools are dangerous
in the hands of untrained users.
Page 4 For technical questions, please call 1-800-444-3353. Item 70822
SaFety OperatiOn MaintenanceSetup
e. Maintain tools and accessories. check for
misalignment or binding of moving parts,
breakage of parts and any other condition that
may affect the tool’s operation. if damaged,
have the tool repaired before use. Many
accidents are caused by poorly maintained tools.
f. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g. use the tool, accessories and tool bits etc.
in accordance with these instructions, taking
into account the working conditions and
the work to be performed. Use of the tool
for operations different from those intended
could result in a hazardous situation.
h. Keep handles and grasping surfaces
dry, clean and free from oil and grease.
Slippery handles and grasping surfaces
do not allow for safe handling and control
of the tool in unexpected situations.
5. Service
a. Have your tool serviced by a qualified
repair person using only identical
replacement parts. This will ensure that
the safety of the tool is maintained.
b. never service damaged Battery packs.
Service of BATTERY packs should
only be performed by the manufacturer
or authorized service providers.
c. Maintain labels and nameplates on the tool.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
6. Garden blower safety warnings
a. Do not use the garden blower in bad
weather conditions, especially when
there is a risk of lightning. This decreases
the risk of being struck by lightning.
b. Wear eye protection and ear protection.
Adequate protective equipment will
reduce the risk of personal injury.
c. While operating the garden blower, always
wear non-slip and protective footwear.
Do not operate the garden blower when
barefoot or wearing open sandals. This
reduces the risk of injury to the feet.
d. Do not wear loose fitting clothing or articles
such as scarves, strings, chains, ties, etc.,
that could get drawn into the air inlets.
tie back or cover long hair to make sure
it does not get drawn into the air inlets. If
any of these items are drawn into the air inlets,
it can increase the risk of personal injury.
e. Keep bystanders away while operating
the garden blower Thrown debris can
increase the risk of personal injury.
f. never point the blower nozzle in the direction
of people or pets or in the direction of
windows. use extra caution when blowing
debris near solid objects, such as trees,
automobiles and walls that can cause debris
to ricochet. Thrown objects can damage
properly and increase the risk of personal injury.
g. Do not use the garden blower to blow
anything that is burning or smoking, such
as cigarettes, matches or hot ashes. These
ignition sources may increase the risk of fire.
h. Do not touch the fan while still in motion.
turn off the garden blower, wait until
the fan stops and unplug the garden
blower, before removing any part that
may give access to the fan. This reduces
the risk of injury from moving parts.
i. When clearing jammed material or
servicing the garden blower, make sure
the power switch is off and the power
cord is disconnected. Unexpected
actuation of the garden blower while
cleaning Jammed material/ or servicing
may increase the risk of personal injury.
7. Battery tool use and care
a. prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to battery pack, picking up or
carrying the tool. Carrying the tool with your
finger on the switch or energizing tool that
have the switch on invites accidents.
b. Disconnect the battery pack from the
tool before making any adjustments,
changing accessories, or storing tool.
Such preventive safety measures reduce
the risk of starting the tool accidentally.
c. recharge only with the charger specified by
the manufacturer. A charger that is suitable
for one type of battery pack may create a risk
of fire when used with another battery pack.
d. use tools only with specifically designated
battery packs. Use of any other battery
packs may create a risk of injury and fire.
e. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from
one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
f. under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
Page 5For technical questions, please call 1-800-444-3353.Item 70822
SaFetyOperatiOnMaintenance Setup
g. Do not use a battery pack or tool that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior
resulting in fire, explosion or risk of injury.
h. Do not expose a battery pack or tool to fire
or excessive temperature. Exposure to fire or
temperature above 140°F may cause explosion.
i. Follow all charging instructions and do
not charge the battery pack or tool outside
of the temperature range specified in the
instructions. Charging improperly or at
temperatures outside of the specified range may
damage the battery and increase the risk of fire.
j. Have servicing performed by a qualified
repair person using only identical
replacement parts. This will ensure that
the safety of the product is maintained.
k. Do not modify or attempt to repair the tool
or the battery pack except as indicated
in the instructions for use and care.
l. The battery Charger gets hot during
use. The Charger’s heat can build up
to unsafe levels and create a fire
hazard if it does not receive adequate
ventilation, due to an electrical fault, or if it is
used in a hot environment. Do not place the
Charger on a flammable surface. Do not obstruct
any vents on the Charger. especially avoid
placing the charger on carpets and rugs; they
are not only flammable, but they also obstruct
vents under the charger. Place the Charger on
a stable, solid, nonflammable surface (such as a
stable metal workbench or concrete floor) at least
1 foot away from all flammable objects, such as
drapes or walls. Keep a fire extinguisher and a
smoke detector in the area. Frequently monitor
the Charger and Battery Pack while charging.
8. Lithium Battery Safety Warnings
LitHiuM BatterieS StOre
a LarGe aMOunt OF enerGy anD
WiLL Vent Fire Or eXpLODe
iF MiStreateD:
a. Keep Battery pack dry.
B. DO nOt DO any OF tHe FOLLOWinG
tO tHe Battery pacK:
• Open,
• Drop,
• Short-circuit,
• puncture,
• incinerate, or
• expose to temperatures greater than 140°F.
c. Charge Battery Pack only according
to its Charger’s instructions.
d. Inspect Battery Pack before every use;
do not use or charge if damaged.
Grounding
tO preVent eLectric SHOcK anD DeatH FrOM incOrrect GrOunDinG:
check with a qualified electrician if you are in doubt as to whether the outlet is properly
grounded. Do not modify the power cord plug provided with the charger. Do not use the charger
if the power cord or plug is damaged. if damaged, have it repaired by a service facility before
use. if the plug will not fit the outlet, have a proper outlet installed by a qualified electrician.
extension cords
note: Extension cords must not be used with this item’s Charger.
Page 6 For technical questions, please call 1-800-444-3353. Item 70822
SaFety OperatiOn MaintenanceSetup
Symbology
V
Volts
Direct Current
a
Amperes
n
0
xxxx/min.
No Load Revolutions per Minute (RPM)
WARNING marking concerning Risk
of Eye Injury. Wear ANSI‑approved
safety goggles with side shields.
Read the manual before
set‑up and/or use.
WARNING marking
concerning Risk of Fire.
Do not cover Charger
ventilation ducts.
Charge on fireproof surface only.
WARNING marking concerning
Risk of Electric Shock.
Properly connect Charger’s power
cord to appropriate outlet.
WARNING marking concerning
Risk of Explosion.
Do not puncture, short, or open
battery packs and do not charge
damaged battery packs.
WARNING marking concerning
Risk of Hearing Loss.
Wear hearing protection.
Specifications
Electrical Rating 72V DC, 80V Max
Battery Type Atlas 40/80V Li‑Ion
Charger Type Atlas 40/80V Li‑ion
Sound Rating 70.3 dBA
For household use only.
Page 7For technical questions, please call 1-800-444-3353.Item 70822
SaFetyOperatiOnMaintenance Setup
Setup - Before use:
read the entire iMpOrtant SaFety inFOrMatiOn section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
note: For additional information regarding the parts listed in the
following pages, refer to Parts List and Diagram on page 15.
assembly
attaching Handle
1. Slide Handle onto Upper Tube.
Handle
upper
tube
2. Secure Handle to Upper Tube with
Handle Bolt and Handle Knob.
Handle Bolt
(on other side)
Handle
Knob
attaching Flex tube
1. Loosen Hose Clamps and install
them over ends of Flex Tube.
2. Slide Flex Tube over Upper Tube.
3. Slide other end over Elbow, and
tighten Hose Clamp Screws.
4. Secure Control Cable to Mounting Clip.
upper
tube
control cable
Mounting
clip
Hose
clamps
Flex tube
elbow
Page 8 For technical questions, please call 1-800-444-3353. Item 70822
SaFety OperatiOn MaintenanceSetup
attaching Blower tube and nozzle
1. Slide Blower Tube over Upper Tube and line
up Slot with Tab, then rotate Blower Tube
clockwise until Tab is securely locked into Slot.
Blower
tube
upper
tube
Slot
tab
2. Slide remaining Blower Tube over end of
Blower Tube, as needed, and line up Slot
with Tab, then rotate Blower Tube clockwise
until Tab is securely locked into Slot.
Blower
tubes
3. Slide Nozzle over Blower Tube and line up Slot
with Tab, then rotate Blower Tube clockwise
until Tab is securely locked into Slot.
nozzle
charging
Charge batteries before using this tool. Follow instructions included with battery charger (sold separately).
Page 9For technical questions, please call 1-800-444-3353.Item 70822
SaFetyOperatiOnMaintenance Setup
Functions
trigger
controls
Blower tubes
nozzle
Battery
compartment
Handle
BATTERY LEVEL
LEFT RIGHT
Shoulder
Straps
Waist
Strap
Page 10 For technical questions, please call 1-800-444-3353. Item 70822
SaFety OperatiOn MaintenanceSetup
Operating instructions
read the entire iMpOrtant SaFety inFOrMatiOn section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
tO preVent SeriOuS inJury FrOM FLyinG DeBriS:
Wear long pants, long sleeves and protective footwear. Wear anSi-approved
safety goggles, dust mask, hearing protectors, and gloves.
installing and removing Battery packs
1. Make sure the Trigger is in the OFF position.
2. To install: Slide Battery Packs into
Battery Compartment until they click into place.
3. To remove: Press Battery Packs′ Release
Buttons and pull Battery Packs out of slot.
Page 11For technical questions, please call 1-800-444-3353.Item 70822
SaFetyOperatiOnMaintenance Setup
General instructions for use
tO aVOiD SeriOuS inJury anD prOperty DaMaGe:
inspect the area before using the Blower. remove all hard objects from work area.
Do not blow debris in the direction of people, animals or property.
cautiOn! tO preVent inJury: Do not
wear multiple harnesses or anything that would
interfere with removal of the harness.
cautiOn! tO preVent inJury: Do not
stand on ladder or unstable support.
1. Strap the Blower to your back.
a. Put your arms though the Shoulder Straps
so the pads rest on your shoulders.
b. Pull Chest Straps across chest and
buckle together to secure.
c. Adjust Shoulder and Chest Straps as needed.
d. Pull Waist Strap around waist and buckle
together to secure, adjust Waist Strap as needed.
Shoulder
Strap
chest
Strap
Buckle
2. Loosen Handle Knob and adjust Handle
position as needed. Tighten Handle Knob.
Handle
Knob
Handle
note: Rake or sweep to loosen debris if necessary.
3. Hold Blower with the Nozzle close to the ground.
4. Press Trigger or push Trigger Lock
forward to start the Blower.
5. Adjust the position of the Trigger or Trigger Lock
to adjust the speed of the Blower.
6. Press and hold Turbo Button to temporarily
increase air speed. Release Button when done.
7. Sweep from side to side.
8. Release Trigger or rotate Trigger Lock
backward to turn Blower off.
trigger
Lock
turbo
Button
trigger
9. When finished, to prevent accidents:
• Remove battery packs.
• Wipe external surfaces of the appliance
with clean cloth. Store in an indoor
dry area out of reach of children.
Page 12 For technical questions, please call 1-800-444-3353. Item 70822
SaFety OperatiOn MaintenanceSetup
user-Maintenance and Storage
procedures not specifically explained in this manual must
be performed only by a qualified technician.
tO preVent SeriOuS inJury FrOM acciDentaL OperatiOn:
Make sure that the trigger is in the off-position and remove its Battery
pack before performing any procedure in this section.
tO preVent SeriOuS inJury FrOM appLiance FaiLure:
Do not use damaged equipment. if abnormal noise or vibration
occurs, have the problem corrected before further use.
cleaning, Maintenance, and Lubrication
1. BeFOre eacH uSe, inspect the
general condition of the appliance. Check for:
• leaking, swollen, or cracked battery pack,
• loose hardware,
• misalignment or binding of moving parts,
• cracked or broken parts,
• damaged electrical wiring, and
• any other condition that may
affect its safe operation.
2. aFter uSe, wipe external surfaces
of the appliance with clean cloth.
3. Li‑Ion BATTERY MUST BE RECYCLED OR
DISPOSED OF PROPERLY.
Do not short, incinerate or open battery.
4. All parts are permanently lubricated.
Do not use additional lubrication.
5. Disconnect battery pack and store battery pack,
charger, and tool in dry, indoor area out of
reach of children and away from metal objects
(i.e., paperclips, coins) to prevent shorting.
ambient temperate range
Tool Operation and Storage 32°F (0°C) ‑ 113°F (45°C)
Page 13For technical questions, please call 1-800-444-3353.Item 70822
SaFetyOperatiOnMaintenance Setup
troubleshooting
problem possible causes Likely Solutions
Tool will not start. 1. Battery Packw not properly
connected.
2. Battery Pack not properly
charged.
3. Battery Pack burnt‑out.
4. Internal damage or wear.
(Trigger, for example.)
1. Remove Battery Pack, make sure there are no
obstructions, reinsert the Battery Pack according
to its shape (it should only fit one way), and press
firmly until the Battery Pack locks in place.
2. Make sure Charger is connected and
operating properly. Give enough time for
Battery Pack to recharge properly.
3. Dispose of old Battery Pack
properly or recycle. Replace Battery Pack.
4. Have technician service tool.
Tool operates slowly. 1. Forcing tool to work too fast.
2. Battery Pack wearing out.
1. Allow tool to work at its own rate.
2. Dispose of old Battery Pack
properly or recycle. Replace Battery Pack.
Excessive noise
or rattling.
Internal damage or wear.
(Bearings, for example.)
Have technician service tool.
Overheating. 1. Forcing tool to work too fast.
2. Blocked motor housing vents.
1. Allow tool to work at its own rate.
2. Wear ANSI‑approved safety goggles and
NIOSH‑approved dust mask/respirator while
blowing dust out of motor using compressed air.
Follow all safety precautions whenever diagnosing or servicing the tool.
Disconnect Battery pack and charger power supply before service.
pLeaSe reaD tHe FOLLOWinG careFuLLy
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Page 14 For technical questions, please call 1-800-444-3353. Item 70822
SaFety OperatiOn MaintenanceSetup
parts List and Diagram
parts List and Diagram
part Description Qty
1‑1 Harness 1
1‑2 Screw 5
1‑3 Nut 2
1‑4 Screw 2
2‑1 Turbo Button 1
2‑2 Spring 1
2‑3 Left Handle 1
2‑4 Light Panel 1
2‑5 Trigger Lock 1
2‑6 Washer 1
2‑7 O‑Ring 1
2‑8 Fixed Seat 1
2‑9 Speed Control Switch 1
2‑10 Right Handle 1
2‑11 Screw 9
2‑12 Wire Harness Assembly 1
2‑13 Handle Knob 1
2‑14 Handle Bolt 1
2‑15 Trigger 1
2‑16 Wire Retaining Plate 1
2‑17 Micro Switch 1
3‑1 Nozzle 1
3‑2 Lower Tube 2
3‑3 Upper Tube 1
3‑4 Sealing Strip 1
3‑5 Connecting Ring 1
3‑6 Hose Clamp 1
3‑7 Hose Clamp Screw 2
3‑8 Nut 2
3‑9 Flex Tube 1
3‑10 Hose Clamp 1
3‑11 Elbow 1
part Description Qty
3‑12 O‑ring 1
4‑1 Screw 46
4‑2 Rear Cover 1
4‑3 Nut 4
4‑4 Spring Cover 2
4‑5 Spring 4
4‑6 Spring Base 2
4‑7 Cover 1
4‑8 Front Housing 1
4‑9 Wire Retaining Plate 1
4‑10 PCBA 1
4‑11 U‑Clip 1
4‑12 Muffler 1
4‑13 Muffler 1
4‑14 Battery Compartment 1
4‑15 Male Terminal 2
4‑16 Pressplate 2
4‑17 Front Cover 1
5‑1 Ducting Rear End 1
5‑2 Motor 1
5‑3 Shock Pad 4
5‑4 Ducting 1
5‑5 Screw 3
5‑6 Impeller 1
5‑7 Flange Nut 1
6‑1 Backplate 1
6‑2 Grommet 4
6‑3 Gasket 4
6‑4 Bolt 4
6‑5 Shock Pad 2
6‑6 Base 1
6‑7 Screw 4
record product’s Date code Here:
note: If product has no Date Code, record month and year of purchase instead.
note: Some parts are listed and shown for illustration purposes only, and are not available individually as
replacement parts. Specify UPC 193175578556 when ordering parts.
Page 15For technical questions, please call 1-800-444-3353.Item 70822
SaFetyOperatiOnMaintenance Setup
parts List and Diagram
2-7
2-6
2-5
2-4
2-3
2-1
2-2
2-17
2-16
2-15
2-14
2-13
1-4
1-3
1-2
1-1
6-4
6-3
6-2
6-1
6-5
6-6
6-7
4-1
4-2
4-3
4-4
4-5
4-6
4-1
4-7
4-8
4-11
4-10
4-9
4-1
4-12
4-13
4-1
4-14
4-15
4-16
4-1
4-17
5-7
5-6
5-5
5-4
5-2
5-1
5-3
3-4
3-3
3-5
3-6
3-8
3-9
3-7
3-10
3-11
3-12
3-2
3-1
2-12
2-11
2-10
2-9
2-8
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
26677 agoura road • calabasas, ca 91302 • 1-800-444-3353
®
Owner's Manual & Safety Instructions
Save This Manual Keep th is manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product's serial number
in
the back
of
the manual near the assembly diagram (or month and year of purchase if product has no number). Keep
this manual and the receipt
in
a safe and dry place for future reference.
209
ATLAS
4DVFIND
BDV
CHRRCiERS
Charger
Rapid
Charger
@
Visit
our
website
at: http://www.harborfreight.com
Email
our
technical
support
at:
When
unpacking,
make
sure
that
the
product
is
intact
and
undamaged.
If
any
parts
are
missing
or
broken,
please
call
1-888-866-5797
as
soon
as
possible.
Copyright©
2020
by
Harbor
Freight
Too
岭
All
rights
reserved
No
portion
of
this
manual
or
any
artwork
contained
herein
may
be
reproduced
in
any
shape
or
form
without
the
express
written
consent
of
Harbor
Freight
Tools.
Diagrams
within
this
manual
may
not
be
drawn
proportionally.
Due
to
continuing
improvements,
actual
product
may
differ
slightly
from
the
product
described
herein
Tools
require
□
for
assembly
and
service
may
not
be
included
£WARNING
Read this material before using this product
Failure to do so can result
in
serious injury.
SAVE THIS MANUAL
