EN
MOBILE AIR CONDITIONER WI-FI
Translation of the original manual
SAC MT9078CH
SAC MT9079CH
SAC MT9078CH
SAC MT9079CH
A
1
2
3
4
5
6
7
8
9
11
10
12
B
1 2 3 4
5 6
7 8
C
1 2 6 73 54
1211109
8
D
1
2
3
4
5
6
7
9
10
11
8
E
45c m
45c m
45c m
F1 F2
G1 G2
H1 H2
H3 H4
1
H5
H6
- 1 -
Revision 11/2023
Copyright © 2023, Fast ČR, a.s.
EN Mobile air conditioner Wi-Fi
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
This symbol indicates that not adhering to
instructions may result in death or serious injuries.
WARNING:
To prevent the death or injury of the user or other
persons or damage to property, the following
instructions must be adhered to. Incorrect use as
aresult of not adhering to instructions may cause
death, injuries or damage.
• This appliance may be used by children 8 years of
age and older and by persons with physical or mental
impairments or by inexperienced persons, if they are
properly supervised or have been informed about how
to use the product in asafe manner and understand the
potential dangers. Cleaning and maintenance performed
by the user must not be performed by unsupervised
children. Children must not play with the appliance.
• If the power cord is damaged, it must be replaced by an
authorised service centre or by another similarly qualified
person, this will prevent the creation of adangerous
situation. It is forbidden to use the appliance if it has
adamaged power cord.
- 2 -
Revision 11/2023
Copyright © 2023, Fast ČR, a.s.
• The appliance must be stored in amanner that prevents its
mechanical damage.
• The appliance must be stored in awell-ventilated location,
where the dimensions of the room correspond to the
dimensions specified for its operation.
• The appliance must be stored in aroom where an
open flame is not continuously in use (e.g. running gas
appliance) or where there are sources of ignition (e.g.
running electrical heating element).
• Before connecting the appliance to apower socket, check
that the rated voltage on its rating label matches the
electrical voltage in the power socket.
• Connect the appliance only to aproperly grounded socket.
• The power socket must be freely accessible so that it is
possible to quickly disconnect the power cord from the
power source if necessary.
• The appliance is designed for use at home, in offices and
similar types of areas. Do not use it in very dusty or humid
rooms such as laundries or bathrooms, in areas where
chemical or explosive substances are stored, in industrial
surroundings or outdoors.
• Do not place the appliance in the vicinity of an open flame
or appliances that are sources of heat.
• Do not place the appliance on unstable surfaces such as
carpets with very long and thick fibres.
• The appliance may only be used on adry, stable, smooth
and horizontal surface.
• The appliance is equipped with travel wheels, so pay
extra attention when handling it so that it does not fall
- 3 -
Revision 11/2023
Copyright © 2023, Fast ČR, a.s.
down stairs or travel down from sloped areas. If necessary
secure the wheels using the stoppers.
• Only use original parts to assemble the appliance. Before
starting to assemble the appliance, make sure that it is
turned off and disconnected from the power socket.
• Prior to connecting the appliance to apower socket, make
sure that the appliance is correctly assembled according
to the instructions in this user’smanual.
• Do not touch the appliance with wet or damp hands. This
applies especially when it is connected to apower socket.
• Do not expose the appliance to dripping or spraying water
or submerge it in water or another liquid.
• Do not cover or insert anything into the air inlet or air outlet
openings. Otherwise, this could damage the appliance.
• During operation there needs to be sufficient space for air
circulation of at least 45 cm on all sides of the appliance.
• Do not expose yourself to acold air current for along time.
This could have anegative effect on your health.
• To turn the appliance on or off, always use the appropriate
buttons on the control panel or the remote control. Do not
turn off the appliance by disconnecting the power cord
from the power socket.
• Always turn off the appliance and disconnect it from the
power socket when leaving it without supervision, when
not using it and before moving, disassembling or cleaning
it.
• Do not attempt to remove the outer case of the appliance.
- 4 -
Revision 11/2023
Copyright © 2023, Fast ČR, a.s.
• Disconnect the appliance from the power socket by pulling
on the plug, never pulling on the power cord. Otherwise,
this could damage the power cord or the socket.
• In the event that the power cord or power plug are
damaged in any way, do not use the appliance.
• Store the appliance in avertical position. It may be
transported in avertical position or tilted on the sided. If
you have already used the appliance, check that all the
condensate has been drained. After transporting it, wait at
least 1 hour before using the appliance.
• Do not use the appliance if it is not working correctly, if
it has been damaged or has been submerged in water.
To avoid ahazardous situation arising, do not repair the
appliance yourself or modify it in any way. Have all
repairs performed at an authorised service centre. By
tampering with the appliance, you risk voiding your legal
rights arising from unsatisfactory performance or quality
warranty.
• Installation must be performed in accordance with the
installation instructions. Incorrect installation may result in
awater leak, injury by electrical shock or fire.
• To prevent the risk of fire or injury by electrical shock, do
not use this appliance with atimer or any another similar
device that could spontaneously start this appliance.
• The appliance must be installed in accordance with
national electrical codes.
• Only use this product for the purposes that are described
in this user’smanual. Otherwise, this may result in
damage or excessive noise and vibrations.
- 5 -
Revision 11/2023
Copyright © 2023, Fast ČR, a.s.
• Use only the accessories and components that are
supplied together with the appliance and the tools
explicitly intended for its installation. The use of
nonstandard parts and accessories may result in awater
leak, injury by electrical shock, fire, injury or damage to
property.
• DO NOT ADJUST the length of the power cord of the unit
and do not use an extension cord for its power supply.
• DO NOT CONNECT the unit to apower socket to which
other electrical appliances are already connected. The
incorrect selection of an electrical power supply may result
in afire or injury by electrical shock.
• Do not cover the cable with acarpet. Do not place carpets,
fillets or any other floor coverings on the power cord. Do
not locate the cable underneath furniture or appliances.
Lead the cable where nothing will ride over it and where
nobody can trip over it. If this occurs, immediately
disconnect the unit from the power socket.
• In the event that the unit is tipped over during use,
turn it off and immediately disconnect it from the main
power supply. Visually check that the unit has not been
damaged in any way. In the event of any doubts that the
unit has been damaged in any way, seek assistance from
atechnician or customer service.
• The power supply must be disconnected during athunder
storm to prevent damage to the appliance in the event of
alightning strike.
• Disconnect the power supply to the appliance if it makes
astrange noise or if an odour or smoke is emitted.
- 6 -
Revision 11/2023
Copyright © 2023, Fast ČR, a.s.
Read this user´smanual.
Warning:
Fire hazard.
SPECIFIC INFORMATION FOR APPLIANCES USING REFRIGERANT GAS R290
• Carefully study any warnings.
• For defrosting and cleaning, do not use any other tools than those recommended by the manufacturer.
• This appliance must be located in an environment that has no continuously running fire sources (for example an open fire, agas appliance or
electrical appliances).
• Do not perform any drilling and do not burn it.
• Refrigerant gases may be odourless.
• This appliance must be located in rooms with an area greater than 14 m
2
.
• This appliance contains approx. 290 g of refrigerant gas R290.
• R290 is arefrigerant gas that meets European environmental protection directives. Do not make holes or drill into any part of the cooling circuit.
• The room in which this appliance is installed, operated or stored must prevent the accumulation of such leaked refrigerants, that could be the cause
of explosion or fire as aresult of the refrigerant igniting following the start-up of electrical heaters, cookers or other sources of ignition.
• The appliance must be stored in such amanner that its mechanical damage is prevented.
• Persons working with or repairing cooling circuits must have appropriate authorisation issued by an authorised institution that certifies this
person’scompetence to work with refrigerants in accordance with the specific assessment of the association for this sector.
• Maintenance tasks must be performed solely on the basis of the recommendations of this appliance’smanufacturer. Maintenance and repair
tasks that required the contribution of other qualified expert personnel may only be performed under the supervision of specialised experts in the
flammable refrigerants sector.
• Check the rating label for the type of refrigerant gas used in your appliance.
• Do not cover the vents.
• Follow the national gas regulations.
- 7 -
Revision 11/2023
Copyright © 2023, Fast ČR, a.s.
Thank you for purchasing aSENCOR brand product and we hope that
you will be happy with it.
Prior to using this appliance, please read the user‘smanual thoroughly,
even in cases, when one has already familiarised themselves with
previous use of similar types of appliances. Only use the appliance in the
manner described in this user’smanual. Keep this user‘smanual in asafe
place where it can be easily retrieved for future use.
We recommend saving the original cardboard box, packaging material,
purchase receipt and responsibility statement of the vendor or warranty
card for at least the duration of the legal liability for unsatisfactory
performance or quality. In the event of transportation, we recommend that
you pack the appliance in the original box from the manufacturer.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE APPLIANCE
A1 Control panel
A2 Handles (located on both
sides)
A3 Castors
A4 Air outlet cover
A5 Remote control sensor
A6 Upper protective grille of air
inlet with filter
A7 Air outlet for connecting
aflexible hose
A8 Power cord plug holder
A9 Power cord
A10 Top drain outlet
A11 Bottom protective grille of air
inlet with filter
A12 Bottom drain outlet
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF ACCESSORIES
B1 Adapter for connection to air
outlet
B2 Flexible air exhaust hose
B3 Window connection adapter
B4 Window insert
B5 Remote control
B6 Drain hose
B7 Textile window seal kit
B8 Velcro
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE CONTROL PANEL
C1 TIMER button for setting the
timer
C2 FAN SPEED button for setting
the speed
C3 – button
C4 Numeric display
C5 + button
C6 MODE button for selecting an
operating mode
C7 ON/OFF button for turning
on/off
C8 Wi-Fi indicator
C9 Timer indicator
C10 Fan speed indicators (high/
medium/low/auto)
C11 Operating mode indicators
(cooling/fan/dehumidification/
heating)
C12 Sleep mode indicator
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
REMOTE CONTROL
D1 Display
D2 On/Off button
D3 button
D4 Timer button
D5 Operating mode button
D6 button
D7 Sleep mode button
D8 Fan speed button
D9 TURBO function button
D10 On/Off button for air outlet
cover movement
D11 Temperature unit change
button
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTALLATION
Location of the mobile air conditioner
Remove the mobile air conditioner from the packaging and make sure you
have removed all parts and accessories. We recommend that two adults
remove the air conditioner from the packaging.
Locate the mobile air conditioner on an even, dry and stable surface and
within reach of agrounded power socket. Do not locate it on unstable or
inclined surface from which the mobile air conditioner could slide, fall,
become damaged or cause injury.
The mobile air conditioner must be located so that it is not exposed to the
direct sunshine.
Make sure there are no heat sources (e.g., heating, portable heaters, stove,
etc.) near where the mobile air conditioner will be located.
For easier handling, the mobile air conditioner is equipped with castors.
Do not use the castors when you need to move the air conditioner over
carpets or similar surfaces. Avoid riding over objects.
To achieve optimal efficiency, maintain adistance of at least 45cm from
the wall or other obstacles – see the figure E.
Locate the mobile air conditioner well away from curtains, drapes, or
blinds.
Ensure the flexible hose does not touch any objects.
Note:
Do not use the mobile air conditioner to cool aroom where
computer servers, etc. are located. Installation, adjustment,
maintenance and repairs must only be performed by
aqualified person.
Installing the flexible hose on to the mobile air conditioner
The flexible hose must be connected to the mobile air conditioner and
installed into awindow in accordance with the operating modes that
you wish to set. Install the flexible hose when you wish to select the
operating modes: cooling, heating, dehumidification, or sleep mode. It
is not necessary to install the flexible hose when you wish to select the
fan mode.
1. Extend the flexible hose to the required length.
2. Attach the adapter for connection to air outlet to one end of the
flexible hose and screw counter clockwise. Attach the window
connection adapter to the other end of the flexible hose and screw
counter clockwise – see the figure F1.
3. Place the flexible hose above the air outlet and move it downwards
to fix it – see the figure F2.
Do not excessively bend or deform the flexible hose.
Installing the flexible hose into aslide window
The window insert is designed to be compatible with the majority of
sliding windows (vertical and horizontal). Nevertheless, for certain types
of slide windows it may be necessary to modify the installation procedure
described below.
1. Slide the panel Ainto the panel B to the window width/length – see
the figure G1. It is important that the holes in the top part of the
window insert are aligned.
2. Make sure the dimension is correct and there are no gaps or air
pockets.
3. Insert ascrew into the hole in the top part of the window insert and
tighten it – see the figure G2. This ensures that the panels will not
move.
4. Open the slide window and place the window insert into the space.
5. Carefully close the slide window. Hold the window insert with one
hand to keep it in the place.
6. Install the flexible hose with the attached adapter into the hole in the
window insert.
EN
Mobile air conditioner Wi-Fi
User´smanual
- 8 -
Revision 11/2023
Copyright © 2023, Fast ČR, a.s.
Note:
If necessary, cut away apart of the window insert if the
window is too small.
Installing the flexible hose using the textile seal kit
The textile seal kit is suitable for tilt-open, sash and roof windows. The
textile seal kit is fitted with aVelcro zip tape to make its installation in the
window easier. Open the window and into the created crevice install the
textile seal kit. We recommend that you thoroughly degrease the location
where you will be attaching the textile seal kit using an appropriate
cleaning agent. Remove the protective paper strip and stick the tape on to
the window frame.
In order to be able to insert the flexible hose, the seal kit is fitted with an
integrated zip. Open the zip in such alocation that will enable you to
easily insert the flexible hose.
It is not necessary to remove the textile seal kit from the window when
not using the mobile air conditioner. The window can be closed even with
the seal installed.
Note:
Avoid excessive bending of the hose. To ensure proper
operation of the mobile air conditioner, it is important not to
overload the hose or to bend it unnecessarily. Excessive
loading or bending may damage the hose.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PUTTING INTO OPERATION
Make sure the mobile air conditioner is correctly assembled and the
flexible hose is properly attached in accordance with the instructions
above.
Make sure the mobile air conditioner is located in asuitable place at
asufficient distance from the power socket.
Insert the power plug into aproperly grounded power socket.
Mobile air conditioner is put into the standby mode.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CONTROLS OF THE MOBILE AIR CONDITIONER
A. CONTROL PANEL
Turning the mobile air conditioner on/off
Press shortly the ON/OFF button and the mobile air conditioner will turn
on and start at the default setting.
Press the ON/OFF button again the turn the mobile air conditioner off
and switch to the standby mode. To turn it off completely, disconnect the
power plug from the power socket.
Warning:
Do not turn the mobile air conditioner on straight after
turning off. Wait afew minutes before turning on.
Otherwise, the compressor may be damaged.
Note:
Never turn off the mobile air conditioner by pulling the
power cord out of the power socket. Turn off the mobile air
conditioner using the ON/OFF button, wait afew minutes
and then pull out the power cord.
Operating modes
1. Cooling mode
Press the MODE button repeatedly until the Cool indicator is lit on the
control panel.
Use the +/– buttons to set the desired temperature. The temperature can
be set in the range of 18–32°C.
Use the FAN SPEED button to set the fan speed. Pressing the FAN
SPEED button repeatedly, you will switch the speed in the following
order: High (high speed) – Med (medium high speed) – Low (low speed)
– Auto (automatic speed). Each time the button is pressed, the respective
indicator will be lit on the control panel.
2. Heating mode
Press the MODE button repeatedly until the Heat indicator is lit on the
control panel.
Use the +/– buttons to set the desired temperature. The temperature can
be set in the range of 13–27°C.
Use the FAN SPEED button to set the fan speed. Pressing the FAN
SPEED button repeatedly, you will switch the speed in the following
order: High (high speed) – Med (medium high speed) – Low (low speed)
– Auto (automatic speed). Each time the button is pressed, the respective
indicator will be lit on the control panel.
In this mode, the fan may operate for short periods, even though the set
temperature has already been reached.
During the heating mode, the air moisture condenses, and it is discharged
into the condensate tank. When the display shows “Ft” (full tank), the
condensate tank must be emptied. For the methods of condensate
drainage, refer to the “CONDENSATE DRAINAGE” section further in this
manual.
Note:
When you use the mobile air conditioner in avery cold
room, it automatically defreezes. The air conditioner
operation is always temporary interrupted. During this
time, you may notice increased noise, this is anormal
phenomenon. Wait until the defrosting process is complete
and the mobile air conditioner restores the heating mode.
3. Fan mode
Fan indicator is lit on the control panel.
In this mode, the fan will circulate the air in the room, but it will not cool it.
Use the FAN SPEED button to set the fan speed. Pressing the FAN
SPEED button repeatedly, you will switch the speed in the following
order: High (high speed) – Med (medium high speed) – Low (low speed).
Each time the button is pressed, the respective indicator will be lit on the
control panel.
4. Dehumidification mode
Press the MODE button repeatedly until the Dry indicator is lit on the
control panel.
In this mode, the humidity in the room is reduces. The condensed
humidity accumulates in the tank. For the methods of condensate
drainage, refer to the “CONDENSATE DRAINAGE” section further in this
manual.
It is not possible to set the temperature or fan speed in this mode. The fan
speed is automatically set to alow speed.
5. Smart mode
In the smart mode, the mobile air conditioner will automatically choose
the suitable operating mode according to the room temperature.
Press the MODE button repeatedly until display shows the following:
Use the FAN SPEED button to set the fan speed. Pressing the FAN
SPEED button repeatedly, you will switch the speed in the following
order: High (high speed) – Med (medium high speed) – Low (low speed)
– Auto (automatic speed). Each time the button is pressed, the respective
indicator will be lit on the control panel.
The mobile air conditioner will automatically choose the operating mode:
– heating when the ambient temperature drops below 20°C;
– fan when the ambient temperature is in the range from 20 to
23°C;
– cooling when the ambient temperature rises above 23°C.
Functions of the mobile air conditioner
1. Timer function
The mobile air conditioner enables to set two different timers – turn-on
timer and turn-off timer of the mobile air conditioner.
a) Turn-on timer of the mobile air conditioner
Turn-on timer of the mobile air conditioner allows you to turn
on the mobile air conditioner after aset period.
When the mobile air conditioner is in standby mode, press the
TIMER button. The numeric display will flash, and the time
indicator will be lit.
Press the TIMER button repeatedly to set the time after which
the mobile air conditioner will turn on. You can set the time in
the range from 1 to 24 hours, in 1-hour increments.
- 9 -
Revision 11/2023
Copyright © 2023, Fast ČR, a.s.
Wait about 5 seconds till the time is stored in the memory.
Then, the automatic countdown of the set period will start.
Once the set time has elapsed, the mobile air conditioner starts
in the last operating mode.
b) Turn-off timer of the mobile air conditioner
Turn-on timer of the mobile air conditioner allows you to turn
off the mobile air conditioner after aset period.
When the mobile air conditioner is operating, press the TIMER
button. The numeric display will flash, and the time indicator
will be lit.
Press the TIMER button repeatedly to set the time after which
the mobile air conditioner will turn off. You can set the time in
the range from 1 to 24 hours, in 1-hour increments.
Wait about 5 seconds till the time is stored in the memory.
Then, the automatic countdown of the set period will start.
Once the set time has elapsed, the mobile air conditioner turns
off and switches to the standby mode.
When you need to cancel the timer, press the TIMER or ON/OFF button
while the countdown is on. The timer indicator will go off.
Temperature unit change
While the mobile air conditioner is on, long press the +/– simultaneously
to change the temperature units from °C to °F and vice versa.
B. REMOTE CONTROL
Inserting and replacing batteries
Slide out the battery compartment cover, which is located on the rear side
of the remote control. Place two AAA/LR03 (2× 1.5V) alkaline batteries
into the battery compartment and close the cover.
When inserting the batteries ensure the correct polarity as shown in the
battery compartment.
When replacing the batteries, always use batteries of the same type,
never combine old and new batteries or batteries of various types.
Note:
Removing the batteries from the remote control will
delete all the settings. After new batteries are inserted the
default remote control settings as programmed by the
manufacturer will be renewed.
If you will not be using the remote control for longer than
2months, remove the batteries.
Warning:
Dispose the used batteries in accordance with the
locally applicable laws. Do not dispose batteries
in common household waste. Do not use old and
new batteries at the same time. Do not use alkaline,
standard, or rechargeable batteries at the same time.
Do not throw batteries into fire. They may explode,
or leak.
Using the remote control
For the remote control to work correctly, ensure that the maximum
distance of the remote control from the mobile air conditioner is not
greater than 7m and that there is no obstacle between the remote control
and the mobile air conditioner that could prevent the transmission of the
signal.
Point the remote control directly at the mobile air conditioner. The
transmission of the signal is confirmed by ashort sound signal.
Do not expose the remote control to direct sunlight or high temperatures.
Otherwise, the signal may not be transmitted.
Turning the mobile air conditioner on/off
Press shortly the button and the mobile air conditioner will turn on and
start at the default setting.
Press the button again the turn the mobile air conditioner off and
switch to the standby mode. To turn it off completely, disconnect the
power plug from the power socket.
Warning:
Do not turn the mobile air conditioner on straight after
turning off. Wait afew minutes before turning on.
Otherwise, the compressor may be damaged.
Note:
Never turn off the mobile air conditioner by pulling the
power cord out of the power socket. Turn off the mobile air
conditioner using the button, wait afew minutes and
then pull out the power cord.
Operating modes
1. Cooling mode
Press the button repeatedly until the indicator is lit on the display.
Use the / buttons to set the desired temperature. The temperature
can be set in the range of 18–32°C.
Use the button to set the fan speed. Pressing the button
repeatedly, you will switch the speed in the following order: High (high
speed) – Med (medium high speed) – Low (low speed) – Auto (automatic
speed). Each time the button is pressed, the respective indicator will be lit
on the control panel.
2. Heating mode
Press the button repeatedly until the indicator is lit on the display.
Use the / buttons to set the desired temperature. The temperature
can be set in the range of 13–27°C.
Use the button to set the fan speed. Pressing the button
repeatedly, you will switch the speed in the following order: High (high
speed) – Med (medium high speed) – Low (low speed) – Auto (automatic
speed). Each time the button is pressed, the respective indicator will be lit
on the control panel.
In this mode, the fan may operate for short periods, even though the set
temperature has already been reached.
During the heating mode, the air moisture condenses, and it is discharged
into the condensate tank. When the display shows “Ft” (full tank), the
condensate tank must be emptied. For the methods of condensate
drainage, refer to the “CONDENSATE DRAINAGE” section further in this
manual.
Note:
When you use the mobile air conditioner in avery cold
room, it automatically defreezes. The air conditioner
operation is always temporary interrupted. During this
time, you may notice increased noise, this is anormal
phenomenon. Wait until the defrosting process is complete
and the mobile air conditioner restores the heating mode.
3. Fan mode
Press the button repeatedly until the indicator is lit on the display.
In this mode, the fan will circulate the air in the room, but it will not cool it.
Use the button to set the fan speed. Pressing the button
repeatedly, you will switch the speed in the following order: High (high
speed) – Med (medium high speed) – Low (low speed). Each time the
button is pressed, the respective indicator will be lit on the control panel.
4. Dehumidification mode
Press the button repeatedly until the indicator is lit on the display.
In this mode, the humidity in the room is reduces. The condensed
humidity accumulates in the tank. For the methods of condensate
drainage, refer to the “CONDENSATE DRAINAGE” section further in this
manual.
It is not possible to set the temperature or fan speed in this mode. The fan
speed is automatically set to alow speed.
5. Smart mode
In the smart mode, the mobile air conditioner will automatically choose
the suitable operating mode according to the room temperature.
Press the button repeatedly until the indicator is lit on the display.
The display of the mobile air conditioner shows the following:
- 10 -
Revision 11/2023
Copyright © 2023, Fast ČR, a.s.
Use the button to set the fan speed. Pressing the button
repeatedly, you will switch the speed in the following order: High (high
speed) – Med (medium high speed) – Low (low speed) – Auto (automatic
speed). Each time the button is pressed, the respective indicator will be lit
on the control panel.
The mobile air conditioner will automatically choose the operating mode:
– heating when the ambient temperature drops below 20°C;
– fan when the ambient temperature is in the range from 20 to
23°C;
– cooling when the ambient temperature rises above 23°C.
Functions of the mobile air conditioner
1. Timer function
The mobile air conditioner enables to set two different timers – turn-on
timer and turn-off timer of the mobile air conditioner.
a) Turn-on timer of the mobile air conditioner
Turn-on timer of the mobile air conditioner allows you to turn
on the mobile air conditioner after aset period.
When the mobile air conditioner is in standby mode, press the
button twice. The display will show anumeric value, the
and “h” symbols will flash.
Use the / buttons to set the time after which the mobile
air conditioner will turn on. You can set the time in the range
from 0.5 to 24 hours.
Press the button and the time is stored in the memory.
The and “h” symbols will be lit on the display. Then, the
automatic countdown of the set period will start.
Once the set time has elapsed, the mobile air conditioner starts
in the last operating mode.
b) Turn-off timer of the mobile air conditioner
Turn-on timer of the mobile air conditioner allows you to turn
off the mobile air conditioner after aset period.
When the mobile air conditioner is in standby mode, press the
button twice. The display will show anumeric value, the
and “h” symbols will flash.
Use the / buttons to set the time after which the mobile
air conditioner will turn on. You can set the time in the range
from 0.5 to 24 hours.
Press the button and the time is stored in the memory.
The and “h” symbols will be lit on the display. Then, the
automatic countdown of the set period will start.
Once the set time has elapsed, the mobile air conditioner starts
in the last operating mode.
When you need to cancel the timer, press the or button while the
countdown is on. The timer indicator will go off.
2. Sleep function
The sleep function is used to reduce the energy consumption during
the night when aconstant temperature is not required. The function also
ensures comfort during sleep, as the operation of the air conditioner is
muted, and the display is dimmed.
Choose the operating mode cooling, dehumidification or heating and
set the start temperature (not valid for dehumidification). Then press the
button to turn on the sleep function. The symbol will be lit on the
display.
The fan speed is automatically set to alow speed and the control panel
brightness is dimmed.
When you choose the cooling operation mode, the temperature will
increase by 1°C/hour during the first two hours. This new temperature will
be maintained for next 6hours. Then, the mobile air conditioner is turned
off and switched to the standby mode.
When you choose the heating operation mode, the temperature will
increase by 1°C/hour during the first three hours. This new temperature
will be maintained for next 5hours. Then, the mobile air conditioner is
turned off and switched to the standby mode.
The sleep function can be cancelled at any time by pressing the ,
or .
The sleep function is not available for fan mode.
3. TURBO function
The TURBO function enables aquick temperature reduction in the room
in the shortest possible time. Temperature and fan speed cannot be
adjusted.
Press the button and the symbol will flash on the display.
Press the button again and the symbol will show on the display.
The TURBO function starts. The temperature of 18 °C and the high fan
speed are set automatically.
To cancel the TURBO function, press the button and the
symbol will flash on the display. Press the button again and the
symbol will go off. The TURBO function is cancelled, and the mobile air
conditioner restores last setting.
The TURBO function can be also cancelled by pressing the , or
.
Note:
The TURBO function is not available for heating mode.
4. Child lock function
The child lock function will lock the remote control to prevent accidental
settings changes.
Press the / buttons simultaneously for 3seconds. The lock symbol
is lit on the display. The remote control buttons will be disabled.
To cancel the child lock function, press the / buttons
simultaneously for 3seconds and the lock symbol goes off the display.
The remote control buttons will be functional again.
Air outlet cover move
Press the button and the air outlet cover will start moving up and
down.
Press the button and the air outlet cover will stop moving.
Temperature unit change
Press the °C/°F to change the temperature units from °C to °F and vice
versa.
C. CONTROL VIA THE SENCOR HOME APPLICATION
This mobile air conditioner can be controlled via the Sencor HOME
application.
Download the application to your smart phone, register yourself and
control the mobile air conditioner via the application.
If you already have the application installed, add the mobile air conditioner
to your devices.
Adding the mobile air conditioner to the list of appliances via Bluetooth
You can add the mobile air conditioner to the Sencor HOME application
by pairing it via Bluetooth.
1. Turn on the Bluetooth function on your mobile phone.
2. Turn on the mobile air conditioner.
3. Open the application and on the home screen of the application,
click on the icon »+«.
4. The appliance will automatically offer the options »Do not add / Go
to Add«.
5. Click on »Go to Add« and the application will automatically guide
you through the addition.
Note:
If the Bluetooth connection fails or is not possible, check
that there are no solid obstacles between your phone and
the mobile air conditioner and that both devices are close
to each other.
- 11 -
Revision 11/2023
Copyright © 2023, Fast ČR, a.s.
Adding the mobile air conditioner to the list of appliances via aQR code
The mobile air conditioner can also be added to the Sencor HOME
application using the QR code provided below. On the home screen of the
application, click on the “+” icon and on the Add device screen, click on
the [–] icon in the top right hand corner.
SAC MT9078CH
Air Conditioner
QR code for adding the control panel of the mobile air conditioner
totheapplication Sencor HOME
Manually adding the mobile air conditioner to the device list
On the main screen, click on “Add device” or on the “+” in the top right
hand corner.
Ascreen with appliance categories will appear together with alist
ofappliances.
Click on “Cooling” and select the mobile air conditioner model from the
list of products.
On the next screen, you will be asked to select aWi-Fi network. Select
anetwork, enter the password and click on “Next”.
Ensure that the mobile air conditioner is ready for pairing. It is important
that the mobile air conditioner is connected to apower source and
is in stand-by mode. The Wi-Fi indicator will start to flash quickly
onthecontrol panel. If the indicator does not start flashing, hold down
theFAN SPEED button for 3seconds until the Wi-Fi indicator starts
flashing quickly. In the application, confirm that the Wi-Fi indicator is
quickly flashing and click on “Next”.
The mobile air conditioner will automatically be added to the device list.
The Wi-Fi indicator will be lit.
In the device list on the main screen, click on the icon of the mobile
airconditioner to enter its control interface.
Wi-Fi reset
While the mobile air conditioner is on, press the FAN SPEED button six
times within 4seconds and abeep will sound twice. The Wi-Fi setting will
be reset, and the Wi-Fi indicator will flash rapidly (twice per second).
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CONDENSATE DRAINAGE
The mobile air conditioner is equipped with two drain outlets where
each draining condensate from adifferent part of the air conditioner. In
the case of afrequent use of the mobile air conditioner, it is necessary to
regularly check the quantity of condensate and drain it. If you choose the
dehumidification mode, we recommend draining the condensate using
adrain hose that you connect to the upper drain hole.
Note:
In cooling and fan operating mode (provided low humidity
in the room), it may not be necessary to drain the
condensate. The mobile air conditioner is designed to
increase the efficiency with asmall amount of water in the
condensate tank.
Condensate drainage from the bottom drain hole
When the water level in the tank reaches the preset level, the operation
of the mobile air conditioner will stop, abeep will sound, and the display
will show “Ft” (full tank). To drain the condensate from the air conditioner,
proceed as follows:
1. Disconnect the power plug from the power socket.
2. Carefully re-locate the mobile air conditioner to alocation where the
water may be drained.
3. Underneath the drain outlet, place acontainer into which the
condensate will flow. Carefully remove the plug of the drain outlet–
see the figure H1. Connect the drain hose – see the figure H2;
and allow the condensate to flow out. You may tilt the mobile air
conditioner slightly backwards while draining the condensate.
4. Once the water tank is empty (condensate has stopped flowing),
disconnect the drain hose and put the plug back into the drain
outlet. Before turning on the mobile air conditioner again, make
sure that plug of the drain outlet is correctly inserted, and seals will.
Otherwise, condensate could leak during the operation, and it could
damage the floor or carpet.
5. Insert the power plug into apower socket and turn on the mobile air
conditioner.
Condensate drainage from the top drain hole
The top drain hole is used for continuous draining.
1. Disconnect the power plug from the power socket.
2. Remove the plug of the drain outlet – see the figure H3. Connect
the drain hose – see the figure H4. If the length of the drain hose
is insufficient, then it is necessary to purchase alonger hose of
the same type. Never extend the length of the drain hose using
extensions.
3. Connect the end of the drain hose to the waste water drain.
4. Insert the power plug into apower socket and turn on the mobile air
conditioner.
Note:
The drain hose should be installed at the same height or
lower than the top drain outlet – see the figures H5 and
H6. Otherwise, the condensate will not be properly drained
from the water tank.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
COMPRESSOR PROTECTION
The compressor is equipped with time protection against damage when it is
switched on again, lasting 3minutes. If the mobile air conditioner is switched
on shortly after it has been switched off, the compressor will only start
running after 3minutes.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TIPS FOR CORRECT USAGE
To ensure the correct usage of the mobile air conditioner, we recommend
that you observe the following:
– Close all windows and doors of the room where you are using
the mobile air conditioner. If you have installed the mobile air
conditioner in the room only temporarily, you can leave the door
slightly ajar (about 1cm) to ensure proper ventilation.
– Avoid direct sunlight entering the room. Close the curtains or
blinds to ensure economical operation of the air conditioner.
– Do not block the air outlet and inlet openings.
– Make sure that no heat source is turned on in the room.
– Never use the mobile air conditioner in avery humid environment,
such as laundry rooms.
– Never use the mobile air conditioner outdoors.
- 12 -
Revision 11/2023
Copyright © 2023, Fast ČR, a.s.
– Make sure the mobile air conditioner is placed on aflat surface. If
necessary, install special brakes on the travel wheels.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MAINTENANCE AND CLEANING
Before cleaning the mobile air conditioner, turn it off and wait afew
minutes, and then pull the power cord out of the power socket.
Cleaning the protective grilles and air filters
When the mobile air conditioner is used regularly, it is necessary to clean
the protective grilles and air filters at least once every 14 days to prevent
the fan from being clogged by dust.
Carefully remove the protective grilles and remove the filters – see the
figure I. To remove the dust, use avacuum cleaner.
In the event of greater soiling, wash the filters in asolution of lukewarm
water (max. 40°C) and neutral detergent. Then thoroughly rinse under
running water and allow to dry naturally. Do not dry it in aclothes dryer
or in direct sunlight. Once the filters are dry, you can install them back in
their place.
In the event of greater soiling, you can wipe the protective grilles with
aslightly damp cloth and wipe dry with aclean cloth.
Note:
Do not use the mobile air conditioner without the air filters
and protective grilles properly installed and do not use it
with wet or damp air filters.
Cleaning the outer case
To clean the outer case, use asoft wiping cloth dipped in asolution of
lukewarm water and neutral detergent. Then wipe the surface dry.
When cleaning it, do not spray the mobile air conditioner with water or
any other liquid, do not pour water on it or submerge it in water or in any
other liquid.
Do not use abrasive cleaning products, solvents, petrol, etc. for cleaning.
Storing the mobile air conditioner
In order to dry it and to prevent the formation of moulds, leave the mobile
air conditioner running in awarm room in the fan mode for approximately
12 hours.
Disconnect the flexible hose and store it in asafe place out of the reach
of children.
Drain all the condensate from the water tank – see chapter
„CONDENSATE DRAINAGE“.
Clean the air filters and reinstall them. Wipe the outer case of the mobile
air conditioner. Remove the batteries from the remote control.
Store the air conditioner in acool, dry and dark location.
Putting into operation again
Check that the power cord and plug are not damaged and that the air
filters are clean. Insert anew set of batteries into the remote control.
Proceed according to the instructions in section „Inserting and replacing
batteries“. Install the mobile air conditioner according to the instructions
contained in the preceding part of this user‘smanual „Installation“.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TROUBLESHOOTING
Before contacting an authorised service centre, please check the
appliance according to the following instructions:
Problem Cause Solution
The mobile air
conditioner does
not turn on.
The power cord is not
plugged in the power
socket, or the power
socket is energised.
Connect the power
plug correctly to
the power socket,
or check the power
socket is energised.
The internal safety
device has been
tripped.
Wait about
30minutes and then
try to turn on the air
conditioner again. If
the problem persists,
contact the authorised
service centre.
The mobile air
conditioner works
for ashort time
only.
The flexible hose is
excessively bended.
Straighten the flexible
hose so that there are
no bends.
Air outlet is blocked. Unblock the air outlet.
The mobile air
conditioner works,
but it does not
cool.
Room windows and
doors of the room are
open and warm air
flows into the room, or
heat sources are on in
the room.
Ensure all windows
and doors are closed,
or turn off heat
sources.
The mobile air
conditioner is exposed
to the direct sunshine
or aheat source.
Re-locate the mobile
air conditioner, dim
it, or turn off aheat
source.
Flexible hose is
disconnected.
Attach the flexible
hose.
Room technical
parameters does
not correspond to
the recommended
parameters of the
mobile air conditioner.
Check the technical
parameters and
use the mobile air
conditioner in the
recommended room
size.
During operation,
there is
unpleasant smell
in the room.
The air filters are
soiled.
Clean the air filters.
The mobile air
conditioner does
not work the first
3 minutes after
turning on again.
The compressor
protection has been
activated.
Wait 3 minutes.
Then, the operation
will automatically
start. It is anormal
phenomenon.
The remote
control does not
work.
The distance between
the remote control and
mobile air conditioner
is too big.
Approach the mobile
air conditioner and
make sure there are
no obstacles between
the control and the
mobile air conditioner.
The remote control
does not point at the
signal sensor.
Batteries are
discharged.
Change the batteries.
- 13 -
Revision 11/2023
Copyright © 2023, Fast ČR, a.s.
Error messages
Error
message
on the
display
Meaning Solution
PF Probe failure Contact the authorised
service centre.
Ft Condensate tank is full. Empty the condensate
tank according to
the instructions in
“CONDENSATE
DRAINAGE” section.
Note:
In the event that one of the aforementioned faults occurs,
turn off the mobile air conditioner and check for the cause
of the fault. Turn it on again, and if the fault reoccurs, turn it
off, disconnect the power cord from the power socket and
contact the manufacturer, an authorised service centre
or aperson with relevant qualifications and have the unit
repaired.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TECHNICAL SPECIFICATIONS
Energy class (cooling/heating) ............................................................ A++ / A+++
Power supply ..........................................................................220-240 V~ / 50 Hz
Cooling power ....................................................................................... 9 000 BTU/h
Cooling input power ...........................................................................................733 W
El. current draw (cooling) .....................................................................................3.2 A
EER cooling factor......................................................................................................3,6
Heating input power ..........................................................................................600 W
El. current draw (heating).....................................................................................2.6 A
COP heating factor .....................................................................................................3,8
Dehumidification capacity ................................................................................0.6 l/h
Capacity of the built-in condensate tank ...........................................................1.2 l
Refrigerant type and weight .............................................................R290 / 290 g
Air flow volume ................................ 410 / 350 / 300 m
3
/h (high/middle/low)
Acoustic power value ...................................................................................64 dB (A)
Sound pressure value ............................50 / 48 / 47 dB(A) (high/middle/low)
Maximum permitted value of operating pressure (low/high)...1.2 / 2.3 MPa
Dimensions of the mobile air conditioner
(w× d × h) ............................................................................... 450 × 745 × 396 mm
Weight ......................................................................................................................33 kg
Range of temperature settings (cooling) ..............................................18 to 32 °C
Range of temperature settings (heating) .............................................13 to 27 °C
Recommended room area (Central Europe)* ...................................31 to 35 m
2
Recommended room size (Central Europe)* ...................................80 to 91 m
3
*Applies for the calculated climatic conditions value typical for Central
Europe. For standard rooms with ceilings at standardised heights.
Theprovided values may differ when the appliance is used in sectioned
areas, in areas with multiple heat sources, heavily glazed or/and poorly
insulated areas.
If you know that you are purchasing the air conditioner for an area with
the above-described characteristics, select amodel with ahigher power
output for the given area.
The declared noise emission level of the appliance is 64dB(A), which
represents alevel Aof sound power with respect to areference sound
power of 1pW.
Note:
The efficiency of the mobile air conditioner may be reduced
in the event that it is used outside the above-described
operating temperature range.
We reserve the right to change text and technical specifications.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DISPOSAL OF USED BATTERIES
Batteries contain environmentally damaging compounds
and, therefore, do not belong in standard communal waste.
Hand over used batteries for proper disposal at locations
intended for their collection.
SENCOR hereby declares that radio devices model number
SACMT9078CH and SAC MT9079CH are in compliance with directive
2014/53/ EU. The full wording of the EU Declaration of Conformity is
available at the website: www.sencor.eu.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF
USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your
municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that
used electric or electronic products must not be added to
ordinary municipal waste. For proper disposal, renewal and
recycling, hand over these appliances to determined
collection points. Alternatively, in some European Union
states or other European countries you may return your
appliances to the local retailer when buying an equivalent
new appliance. Correct disposal of this product helps save
valuable natural resources and prevents potential negative effects on the
environment and human health, which could result from improper waste
disposal. Ask your local authorities or collection facility for more details. In
accordance with national regulations penalties may be imposed for the
incorrect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic equipment, ask your retailer
or supplier for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this
product, request the necessary information about the correct disposal
method from the local council or from your retailer.
This product meets all the basic requirements of EU
directives related to it.
FAST ČR, a.s.
U Sanitasu 1621
CZ-251 01 Říčany
www.sencor.eu
