Technical Support and E-Warranty Certificate www.vevor.com/support
Thread Repair Kits
MODEL:
XRSS061 / XRSS049
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL:
XRSS061
MODEL:
XRSS049
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
Thread Repair Kits
- 2 -
INSTRUCTIONS
Thank you very much for choosing this Thread Repair Kit.
- Please read all of the instructions before using it. The information will help you
achieve the best possible results.
The products carried in this catalog may be different in color than the actual item.
SAVE THESE INSTRUCTIONS
WARNING:
Ensure Health and Safety, local authority and general workshop practice
regulations are adhered to when using tools.
* DO NOT use tools if damaged.
* Maintain tools in good and clean condition for best and safest performance.
* If the vehicle to be worked on is raised, ensure that it is adequately supported
with axle stands or ramps and chocks.
* Wear suitable clothing to avoid snagging. Do not wear loose jewellery and tie
back long hair.
* Account for all tools and parts being used.
* If working off the vehicle, ensure that the workplace is secure and stable.
* Do Not use these tools if you are tired or under the influence of alcohol, drugs or
intoxicating medication.
MODEL AND PARAMETERS
XRSS061 contains 61 pieces ,UNC& UNF & Metric,As follows:
7 Pc - Inch Coarse (UNC) Sizes Taps:
9/16″-12, 1/2″-13, 7/16″-14, 3/8″-16, 5/16″-18, 1/4″-20，5/8″
7Pc - Inch Fine (UNF) Sizes Taps:
9/16″-18, 1/2″-20, 7/16″-20, 3/8″-24, 5/16″-24, 1/4″-28， 5/8″
14Pc - Metric Sizes Taps:
- 3 -
M14*1.5, M12*1.75, M12*1.5, M12*1.25, M11*1.5, M10*1.5, M10*1.25, M10*1.0,
M8*1.5, M8*1.25, M8*1.0, M7*1.0，M6*1.25，M6*1.0
7 Pc - Inch UNC Thread Chaser:
5/8″-11, 9/16″-12, 1/2″-13, 7/16″-14, 3/8″-16, 5/16″-18, 1/4″-20
7 Pc - Inch UNF Thread Chaser:
5/8″-18, 9/16″-18, 1/2″-20, 7/16″-20, 3/8″-24, 5/16″-24, 1/4″-28
14pc-Metric Thread Chaser:
M14*1.5, M12*1.75, M12*1.5, M12*1.25, M11*1.5, M10*1.5, M10*1.25, M10*1.0,
M8*1.5, M8*1.25, M8*1.0, M7*1.0，M6*1.25，M6*1.0
SAE Thread File: 9 - 10 - 12 - 16 - 20 - 27 - 28 - 32;
Metric Thread File: 0.75mm - 1.0mm - 1.25mm - 1.50mm - 1.75mm - 2.00mm -
3.00mm;
SAE Thread File: 11 - 12 - 13 - 14 - 16 - 18 - 20 - 24
XRSS049 contains 49 pieces ,UNC& UNF & Metric,As follows:
6Pc - Inch Coarse (UNC) Sizes Taps:
9/16″-12, 1/2″-13, 7/16″-14, 3/8″-16, 5/16″-18, 1/4″-20
6Pc - Inch Fine (UNF) Sizes Taps:
9/16″-18, 1/2″-20, 7/16″-20, 3/8″-24, 5/16″-24, 1/4″-28
10Pc - Metric Sizes Taps:
M14*1.5, M12*1.75, M12*1.5, M12*1.25, M11*1.5, M10*1.5, M10*1.25, M10*1.0,
M8*1.25, M6*1.0
7 Pc - Inch UNC Thread Chaser:
5/8″-11, 9/16″-12, 1/2″-13, 7/16″-14, 3/8″-16, 5/16″-18, 1/4″-20
7 Pc - Inch UNF Thread Chaser:
5/8″-18, 9/16″-18, 1/2″-20, 7/16″-20, 3/8″-24, 5/16″-24, 1/4″-28
- 4 -
Metric Thread Chaser:
M14*1.5, M12*1.75, M12*1.5, M12*1.25, M11*1.5, M10*1.5, M10*1.25, M10*1.0,
M8*1.25, M6*1.0
SAE Thread File: 9 - 10 - 12 - 16 - 20 - 27 - 28 - 32;
Metric Thread File: 0.75mm - 1.0mm - 1.25mm - 1.50mm - 1.75mm - 2.00mm -
3.00mm;
SAE Thread File: 11 - 12 - 13 - 14 - 16 - 18 - 20 - 24
ASSEMBLY AND USE
Repair Damaged Threads.
Restore Thread Functionality.
Clean Threaded Connection.
Remove Nut or Bolt.
Different from a tap and die set to cut new threads a thread chaser set is
designed for cleaning up and restoring existing threads. They remove dirt
and corrosion from threads without shaving off metal and aim to eliminate
resistance when reinstalling and removing the bolt and avoid
cross-threading.
To use a thread chaser, simply fasten it on a threaded hole or bolt as you
would with regular bolts or nuts. Then, turn the chaser slowly down the
gunky or slightly damaged threads. Be gentle to avoid causing more
damage.
A thread chaser set is for anyone who takes things apart and reassembles
them. But most importantly, it is a must-have kit for any auto mechanic for
chasing threads on rusty fasteners and bolt holes on cylinder heads,
engine blocks, and bodies of vehicles.
MAINTENANCE
1. Avoid prolonged exposure to the sun to avoid aging
- 5 -
Manufacturer:Shanghaimuxinmuyeyouxiangongsi
Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu, shanghai
200000 CN.
Imported to AUS: SIHAO PTY LTD. 1 ROKEVA STREETEASTWOOD NSW 2122
Australia
Imported to USA: Sanven Technology Ltd. Suite 250, 9166 Anaheim Place,
Rancho Cucamonga, CA 91730
REP
EC
E-CrossStu GmbH
Mainzer Landstr.69, 60329 Frankfurt am Main.
REP
UK
YH CONSULTING LIMITED.
C/O YH Consulting Limited Office 147, Centurion House,
London Road, Staines-upon-Thames, Surrey, TW18 4AX
