PLEASEREADANDFOLLOWALLINSTRUCTIONSCAREFULLYBEFOREUSE.
FAILURETOFOLLOWTHESEINSTRUCTIONSCOULDRESULTINBODILY
INJURY, AND/ORPROPERTY LOSS.
RETAIN INSTRUCTIONMANUALFORFUTUREUSE.
MODEL:FM50CH
VoltageRange：115
V/60Hz
INSTRUCTION MANUAL
1
STRUCTURE
Product Feature
1.
Theappliance adoptssemiconductor refrigerationtechnology, novibration inthework,
lowpowerconsumption andenvironmentalprotection.
2.
Thestorage intheboxis clearataglancewithglassdoor.
3.
Theaircoolingsystemisusedtorealize thenatural aircirculation insidethe humidor
avoidthepreventstemperatureimbalance andlocal mildew.
4.
Temperature andhumiditytouchcontrolmode,interiortemperatures15-22℃(59°F-
72°F)andHumidityrange 60%-7
5%.
5.
Thecondensedwater canbeautomaticallyrecovered andrecycling.
6.
Thewhitespongeinside thewaterbox isused forhumidifying.
Install the cigar humidor
1.Placecigarhumidoron afloorthatis strongenoughtosupport itwhenitis fully
loaded.Tolevel cigarhumidor,adjustthe levelinglegs atthebottom.(Themaximum
adjustableheight is10mm)
2.Locatingthe unitinan indoordryenvironment,and avoidlocatinginmoistareas.
1.Cabinet
2.Venthole
3.Adjustableleg
4.Shelves
5.
TopHinge
6.
Handle
7.
Glassdoor have lock
8.
Waterbox
9.
Temperatureand
humiditycontrol
6
7
8
2
1
3
5
9
4
2
3. Locate the cigar humidor away from direct sunlight and sources of heat (stove,
heater, radiator, etc.)
4. Plug the cigar humidor into an exclusive, properly installed-grounded wall outlet. Do
not under any circumstances cut or remove the third (ground) prong from the power
cord. Any questions concerning power and/or grounding should be directed toward a
certified electrician or an authorized Products service center.
5. Place cigar after 2 hours power on.
SAFETY PRECAUTIONS
Please follow below instructions when use:
1. Please read carefully manual before use.
2. The appliance only be used indoor.
3. Make sure the voltage on the rating label is the same as the voltage used, select a
three-hole socket with ground wire.
4. When you are not using or cleaning products, need remove the plug of the power
cable first. Do not remove or insert the power plug with wet hands.
5. If the power cable is damaged or the product cannot run normally, send the product
to the nearest service center for repair.
6. Except normal cleaning, the maintenance center designated by the supplier shall be
responsible for product maintenance.
7. The product must be effectively grounded, the supplier is not responsible for any
damage caused by non-benign grounding. If in doubt,please contact a qualified
electrician.
8. Please do not allow children to climb on any part of the appliance, lest the appliance
topple over.
9. Do not store or use gasoline or any other flammable vapors and liquids in the
vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.
10. Please do not put any water containers or pour water on the top of the appliance.
11. If the appliance is not used for a long time, please unplug it.
12. Do not hit the glass door.
3
Moving cigar humidor
Unplug the power cord, remove all items.
Tape the door shut.
It is recommended to use original product packaging when transported to distant place.
Warning:
1. If the supply cord is damaged, it must be replaced by the manufacturer or service
agent or similarly qualified person in order to avoid hazard.
2. Please screw off the door before throwing it away.
3. Please keep the appliance away from any flammable substances.
4. To avoid a hazard due to the instability of the appliance, it must be fixed
according to the instructions.
5. Do not use electrical appliances inside the food storage compartments of the
appliance.
6. This appliance is not intended for use by persons (including children) with reduced
physical,
7. Children should be supervised to ensure that they do not play with the appliance.
8. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
9. Keep ventilation openings, in the appliance enclosure or in the built-in structure,
clear of obstruction.
T
he symbol is a warning symbol for risk of fire/flammable material.
WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
W
ARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear
of the appliance.
4
OPERATING YOUR CIGAR HUMIDOR
Temperature settings
Temperature
display
Humidity
display
Pressthisbuttontoturnon theappliance, andpress 3seconds toturnoffthe
appliance.
LeftLEDshown temperature,Right LEDshownhumidity.
Pressthisbutton,LeftLEDflashingand shownoriginalsettemperature,enter the
temperaturesettingstate;
Pressagain, RightLEDflashingand shownoriginalsethumidity, enterthe
humidity
settingstate
LEDwill displaytheactualtemperatureandhumidity
after5seconds
if
nooperation.
Turnstheinteriorlightonoroff.
TogglesthetemperaturedisplaybetweenCelsiusandFahrenheitforpress3seconds.
Pressthisbuttontoadjuststhe temperatureandhumidityin1degreedecrements,and
willdisplay
theactual temperatureandhumidity after5seconds ifno opera
tion.
Pressthisbuttontoadjuststhe temperatureandhumidityin1degreeincrements,
and
will
displaytheactual temperatureandhumidityafter5secondsifno operation.
NOTE:
That's normall which temperature deviation is ±4° and humidity deviation is ±5%RH.
50-77 the performance may be affected if the temperature exceeds this range.
It is recommended install the cigar humidor in a place where the ambient temperature is between
F
°F,
%RH
5
Replacement of lighting
The light is LED, if not light, please contact professional or send to the nearest repair
center for repair
Cleaning your Cigar humidor
1. Normally, clean and maintain the cigar humidor every six months.
2. Turn off the power, unplug the appliance, and remove all items including shelves.
Wash the inside surfaces with a neutral detergent, then dry with a clean and soft cloth.
3. Do not rinse the cigar humidor with water.
4. Do not use hot water, gasoline, acid detergent, benzene, acid to clean the cigar
humidor. Pay attention to the regular maintenance of the door sealing, do not damage
the door seal. Check whether the power cable is damaged after cleaning.
5. After the power supply is plugged in and the power cable plug is inserted in place,
check whether the power cable plug is abnormally hot.
TROUBLE SHOOTING
1. Cannot refrigerate
● Check power supply is normal or not.
●
Check the power plug is plugged in properly.
● Is the power cable intact.
2. Poor refrigeration effect
● The temperature set too high.
● The ambient temperature too high or the ambient ventilation poor.
●
The door is opened too often.
3. Noise or unusual sound
●
The cigar humidor is not level.
● Anything else on the top of cigar humidor.
● Foreign matter enter the inside fan.
6
The following are not machine faults
● Dew condensation on the surface of glass door：
When the environment humidity is bigger, the moisture in the air touches the glass
door of the cigar humidor, dew condensation on the surface of glass door. You can
adjusts the temperature increments to reduce dew condensation. The lower inner
temperature will produce dew condensation, please use dry cloth to wipe the glass
surface condensation.
● Dew condensation on the inner wall:
When t
he environment humidity is bigger, open the door too often or too long, will
cause dew condensation on the inner wall. Especially the refrigeration system, the
condensation water will flow and enter the water box from the drain hole.
Warning
● Do not block the cigar humidor drain
● It is necessary to check the water box at the bottom of inside the cigar humidor, filled
2/3 filtered water or mineral water, period of changing water is once every half month.
● It is recommended to rep
lace the white sponge inside the water box every two
months.
7
ELECTRIC PRINCIPLE DIAGRAM
DISPLAYPCB
AC115V/60Hz
THERMOELECTRIC
MODULE
POWERPCB
HumidifyingFan
NTC
Temperature
sensor
NTC
Humidity
sensor
LED LIGHT
OutsideFan
InsideFan
PTC heater
Heating fan
