FRENCH FRY CUTTER
MODEL:LD02
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only
represents an estimate of savings you might benefit from buying certain tools
with us compared to the major top brands and does not necessarily mean to cover
all categories of tools offered by us. You are kindly reminded to verify carefully
when you are placing an order with us if you are actually Saving
Half in comparison with the top major brands.
- 1 -
MODEL:LD02
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
FRENCH FRY CUTTER
- 2 -
Warning-To reduce the risk of injury, user must read
instructions manual carefully.
INSTRUCTIONS FOR USE
1. It is not recommended to cut sweet potatoes and tomatoes.
You can cut potatoes, cucumbers, carrots, zucchini, onions, etc.
2.When cutting onions, it is recommended to cut off the ends and hard skin
first before putting them into the machine.
3.It is not recommended to put the machine or accessories such as the
cutter head into the dishwasher for cleaning or soaking for a long time.
Proper usage not only avoids the awkwardness of potato jams but also
prolongs the blade’s service life.
Correct usage methods can lengthen the blade’s lifespan, make potato
cutting easier.
Tips for extending the blade’s service life:
1. Cutting the potato into two pieces will make it easier to cut.
2. Align the potato’s small end with the blade and the big end with the tail to
make the pushing more even.
ASSEMBLY INSTRUCTION
Put the washers in position
and line up all the holes from handle
and main body
Make sure the washers have been
located inside of connecting arm
then insert the duel screw into holes
and tight them with Allen wrench
- 3 -
Put assembled onto suction cup and
tighten the nut by clockwise
Land the cutter with its legs on
horizontal surface and use
appropriate bolt (buy separately) to
fix it
Make sure the cutter is mounted
onto a solid wall and use
appropriate bolt (buy separately) to
fix it
DO NOT HOLD ONTO POTATO WHILE PULLING THE HANDLE
CLEAN AND REPLACE THE CUTTER
NOTE:The cutter head and pusher head need to be replaced to
match ,and make sure the push head and the cutter head are centered
before tightening the screws
Take out the cutting blades after
removing the nuts then handwash
the blades by water with brush
- 4 -
Rotate the quick releaser 180° and
pull out the pushing block vertically
then handwash it with brush
COMPONENT LIST
NOTE OF CAUTION
Keep fingers away from blades
Do not operate when it's unsteady
- 5 -
Do not use frozen potato
Do not use oversize potato
Wash food-contact parts before
and after use
Damage part check before use
KEEP OUT OF REACH OF CHILDREN
Reasons for potato jams and solutions:
1. The potato is too large, insufficient force or an incorrect exertion posture
may cause it to jam.
2. After the potato gets stuck, locate the jammed part and cut it out with a
knife, then push the
potato out.
Try several times, and believe that this little dog will become your excellent
partner.
- 6 -
