KODAK
DIGITAL CAMERA
PIXPRO
AZ528
User Manual
ii 1ii 1
Declaration of Conformity
Responsible Party: JK Imaging Ltd.
Address: JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
Company Website: kodakpixpro.com
INDUSTRY CANADA
This device complies with Canadian RSS-210.
This device complies with Industry Canada license-exempt RSS standard (s).Operation
is subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Radiation Exposure Statement:
This product complies with the Canadian portable RF exposure limit set forth for an
uncontrolled environment and is safe for intended operation as described in this manual.
Additional RF exposure reduction can be achieved if the product can be kept as far as
possible from the user body or set the device to lower output power if such function is
available.
NEW CAMERA OWNER / IMPORTANT INFORMATION
Thank you for purchasing your new KODAK PIXPRO AZ528 Astro Zoom camera. In an
eort to provide you with the most up to date benefits and features of the AZ528, we
strongly encourage you to register your new camera on our website:
https://kodakpixpro.com/support/product-registration
Doing so will keep you informed of important updates, including firmware, features
and other important information that pertain to the AZ528. Your information is always
kept secure, is encrypted and is never sold, shared or used for any purposes other than
for AZ528 camera specific notifications, unless you opt-in to receive other types of
communications during the registration process.
BEFORE YOU START
2
For Customers in Europe
This symbol [crossed-out wheel bin WEEE Annex IV] indicates separate collection of
electrical waste and electronic equipment in the European countries. Please do not
throw the equipment into domestic refuse. Please use the return and collection sys-
tems available in your country for proper, safe disposal of this product.
“CE” mark indicates that this product complies with the European requirements
for safety, health, environment and customer protection. “CE” marked cameras are
intended for sales in Europe.
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the RED Directive 2014/53/
EU. The following test methods have been applied in order to prove presumption of
conformity with the essential requirements of the RED Directive 2014/53/EU:
- EN60950-1/A12:2011+A2:2013
Safety of Information Technology Equipment
- EN55032:2015/AC:2016 Class B
- EN61000-3-2:2014
- EN61000-3-3:2013
- EN55035:2017
- EN 62479:2010
Assessment of electronic and electrical equipment related to human exposure
restrictions for electromagnetic fields (0 Hz-300 GHz)
- EN 300 328 V2.2
.2 (2019-07)
Wideband transmission systems; Data transmission equipment operating in the 2.4
GHz ISM band and using wide band modulation techniques
- EN 301 489-1 V2.1.1 (2017-02)
Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic
Compatibility (EMC) standard for radio equipment and services; Part 1: Common
technical requirements
3
- EN 301 489-17 V3.1.1 (2017-02)
Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic
Compatibility (EMC) standard for radio equipment; Part 17: Specific conditions for
Broadband Data Transmission Systems
For SAR statement
A minimum separation distance of XX cm must be maintained between the user’s body
and the device, including the antenna during body-worn operation to comply with the RF
exposure requirements in Europe.
To compliance with RF Exposure requirements in Europe, third-party belt-clips, holsters
or similar accessories used by this device should not contain any metallic components.
The use of accessories that do not satisfy these requirements may not comply with RF
exposure requirements, and should be avoided.
Hereby, Sintai Optical (Shenzhen) Co., Ltd, declares that this PIXPRO AZ528 is in
compliance with the essential requirements and other relevant provisions of Direc-
tive 2014/53/EU.
Manufacturer: Sintai Optical (Shenzhen) Co., Ltd
Address: Qiwei Ind Sec, 1st, 2nd,& 3RD Bldg, Lisonglang Village, Gongming
Town, Bao’an District, Shenzhen, Guangdong, China
Batteries: Please dispose of used batteries at designated collection centers.
Packaging: Please follow local regulations for the recycling of packaging.
For Customers in the U.S.A.
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
4
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Radiation Exposure Statement:
This product complies with the FCC portable RF exposure limit set forth for an
uncontrolled environment and is safe for intended operation as described in this manual.
Additional RF exposure reduction can be achieved if the product can be kept as far as
possible from the user body or set the device to lower output power if such function is
available.
5
About this Manual
Thank you for purchasing the KODAK PIXPRO Digital Camera. Please carefully read this
manual and keep it well for future reference.
JK Imaging Ltd. reserves all rights of this document. No part of this published manual
may be reproduced, transmitted, transcribed, stored in a retrieval system or translated
into any language or computer language, in any form, by any means, without the prior
written permission of JK Imaging Ltd.
All trademarks mentioned in this manual are used for identification purposes only and
are properties of their respective owners.
This manual provides you with instructions on how to use your new KODAK PIXPRO
Digital Camera. Every eort has been made to ensure that the contents of this manual
are accurate; however JK Imaging Ltd. reserves the right to make changes without
notice.
Throughout this manual, the following symbols are used to help you locate
information quickly and easily:
Indicates useful information.
In introducing you how to operate this camera, the following symbols may appear to
facilitate your understanding:
「Item properties」：The optional properties in the camera interface are indicated by
the symbol「 」.
6 7
SAFETY NOTES
Safety notes for this camera
Do not drop the camera or allow it to hit solid objects.
Do not attempt to disassemble or repair the camera.
Do not use or store the camera in dusty places or on a beach to prevent dust or sand
from entering the camera, causing possible damage.
Do not use or store the camera in a hot environment or in direct sunlight.
Do not use or store the camera near a powerful magnetic field, such as a magnet or
transformer.
Avoid touching the lens of the camera.
Do not expose the camera to direct sunlight for a long period of time.
To prevent the camera from being damaged by moisture, do not use or store the
camera in very humid environments, such as in rain or near bodies of water.
If water accidentally comes in contact with the camera, turn the camera o, remove
the battery and the memory card, and dry it completely within 24 hours.
When you take the camera from a cold environment to a warmer environment,
condensation may occur. Please wait for a reasonable period of time before you turn
the camera on.
Before you remove the battery and memory card, the camera should be turned o.
When you clean the body of the camera, do not use abrasive, alcohol-based or
organic cleansers or solvents.
Use a professional lens cleaning cloth and appropriate cleaner to wipe and clean the lens.
Download your photos and remove the memory card when you are going to store the
camera for a long period of time.
If this camera is not in use for a long period of time, please keep it in a dry and clean
storage location.
Our company will not pay compensation for any failure of playback including: pictures
or videos damaged or unrecoverable by improper operation.
76 7
Safety notes for battery
Please use a battery that is the same type as the one included.
Please use the attached charger to charge the battery.
If battery fluid leaks inside the camera, contact our customer service department
immediately. If battery fluid leaks onto your skin, rinse your skin with clean water and
seek immediate medical attention.
Disposal of used batteries should be carried out in accordance with the local (national
or regional) regulations.
To prevent the battery from being damaged, do not drop the battery or allow it to hit
solid objects or to be scratched by foreign objects.
Do not let the battery come in contact with metal objects (including coins) to avoid
short circuiting, discharging, excessive heat, or possible leakage.
Do not attempt to disassemble the battery.
Do not expose the battery to water. Always keep the battery contacts dry.
Do not heat the battery or throw it into a fire to avoid a possible explosion.
Do not store the battery in a hot environment or in direct sunlight.
If the battery overheats during charging or use, stop charging or stop use immediately.
Turn o the product, remove the battery carefully, and wait until it cools down.
When the camera is stored for a long period of time, remove the battery and keep it in
a dry place that is not accessible to infants and children.
In a colder environment, the performance of the battery could be noticeably reduced.
When you install the battery, align the battery markings according to the positive and
negative markings inside the battery compartment. Never force the battery into the
battery compartment.
8
Safety notes for memory card
We suggest buying only well-known, name brand memory cards to ensure peak
performance and reliability.
Format the memory card using the camera before you use it or insert a new one.
Do not drop the memory card or allow it to hit solid objects to avoid damaging it.
Do not attempt to disassemble or repair the memory card.
Do not expose the memory card to water. Always keep it dry.
Do not remove the memory card when the camera is turned on. Otherwise, the
memory card and photo/video files could be permanently damaged.
Do not directly edit the data on the memory card. Copy the data to your computer
before you edit them.
When the camera is stored for a long period of time, be sure to download your photos
and remove the memory card. Store the memory card in a dry environment.
Do not modify the name of the files or folders of the memory card using your
computer. Modifying the file names may cause the files to not be recognized on the
camera or a possible permanent error may occur.
A photo taken with the camera will be stored in the folder that is automatically
generated on the memory card. Do not store photos that are not taken using this
camera in these folders as the pictures cannot be recognized during the playback.
When you insert the memory card, make sure the notch of the card matches the
markings on the top of the camera card slot.
9
Other Safety Notes
Do not disconnect the power or turn the camera o during the update process. Doing
so may cause incorrect data to be written and the camera may not power on later.
Do not hang the neck strap of the camera around the neck of a child.
When using your camera on an airplane, observe the relevant rules specified by the
airline and FAA regulations.
Due to the limitations of manufacturing technology, the LCD may have a few dead
or bright pixels. These pixels do no eect the quality or performance of the camera,
photos or video.
Do not expose the camera’s LCD to water. In a humid environment, only wipe it with a
soft and dry cleaning cloth.
If the LCD screen is damaged, pay particular attention to the liquid crystal in the
screen.
If any of the following situations arise, immediately take the steps listed below:
1. If liquid crystal comes in contact with your skin, please wipe with a dry cloth, wash
thoroughly with soap, and rinse with plenty of clean water.
2. If liquid crystal gets into your eye, flush the eye immediately with plenty of clean
water for at least 15 minutes and then seek medical assistance.
3. If liquid crystal is swallowed, immediately rinse your mouth thoroughly with clean
water and induce vomiting. Seek medical assistance.
WARNING
Altering, tampering or modifying the any parts of AZ528 camera are unauthorized and
will void the manufacturer’s warranty and “could” void Federal and/or State Compli-
ance.
10 11
CONTENTS
BEFORE YOU START ...............1
SAFETY NOTES ......................6
CONTENTS ........................... 10
GETTING READY ................... 15
Accessories Included ....................... 15
Install Lens Cap and Neck Strap ...... 16
Part Names ....................................... 17
Installing Battery and
Memory Card .................................... 19
Charging Battery .............................. 21
Turning Camera On and O............. 23
Set your Language, Date/Time ........ 24
Set your Language, Date/Time
after the First Power-On ............. 24
Resetting your Language ........... 25
Resetting Date/Time .................. 26
MODE OVERVIEW ................ 27
Display Setting ................................. 27
LCD Display....................................... 28
Overview of the screen icons in
photo shooting mode ................ 28
Overview of the screen icons in
movie mode ............................... 29
Overview of the screen icons in
playback mode ........................... 30
How to Take Pictures ........................ 31
Using the Mode Dial ......................... 32
1110 11
Auto Mode .................................. 35
Face Beautifier ........................... 37
Wi-Fi® Mode ................................ 38
Scene Mode ............................... 45
Panorama Mode ......................... 47
Movie Mode ................................ 50
Custom Settings ........................ 51
BASIC OPERATION ............... 53
Using the Zoom Function................. 53
Focus Setting.................................... 54
Macro Mode...................................... 55
Self-Timer Setting ............................. 56
Flash Mode ....................................... 57
White Balance Setting ...................... 58
Continuous Shot .............................. 59
EV Settings ....................................... 60
EV Adjustment...................... 60
ISO Adjustment .....................61
Shutter Adjustment .................... 61
Aperture Adjustment ................. 62
Using Quick Recording .................... 62
i Button Function Menu .................... 63
PLAYBACK MODE ................. 64
Viewing Photos and Videos ............. 64
Thumbnail View ................................ 65
12
Using Zoom Playback (for still
pictures only) .................................... 66
Deleting Photos and Videos ............. 67
Slideshow ......................................... 68
Continuous Capture Group
Playback ............................................ 69
Animation Panorama Play ................ 70
USING THE MENUS .............. 71
Photo Setup Menu ............................ 71
Expo Metering ............................ 71
Image Size .................................. 72
OIS (Optical Image
Stabilization) .............................. 73
Cont. AF (Continuous
Auto-Focus) ................................ 73
HDR (High Dynamic Range) ....... 74
Beautifier .................................... 74
Scene .......................................... 75
Photo Shooting Settings Menu ........ 76
Quality ........................................ 77
AF Assist Beam ........................... 77
Digital Zoom ............................... 77
Date Imprint ............................... 78
Quick Review.............................. 78
Custom Settings ........................ 79
Movie Menu ...................................... 80
Expo Metering (Exposure
Metering) .................................... 80
Movie Size .................................. 81
13
OIS (Optical Image
Stabilization) .............................. 82
Movie Setting Menu ......................... 83
Digital Zoom ............................... 84
Custom Settings ........................ 84
Playback Menu ................................. 85
Playback Mode ........................... 85
HDR (High Dynamic Range) ....... 86
Touch-Up .................................... 86
Rotate ......................................... 87
Resize ......................................... 87
Color ........................................... 88
Playback Settings Menu ................... 89
Protect ........................................ 90
Delete ......................................... 91
DPOF (Digital Print Order
Format) ....................................... 92
Trim ............................................. 92
General Settings Menu .................... 93
Sound Settings........................... 94
Power Saver................................ 94
Language .................................... 95
Zone ............................................ 95
Date/Time ................................... 95
LCD Brightness ........................... 95
File Settings ...................................... 96
Format ........................................ 97
14 1514
Copy to Card .............................. 97
File Numbering ........................... 98
Reset ........................................... 98
FW Version.................................. 99
CONNECTION SETTINGS ...100
Connecting to a Computer ............. 101
Setting the USB Mode .............. 101
Transferring files to your
computer ................................... 102
Connecting to a PictBridge
Compatible Printer ......................... 103
Setting the USB Mode ............ 103
Connecting to your Printer ..... 104
Using the PictBridge
Menu .............................................. 105
Video System ................................ 109
APPENDICES ....................... 110
Product Specifications .....................110
Prompts and Warning Messages ..... 114
Troubleshooting ............................... 118
14 15
GETTING READY
Your camera box should contain the camera model you purchased along with the follow-
ing accessories. If anything is missing or appears to be damaged, please contact your
retailer first or our customer service center. (The battery chargers may be a little dierent
in shape due to the dierent countries or regions this camera is sold to. The illustration
may not match the actual product.)
Micro USB Cable
Warranty CardNeck Strap
Rechargeable
Li-ion Battery
AC Adapter
(Optional)
Lens Cap With Strap
Quick Start Guide
Quick Start Guide
STOP
Service Card
Accessories Included
16 17
Install Lens Cap and Neck Strap
16 17
Part Names
1. Micro USB/AV Port
2. Zoom Lever
3. Shutter Button
4. Strap Eyelet
5. Exposure Compensation Button
6. Continuous Shot Button
7. Power Button
8. AF Assist Beam/Self-Timer Lamp
9. Flash Lamp
10. Lens
18 1918
11. Flash Button
12. Microphones
13. Indicator Lamp
14. Mode Dial
15. Fast Video Recording Button
16. Menu Button
17.
AC
AF Button/Up Button
18.
A
C
Macro Button/Left Button
19.
CA
Flash Button/Right Button
20.
C
A
Delete Button/Self-Timer
Button/Down Button
21. Display Button
22. Playback Button
23. SET Button
24. i Button
25. LCD
26. Speaker
27. Battery Cover Door
28. Tripod Socket (1/4'' Standard)
27
28
18 19
1. Open the battery cover according to
the direction of arrow.
1
2
2. Insert the battery into the battery
compartment according to the
negative and positive directions as
illustrated in the picture. Push the
battery down until it locks in place.
Installing Battery and Memory Card
Battery Lock
Knob
20 21
20
4. Close the battery cover.
2
1
3. Insert the memory card into the
memory card slot as shown in the
diagram.
Write
Protection
Buckle
A standard SD memory card is not included in the camera packaging and needs to
be purchased separately. This camera takes a standard (SD/SDHC) memory card.
We recommend using a name brand memory card that is Class 4 or higher and has
a capacity of 4GB to 32GB. The camera is not compatible with Micro SD, Ultra, Ultra
Plus, Extreme, or adapters for any of these other memory cards.
To remove your memory card, open the battery cover, gently press the memory
card to eject it and remove it carefully.
20 21
Before you charge the battery, ensure that
the battery is inserted properly and the
camera is o.
1. Connect the camera and the power
charger using the supplied Micro USB
cable.
2. Insert the plug of the power charger into
the power outlet to charge the battery.
After the battery is stored for a long
period of time, use the supplied power
charger to charge the battery prior to
use.
To have maximum battery life, charge
the battery for at least 4 hours the first
time.
Charging indicator:
Steady orange: Charging
The indicator will go out once charging
is finished.
Indicator Lamp
2
1
Charging Battery
22 2322
3. When the camera is turned o, you can also connect the camera to your PC using a
USB cable to charge the battery.
3
Please charge the battery indoors between 0°C and 40°C (32°F and 104°F).
22 23
Press the power button to turn the camera on. To turn the camera o, press the power
button again.
Power Button
When the power is o, press and hold the button to power on and enter playback
mode.
Turning Camera On and O
24 25
Set your Language, Date/Time after the First Power-On
1. When you turn the camera on for the first
time, the language selection screen will
appear.
2. Press the
AC
/
C
A
/
A
C
/
CA
buttons to select your desired language.
3. After you press the button to confirm
the selection, the Date/Time settings
screen appears.
4. Press the
A
C
/
CA
button to select
the Date/Time to be adjusted: Time is
displayed in YYYY.MM.DD HH:MM.
5. Press the
AC
/
C
A
button to adjust
the value for the selected Date/Time.
6. Press the button to confirm the time
settings and the shooting screen will
appear.
籖넒⚥俒
English
Français
皍⡤⚥俒
傈劥铃
묻펂
Español
Svenska
Português
Italiano
Deutsch
ļyŝŝŖŔŕ
Language
Date & Time
:
03 21 00 00
H-M
2019
Set your Language, Date/Time
2524 25
1. Press the button, press the
AC
/
C
A
button to select , and press the
button to enter the menu.
2. Press the
AC
/
C
A
button to select
, and press the /
CA
button to enter
the menu.
3. Press the
AC
/
C
A
button to select
「Language」and press the /
CA
button to enter the menu.
4. Press the
AC
/
C
A
/
A
C
/
CA
buttons to select your desired language
and press the button to confirm.
5. Press the button and the shooting
screen appears.
Sound Settings
Power Saver
Auto
Language
English
World Time
Home
Date & Time
2019.03.21 00:00
籖넒⚥俒
English
Français
皍⡤⚥俒
傈劥铃
묻펂
Español
Svenska
Português
Italiano
Deutsch
ļyŝŝŖŔŕ
Language
Resetting your Language
After you set your language for the first time, follow the instructions below to reset your
desired language.
26 2726
1. Press the button, press the
AC
/
C
A
button to select , and press the
button to enter the menu.
2. Press the
AC
/
C
A
button to select
, and press the /
CA
button to enter
the menu.
3. Press the
AC
/
C
A
button to select
「Date & Time」and press the /
CA
button to enter the menu.
4. Press the
A
C
/
CA
button to select the
Date/Time to be adjusted: Time is displayed
in YYYY.MM.DD HH:MM.
5. Press the
AC
/
C
A
button to press
the value for your selected block. After you
finish your settings, press the button to
confirm.
6. Press the button and the shooting
screen appears.
Resetting Date/Time
After you set your Date/Time for the first time, follow the instructions below to reset date
and time.
Sound Settings
Power Saver
Auto
Language
English
World Time
Home
Date & Time
2019.03.21 00:00
Date & Time
:
03 21 00 00
Back
H-M
2019
26 27
O: Does not display any additional
icons on screen
MODE OVERVIEW
Press the button to display the settings: Classic, Full, O.
Classic: Displays the camera parameters
on screen
-0.3
EV
F2.8
400
ISO
1234
00:56:00
SD
1/50
Full: Camera parameters with Grid and
Histogram
-0.3
EV
400
ISO
1234
00:56:00
SD
F2.8
1/50
Display Setting
28 29
Overview of the screen icons in photo shooting mode
8 White Balance
9 Color Eect
10 Number of Remaining Shots
11 Image Size
12 Video Quality
13 ISO Value
14 Remaining Recording Time
15 Exposure Compensation
16 Shutter Speed
17 Histogram
18 Aperture Value
19 OIS (Optical Image Stabilization)
20 HDR
21 Expo Metering
22 Continuous Shot
23 AF Mode
24 Flash Mode
1234
-0.3
EV
400
ISO
00:56:00
SD
16M
1/50
x3.6x3.6
F3.6F3.6
1 Shooting Mode
2 Macro Mode
3 Self-Timer
4 Zoom Display (By turning the Zoom
Lever)
5 Focus Frame
6 SD Memory Card/Built-in Memory
7 Battery Status
LCD Display
2928 29
-0.3 EV
00:56:00
00:56:00
SD
x3.6
1 Movie Mode
2 Macro Mode
3 Self-Timer
4 Zoom Display (By turning the Zoom
Lever)
5 SD Memory Card/Built-in Memory
6 Battery Status
7 Color Eect
8 Video Quality
9 Remaining Recording Time
10 Exposure Compensation
11 OIS (Optical Image Stabilization)
12 Focus Frame
13 Expo Metering
14 AF Mode
For optimal video shooting, it
is recommended that an SDHC
memory card be used.
Optical Zoom and Digital Zoom can
be adjusted (208X in total). Digital
Zoom can be adjusted to 4X.
Overview of the screen icons in movie mode
30 3130
1 DPOF File
2 File Protection
3 Memory Space (indicating the current
number of photos and total number
of photos)
4 SD Memory Card/Built-in Memory
5 Battery Status
6 Zoom Magnification Area
7 Image Zoom Ratios
8 Image Zone
9 Shooting Date
10 Continuous Capture Group Playback
11 Touch-up
12 HDR
13 Date Folder
Overview of the screen icons in playback mode
30 31
How to Take Pictures
1. Hold the camera securely with both
hands, being careful not to block the
flash and lens with fingers.
2. Point the lens toward the object you
want to take a picture of.
3. Use the zoom lever to select Tele or
Wide position to zoom in or out on
your subject.
4. Press the shutter button down half-way
to allow the camera to focus on your
subject.
5. When the frame around your subject
turns green and the LCD is focused to
your liking, push the shutter button
down completely to take the picture.
32 33
Using the Mode Dial
This camera provides a convenient mode dial that allows you to manually switch between
dierent modes with ease. The available modes are listed below:
Mode Name Icon Description
Auto Mode
In this mode, the optimal conditions for taking pictures will be
set based on the subject and environment. It is the most com-
monly used mode for taking pictures.
Program AE
Under dierent scenes, the user can switch the ISO and EV value
according to personal preference, the camera can automatically
set the shutter speed and aperture value.
Shutter priority
Setting allows you to adjust the shutter speed / EV value and
ISO value. The camera automatically sets the aperture value
based on the shutter speed and ISO value to get the most ap-
propriate exposure value.
Aperture
priority
In this mode, you can adjusting the aperture size, EV and ISO val-
ues. The large aperture is to highlight the object focused through
blurring the background, while the small aperture is for clear
focusing on both the background and the object.
3332 33
Manual Mode
This mode is for manually setting the aperture, shutter speed
and ISO value.
Face Beautifier
This mode automatically enhances facial features with skin
softening touches and eye brightening capabilities.
Wi-Fi Mode
Enable image transmission and remote control by connecting
smart device with Wi-Fi.
Scene Mode
Choose from 13 dierent pre-set scene types and eects for
your photos.
Movie Mode Record videos.
Custom Settings
The user can store frequently used shooting modes and pa-
rameters. Switching to this mode enables quick adjustment.
34
Mode:
Follow the steps below to adjust the parameters:
1. Rotate the mode dial to select a mode you want, press the button to configure
settings.
1/50
400 ISO
1/50
400 ISO
0.3 EV
0.3 EV
F2.8F2.8
2. Press the
A
C
/
CA
button to select an adjustment setting.
3. Press the
AC
/
C
A
button to adjust the parameters.
4. Press the button to confirm the settings and enter the shooting screen.
Please refer to the table below for any nonadjustable options in mode:
(O: Available X: Not Available)
Options
Mode
Aperture Shutter EV ISO
X X O O
X O O O
O X O O
O O X O
Please note that even if
an option is not able to
be adjusted in a particular
mode, its value will still be
displayed on the shooting
screen.
35
Auto Mode
The camera will automatically detect the most suitable scene to capture the best
pictures.
SD
00:56:00
Auto Mode
The camera automatically adjusts the exposure and focus to ensure the best possible
pictures.
Landscape Mode
For landscapes, automatically adjusts the exposure to match the background.
36
Portrait Mode
Most suitable for capturing people with focus on their faces.
Night Portrait
When you take portraits at night or in low light conditions, automatically adjust the expo-
sure for people and night scenes.
Backlit Portrait
When the sun or any other light source is behind you, automatically adjusts the fore-
ground exposure to produce the best pictures possible.
Night Mode
For night scenes, automatically increases the ISO value to compensate for low light.
Macro Mode
To produce more detailed close-ups, will automatically engage the camera’s Macro Mode
and automatically focus the lens.
37
Face Beautifier
The camera is set to automatically adjust camera exposure for realistic portrayal of skin
tones.
1. Turn the mode dial to select face beautifier mode .
2. Press the button and press the
AC
/
C
A
button to select .
3. Press the
A
C
/
CA
button to select an option and press the button to confirm
and return to photo shooting mode.
1234
-0.3
EV
400
ISO
SD
16M
00:56:00
x3.6
x3.6
• Eect 1: Skin Soften
• Eect 2: Skin Soften+Eye Brightening
• Eect 3: Skin Soften+Eye Brightening+Eye Enlargement
38
Wi-Fi® Mode
Enable image transmission and remote control by connecting smart device with Wi-Fi®.
Before utilizing Wi-Fi® Mode, please review the following:
Your smart device operating system version needs to be iOS 14 or higher, or Android
8.0 or higher. If not, please upgrade your smart device before using the App.
Please do not use in places having high intensity magnetic field, electrostatic and
electric wave interference (for example near a microwave oven), which may cause
failure in receiving signals.
To maintain a connection, please keep the camera within 10 meters (32.8 feet) without
signal shielding interference.
Please do not use Wi-Fi® connection functionality on a plane.
The camera and the smart device can only be connected one to one.
39
Downloading the App package:
Download a dedicated installation package from the application store (App name:
PIXPRO Remote Viewer ) and then install it.
• Android devices : Search and download the App “PIXPRO Remote Viewer”
in Google play, and install it following the instructions on the
interface.
• iOS devices : Search and download the App “PIXPRO Remote Viewer” in App
store, and install it following the instructions on the interface.
40
Settings of Camera:
Press the
AC
/
C
A
button to select
options to be adjusted, and press the
button to enter the setting interface.
Wi-Fi Mode
Cancel
Change Password
Setting pre-connected device for the
following serial number:
SSID:
PIXPRO AZ528_XXXX
WPA2-PSK: XXXXXXXX
• Change Password: Enter the WPA2
PSK password refresh interface.
Yes: Create a new WPA2 PSK
password.
No: Back to previous page.
• Cancel: Back to previous page.
Rotate the mode dial to and then enter
the Wi-Fi® selection interface.
●
To ensure a stable connection, please connect
to the new camera in Wi-Fi settings
●
Ensure that the password is correct.
Next
• Next: Enter the SSID interface.
Rotate the mode dial to disconnect.
41
Settings of Smart Device:
1. Enable the Wi-Fi® of smart device and then search surrounding wireless devices.
2. Select the name of camera SSID to be connected and then input the eight-digit number
password after WPA2-PSK on the camera.
3. Click the icon of the PIXPRO Remote Viewer App to enable the App.
Set up completion:
Once the App is connected to the camera, functional operation can be enabled on the smart
device.
Every AZ528 camera is shipped with a default factory Wi-Fi® password that is
randomized and unique to that camera and will not change unless you wish to reset
the password with a new randomly generated password. If you wish to change the
Wi-Fi® password in your AZ528 from the assigned, unique factory password, you
can do so by selecting and using the refresh setting. If “refresh” is selected, a new
random password will be generated and saved in the camera until changed or if you
use the “Reset” function. If you reset your AZ528 to the factory settings, then the
initial, randomly factory assigned and unique Wi-Fi® password will be restored to
your camera. (Please refer to Reset instructions on page 98).
42
Display of Wi-Fi® Connection Status
The Wi-Fi® has successfully connected but
App is not enabled:
Connected with device
MAC address: xx:xx:xx
Disconnect
The Wi-Fi® has successfully connected
and App is enabled:
Connected with App
XXXXX
Disconnect
ToDisconnectfromWi-Fi®:
Wi-Fi Mode
No
Disconnect from device?
Yes
• No: Keep Wi-Fi® connected and
back to previous page.
• Yes: Disconnect and back to Wi-Fi®
connection screen.
43
Settings
The name of this camera can be changed
under Wi-Fi® settings.
1. In other modes, press the button
and press the up/down button to select
. Press the button to enter the
menu.
2. Press the up/down button to select
and press the button or right arrow
button to enter the menu.
3. Press the up/down buttons to select
options to be adjusted and then press
the button to enter the menu.
DSC Device
MAC Address
PIXPRO AZ528_XXXX
38:67:93:XX:XX:XX
4. Press the button to confirm settings
and then skip the menu.
Disconnected from smart device Wi-Fi®:
Disconnected, please check wifi device
and try again.
Back
• Back: Back to the SSID interface.
44
DSC Device
The default name of DSC Device
is「PIXPRO AZ528_XXXX」. Change the
name of DSC device through typing.
Name between 1-18 Letters
PIXPRO AZ528_XXXX
Cancel
DSC Device
Save
#!?
ABCDEFGH IJ
KL
MNO
PQ RST
UV
WXYZ
A/a
4 567 90
123
Meanings of interface icons:
Icon Description
Backspace
$D
Switch between capital and
lowercase letters
Move the Cursor
#!?
Switch the symbol input
Space
MAC Address
Check the wireless MAC Address of this
camera.
App Operating Instructions
Refer to the "PIXPRO Remote Viewer User
Manual" located on the web:
http://kodakpixpro.com/Ameri-
cas/support/downloads.php
Americas / Europe
45
Scene Mode
The user can select an appropriate mode from the 13 scene modes according to the type
of environment you are shooting in. The camera then configures the most appropriate
settings for the best possible photos.
1. Rotate the mode dial to select .
2. Press the
AC
/
C
A
/
A
C
/
CA
buttons to select a scene, and press the
button to confirm.
Multi Exposure
3. To change to a dierent scene, please press the button and then the button and
finally the
AC
/
C
A
/
A
C
/
CA
buttons to reselect the scene.
46
Scene Description
Handheld Night Reduce blur when shooting low light/ illuminated scenes.
Cat/Dog
Rapidly identify pet (dog/cat), capture the dynamic moment
of pet.
Sunset For sunsets. Capture subjects in strong sunlight.
Fireworks For fireworks at night. The use of a tripod is recommended.
Multi Exposure
Suitable for shooting moving objects (as many as 7) in the
same background.
Sport
For fast-moving subjects. Capture sharp action shots without
blur.
Night Portrait
For portraits against night time scenery. The use of a tripod is
recommended.
Landscape
For landscapes and outdoor shots. Vivid reproduction of
greens and blues.
Portrait Most suitable for capturing people with focus on their face.
Snow For snowy scenes. Reproduces natural, clear, white scenes.
Children For kids and pets. Flash is disabled for eye protection.
Party
Suitable for taking indoor party photos, even under
complicated lighting conditions.
Panorama Mode
For shooting up to 360-degrees of landscape. This feature
allows you to capture a panoramic view that will have signifi-
cantly more content than a single photograph.
47
Handheld Night
Quickly take 4 photos below 8M (including 8M) and then overlap as a clear night
image.
Pet Mode
When a cat /dog face is detected, a white focus frame appears. The camera
will take a picture and save it regardless of whether the focus is successful (if
successful, there appears a green focus frame; if not, there is an orange frame).
At most, 10 dog/cat faces can be detected at one time.
Multi Exposure
Keep camera steady before shooting. Press and hold the Shutter button to take 7
photos continuously when it will stop automatically. To stop shooting, release the
Shutter button in the midway.
Objects shall be moved only from left to the right in order to be recorded. Objects
moving from other directions would not be recorded.
Shooting eect will be influenced if object is moving too fast or too close.
48
Panorama Mode
Follow the arrow while keeping the camera steady to seamlessly shoot an ultra-wide
scene of up to 360 degrees.
Follow the steps below:
1. Select the Panorama Mode ( ) and then press the button to confirm.
2. Press the
AC
/
C
A
/
A
C
/
CA
button to select a shooting direction. (Should
you not select the direction, the default shooting direction is "right"). 2 seconds later,
the camera is ready to take pictures. You can also press the button or press the
Shutter button halfway down to be ready to take pictures.
3. Compose your shot on the LCD and half press the shutter button to focus on the
subject. After focusing, fully press the down shutter button to take the first picture. At
this time, the process dialog of panorama mode stitching appears on the screen.
4. Move the camera according to the set direction. When the range of motion does not
exceed the range that the camera can detect, the progress dialog along the indication
arrow partially turns red. When it completely turns red, panorama mode shooting is
finished.
49
Panoramic image can be played back by the method of flash playing. Please see the
animation panoramic playback on page 70.
During shooting, the flash, self-timer, macro modes and exposure compensation are
not available. Focus adjustment is also not available at this time.
During panorama mode shooting, press the button to interrupt shooting and
save the current pictures taken. Press the
C
A
button to cancel shooting and
not to save the previously taken pictures.
During panorama mode shooting, when the moving direction of the camera is
wrong or the angle deviates from the internal settings, the LCD shows a warning
message「Improper alignment. Please try again.」and the current pictures taken
are saved.
50
Movie Mode
Switch to this mode to record videos.
Follow the steps below:
1. Rotate the mode dial to select , and it will enter the movie screen.
2. Press the button or the Shutter button to start recording.
00:00:06
x3.6
3. Press the button or the Shutter button again to stop recording, save it
automatically and then the camera will return to the movie screen.
In the recording process, you can rotate the zoom lever to zoom in or out on the
subject.
51
Settings under mode (unset state or
state after reset):
1. Turn the mode dial to select the
mode, and enter the setup screen, as
shown in the figure below:
Select one capture mode to define CS .
Auto Mode
Save
Exit
2. As shown in the picture, press the
A
C
/
CA
button to select a capture
mode that you want to define as ,
and press the button to enter the
shooting screen.
3. As shown in the picture, press the
button to confirm setting or to exit
without setting by turning the mode
dial.
Rotate the mode dial to skip .
Go to setting CS mode.
Yes
Or
For setting under other modes (use this
method to select a dierent custom
setting):
1. Select any mode or scene mode to be
stored.
2. Set your desired parameters in the
current mode.
Custom Settings
The user can store the frequently used shooting modes and parameters and switch to
this mode for quick adjustment.
52 5352
Custom Settings
Reset camera settings to
custom settings mode.
No
Yes
7. Rotate the mode dial to switch to .
8. The photo settings you stored the last
time are invoked.
When the mode is used for
the first time, there is no preset
parameter stored in the mode.
If you want to remove the parame-
ter setting of「Custom Settings」,
please see the reset function on
page 98 to operate.
3. Press the button and then the
AC
/
C
A
button to select ,
and press the button to enter the
menu.
4. Press the
AC
/
C
A
button to
select , and press the /
CA
button to enter the menu.
5. Press the
C
A
button to select
「Custom Settings」and then press the
/
CA
button to enter the menu.
Custom Settings
6. Select「Yes」to save or「No」to
cancel.
52 53
BASIC OPERATION
Your camera is equipped with two types of zoom functions: Optical Zoom and Digital
Zoom. Toggle the Zoom Lever of the camera to zoom in or out on the subject while
taking pictures.
Zoom Lever
When the Optical Zoom reaches the threshold as Digital Zoom, release and turn the
Zoom Lever to T to switch between the Optical Zoom and Digital Zoom.
Zoom Indicator
Using the Zoom Function
54 55
This function can be adjusted in mode, please follow the steps below to
configure the settings:
1. Press the
AC
button to enter the Focus menu.
Single-AF
2. Press the
A
C
/
CA
button to select the following 3 modes:
• Single-AF
The focus frame appears on the center of the LCD to focus on the subject.
• Multi-AF
The camera automatically focuses the subject in a wide area to find the focus
point.
• Object Tracking
Smart tracking of the object in motion under the focusing shooting.
3. Press the button to confirm the settings and exit the menu.
Once enabled, Object Tracking will only work when lens is focused on the object.
Focus Setting
54 55
The Macro Setting is ideal for shooting small objects or close-up photos. This mode
allows you to focus on subjects very close to the camera.
It can be adjusted in mode. Please follow the steps below to configure the
settings:
1. Press the
A
C
button to enter the Macro menu.
Macro O
2. Press the
A
C
/
CA
button to select the following 2 modes:
• Macro O
Select this option to disable Macro.
• Macro On
Select this option to make focusing on the object closer to the lens. (At the W
side, the shooting distance should be more than 1 cm).
3. Press the button to confirm the settings and exit the menu.
Macro Mode
56 57
Use this function to take pictures at pre-set intervals. The camera can be set to shoot
after 2 seconds, 10 seconds after pressing the shutter or when a smile is detected.
It can be adjusted in mode. Please follow the steps below to configure
the settings:
1. Press the
C
A
button to enter the
Self-Timer menu.
Self-timer O
2. Press the
A
C
/
CA
button to select
the following 4 modes:
• Self-Timer O
Disables the Self-Timer.
• Self-Timer 2 sec
A single picture is shot 2
seconds after the Shutter Button
is pressed.
• Self-Timer 10 sec
A single picture is shot 10
seconds after the Shutter Button
is pressed.
• Self-Timer Smile
Press the Shutter Button
and a picture will be taken
immediately after a smile is
detected.
3. Press the button to confirm the
settings and exit the menu.
When enabling the Self-Timer,
pressing the Shutter Button or
the
C
A
button will select the
highlighted Self-Timer option and
return to the shooting screen, and
keep the Self-Timer setting.
When enabling the smile detection,
pressing the Shutter Button or the
button will select the Self-Timer
smile option (if highlighted) and
return to the shooting screen,
and keeping the Self-Timer smile
setting.
Self-Timer Setting
56 57
The flash provides supplemental light for a scene. The flash is usually used when shoot-
ing against the light to highlight the object. It is also suitable for metering and shooting
in darker scenes to improve the exposure.
It can be adjusted in mode. Please follow the steps below to configure the
settings:
1. Press the Flash Button to pop up
the flash.
2
1
2. Press the
CA
button to enter the
Flash Settings Menu.
ܠ昘旅
⥺斿Ұ
Force O
3. Press the
A
C
/
CA
button to
select the following 6 modes:
• Force O
Flash is turned o.
• Flash Auto
Camera flash goes o automatically
based on existing light conditions.
• Fill Flash
The flash goes o when a picture is taken,
supplementing the existing light in a
scene and helping to eliminate shadows.
• Slow Sync.
This allows you to take pictures of people
at night that clearly show both your
subjects and the night time backdrop. The
use of a tripod is recommended when
shooting with this setting.
• Slow Sync. + Red-Eye
Use this mode for slow synchro shots
with red-eye reduction.
• Red-Eye Reduction
The camera emits a brief pre-flash
before the picture is taken to reduce
red-eye eects.
4. Press the button to confirm the
settings and enter the shooting screen.
Flash Mode
58 59
The white balance function allows adjustment of the color temperature for dierent light
sources.
It can be adjusted in mode. Please follow the steps below to configure the
settings:
1. Press button to enter the White
Balance menu.
ܠ昘旅
AWB
AWB
2. Press the
A
C
/
CA
button to select
the following 8 modes:
• AWB
• Daylight
• Cloudy
• Fluorescent
• Fluorescent CWF
• Incandescent
• Manual WB
(Fully press the Shutter button
to detect the white balance
value)
• Color Temp. (1900K~10000K)
Press the
AC
/
C
A
button to "Adjust the K value";
Press the
A
C
button to exit
the K value.
3. Press the button to confirm the
settings and exit the menu.
White Balance Setting
58 59
This function can be adjusted in mode. Please follow the steps below to
configure the settings:
1. Press the button to enter the
Continuous Shot menu.
Single
2. Press the
A
C
/
CA
button to select
the following 5 modes:
• Single
Capture a single shot only.
• Continuous Shot
Take several pictures at a time.
• Cont.Shot-High Speed (VGA)
For continuous shot with VGA
pixel.
• Cont.Shot-Fast (4M)
For continuous shot with 4M
pixels.
• Time-Lapse
Take pictures based on the
preset interval (30sec/ 1min/
5min/ 10min).
3. Press the button to confirm the
settings and exit the menu.
4. Press the Shutter button to start
continuous shooting.
In Continuous Shot mode, the flash
is automatically set to Force O in
order to achieve quick succession
of shots.
Continuous Shot
60 61
EV Adjustment
Set up to adjust the picture brightness. In
the case of a very high contrast between
the photographed object and the
background, the brightness of the picture
can be appropriately adjusted. (Adjustable
in Mode)
1/50
400 ISO
1/50
400 ISO
0.3 EV
0.3 EV
F2.8F2.8
The adjustable range of exposure value is
from EV -3.0 to EV+3.0.
The EV function menu of the camera
includes functions, such as EV (Exposure
Value) Adjustment, ISO, Shutter Adjust-
ment, Aperture Adjustment, etc. Using the
appropriate function settings can improve
your pictures.
Please follow the steps below to set:
1. Press the button to display the
settings screen.
2. Press the
A
C
/
CA
button to select
the setting options.
3. Press the
AC
/
C
A
button to
adjust the option values.
4. Press the button to complete the
setting and enter shooting mode.
EV Settings
6160 61
ISO Adjustment
ISO allows you to set the sensitivity of the
camera sensor. Please use a higher ISO
value in darker places and a lower value in
brighter conditions. (Adjustable in
Mode).
1/50
1/50
0.3 EV 400 ISO0.3 EV 400 ISO
F2.8F2.8
Options for ISO value: Auto, 100, 200,
400, 800, 1600 and 3200.
Shutter Adjustment
For shutter speed, the camera may
automatically set the aperture value
corresponding to the manually set shutter
speed so as to obtain a most suitable
exposure value. The movement of object
may be shown by adjusting the shutter
speed. High shutter value can help you
more clearly capture fast moving objects
while low shutter value can better show
the movement of objects. (Adjustable in
Mode).
-1.0 EV
1/50
400 ISO
1/50
400 ISO
0.3 EV0.3 EV
F2.8F2.8
62 6362 63
Aperture Adjustment
You can adjust the aperture size value.
Selecting a large aperture opening will
emphasize the point of focus and show
a blurry background and foreground. A
small aperture opening will keep both
the background and main object in clear
focus. (Adjustable in Mode)
400 ISO0.3 EV0.3 EV 400 ISO
1/50
1/50
F2.8F2.8
In shooting mode, press the button to
begin recording video.
After recording, press the button
again or press the Shutter Button to stop
recording. The camera will save the video
and return to the shooting screen.
Using Quick Recording
62 6362 63
The Image Color Setting allows you to select dierent color eects.
It can be adjusted in mode. Please
follow the steps below to configure the settings:
1. Press the button to select the Image
Color Setting Menu.
2. Press the
A
C
/
CA
button to select
the Image Color Setting options.
( ) represents options that are available
in Movie mode.
There are 20 Image Color options in photo shooting mode :
Normal ( ) Sepia ( ) Vignetting
Vivid ( ) Partial Color-Red ( ) Salon
Japan Style Partial Color-Blue ( ) Fish Eye
Italian Style Partial Color-Yellow ( ) Reflection
French Style Partial Color-Green ( )
4 Grids -
Stylish(2M)
Punk Negative Sketch
Black and White ( ) Dreamy
Normal
i Button Function Menu
64 6564 65
For viewing previously taken photos and videos on the LCD:
1. After pressing the button, the last photo or video clip taken will be displayed on
the LCD.
2. Press the
A
C
/
CA
button to scroll through the photos or video clips stored in the
internal memory or on the memory card.
3. To play a selected video clip, press the button to enter the Movie Playback mode.
An operation guide appears on the screen when playing back a video. Press the
appropriate buttons to enable the corresponding functions.
Mute
Under Playback
Paused
00:00:47 00:01:23
1
2
3
4
5
00:00:47 00:01:23
6
7
8
9
10
1
Increase Volume
6 Back to the beginning of the video
2
Pause
7 Play
3
Fast Forward
8 Frame Forward
4
Decrease Volume
9 Cancel playback
5
Rewind
10 Frame Backward
PLAYBACK MODE
Viewing Photos and Videos
64 6564 65
When in Playback Mode, rotate the Zoom Lever counter clockwise to the position to
display thumbnail images of the photos and videos on the screen.
W Zoom Out
T Zoom Out
1. Slide the Zoom Lever to switch between 3x3 and 4x4 thumbnails.
2. Press the
AC
/
C
A
/
A
C
/
CA
buttons to select a picture or video clip to
view and press the button to restore it to the original size.
When the icon appears, it means this is a video file.
Thumbnail View
66 67
When playing back photos, you can also use the Zoom Lever to zoom in on the photos 2
to 8 times.
1. Press the button to switch to Playback Mode.
2. Press the
A
C
/
CA
button to select a picture to be zoomed in on.
3. Rotate the Zoom Lever clockwise to to zoom in.
4. The screen will display the number of times and
area of the photo zooming operation.
5. Press the
AC
/
C
A
/
A
C
/
CA
buttons to navigate and select a part of the
image to be zoomed in on.
6. Press the button to return the image to its original scale.
Movie images cannot be magnified.
x2
Using Zoom Playback (for still pictures only)
66 67
In Playback Mode, press the
C
A
button to delete your photos and videos.
To delete photos or videos:
1. Press the button to switch to Playback Mode.
2. Press the
A
C
/
CA
button to select the photos and videos to be deleted.
3. Press the
C
A
button and the deletion screen is displayed.
Delete One
Exit
4. Press the
AC
/
C
A
button to select 「Delete One」or「Exit」and press the
button to confirm.
Erased photos/video clips cannot be recovered.
Please refer to page 91 for instructions on deleting more than one image at a time.
Deleting Photos and Videos
68 69
This setting allows you to view all the stored images as a slideshow.
1. Press the button to enter playback screen.
2. Press the button to enter slide option.
3. Press the
A
C
/
CA
button to select the slideshow playing option or「Cancel」
to return to the playback screen.
Cancel
4. Press the button to confirm the setting.
The Continuous Capture Group Playback may be displayed by slideshow.
Pictures rotate automatically during a slide show.
Slide playing function supports movie playing.
Slideshow
68 69
Cont.Shot-High Speed (VGA) and Cont.Shot-Fast (4M) can make continuous capture for
group image playback.
1. Press button to enter playback screen.
2. Press the
A
C
/
CA
button to select Cont. Group.
3. Press to start playback.
25
1/45
SD
03-2103-21 00:0000:00
9
2019
Continuous Capture Group Playback
70 7170 71
Panoramic Animation Playing is when full sized images are played in accordance with
the shooting direction. After playing, it will automatically return to the initial panorama
screen.
1. Press the button to enter Playback Screen.
2. Press the
A
C
/
CA
button to select animated panoramic photos.
3. Press the button to play in selected shooting direction.
In the process of Panoramic Animation Playback, press the
C
A
button ( ) to
stop playing and return to the Playback Screen.
Animation Panorama Play
70 7170 71
Photo Setup Menu
USING THE MENUS
Mode:
1. In Photo Shooting Mode, press the
button to enter the Photo Setup
menu.
2. Press the
AC
/
C
A
button
to select the item to be set.
3. Press the
A
C
/
CA
button to
select an option and press the
button to confirm.
Refer to the following pages for more
details about each setting.
Expo Metering
Use this setting to select the “target” size of
the camera’s field of view to be metered.
• AiAE (Artificial Intelligence AE):
Evaluates the light intensity at
multiple points in the frame and
automatically determines the best
value for the light meter.
• Spot: For metering the block
displayed in the center of the screen.
• Center: For metering the object in
the center of the screen.
It can be adjusted in all modes except
for Panorama Mode.
72
Image Size
The size setting refers to the image resolu-
tion in pixels. A higher image resolution
allows you to print that image in larger
sizes without sacrificing the image quality.
• Size: High quality printing
• Size: Full size printing
• Size: 16:9 display
• Size: Poster printing
• Size: A3 printing
• Size: A4 printing
• Size: 4”x 6” printing
• Size: E-Mail
The larger the number of recorded
pixels, the larger the file size and the
fewer files that can be saved on your
memory card.
73
OIS (Optical Image Stabilization)
This mode can help reduce photo blur
caused by unsteady hands and low light.
• OIS: O
• OIS: On
Use this image stabilization mode in
dark environments.
Shooting in a windy or unstable
environment (such as a moving
vehicle) may cause blurry images.
It is recommended to turn o OIS
when using a tripod.
Cont. AF (Continuous Auto-Focus)
Enable Continuous AF to be able to con-
tinuously focus automatically when taking
pictures.
• Cont.AF: O
• Cont.AF: On
74
Beautifier
Select an eect of the Face Beautifier Mode.
• Eect 1: Skin Soften
• Eect 2: Skin Soften+Eye
Brightening
• Eect 3: Skin Soften+Eye
Brightening +Eye
Enlargement
Please refer to P37 for more detailed
instructions.
HDR (High Dynamic Range)
Use this setting to control wide dynamic
image range when taking static pictures.
Photos with extreme contrast of
bright and dark areas will still maintain
distinguishable detail and depth. (Use
of a tripod is recommended with this
setting)
• HDR: O
• HDR: On
In a setting with extreme contrast
(very dark or very bright), this
function can be used to shoot
better photos.
75
Scene
Select the scene mode under the SCN
mode.
Night Portrait
Press SET To Select Scene
Please refer to P45 for more detailed
instructions.
Shooting menu in the Photo Shooting Mode
(O: Available X: Not Available)
Options
Photo Shooting Modes
O O O O O O
O O O O O O
X O O O O O
X O O O O O
X O O O O X
X X X X X O
76 77
Mode:
1. Press the button in Photo Shooting Mode and press the
AC
/
C
A
button to
select .
2. Press the button to enter the menu.
3. Press the
AC
/
C
A
button to select , and press the /
CA
button to
enter the menu.
4. Press the
AC
/
C
A
button to select the item to be set and press the /
CA
button to enter the menu.
5. Press the
AC
/
C
A
button to select an option and press the button to
confirm.
Photo Shooting Settings Menu
7776 77
Quality
The Quality Setting can be used to adjust
the image compression ratio.
Quality Best
Fine
Normal
There are three options for picture quality:
• Best
• Fine
• Normal
AF Assist Beam
In a darker environment, AF Assist Beam
can be turned on for better focus.
AF Assist Beam
O
On
Digital Zoom
Turn on or o the digital zoom.
Digital Zoom
O
On
78
Quick Review
This option enables a quick review of the
photos immediately after they are taken.
Each photo is displayed on the LCD based
on the selected time.
Quick Review
O
1 sec
2 sec
3 sec
There are 4 options:
• O
• 1 sec
• 2 sec
• 3 sec
Date Imprint
Include a Date/Time stamp on the photo
image.
Date Imprint
O
Date
Date/Time
• O
• Date
• Date/Time
79
Custom Settings
Custom Settings stores the current
photo shooting mode or scene mode
and its parameters. The stored mode and
parameters are retrieved in mode.
Custom Settings
Reset camera settings to
custom settings mode.
No
Yes
There are 2 options:
• No
• Yes
In mode, select「Custom
Settings」the camera will enter the
setting menu as shown below:
Select one capture mode to define CS .
Auto Mode
Save
Exit
80 81
Movie Menu
Mode:
1. Rotate the mode dial to select and
press the button to enter the Movie
menu.
Expo Metering: AiAE
2. Press the
AC
/
C
A
button to
select the item to be set.
3. Press the
A
C
/
CA
button to select
an option and press the button to
confirm.
Expo Metering (Exposure
Metering)
Use this setting to select the “target” size of
the camera’s field of view to be metered.
Expo Metering: AiAE
• AiAE (Artificial Intelligence AE):
Evaluates the light intensity at
multiple points in the frame
and automatically determines
the best value for the light
meter.
• Spot: For metering the block
displayed in the center of the
screen.
• Center: For metering the
object in the center of the
screen.
8180 81
Movie Size
Set the image resolution used during video recording.
Size: 1080p 30fps
The speed requirements for reading and writing high image pixel images to SD card are
as follows:
No. Image Pixel Frame Recommendation Recording time (4GB) About
1 1920x1080 * 30 Class 6 30 minutes
2 1280x720 * 60 Class 6 32 minutes
3 1280x720 * 30 Class 4 59 minutes
4 640x480 30 Class 4 106 minutes
5 640x480 120 Class 6 54 minutes
• Size: 1080p 30fps
• Size: 720p 60fps
• Size: 720p 30fps
• Size: 640x480 30fps
• Size: High Speed Movie
82 8382
* The longest recording time is 29
minutes at one time.
When recording in higher pixel
resolutions for extended periods of
time, this can cause the camera to
generate heat. This is not a camera
malfunction.
When the video format is set as
640x480 (120fps), shooting time
is 30 seconds, playback time is 2
minutes.
Sound recording is disabled when
640x480 120fps is chosen.
OIS (Optical Image Stabilization)
This mode can help reduce photo blur
caused by unsteady hands and low light.
OIS: O
• OIS: O
• OIS: On
Use this image stabilization mode in
dark environments.
Shooting in a windy or unstable
environment (such as a moving
vehicle) may cause blurry images.
It is recommended to turn o OIS
when using a tripod.
82 83
Movie Setting Menu
Mode:
1. Rotate the Mode Dial and select to enter the video recording screen.
2. Press the button, press the
AC
/
C
A
button to select , and press the
button to enter the Movie Setting menu.
Press SET To Enter
Menu
3. Press the
AC
/
C
A
button to select , and press the /
CA
button to
enter the menu.
4. Select the item to be set and press the /
CA
button to enter the menu.
5. Press the
AC
/
C
A
button to select an option and press the button to
confirm.
84 8584
Custom Settings
Custom Settings stores the current movie
mode and its parameters. The stored
mode and parameters can be retrieved
directly in mode.
Custom Settings
Reset camera settings to
custom settings mode.
No
Yes
Digital Zoom
Turn the Digital Zoom on or o.
Digital Zoom
O
On
84 85
Playback Menu
Mode:
1. Press the button to display the
playback screen and press the
button to enter the menu.
2. Press the
AC
/
C
A
button to
select the item to be set and press
the button to enter.
3. Press the
A
C
/
CA
button to
select an option and press the
button to confirm.
Normal Mode
Press SET To Confirm
Refer to the following pages for more
details about each setting.
Playback Mode
Select , and press the button to enter
the settings screen:
Normal Mode: Display all images.
• Normal Mode:
Display all images.
• Date Mode:
Arranged by date.
• Cont. Photo Mode:
Arranged by Cont. Photo Group.
The Date Folder is displayed in date
order based on camera's Date/Time
Settings.
If there is no Continuous Shot image file
in memory, Continuous Shot Playback
mode cannot be enabled.
86
HDR (High Dynamic Range)
With the HDR function, pictures that
are overexposed may be corrected to
optimize the highlights and lowlights
captured to more accurately represent
the actual scene.
Select , and press the button to
enter the settings screen:
HDR
HDR
Cancel
After using the HDR function, the
image will be saved as a new file and
the original file is still stored in the
memory.
Touch-Up
The playback beauty feature allows for
beautification using three individual
eects.
Select , and press the button to
enter the settings screen:
Red-Eye Reduction
Red-Eye Reduction
Skin Soften
Eye Brightening
Eye Enlargement
Cancel
Using the Face Beautifier Mode
allows you to select from one, two,
or all three eects combined.
87
Rotate
You can use this setting to change the
orientation of the picture.
Select , and press the button to
enter the settings screen:
Turn Right
Turn Right
Turn Left
Cancel
Videos and panoramic pictures
cannot be rotated.
The rotated picture file will replace
the original photo.
Resize
This setting allows you to resize a picture
to a particular resolution and saves it as a
new picture.
Select , and press the button to
enter the settings screen:
Resize to 1024x768
Resize to 1024x768
Resize to 640x480
Cancel
This function can only be used
to downsize photos to a lower
resolution.
Sizes of photos taken in panorama
mode or rotated cannot be adjusted.
88 8988
Color
This setting allows you to change the picture color eect. The file is saved as a new photo
and stored in memory together with the original photo.
Press the button to enter the settings screen:
Cancel
There are 19 options available:
Cancel Sepia Vignetting
Vivid Partial Color-Red Salon
Japan Style (8M) Partial Color-Blue Fish Eye
Italian Style (8M) Partial Color-Yellow Reflection
French Style (8M) Partial Color-Green 4 Grids - Stylish (2M)
Punk (4M) Negative (8M)
Black and White Dreamy
88 89
Mode:
1. Press the button to show the playback screen, press the button, press the
AC
/
C
A
button to select , and press the button to enter the menu.
2. Press the
AC
/
C
A
button to select , and press the /
CA
button to enter
the menu.
Protect
DPOF
Delete
Trim
3. Press the
AC
/
C
A
button to select the item to be set and press the /
CA
button to enter the menu.
4. Press the
AC
/
C
A
button to select an option and press the button to
confirm.
Refer to the following pages for more details about each setting.
Playback Settings Menu
90
Protect
To prevent any pictures or videos from being accidentally erased, use this setting to lock
one or all of the files.
Protect
One
Cont. Group
Reset
All
Reset
Date Folder
There are 5 options available:
• One: Lock the selected photo or video if it is unprotected; unlock the
selected photo or video if it is protected.
• Date Folder: Protect all photos in the Date Folder.
• Cont. Group: Protect all photos in the Cont. Photo Folder.
• All: Lock all photos or videos.
• Reset: Unlock all photos or videos.
91
Delete
You can delete one or all photo/video files.
Delete
One
Cont. Group
Date Folder
All
There are 4 options available:
• One: Delete one photo or video.
• Date Folder: Delete all photos in the Date Folder.
• Cont. Group: Delete all photos in the Cont. Photo Folder.
• All: Delete all photos or videos
The “ ” indicator means a file is protected. File protection must be removed first
before a file can be deleted.
Deleting files will cause DPOF settings to be reset.
When one photo in the Cont. Photo and Date Folders is protected, it will be kept but
any other photos will be deleted.
92 9392
Trim
The Trim Setting allows you to crop
photos and save them as new pictures.
1. Select「Yes」to confirm trim. Rotate
the zoom lever to select the aspect
ratio and press the
AC
/
C
A
/
A
C
/
CA
buttons to adjust the
part you want to trim.
2. Press the button and the「Save
change?」prompt appears. Select
「 」to change and save the
picture. Select「 」to cancel
changes and return to the trim
prompt screen.
The image cannot be clipped/
trimmed again once it has been
clipped to 640X480.
A trimmed picture cannot be
trimmed again.
DPOF (Digital Print Order Format)
The DPOF feature allows you to compile and
select a group of pictures that you would
like to print and will save your selection on
the memory card so that you can use the
SD memory card to print without having to
individually specify the photos you want to
print.
DPOF
One
All
Reset
The printer that supports DPOF is
needed for printing.
92 93
Mode:
1. Press the button in any mode, press the
AC
/
C
A
button to select , and
press the button to enter the menu.
2. Press the
AC
/
C
A
button to select , and press the /
CA
button to enter
the menu.
Sound Settings
Power Saver
Auto
Language
English
World Time
Home
Date & Time
2019.03.21 00:00
3. Press the
AC
/
C
A
button to select the item to be set and press the /
CA
button to enter the menu.
4. Press the
AC
/
C
A
button to select an option and press the button to
confirm.
Refer to the following pages for more details about each setting.
General Settings Menu
94
Power Saver
This setting allows you to save power and
get the maximum possible running time
for your camera’s batteries. It turns the
LCD and camera o automatically after a
certain period of inactivity.
Power Saver
Auto
Normal
Best
• Auto
• Normal
• Best
Power
Saver
LCD power o
time
Turn o time
Auto 3 min 5 min
Normal 1 min 3 min
Best 30 sec 1 min
Sound Settings
With this setting you may adjust the sound
volume.
Press the
A
C
/
CA
button to adjust
the volume and press the button to
confirm your setting.
Sound Settings
Volume
Back
95
Language
Refer to the “Reset your language” section
on page 25.
Zone
The Zone setting is a useful function for
your overseas trips. This feature enables
you to display the local time on the LCD
while you are abroad.
1. Press the
AC
/
C
A
button to
select the departure place ( ) and
destination ( ) fields.
2. Press the
A
C
/
CA
button to select
a city located in the same time zone as
that of the field. Press the button to
confirm settings.
Date/Time
Refer to the “Reset Date/Time” section on
page 26.
LCD Brightness
Use this setting to adjust the brightness of
your LCD.
Press the
AC
/
C
A
button to adjust
the brightness of screen and press the
button to confirm.
LCD Brightness Normal
+2
-2
+1
-1
Normal
96 97
Mode:
1. Press the button, press the
AC
/
C
A
button to select and press the
button to enter the menu.
2. Press the
AC
/
C
A
button to select and press the /
CA
button to enter
the menu.
3. Press the
AC
/
C
A
button to select the item to be set and press the /
CA
button to enter the menu.
Format
File Numbering
Copy to Card
Reset
FW Version X.XX
4. Press the
AC
/
C
A
button to select an option and press the button to
confirm.
Refer to the following pages for more details about each setting.
File Settings
9796 97
Format
Please note: formatting enables you to
delete all contents in the memory card
and built-in memory, including protected
photo and movie files.
Format
Doing so will clear all data.
No
Yes
If you select「Yes」the camera will
format its memory.
If there is no memory card in the
camera, the built-in memory will be
formatted; if there is a memory card,
only the card will be formatted.
Copy to Card
Use this setting to copy the files stored in
the built-in memory to a memory card.
Copy to Card
Copy files from built-in memory to
the memory card.
No
Yes
If there is no card available in the
camera, this function will not be
displayed.
98
Reset
Use this setting to restore the camera to
its original default settings.
Reset
Reset camera settings to factory defaults.
No
Yes
File Numbering
After you take a picture or video clip,
the camera will save it with a sequential
number. You can use this to reset the file
numbering to 1.
File Numbering
Create a new directory and
reset the file number.
No
Yes
99
FW Version
Use this setting to view the current
camera firmware version.
FW Version
Current Ver:1.XX
Back
When there is a new firmware version in
the memory card, select「Yes」to update.
FW Version
Current Ver:1.XX
New Ver.:2.XX
Cancel
Yes
Update Firmware?
NEW CAMERA OWNER / IMPORTANT INFORMATION
Thank you for purchasing your new KODAK PIXPRO AZ528 Astro Zoom camera. In an
eort to provide you with the most up to date benefits and features of the AZ528, we
strongly encourage you to register your new camera on our website:
https://kodakpixpro.com/support/product-registration
Doing so will keep you informed of important updates, including firmware, features
and other important information that pertain to the AZ528. Your information is always
kept secure, is encrypted and is never sold, shared or used for any purposes other than
for AZ528 camera specific notifications, unless you opt-in to receive other types of
communications during the registration process.
100 101100 101
CONNECTION SETTINGS
Mode:
1. Press the button, press the
AC
/
C
A
button to select and press the
button to enter the menu.
2. Press the
AC
/
C
A
button to select and press the /
CA
button to enter
the menu.
3. Press the
AC
/
C
A
button to select the item to be set and press the /
CA
button to enter the menu.
US
BP
C
TV-System NTSC
4. Press the
AC
/
C
A
button to select an option and press the button to
confirm.
Refer to the following pages for more details about each setting.
100 101100 101
You can use the Micro USB cable to connect the camera and copy (transmit) photos to a
computer, printer or other device.
Setting the USB Mode
The camera’s Micro USB port can be set to connect with either a computer or a printer.
The following steps will allow you to ensure that the camera is correctly configured to
connect with a PC.
1. Press the
AC
/
C
A
button to select「USB」and press the /
CA
button to
enter the menu.
2. Press the
AC
/
C
A
button to select「PC」and press the button to confirm.
USB
PC
Printer
Connecting to a Computer
102 103102
Transferring files to your computer
The computer will automatically detect the camera as a removable drive. Double-click
the My Computer icon on the desktop to locate the removable drive and to copy folders
and files in the drive to a directory on your PC as you would copy any typical folder or
file.
Follow the steps below to connect the camera to a computer.
1. Make sure the computer is turned on.
2. Connect one end of the supplied Micro USB cable to the Micro USB port on your
camera.
3. Connect the other end of the cable to an available USB port on your computer.
4. After the transmission is complete, disconnect the Micro USB cable according to the
instructions specifying how to safely remove USB devices.
102 103
To find out if a printer is PictBridge
compatible, simply look for the PictBridge
logo on the packaging or check the
owner’s manual for specifications. With
the PictBridge function on your camera,
you can print the captured photos directly
to a PictBridge compatible printer using
the supplied Micro USB cable, without the
need for a PC.
Setting the USB Mode
The camera’s Micro USB port can be set
to connect with either a PC or a Printer;
the following steps will ensure that the
camera is correctly configured to connect
with a Printer.
1. Press the
AC
/
C
A
button to
select「USB」and press the /
CA
button to enter the menu.
2. Press the
AC
/
C
A
button to
select「Printer」and press the
button to confirm.
USB
PC
Printer
After the camera is reset, it will
switch to PC mode automatically
from USB mode.
See “PictBridge“ section on page
105.
Connecting to a PictBridge Compatible Printer
PictBridge technology allows printing of the photos saved in the memory card by the
printer.
104 105104
If the camera is not connected to a
PictBridge compatible printer, the
following error message will appear on
the LCD.
Connection Failed!
The error message above will
also appear if the USB mode is
set incorrectly, in which case you
should disconnect the Micro USB
cable, check the USB mode settings,
ensure that the printer is turned on,
and then try connecting the Micro
USB cable again.
1. Make sure the printer is turned on.
2. Connect one end of the supplied Micro
USB cable to the Micro USB port on
your camera.
3. Connect the other end of the cable to
the USB port on the printer.
Connecting to your Printer
104 105
After setting the USB mode to Printer, the
PictBridge menu will appear.
PictBridge
Print (with Date)
Exit
Print (without Date)
Print Index
Print DPOF Images
Press the
AC
/
C
A
button to select
a menu item and press the /
CA
button to enter the item.
Refer to the following sections for more
detailed information on each setting.
Using the PictBridge Menu
Print (with Date)
If you have set the date and time on
your camera, the date and time will be
recorded and saved with each photo you
take.
1. In the PictBridge menu, select「Print
(with Date)」and the screen as shown
below appears.
01
Back
2. Press the
A
C
/
CA
button to select
a photo to be printed.
106
3. Press the
AC
/
C
A
button to
select the number of copies for the
currently displayed photo.
4. Press the button and the following
screen will appear.
Print (with Date)
Cancel
Yes
5. Select「Yes」and press the button
to confirm printing; select「Cancel」
andpress the button to cancel
printing.
Print (without Date)
Use this setting to print the photos
without dates on them.
1. In the PictBridge menu, select「Print
(without Date)」and the screen as
shown below appears.
01
Back
2. Press the
A
C
/
CA
button to select
a photo to be printed.
3. Press the
AC
/
C
A
button to
select the number of copies for the
currently displayed photo.
107
4. Press the button and the following
screen will appear.
Print (Without Date)
Cancel
Yes
5. Select「Yes」and press the button
to confirm printing; select「Cancel」
andpress the button to cancel
printing.
Print Index
You can print all photos in the camera via
this function.
1. In the PictBridge menu, select「Print
Index」and the screen as shown below
appears.
Yes
Print Index
Cancel
Yes
2. Select「Yes」and press the button
to confirm printing; select「Cancel」
andpress the button to cancel
printing.
108 109108
Print DPOF Images
To use DPOF printing, you must select
your photos for printing using the DPOF
settings beforehand. See “DPOF” section
on page 92.
1. In the PictBridge menu, select「Print
DPOF Images」and the screen as
shown below appears.
Print DPOF Images
Cancel
Yes
2. Select「Yes」and press the button
to confirm printing; select「Cancel」
andpress the button to cancel
printing.
Exit
Select「Exit」to exit the PictBridge menu.
At this time, the message「Remove USB
Cable!」appears on the screen.
Remove USB Cable!
Disconnect the Micro USB cable from the
camera and printer.
108 109
You can use the AV cable (which should be purchased separately) to connect the camera
and the television for setting up the video output. Connect one end of the AV cable to
Micro USB/AV port of the camera, and connect the other end to AV-OUT port of the tele-
vision. To adjust the format of the video output system according to your requirements:
1. Press the
AC
/
C
A
button to select「TV-System」and press the /
CA
button to enter the menu.
2. Press the
AC
/
C
A
button to select[NTSC]or[PAL]and press the button to
confirm.
TV-System
PAL
NTSC
NTSC: English, Chinese (Traditional), Japanese, Korean, Vietnamese
PAL: German, Spanish, Italian, Chinese (Simplified), Portuguese, Swedish,
Danish, Finnish, Indonesia, Norwegian, Dutch, Turkish, Polish, Thai,
Croatian, Czech, Arabic, Hindi, Hungarian, Greek, Russian, French
Video System
110 111
Design and specifications are subject to change without notice.
Sensor
Type 1/2.3”BSI CMOS
Eective Pixels 16.35 Megapixels
Total Pixels 16.76 Megapixels
Lens
Focal Length 4.3mm (Wide) — 223.6mm (Tele)
35mm film
equivalent
24mm (Wide) — 1248mm (Tele)
F number F2.8 (Wide) ~ F5.6 (Tele)
Lens Construction 13 groups 15 elements
Optical Zoom 52x
Optical Zoom
Normal: (Wide) 60cm ~ ∞, (Tele) 300cm ~ ∞;
Macro: 1cm ~ ∞ (Wide Only)
Autofocus System TTL Autofocus
Anti-Handshake Optical Image Stabilization
Digital Zoom 4x Digital Zoom (Combined Zoom: 208x)
APPENDICES
Product Specifications
111110 111
Number
of
Recording
Pixels
Still
(4:3)
16MP: 4608 X 3456
10MP: 3648 X 2736
5MP: 2592 X 1944
3MP: 2048 X 1536
0.3MP: 640 X 480
(3:2)
14MP: 4608 X 3072
(16:9)
12MP: 4608 X 2592
2MP: 1920 X 1080
Movie
1920 X 1080 (30fps), 1280 X 720 (60fps/30fps), 640 X 480
(30fps), High-Speed Movie: 640 X 480 (120fps)
Image Compression Best, Fine, Normal
DCF, DPOF (Ver1.1)
Support
Yes
File Format
Still
Exif 2.3 (JPEG)
Movie MOV [Image: H.264; Audio: Linear PCM (Stereo)]
Shooting Modes
Auto Mode, Program AE, Shutter priority, Aperture priority,
Manual Mode, Face Beautifier, Wi-Fi Mode, Scene Mode, Movie
Mode, Custom Settings
Scene Mode
Handheld Night, Pet Mode, Sunset, Fireworks, Multi Exposure,
Sport, Night Portrait, Landscape, Portrait, Snow, Children, Party,
Panorama Mode
Detection Features Face, Smile, Blink, Cat, Dog
Photo Touch-up Red-Eye Reduction, Skin Soften, Eye Brightening, Eye Enlargement
HDR Yes
112
Scan Panorama Up to 360°
LCD 3.0 inch (460k Pixels)
Image Auto Rotation Yes
ISO Sensitivity Auto, ISO100/200/400/800/1600/3200
AF Method
Single AF, Multi-AF (TTL 25-point), Object Tracking ,
Face-Detection
Exposure Metering
Method
Artificial Intelligence AE (AiAE), Center-Weighted Average,
Spot (Fixed to Center of Frame), Face AE
Exposure Control
Method
Program AE (AE-Lock Available), Shutter Prior AE, Aperture
Prior AE
Exposure
Compensation
±3 EV in 1/3 Step Increments
Shutter Speed 1/2000 ~ 30 Seconds
Continuous Shot Yes
Playback Modes
Single, Index (9/16 Thumbnails), Slide Show, Date,
Continuous Shooting, Zoom (Approx. X 2 ~ X 8)
White Balance Control
AWB, Daylight, Cloudy, Fluorescent, Fluorescent CWF,
Incandescent, Manual WB, Color Temp. (1900K ~ 10000K)
Flash
Flash Method Pop-up (Manual)
Flash Modes
Force O, Flash Auto, Fill Flash, Red-Eye Reduction, Slow
Sync., Slow Sync.+Red-Eye Reduction
113
Recording Media
Internal Memory: Approx. 8MB
SD/SDHC Card (Up to 32GB Support) [MMC Card Not
Supported]
Multi-Language
Support
27 Languages
Jacks AV-OUT/USB 2.0 (Micro 5 pin USB)
Wi-Fi Yes (802.11b/g/n)
Remote Viewfinder Yes (via smart device)
Power
Rechargeable Li-ion Battery LB-060, 3.7V 1100mAh,
In-Camera Charging
Shooting Capability
(Battery Performance)
Approx. 240 Shots (Based on CIPA Standards)
Operation
Environment
Temperature: 0 ~ 40°C, Humidity: 0 ~ 90%
Dimensions (W X H
X D)
Approx. 121.3 X 85.8 X 97.5mm (Based on CIPA Standards)
Weight Approx. 508g (Body only)
114 115
Prompts and Warning Messages
Message Description Action
Warning! Battery
exhausted.
Camera battery is depleted. It is a
warning indicating that the camera
is going to shut o.
Charge battery or replace
with a charged battery.
Lens obstruction,
Re-start Camera.
The lens is jammed or some
foreign object is preventing the
lens from functioning properly.
Turn o the camera and
restart it to reset the lens.
Suggest using
tripod.
When continuous exposure is
enabled, this prompt message is
displayed when the photo shooting
screen is displayed for the first
time.
The message will
disappear after 2 seconds.
Built-in memory
error!
An error has occurred in the built
in memory.
Try shutting o the
camera and turning it on
again.
Improper alignment.
Please try again.
The oset is too big for panorama
shooting.
Keep the camera steady
while shooting to maintain
alignment.
Warning! Do not
turn o your camera
during update!
The message appears during the
firmware update process.
The message disappears
after the camera update
and restart.
115114 115
Message Description Action
Remove USB
Cable!
Indicates that you can
disconnect the Micro USB
cable.
The message disappears after
you disconnect the Micro USB
cable.
Connection Failed!
Failure to connect to PC,
printer, or TV-system.
Remove cable, reinsert cable,
and retry connection.
Write Protect ! The SD card is locked.
Turn o camera and remove SD
card. Slide tab on the side of
card to unlock.
Card Full !
The memory of the SD card
is full.
Either delete photos or videos
to create room on the card, or
replace with another card that
has available memory.
Memory Full !
The camera’s internal memory
is full.
Erase files or insert a memory
card that has available memory.
116
Message Description Action
Card Error !
The card cannot be recog-
nized after being formatted.
Check that the SD card is
compatible with the camera.
Card is not
formatted.
An error has occurred with
the memory card.
Format the memory card. This
will erase all data on the card; be
sure to copy the data from the
card onto another device if you
wish to keep it.
Slow access
When a card lower than
Class 4 is recording movie
above HD, the writing speed
will be slower and the re-
cording will not continue.
Replace SD card with a Class 4
or higher card.
Cannot write to
SD card.
The camera cannot write to
the SD card.
Turn o the camera. Remove and
reinsert the SD card and turn the
camera on to try again.
Check if the SD card is in a locked
position, or if the memory is full.
No Red-Eye
Detected!
No red-eye is detected when
selecting Red-Eye Removal
in Playback Touch-up.
The message will disappear
after 2 seconds and return to the
touch-up menu.
This image cannot
be edited.
The file format does not sup-
port editing or the edited
file cannot be edited again.
The message will disappear
after 2 seconds and return to the
original image.
117
Message Description Action
Exceeded
maximum
folder number.
The folder number in the card exceeds the
maximum folder number (999).
Copy the data to your
PC, and format the
memory card.
Too many
pictures for fast
processing.
During Playback by Date, the images
exceed specifications so it is not possible
to play by date.
The message will dis-
appear after 2 seconds
and return to Thumb-
nail 3x3 mode.
Unable to
recognize files.
The format of the file viewed is not sup-
ported or the file is damaged and cannot
be recognized properly.
This message will only
disappear after the file
is deleted.
No Picture!
When the play button is pushed and there
are no files on memory card or in camera.
The message will dis-
appear after 2 seconds
and return to previous
screen.
No continuous
group file.
When the camera switches from Playback
Mode to Cont. Playback Mode, and there
are no continuous group files, this mes-
sage will be displayed.
The message will dis-
appear after 2 seconds
and return to Thumb-
nail 3x3 mode.
Protected!
Undeletable!
The file is protected and cannot be de-
leted.
Unlocked file under
“Protect”, and make
sure SD card is un-
locked.
118 119
Troubleshooting
Problem Possible Causes Solution
Camera does not
turn on
The battery has been
depleted.
The battery is not inserted
correctly.
Recharge the battery.
Correctly reinstall the battery.
Camera turns o
suddenly during
operation
The batteries have been
depleted.
Recharge the battery.
Make sure the camera is actually
shutting o and not entering
Power Save Mode, where the
LCD will turn o after the camera
has been idle for a period of
time.
The picture is blurry
Camera shakes while taking
a picture.
Turn on OIS feature.
Please use tripod for high
magnification (above 15X)
optical zoom. If you are holding
the camera, be sure to use
both hands.
Images and video
files cannot be
saved
The SD memory card is full.
The memory card is locked.
Use another memory card or
delete unnecessary files.
Unlock the memory card.
119118 119
Problem Possible Causes Solution
Images will not print
from the connected
printer
The camera is not connected
to the printer correctly.
The printer is not PictBridge
compatible.
The printer is out of paper or
ink.
The printer paper is jammed.
Check the connection
between the camera and
printer.
Use a PictBridge
compatible printer.
Load paper into the printer
or replace the ink cartridge
in the printer.
Remove the jammed
paper.
Saving data to
memory card is
slow
Using a memory card below
Class 4 may result in slower
recording times.
Use a memory card
with write Class 4 or
higher than 4 to improve
performance.
Cannot write to the
memory card
The SD memory card has
been locked.
Release the write lock
of the memory card or
replace with another card.
Too many movies
to process
The number of pictures or
folders in the memory card
exceed the specifications, so
the playback of data folder
can not be displayed.
Delete unwanted files.
The flash icon
appears on the LCD
Current shooting environment
requires flash.
Turn on flash.
120
If you choose to change the factory assigned, random Wi-Fi® password on your
AZ528 camera, please be sure to update and enter the new randomly assigned
password on your smart device. Some smart devices will automatically remember
and save any previously entered Wi-Fi® password. Be sure to clear the old password
on your smart device manually before attempting to connect the AZ528’s Wi-Fi® to
your device. (Depending upon your smart device make and model, operation may
vary, so please refer to your smart device user manual and instructions.
1
2
3
1
2
iOS™ Example Android™ Example
When shooting with stacked filters attached, the corners of the photo may turn dark
(Vignetting eect) because the filter holder blocks light from reaching the camera
image sensor; especially, at wide angle zoom control settings. Please take test shots
and review the results when using stacked filters.
121
Memory Card Compatibility
Refer to the chart below for compatible types of SD cards (√: Compatible X: Not
Compatible)
micro
SD
micro
SDHC
micro
SDXC
Conversion
adapter to
SD card
SD SDHC SDXC
Format FAT12, 16 FAT32
exFAT -
FAT12, 16 FAT32
exFAT
Capacity Up to 2GB 4~32GB 64GB~2TB
-
Up to 2GB 4~32GB 64GB~2TB
Compati-
bility
X X X
√ √ √
X
It indicates that the writing speed class will be displayed on the memory card.
Use a memory card with the appropriate writing speed for the video recording mode to
be recorded. (O: Recommended X: Not recommended)
Speed
Class
UHS
Speed
Class
Video
Speed
Class
Video Recording
4K FHD HD VGA
90MB/sec
V90
O O O O
60MB/sec
UHS-III V60
O O O O
30MB/sec
UHS-I V30
O O O O
10MB/sec
Class 10 V10
O O O O
6MB/sec
Class 6 V6
X O O O
4MB/sec
Class 4
X X X O
2MB/sec
Class 2
X X X O
Ver6.0
© 2022 JK Imaging Ltd. All Rights Reserved.
The Kodak and Kodachrome, Kodacolor and Ektachrome trademarks, logo and trade dress are used under license from
Eastman Kodak Company.
All other logos, products or company names that are referred to in this document are trade names, trademarks or
registered trademarks of their respective owners and holders. The owners and holders are not ailiated with JK
Imaging Ltd., our products or our website.
JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
kodakpixpro.com
Made in Myanmar
Document No/Sequence: U.DIS.0062.1222.en.06
