WIRELESS CLIP ON MINI MICROPHONE
OPERATING INSTRUCTIONS
This Wireless Clip-on Mini Microphone of good quality, will bring you into a world where you can sing
happily and freely to your heart's content so that you enjoy it admiringly.
HOW DO YOU OPERATE IT?
1. Open the bottom cover (4) of the transmitter, insert the battery with the correct polarity and close the
bottom cover until it clicks to shut.
2. Insert the Microphone connector (9) into the socket (1) of transmitter.
3. Open the battery cover (5) of the receiver, insert two batteries (size AAA) into the receiver with correct
polarity and close the battery cover.
4. Plug the receiver into the input socket of the microphone on the amplier, set both switch (2) of the
transmitter then switch (8) of the receiver to ON position, then the pilot light (3) and (7) will turn on that
indicates good condition and ready for operation.
ATTENTIONS:
1. If the acoustic quality and volume is not normal or receiving distance is shortened, the batteries in the
transmitter and receiver should be replaced, if thereafter still not working normal, carefully trim the
frequency by adjusting the screw (6) in the receiver with a screwdriver to operate normally.
2. If your microphone will not be used for a long period, the battery should be taken out to avoid
deterioration and damage of components.
3. If two wireless microphones will be used at the same time, you should use them with one red and green
light. You can’t use the microphone with both the same color.
4. lf the microphone is too close to the speaker or the volume of the amplier is too loud, shrill sound will
occur that may damage the amplier or speaker. In that case, please keep the microphone far from the
speaker and tone down the volume of the amplier.
SPECIFICATIONS:
Modulation
Wireless Operating Frequency
Output Impedance
Operating voltage
Eective distance
FM
179.4 / 202.8 MHz
600 ohm
9V DC for Transmitter
3V DC for Receiver
20 m
www.PyleUSA.com
PDWM96
