Sencor SVC 8776BK 4-in-1 Stick Vacuum Cleaner User Manual

VERSATILE CORDLESS VACUUM

CLEANER 4 IN 1

Translation of the original manual

SVC 8776BK

13 12 11 10

1 2

5 6

8 9 10 11 12 13 14

25 24

15 16

21 22

C1 C2

G1 G2

G3 G4

G5 G6

G7 G8

- 1 -

Revision 12/2024

Versatile Cordless Vacuum Cleaner 4 in 1

User’smanual

Important safety instructions

READ CAREFULLY AND STORE FOR FUTURE USE.

• This vacuum cleaner may be used by children 8years of

age and older and by persons with physical, sensory, or

mental impairments or by inexperienced persons, if they

are properly supervised or have been informed about

how to use this vacuum cleaner in asafe manner and

understand the potential dangers.

• Children must not play with the vacuum cleaner. Cleaning

and maintenance performed by the user must not be

performed by unsupervised children.

WARNING:

This appliance contains a UV-C light. Do not look

into the light of the UV-C lamp and do not point the

UV-C lamp at eyes.

• If the power adapter is damaged, it must be replaced with

an original type. For areplacement power adapter, please

contact an authorised service centre. It is forbidden to use

the appliance if it has adamaged power adapter.

- 2 -

Revision 12/2024

WARNING:

Avoid coming into contact with the rotating parts of

the vacuum cleaner‘shand accessories. There is

arisk of getting caught on these parts and possible

injury.

Only use the vacuum cleaner with the original power

adapter, charging base and accessories that were

supplied with it.

• This vacuum cleaner is designed for use in households, offices and similar types of areas. Do not use in industrial surroundings.

• Do not expose the vacuum cleaner to direct sunlight and do not place it near an open fire or appliances that are asource of heat.

• Before connecting the adapter to apower socket, check that the technical details on its rating label match the electrical voltage in the power socket.

• Make sure the adapter power cord is not touching ahot surface or sharp objects. Position the adapter power cord so that it will not be tripped over.

• Never submerge the vacuum cleaner, the charging base and the power adapter in water or any other liquid and do not wash under running water.

• Before turning on the vacuum cleaner, make sure that all the inflow and outflow filters are installed in their place.

• When the vacuum cleaner is running, ensure that the air outlets and the suction hole are not blocked.

• Do not use the vacuum cleaner to vacuum the following items:

– smouldering cigarettes, burning items, matches or embers;

– water and other liquids;

– flammable or volatile materials;

– items, e.g. broken glass, needles, pins, etc.;

– flour, wall plaster, cement and other building materials;

– larger pieces of paper or plastic bags, which can easily block the suction hole.

• Vacuuming of some types of floors or floor surfaces can create an electrostatic discharge, which presents no danger to the user.

• Always turn off the vacuum cleaner when leaving it without supervision, after finishing using it and before cleaning it.

• Disconnect the power adapter from the power socket before cleaning it and after it has finished charging.

• Disconnect the power adapter from the power socket by pulling on the plug, never pull on the power cord. Otherwise, this could damage the power

adapter or the socket.

• If the power adapter is damaged, it must be replaced with an original type. For areplacement power adapter, please contact an authorised service

centre.

• Do not use the vacuum cleaner if it is not working correctly if it has been damaged or has been submerged in water.

• Do not repair the vacuum cleaner yourself or make any adjustments to it. Have all repairs performed at an authorised service centre. By tampering

with the appliance, you risk voiding your legal rights arising from unsatisfactory performance or quality warranty.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

EXPLANATION OF SYMBOLS PLACES ON THE PRODUCT OR IN THE ACCOMPANYING DOCUMENTATION

This product meets all the basic requirements of the applicable EU directives.

This symbol on products or original documents means that used electric or electronic products must not be added to ordinary municipal

waste.

Safety class for electrical shock protection:

Class II – Electrical shock protection is provided by double or heavy-duty insulation.

House symbol (domestic use)

The product is intended for household use only. The product is not intended for outdoor use.

Thoroughly read the all the instructions before using the product.

DISPOSAL OF BATTERIES

Prior to disposing of the product or handing it over at aspecialised collection facility, it is necessary to ensure that the battery is removed.

Before removing the battery, it is necessary to start the vacuum cleaner and wait until it is completely flat. The battery contains

environmentally damaging substances and therefore does not belong in standard household waste. Their correct disposal will be

performed by the respective collection facility.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

- 3 -

Revision 12/2024

• Thank you for purchasing aSENCOR brand product and we hope that

you will be happy with it.

• Prior to using this appliance, please read the user'smanual

thoroughly, even in cases, when one has already familiarised

themselves with previous use of similar types of appliances. Only use

the appliance in the manner described in this user’smanual. Keep

this user'smanual in asafe place where it can be easily retrieved for

future use.

• We recommend saving the original cardboard box, packaging

material, purchase receipt and responsibility statement of the vendor

or warranty card for at least the duration of the legal liability for

unsatisfactory performance or quality. In the event of transportation,

we recommend that you pack the appliance in the original box from

the manufacturer.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DESCRIPTION OF THE VACUUM CLEANER

DESCRIPTION OF THE MOTOR UNIT

A1 Output hole of the motor unit

A2 Dust container release button

A3 Inflow filter cover

A4 Inflow filter

A5 Speed button

A6 On / Off button

A7 Handle

A8 Charging battery light

A9 Power adapter socket

A10 Rechargeable battery

A11 Outer filter

A12 Tube filter

A13 Transparent dust container

A14 Release button of the dust

container bottom for quick

removal of dirt

A15 Battery release button

A16 Lock to release the motor unit

A17 Metal tube

A18 Floor nozzle

A19 Lock to release the floor

nozzle

A20 Protective cover

A21 LED diodes

A22 Lock

A23 Side cover to remove the

rotary brush

A24 Castors

A25 Electric rotary brush

DESCRIPTION OF THE ACCESSORIES

B1 Cat&Dog motorised mini

brush

B2 Lock to release the mini brush

B3 Protective cover

B4 Rotary brush lock

B5 UV-Clight

B6 Castors

B7 Rotary brush

B8 Combined crevice nozzle

B9 Crevice nozzle brush

B10 Button to slide out / back the

brush

B11 Combined attachment for

upholstery and furniture

B12 Attachment brush

B13 Button to slide out / back the

brush

B14 Soft brush

B15 Articulated connector

B16 Flexible hose

B17 Holder

B18 Power adapter

B19 Wiping attachment

B20 Water tank

B21 Tank lid

B22 Water control button

Not shown

Wall plug

Screws

Removable Velcro zip sleeve

(6 pcs)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ASSEMBLY AND DISASSAMBLY OF THE VACUUM CLEANER

1. ASSEMBLY AND DISASSAMBLY OF THE STICK VACUUM

CLEANER

Place the floor nozzle on aflat, dry and stable surface. Attach the

tube to the floor nozzle so that the connectors at the back of the floor

nozzle are aligned with the holes inside the tube – see picture C1.

Push the tube until it clicks.

Insert the output hole of the motor unit into the tube so that the

connectors at the back of the tube are aligned with the holes inside

the outlet hole – see picture C2.

When you need to disassemble the stick vacuum cleaner, press

the lock A16 to release the motor unit. Then press the lock A19 to

release the floor nozzle.

2. ASSEMBLY AND DISASSEMBLY THE WIPING ATTACHMENT

Assemble the stick vacuum cleaner – see the previous part of the

manual.

Attach the sleeve to the bottom surface of the attachment B19 and

put the attachment on the floor.

Place the vacuum cleaner above the wiping attachment B19 so

that the protrusion on the attachment is aligned with the hole on

the bottom surface of the floor nozzle. Gently push the vacuum

cleaner until it clicks. That signalizes the correct connection of the

attachment to the floor nozzle.

When you need to remove the attachment from the vacuum

cleaner, carefully hold the attachment by one hand and pull the

vacuum cleaner upwards until the floor nozzle is released from the

attachment.

3. ASSEMBLY AND DISASSEMBLY OF THE VACUUM CLEANER

WITH ACCESSORIES

To ensure perfect cleaning of your home, you can attach any of the

supplied accessories to the output hole of the motor unit. Simply

remove the accessory by pulling it out of the output hole of the

motor unit. Press the lock B2 first to remove the mini brush.

1. Cat&Dog motorised mini brush and UV-C disinfection light

Cat&Dog motorised mini brush is the ideal helper for removing

animal fur, hair, etc., while at the same time being suitable for

vacuuming hard-to-reach places. Its use is not limited to the

home and can be used for vacuuming the car. It quickly and

effectively removes hair, animal fur and other materials from car

seats, upholstery, pillows, and other textile surfaces and at the

same time disinfects surfaces.

Warning:

This appliance contains a UV-C light. Do not look into

the light of the UV-C lamp and do not point the UV-C

lamp at eyes.

2. Combined crevice nozzle

It is suitable for vacuuming hard to reach places (e.g., window

frames, corners, libraries, spaces between mattresses,

upholstery, etc.). Press and hold the B10 button and move

forward to slide the brush out. Press B10 button and move

backward to slide the brush back.

3. Combined attachment for upholstery and furniture

The attachment is suitable for vacuuming surfaces, such as

furniture or upholstery. Press and hold the B13 button and move

forward to slide the brush out. Thanks to the soft bristles, the

attachment is ideal for removing dirt from fine surfaces, such as

net curtains, curtains, etc. Press B13 button and move backward

to slide the brush back.

4. Soft brush

It is ideal for vacuuming dirt and dust from fragile objects,

libraries, walls, blinds, etc.

5. Articulated connector and flexible hose

Attach the articulated connector or flexible hose to the output

hole when you need to extend the reach of the used accessory,

e.g., you need to vacuum dust on the wardrobe.

Note:

The picture D shows the possibilities how to combine the

accessories.

Versatile Cordless Vacuum Cleaner 4 in 1

User'smanual

- 4 -

Revision 12/2024

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CHARGING THE BATTERY

The battery can be charged either installed in the motor unit or removed.

Insert the connector of the power adapter into the socket A9 and insert the

adapter plug into the power socket.

The light A8 turns red. The charging time usually takes 4-5hours. The

battery is charged once the light A8 turns green. Then disconnect the

connector of the power adapter from the socket A9 and remove the plug

from the power socket.

When you finish cleaning and have cleaned out the appliance, place it

back into the stand so that the battery can recharge.

Keep the charging adapter plugged in permanently. The electronics

in the appliance control the battery charging process and ensure that

it is always optimally charged. When the battery is fully charged, the

electronics interrupt the charging process and resume it when it is

necessary to charge the battery again. There is no need to worry about

wasting electricity.

Disconnect the charging adapter from the power socket only in the event

of a long term absence. When you return, plug it back into the socket so

that the vacuum cleaner is again ready for use.

Note:

Once the battery is almost discharged, the operation of

the vacuum cleaner will automatically stop to prevent the

battery from being completely discharged.

In order to ensure the long life of the battery, it is advised to

fully charge the battery before the first use and to discharge

before the second charging (operation of the vacuum

cleaner will automatically stop).

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INSERTING AND REMOVING THE BATTERY

1. Inserting the battery: Carefully turn the motor unit upside down

and insert the fully charged battery so that the battery fits into

the connective grooves – see picture E. Push the battery until it

clicks. The battery can only be inserted with one side.

Warning:

Never insert the battery in the opposite way or with

great force. There is arisk of damage.

2. Removing the battery: When you need to remove the battery,

press the A15 button to release the battery. Carefully remove it

from the motor unit.

Warning:

If you do not use the vacuum cleaner for along time,

remove the battery from it and store it in acold and

dry place. Charge the battery regularly. Keep it away

from the reach of metal objects to prevent excessive

discharge.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

USING THE STICK VACUUM CLEANER

1. Assemble the vacuum cleaner according to the instructions in

the section “ASSEMBLY AND DISASSAMBLY OF THE STICK

VACUUM CLEANER”.

2. Insert the fully charged into the motor unit.

3. Press the On / Off button and the vacuum cleaner turns on.

4. You can adjust the speed using the A5 button. Press the A5

button repeatedly to switch the speed as following:

I(low speed – ensures longer vacuuming time)

II (high speed – vacuuming at high power)

III (turbo speed – vacuuming at maximum power)

5. When vacuuming is completed, press the On / Off button and

the vacuum cleaner turns off.

Note:

Electric rotary brush will automatically stop once it is

blocked by, e.g., aforeign object or large amount of hair

or animal hair. It is asafety feature that prevent the brush

from damage. In such case, turn the vacuum cleaner off by

pressing the On / Off button and remove the blocked object

or hair from the brush.

Using the vacuum cleaner with wiping attachment

Place the wiping attachment with the attached sleeve on the floor.

Remove the lid B21 and pour water or cleaning solution into the water

tank. Put the lid B21 back.

Note:

Always use aneutral cleaning agent with low foaming

effect.

Attach the vacuum cleaner to the attachment B19.

In order to vacuum and wipe the floor simultaneously, press button B22

and it will click up. This will result in water slowly flowing into the sleeve.

Turn the vacuum cleaner on, and while vacuuming you will also wipe

the floor.

Note:

Regularly check the water/solution level in the water tank

and fill it up as necessary.

When no longer using the wiping attachment, turn off the vacuum

cleaner and press button B22 and it will click down. This will prevent air

from entering the water tank and the water will stop flowing out. Pull the

vacuum cleaner out in the upward direction.

Tip:

We recommend that you wet the wiping sleeve before

attaching it to the attachment. This will speed up the

wetting process and wiping will be more effective from the

very beginning.

Storage under normal use

The vacuum cleaner SVC 8776BK is supplied with aholder which can

be fixed on the wall. Choose the place where the holder will be easily

accessible and there will be free space around it.

Mounting the holder on the wall

1. Put the holder on the wall and using apencil, mark the points

where it is necessary to drill the holes.

2. Drill two holes which you insert the wall plugs into.

3. Place the holder to the wall and insert the screws into the holes

in the holder. Use ascrewdriver to fix them. Make sure the holder

does not move and the screws are properly tightened.

Warning:

Never install the holder in environments with high

huminidity or dustiness.

Storage of the motor unit and accessories

The holder is designed to store the motor unit and accessories in it.

Insert the motor unit into the holder and you can attach the selected

accessories you use the most often to two pins – see the picture F.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CLEANING AND MAINTENANCE

Before cleaning, always make sure the vacuum cleaner is switched off.

Remove the battery from the motor unit.

Cleaning the motor unit and accessories

Use asoft cloth, lightly dampened in alukewarm water, to clean the

outer parts of the vacuum cleaner. Do not use abrasive cleaning agents,

solvents, or dissolving agents, otherwise the unit surface may be

damaged.

- 5 -

Revision 12/2024

Cleaning the stick vacuum cleaner

Empty the dust container

It is advised to empty the dust container after each use. However, if

the dirt level reaches the MAX mark, it is necessary to empty the dust

container immediately.

1. Remove the accessory from the motor unit.

2. Place the motor unit above the waste bin with the dust container

bottom facing down.

3. Press the A14 button and the dust container bottom is released

and opens – see picture G1.

4. This will empty the container content directly into the waste bin.

5. Use your hand to close the container bottom. It clicks once

correctly fitted.

Cleaning the dust container

Clean the dust container regularly to prevent unpleasant odours.

1. Remove the accessory from the motor unit and empty the dust

container according to the instructions above.

2. Press the button to release the dust container and at the same

time, turn the container until the arrow on the motor unit points

at the symbol. Carefully remove it from the motor unit – see

picture G2.

3. Wipe the inner walls of the dust container using alight

dampened soft sponge. Dry with aclean cloth.

4. Turn the outer filter until the arrow on the filter points at the

symbol to release the outer filter. Carefully remove it from the

motor unit downwards – see picture G3. Remove the tube filter

from the motor unit downwards – see picture G4.

5. Remove the dirt from both filters. If necessary, you can wash

them under the running clean water. And then dry them with

clean cloth.

Warning:

Never insert wet or damp filters A11 and A12 into the

motor unit! Always wait until it is completely dry.

6. Attach the tube filter to the motor unit.

7. Attach the outer filter to the motor unit so that the arrow on the

filter is aligned with the symbol. Then turn the filter until the

arrow on the filter A11 points at the symbol and it clicks.

8. Attach the container A13 to the motor unit so that the arrow on

the motor unit is aligned with the symbol. Turn until the arrow

on the motor unit points at the symbol. Correct securing of the

container A13 is signalised by aclick.

Cleaning and change of the inflow filter

It is advised to clean inflow filter regularly to ensure proper vacuum

cleaner operation. Depending on how often you use the vacuum cleaner,

change the inflow filter once every 3 or 6months.

1. Take the cover A3 and pull it upwards.

2. Turn the filter A4 clockwise to release it – see picture G5.

3. Remove the dirt from the filter over the waste bin. If the filter is

heavily soiled, rinse it under running clean water – see picture

G6. Leave it to dry.

4. Insert the filter to the bottom of the cover A3 by aligning the

protrusions on the filter with the grooves inside the cover. Turn

the filter counter clockwise until you feel resistance.

5. Insert the cover A3 with installed filter A4 into the motor unit.

Cleaning the floor nozzle

It is necessary to clean the floor nozzle regularly to ensure the desired

and stable suction power.

1. Remove the floor nozzle from the vacuum cleaner and turn it

upside down.

2. Move the lock A23 up to remove the side cover – see picture G7.

Remove it.

3. Carefully remove the rotary brush – see picture G8.

4. Remove tangled hair, animal hair and other dirt from the rotary

brush. You can use scissors to remove tangled hair or animal hair

quicker.

5. Clean the inner part of the floor nozzle by adry cloth.

6. Insert the clean rotary brush into the floor nozzle.

7. Finally, attach the side cover.

Cleaning the wiping attachment

Always empty out the tank B20 after every use of the attachment B19.

Wipe the attachment with asoft sponge lightly dampened in warm water.

Wipe dry using aclean wiping cloth.

Remove the sleeve and wash it by hand in cold water. Allow it to dry

naturally.

Warning:

Under no circumstances submerge or wash the

attachment in water or any other liquid.

Cleaning the Cat&Dog Mini brush

It is necessary to clean the Cat&Dog Mini brush regularly to ensure the

desired and stable suction power.

1. Remove the rotary brush from the vacuum cleaner and turn it

upside down.

2. Turn the lock B4 to release the brush and take it out.

3. Remove tangled hair, animal hair and other dirt from the brush.

You can use scissors to remove tangled hair or animal hair

quicker.

4. Clean the inner part of the rotary brush by adry cloth.

5. Place the brush back and turn the lock B4 until it clicks.

Storage

If you do not use the vacuum cleaner, clean it according to the instructions

above and remove the battery from the motor unit.

Before storing, make sure the vacuum cleaner and all accessories are

clean and dry.

Store the appliance on adry, clean and well-ventilated place where it

will not be exposed to extreme temperature and out of reach of children

or animals.

It is advised to regularly charge the battery every 6months.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TROUBLESHOOTING

Before you decide to contact an authorised service centre, please read

through the following table:

Problem Possible cause Solution

Vacuum cleaner

does not work.

Battery is discharged. Charge the battery

before using the

vacuum cleaner.

Suction hole is blocked. Remove the dirt from

the suction hole.

Vacuum cleaner is not

correctly assembled.

Make sure all the

parts are correctly

assembled.

Suction power

is low.

Dust container is full, or

the filters A11 and A12

are soiled.

Empty the dust

container and clean the

filters A11 and A12.

Alarge amount of hair

or animal hair is wound

on the rotary brush.

Clean the rotary brush.

Short operation

time of battery after

charging.

Battery is not fully

charged.

Fully charge the

battery.

Battery is at the end

of its life.

Buy anew battery.

The wiping

attachment

does not wipe

immediately

when the vacuum

cleaner is turned

on.

The wetting of the

sleeve may take

several seconds.

We recommend that

you wet the wiping

sleeve before attaching

it to the attachment.

- 6 -

Revision 12/2024

Cautions:

If you cannot find your problem in the table above, or

the problem persists, stop using the vacuum cleaner,

turn it off and contact the authorised service centre.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TECHNICAL SPECIFICATIONS

Adapter

Input ........................................................................ 100 – 240 V~, 50/60 Hz, 1.0 A

Output ............................................................................................ 30 V , 0.6 A

Vacuum cleaner

Power input ..........................................................................................................400 W

Electric rotary brush ............................................................................................. 30 W

Cat&Dog electric rotary brush..............................................................................5 W

Battery ............................................................ Li-Ion / 25.2 V / 2,500 mAh

Time required for charging to full capacity ..........................approx.4 - 5 hours

Operating time when fully charged ...................................................up to 50 min

Noise level .....................................................................................................≤ 83 dB(A)

Dust container capacity .....................................................................................0.58 l

Water tank capacity ............................................................................................ 0,25 l

The declared noise emission level of vacuum cleaner is ≤83dB(A), which

represents level Aof acoustic power with respect to areference acoustic

power of 1pW.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF

USED PACKAGING MATERIALS

Dispose of used packaging material at asite designated for waste in your

municipality.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT

For proper disposal, renewal and recycling, hand over these appliances

to determined collection points. Alternatively, in some European Union

states or other European countries you may return your appliances to the

local retailer when buying an equivalent new appliance. Correct disposal

of this product helps save valuable natural resources and prevents

potential negative effects on the environment and human health, which

could result from improper waste disposal. Ask your local authorities or

collection facility for more details. In accordance with national regulations

penalties may be imposed for the incorrect disposal of this type of waste.

For business entities in European Union states

If you want to dispose of electric or electronic equipment, ask your retailer

or supplier for the necessary information.

Disposal in other countries outside the European Union.

If you wish to dispose of this product, request the necessary information

about the correct disposal method from the local council or from your

retailer.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

We reserve the right to change text and technical specifications.

FAST ČR, a.s.

U Sanitasu 1621

CZ-251 01 Říčany

www.sencor.eu

info@sencor.coms

Sencor SVC 8776BK 4-in-1 Stick Vacuum Cleaner

Product's Documents

User Manual

Specifications

Sencor SVC 8776BK Questions and Answers
