Register your product and get support at
www.philips.com/TVsupport
User Manual
55OLED910
65OLED910
77OLED910
AMBILIGHT tv
OLED910 Series
Content
1 OLED Screen Care 4
2 Home Screen 6
2.1 Introduction 6
2.2 Dashboard and Settings 6
2.3 Google TV and Basic Mode 6
2.4 Open the Home Screen 7
3 Setting Up 8
3.1 Read the Safety Instructions 8
3.2 TV Stand and Wall Mounting 8
3.3 Tips on Placement 8
3.4 Power Cable 8
3.5 Antenna Cable 9
3.6 Satellite Dish 9
4 Remote Control 10
4.1 Key Overview 10
4.2 Pair Your Remote Control to TV 11
4.3 Voice Search 12
4.4 IR Sensor 12
4.5 Charging and Cleaning 12
4.6 Simple Setup App for Set Top Box 13
5 Switching On and Off 14
5.1 On or Standby 14
5.2 Keys on TV 14
6 Channel Installation 15
6.1 Satellite Installation 15
6.2 Antenna Installation 18
6.3 Channel List Copy 20
6.4 Internet Channel Installation 21
7 Channels 22
7.1 Install Channels 22
7.2 Channel Lists 22
7.3 Channel List sorting 22
7.4 Watching channels 23
7.5 Favourite Channels 26
7.6 Text / Teletext 27
7.7 Interactive TV 28
8 TV Guide 29
8.1 TV Guide Data 29
8.2 Using the TV Guide 29
9 Connect Devices 30
9.1 About Connections 30
9.2 Home Theatre System - HTS 31
9.3 Digital Audio Out - Optical 32
9.4 CAM with Smart Card - CI+ 32
9.5 Smartphones and Tablets 33
9.6 Blu-ray Disc Player 33
9.7 Headphones 33
9.8 Game Console 33
9.9 USB Keyboard 34
9.10 USB Storage Device 34
9.11 Photo Camera 35
9.12 Camcorder 35
9.13 Subwoofer 35
9.14 Computer 35
10 Connect Your TV 37
10.1 Network and Internet 37
10.2 Google Account 38
10.3 Internet 39
11 Sources 40
11.1 Switch to a device 40
11.2 Apple AirPlay and HomeKit 40
12 Quick Menu and Frequent Settings 41
13 Display and Sound 42
13.1 Picture 42
13.2 Screen 46
13.3 Sound 47
13.4 Audio Output 50
13.5 Multi View 50
13.6 Ambilight 51
14 Apps 55
14.1 About Apps 55
14.2 Google Play 55
14.3 Start or Stop an App 56
14.4 Manage Apps 56
15 System 57
15.1 About 57
15.2 Date and Time 58
15.3 Language 59
15.4 Keyboard 59
15.5 Storage 59
2
15.6 Ambient Mode 59
15.7 Power and Energy 59
15.8 Cast 60
15.9 System Sounds 60
15.10 Childlock 60
15.11 Retail Mode Settings 60
15.12 Restart 61
16 Accessibility 62
17 Remote and Accessories 63
17.1 Bluetooth® On or Off 63
17.2 Remote Control 63
18 Eco Settings 65
19 Videos, Photos and Music 66
19.1 From a Computer or NAS 66
19.2 Favourites Menu 66
19.3 From a USB Connection 66
19.4 Play your Videos 66
19.5 View your Photos 67
19.6 Play your Music 67
20 Smartphones and Tablets 69
20.1 Philips Smart TV App 69
21 Games 70
21.1 What You Need 70
21.2 Gamepads 70
21.3 Play a Game From Game Console
or Computer
70
21.4 Gaming Bar 70
22 Netflix 72
23 Alexa 73
23.1 About Alexa 73
23.2 Using Alexa 73
24 Specifications 74
24.1 Environmental 74
24.2 Power 74
24.3 Operating System 74
24.4 Reception 74
24.5 Display Type 74
24.6 Display Input Resolution 75
24.7 Connectivity 75
24.8 Sound 75
24.9 Multimedia 75
25 Help and Support 77
25.1 Register your TV 77
25.2 Using Help 77
25.3 TV Diagnose and Self-diagnose 77
25.4 Troubleshooting 78
25.5 Online Help 80
25.6 Support and Repair 80
26 Safety and Care 81
26.1 Safety 81
26.2 Screen Care 82
27 Terms of Use 83
27.1 Terms of Use - TV 83
27.2 Terms of Use - Smart TV 83
28 Copyrights 85
28.1 Google TV 85
28.2 HDMI 85
28.3 HEVC Advance 85
28.4 Works with Apple AirPlay 85
28.5 Works with Apple Home 85
28.6 NVIDIA G-SYNC 85
28.7 AMD FreeSync Premium 86
28.8 Dolby Vision and Dolby Atmos 86
28.9 IMAX Enhanced 86
28.10 DTS:X 86
28.11 DTS Play-Fi 86
28.12 Wi-Fi CERTIFIED 6 86
28.13 Kensington 87
28.14 Other Trademarks 87
29 Disclaimer regarding services and/or
software offered by third parties
88
Index 89
3
1. OLED Screen Care
OLED Display is state of the art technology and
combined with our Picture Quality Engine it has won an
outstanding number of awards. To ensure that your TV
always offers the best possible performance, it will
sometimes perform a display clean-up process while in
standby. OLED TV shall be always placed in location
without direct sunlight shining on the screen.
If you never put your TV in standby, you will regularly
be notified by on screen messages that the display
needs to execute this clean-up process. Please always
follow those instructions. Repeatedly postponing this
process may result in image retention, which may void
your warranty.
Your TV should be left in standby in order to execute
the cleaning process in the background.
We also recommend that you avoid continuously
displaying static images or static parts in moving images
(like news ticker bar, soccer scores, game HUDs...).
TV Display refreshing
To protect the screen, OLED TV need refreshing process
over time.
There are 2 types of refreshing process:
• Normal refreshing: This will take place automatically
and it takes a few minutes with TV in standby mode.
• Deep refreshing: This will take a few minutes and
need to be triggered by consumer.
To allow OLED TV to perform refreshing properly,
please adhere to the following:
• For normal refreshing process to take place
automatically, always use remote control to switch off
TV and keep the TV power plugged.
• When normal refreshing message is shown on TV
screen, follow the onscreen recommended instructions.
• For deep refreshing process, it can be activated
manually via Settings > Display and sound > Screen
> OLED SCREEN SETTINGS > Clear residual image. A
reminder message can also be shown on TV to request
user to perform deep refreshing, please follow
instructions and keep TV power plugged to allow the
whole process complete. It will take a few minutes. The
deep refreshing process shall only be done when
residual image is seen on screen even after 8 hours
standby. Manually performing Clear residual image too
often may reduce OLED display life time. However, it is
important to allow the refresh cycles, when requested
by the TV.
• Do not touch or apply pressure on TV screen during
the refreshing process.
• Always use remote control to switch off TV and keep
the TV power plugged on when refreshing is triggered.
* Note: In order to enjoy the best picture quality this
process is essential. If the unit demonstrably did not
have the chance to complete a refreshing process on a
regular basis, we cannot accept any returns, repairs,
exchanges or warranty claims on behalf of image
residual phenomenon within and/or out of the
warranty period. This is also the case when the TV is
used predominantly for gaming with static content on
the screen, the TV is only used for watching news
channels (with static news ticker bars) or other similar
use cases that implication-wise bear an increased risk
for sustaining burn-in effects. This is not in scope of the
warranty.
Special Care for OLED TV
Organic LED (OLED) may experience on-screen image
retention (due to the characteristics of the material),
when an image is continuously displayed for a long
period of time or the same image is repeatedly
displayed. So it is strongly recommended to follow the
instructions to take care of OLED TV:
• Do not display any still image continuously or display
the same image for more than 10 minutes.
• Recommend to use ECO, HDR ECO or Dolby
Vision Filmmaker as picture style in normal home
viewing condition.
• Recommend to use OLED Contrast setting 50 or
below in picture settings when playing Game or
watching TV programs with logos or clocks on any parts
of the screen.
• Switch off On Screen Display (e.g. the home menus) of
TV application program when not used.
• Switch off On Screen Display from connected external
video devices (e.g. DVD player). For details, refer to the
instruction manuals for the connected devices.
• Avoid displaying video with bright colours (including
white), text, clocks or logos on any parts of the screen
for a long time.
• Use Wide screen or Fill screen as picture format
option (see TV picture settings).
• Always watch video in full screen instead of a small
window on TV screen. (e.g. video in internet browser
page)
• Do not attach any sticker or label on the OLED panel
to reduce the chance of image residual phenomenon.
• Organic LED (OLED) displays are extremely sensitive to
hostile climate and external factors, like placing these
straight under the sunlight and/or ultraviolet
illumination as well as improper ambient temperature,
resulting in a decrease of luminosity, brightness and
lifetime of the OLED displays, pixel reduction and
irreparable harm and/or failure of the display. Please
note that the warranty does not apply to problems that
result, directly or indirectly, from the usage which is not
in conformity with these product instructions.
4
Displaying a still image for a prolonged period of time
may cause an image sticking. This phenomenon is
normal character for OLED panel and does not
represent a defect of the TV. Avoid displaying a fixed
image on the TV screen for an extended length of time.
Screen saver
To reduce the chances of residual images on the TV
screen, the screen saver (moving logo) will be triggered
in such circumstances.
- when static setting menu elements are shown on
screen for more than 2 minutes.
- when static setting menu elements of Apps are shown
on screen for more than 2 minutes.
- when Teletext is being displayed for more than 2
minutes.
The screen saver may not be triggered in such
circumstances.
- pausing playback on an external source (e.g. HDMI), as
the TV is not displaying static setting menu elements.
Once the screen saver is active, it can be closed by
pressing any remote control button. Other actions like
inserting a USB stick or casting content will execute in
the background, but these activities will not interrupt
the screen saver.
Philips TV is equipped with the following to take care
of OLED screen:
• Automatic refreshing process
Perform screen refreshing process when necessary.
• Automatic screen brightness control
Gradually reduce the screen brightness when still image
is displayed for a long time.
• Screen Saver
Display screen saver when still image is displayed on
screen over a longer period of time.
5
2. Home Screen
2.1. Introduction
To enjoy the benefits of your Google TV, connect the TV
to the Internet. Press HOME on your remote control
to get your Home screen. Like on your Android
smartphone or tablet, the Home screen is the centre of
your TV. From the Home screen you can decide what to
watch by browsing entertainment options from app
and live TV.
The Home screen is organized in rows to let you
discover great contents from your favourite apps. You
can also add additional rows or find new apps to get
more contents. Apps may populate their
recommendation (if available) according to their own
choice as an individual rows in the home screen.
Highlights on your home screen
With multiple tabs* like Search, For you, Movies,
Shows, Apps, Library and Philips, you can discover
movies and shows from your services and popular apps.
Sign in to your Google Account to get personalised
recommendations from your streaming services based
on what you have watched and what interests you. You
can also trigger Google search with voice or text input
in Search tab.
* The tabs on your home screen are vary depending on
you location and language setting of your TV.
Apps
The Apps tab of Home screen contains all installed Apps
that come with the TV and the Apps you have installed
from Google Play™ Store. You can also install and add
more apps as favourite from the Apps tab.
Navigation
Decide what to watch next with easy-to-use navigation.
Browse your personalised recommendations, pick up
where you left off, or quickly find a certain app using
the new tab system.
Discover personalised recommendations
Browse shows and movies that you will love on all your
favourite media services. Sign in to your Google
Account to get started.
Get recommendations across Google
Your services are saved to your Google Account so you
can get better recommendations across Google.
All about your Philips TV
The Philips tab includes the information of your Philips
TV. Smart TV Collection row to list the apps that
designed for your TV or guide you to register your TV.
How to… row to introduce the tips of common
operations on your TV. Help row to help you to access
the user manual, perform the TV diagnose or Self-
diagnose to check your TV status.
See also www.support.google.com/googletv
2.2. Dashboard and Settings
Dashboard
The Dashboard is a side panel in Google TV that
provides access to Settings, device controls,
notifications and more.
The Dashboard can be accessed in three ways as
follows:
1 - Navigating to the profile icon in the upper right of
the home screen.
2 - Press DASHBOARD key on the remote control.
3 - Long press HOME key on the remote control.
The dashboard contains following features.
• Profile: to display current user profile icon or to add
new user profile
• Settings: to access all setting menus for adjusting the
TV settings.
• Clock and screensaver: to indicate the system clock
and press to activate screen saver immediately.
• Sources: to launch the input source list for switching
to any of the connected devices.
• Picture / Wi-Fi / Accessibility / Bluetooth®: quick link
to adjust Picture / Wi-Fi / Accessibility / Bluetooth®
settings.
• Notifications: to provide you the messages about the
Google TV system; press Clear all to dismiss all
notifications.
Adjust settings
You can access Settings menu via the dashboard at the
top right corner. Alternately, you can access the
Frequent settings menu and Quick Menu items in the
Philips TV Menu, which can be invoked directly from the
remote control.
6
2.3. Google TV and Basic
Mode
Difference of feature
You can set your TV to Google TV mode or Basic Mode.
Basic Mode contains only Live TV and External devices
(e.g. HDMI) features. Google TV requires you to login
with your Google account and Internet connection.
With Google TV, you can have all Basic Mode features
and more Google’s personalised services. For example,
movies and TV shows from your favourite streaming
apps, personalised recommendations, and Google
Assistant to search and control your TV with your voice.
Some features are not available in Basic Mode. For
more information, please refer to Google support page.
Difference of Home screen
The Home screen of Basic Mode has only two rows and
without tabs. The first Home row contains Watch TV,
TV Guide, Sources and Dashboard icons for TV feature
operations. The second App row contains all pre-
installed Apps. The Dashboard on Basic Mode does not
include personal profile and can only perform setting
change and displaying system notifications.
The Home screen of Google TV has multiple tabs like
Home, Apps, Library and Search. Each tab contains
rows of apps, movies and shows from your services and
popular apps. You can get personalised
recommendations from your streaming services based
on what you have watched and what interests you. You
can also trigger Google search with voice or text input
in Search tab.
2.4. Open the Home Screen
To open the Home screen and open an item:
1 - Press HOME.
2 - Select an item and press OK to open or start it.
3 - Press Back continuously or press HOME can go
back to Home screen.
When opening the Home screen, the background
application/content playback will stop. You have to
select the application or content from the Home screen
to resume.
7
3. Setting Up
3.1. Read the Safety
Instructions
Please read the safety instructions before you use the
TV.
To read the instructions, check on Help > User manual >
Safety and Care.
3.2. TV Stand and Wall
Mounting
TV Stand
You can find the instructions for mounting the TV stand
in the Quick Start Guide that came with the TV. In case
you lost this guide, you can download it from
www.philips.com/TVsupport.
Use the product type number of the TV to look for
the Quick Start Guide to download.
Wall Mounting
Your TV is also prepared for the wall
mount bracket (sold separately).
The wall mount size may vary depending on different
type of back cases; refer to the Quick Start Guide in
your product package to see which size is applied to
your TV.
Use the following wall mount dimension when
purchasing the wall mount.
• 55OLED910
300x300, M6 (min.: 10 mm, max.: 15 mm)
• 65OLED910
300x300, M6 (min.: 10 mm, max.: 15 mm)
• 77OLED910
400x300, M6 (min.: 10 mm, max.: 22 mm)
Caution
Wall mounting the TV requires special skills and should
only be performed by qualified personnel. The TV wall
mounting should meet safety standards according to
the TVs weight. Also read the safety precautions before
positioning the TV.
TP Vision Europe B.V. bears no responsibility for
improper mounting or any mounting that results in
accident or injury.
3.3. Tips on Placement
• Position the TV where light does not shine directly on
the screen.
• Dim lighting conditions in the room for best
Ambilight effect.
• The ideal distance to watch TV is 2 to 5 times its screen
height. When seated, your eyes should be level with the
centre of the screen.
• Recommended distance to the wall:
A. When wall mounted, position the TV from 7 to 10 cm
away from the wall.
B. When TV is with stand, position the TV from 10 to 20
cm away from the wall depends on the size of stand.
Note:
Please keep the TV away from dust-producing sources
such as stoves. It is suggested to clean the dust regularly
to avoid getting dust into the TV.
3.4. Power Cable
• Insert the power cable into the POWER connector on
the back of the TV.
• Make sure the power cable is securely inserted in the
connector.
• Make sure that the power plug, in the wall socket, is
accessible at all times.
• When you unplug the power cable, always pull the
plug, never pull the cable.
8
Although this TV has a very low standby power
consumption, unplug the power cable to save energy if
you do not use the TV for a long period of time.
3.5. Antenna Cable
Insert the antenna plug firmly into the Antenna socket
at the back of the TV.
You can connect your own antenna or an antenna
signal from an antenna distribution system. Use an IEC
Coax 75 Ohm RF antenna connector.
Use this antenna connection for DVB-T and DVB-C input
signals.
3.6. Satellite Dish
Attach the satellite F-type connector to the satellite
connection SAT at the back of the TV.
9
4. Remote Control
4.1. Key Overview
Top
Special features of remote control
There are some special features embedded with the
remote control. Motion sensing to detect the remote
control motion and turn on the backlight. Hidden keys
to extend more control functions while pressing the
123 key. Charging the battery by USB type-c connector.
Motion sensing
The remote control has built-in Motion sensor, when
you pick up the remote control normally and tilt the
remote control keys towards you, the backlight will turn
on for few seconds. The default for motion sensing
feature is on, you can turn it off by long pressing OK
and Colour key
for 3 seconds. To turn on the feature
again, long press OK and Colour key
key for 3
seconds.
Hidden keys
There is a 123 key on the middle of remote control,
which is used to turn on/off hidden keys mode. When
hidden key mode is turned on by pressing the 123 key,
the number keys 0 to 9 and media play control keys
will appear with backlight and trigger the functions.
When hidden key mode is turned off by pressing 123
key again or automatically turned off, the remote
control will work with normal keys.
Wired and Wireless charging the remote control
The remote control is without replaceable battery, you
can charge the remote control with the USB type-c
connector in front of the remote control. Alternately,
you can charge the remote control by Qi wireless
charger*.
* Note: Wireless charging device/pad is not included in
product package.
Warning
Choking Hazard! This TV remote control contains small
parts, not suitable for children under 5 years old.
1 - (Standby / On)
To switch the TV on or back to Standby. Long press for
three seconds to reboot the TV.
2 - VOICE microphone
3 -
To select one of the Ambilight style.
4 - (SOURCES)
To open or close the Sources menu.
5 - (DASHBOARD)
To launch Dashboard on side of screen to access
Settings, device controls, notifications and more.
6 - (Google Voice Search)
To start the Google Voice Search.
Middle
1 - TV Guide (
)
To open or close the TV Guide.
2 - OK key
To confirm a selection or setting. To open the channel
list while watching TV.
10
3 - Arrow / navigation keys
To navigate up, down, left or right.
4 - OPTIONS ()
To open or close the options menu. Long press to open
programme info.
5 - (Back)
To switch back to the previous channel you selected.
To return to previous menu.
To go back to the previous App/Internet page.
6 - Volume / (Mute)
Move down or up to adjust the volume level. Press the
middle of key to mute the sound or to restore it.
7 - 123 key
To turn on or off the hidden function keys and switch
the keys between different sets of operations.
8 - Quick Menu / MENU (
)
To open the Quick Menu with typical TV functions.
9 - Number keys (hidden keys, available after 123 key is
pressed)
To select a channel directly.
10 - SUBTITLE
To open Subtitle page. Long press to open
Text/Teletext.
11 - TV (
) / EXIT
To switch back to watch TV or to stop an interactive TV
application. However, it might not work on some
applications; behaviour is dependent on third party TV
apps.
This key will be changed to Number key 0 after 123 key
is pressed.
12 - (HOME)
To open the Home menu. Long press to access the
Dashboard.
13 -
(Channel)
Move down or up to switch to the next or previous
channel in the channel list. To open the next or previous
page in Text/Teletext. Press the middle of key to open
the channel list.
Bottom
1 - Colour keys
Direct selection of options. Press Blue key to open
the Help.
2 -
• If you have a Netflix membership subscription, you
can enjoy Netflix on this TV. Your TV must be connected
to the Internet.
• To launch the Netflix, press to open Netflix
immediately with the TV switched on or from standby.
www.netflix.com
3 -
To launch the Amazon prime video App.
4 - Eco / Green key
Press to invoke a message to remind you to enter the
Eco settings menu; long press to invoke the Eco
settings menu directly. Once the Eco settings menu is
triggered via long press the key few times, the message
will no longer to show.
5 - Playback (hidden keys, available after 123 key is
pressed)
• Play , to playback.
• Pause , to pause playback
• Rewind , to rewind
• Fast forward , to go fast forward
6 - YouTube
To launch the YouTube App.
7 - (Apps) / Public Value* / IVI**
To launch Your apps page to display the list of Apps
that are pre-installed, or installed by user.
* When the country is set to France, the key will be the
quick key to launch Public Value tab on Home screen.
** When the country is set to Russia, the key will be the
quick key to launch the IVI app.
4.2. Pair Your Remote Control
to TV
This remote control uses both Bluetooth® and IR
(infrared) to send its commands to the TV.
• You can use this remote control via IR (infrared) for
most operations.
• To use advanced operation like voice search, you need
to pair (link) the TV with the remote control.
When you start the initial TV installation, the TV invites
you to press Home + Back key to pair the remote
control. It is suggested to complete the pairing during
the first TV installation.
Note:
1 - Once the remote control has entered pairing mode
successfully, the LED indicator around the microphone
on the front side of the remote control starts blinking.
2 - The remote control must be kept close to the TV
(within 1m distance) during pairing in order to ensure
11
success.
3 - If the TV does not launch the voice control
field when press , pairing was unsuccessful.
4 - It is advisable to wait until the set has fully started up
and launched all background processes before pairing
mode is entered as the toast message containing
further instructions may appear too late, thereby
negatively impacting the pairing procedure.
Pairing or pairing again
If the pairing with the remote control was lost, you can
pair the TV with the remote control again.
You can press Home + Back key (approximate for 3
seconds) for pairing.
Alternatively, go to Settings > Remote and
accessories > Remote control settings > Pair remote
control, then follow the on-screen instructions.
A message appears when the pairing is successful.
Remote Control Software
Settings > Remote and accessories > Remote control
settings > Remote control info
Once the remote control is paired, you can check the
current remote control software version.
Settings > Remote and accessories > Remote control
settings > Update remote control software
Check available remote control software for updates.
4.3. Voice Search
You can search for videos, music or anything else on the
Internet by simply using your voice. You can speak into
the microphone on the remote control.
You need to pair the remote control to the TV before
use voice search.
To use Voice:
1 - Press and hold the
key on remote control, the
blue light on the remote control lights up and the
search field opens, the microphone is active.
2 - Speak out what you are looking for with clear
pronunciation. Once the voice input is done, release the
key to start the search. It might take some time for
the results to appear.
3 - In the list of search results, you can select the item
you want.
4.4. IR Sensor
The TV can receive commands from a remote control
that uses IR (infrared) to send commands. If you use
such a remote control, always make sure you point the
remote control at the infrared sensor on the front of
the TV.
Warning
Do not put any objects in front of IR sensor of the TV, it
may block the IR signal.
4.5. Charging and Cleaning
Wired and Wireless charging the remote control
Refer to the Quick Start Guide in your product package
for detailed information about charging the remote
control.
If the TV does not react on a key press on the remote
control or charging notification is received on TV, you
can charge the remote control with the USB type-c
connector in front of the remote control.
To charge the remote control, connect it with the USB
cable that come with your remote control to your USB
power supply device. The input power of the remote
control is 5.0V 0.5A, please check the power voltage
before connecting to charge.
When the remote control is charging, the microphone
LED indicator on top of remote control will blink or turn
on:
• White LED at microphone hole will be glowing during
charging.
• White LED at microphone hole turns on at full charge.
• No LED blinking if any charging fault detected.
Wireless charging coil is located at the Philips logo at
the reverse side of the remote control. Using a
compatible Qi wireless charger, the remote control can
be charged by placing it on the wireless charging
device/pad*. If the remote control is not aligned
properly with the wireless charger, the white LED may
blink rapidly.
* Note: Wireless charging device/pad is not included in
product package.
Cleaning
Your remote control is treated with a scratch-resistant
coating.
12
To clean the remote control, use a soft damp cloth.
Never use substances such as alcohol, chemicals or
household cleaners on the remote control.
4.6. Simple Setup App for Set
Top Box
Simple Setup app will allow user to control their set top
box using the TV remote control (via IR control to the
set top box).
Setup via App for connected set top box
1 - Connect a set top box via HDMI to TV.
2 - Launch Simple Setup app on TV
3 - To setup for a new set top box, select the brand and
model for your set top box.
Simple Setup app on TV will send set top box IR code
database via Bluetooth® to TV remote control.
Control of set top box using TV remote control
1 - When user is watching TV source, TV remote control
will be in TV mode and sending TV IR codes.
2 - When Simple Setup app is running on TV, it will
detect when user switch to HDMI input for set top box
and trigger TV remote control to switch to send set top
box IR codes during key press.
13
5. Switching On and
Off
5.1. On or Standby
Make sure the TV is connected to the mains AC power.
Connect the supplied power cord to the AC
in connector at the back of the TV. The indicator light at
the bottom of the TV lights up.
Switch on
Press on the remote control to switch the TV on. You
can also press the small joystick key on the bottom of
the TV to switch the TV on in case you can't find the
remote control or its batteries are empty.
Reboot
Long press on the remote control for three seconds
to reboot the TV.
Switch to standby
To switch the TV to standby, press on the remote
control. You can also press the small joystick key on the
back of the TV.
In standby mode, the TV is still connected to the mains
power but consumes very little energy.
To switch off the TV completely, disconnect the power
plug.
When disconnecting the power plug, always pull the
power plug, never the cord. Ensure that you have full
access to the power plug, power cord and outlet socket
at all times.
5.2. Keys on TV
If you lost the remote control or its batteries are empty,
you can still do some basic TV operations.
To open the basic menu:
1 - With the TV switched on, press the joystick key on
the back of the TV to bring up the basic menu.
2 - Press left or right to select Volume, Channel
or Sources. Select Demo, to start a demo movie.
3 - Press up or down to adjust the volume or tune to the
next or previous channel. Press up or down to go
through the list of sources, including the tuner
selection. Press the joystick key to start the demo movie.
4 - The menu will disappear automatically.
To switch the TV on standby, select and press the
joystick key.
14
6. Channel
Installation
6.1. Satellite Installation
About Installing Satellites
Up to 4 Satellites
You can install up to 4 satellites (4 LNBs) on this TV.
Select the exact number of satellites you wish to install
at the start of the installation. This will speed up the
installation.
Unicable
You can use a Unicable system* to connect the antenna
dish to the TV. You can select Unicable for up to 4
satellites at the start of the installation.
* Note: supports Unicable 1 (EN50494) and Unicable 2
(EN50607/JESS).
Start the Installation
Make sure your satellite dish is connected correctly and
is perfectly aligned before you start the installation.
To start the satellite installation:
1 - Select Settings > Channels and
inputs > Channels > Satellite Installation and
press OK. Enter your PIN code if necessary.
2 - Select Search for Satellite and press OK.
3 - Select Search and press OK. TV will search for
satellites.
4 - Select Install and press OK. The TV shows the current
satellite installation setup.
If you want to change this setup, select Settings.
If you don't want to change the setup, select Search. Go
to step 5.
5 - In Installation System, select the number of satellites
you want to install or select one of the Unicable
systems. When you select Unicable, you can choose the
User Band Numbers and enter the User Band
Frequencies for each tuner. In some countries, you can
adjust some expert settings for each LNB in More
Settings.
6 - The TV will search for the satellites available on the
alignment of your antenna dish. This may take a few
minutes. If a satellite is found, its name and reception
strength are shown on screen.
7 - When the TV found the satellites you need,
select Install.
8 - If a satellite offers Channel Packages, the TV will
show the available packages for that satellite. Select the
package you need. Some packages offer
a Quick or Full install for their available channels, select
one or the other. The TV will install the satellite
channels and radio stations.
9 - To store the satellite setup and installed channels
and radio stations, select Finish.
Satellite Installation Settings
The satellite installation settings are preset according to
your country. These settings determine how the TV
searches and installs satellites and its channels. You can
always change these settings.
To change the satellite installation settings:
1 - Start the satellite installation.
2 - On the screen where you can start searching for
satellites, select Configure and press OK.
3 - Select the number of satellites you want to install or
select one of the Unicable systems. When you select
Unicable, you can choose the User Band Numbers and
enter the User Band Frequencies for each tuner.
4 - When you're done, select Next and press OK.
5 - On the Settings menu, press Back to return to the
screen to start searching for satellites.
Homing Transponder and LNB
In some countries, you can adjust the expert settings for
homing transponder and each LNB. Only use or change
these settings when a normal installation fails. If you
have non-standard satellite equipment, you can use
these settings to overrule the standard settings. Some
providers might give you some transponder or LNB
values which you can enter here.
Back
Satellite CAMs
If you use a CAM – a Conditional Access Module with a
smart card – to watch satellite channels, we recommend
to do the satellite installation with the CAM inserted in
the TV.
Most CAMs are used to descramble channels.
Newest generation CAMs can install all the satellite
channels by themselves on your TV. The CAM will invite
you to install its satellite(s) and channels. These CAMs
not only install and descramble the channels but also
handle regular channel updates.
15
Channel Packages
Satellite operators can offer channel packages that
bundle free channels (free-to-air) and offer a sorting
that suits a country. Some satellites offer subscription
packages - a collection of channels you pay for.
If you choose a subscription package, the TV might ask
you to select a Quick or Full installation.
Select Quick to install the channels of the package only
or select Full to install the package and all other
available channels too. We recommend a Quick
installation for subscription packages. If you have
additional satellites that are not part of your
subscription package, we recommend a Full installation.
All installed channels are put in the channels list All.
Unicable Setup
The Unicable System
You can use a Single Cable system or Unicable system*
to connect the antenna dish to the TV. A Single Cable
system uses one cable to connect the satellite dish to all
satellite tuners in its system. A Single Cable system is
typically used in apartment buildings. If you use a
Unicable system, the TV will ask you to assign a user
band number and corresponding frequency during the
installation. You can install up to 4 satellites with
Unicable on this TV.
If you notice some missing channels after a Unicable
installation, another installation might have been done
at the same moment on the Unicable system. Do the
installation again to install the missing channels.
* Note: supports Unicable 1 (EN50494) and Unicable 2
(EN50607/JESS).
User Band Number
In a Unicable system, each connected satellite tuner
must be numbered (e.g. 0, 1, 2 or 3, etc.).
You can find the available user bands and their number
on the Unicable switchbox. User band is sometimes
shortened as UB. There are Unicable switchboxes that
offer 4 or 8 user bands. If you select Unicable in the
settings, the TV will ask you to assign the unique user
band number for each built-in satellite tuners. A
satellite tuner cannot have the same user band number
as another satellite tuner in the Unicable system.
User Band Frequency
Next to the unique user band number, the built-in
satellite receiver needs the frequency of the selected
user band number. These frequencies are mostly shown
next to the user band number on a Unicable switchbox.
Manual Channel Update
You can always start a channel update yourself.
To start a channel update manually:
1 - Select Settings > Channels and inputs >
Channels > Satellite Installation and press OK.
2 - Select Search for Channels and press OK.
3 - Select Update Channels and press OK. The TV will
start updating. The update may take a few minutes.
4 - Follow the instructions on screen. The update may
take a few minutes.
5 - Select Finish and press OK.
Manual Installation
Manual Installation is intended for expert users.
You can use Manual Installation to quickly add new
channels from a satellite transponder. You need to
know the frequency and polarisation of the
transponder. The TV will install all channels of that
transponder. If the transponder was installed before, all
its channels - the former and the new ones - are moved
to the end of the channel list All.
You cannot use Manual installation if you need to
change the number of satellites. If this is needed, you
have to do a complete installation with Install Satellites.
To install a transponder:
1 - Select Settings > Channels and inputs >
Channels > Satellite Installation and press OK.
2 - Select Manual Installation and press
(right) to
enter the menu.
3 - If you have more than 1 satellite installed,
select LNB for which you want to add channels.
4 - Set the Polarisation you need. If you set the Symbol
Rate Mode to Manual, you can enter the symbol rate
in Symbol Rate manually.
5 - Press the Arrow / navigation keys to adjust the
frequency, and select Done.
6 - Select Search and press OK. The signal strength is
shown on screen.
7 - If you want to store the channels of a new
transponder, select Store and press OK.
8 - Press (left) repeatedly if necessary, to close the
menu.
16
Homing Transponder and LNB
In some countries, you can adjust the expert settings for
homing transponder and each LNB. Only use or change
these settings when a normal installation fails. If you
have non-standard satellite equipment, you can use
these settings to overrule the standard settings. Some
providers might give you some transponder or LNB
values which you can enter here.
LNB Power
By default, LNB Power is set to Automatic.
22 kHz Tone
By default, the Tone is set to Automatic.
Low LO Frequency / High LO Frequency
The local oscillator frequencies are set to standard
values. Adjust the values only in case of exceptional
equipment that needs different values.
Problems
The TV cannot find the satellites I want or the TV
installs the same satellite twice
• Make sure that the correct number of satellites is set
in Settings at the start of the installation. You can set
the TV to search for One, Two or 3/4 satellites.
A dual head LNB cannot find a second satellite
• If the TV finds one satellite but cannot find a second
one, turn the dish a few degrees. Align the dish to get
the strongest signal on the first satellite. Check the
signal strength indicator of the first satellite on screen.
With the first satellite set at the strongest signal, select
Search again to find the second satellite.
• Make sure the settings are set to Two Satellites.
Changing the installation settings did not solve my
problem
• All settings, satellites and channels are only stored at
the end of the installation when you finish.
All satellite channels are gone
• If you use a Unicable system, make sure you assigned
two unique user band numbers for both built-in tuners
in the Unicable settings. It might be that another
satellite receiver in your Unicable system is using the
same user band number.
Some satellite channels seem to have disappeared
from the channel list
• If some channels seem to be gone or displaced, the
broadcaster might have changed the transponder
location of these channels. To restore the channel
positions in the channel list, you can try an update of
the channel package.
I cannot remove a satellite
• Subscription packages do not allow removing a
satellite. To remove the satellite, you have to do a
complete installation again and select another package.
Sometimes the reception is poor
• Check if the satellite dish is solidly mounted. Strong
winds can move the dish.
• Snow and rain can degrade the reception.
Operator Apps
HD+ OpApp
HD+ OpApp
HD+ OpApp* is an app provided by HD+ for Germany
users that can run a virtual set-top box on TV. The app
has the applications and features that you previously
needed a physical set-top box to access.
You need internet connection and accept the Philips
Terms of Use, the Privacy Policy and Smart TV Terms of
Use to install the HD+ OpApp. You can install the App
either using the Apps Screen or the Search for satellites
option in the Settings Menu.
If the HD+ OpApp cannot be downloaded or installed,
you may try to download again later. If problem
persists, please contact HD+.
Once the HD+ OpApp has been installed successfully,
you can start the free period. Please switch the source
to Watch Satellite after the installation. If you have
been using a CAM Module for HD+ before, you can
remove it now. If a CICAM is inserted in the TV, it will
not be used to descramble the signal when you are
watching a satellite channel.
After HD+ OpApp is installed, there are some features
will be affected.
• Recording and reminder functionalities are not
allowed for satellite channels.
• Favourite list is only available in Antenna/Cable.
• The channel selection, TV Guide, channel information
are replaced by the OpApp user interface
• Satellite channels renaming and cloning will be
disabled.
* Note: HD+ OpApp is only available for HD+ subscriber
and the country setting is Germany.
M7 TV App
M7 TV App
M7 TV App* is an app provided by M7 subscribers that
can run a virtual set-top box on TV. The app has the
17
applications and features that you previously needed a
physical set-top box to access.
You need internet connection and accept the Philips
Terms of Use, the Privacy Policy and Smart TV Terms of
Use to install the M7 TV App. You can install the App
either using the Apps Screen or the Search for satellites
option in the Settings Menu.
If the M7 TV App cannot be downloaded or installed,
you may try to download again later. If problem
persists, please contact M7.
Once the M7 TV App has been installed successfully,
you can start to receive additional commercial channels
in HD and UHD quality. Please switch the source to
Watch Satellite after the installation. If you have been
using a CAM Module for M7 before, continue to use it
to descramble the signal when you are watching a
satellite channel.
After M7 TV App is installed, there are some features
will be affected.
• Recording and reminder functionalities are not
allowed for satellite channels.
• Favourite list is only available in Antenna/Cable.
• The channel selection, TV Guide, channel information
are replaced by the TV App user interface
• Satellite channels renaming and cloning will be
disabled.
* Note: M7 TV App is only available for M7 subscriber of
certain countries only.
6.2. Antenna Installation
Update Channels
Automatic Channel Update
If you receive digital channels, you can set the TV to
automatically update these channels.
Once a day, at 7 AM, the TV updates the channels and
stores new channels. New channels are stored in the
Channels List and are marked with a . Channels
without a signal are removed. The TV must be in
standby to automatically update channels. You can
switch off Automatic Channel Update.
To switch off the automatic update:
1 - Select Settings > Channels and inputs >
Channels > Antenna/Cable Installation or Antenna
Installation and press OK.
2 - Enter your PIN code if necessary.
3 - Select Automatic Channel Update and press OK.
4 - Select Off and press OK.
5 - Press (left) to go back one step or press Back to
close the menu.
When new channels are found or if channels are
updated or removed, a message is shown at TV start up.
To avoid this message to appear after every channel
update, you can switch it off.
To switch off the message:
1 - Select Settings > Channels and inputs >
Channels > Antenna/Cable Installation or Antenna
Installation and press OK.
2 - Enter your PIN code if necessary.
3 - Select Channel Update Message and press OK.
4 - Select Off and press OK.
5 - Press (left) to go back one step or press Back to
close the menu.
In certain countries, the Automatic channel update is
done while watching TV or on any moment when the
TV is in standby.
Manual Channel Update
You can always start a channel update yourself.
To start a channel update manually:
1 - Select Settings > Channels and inputs >
Channels > Antenna/Cable Installation or Antenna
Installation and press OK.
2 - Enter your PIN code if necessary.
3 - Select Search for Channels and press OK.
4 - Select Start and press OK.
5 - Select Update Digital Channels, select Next and
press OK.
6 - Select Start and press OK to update the digital
channels. This can take a few minutes.
7 - Press (left) to go back one step or press Back to
close the menu.
Reinstall Channels
Reinstall All Channels
You can reinstall all channels and leave all other TV
settings untouched.
If a PIN code is set, you will need to enter this code
before you can reinstall channels.
To reinstall channels:
1 - Select Settings > Channels and Inputs >
Channels > Antenna/Cable Installation or Antenna
Installation and press OK.
2 - Enter your PIN code if necessary.
3 - Select Search for Channels and press OK.
4 - Select Start and press OK.
5 - Select Advanced channel reinstall and press OK.
6 - Select the type of installation you want, Antenna
(DVB-T) or Cable (DVB-C) and press OK.
7 - Select the type of channels you want, Digital and
Analogue* Channels or Only Digital Channels and
18
press OK.
8 - Select Start and press OK to reinstall channels. This
can take a few minutes.
9 - Press (left) to go back one step or press Back to
close the menu.
* Note: Analogue channel support is not available for
countries that have completed analogue switched off.
Factory reset
You can redo a full TV installation. The TV is completely
reinstalled.
To redo a full TV installation:
1 - Select Settings > System > About > Reset >
Factory reset and press OK.
2 - Enter your PIN code if necessary.
3 - The TV will reinstall completely. All settings will be
reset and installed channels will be replaced. The
installation can take a few minutes.
4 - Press (left) to go back one step or press Back to
close the menu.
DVB Settings
DVB-T or DVB-C Reception
During the channel installation, just before you search
for channels, you selected Antenna (DVB-T) or Cable
(DVB-C). Antenna DVB-T searches for terrestrial
analogue channels and digital DVB-T/T2 channels.
Cable DVB-C searches for analogue and digital channels
available from a cable DVB-C operator.
DVB-C Channel Installation
For ease of use, all DVB-C settings are set to automatic.
If your DVB-C operator gave you specific DVB-C values,
the network ID or network frequency, enter these
values when the TV asks for them during installation.
Channel Number Conflicts
In some countries, different TV channels (broadcasters)
might have the same channel number. While installing,
the TV shows the list with channel number conflicts.
You need to select which TV channel you want to install
on a channel number with multiple TV channels.
Network Frequency Mode
If you intend to use the fast Quick Scan method
in Frequency Scan to search for channels,
select Automatic. The TV will use 1 of the predefined
network frequencies (or HC - homing channel) as used
by most cable operator in your country.
If you received a specific network frequency value to
search for channels, select Manual.
Network Frequency
With the Network Frequency Mode set to Manual, you
can enter the network frequency value received from
your cable operator here. To enter the value, use the
number keys.
Frequency Scan
Select the method of searching for channels. You can
select the faster Quick Scan method and use the
predefined settings used by most cable operator in your
country.
If this results in having no channels installed or if some
channels are missing, you can select the extended Full
Scan method. This method will take more time to
search for and install channels.
Frequency Step Size
The TV searches for channels in steps of 8 MHz.
If this results in having no channels installed or if some
channels are missing, you can search in smaller steps
of 1 MHz. Using the 1MHz steps will take more time to
search for and install channels.
Digital Channels
If you know your cable operator is not offering digital
channels, you can skip searching for digital channels.
Analogue Channels
If you know your cable operator is not offering
analogue channels, you can skip searching for analogue
channels.
Free / Scrambled
If you have a subscription and a CAM - Conditional
Access Module for pay TV services, select Free +
Scrambled. If you did not subscribe to pay TV channels
or services, you can select Free Channels Only.
Reception Quality
You can check the quality and signal strength of a
digital channel. If you have your own antenna, you can
reposition the antenna to try and improve the
reception.
To check the reception quality of a digital channel:
1 - Tune to the channel.
19
2 - Select Settings > Channels and inputs >
Channels > Antenna/Cable Installation or Antenna
Installation and press OK. Enter your PIN code if
necessary.
3 - Select Digital: Reception Test and press OK.
4 - Select Search and press OK. The digital frequency is
shown for this channel.
5 - Select Search again and press OK to check the signal
quality of this frequency. The test result is shown on
screen. You can reposition the antenna or check the
connections to possibly improve the reception.
6 - You can also change the frequency yourself. Select
the frequency number one by one and use the Arrow /
navigation keys to change the value. Select Search and
press OK to test the reception again.
7 - Press (left) repeatedly if necessary, to close the
menu.
6.3. Channel List Copy
Introduction
Channel List Copy is intended for dealers and expert
users.
With Channel List Copy, you can copy the channels
installed on one TV onto another Philips TV of the same
range. With Channel List Copy, you avoid the time-
consuming channel search by uploading a predefined
channel list on a TV. Use a USB flash drive of minimum 1
GB.
Conditions
• Both TVs are from the same year range.
• Both TVs have the same hardware type. Check the
hardware type on the TV type plate on the back of the
TV.
• Both TVs have compatible software versions.
• For the Netherlands or any of these cable operators
(Switzerland:Sunrise / Austria:Magenta / Poland:UPC /
Romania:Vodafone / Hungary:Vodafone /
Ireland:VirginMedia), the channel list copy is limited to
satellite channel list copy. The terrestrial and cable
channels list will not be copied or erased.
Current channel version
To check the current version of the channel list:
1 - Select Settings > Channels and inputs > Channels
and select Channel List Copy.
2 - Check the version information from Current Version.
Current software version
You can go to Settings > System > About > SW
version to view the version number of current TV
software.
Copy a Channel List
To copy a channel list:
1 - Switch on the TV. This TV should have channels
installed.
2 - Plug in a USB flash drive.
3 - Select Settings > Channels and inputs > Channels
> Channel List Copy and press OK.
4 - Select Copy to USB and press OK. You might be
asked to enter the Child Lock PIN code to copy the
channel list.
5 - When copying is done, unplug the USB flash drive.
6 - Press (left) repeatedly if necessary, to close the
menu.
Now you can upload the copied channel list onto
another Philips TV.
Channel List Version
Check the current version of the channel list:
1 - Select Settings > Channels and inputs >
Channels and press (right) to enter the menu.
2 - Select Channel List Copy and select Current Version,
then press OK.
3 - Press (left) repeatedly if necessary, to close the
menu.
Upload a Channel List to TV
To not Installed TVs
Depending on whether your TV is already installed or
not, you must use a different method to upload a
channel list.
To a TV that is not yet installed
1 - Plug in the power plug to start the installation and
select language and country. You can skip the channel
search. Finish the installation.
2 - Plug in the USB flash drive that holds the channel list
of the other TV.
3 - To start the channel list upload,
select Settings > Channels and inputs > Channels >
Channel List Copy > Copy to TV and press OK. Enter
your PIN code if necessary.
4 - The TV notifies you if the channel list is copied to the
TV successfully. Unplug the USB flash drive.
To Installed TVs
Depending on whether your TV is already installed or
not, you must use a different method to upload a
channel list.
To an already installed TV
20
1 - Plug in the USB flash drive that holds the channel list
of the other TV.
2 - To start the channel list upload,
select Settings > Channels and inputs > Channels >
Channel List Copy > Copy to TV and press OK. Enter
your PIN code if necessary.
3 - The TV notifies you if the channel list is copied to the
TV successfully. Unplug the USB flash drive.
* Note: The country of the TV will changed to that of
the source (USB) after the cloning has completed.
6.4. Internet Channel
Installation
Search and Update Internet Channels
Search Internet channels
Settings > Channels and
inputs > Channels > Internet channel installation
> Search for channels
1 - Select Search for channels and press OK.
2 - Select Update channels to update the installed
internet channel list.
Select Reinstall channels to do a full re-installation
which takes you through each step.
Select Install new channels will install new internet
channel list. You can install up to 3 internet channel
lists.
Select Uninstall channels will uninstall the selected
internet channel list.
3 - Press OK to search channels. This can take a few
minutes.
Automatic channel update for Internet channels
Settings > Channels and
inputs > Channels > Internet channel installation
> Automatic channel update
Turn on to set the TV to automatically update the
Internet channels.
Automatic channel update
Once a day, at 6 AM, the TV updates the channels and
stores new channels. New channels are stored in the All
channels list but also in the New channels list. Empty
channels are removed.
If new channels are found or if channels are updated or
removed, a message is shown at TV start up. The TV
must be in standby to automatically update channels.
21
7. Channels
7.1. Install Channels
For more information about how to install channels,
check on Help > User manual > Channel Installation.
7.2. Channel Lists
About Channel Lists
After a channel installation, all channels appear on the
All channel list. The channels displayed in All Channel
list is listed based on genre*. For example: Premium,
Premium News, Premium Local, Children, Sport, etc. The
Premium genre are top broadcast channels positioned
with market share above 3%. Channels are shown with
their name and logo if this information is available.
With a channel list selected, press the arrows (up)
or (down) to select a channel, then press OK to watch
the selected channel. You only tune to the channels in
that list when using
or
keys.
* Note: The listed by genre function is only apply to
Germany.
Channel icons
After an Automatic Channel Update of the channel list,
newly found channels are marked with a (star).
If you lock a channel, it will be marked with a (lock).
Radio stations
If digital broadcasting is available, digital radio stations
are installed during installation. Switch to a radio
channel just like you switch to a TV channel.
This TV can receive digital television standard DVB. TV
may not work properly with some operators of digital
television, non-compliance with requirements of the
standard in full.
Open a Channel List
Next to the list with all channels, you can select a
filtered list or you can select one of the favourite lists
you created.
To open the current channel list:
1 - Press , to switch to TV.
2 - Press OK* to open the current channel list.
3 - Alternately, long press TV Guide to open the
channel list.
4 - Press Back to close the channel list.
* The operation may not work when OK key is occupied
by HbbTV.
To select one of the channel lists:
1 - With a channel list open on screen,
press OPTIONS.
2 - Select Select Channel List and press OK.
3 - In the list menu, select one of the available channel
lists and press OK.
Alternatively, you can select the list name at the top of
the channel list and press OK to open the list menu.
Search for a Channel
You can search for a channel to find it in a long list of
channels.
The TV can search for a channel within one of the main
channel lists - the Satellite, Antenna or Cable channel
list.
To search for a channel:
1 - Press .
2 - Press OK to open the current channel list.
3 - Press OPTIONS.
4 - Select Select Channel List and press OK.
5 - Select Filter Antenna Channels or Filter Cable
Channels and press OK.
6 - Select Search Channel and press OK to open a text
field.You can use the remote control keyboard (if
available) or the on-screen keyboard to enter text.
7 - Enter a name or part of a name and select Apply and
press OK. The TV will search for matching channel
names in the list you selected.
Search results are listed as a channel list – see the list
name at the top. The search will return the matching
channel name with the result arranged in alphabetical
order. The search results disappear once you select
another channel list or close the list with search results.
7.3. Channel List sorting
You can do channel list sorting with all channels. You
can set the channel list to show only TV channels or
only Radio stations. For Satellite/Antenna/Cable
channels you can set the list to show the Free-to-Air or
the Scrambled channels.
To set a filter on a list with all channels:
22
1 - Press .
2 - Press OK to open the current channel list.
3 - Press OPTIONS.
4 - Select Select Channel List and press OK.
5 - Select Filter Antenna Channels or Filter Cable
Channels according to the list you want to filter, and
press OK.
6 - In the Options menu, select the filter you want and
press OK to activate. The name of the filter appears as
part of the channel list name on top of the channel list.
7 - Press (left) to go back one step or press to close
the menu.
7.4. Watching channels
Tune to a Channel
To start watching TV channels, press . The TV tunes
to the channel you last watched.
Switch Channels
To switch channels, press
or
.
If you know the channel number, type in the number
with the number keys. Press OK after you entered the
number to switch immediately.
If the information is available from the Internet, the TV
shows the current programme name and details
followed by the next programme name and details.
Previous channel
To switch back to the previously tuned channel,
press Back.
You can also tune to channels from a Channel List.
Lock a Channel
Lock and Unlock a Channel
To prevent children from watching a channel, you can
lock a channel. To watch a locked channel, you must
enter the 4 digit Child Lock PIN code first. You cannot
lock programmes from connected devices.
To lock a channel:
1 - Press .
2 - Press OK to open the channel list. If necessary
change the channel list.
3 - Select the channel you want to lock.
4 - Press OPTIONS and select Lock Channel and
press OK.
5 - Enter your 4 digit PIN code if the TV asks for it. A
locked channel is marked with a (lock).
6 - Press (left) to go back one step or press Back to
close the menu.
To unlock a channel:
1 - Press .
2 - Press OK to open the channel list. If necessary
change the channel list.
3 - Select the channel you want to unlock.
4 - Press OPTIONS and select Unlock Channel and
press OK.
5 - Enter your 4 digit PIN code if the TV asks for it.
6 - Press (left) to go back one step or press Back to
close the menu.
If you lock or unlock channels in a channel list, you only
have to enter the PIN code just once until you close the
channel list.
Parental Rating
To prevent children from watching a programme not
suitable for their age, you can set an age rating.
Digital channels can have their programmes age rated.
When the age rating of a programme is equal to or
higher than the age you have set as age rating for your
child, the programme will be locked. To watch a locked
programme, you must enter the Parental Rating (only
available for certain countries) code first.
To set an age rating:
1 - Select Settings > System > Child Lock > Parental
Rating and press OK.
2 - Enter a 4-digit Child lock code. If you did not set a
code yet, select Set Code in Child Lock. Enter a 4-digit
Child lock code and confirm. Now you can set an age
rating.
3 - Back in Parental Rating, select the age and press OK.
4 - Press (left) repeatedly if necessary, to close the
menu.
To switch off the parental age rating, select None.
However, in some countries you must set an age rating.
For some broadcasters/operators, the TV only locks
programmes with a higher rating. The parental age
rating is set for all channels.
Channel Options
Open Options
While watching a channel, you can set some options.
Depending on the type of channel you are watching
(analogue or digital) or depending on the TV settings
you made, some options are available. For example, the
Screen off option is only available for radio channels. It
is suggested to turn off the TV screen for saving energy
and protecting the screen.
To open the options menu:
23
1 - While watching a channel, press OPTIONS.
2 - Press OPTIONS again to close.
Subtitles
Switch On
Digital broadcasts can have subtitles for their
programmes.
To show the subtitles:
Press OPTIONS and select Subtitles.
You can switch subtitles On or Off. Alternatively you
can select Automatic.
Automatic
If language information is part of the digital broadcast
and the broadcasted programme is not in your
language (the language set on TV), the TV can show
subtitles automatically in one of your preferred subtitle
languages. One of these subtitle languages must also
be part of the broadcast.
You can select your preferred subtitle languages
in Subtitle Language.
Subtitles from Text
If you tune to an analogue channel, you need to make
the subtitles available for each channel manually.
1 - Switch to a channel and press TEXT to open Text.
2 - Enter the page number for subtitles.
3 - Press TEXT again, to close Text.
If you select On in the Subtitle menu when watching
this analogue channel, subtitles will be shown if
available.
To know if a channel is analogue or digital, switch to
the channel and open Information in OPTIONS.
Subtitle Language
Preferred Subtitle Languages
A digital broadcast can offer several subtitle languages
for a programme. You can set a preferred primary and
secondary subtitle language. If subtitles in one of these
languages are available, the TV will show the subtitles
you selected.
To set the primary and secondary subtitle language:
1 - Go to Settings > Channels and inputs > Channels.
2 - Select Primary Subtitles or Secondary Subtitles.
3 - Select the language you need and press OK.
4 - Press (left) to go back one step or press Back to
close the menu.
Select a Subtitle Language
If none of the preferred subtitle languages are
available, you can select another subtitle language if
available. If no subtitle languages are available, you
cannot select this option.
To select a subtitle language when none of your
preferred languages are available:
1 - Press OPTIONS.
2 - Select Subtitle Language and select one of the
languages as subtitles temporarily.
Audio Language
Preferred Audio Language
A digital broadcast can offer several audio languages
(spoken languages) for a programme. You can set a
preferred primary and secondary audio language. If
audio in one of these languages is available, the TV will
switch to the audio language.
To set the primary and secondary audio language:
1 - Go to Settings > Channels and inputs > Channels.
2 - Select Primary Audio or Secondary Audio.
3 - Select the language you need and press OK.
4 - Press (left) to go back one step or press Back to
close the menu.
Select an Audio Language
If none of the preferred audio languages are available,
you can select another audio language if available. If no
audio languages are available, you cannot select this
option.
To select an audio language when none of your
preferred languages are available:
1 - Press OPTIONS.
2 - Select Audio Language and select one of the
languages as audio temporarily.
Universal Access
Settings > Channels and
inputs > Channels > Universal access.
With Universal Access switched on, the TV is prepared
for use for the deaf, hard of hearing, blind or partially
sighted people.
Universal access for hearing impaired people
Settings > Channels and
inputs > Channels > Universal access > Hearing
impaired.
24
• Some digital TV channels broadcast special audio and
subtitles adapted for the hard of hearing or deaf
people.
• Switched on, the TV automatically switches to the
adapted audio and subtitles, if available.
Universal access for blind or partially sighted people
Settings > Channels and
inputs > Channels > Universal access > Audio
description.
Digital TV channels can broadcast special audio
commentary describing what is happening on screen.
Settings > Channels and
inputs > Channels > Universal access > Audio
description > Mixed volume, Audio effects, Speech.
• Select Mixed volume, you can mix the volume of the
normal audio with the audio commentary.
• Switch Audio effects on for extra audio effects in the
commentary audio, like stereo or fading sound.
• Select Speech to set speech
preference, Descriptive or Subtitles.
Dialogue enhancement
Settings > Channels and
inputs > Channels > Universal access > Dialogue
enhancement.
Increase the intelligibility of dialogue and commentary,
if available. Only available when sound setting Clear
dialogue is On and audio stream is AC-4.
HbbTV and Operator Apps Settings
View or adjust the settings for HbbTV and Operator
Apps.
Switch on or off HbbTV
Settings > Channels and inputs > Channels > HbbTV
and Operator Apps settings > HbbTV.
If you want to avoid access to HbbTV pages on a
specific channel, you can block the HbbTV pages for this
channel only.
Switch off History Tracking
Settings > Channels and inputs > Channels > HbbTV
and Operator Apps settings > Tracking.
If switched on, you have no personal preference
regarding the tracking. If switched off, you do not allow
the tracking by HbbTV and Operator Apps (if
applicable) pages.
Remove Cookies
Settings > Channels and inputs > Channels > HbbTV
and Operator Apps settings > Cookies.
Switch the storage of cookies from HbbTV and
Operator Apps (if applicable) pages on or off.
Clear approved app listing
Settings > Channels and inputs > Channels > HbbTV
and Operator Apps settings > Clear approved app
listing.
To clear all User's approved applications.
HbbTV Device ID reset
Settings > Channels and inputs > Channels > HbbTV
and Operator Apps settings > HbbTV Device ID reset.
You can reset your TV unique device identifier. A new
identifier will be created. This will replace your Device
ID with a new identifier.
Common Interface
If you installed a CAM in the Common Interface slot,
you can view the CAM and operator information or do
some CAM related settings.
To view the CAM information:
1 - Press SOURCES.
2 - Select the channel type you are using the CAM
for Watch TV.
3 - Press OPTIONS and select Common Interface.
4 - Select the TV operator of the CAM and press OK. The
following screens come from the TV operator.
CAM Settings
Set profile name for installed CI+/CAM
Settings > Channels and inputs > Channels > CAM
settings > CAM profile name.
Select the type of CI+/CAM
Settings > Channels and inputs > Channels > CAM
settings > CAM interface.
Select USB to enable the USB CAM, then the PCMCIA
CAM will be disabled. Select PCMCIA to enable the
PCMCIA CAM, then the USB CAM will be disabled.
25
Programme Info
View programme details
To call up the details of the selected programme:
1 - Tune to the channel.
2 - Press OPTIONS, select Programme Info and
press OK.
3 - To close this screen, press OK.
View programme information from channel list
To call up the programme information from channel
list:
1 - Tune to the channel, press OK or Channel list to
open the channel list.
2 - Press OPTIONS, select Programme Info and
press OK to view general information of the
programme.
3 - To close this screen, press Back to go back to
channel list.
Mono / Stereo
You can switch the sound of an analogue channel to
Mono or Stereo.
To switch to Mono or Stereo:
1 - Tune to an analogue channel.
2 - Press OPTIONS, select Mono/Stereo and
press (right).
3 - Select Mono or Stereo and press OK.
4 - Press (left) to go back one step or press Back to
close the menu.
7.5. Favourite Channels
About Favourite Channels
In a favourite channel list, you can collect the channels
you like.
You can create 4 different lists* of favourite channels
for easy channel zapping. You can name each
Favourites List individually. Only in a Favourites List you
can reorder channels.
With a Favourites List selected, press the arrows (up)
or (down) to select a channel, then press OK to watch
the selected channel. You only tune to the channels in
that list when using or keys.
* Note: If your installation country is UK or Italy, the
Antenna/Cable channels are only stored in first 2
favourite lists; Satellite/third party app channels are
only stored in last 2 favourite lists.
Create a Favourites List
To create a favourite channels list:
1 - Press , to switch to TV.
2 - Press OK to open the current channel list.
3 - Press OPTIONS.
4 - Select Create Favourites List and press OK.
5 - In the list at the left, select a channel you want as a
favourite and press OK. Channels come in the list at the
right in the order you add them. To undo, select the
channel in the list at the left and press OK again.
6 - If necessary, you can go on selecting and adding
channels as favourites.
7 - To finish adding channels, press Back.
The TV will ask to rename the Favourites List. You can
use the on-screen keyboard.
1 - Use the on-screen keyboard to delete the current
name and enter a new name.
2 - When done, select Close and press OK.
The TV will switch to the newly created Favourites List.
You can add a range of channels in one go or start a
Favourites List by duplicating the channel list with all
channels and removing the channels you do not want.
The channels in the Favourites List are renumbered.
Edit Favourites
To add a consecutive range of channels to a Favourites
List in one go, you can use Edit favourites.
To add a range of channels:
1 - Open the Favourites List where you want to add a
range of channels.
2 - Press OPTIONS, select Edit favourites and
press OK.
3 - In the list at the left select the first channel of the
range you want to add and press OK.
4 - Press (down) to select the last channel of the
range you want to add. The channels are marked at the
right.
5 - Press OK to add this range of channels and confirm.
You can also start creating a Favourites List from Edit
favourites.
26
Rename a Favourites List
To rename a Favourites List:
1 - Open the Favourite List you want to rename.
2 - Press OPTIONS, select Rename Favourites List and
press OK.
3 - Use the on-screen keyboard to delete the current
name and enter a new name.
4 - When done, select Close and press OK.
5 - Press Back to close the channel list.
Remove a Favourites List
To remove a Favourites List:
1 - Open the Favourites List you want to remove.
2 - Press OPTIONS, select Remove Favourites List and
press OK.
3 - Confirm to remove the list.
4 - Press Back to close the channel list.
Duplicate Channel List
To duplicate a Favourites List:
1 - Open the Favourites List you want to duplicate.
2 - Press OPTIONS, select Duplicate channel list and
press OK.
3 - Confirm to duplicate the list.
4 - Press Back to close the channel list.
Reorder Channels
Only in a Favourites List you can change the sequence
of channels (reorder)*.
To change the sequence of channels:
1 - Open the Favourites List you want to reorder.
2 - Press OPTIONS, select Reorder Channels and
press OK.
3 - In the Favourites List, select the channel you want to
reorder and press OK.
4 - With the (up) or (down) keys move the channel
where you want it.
5 - Press OK to confirm the new location.
6 - You can reorder channels with the same method
until you close the Favourites List with the Back key.
* Note: The reorder operation is not available if country
setting is UK or Italy.
7.6. Text / Teletext
Text Pages
If your remote control is with TEXT key, you can
press TEXT to open Text/Teletext while you are
watching TV channels. To close Text, press TEXT key
again.
If your remote control is not with TEXT key,
press OPTIONS while you are watching TV channels,
select Teletext to open Text/Teletext.
Select a Text page
To select a page:
1 - Enter the page number with the number keys.
2 - Use the arrow keys to navigate.
3 - Press a colour key to select a colour-coded subject at
the bottom of the screen.
Text sub-pages
A Text page number can hold several subpages. The
subpage numbers are shown on a bar next to the main
page number.
To select a subpage, press or .
T.O.P. Text pages
Some broadcasters offer T.O.P. Text.
To open T.O.P. Text pages within Text,
press OPTIONS and select T.O.P. Overview.
Text from a connected device
Some devices that receive TV channels can also offer
Text.
To open Text from a connected device:
1 - Press SOURCES, select the device and press OK.
2 - While watching a channel on the device,
press OPTIONS, select Show Device Keys and select
the key and press OK.
3 - Press Back to hide the device keys.
4 - To close Text, press Back again.
Digital Text (UK only)
Some digital broadcasters offer dedicated Digital Text
or interactive TV on their digital TV channels. This
includes normal Text using the number, colour and
arrow keys to select and navigate.
To close Digital Text, press Back.
* The teletext can only be reached when the channels
are installed directly on the TV’s internal tuner and the
set is on TV mode. If a set-top box is being used, the
teletext will be unavailable via TV. In that case, the set-
top box’s teletext can be used instead.
27
Text Options
In Text/Teletext, press OPTIONS to select the
following:
• Freeze page / Unfreeze page
To start or stop the automatic rotation of subpages.
• Dual screen / Full screen
To show the TV channel and Text alongside each other.
• T.O.P. overview
To open T.O.P. Text.
• Enlarge / Normal view
To enlarge the Text page for comfortable reading.
• Reveal
To unhide hidden information on a page.
• Language
To switch the group of characters that Text uses to
display correctly.
Text Setup
Text language
Some digital TV broadcasters have several Text
languages available.
To set your primary and secondary Text language:
1 - Select Settings > Channels and inputs > Channels.
2 - Select Primary Text or Secondary Text and press OK.
3 - Select your preferred Text languages.
4 - Press (left) repeatedly if necessary, to close the
menu.
7.7. Interactive TV
About iTV
With interactive TV, some digital broadcasters combine
their normal TV programme with information or
entertainment pages. On some pages, you can respond
to a programme or vote, do online shopping or pay for
a video-on-demand programme.
HbbTV
Broadcasters use various interactive TV systems e.g.,
HbbTV (Hybrid Broadcast Broadband TV). Interactive TV
is sometimes referred to as Digital Text or Red button.
But each system is distinct.
Visit the broadcaster's Internet website for more
information.
What You Need
Interactive TV is only available on digital TV channels.
To enjoy the full benefits of Interactive TV, you need a
high-speed (broadband) Internet connection to the TV.
HbbTV
If a TV channel offers HbbTV pages, you must first
switch on HbbTV in the TV settings to view the pages.
Settings > Channels and inputs > Channels > HbbTV
and Operator Apps settings > HbbTV > On.
Use iTV
Open iTV pages
Most channels that offer HbbTV or iTV invite you to
press the colour key (red) or OK key to open their
interactive programme.
Navigate iTV pages
You can use the arrow and colour keys, the number
keys and the Back key to navigate the iTV pages.
You can also use the playback keys on remote control
to watch videos within iTV pages.
Digital Text (UK only)
To open Digital Text, press TEXT. To close, press Back.
Close iTV pages
Most iTV pages inform you which key to use to close.
To force an iTV page to close, switch to the next TV
channel and press Back.
28
8. TV Guide
8.1. TV Guide Data
With the TV Guide you can view a list of the current and
scheduled TV programmes of your
channels. Depending on where the TV guide
information (data) is coming from, analogue and digital
channels or only digital channels are shown. Not all
channels offer TV Guide information. The TV can collect
TV Guide information for the channels that are installed
on the TV. The TV cannot collect the TV Guide
information from channels viewed from a digital
receiver or decoder.
8.2. Using the TV Guide
Open the TV Guide
To open the TV Guide, press TV GUIDE. The TV Guide
shows the channels of the selected tuner.
Press TV GUIDE again to close.
The first time you open the TV Guide, the TV scans all
TV channels for programme information. This may take
several minutes. TV Guide data is stored on TV.
Tune to a Programme
From the TV Guide, you can tune to a current
programme.
To switch to the programme (channel), select the
programme and press OK.
View programme details
To call up the details of the selected programme:
1 - Press OPTIONS, select Programme Info and
press OK.
2 - Press Back to close.
Search by Genre
If the information is available, you can look up
scheduled programmes by genre like movies, sports,
etc.
To search for programmes by genre:
1 - Press TV GUIDE.
2 - Press OPTIONS.
3 - Select Search by genre and press OK.
4 - Select the genre you want and press OK. A list with
the found programmes appears.
5 - Press Back to close the menu.
* Note: The Search by genre function is only available
for certain countries.
29
9. Connect Devices
9.1. About Connections
Connectivity Guide
Always connect a device to the TV with the highest
quality connection available. Also, use good quality
cables to ensure a good transfer of picture and sound.
When you connect a device, the TV recognizes its type
and gives each device a correct type name. You can
change the type name if you wish. If a correct type
name for a device is set, the TV automatically switches
to the ideal TV settings when you switch to this device
in the Sources menu.
Antenna port
If you have a Set-top box (a digital receiver) or
Recorder, connect the antenna cables to run the
antenna signal through the Set-top box and/or
Recorder first before it enters the TV. In this way, the
antenna and the Set-top box can send possible
additional channels to the Recorder to record.
HDMI ports
HDMI Quality
An HDMI connection has the best picture and sound
quality. One HDMI cable combines video and audio
signals. Use an HDMI cable for High Definition (HD) TV
signals.
For best signal quality transfer, use an Ultra High Speed
certified HDMI cable and do not use an HDMI cable
longer than 5 m.
If a device connected with HDMI is not working
correctly, check if a different HDMI Ultra HD setting can
solve this problem.
Copy protection
HDMI ports support HDCP (High-bandwidth Digital
Content Protection). HDCP is a copy protection signal
that prevents copying content from a DVD disc or Blu-
ray Disc. Also referred to as DRM (Digital Rights
Management).
HDMI ARC and eARC
Only HDMI 2 on the TV supports HDMI ARC (Audio
Return Channel) and HDMI eARC.
If the device, typically a Home Theatre System (HTS),
soundbar or AV receiver, also has the HDMI ARC
connection, connect it to HDMI 2 on this TV. With the
HDMI ARC connection, you do not need to connect the
extra audio cable that sends the sound of the TV picture
to the HTS. The HDMI ARC connection combines both
signals.
HDMI eARC (Enhanced Audio Return Channel) is an
advancement over the previous ARC. It covers all ARC
features but with higher bandwidth and speed. eARC
supports high quality audio transmission up to192kHz,
24-bit, uncompressed 5.1 and 7.1, and 32-channel
uncompressed audio.
Note: HDMI eARC is only available on HDMI 2.
Use Ultra High-speed HDMI cable for eARC. Only one
eARC device is available at a time.
HDMI CEC - EasyLink
Connect HDMI CEC-compatible devices to your TV, you
can operate them with the TV remote control. EasyLink
HDMI CEC must be switched on on the TV and the
connected device.
Switch on EasyLink
Settings > Channels and inputs > External Inputs
> EASYLINK > EasyLink > On.
Operate HDMI CEC-compatible devices with TV remote
control
Settings > Channels and inputs > External Inputs
> EASYLINK > EasyLink remote control > On.
To turn on or off the EasyLink remote control function.
Please note that you can always control the volume of
connected HDMI CEC-compatible devices irrespective of
this setting.
30
Power off HDMI devices with the TV
Settings > Channels and inputs > External Inputs
> EASYLINK > EasyLink auto device off.
Select On to allow TV to turn the HDMI devices to
standby. Select Off to disable this function.
Power on the TV with HDMI devices
Settings > Channels and inputs > External Inputs
>EASYLINK > EasyLink auto TV on.
Select On to allow HDMI devices to wake up the TV
from standby status. Select Off to disable this function.
Power on the HDMI sound system with TV
Settings > Channels and inputs > External Inputs
> EASYLINK > EasyLink auto ARC on.
Select On to allow TV to wake up the connected HDMI
sound system from standby status. Select Off to disable
this function.
Note:
• EasyLink might not work with devices from other
brands.
• The HDMI CEC functionality has different names on
different brands. Some examples are: Anynet, Aquos
Link, Bravia Theatre Sync, Kuro Link, Simplink and Viera
Link. Not all brands are fully compatible with EasyLink.
Example HDMI CEC branding names are property of
their respective owners.
HDMI Ultra HD
This TV can display Ultra HD signals. Some devices -
connected with HDMI - do not recognise a TV with Ultra
HD and might not work correctly or show distorted
picture or sound.
TV will automatic detect HDMI video device connected
and make TV adjustment to the best matching
configuration. In case you still face black screen or
distorted screen or sound, you can adjust HDMI Ultra
HD setting to Standard for legacy devices.
Set the signal quality for each HDMI connectors
Settings > Channels and inputs > External Inputs >
HDMI (port) > HDMI Ultra HD > Standard, Optimal,
or Optimal (Auto Game xxxHz Pro) / Automatic.
Ultra High Speed certified HDMI cable is highly
recommended for all HDMI connections. To change the
settings, switch to the HDMI source first. Select
Automatic to enable TV automatically matching your
HDMI device. Select Optimal to enable the highest
quality HDMI signal for 4K program or movie watching
(such as Ultra HD 4K set top box, 4K Blu-ray player or
streaming box).
• The setting Optimal allows maximum up to Ultra HD
(100Hz# or 120/144Hz#) RGB 4:4:4 or YCbCr
4:4:4/4:2:2/4:2:0 signals.
• The setting Standard allows maximum up to Ultra HD
(50Hz or 60Hz) YCbCr 4:2:0 signals.
Maximum supported video timing format for HDMI
Ultra HD options:
• Resolution: 3840 x 2160
• Frame rate (Hz): 50Hz, 59.94Hz, 60Hz, 100Hz#,
120Hz#, 144Hz^
• Video data sub-sampling (bit-depth)
- 8 bit: YCbCr 4:2:0, YCbCr 4:2:2*, YCbCr 4:4:4*, RGB
4:4:4*
- 10 bit: YCbCr 4:2:0*, YCbCr 4:2:2*, RGB 4:4:4*
- 12 bit: YCbCr 4:2:0*, YCbCr 4:2:2*
* Supported only when HDMI Ultra HD is set to
Optimal or Optimal (Auto Game xxxHz Pro).
Note:
# 4K2K 100Hz is only supported when HDMI Ultra HD is
set to Optimal in HDMI 1 and HDMI 2.
# 4K2K 120Hz is only supported when HDMI Ultra HD is
set to Optimal or Optimal (Auto Game xxxHz Pro) in
HDMI 1 and HDMI 2.
^ 4K2K 144Hz is only supported when HDMI Ultra HD is
set to Optimal (Auto Game xxxHz Pro) in HDMI 1 and
HDMI 2.
Select Standard if the picture or sound are distorted.
Select Optimal (Auto Game xxxHz Pro) to enable TV to
support all gaming features including HDMI Variable
Refresh Rate* / FreeSync Premium* (HDMI 1 and HDMI
2) / G-Sync* video (on some models only). This option
also enables TV to automatically set Picture style to
Game whenever it is informed by the HDMI device
connected to TV.
* With HDMI Variable Refresh Rate / FreeSync Premium
/ G-Sync supported, the TV changes its refresh rate in
real time according to the frame rate signal to
synchronize with every picture. It is applied to reduce
the lag, judder and frame tearing for better gaming
experience.
Note: G-Sync compatible is supported using Nvidia GTX
30 or 40 series Graphics card only.
Note:
To watch HDR10+ or Dolby Vision content from HDMI
source, you may need to power off your player and
power on again when the player connected to TV
playing such content for the first time. HDR10+ content
is supported only when HDMI Ultra HD is set
to Optimal or Optimal (Auto Game xxxHz Pro). Dolby
Vision content is supported only when HDMI Ultra HD
is set to Optimal (Auto Game xxxHz Pro).
When selecting this option, you may need to power off
your game computer or game console and power on
again to complete the first time setup.
31
9.2. Home Theatre System -
HTS
Connect with HDMI ARC/eARC
Use an HDMI cable to connect a Home Theatre System
(HTS) to the TV. You can connect a Philips Soundbar or
an HTS with a built-in disc player.
HDMI ARC
Only HDMI 2 on the TV can offer the Audio Return
Channel (ARC) signal. Once you have connected the
Home Theatre System, the TV can only send the ARC
signal to this HDMI connection. With HDMI ARC, you do
not need to connect the extra audio cable. The HDMI
ARC connection combines both signals.
HDMI eARC
HDMI eARC (Enhanced Audio Return Channel) is an
advancement over the previous ARC. It supports the
latest high-bitrate audio formats up to192kHz, 24-bit,
and uncompressed 5.1 and 7.1, and 32-channel
uncompressed audio. HDMI eARC is only available on
HDMI 2.
Audio to video synchronisation (sync)
If the sound does not match the video on screen, you
can set a delay on most Home Theatre Systems with a
disc player to match the sound with the video.
Problems with HTS sound
Sound with loud noise
If you watch a video from a plugged in USB flash drive
or connected computer, the sound from your Home
Theatre System might be distorted. This noise is heard
when the audio or video file has DTS sound but the
Home Theatre System has no DTS sound processing.
You can fix this by setting the Digital Out Format of the
TV to Stereo.
Select Settings > Display and sound > Audio out
> Digital out format.
No sound
If you cannot hear the sound from the TV on your
Home Theatre System, check if you connected the
HDMI cable to an HDMI ARC/eARC connection on the
Home Theatre System. HDMI ARC/eARC is only
available on HDMI 2.
9.3. Digital Audio Out -
Optical
Audio Out - Optical is a high quality sound connection.
This optical connection can carry 5.1 audio channels. If
your device, typically a Home Theatre System (HTS), has
no HDMI ARC connection, you can use this connection
with the Audio In - Optical connection on the HTS. The
Audio Out - Optical connection sends the sound from
the TV to the HTS.
9.4. CAM with Smart Card -
CI+
CI+
This TV is ready for the CI+ Conditional Access.
With CI+ you can watch premium HD programmes, like
movies and sports, offered by digital TV operators in
your region. These programmes are scrambled by the
TV operator and descrambled with a prepaid CI+
module.
Digital TV operators provide a CI+ module (Conditional
Access Module - CAM) and an accompanying smart
card, when you subscribe to their premium
programmes. These programmes have a high level of
copy protection.
With the support of CI+ 2.0, this TV can accept the CAM
in both PCMCIA and USB form factor (for all of USB
ports).
Contact a digital TV operator for more information on
terms & conditions.
32
Smart Card
Digital TV operators provide a CI+ module (Conditional
Access Module - CAM) and an accompanying smart
card, when you subscribe to their premium
programmes.
Insert the smart card into the CAM module. See the
instruction you received from the operator.
To insert the CAM in the TV:
1 - Look on the CAM for the correct method of
insertion. Incorrect insertion can damage the CAM and
TV.
2 - While looking at the back of the TV, with the front
of the CAM facing towards you, gently insert the CAM
into the slot COMMON INTERFACE.
3 - Push the CAM in as far as it will go. Leave it in the
slot permanently.
When you switch on the TV, it may take a few minutes
before the CAM is activated. If a CAM is inserted and
subscription fees are paid (subscription methods can
differ), you can watch the scrambled channels
supported by the CAM smart card.
The CAM and smart card are exclusively for your TV. If
you remove the CAM, you will no longer be able to
watch the scrambled channels supported by the CAM.
Passwords and PIN codes
For some CAMs, you must enter a PIN code to watch its
channels. When you set the PIN code for the CAM, we
recommend you to use the same code you are using to
unlock the TV.
To set the PIN code for the CAM:
1 - Press SOURCES.
2 - Select the channel type you are using the CAM for
Watch TV.
3 - Press OPTIONS and select Common Interface.
4 - Select the TV operator of the CAM. The following
screens come from the TV operator. Follow the on-
screen instruction to look up the PIN code setting.
9.5. Smartphones and Tablets
To connect a smartphone or tablet to the TV, you can
use a wireless connection. For a wireless connection, on
your smartphone or tablet download the Philips Smart
TV app from your favourite app store.
9.6. Blu-ray Disc Player
Use an Ultra High speed HDMI cable to connect the Blu-
ray Disc player to the TV.
If the Blu-ray Disc player has EasyLink HDMI CEC, you
can operate the player with the TV remote control.
9.7. Headphones
You can connect a set of headphones to
the connection on the back of the TV. The
connection is a mini-jack 3.5mm. You can adjust the
volume of the headphones separately.
To adjust the volume:
1 - Press Volume, select the headphones icon by
arrows (left) or (right).
2 - Press the arrows (up) or (down) to adjust the
volume.
33
9.8. Game Console
HDMI
For best quality, connect the game console with an
Ultra High speed HDMI cable to the HDMI 1 or HDMI 2
on TV.
If external audio system with HDMI ARC/eARC support
is used together with TV and game console,
recommended connection is: connecting game console
device’s HDMI output to TV HDMI 1 port and
connecting TV HDMI 2 to external audio system’s HDMI
input with another Ultra high speed HDMI cable. To
have best gaming audio effect matching video, you can
set TV Audio output to Multichannel (bypass)
here: Settings > Display and sound > Audio output >
Digital out format.
9.9. USB Keyboard
Connect
Connect a USB keyboard (USB-HID type) to enter text
on your TV.
Use one of the USB connections to connect.
Configure
Install the keyboard
To install the USB keyboard, switch on the TV and
connect the USB keyboard to one of
the USB connections on the TV. When the TV detects
the keyboard for the first time, you can select your
keyboard lay-out and test your selection. If you select a
Cyrillic or Greek keyboard layout first, you can select a
secondary Latin keyboard layout.
To change the keyboard layout setting when a layout
was selected:
1 - Select Settings > System > Keyboard.
2 - Select USB Keyboard Settings, and press OK to start
the keyboard setup.
Special Keys
Keys for entering text
• Enter key = OK
• Backspace = delete character before cursor
• Arrow keys = navigate within a text field
• To switch between keyboard layouts, if a secondary
layout is set, press the Ctrl + Spacebar keys
simultaneously.
Keys for apps and Internet pages
• Tab and Shift + Tab = Next and Previous
• Home = scroll to the top of the page
• End = scroll to the bottom of the page
• Page Up = jump one page up
• Page Down = jump one page down
• * = fit the web page to the screen width
9.10. USB Storage Device
You can view photos or play your music and videos
from a connected USB flash drive or USB hard drive.
Insert a USB storage device in one of
the USB connections on the TV while the TV is switched
on.
The TV detects the device and opens a list showing its
content.
If the contents list does not appear automatically,
press
SOURCES and select USB.
To stop watching the USB storage device content,
press EXIT or select another activity.
To remove the USB storage device safely:
34
1 - Press HOME.
2 - Select the USB drive under Dashboard >
Notifications from top-right corner and press OK.
3 - Select your device and press OK.
4 - Select Eject and press OK.
5 - Wait until the eject procedure is finished and then
pull out the USB storage device.
Ultra HD on USB
You can view photos in Ultra HD resolution from a
connected USB storage device. The TV will downscale
the resolution to Ultra HD if the resolution of the photo
is higher.
9.11. Photo Camera
To view photos stored on your digital photo camera,
you can connect the camera directly to the TV.
Use one of the USB connections on the TV to connect.
Switch on the camera after you made the connection.
If the contents list does not appear automatically,
press SOURCES, and select USB.
Your camera might need to be set to transfer its
content with PTP (Picture Transfer Protocol). Read the
user manual of the digital photo camera.
Ultra HD on USB
You can view photos in Ultra HD resolution from a
connected USB device or flash drive. The TV will
downscale the resolution to Ultra HD if the resolution
of the photo is higher. You cannot play a video with
native resolution higher than Ultra HD on any of the
USB connections.
9.12. Camcorder
For best quality, use an HDMI cable to connect the
camcorder to the TV.
9.13. Subwoofer
Connect a subwoofer to boost the bass and enhance
your listening experience.
Note:
The Subwoofer Pre-Out has a preset cross-over
frequency setting. The cross over is 30Hz at -3dB.
In order to get the best experience, please connect your
subwoofer without any cross-over filters applied or to
the maximum Low Pass Filter frequency settings
available.
35
9.14. Computer
You can connect your computer to the TV using an
Ultra High Speed certified HDMI cable and use TV as a
PC monitor.
* Note for Nvidia Graphics card users:
If you connect your computer to TV via HDMI, Nvidia
card may automatically output Variable Refresh Rate
(VRR) video to TV when TV’s HDMI Ultra HD setting is
Automatic or Optimal (Auto Game xxxHz Pro). Please
always ensure to turn off VRR function in graphics card
before you change TV’s HDMI Ultra HD to Optimal or
Standard, the TV UI selection Optimal or Standard will
turn off VRR support in TV.
* Note for AMD Graphics card users:
If you connect your computer to TV via HDMI, please
ensure following settings in graphics card used to have
proper performance.
- If graphics card output video is 4096 x 2160p or 3840
x 2160p and RGB pixel format is used, RGB 4:4:4 pixel
format studio (limited RGB) shall be set in computer
graphic card.
- If graphics card output video is 2560 x 1440p 120Hz
and RGB pixel format is used, RGB 4:4:4 Pixel Format PC
Standard (Full RGB) shall be set in computer graphic
card.
36
10. Connect Your TV
10.1. Network and Internet
Home Network
To enjoy the full capabilities of your Philips Google TV,
your TV must be connected to the Internet.
Connect the TV to a home network with a high-speed
Internet connection. You can connect your TV wirelessly
or wired to your network router.
Connect to Network
Wireless Connection
What You Need
To connect the TV to the Internet wirelessly, you need a
Wi-Fi router with a connection to the Internet.
Use a high-speed (broadband) connection to the
Internet.
Turn Wi-Fi On or Off
Settings > Network and Internet > Wi-Fi > On/Off.
Make the Connection
Settings > Network and Internet > Wi-Fi > On/Off
1 - In the list of found networks, select on your wireless
network. If your network is not in the list because the
network name is hidden (you switched off the SSID
broadcast of the router), select Add New Network to
enter the network name yourself.
2 - Depending on the type of router, enter your
encryption key - WPA2 or WPA3. If you entered the
encryption key for this network before, you can
select OK to make the connection immediately.
3 - A message will be shown when the connection is
successful.
Problems
Wireless network not found or distorted
• Microwave ovens, DECT phones or other Wi-Fi devices
in your proximity might disturb the wireless network.
• Make sure that the firewalls in your network allow
access to the TV's wireless connection.
• If the wireless network does not work properly in your
home, try the wired network installation.
Internet does not work
• If the connection to the router is OK, check the router
connection to the Internet.
The PC and Internet connection are slow
• Look in your wireless router's user manual for
information on indoor range, transfer rate and other
factors of signal quality.
• Use a high-speed (broadband) Internet connection for
your router.
DHCP
• If the connection fails, you can check the DHCP
(Dynamic Host Configuration Protocol) setting of the
router. DHCP should be switched on.
Wired Connection
What You Need
To connect the TV to the Internet, you need a
network router with a connection to the Internet. Use a
high-speed (broadband) connection to the Internet.
Network and Internet Settings
View Network Settings
Settings > Network and Internet > View network
settings.
You can view all current network settings here. The IP
and MAC address, signal strength, speed, encryption
method, Address/Netmask/Gateway/DNS of IPv4 or
IPv6, etc.
37
Switch On with Wi-Fi (WoWLAN)
Settings > Network and Internet > Switch On with
Wi-Fi (WoWLAN).
You can switch this TV on from your smartphone or
tablet if the TV is in Standby. The setting Switch On with
Wi-Fi (WoWLAN) must be switched on.
Switch on with Chromecast
Settings > Network and Internet > Switch on with
Chromecast.
Set it On to allow this TV to be switched on from a
Chromecast app on your mobile device. Power
consumption of the TV in standby status will be higher
when switched this on. The Wi-Fi (WoWLAN) setting
should be turned on firstly before you can change the
setting of Switch on with Chromecast.
Digital Media Renderer - DMR
Settings > Network and Internet > Digital Media
Renderer - DMR.
If your media files do not play on your TV, make sure
that the Digital Media Renderer is switched on. As a
factory setting, DMR is switched on.
Quick Connect
Quick connect to your Wi-Fi
Settings > Network and Internet > Quick connect.
Quick connect helps you to quickly connect to your Wi-
Fi by scanning QR code on your TV screen.
Join a Wi-Fi by scanning the QR code with an Android
Phone and follow the instructions. On the Android
Phone, go to Settings > Network and Internet > Wi-Fi >
Select a Wi-Fi > Advanced > Add device and then scan
the QR code. Your TV will join the Wi-Fi quickly by the
assistance from your Android Phone.
TV Control with Matter
Connect your TV to Matter smart home network
Settings > Network and Internet > TV Control with
Matter.
Matter is the foundation for connected things and a
protocol to connect compatible devices and systems.
You can add your TV to a Matter smart home network
by scanning the QR code or enter the setup code.
Connects with Control4®
Switch to enable to connect with Control4®
Settings > Network and Internet > Connects with
Control4.
Control4® is the provider of personalised automation
and control solutions, helping to control multiple
devices in your home. To join your Philips Smart TV to
Control4®, please make sure your Control4®
environment and devices are properly set.
10.2. Google Account
Sign In
To enjoy the full capabilities of your Philips Google TV,
you can sign in to Google with your Google Account.
By signing in you will be able to play your favourite
games across phone, tablet and TV. You will also get
customised video and music recommendations on your
TV home screen as well as access to YouTube, Google
Play and other apps.
Sign In
Use your existing Google Account to sign in to Google
on your TV. A Google Account consists of an email
address and a password. If you don't have a Google
Account yet, use your computer or tablet to create one
(accounts.google.com). If you did not sign in during the
first TV installation, you can always sign in later.
To sign in after you did the TV installation:
1 - Select Settings > Account and sign-in and
press OK.
2 - Select Sign In and press OK.
3 - Select Use your remote and press OK.
4 - With the on-screen keyboard, enter your email
address and press OK.
5 - Enter your password and press OK to sign in.
6 - Press (left) repeatedly if necessary, to close the
menu.
Kids Profile
Once you have signed a Google account, you may like
to create a Kids profile for your kids. Kids Profile allows
parents to grant their kids access to both general
audience TV apps and apps intended for kids. Parents
select which apps to install, and can configure bedtime
reminders and screen time limits.
Under Kids profile, only granted apps can be accessed
and only HDMI connections are allowed to select as
38
external sources.
Create a Kids profile
You may use your existing Google Account to sign in to
your TV or add an account to create Kids profile.
1 - Select the Profile icon via the Dashboard at the top
right corner of Home screen.
2 - Select an existed account if you already created
accounts, or select + Add account and follow the
instructions to add a new account.
3 - Select Add a kid to create a personalised space for
your kid.
4 - During the on boarding process into Kids Profiles,
parents select which apps to install in Kids Profile from
the apps on the Play Store that are rated for all ages.
10.3. Internet
Start Internet
You can browse the Internet on your TV. You can view
any Internet website but most of them are not
prepared for a TV screen.
• Some plug-ins (e.g. to view pages or videos) are not
available on your TV.
• You cannot send or download files.
• Internet pages are shown one page at a time and full
screen.
To start the Internet browser:
1 - Press HOME.
2 - Select Your apps > WEB BROWSER (second row of
icons in Basic mode) and press OK.
3 - Enter an Internet address and select to confirm.
4 - To close Internet, press Back , and then confirm to
leave on message screen.
* Note: If WEB BROWSER is not on Your Apps row, you
can add the app manually.
39
11. Sources
11.1. Switch to a device
From the list of Sources, you can switch to any of the
connected devices. You can switch to a tuner to watch
TV or open the content of a connected USB storage
device. You can switch to your connected devices to
watch their programme, a digital receiver or a Blu-ray
Disc player.
To switch to a connected device:
1 - Press SOURCES to open the Sources menu.
2 - Select one of the item in the source list and press OK.
The TV will show the programme or content of the
device.
* Note: HDMI device listed in Source list as Unregistered
cannot be controlled with the TV's remote control as
communication protocol is limited.
11.2. Apple AirPlay and
HomeKit
Streaming contents via AirPlay
You can stream the media files from Apple devices to
your TV via AirPlay. Go to Settings > Channels and
inputs > Apple AirPlay and HomeKit to enter AirPlay
and HomeKit Settings page and make sure AirPlay is
turned On. Your Apple device must be connected to the
same Wi-Fi home network as your TV to stream
contents.
Add your TV to Apple HomeKit
To add your TV to HomeKit and control your TV via
Apple devices:
1 - Go to Settings > Channels and inputs > Apple
AirPlay and HomeKit to enter AirPlay and HomeKit
Settings page.
2 - Select Set UP under HomeKit section to generate a
QR code on your TV.
3 - On your Apple device, open the Home app and tap
Add and then scan the QR code on TV.
4 - Follow the instructions on your Apple device and
join your TV to HomeKit.
Use of the Works with Apple badge means that an
accessory has been designed to work specifically with
the technology identified in the badge and has been
certified by the developer to meet Apple performance
standards. Apple is not responsible for the operation of
this device or its compliance with safety and regulatory
standards.
Use of the Works with Apple AirPlay badge means that
an accessory has been designed to work specifically
with the technology identified in the badge and has
been certified by the developer to meet Apple
performance standards.
Apple, AirPlay and Apple Home, HomeKit are
trademarks of Apple Inc., registered in the U.S. and
other countries and regions.
40
12. Quick Menu and
Frequent Settings
In the Quick Menu and Frequent settings, you will find
a quick way to access TV functions or setting menus.
To open Quick Menu / Frequent settings and open an
item:
1 - Press Quick Menu / MENU to open Quick Menu.
2 - Press the arrows (Left) or
(right) to switch
between Quick Menu and Frequent settings.
3 - Select an item and press OK to open or start it.
4 - Press Back to close Quick Menu or Frequent
settings without starting anything.
You can press OPTIONS to enable or disable the items
from the list of Frequent settings.
41
13. Display and
Sound
13.1. Picture
Picture Settings
About Picture Settings Menu
The picture setting menu provides an easy flow to
access multi-level picture settings from general to
advanced. For some picture settings, values can be
changed by breakaway menu to let you view all the
setting values and preview the effects that will be
applied.
On the first level of Picture setting menu, you can
always select an item and press OK key to go to next
level options. If a breakaway menu is appeared, you can
slide or tick to select the setting values and preview the
effect and then press OK to confirm the change. If there
is other setting options on same level, you can
press (up) or (down) key to scroll to other setting
options and continue the setting without leaving from
the breakaway menu. Once all setting changes are
done, you can keep pressing Back key to leave or
close the setting menus.
AI Picture Style
Select a style
Settings > Display and sound > Picture > AI Picture
style.
Alternately, press (DASHBOARD) on remote control
and select Picture > AI Picture style.
For easy picture adjustment, you can select a preset
picture style.
• Personal - The picture preferences you set during the
first start up.
• Crystal Clear - Ideal for daylight viewing.
• Home Cinema - Ideal for daily movie home
entertainment experience.
• ECO - Most energy conscious setting
• Filmmaker Mode - Ideal for watching movies with
original studio effect.
• Game* - Ideal for playing games.
• Monitor** - Ideal for computer application display.
Original video is displaying with minimum processing.
• Calman - For Calman colour Calibration
* Picture style - Game is only available in HDMI video
and streaming video apps application.
** Picture style - Monitor is only available when HDMI
source video is applicable for PC application.
When TV receives HDR signal (Hybrid Log Gamma,
HDR10 and HDR10+), select a picture style below:
• HDR Personal
• HDR Crystal Clear
• HDR Home Cinema
• HDR ECO
• HDR Filmmaker Mode
• HDR IMAX Enhanced
• HDR Game
• HDR Monitor
• HDR Calman - For Calman colour Calibration
When TV receives Dolby Vision HDR signal, select a
picture style below:
• HDR Personal
• HDR Crystal Clear
• Dolby Vision Bright
• Dolby Vision Filmmaker
• Dolby Vision Game
Restore Picture style
Settings > Display and sound > Picture > Restore
picture style.
Select to restore the picture style.
Auto Film Picture style
Preferred Film Picture style
Settings > Display and sound > Picture > Auto Film
Picture style > Preferred Film Picture style.
You can select which AI Picture style will be
automatically set when film contents is detected. The
preferred Film Picture style option is depending on the
availability of Settings > Display and
sound > Picture > AI Picture style.
*Note: To automatically detect film content and set
your preference AI Picture style, you need to switch on
the Auto Film Picture style from Settings > Display
and sound > Picture > Auto Film Picture style > Auto
Film Picture style.
Switch on/off Auto Film Picture style
Settings > Display and sound > Picture > Auto Film
Picture style > Auto Film Picture style.
Switch on or off to detect film content automatically
and set your preference in the Settings > Display and
sound > Picture > Auto Film Picture style > Preferred
Film Picture style.
Film detection method
42
Settings > Display and sound > Picture > Auto Film
Picture style > Film detection method.
The TV will automatically set to your preferred AI
Picture style when film content is detected. You can set
the film detection method by Using AI or Using content
signalling.
Ambient Intelligence
Light level optimisation
Settings > Display and sound > Picture > Light level
optimisation.
Switch on to automatically reduce eye strain under
different ambient light conditions.
Dark detail optimisation
Settings > Display and sound > Picture > Dark detail
optimisation.
Select on to automatically enhance dark details based
on the ambient light conditions.
Colour temperature optimisation
Settings > Display and sound > Picture > Colour
temperature optimisation.
Select on to automatically optimise the colour
temperature based on the ambient light conditions.
HDR optimisation
Settings > Display and sound > Picture > HDR
optimisation.
Select on to automatically optimise the HDR tone
mapping effect based on the ambient light conditions.
More Picture Settings
Contrast
Brightness
Ambient Light Level Optimisation
Settings > Display and sound > Picture > Contrast
> Brightness > Ambient light level optimisation.
Switch on to adjust the picture settings automatically to
the lighting conditions of the room.
OLED Contrast
Settings > Display and sound > Picture > Contrast
> Brightness > OLED contrast.
Adjust the contrast value of the picture. You can
decrease contrast value to reduce power consumption.
Peak Light Boost
Settings > Display and sound > Picture > Contrast
> Brightness > Peak light boost.
Switch on to temporary boost the display brightness
depending on content (AI Adaptive).
Settings > Display and sound > Picture > Contrast
> Brightness > Peak light.
If the Peak light boost is not turned on, you can select
Off, Minimum, Medium or Maximum to set the TV
automatically reduces the contrast, for best power
consumption or for best picture experience.
Video Level
Settings > Display and sound > Picture > Contrast
> Brightness > Video level.
Adjust the video contrast level.
Dark Details
Ambient Dark Detail Optimisation
Settings > Display and sound > Picture > Contrast >
Dark details > Ambient dark detail optimisation.
To automatically enhance dark details based on the
ambient light conditions.
Gamma
Settings > Display and sound > Picture > Contrast >
Dark details > Gamma.
To set a non-linear setting for picture luminance and
contrast.
Note: Not available on some models when Ambient
dark detail optimisation or Dark detail optimisation is
set to On.
Black Level
Settings > Display and sound > Picture > Contrast >
Dark details > Black level.
To set the black level of picture.
43
Note: Setting of black level much away from reference
value (50) may result lower contrast (dark detail
disappear or black picture become grey).
Contrast Enhancement
Settings > Display and sound > Picture > Contrast >
Contrast enhancement > Contrast optimiser.
Contrast optimiser improves the contrast and
brightness impression to create HDR effect for standard
sources. Select Off to turn off the optimisation or select
Basic to perform the Contrast enhancement.
Alternatively, you can select AI Adaptive to
automatically adjust the contrast enhancement based
on video content.
Settings > Display and sound > Picture > Contrast >
Contrast enhancement > Dynamic range.
When Contrast optimiser is set to AI Adaptive, you can
choose the style of automatic Contrast enhancement by
selecting Subtle, High dynamic range, or Balanced.
HDR Control
Settings > Display and sound > Picture > Contrast >
HDR control > Ambient HDR optimisation.
Enable TV automatically overrules HDR settings to
adapt to bright ambient light conditions.
Settings > Display and sound > Picture > Contrast >
HDR control > HDR tone mapping.
Set the method used in HDR tone mapping processing.
Off is to disable TV internal tone mapping or follow
HGiG (HDR Gaming Interest Group) gaming HDR
standard to match gaming device. You can adjust the
method to Static (when HDR10 signal detected),
Dynamic (when HDR10+ signal detected) or AI
Adaptive to have different effect.
Note: Available when HDR10 or HDR10+ signal
detected and Ambient HDR optimisation is off.
Settings > Display and sound > Picture > Contrast >
HDR control > HDR10 effect / HDR10+ effect / HLG
effect.
When HDR10 / HDR10+ / HLG signal detected, HDR
tone mapping is not set to Off and Ambient HDR
optimisation is off, you can adjust the HDR effect level
to More details, Balanced or More brightness for each
type of HDR contents.
Colour
Settings > Display and sound > Picture > Colour.
Saturation
Settings > Display and sound > Picture > Colour >
Saturation.
To adjust the value of saturation for the colours.
Note: not available when picture style is Monitor or
HDR Monitor.
Gamut optimiser
Settings > Display and sound > Picture > Colour >
Gamut optimiser.
The gamut optimiser allows TV to display a wider range
of colours. Select Off to turn off the optimisation or
select Basic for a wider range of colours rendered.
Alternatively, you can select AI Adaptive to
automatically set the gamut based on video content.
Colour content adaptation
Settings > Display and sound > Picture > Colour >
Colour content adaptation.
When Gamut optimiser is set to AI Adaptive, you can
choose the style of colour content adaptation by
selecting Natural, Vibrant or Balanced.
Adjust colour temperature
Settings > Display and sound > Picture > Colour >
Colour temperature > Ambient colour temperature
optimisation.
Set to automatically optimize the colour temperature
based on the ambient light conditions.
Settings > Display and sound > Picture > Colour >
Colour temperature > Whitepoint.
Select Warm, Normal, Cool or Custom to set the colour
temperature for your preference.
Settings > Display and sound > Picture > Colour >
Colour temperature > 2 whitepoint alignment or 20
whitepoint alignment.
Customise the whitepoint alignment based on the
selected colour temperature of the picture.
Colour control
Settings > Display and sound > Picture > Colour
> Colour control.
Colour control setting is only available when Gamut
44
optimiser is set to Off. To adjust or reset to default
value of Hue, Saturation and Intensity for the colour
Red, Yellow, Green, Cyan, Blue and Magenta
respectively. If you want to reset all value to default,
select Reset all to default.
Sharpness
Enhancement
Settings > Display and sound > Picture > Sharpness >
Enhancement.
To adjust the sharpness value of the picture.
Texture enhancement
Settings > Display and sound > Picture > Sharpness >
Texture enhancement.
Switch on to have a superior sharpness in line edges
and details. Not available when Picture format is set to
Fill Screen.
Picture Noise
Noise reduction
Settings > Display and sound > Picture > Picture
noise > Noise reduction.
Select Off, Maximum, Medium, or Minimum to set the
level for removing the noise in video content.
Noise is mostly visible as small moving dots in on-screen
picture.
Artefact Reduction
Settings > Display and sound > Picture > Picture
noise > Artefact Reduction.
Select Off, Maximum, Medium, or Minimum to have
different degrees of smoothing the artefact in digital
video content.
Artefact is mostly visible as small blocks or jagged edges
in on-screen images.
Picture noise is not available when Picture style/AI
Picture style is Game, HDR Game, Dolby Vision Game,
Monitor or HDR Monitor.
Motion
Motion styles
Settings > Display and sound > Picture > Motion
> Motion styles.
Motion styles provides optimised motion setting modes
for different video content.
Select one of the motion styles to have different
viewing experience on motion video. (Off, Pure
Cinema, Movie, Standard, Smooth, Personal)
Not available for below cases:
• Settings > Display and sound > Picture > Picture
style/AI Picture style > Monitor
• Settings > Display and sound > Picture > Picture
style/AI Picture style > Game
• Video source is variable refresh rate
• Video source frame rate is 120Hz or higher
Game motion styles
Settings > Display and sound > Picture > Motion >
Game motion styles.
Game motion styles provides optimised motion setting
modes for different game contents.
Select one of the Game motion styles to have different
viewing experience on motion video. Available setting
options for Game motion style are Off (lowest latency),
Smooth and Personal.
Only available for below cases:
• Picture style/AI Picture style is Game, HDR Game,
Dolby Vision Game, Monitor, or HDR Monitor style
• Video source is not variable refresh rate
• Video source frame rate is not more than 60Hz
Sports optimisation
Settings > Display and sound > Picture > Motion >
Sports optimisation.
Turn on to improves motion when sports content is
identified (AI Adaptive). Only available on specific
models.
Smoothness
Settings > Display and sound > Picture > Motion >
Smoothness.
To make picture movement smooth by minimizing
judder.
Select from 0 to 10 to have different degrees
for reducing the motion judder, visible in movies on TV.
Select 0 when noise appears in playing moving picture
on-screen.
Note: Only available when Motion styles / Game
motion styles set to Personal.
Blur reduction
Settings > Display and sound > Picture > Motion >
45
Blur reduction.
To reduce the blur to makes picture movement clear
and sharp.
Select from 0 to 10 to have different degress
for reducing motion blur. Visible in movies on TV.
Select 0 when noise appears in playing moving picture
on-screen.
Note: Only available when Motion styles / Game
motion styles set to Personal.
Quick Picture Setting
During the first installation, you did some picture
settings in a few easy steps. You can redo these steps
with Quick Picture Setting.
To set the picture in a few easy steps:
1 - Select Settings > Display and sound > Picture.
2 - Select Quick Picture Setting*, and press OK.
3 - Use the navigation keys to select your preferable
P5/P5 AI processing picture taste matching the ambient
viewing light condition.
4 - Select Finish or press (left) repeatedly if necessary,
to close the menu.
* Quick Picture Setting is not available when Picture
style is set to Monitor/HDR Monitor/Game.
13.2. Screen
Picture Format
If the picture is not filling the whole screen, if black bars
are showing on the top or bottom or at both sides, you
can adjust the picture to fill the screen completely.
To select one of the basic settings to fill the screen:
1 - Press Settings > Display and sound > Screen >
Picture format > Fill Screen, Fit to Screen, Wide Screen
and Original, and press OK.
2 - Press (left) repeatedly if necessary, to close the
menu.
• Fill Screen – automatically enlarges the picture to fill
the screen. Picture distortion is minimal, subtitles
remain visible. Not suitable for PC input. Some extreme
picture content can still show black bars. Picture
content aspect ratio may change.
• Fit to Screen – automatically zooms in the picture to
fill the screen without distortion. Black bars may be
visible. Not suitable for PC input.
• Wide Screen – automatically zooms in the picture to
16:9 full screen. Picture content aspect ratio may
change.
• Original – automatically zooms in the picture to fit the
screen with original aspect ratio. No content lost visible.
To format the picture manually:
1 - Press Settings > Display and sound > Screen >
Picture format > Advanced and press OK.
2 - Use Shift, Zoom, and Stretch to adjust the picture.
3 - Or select Undo to return to the setting the picture
had when you opened Picture Format.
• Shift – Select on the arrows to shift the picture. You
can only shift the picture when it is zoomed in.
• Zoom – Select on the arrows to zoom in.
• Stretch – Select on the arrows to stretch the picture
vertically or horizontally.
• Undo – Select to return to the picture format you
started with.
Some Picture format setting selections may not be
available in some conditions. For example, in video
streaming, Android app application, gaming mode, etc.
OLED Screen Settings
Local image protection
Settings > Display and sound > Screen > Local image
protection.
Set the level of protection when local still image is
displayed.
Displaying a still image for a prolonged period of time
may cause an image sticking. This phenomenon is
normal character for OLED panel. Avoid displaying a
fixed image on the TV screen for an extended length of
time.
Auto pixel shift
Settings > Display and sound > Screen > Auto pixel
shift.
Switch on to shift pixel position to reduce pixel stress.
This is for protection of OLED screen from displaying
still image.
Clear residual image
Settings > Display and sound > Screen > Clear
residual image.
When you encounter image residual on the TV, you can
clear such image retention on-screen by activating this
function.
1 - Select Settings > Display and sound > Screen.
2 - Select Clear residual image.
3 - Select Confirm.
The TV will be switched off until the process is
completed.
If you turn the TV on during the process, it will be
46
stopped and will be restarted automatically when the
TV switches to standby at a later time.
While processing, a white line may appear on the
screen. This is normal when clearing on-screen image
retention.
Clear residual image is a deep refreshing process, it is
not for residual image prevention. It shall be manually
operated only when residual image is seen on screen
even after TV is in standby mode for at least 8 hours.
13.3. Sound
Sound Style
Select a style
Settings > Display and sound > Sound > Sound style.
For easy sound adjustment, you can select a preset
setting with sound style.
• AI mode – Automatic optimisation by Dolby.
• Original – General-purpose mode for everyday
listening.
• Entertainment – For Immersive movies & games, with
Dolby Atmos.
• Music – Music optimised for True Sound by Bowers &
Wilkins.
• Spatial Music – For Immersive music, with Dolby
Atmos Music.
• Dialogue – Provides enhanced vocal clarity.
• Personal – Adjust sound to your personal preference.
Customise personal settings
1 - Set the sound style to Personal.
2 - Go to Settings > Display and
sound > Sound > Personal settings to change personal
sound settings.
Restore personal settings
Settings > Display and sound > Sound > Personal
settings > Restore personal mode.
Select to restore personal sound settings.
Personal Settings
Speaker virtualizer
Settings > Display and sound > Sound > Personal
settings > Speaker virtualizer.
Select On or Auto (Dolby Atmos) to enable Dolby
Atmos which can add height dimension in sound. With
height dimension, sound can be precisely placed and
moved in three-dimensional space. Select Off to turn
the function off.
Clear dialogue
Settings > Display and sound > Sound > Personal
settings > Clear dialogue.
Select On to get an improved sound quality for speech
programme.
AI Equalizer
Settings > Display and sound > Sound > Personal
settings > AI Equalizer.
Select On to enable intelligent equalizer adjustment
based on audio content and custom settings.
Custom AI Equalizer
Settings > Display and sound > Sound > Personal
settings > Custom AI Equalizer.
Press the Arrow / navigation keys to adjust the level of
AI Equalizer.
Restore personal settings
Settings > Display and sound > Sound > Personal
settings > Restore personal mode.
Select to restore personal sound settings.
TV Placement
TV placement
Settings > Display and sound > Sound > TV
placement.
Select On a TV stand or On the wall to have best sound
reproduction according to the setting.
DTS Play-Fi
Setup DTS Play-Fi
DTS Play-Fi
Settings > Display and sound > Sound > DTS Play-Fi.
With DTS Play-Fi on your Philips TV, you can connect to
compatible speakers to stream audio wirelessly to other
rooms in your house.
Note: Settings for Multiroom TV Audio are not available
when connected to the DTS Play-Fi Headphones app or
playing music from the DTS Play-Fi app.
To stream audio wirelessly to speakers, you will need:
• Philips Smart TV that supports DTS Play-Fi
47
• DTS Play-Fi compatible device
• DTS Play-Fi app on your Philips TV
• Mobile device such as your phone or tablet
• Philips Sound app installed on your phone or tablet
• Wi-Fi network
Setup to connect DTS Play-Fi compatible device
1 - Download Philips Sound app and install the App on
your phone or tablet.
2 - Use Philips Sound app to search and setup DTS Play-
Fi compatible device. Make sure the DTS Play-Fi device is
connected with same Wi-Fi network of your TV.
3 - On your Philips TV, open the pre-installed DTS Play-Fi
app and select Connect Speakers to search DTS Play-Fi
compatible devices.
4 - When the DTS Play-Fi devices is successfully
connected with your TV, you can select the devices from
device list and adjust the volume.
5 - Now you can start to stream audio from your TV to
multiple DTS Play-Fi devices.
DTS Play-Fi Home Theater
Experience immersive home theater audio with Play-Fi
wireless subwoofers, soundbars, front speakers,
surround speakers, or a Play-Fi receiver that powers
home theater speakers.
Play-Fi Speakers as Front TV Speakers
• You may output TV audio to a pair of Play-Fi speakers
such as the TAW6205, TAW6505 or TAFW1.
• TV speakers will be muted when connected to Play-Fi
speakers.
• Use the Play-Fi app on TV to set up the Play-Fi
speakers.
1 - Select Play-Fi Wireless Home Theatre
2 - Select Two as the Front Speakers
3 - Follow the setup wizard to complete the setup.
Setup Home Theater system with your TV and Play-Fi
Speakers
1 - On Play-Fi app, select DTS Play-Fi Home Theater >
Setup > Connect Speakers to connect all of your Play-Fi
devices. If the devices are already connected, you can
select My speakers are connected… to go to next step.
2 - Setup to assign the Front Speaker, Surround
Speakers, Subwoofer to connected Play-Fi devices. The
graphic on left side will show the positions of the
speakers.
3 - Suggest to use TV+ Two as it provides dedicated
center channel for dialog clarity.
4 - Once the devices are assigned, select Continue… to
complete the Home Theater system setup.
On Settings menu of Home Theater system. You can
select Distance To Speakers to choose proper distance
or select Disable Home Theater, Disband Setup if
necessary.
Note:
1. Wireless surround/Stereo pair should proceed under
Play-Fi Home Theater.
2. The features depend on TV model and Play-Fi
speakers in use.
EasyLink 2.0
Control the sound settings of the HDMI sound system
via EasyLink 2.0
Settings > Display and sound > Sound > EasyLink
2.0.
You can adjust the individual sound settings of the
HDMI sound system via Frequent settings or Display
and sound > Sound. This is only applicable with
EasyLink 2.0 compliant HDMI sound system. To switch
on the control, make sure the EasyLink 2.0 sound
control menu item is set to On under Channels and
inputs > External Inputs.
Select sound style
Settings > Display and sound > Sound > EasyLink
2.0 > Sound style.
Switch between the preset sound styles. There are ideal
styles for watching movies, listening to music, or other
sound contents.
• Movie - Ideal sound style for watching movie.
• Music - Optimised for listening to music.
• Voice - Enhanced the dialog in the vocals.
• Stadium - Gives a feel of a large open-air stadium.
• Custom - Personalised sound mode. The setting is only
available when connected device is compatible with TV
for the feature.
Adjust bass level
Settings > Display and sound > Sound > EasyLink
2.0 > Bass.
Press the Arrow / navigation keys to adjust the level of
bass.
Adjust treble level
Settings > Display and sound > Sound > EasyLink
2.0 > Treble.
Press the Arrow / navigation keys to adjust the level of
treble.
Custom Equaliser
Settings > Display and sound > Sound > EasyLink
2.0 > Custom Equaliser.
Adjustable frequency bands when the Sound style is set
to Custom. Press Arrow / navigation keys to adjust the
48
level of AI Equalizer. The setting is only available when
connected device is compatible with TV for the feature.
Surround Sound
Settings > Display and sound > Sound > EasyLink
2.0 > Surround Sound.
Select a surround effect from the preset types.
• Upmix - Upmix to take full advantage of all speakers.
• Standard - Speakers output follow the original
channels.
• Surround AI - Optimum surround effect using AI
analysis.
DRC
Settings > Display and sound > Sound > EasyLink
2.0 > DRC.
Select the preferred Dynamic Range Control (DRC).
• Auto - Dynamic range is automatically adjusted.
• On - Optimize the dynamic range.
• Off - Turn off dynamic range adjustment.
Height speakers
Settings > Display and sound > Sound > EasyLink
2.0 > Height speakers.
Select the preferred height speakers movement. The
setting is only available when connected device is
compatible with TV for the feature.
• Auto - Dynamic movement follow contents.
• On - Always elevated.
• Off - Flat position.
Select sound stage
Settings > Display and sound > Sound > EasyLink
2.0 > Sound stage.
Select a listening experience. The setting is only
available when connected device is compatible with TV
for the feature.
• Auto - Dynamic setting follow contents.
• On - Immersive Sound Stage, good for watching
movies.
• Off - Crystal Sound Stage, good for listening to music
and dialogue.
Reset all to default
Settings > Display and sound > Sound > EasyLink
2.0 > Reset all to default.
Reset all the EasyLink 2.0 sound settings back to the
original factory settings.
There are more setting options may available if your
HDMI sound system supports the options:
Subwoofer level adjustment
Dolby Atmos adjustment
Height level adjustment
DTS Virtual X enable/disable
TRUE Volume enable/disable
Night mode enable/disable
Auto volume setting
Display enable/disable
Advanced Sound Settings
Volume Control
Auto volume
Settings > Display and
sound > Sound > Advanced > Auto volume.
Select On or Off to switch on or off the auto volume
adjustment.
Select Night Mode for a more comfortable quiet
listening experience.
Delta volume
Settings > Display and
sound > Sound > Advanced > Delta volume.
The Delta volume setting can be used to adjust to
balance the sound level difference between the TV
channel and the HDMI source input. Press the Arrow /
navigation keys to adjust the delta value for TV speaker
volume.
* Note: Delta volume is available when the input source
is set to HDMI or Analogue sources and the Audio out is
set to TV speakers or HDMI sound system.
Centre speaker volume
Settings > Display and
sound > Sound > Advanced > Centre speaker volume.
Adjust the loudness level of TV centre speaker if the
centre speaker is available on your TV.
Dolby Atmos for Headphone
Settings > Display and sound > Sound > Dolby
Atmos for Headphone.
Switch On or Off the Dolby Atmos for Headphone
when Dolby Atmos content is available. Select Wired
headphones from Speakers setting or connect a
Bluetooth® device to enjoy the Dolby Atmos sound
49
experience with your headphones.
13.4. Audio Output
Speakers and eARC
Audio output
Settings > Display and sound > Audio output >
Speakers.
Set the TV to play the sound on TV or on the connected
audio system.
You can select where you want to hear the TV sound
and how you want to control it.
• If you select TV speakers, the TV speakers are always
on.
• If you select Wired headphones, the sound will be
played through headphones.
• If you select Optical, the TV speakers are switched off
and Digital output/Optical is turned on.
With an audio device connected with HDMI CEC,
select HDMI sound system. The TV will switch off the TV
speakers when the device is playing the sound.
When the DTS Play-Fi compatible device is configured
correctly and switched on, you can select Play-Fi
Wireless Home Theater to set it as audio out device.
eARC
Settings > Display and sound > Audio output >
eARC.
Set eARC mode to Automatic or Off.
Digital Output Settings
Digital output settings are available for optical and
HDMI ARC sound signals.
Digital out format
Settings > Display and sound > Audio output
> Digital out format.
Set the audio out signal of the TV to fit the sound
capabilities of the connected Home Theatre System.
• Stereo (uncompressed): If your audio playback
devices have no multichannel sound processing, select
to only output stereo content to your audio playback
devices.
• Multichannel: Select to output multichannel audio
content (compressed multichannel sound signal) or
stereo audio content to your audio playback devices.
• Multichannel (bypass): Select to output Dolby Digital
Plus or DTS content to your audio playback devices or
Home theatre system.
- Make sure your audio playback devices support Dolby
Atmos feature.
Digital out levelling
Settings > Display and sound > Audio output
> Digital out levelling.
Adjust the loudness level of the HDMI sound system.
• Select More to have louder volume.
• Select Less to have softer volume.
Digital out delay
Settings > Display and sound > Audio output
> Digital out delay.
For some Home Theatre Systems you might need to
adjust the audio sync delay to synchronise the audio to
the video. Select Off if a sound delay is set on your
Home Theatre System.
Digital out offset (Only available when Digital out
delay set to On)
Settings > Display and sound > Audio output
> Digital out offset.
If you cannot set a delay on the Home Theatre System,
you can set the TV to sync the sound. You can set an
offset that compensates for the time necessary for the
Home Theatre System to process the sound of the TV
picture. You can set the value in steps of 5ms. Maximum
setting is 60ms.
Subwoofer out
Settings > Display and sound > Audio output >
Subwoofer out.
Adjust the volume offset of the wired active subwoofer.
13.5. Multi View
The Multi View allows two video sources to share
the same screen simultaneously. Videos can be Side by
Side or one video in a small window overlaying other
videos (Picture in Picture mode).
Activation and deactivation
Press (Quick Menu/MENU) to open Quick Menu and
50
select Multi View to open Multi View settings menu.
You can also press HOME, move to Your apps row
and open Multi View app to link to Multi View settings
menu. To deactivate the Multi View, select Exit Multi
View on top of Multi View settings menu.
Multi View settings
On Multi View setting menu, you can manage the video
source for View 1 (Main view) and View 2 (Sub view),
change the view mode between Side by Side or Picture
in Picture, enable/disable Dual sound to output the
audio from both sources, adjust the sound balance
when Dual sound is enabled and select Exit Multi View
to deactivate the Multi View. Multi View setting menu
will be dismissed if there is no user interaction after few
seconds.
Select source for main view and sub view
Multi View has two views, which are View 1 (Main view)
and View 2 (Sub view). Both position and size of Main
view and Sub view are predefined. From the Multi View
setting menu, the view mode can be switched between
Side by Side (equal size) or Picture in Picture (a small
Sub view overlaying Main view).
The video sources of Main view and Sub view can be
installed Satellite channels, installed Antenna/Cable
channels and input video from HDMI/USB ports. When
the video source is not set from Multi View setting
menu, the default priority to show on View 1 and View
2 are installed Satellite channels, Installed
Antenna/Cable channels and then HDMI/USB videos.
Control mode
In MANAGE VIEW setting menu, after a source is
selected, you can enter the Control mode by selecting
Control for more settings. The Control mode is available
for Satellite/Antenna/Cable channels and USB sources.
The Control mode for Satellite/Antenna/Cable
channels includes Subtitles, Subtitle language and
Audio language setting options. For USB sources, the
Control mode can adjust the settings of Select USB (USB
devices), Browse (Videos), Play All/Once, Subtitles,
Subtitle language, Character set and Audio language.
Press OPTIONS key on remote control will exit from
Control mode.
Dual sound
The audio from View 1 (Main view) is always enabled
and the audio from View 2 (Sub view) is turned off by
default. Switch on the Dual sound will turn on the
audio from View 2 and the TV output sound will be
mixed sound from both View 1 audio and View 2 audio.
You can also adjust the sound balance between View 1
and View 2 by Dual sound balance slider.
Independent Listening
The Sound on Bluetooth® device under the MANAGE
VIEW settings of View 2 allows TV to send View 2 audio
to a Bluetooth® audio device for independent listening.
When entering Sound on Bluetooth® device menu,
select one of paired Bluetooth® audio device from the
list to output the View 2 audio. Once a Bluetooth®
audio device is assigned for View 2 audio, the TV output
sound will not be mixed sound when the Dual sound is
enabled. The View 1 audio will be output to TV
speakers and the View 2 audio will be output
to Bluetooth® audio device.
13.6. Ambilight
Turn Ambilight On or Off
Turn on Ambilight
Press AMBILIGHT to turn on, or you can turn on by
selecting Settings > Display and
sound > Ambilight > Ambilight style > Enable.
To switch off Ambilight:
1 - Press AMBILIGHT.
2 - Press OK on Enable option to switch on or off the
Ambilight.
3 - Press (left) to go back one step or press Back to
close the menu.
Ambilight Style
AI Ambilight style
Settings > Display & sound > Ambilight > Ambilight
style > AI Ambilight style.
When AI Ambilight style is enabled, the TV will
automatically adjust the Ambilight styles for different
use cases.
Select a Ambilight style manually
Settings > Display and sound > Ambilight >
Ambilight style.
When AI Ambilight style is disabled, you can
manually select a preset Ambilight style.
• Standard - Ideal for day to day TV watching.
• Sports - Ideal for sports programme.
• Cinema - Ideal for movie and home entertainment
experience.
51
• Gaming - Ideal for playing games.
• Music - Listening music and follow the dynamics of
the sound.
• Fixed colour - Select a static colour of your choice.
When Ambilight style is set to Fixed colour, you can
customise the style:
• Fixed colour selection - Select your preferred static
colour from the colour palette and tune it via colour
sliders to your preference.
• Dynamic effects - Add dynamic effects to the selected
colour.
When Ambilight style is set to Music, you can select
predefined Ambilight music profiles from Music style
selection:
• Lumina - Ideal for watching music video.
• Disco - Ideal for listening to loud retro music.
• Rhythm - Ideal for listening to rhythmic music.
Follow App
Follow App setting is available when you control
Ambilight with Philips Smart TV app.
Ambilight personalisation
Settings > Display and sound > Ambilight >
Ambilight personalisation / Ambilight personalisation
(current selected style).
You can customise the current style to your preference.
• Eco room adaptive - Enable or disable automatic
brightness adjustment linked to room conditions.
• Brightness - To set the level of Ambilight brightness.
• Saturation - To set the level of Ambilight saturation.
• Dynamics - To set the speed of Ambilight dynamic
effect.
• Ambilight on dark content - Select the minimum
brightness of Ambilight while dark content is being
displayed.
• Restore to default - Select to restore the Ambilight
style.
Advanced Ambilight Settings
Ambilight bottom side
Settings > Display and
sound > Ambilight > Advanced > Ambilight bottom
side.
Switch Ambilight bottom side on or off.
Brightness bottom side
Settings > Display and
sound > Ambilight > Advanced > Brightness bottom
side.
If Ambilight bottom side is turned on, select to adjust
the level of brightness of Ambilight bottom side.
Neutralise the influence of a coloured wall on the
Ambilight colours
Settings > Display and
sound > Ambilight > Advanced > Wall colour behind
the TV.
Select the colour of the wall behind the TV and the TV
will modify the Ambilight colours to appear as they are
intended.
Set Ambilight to turn off immediately or slowly fade
out when you switch off the TV
Settings > Display and
sound > Ambilight > Advanced > Fade out to off.
Set the fade out to off time in seconds or select
Immediate to turn off the Ambilight immediately.
Ambilight animation
Settings > Display and
sound > Ambilight > Advanced > Ambilight animation.
Enable or disable to display Ambilight animation during
TV wake-up from mains on.
Lounge light autostart
Settings > Display and
sound > Ambilight > Advanced > Lounge light
autostart.
Switch on to allow lounge light mode activated when
TV is on standby.
Ambilight Suite
Introduction
Ambilight Suite is an integrated control centre to
utilize whole Ambilight feature in your daily life.
Press Quick Menu / MENU key on the remote
control to find the Quick Menu, select Ambilight Suite
and press OK to enter the control centre. Alternatively,
you can go to Settings > Display and
sound > Ambilight > Ambilight Suite and press OK to
launch Ambilight Suite.
The Ambilight Suite can switch among Lounge, Sleep
and Sunrise styles for different scenarios; each style has
52
its own quick setting items to adjust the settings for you
need.
Lounge
Lounge mode
The Lounge mode of your TV allows you to switch on
the Ambilight when the TV is in standby. So you can
light up your room with Ambilight. You can select a
theme from the bottom icons with different preset
Ambilight colour or personalise your own to mood up
your room and chill.
Select one of preset colours from bottom icons and
press OK to adjust detailed settings of selected colour.
Start now
To start the Lounge mode immediately with selected
Ambilight colour.
Colour
The option is only available when selecting Personal
colour. You can select your preferred Lounge light
colour from the colour palette and tune it via colour
sliders to your preference.
Dynamic effects
Activate dynamic effects for your selected Ambilight
colour.
Brightness
Lounge light brightness level selection.
Duration
Set the duration (in minutes) of Lounge mode.
Set as default
Set current selected Ambilight colour and related
settings as default setting of Lounge mode.
Sleep
Sleep mode
Sleep mode simulates sunset to help you unwind before
you fall asleep. At the end of simulation, the TV will
automatically switch to standby. You can select a theme
with Ambilight colour and nature sound or personalise
your own to lull yourself to sleep.
Select one of preset themes from bottom icons and
press OK to adjust detailed settings of selected theme.
Start now
To start the Sleep mode immediately with selected
theme.
Colour
Adjust the Ambilight colour of selected theme.
Dynamic effects
Activate dynamic effects for your selected Ambilight
colour.
Brightness
Set the starting brightness of Sleep mode.
Duration
Set the duration (in minutes) of Sleep mode.
Set as default
Set current selected theme and related settings as
default setting of Sleep mode.
Sunrise
Sunrise alarm
Sunrise alarm uses Ambilight, music and weather
information for a new wake up experience.
• TV wakes up at selected time and day set by you.
• Lights up Ambilight with fade-in coloured screen and
music.
• Slowly transit to weather forecast with matching
backdrop.
From the bottom icons, select Add alarm icon to set a
new alarm, select Settings icon to adjust alarm settings,
select an already set alarm to check the setting details.
Set alarm
To enable or disable the alarm.
Time
Set the alarm time.
53
Repeat
Set to trigger the alarm repeatedly.
Backdrop theme
Set to indicate the weather forecast or select from
photo categories.
Music
Set the music track to play during wake up.
Switch on volume
Set the music volume during wake up.
Preview
Preview the wake up effect.
If TV is in standby and alarm time is reached, TV shall
wake up from standby. Wake-up screen fade-in,
Ambilight is On, music fade-in and then show weather
information with backdrop.
To exit Sunrise alarm, press Standby / On, Back
or (Home) key on remote control.
- Standby / On: exits the Sunrise alarm and switch TV
to standby.
- Back: exits the Sunrise alarm and switch to last
viewed TV source.
- (Home): exits the Sunrise alarm and switch to
launcher.
- If Sunrise alarm is not exited to other application after
30 min since Sunrise wake-up, TV shall auto shutdown
to standby.
Note:
Keep the network connection alive for Sunrise alarm to
function properly. Sunrise alarm cannot operate when
the TV clock mode is set to manual. Go to the settings
menu and change the clock mode to automatic. Alarm
will not work if Location is set to Shop.
Aurora
Aurora App is an application that enhances ambience
of the TV living space with showpieces and colourful
Ambilight. Aurora make use of imageries, animation,
audio and Philips signature Ambilight to augment the
living area to suit your new lifestyle.
To launch Aurora app:
1 - Press Quick Menu / MENU to open Quick Menu,
select Aurora and press OK to open.
2 - Alternately, press HOME to go to Home screen.
Select Aurora app from Your apps row and press OK to
open.
Categories
There are four categories of themes: Ambience, Scenes,
Gallery, and Clocks. You can download more themes
when your TV connected to the internet. Use the
navigation keys to browse horizontally / vertically on
the menu. Press OK on a theme to start the playback.
Press OK on Play all to play all items in this category list,
starting with the first item. Press Back to exit the
Aurora application.
Put the TV to standby
You can set the duration of Aurora theme playback, the
TV will go to standby when the time limit reached.
To put the TV to standby:
1 - When the Aurora app is activated, press OPTIONS.
2 - Select 1 hour, 2 hours, or 4 hours to put the TV to
standby.
3 - At two minutes before timer expiry, TV will show a
dialogue to provide the options to go to standby
immediately or postpone it to 1 or 2 hours later. The
timer set to countdown or postpone cannot exceed the
maximum allowed 4 hours.
54
14. Apps
14.1. About Apps
You can find your favorite Apps on Your apps row in
the Home menu.
Like apps on your smartphone or tablet, the apps on
your TV offer specific functions for an enriched TV
experience. You can use the WEB BROWSER app to surf
the Internet.
Apps can come from the Google Play™ Store. To get
you started, some practical apps are pre-installed on
your TV.
To install apps from the Google Play™ Store, the TV
must be connected to the Internet. You must sign in
with a Google Account to use the Google Play apps and
Google Play™ Store. Select the app you want to install
and select Install button to start the installation. Once
the app installation is done, you can select Open button
to open the app, or Uninstall button to uninstall the
app.
14.2. Google Play
Movies and TV
With Google TV app, you can rent or buy movies and
TV shows to watch on TV.
What You Need
• your TV must be connected with the Internet
• you must sign in with your Google Account on TV
• add a credit card to your Google Account to purchase
movies and TV shows
To rent or buy a movie or TV show:
1 - Press HOME and select Apps tab.
2 - Select Google TV app and open it.
3 - Select a movie or TV show and press OK.
4 - Select the purchase you want and press OK. You will
be taken through the purchase procedure.
To watch a rented or bought movie or TV show:
1 - Press HOME and select Apps tab.
2 - Select Google TV app and open it.
3 - Select the movie or TV show from your library in the
app, select the title and press OK.
4 - You can use the Stop, Pause, Rewind or Fast
forward keys on the remote control.
5 - To stop the Movies & TV app, press Back repeatedly
or press EXIT.
* Note: If Google TV is not on Your Apps row, you can
search it in search field to Open or Install it.
Find more information on
www.support.google.com/googletv
Music
With YouTube Music, you can play your favourite music
on TV.
You can buy new music on your computer or mobile
device. Or, on your TV, you can sign up for All Access,
the Google Play Music subscription. Alternatively, you
can play the music you already own, stored on your
computer.
What You Need
• your TV must be connected with the Internet
• you must sign in with your Google Account on TV
• add a credit card to your Google Account to take a
music subscription
To start YouTube Music:
1 - Press HOME and select Apps tab.
2 - Select YouTube Music app and open it.
3 - Select the music you want and press OK.
4 - To stop the Music app, press Back repeatedly or
press EXIT.
* Note: If YouTube Music is not on Your Apps row, you
can search it in search field to Open or Install it.
Find more information on
www.support.google.com/googletv
or support.google.com/youtubemusic
Games
With Google Play Games, you can play games on TV.
Online or offline.
You can see what your friends are playing currently or
you can join the game and compete. You can track your
achievements or start wherever you left off.
What You Need
• your TV must be connected with the Internet
• you must sign in with your Google Account on TV
• add a credit card to your Google Account to purchase
new games
Start the Google Play Games app to select and install
new game apps on your TV. Some games are free of
charge. A message appears if a particular game needs a
gamepad to play the game.
To start or stop a Google Play Game:
55
1 - Press HOME and select Apps tab.
2 - Select Google Play Games app and open it.
3 - Select a game to play or select a new game to install
and press OK.
4 - When done, press Back repeatedly or press EXIT
or stop the app with its dedicated exit/stop button.
* Note: If Google Play Games is not on Your Apps row,
you can search it in search field to Open or Install it.
Find more information on
www.support.google.com/googletv
Google Play Store
From the Google Play Store you can download and
install new apps. Some apps are free of charge.
What You Need
• your TV must be connected with the Internet
• you must sign in with your Google Account on TV
• add a credit card to your Google Account to purchase
apps
To install a new app:
1 - Press HOME and select Apps tab.
2 - Select Google Play Store app and open it.
3 - Select the app you want to install and press OK.
4 - To close the Google Play Store,
press Back repeatedly or press EXIT.
Parental controls
In the Google Play Store, you can hide apps according
to users/buyers maturity. You need to enter a PIN code
to select or change the level of maturity.
To set the parental control:
1 - Press HOME and select Apps tab.
2 - Select Google Play Store app and open it.
3 - Select Settings > Parental controls.
4 - Select the level of maturity you want.
5 - On request, enter the PIN code.
6 - To close the Google Play Store,
press Back repeatedly or press EXIT.
* Note: If Google Play Store is not on Your Apps row,
you can search it in search field to Open or Install it.
Find more information on
www.support.google.com/googletv
Payments
To make a payment on Google Play on TV, you must
add a form of payment - a credit card (outside the
United States) - to your Google Account. When you
purchase a movie or TV show, you will be charged on
this credit card.
To add a credit card:
1 - On your computer, go to accounts.google.com and
sign in with the Google Account you will use with
Google Play on TV.
2 - Go to wallet.google.com to add a card to your
Google Account.
3 - Enter your credit card data and accept the terms and
conditions.
14.3. Start or Stop an App
You can start an app from the Home screen.
To start an app:
1 - Press HOME.
2 - Move to Your apps row, select the app you want
and press OK.
3 - You can also search the app in search field to Open
or Install it.
4 - Alternately, you can go to Settings > Apps > See
all apps or Show system apps to select an app to open.
5 - To stop an app, press Back or press EXIT or
stop the app with its dedicated exit/stop button.
14.4. Manage Apps
Settings > Apps.
If you stop an app and return to the Home menu, the
app is not really stopped. The app is still running in the
background to be readily available when you start it
again. To run fluently, most apps need to save some
data in the cache memory of the TV. It might be good
to stop an app completely or clear the cache data of a
particular app to optimise the overall performance of
apps and to keep memory usage low on your TV. Also, it
is best to uninstall apps that you are not using anymore.
You can select Apps > See all apps or Unused apps to
list your installed or used apps.
For each installed app, you can also set the permissions
for Manage updates, App permissions, Special app
access and Security.
Find more information on
www.support.google.com/googletv
56
15. System
15.1. About
System Software Update
Update from Internet
If the TV is connected to the Internet, you may receive a
message to update the TV software. You need a high-
speed (broadband) Internet connection. If you receive
this message, we recommend you to carry out the
update.
With the message on screen, select Update and follow
the instructions on-screen.
You can also look for a software update yourself.
During the software update, there is no picture and the
TV will switch off and on again. This might happen
several times. The update can take a few minutes. Wait
until the TV picture comes back up. Do not press the
power switch on the TV or on the remote control
during the software update.
To look for a software update yourself:
1 - Select Settings > System > About > System
update > Internet (recommended) and press OK.
2 - The TV will look for an update on the Internet.
3 - If an update is available, you can update the
software right away.
4 - A software update can take several minutes. Do not
press the key on the TV or remote control.
5 - When the update is done, the TV will return to the
channel you were watching.
Update from USB
It might be necessary to update the TV software.
You need a computer with a high-speed Internet
connection and an USB flash drive to upload the
software on the TV. Use an USB flash drive with at least
2Gb free space. Make sure that write protection is
switched off.
To update the TV software:
1 - Select Settings > System > About > System
update.
2 - Select USB and press OK.
Identify the TV
1 - Insert the USB flash drive into one of the USB
connections of the TV.
2 - Select Write to USB and press OK. An identification
file is written on the USB flash drive.
Download the software
1 - Insert the USB flash drive into your computer.
2 - On the USB flash drive, locate the
file update.htm and double click it.
3 - Click Send ID.
4 - If new software is available, download the .zip file.
5 - After the download, unzip the file and copy the
file autorun.upg onto the USB flash drive. Do not place
this file in a folder.
Update the TV software
1 - Insert the USB flash drive into the TV again. The
update starts automatically.
2 - A software update can take several minutes. Do not
press the key on the TV or remote control. Do not
remove the USB flash drive.
3 - When the update is done, the TV will return to the
channel you were watching.
If a power cut occurs during the update, never remove
the USB flash drive from the TV. When the power
returns, the update will continue.
To prevent an accidental update of the TV software,
delete the autorun.upg file from the USB flash drive.
Automatic Software Update
To switch on Automatic software update to update
your TV software automatically. Leave the TV in
standby.
1 - Select Settings > System > About > System
update > Automatic Software Update.
2 - Follow the on-screen instruction.
3 - Press (left) repeatedly if necessary, to close the
menu.
When the setting is enabled, the upgrade gets
downloaded when the TV is powered ON and installed
15min after the TV has gone to standby (as long as
there are no alarms scheduled).
When the setting is disabled, the "Upgrade Now" /
"Later" OSD will be shown.
View Software Update History
Display the list of software versions that are successfully
update on the TV.
To view the software update history:
1 - Select Settings > System > About > System
update > View software update history.
2 - The software update history on this TV will be listed.
57
Reset
Rinstall TV
Settings > System > About > Reset > Factory reset.
Reset and redo the complete TV installation.
Reset all settings value to original TV settings
Settings > System > About > Reset > Factory
settings.
Reset all settings to factory settings.
Status
Display TV status information
Settings > System > About > Status.
To display the TV status about IP address, Device MAC
address, Bluetooth® address, Serial Number, etc.
Legal Information
Open Source Software
This television contains open source software. TP Vision
Europe B.V. hereby offers to deliver, upon request, a
copy of the complete corresponding source code for
the copyrighted open source software packages used in
this product for which such offer is requested by the
respective licences.
This offer is valid up to three years after product
purchase to anyone in receipt of this information.
To obtain the source code, please write in English to...
Open Source License
About Open Source License
README for the source code of the parts of TP Vision
Europe B.V. TV software that fall under open source
licenses.
This is a document describing the distribution of the
source code used on the TP Vision Europe B.V. TV,
which fall either under the GNU General Public License
(the GPL), or the GNU Lesser General Public License (the
LGPL), or any other open source license. Instructions to
obtain copies of this software can be found in the
Directions For Use.
TP Vision Europe B.V. MAKES NO WARRANTIES
WHATSOEVER, EITHER EXPRESS OR IMPLIED,
INCLUDING ANY WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, REGARDING
THIS SOFTWARE. TP Vision Europe B.V. offers no
support for this software. The preceding does not affect
your warranties and statutory rights regarding any TP
Vision Europe B.V. product(s) you purchased. It only
applies to this source code made available to you.
System Information
To view the current TV software version:
1 - Select Settings > System > About > Model,
Android TV OS version, Android TV OS security patch
level, Kernel version, Android TV OS build, Software
version, Netflix ESN, Nagra Unique Device.
2 - The version, release notes and creation date are
shown. Also, the Netflix ESN Number and other
information are shown if available.
3 - Press (left) repeatedly if necessary, to close the
menu.
15.2. Date and Time
Settings > System > Date and Time.
Automatic date and time
Settings > System > Date and Time > Automatic
date and time.
Set to use network-provided time or Off to use system
time.
Set date
Settings > System > Date and Time > Set date.
Set current date.
Set time
Settings > System > Date and Time > Set time.
Set current time.
Set time zone
Settings > System > Date and Time > Set time zone.
Set current time zone.
Use 24-hour format
Settings > System > Date and Time > Use 24-hour
format.
58
Set to use 24-hour format to display the time.
15.3. Language
Change the language of the TV menu and messages
Settings > System > Language.
Select the language to display TV menu and messages.
15.4. Keyboard
Settings for the connected keyboard and virtual
keyboards
Settings > System > Keyboard.
Connect the USB keyboard to one of the USB
connections on this TV. When the TV detects the
keyboard for the first time, you can select your
keyboard lay-out and test your selection. You can also
manage the settings of connected keyboard and virtual
keyboards.
15.5. Storage
Internal shared storage
You can see how much storage space - the internal TV
memory - you are using for your apps, videos, music,
etc. You can see how much free space you still have
available for installing new apps. Check your storage if
apps start to run slow or in case of app trouble.
Select Settings > System > Storage to see how much
storage you are using.
15.6. Ambient Mode
Settings for Ambient mode
Settings > System > Ambient Mode.
Ambient mode is the screen saver to avoid displaying
still images for a longer period of time. You can set the
photo source, display weather or time information,
adjust the speed of slideshow.
15.7. Power and Energy
Set Shut-off timer
Settings > System > Power and Energy > Shut-off
timer.
Set the time to turn off TV display automatically to save
energy. The time setting can be set for When inactive
or When watching. When inactive, you can set the time
to Never, 15/20/30 minutes or 1/4/8/12/24 hours.
When watching, you can set the time to 4/6/8 hours or
Never.
Set the Power on behavior
Settings > System > Power and Energy > Power on
behavior.
Set the TV stay on Google TV home screen or on Last
used input when power on the TV.
Set the TV to switch to Standby automatically after a
preset time
Quick Menu / MENU > Frequent Settings > Sleep
timer.
Alternatively, go to Settings > System > Power and
Energy > Sleep timer.
TV switches to standby mode automatically after a
preset time. You can set the time to
10/20/30/40/50/60 minutes. If set to Off, the sleep
timer is switched off. You may stop the timer when the
notification pop-up at last one minutes.
Set screen off to save energy consumption
Quick Menu / MENU > Frequent Settings > Screen
off.
Alternatively, go to Settings > System > Power and
Energy > Screen off. You can also press OPTIONS key
to access Screen off under TV and HDMI sources.
Select Screen off, the TV screen is switched off. To
switch the TV screen back on, press any key (except
, Volume + or - , 123 key and navigation keys)
on the remote control.
Set TV switch off timer
MENU > Eco settings > Switch off timer.
Alternatively, go to Settings > System > Power and
Energy > Switch off timer.
Set the switch off timer, the TV switches off
automatically to save energy. You can set the time
59
to 30/60/90/120/150/180/210/240 minutes. If set to
Off, the timer is disabled.
• The TV is automatically switched off when there is no
user interaction for the time set.
• If the TV is used as a monitor or using a digital receiver
to watch TV, and you do not use the remote control of
the TV, you should deactivate this automatic switch off.
Set no signal timer
MENU > Eco settings > No signal timer.
Alternatively, go to Settings > System > Power and
Energy > No signal timer.
Set the no signal timer, the TV switches off
automatically if not receiving the signal from TV source
or HDMI source for the time set. You can set the time to
10/15/20 minutes.
15.8. Cast
What You Need
If an app on your mobile device has Google Cast, you
can cast your app on this TV. On the mobile app, look
for the Google Cast icon. You can use your mobile
device to control what's on TV. Google Cast works on
Android and iOS.
* Note: The Google Cast functionality works only in
Google TV Mode and not in Basic TV mode.
Your mobile device must be connected to the same Wi-
Fi home network as your TV.
Apps with Google Cast
New Google Cast apps come available every day. You
can already try it with YouTube, Chrome, Netflix,
Photowall… or Big Web Quiz for Chromecast. See also
google.com/cast
Some Google Play products and features aren't
available in all countries.
Find more information on
www.support.google.com/googletv
Cast to Your TV
To cast an app to the TV screen:
1 - On your smartphone or tablet, open an app that
supports Google Cast.
2 - Tab the Google Cast icon.
3 - Select the TV you would like to cast to.
4 - Press play on your smartphone or tablet. What you
selected should start playing on TV.
15.9. System Sounds
Settings for system sound
Settings > System > System sounds.
Enable or disable the system sounds.
15.10. Childlock
Set Code and Change Code
Set a new code or reset the change code
Settings > System > Child lock > Set code / Change
code.
The child lock code is used to lock or unlock channels or
programmes.
Note:
If you forgot your PIN code, you can override the
current one by using the code 8888 and entering a new
one.
Lock for Programme
Set a minimum age to watch rated programmes (only
available for certain countries)
Settings > System > Child lock > Parental rating.
15.11. Retail Mode Settings
Home or Shop
Select the location of your TV
Settings > System > Retail mode settings > Location.
Select Shop, the picture style settings will be restored to
default, and can adjust shop settings.
Shop mode is for in-store promotion.
60
Shop Setup
Adjust shop settings
Settings > System > Retail mode settings > Shop
setup.
If the TV is set to Shop, you can set the availability of a
specific demo for in store use.
Adjust Picture and audio
Settings > System > Retail mode settings > Shop
setup > Picture and audio.
Select Optimized for shop or Custom for picture and
audio settings.
Demo Me autostart
Settings > System > Retail mode settings > Shop
setup > Demo Me autostart.
Turn On/Off the Demo Me autostart.
OLED refreshing process
Settings > System > Retail mode settings > Shop
setup > Refresh OLED (every 4 hours).
Enable to refresh your OLED TV screen every 4 hours.
Switching off this process may result in image retention,
which may void your warranty.
AI Picture demo autostart
Settings > System > Retail mode settings > Shop
setup > AI Picture demo autostart.
Turn On/Off the AI Picture demo autostart.
On AI Picture demo mode, you can see how AI Picture
processing is enhancing the picture quality in real time.
The demo mode includes three steps, which will be
shown in repeat cycle.
First Step: P5 AI enhanced effect video shown on screen
center with live AI measurements and analyzing.
Left side measurement demonstration:
• Small size window view shows sub-sampling of live
video.
• Half-moon shape meters to show the status of
Sharpness, Noise, Motion, Colour of video and viewing
ambient light condition.
• Contrast meter: histogram of video level contribution.
Right side AI analyzing results:
Scene Classification: Output Live AI scene classification
category (circle colour filled is proportionally indicating
confidence level for each category).
Second Step: Split screen to show live visual effect.
Left half screen is original video content with AI picture
enhancement turned off; right half screen will have full
AI picture settings applied. It tells the differences after
AI picture processing.
Third Step: Full screen P5 AI enhanced effect video
shown on screen.
POS Sound
Settings > System > Retail mode settings > Shop
setup > POS Sound.
Turn On/Off the POS Sound. This feature is intended
for dealers.
15.12. Restart
Settings > System > Restart
Note:
• Disconnect the external USB hard disc before
rebooting.
• Wait for few seconds, the TV restart automatically.
This will remove unnecessary data and information in
the memory.
If your TV runs low performance when using Apps, such
as the video and audio are not synchronised or the App
is running slow, reboot your TV for better performance.
61
16. Accessibility
Settings > Accessibility.
With Accessibility switched on, the TV is prepared for
use for the deaf, hard of hearing, blind or partially
sighted people.
High contrast text
Settings > Accessibility > High contrast text.
Turn on to make texts displayed with higher contrast
for easier reading.
Text to speech
Settings > Accessibility > Text to speech.
Set to convert the text into speech for blind or partially
sighted people.
Accessibility shortcut
Settings > Accessibility > Accessibility shortcut.
Quick access to Accessibility settings.
There are more services provided by Google, e.g.,
Captions, TalkBack, Switch Access to help your TV more
accessible. To find more information about the services
please visit
www.support.google.com/googletv/answer/10070337
62
17. Remote and
Accessories
17.1. Bluetooth® On or Off
Pair Accessory
Position the Bluetooth® device within a distance of 5
meters from the TV. Read the user manual of the device
for specific information on pairing and on wireless
range. Make sure the Bluetooth® setting on TV is
switched on.
Once a Bluetooth® device is paired, you can select it to
play the TV sound. When a device is paired, you do not
need to pair it again unless you remove the device.
To pair a Bluetooth® device with the TV:
1 - Switch on the Bluetooth® device and place it within
range of the TV.
2 - Select Settings > Remote and accessories > Pair
accessory.
3 - Select Search and press OK. Follow the instructions
on screen. You will pair the device with the TV and the
TV will store the connection. You might need to unpair
a paired device first if the maximum number of paired
devices was reached.
4 - Press (left) repeatedly if necessary, to close the
menu.
Device Operation
To connect or disconnect a Bluetooth® device:
1 - Select Settings > Remote and accessories.
2 - In the list, select a Bluetooth® device.
3 - Select Connect or Disconnect to connect or
disconnect a Bluetooth® device.
4 - Press (left) repeatedly if necessary, to close the
menu.
To rename a Bluetooth® device:
1 - Select Settings > Remote and accessories.
2 - In the list, select a Bluetooth® device.
3 - Select Rename to rename a Bluetooth® device.
4 - Press (left) repeatedly if necessary, to close the
menu.
You can connect or disconnect a wireless Bluetooth®
device. You can also remove a Bluetooth® device
further. If you remove a Bluetooth® device, the device
will be unpaired.
To remove Bluetooth® device:
1 - Select Settings > Remote and accessories.
2 - In the list, select a Bluetooth® device.
3 - Select Forget to remove the Bluetooth® device.
4 - Press (left) repeatedly if necessary, to close the
menu.
To view the information of Bluetooth® device:
1 - Select Settings > Remote and accessories.
2 - In the list, select a Bluetooth® device.
3 - The information of Bluetooth® device is listed on the
bottom.
4 - Press (left) repeatedly if necessary, to close the
menu.
17.2. Remote Control
Pair Remote Control
Pairing or pairing again
When you start the initial TV installation, the TV invites
you to press the Home + Back key to pair the remote
control. If the pairing with the remote control was lost,
you can pair it again by pressing the Home + Back key.
Alternatively, go to Settings > Remote and
accessories > Remote control settings > Pair remote
control, then follow the on-screen instructions.
A message appears when the pairing is successful.
Remote Control Info
View the remote control information
Settings > Remote and accessories > Remote control
settings > Remote control info.
You can select Version to check the embedded
software version of remote control or select Battery
level to see current battery percentage.
Update Remote Control Software
Update remote control software
Settings > Remote and accessories > Remote control
settings > Update remote control software.
Check available remote control software for updates. If
a new software update is available for your remote
control, you can start the software update. Please install
new batteries or fully charge the battery, and then
63
position your remote control within one meter from TV
for updating software.
64
18. Eco Settings
Settings for Energy saving
MENU > Eco settings > Energy saving.
Select and confirm to apply the Eco settings on TV. This
may reset some picture settings to original and reduce
some brightness of the Ambilight*. Please note that TV
experience might be affected by this setting. The
green leaf icon will be appended when Eco settings are
applied.
* Ambilight setting is only for models which support
Ambilight function.
Set screen off to save energy consumption
MENU > Eco settings > Screen off.
Alternatively, you can also press OPTIONS key to access
Screen off under TV and HDMI sources.
Select Screen off, the TV screen is switched off. To
switch the TV screen back on, press any key (except
, Volume + or - , and navigation keys) on the
remote control.
Set TV switch off timer
MENU > Eco settings > Switch off timer.
Set the switch off timer, the TV switches off
automatically to save energy. Press the Arrow /
navigation keys to adjust the value of time. Select Off
to deactivate the automatic switch off.
• The TV is automatically switched off when there is no
user interaction for the time set.
• If the TV is used as a monitor or using a digital receiver
to watch TV, and you do not use the remote control of
the TV, you should deactivate this automatic switch off.
Set no signal timer
MENU > Eco settings > No signal timer.
Set the no signal timer, the TV switches off
automatically if not receiving the signal from TV source
or HDMI source for the time set. Press the Arrow /
navigation keys to adjust the value of time.
65
19. Videos, Photos
and Music
19.1. From a Computer or NAS
You can view your photos or play your music and videos
from a computer or a NAS (Network Attached Storage)
in your home network.
The TV and computer or NAS must be in the same home
network. On your computer or NAS, you need to install
Media Server Software. Your Media Server must be set
to share your files with the TV. The TV shows your files
and folders as they are organised by the Media Server
or as they are structured on your computer or NAS.
The TV does not support subtitles on video streams
from a computer or NAS.
If the Media Server supports searching for files, a search
field is available.
To browse and play the files on your computer:
1 - Press SOURCES, select Network and press OK.
2 - Select Network Devices and press (right) to select
the device you need.
3 - Once a Network device is connected, the Network
Devices item will be replaced by connected device
name.
4 - You can browse and play your files.
5 - To stop playing videos, photos and music, press
EXIT.
19.2. Favourites Menu
Add a folder or a file to favourites menu
1 - Press SOURCES, select USB and press OK.
2 - Select USB Devices and select a folder or a file.
3 - Press OPTIONS while playing a file and select Mark
as favourites to add the file to the favourite menu.
View favourite files
1 - Press SOURCES, select USB and press OK.
2 - Select Favourites.
3 - You can view all favourite files in the list.
19.3. From a USB Connection
You can view your photos or play your music and videos
from a connected USB flash drive or USB Hard Drive.
With the TV switched on, plug in a USB flash drive or a
USB Hard Drive to one of the USB connections. The TV
detects the device and will list your media files.
If the list of files does not appear automatically:
1 - Press SOURCES, select USB and press OK.
2 - Select USB Devices and press (right) to select the
USB device you need.
3 - You can browse your files in the folder structure you
have organised on the drive.
4 - Select Play all to play all files in the USB folder or
select Mark as favourite to add the selected file to
favourite menu - Favourites.
5 - To stop playing videos, photos and music, press EXIT.
19.4. Play your Videos
Play Videos
Open video folder
1 - Press SOURCES, select USB and press OK.
2 - Select USB Devices and press (right) to select the
USB device you need.
Play a video
1 - Press SOURCES, select USB and press OK.
2 - Select USB Devices and press (right) to select the
USB device you need.
3 - Select Videos and select one of video file to play.
Control bar
1 - Progress bar
66
2 - Playback control bar
- : Jump to the previous video in a folder
- : Jump to the next video in a folder
- : Rewind
- : Fast forward
- : Pause the playback
3 - Mark as favourites
4 - Play all videos
5 - Subtitle: switch subtitles On, Off or On During Mute.
6 - Subtitle language: select a Subtitle Language
7 - Audio language: select an audio language
8 - Shuffle: play your files in a random order
9 - Repeat: plays all videos in this folder once or
continuously
Video Options
Browse video files:
• Play all – Play all files in the folder
• List/Thumbnails – List or thumbnails views
• Shuffle – Play your files in a random order
• Repeat – Plays all videos in this folder once or
continuously
• Info – Show file information
Playing video files:
• Mark as favourites – Mark the video as favourites
• Subtitle setting – Set subtitle font size, colour,
position, etc.
• Info – Show file information
19.5. View your Photos
View Photos
Open photo folder
1 - Press SOURCES, select USB and press OK.
2 - Select USB Devices and press (right) to select the
USB device you need.
View a photo
1 - Press SOURCES, select USB and press OK.
2 - Select USB Devices and press (right) to select the
USB device you need.
3 - Select Photos and select one of photo file to view.
Control bar
1 - Playback control bar
- : Jump to the previous photo in a folder
- : Jump to the next photo in a folder
- : Pause the slideshow playback
2 - Mark as favourites
3 - Start a slideshow
4 - Rotate the photo
5 - Shuffle: play your files in a random order
6 - Repeat: plays all photos in this folder once or
continuously
7 - Stop the music playing in the background
8 - Set the speed of the slide show
Photo Options
Browse photo files:
• Slide show – If there are several photos in the same
folder, select to start a slide show of all photos in this
folder.
• Sort – Browse your photos by date, timeline or file
name
• List/Thumbnails – List or thumbnails views
• Shuffle – Play your files in a random order
• Repeat – Play the slide show once or continuously
• Stop music – Stop background music playing
• Slide Show Speed – Set the speed of the slide show
• Info – Show file information
Playing photo files:
• Mark as favourites – Mark the photo as favourites
• Info – Show photo information
19.6. Play your Music
67
Play Music
Open music folder
1 - Press SOURCES, select USB and press OK.
2 - Select USB Devices and press (right) to select the
USB device you need.
3 - You can quickly find a music using classification
- Genres, Artists, Albums, Tracks.
Play music
1 - Press SOURCES, select USB and press OK.
2 - Select USB Devices and press (right) to select the
USB device you need.
3 - Select Music and select one of classifications to view
music files.
4 - Select a music file to play.
Control bar
1 - Progress bar
2 - Playback control bar
- : Jump to the previous music in a folder
- : Jump to the next music in a folder
- : Rewind
- : Fast forward
- : Pause the playback
3 - Mark as favourites
4 - Play all music
5 - Shuffle: play your files in a random order
6 - Repeat: plays all music in this folder once or
continuously
Music Options
Browse music files:
• Play all – Play all files in the folder
• List/Thumbnails – List or thumbnails views
• Shuffle – Play your files in a random order.
• Repeat – Plays all songs in this folder once or
continuously.
Playing music files:
• Mark as favourites – Mark the music as favourites
68
20. Smartphones and
Tablets
20.1. Philips Smart TV App
The Philips Smart TV on your smartphone or tablet is
your new TV buddy. The app lets you switch channels
and adjust the volume — just like a remote control.
Download the Philips Smart TV App from your favourite
app store today.
The Philips Smart TV App is available for iOS and
Android and is free of charge.
Alternatively, you can go Settings > Network and
Internet > Remote app QR code and press OK; a QR
code will be presented on TV screen. Scan the QR code
with your mobile device and follow the instruction to
download and install the Philips Smart TV App. When
using the app, your mobile device and Philips TV need
to connect to the same Wi-Fi network.
69
21. Games
21.1. What You Need
On this TV, you can play games:
• from the Google Play Store in the Home menu
• from a connected Game Console
Games from the Google Play Store must be
downloaded and installed on TV before you can play
them. Some games need a gamepad to play.
To install game apps from the Google Play Store, the TV
must be connected to the Internet and you need to
agree to the Terms of Use to use apps. You must sign in
with a Google Account to use the Google Play apps and
Google Play Store.
21.2. Gamepads
To play games from the Internet on this TV, you can
connect a selected range of wireless Gamepads. The TV
can support 2 connected Gamepads at a time. When
you connect the Gamepad, you can use it immediately.
21.3. Play a Game From Game
Console or Computer
To start a game from a Game Console or Computer on
the first time:
1 - Connect Game Console or Computer to TV via Ultra
High Speed HDMI cable before power on the console or
computer.
2 - Press SOURCES and select a game console or the
name of the connection.
3 - Set HDMI Ultra HD to Automatic or Optimal (Auto
Game xxxHz Pro) for HDMI Variable Refresh Rate
gaming (on specific models only).
4 - Power on Game Console or Computer.
5 - Start the game.
21.4. Gaming Bar
The Game bar is an integrated centre for information
display and setting control while playing game. It
provides a quick way to change picture, audio and
Ambilight* settings. You can also create up to 10
separate game profiles for different type of games for
own preference. It is applicable for HDMI source as long
as the Picture style is set to Game/HDR Game/Dolby
Vision Game.
Toggle to enable or disable from HDMI (ports) >
Options > Game bar, or long press the MENU to
enable/disable Gaming bar when game signal detected
and game mode is enabled.
* Ambilight setting is only for models that support
Ambilight function.
Activation and deactivation
When TV auto switch to Game mode (via game
detection), the TV will show a message to inform user
that Game mode is enabled and the Game bar is
available, press OK to activate the Game bar. To
deactivate the Game bar, you can press Back or it will
be close automatically after 20 seconds without
interaction.
Gaming information
Game bar will show the key information for the
gaming.
Frame rate: current FPS (frame per second), displayed
on top of screen.
Profile name: current applied profile of settings,
displayed on top of Game bar.
HDMI information: current HDMI port, speed/mode
and HDCP version, displayed under the profile name.
Video source information: displayed on bottom of
Game bar.
- VRR type: current type of VRR
- Resolution: video source resolution
- Bit depth and pixel format: data information of
current source
- SDR/HDR format: the supported HDR type or SDR of
source
- ALLM: to show the HDMI ALLM is supported
- Motion setting: current setting of Motion
Game tools
The Game tools* contains frequently used tools that
can improve your gaming experience. Move the cursor
to Profile name bar and press OK to enable or disable
the game tools. Move the cursor to Game tool icon and
70
press OK can turn on the green light on icon and enable
the tool. Press OK again will disable the tool. Move
down to select under the icon can enter the setting
options for the Game tool.
Crosshair: enable/disable to show the dial point. You
can adjust Type, Size, Thickness and Colour of the
crosshair from setting options.
Shadow enhancer: enable dark detail boost to improve
shadow detail visibility. You can adjust the type in
setting options to apply different enhancement level.
Setting 8 is a special mode, which applies reverse effect
for brightness and darkness in gaming content.
Colour filter: enable to apply visual filter effect on video
based on the colour selected in options. Single colour is
to filter out other colours and show only selected
colour. Exclude colour is to filter out only selected
colour and keep other colour displayed. If colour filter
feature is enabled, Colour enhancement and Colour
control under Picture > Colour settings are not
accessible.
Centre zoom*: enable to zoom in centre portion of the
screen. You can set the Strength, Size and transparency
of Centre zoom effect from setting options. Not
supported for 144Hz input.
Edge enhancer*: enable to strengthen the edge of
objects on the screen. You can set the size of Area,
enable/disable the Colour mode or Blend to original.
* Depending on your TV model, some tools may not be
available on your TV.
Game bar settings
Select the setting icon on the left side of Game bar
and press OK to change following settings:
Profile: the profile stores the settings of the Game bar.
You can select a Standard profile or create your own
profiles. The Game bar settings can be adjusted for
different types of Games. When you are satisfied with
current settings for specific game or game type, you can
go to Game bar setting > Profile and select Add profile
to store current settings and name the profile. Along
with the Standard profile, there are up to eight
customised profiles can be created. Once the
customised profile is created, you can press left or right
key to switch among the profiles from the Profile
name bar.
FPS indicator: set to enable/disable and display position
for the FPS information.
HDMI Ultra HD: quick link to adjust the HDMI Ultra HD
setting.
Motion: quick link to adjust the Motion setting.
HDR tone mapping: quick link to adjust the HDR tone
mapping setting.
All picture settings: quick link to adjust All picture
settings.
Ambilight* style: quick link to adjust the Ambilight
settings.
Sound style: quick link to adjust the Sound style setting
Profile restore: restore default settings for the current
profile.
* Ambilight setting is only for models that support
Ambilight function.
71
22. Netflix
If you have a Netflix membership subscription, you can
enjoy Netflix on this TV. Your TV must be connected to
the Internet. In your region, Netflix might only come
available with future software updates.
To open Netflix, press to open the Netflix App.
You can open Netflix immediately from a TV in standby.
www.netflix.com
Note for Netflix Spatial Audio
Some of Netflix contents provide Spatial Audio sound
effect, to support the feature on your TV, please follow
the steps:
1 - Go to Settings > Display and sound > Audio
output > Digital out format and set the option to
Stereo (uncompressed).
2 - Go to Settings > Display and sound > Sound
> Sound style and set the style to Personal.
3 - Go to Settings > Display and
sound > Sound > Personal settings > Speaker
virtualizer and select Off to turn off the Speaker
virtualizer.
72
23. Alexa
23.1. About Alexa
Your TV supports Amazon Alexa* voice control
operations.
About Alexa
Alexa is a cloud-based voice service available on Alexa
Echo devices from Amazon and device manufacturers.
With Alexa working on your TV, you can switch on/off
TV, change channels, change volume and more.
To control your TV with Alexa, you will need:
• Philips Smart TV that supports Alexa
• Amazon Echo device
• Google account
• Mobile device such as your phone or tablet
• Wi-Fi network
About Alexa Skill
Alexa uses the Alexa Skills to extend the voice control
operations. Skills add new capabilities that create a
more personalised experience with your Alexa enabled
TV. "Philips Smart TV Voice Control" skill can be found
on Alexa Skills store, it offers various voice control
commands to work with your Philips Smart TV.
* Alexa is not available in all languages and countries.
Amazon, Alexa and all related logos are trademarks of
Amazon.com, Inc. or its affiliates.
Note: The supported Ambilight styles may depend on
specific TV models. Please refer the user manual of your
TV to know the supported Ambilight styles.
23.2. Using Alexa
To use Alexa, you need to first setup the Alexa client
service on your Philips Smart TV. Follow the instructions
and complete the following steps:
- Select a name for your Smart TV for Alexa to
recognize.
- Select a Google account and sign-in.
- Return to this skill in the Alexa App on your phone to
enable it, link accounts, and discover your devices.
- Return to your TV to complete setup.
Setup on TV for Alexa
1 - Go to Settings > Network and Internet > TV
control with Amazon Alexa to start the setup process.
2 - You need Amazon Echo device and Alexa
companion app (on mobile device or web version) be
ready to start the setup.
3 - Follow the instructions on screen to accept Privacy
Policy terms, name your TV and sign in your Google
account. The Google account is needed to pair with
Alexa device.
4 - On your mobile device, sign in with the same Google
account in the Amazon Alexa companion app.
5 - Complete following steps in the Amazon Alexa
companion app. The first is to enable "Philips Smart TV
Voice Control" skill. The second is to link your Google
account and then the final is to discover devices.
6 - Select Enable or Disable for the TV switch on setting.
You can use Alexa to turn your TV On/Off by voice
command.
7 - At the end of setup screen, you can select Done to
start to use Alexa. Select Manage TVs to do the
management of Alexa-paired TVs or un-pair the TVs
with Alexa.
Go to alexa.amazon.com, click on Skills, and search for
“Philips Smart TV Voice Control”. The skill will be listed
in the results.
73
24. Specifications
24.1. Environmental
European Energy Label
The European Energy Label informs you on the energy
efficiency class of this product. The greener the energy
efficiency class of this product is, the lower the energy it
consumes.
On the label, you can find the energy efficiency class,
the average power consumption of this product in use.
You can also find the power consumption values for
this product on the Philips website for your country
at www.philips.com/TVsupport.
EPREL Registration Number
EPREL registration number
55OLED910 : 2293800
65OLED910 : 2293837
77OLED910 : 2293853
End of Use
Disposal of your old product and batteries
Your product is designed and manufactured with high
quality materials and components, which can be
recycled and reused.
When this crossed-out wheeled bin symbol is attached
to a product it means that the product is covered by the
European Directive 2012/19/EU.
Please inform yourself about the local separate
collection system for electrical and electronic products.
Please act according to your local rules and do not
dispose of your old products with your normal
household waste. Correct disposal of your old product
helps to prevent potential negative consequences for
the environment and human health.
Your product contains batteries covered by the
European Regulation (EU) 2023/1542, which cannot be
disposed with normal household waste.
Please find out for yourself about the local rules on
separate collection of batteries because correct disposal
will help to prevent negative consequences for the
environment and human health.
24.2. Power
Product specifications are subject to change without
notice. For more specification details of this product,
see www.philips.com/TVsupport
Power
• Mains power : AC 100-240V
• Ambient temperature : 5°C to 35°C
• Power saving features : Eco mode, Picture mute (for
radio), Auto switch-off timer, Eco settings menu.
24.3. Operating System
Android OS :
Android 14
24.4. Reception
• Aerial input : 75 ohm coaxial (IEC75)
• Tuner bands : Hyperband, S-Channel, UHF, VHF
• DVB : DVB-T2, DVB-C (cable) QAM
• Analogue: SECAM, PAL
• Tuner terrestrial signal support
• Digital video playback : MPEG2 SD/HD (ISO/IEC
13818-2), MPEG4 SD/HD (ISO/IEC 14496-10), HEVC
• Digital audio playback (ISO/IEC 13818-3)
• Satellite aerial input : 75 ohm F-type
• Input frequency range : 950 to 2150MHz
• Input level range : 25 to 65 dBm
• DVB-S/S2 QPSK, symbol rate 2 to 45M symbols, SCPC
and MCPC
• LNB : DiSEqC 1.0, 1 to 4 LNBs supported, Polarity
selection 13/18V, Band selection 22kHz, Tone burst
mode, LNB current 300mA max
74
24.5. Display Type
Diagonal screen size
• 105 cm / 42 inch
• 108 cm / 43 inch
• 121 cm / 48 inch
• 126 cm / 50 inch
• 139 cm / 55 inch
• 164 cm / 65 inch
• 189 cm / 75 inch
• 194 cm / 77 inch
• 215 cm / 85 inch
Display resolution
• 3840 x 2160
24.6. Display Input Resolution
Supported Computer/Video resolution
Resolution — Refresh rate
• 640 x 480 - 60Hz
• 576p - 50Hz
• 720p - 50Hz, 60Hz
• 1920 x 1080p - 24Hz, 25Hz, 30Hz, 50Hz, 60Hz, 100Hz,
120Hz, 144Hz
• 2560 x 1440p - 60Hz, 120Hz, 144Hz
• 3840 x 2160p - 24Hz, 25Hz, 30Hz, 50Hz, 60Hz, 100Hz,
120Hz, 144Hz
* Note:
100Hz is only supported when HDMI Ultra HD is set to
Optimal in HDMI 1 and HDMI 2.
120/144Hz (up to 3840 x 2160p) is only supported
when HDMI Ultra HD is set to Optimal (Auto Game
144Hz Pro) in HDMI 1 and HDMI 2.
120/144Hz (up to 2560 x 1440p) is only supported
when HDMI Ultra HD is set to Optimal (Auto Game
144Hz Pro) in HDMI 3 and HDMI 4.
HDMI Ultra HD settings will be automatically changed
to match HDMI device connected if Automatic option is
selected.
Supported Video only resolution
Resolution — Refresh rate
• 480i - 60Hz (when HDMI Ultra HD is set to Standard)
• 576i - 50Hz (when HDMI Ultra HD is set to Standard)
• 1080i - 50Hz, 60Hz
• Variable refresh rate video 1080p, 1440p, 2160p with
frame rate up to 40-144Hz when HDMI Ultra HD is set
to Automatic or Optimal (Auto Game 144Hz Pro).
* Note: Some resolution and frame rate may not be
supported in all input sources.
24.7. Connectivity
TV Side
• Common Interface slot: CI+/CAM
• USB 2 - USB 2.0
• USB 1 - USB 3.0
• Headphones - Stereo mini-jack 3.5mm
• HDMI 4 input - Ultra HD - HDR
• HDMI 3 input - Ultra HD - HDR
TV Bottom
• Satellite tuner
• Antenna (75 ohm)
• HDMI 1 input - Ultra HD High Frame Rate - HDR
• HDMI 2 input - ARC/eARC - Ultra HD High Frame Rate
- HDR
• Digital audio out - Optical Toslink
• Network LAN - RJ45
• Subwoofer Pre Out
24.8. Sound
• Output power (RMS) : 81W
• Dolby MS12
• Dolby Atmos
• DTS Play-Fi
• DTS:X
• Surround Virtualizer + Height Virtualizer
• Dolby Bass Enhancement
• Dolby Dialogue Enhancement
• Dolby Volume (AVL/Night Mode)
• AI Sound
• AI EQ
24.9. Multimedia
Connections
• USB 2.0 / USB 3.0
• Ethernet LAN RJ-45
• Wi-Fi 802.11a/b/g/n/ac/ax, Dual Band
• Bluetooth® 5.2
Supported USB file systems
• FAT 16, FAT 32, NTFS
Playback formats
• Containers: PS, TS, M2TS, TTS, AVCHD, MP4, M4V,
MKV, ASF, AVI, 3GP, Quicktime
• Video Codecs : AVI, MKV, HEVC, H.264/MPEG-4 AVC,
75
MPEG1, MPEG2, MPEG4, VP9, HEVC (H.265), AV1
• Audio Codecs : MP3, WAV, AAC, FLAC
• Subtitles :
– Formats : SRT, SMI, SSA, SUB, ASS, TXT
– Character encodings : UTF-8, Central Europe and
Eastern Europe (Windows-1250), Cyrillic
(Windows-1251), Greek (Windows-1253), Turkish
(Windows-1254), Western Europe (Windows-1252),
Hebrew(CP-1255), Arabic(CP-1256), Baltic(CP-1257),
Korean(Windows-949)
• Maximum Supported Data Rate :
– MPEG-4 AVC (H.264) supported up to High Profile @
L5.2 80Mbps
– H.265 (HEVC) supported up to main 10 high profile
L5.1 with 100Mbps
– AV1 supported up to main profile L5.1 with 80Mbps
• Image Codecs : JPEG, GIF, PNG, BMP, HEIF
Wi-Fi Certified
This TV is Wi-Fi Certified device.
76
25. Help and Support
25.1. Register your TV
Register your TV and enjoy a range of benefits
including full support (including downloads), privileged
access to information about new products, exclusive
offers and discounts, the chance to win prizes and even
participate in special surveys about new releases.
Go to www.philips.com/TVsupport
25.2. Using Help
Open Help
Press the key (blue) to open Help immediately.
For some activities, like Text (Teletext), the colour keys
have specific functions and cannot open Help.
TV Help on your tablet, smartphone or computer
To carry out extended sequences of instructions more
easily, you can download the TV Help in PDF format to
read on your smartphone, tablet or
computer. Alternatively, you can print the relevant Help
page from your computer.
To download the Help (user manual) go
to www.philips.com/TVsupport
Quick Menu / MENU > Help
You can use more Help functions to diagnose and get
more information about your TV.
• TV information - View the Model name, Serial
number, Software version and Operation hours of your
TV.
• How to - You can see instructions on how to install
channels, sort channels, update TV software, connect
external devices and use Smart functions on your TV.
• TV diagnose - Run TV diagnose to check the condition
of your TV.
• Self-diagnose - You can check if the picture, sound,
network and other settings are working well.
• User manual - Read the user manual for TV
information.
• Troubleshooting - Find a solution for frequently asked
questions.
• Settings list copy to USB - Copy the TV settings to a
USB Flash Drive.
• Factory settings - Reset all settings to factory settings.
• Reinstall TV - Reinstall and redo the complete TV
installation.
• Contact info - Shows the telephone number or web
address for your country or region.
25.3. TV Diagnose and Self-
diagnose
TV diagnose
You can run the TV diagnose test to check the condition
of your TV. At the end of the diagnose, TV will clear the
cache memory and close any unused apps to continue
the smooth functioning of your TV.
To run the TV diagnose test:
1 - Select Quick Menu / MENU > Help > TV
diagnose and press OK.
2 - Select Start to run a series of diagnostic tests.
3 - When the test completed, you can view the status of
following items.
- Remote control
- Power
- Picture
- Sound
- External devices
- Network
- Tuner
- Storage
- Clear cache memory
- Apps
4 - Select Close to close the result page and go back to
TV diagnose wizard.
5 - Select Done to exit from TV diagnose, select Self-
diagnose to do other diagnostic check, select View
results to view the result page again.
Self-diagnose
Self-diagnose can help you to do troubleshooting of
your TV by checking the configurations of the TV.
To run the Self-diagnose:
1 - Select Quick Menu / MENU > Help > Self-
diagnose and press OK.
2 - Select following items to check the configurations.
• Check the TV - You can check if the picture, sound
and other settings are working fine..
• Check the network - Check the network connection.
• Check the HDMI sound system - Perform this test to
verify the sound connection and support of your HDMI
sound system with the TV.
• Check the remote control - Perform the test to verify
the TV bundled remote control functionality.
• View weak signal history - Display the list of channel
numbers that were automatically saved when signal
strength was weak.
• Optimise internal storage - Free up space in TV’s
77
internal storage for optimal performance.
• Update software - Check available software updates.
25.4. Troubleshooting
Switch On and Remote Control
The TV does not switch on
• Disconnect the power cable from the power outlet.
Wait for one minute then reconnect it.
• Make sure that the power cable is securely connected.
Creaking sound at startup or switch off
When you are switching the TV on, off or to standby,
you hear a creaking sound from the TV chassis. The
creaking sound is due to the normal expansion and
contraction of the TV as it cools and warms up. This
does not affect performance.
TV does not respond to the remote control
The TV requires some time to start up. During this time,
the TV does not respond to the remote control or TV
controls. This is normal behaviour.
If the TV continues to be unresponsive to the remote
control, you can check if the remote control is working
by means of a mobile phone camera. Put the phone in
camera mode and point the remote control to the
camera lens. If you press any key on the remote control
and you notice the infra red LED flicker through the
camera, the remote control is working. The TV needs to
be checked.
If you do not notice the flickering, the remote control
might be broken or its batteries are low.
This method of checking the remote control is not
possible with remote controls which are wirelessly
paired with the TV.
The standby light keeps on blinking
Disconnect the power cable from the power outlet.
Wait 5 minutes before you reconnect the power cable.
If the blinking reoccurs, contact Philips TV Consumer
Care.
Channels
No digital channels found during the installation
See the technical specifications to make sure that your
TV supports DVB-T or DVB-C in your country.
Make sure that all cables are properly connected and
that the correct network is selected.
Previously installed channels are not in the channel
list
Make sure that the correct channel list is selected.
No picture / distorted picture
• Make sure that the antenna is properly connected to
the TV.
• Make sure that the correct device is selected as the
display source.
• Make sure that the external device or source is
properly connected.
Sound but no picture
• Change to other video sources and then change back
to current source, then do picture style restore in
Picture settings or do Factory reset in General settings
option.
Poor antenna reception
• Make sure that the antenna is properly connected to
the TV.
• Loud speakers, unearthed audio devices, neon lights,
high buildings and other large objects can influence
reception quality. If possible, try to improve the
reception quality by changing the antenna direction or
moving devices away from the TV.
• If reception on only one channel is poor, fine-tune this
channel with Manual Installation.
Poor picture from a device
• Make sure that the device is connected properly.
Make sure the device's output video setting is the
highest possible resolution if applicable.
• Restore picture style or change to other picture styles.
Picture settings change after a while
Make sure that Location is set to Home. You can
change and save settings in this mode.
A commercial banner appears
Make sure that Location is set to Home.
Picture does not fit the screen
• Change to a different picture format.
• Change Picture format to Original.
Picture position is incorrect
• Picture signals from some devices may not fit the
screen correctly. Check the signal output of the
connected device.
• Change Picture format to Original.
Computer picture is not stable
Make sure that your PC uses the supported resolution
and refresh rate.
78
Sound
No sound or poor sound quality
If no audio signal is detected, the TV automatically
switches the audio output off — this does not indicate
malfunction.
• Make sure that the sound settings are correctly set.
• Make sure that all cables are properly connected.
• Make sure that the volume is not muted or set to zero.
• Make sure that the TV audio output is connected to
the audio input on the Home Theatre System.
Sound should be heard from the HTS speakers.
• Some devices may require you to manually enable
HDMI audio output. If HDMI audio is already enabled,
but you still do not hear audio, try changing the digital
audio format of the device to PCM (Pulse Code
Modulation). Refer to the documentation
accompanying your device for instructions.
HDMI and USB
HDMI
• Note that HDCP (High-bandwidth Digital Content
Protection) support can delay the time taken for a TV to
display content from an HDMI device.
• If the TV does not recognise the HDMI device and no
picture is displayed, switch the source from one device
to another and back again.
• If the picture and sound of a device connected to
HDMI is distorted, connect the device to another HDMI
port on TV and power reboot your source device.
• If the picture and sound of a device connected with
HDMI is distorted, check if a different HDMI Ultra
HD setting can solve this problem.
• If there are intermittent sound disruptions, make sure
that output settings from the HDMI device are correct.
• If you use an HDMI-to-DVI adapter or HDMI-to-DVI
cable, make sure that an additional audio cable is
connected to AUDIO IN (mini-jack only), if available.
HDMI EasyLink does not work
• Make sure that your HDMI devices are HDMI-CEC
compatible. EasyLink features only work with devices
that are HDMI-CEC compatible.
HDMI eARC is not working well
• Make sure the HDMI cable is connected to HDMI 2.
• Make sure the Ultra High-speed HDMI cable is used
for eARC connection.
• Only one eARC device is available at a time.
No volume icon shown
• When an HDMI-CEC audio device is connected and
you use the TV Remote Control to adjust the volume
level from the device, this behaviour is normal.
Photos, videos and music from a USB device do not
show
• Make sure that the USB storage device is set to Mass
Storage Class compliant, as described in the storage
device's documentation.
• Make sure that the USB storage device is compatible
with the TV.
• Make sure that the audio and picture file formats are
supported by the TV.
Choppy playback of USB files
• The transfer performance of the USB storage device
may limit the data transfer rate to the TV which causes
poor playback.
Network
Wi-Fi network not found or distorted
• Microwave ovens, DECT phones or other Wi-Fi devices
in your proximity might disturb the wireless network.
• Make sure that the firewalls in your network allow
access to the TV's wireless connection.
• If the wireless network does not work properly in your
home, try the wired network installation.
Internet does not work
• If the connection to the router is OK, check the router
connection to the Internet.
The PC and Internet connection are slow
• Look in your wireless router's user manual for
information on indoor range, transfer rate and other
factors of signal quality.
• Use a high-speed (broadband) Internet connection for
your router.
DHCP
• If the connection fails, you can check the DHCP
(Dynamic Host Configuration Protocol) setting of the
router. DHCP should be switched on.
Poor quality when watching streaming video
• The image/sound quality of stream video is
depending on the original video content provided by
streaming video apps.
• To ensure the best experience of watching streaming
videos, a fast and stable network connection is
essential. The recommended network connection speed
for the streaming videos are as follows:
- Standard image quality (SD): 5 Mbps
- High image quality (HD): 10 Mbps
- 4K/Ultra HD (UHD): 25 Mbps
Bluetooth®
Unable to pair
• Make sure the device is in pairing mode. Read the user
manual of the device.
• Keep the wireless speaker as close to the TV as
possible.
• Trying to pair several devices with the TV at the same
time, may not work.
Bluetooth® lost connection
• Always position the wireless speaker within a range of
79
5 meters from the TV.
Bluetooth® Audio and Video syncronisation
• Before you purchase a wireless Bluetooth® speaker,
inform yourself about its quality of Audio to Video
syncronisation, commonly called 'lip sync'. Not
all Bluetooth® devices perform correctly. Ask your
dealer for advice.
Wrong Menu Language
Wrong menu language
Change the language back to your language in Googel
TV mode.
1 - Press DASHBOARD key on remote control to
launch Dashboard menu.
2 - Select icon and press OK to open Settings menu.
3 - Press 6 times (down) and press OK to enter System
menu.
4 - Press 3 times (down) and press OK to enter
Language menu
5 - Select your language and press OK.
6 - Press Back to close the menu.
Change the language back to your language in Basic
Mode.
1 - Press DASHBOARD key on remote control to
launch Dashboard menu.
2 - Select icon and press OK to open Settings menu.
3 - Press 7 times (down) and press OK to enter System
menu.
4 - Press 3 times (down) and press OK to enter
Language menu
5 - Select your language and press OK.
6 - Press Back to close the menu.
25.5. Online Help
To solve any Philips TV related problem, you can consult
our online support. You can select your language and
enter your product model number.
Go to www.philips.com/TVsupport
On the support site you can find your country's
telephone number to contact us as well as answers to
frequently asked questions (FAQs). In some countries,
you can chat with one of our collaborators and ask your
question directly or send a question by email.
You can download new TV software or the manual to
read on your computer.
25.6. Support and Repair
For support and repair, call the Consumer Care hotline
in your country. Our service engineers will take care of a
repair, if necessary.
Find the telephone number in the printed
documentation that came with the TV.
Or consult our
website www.philips.com/TVsupport and select your
country if needed.
TV model number and serial number
You might be asked to provide the TV product model
number and serial number. Find these numbers on the
packaging label or on the type label on the back or
bottom of the TV.
Warning
Do not attempt to repair the TV yourself. This may
cause severe injury, irreparable damage to your TV or
void your warranty.
80
26. Safety and Care
26.1. Safety
Important
Read and understand all safety instructions before you
use the TV. If damage is caused by failure to follow
instructions, the warranty does not apply.
Risk of Electric Shock or Fire
• Never expose the TV or the remote control to rain or
water. Never place liquid containers, such as vases, near
the TV or the remote control.
If liquids are spilt on or into the TV, disconnect the TV
from the power outlet immediately.
Contact Philips TV Consumer Care to have the TV
checked before use.
• Never expose the TV, remote control or batteries to
excessive heat. Never place them near burning candles,
naked flames or other heat sources, including direct
sunlight.
• Never insert objects into the ventilation slots or other
openings on the TV.
• Never place heavy objects on the power cord.
• Avoid force coming onto power plugs. Loose power
plugs can cause arcing or fire. Ensure that no strain is
exerted on the power cord when you swivel the TV
screen.
• To disconnect the TV from the mains power, the
power plug of the TV must be disconnected. When
disconnecting the power, always pull the power plug,
never the cord. Ensure that you have full access to the
power plug, power cord and outlet socket at all times.
Risk of Injury or Damage to the TV
• Two people are required to lift and carry a TV that
weighs more than 25 kg or 55 lbs.
• If you mount the TV on a stand, only use the supplied
stand. Secure the stand to the TV tightly.
Place the TV on a flat, level surface that can support the
weight of the TV and the stand.
• When wall mounted, ensure that the wall mount can
safely bear the weight of the TV set. TP Vision bears no
responsibility for improper wall mounting that results in
accident, injury or damage.
• Parts of this product are made of glass. Handle with
care to avoid injury or damage.
Risk of damage to the TV !
Before you connect the TV to the power outlet, ensure
that the power voltage matches the value printed on
the back of the TV. Never connect the TV to the power
outlet if the voltage is different.
Stability Hazards
This product is designed and intended for consumers
and personal use in a domestic home environment,
unless agreed otherwise with the manufacturer in
writing. Failure to follow this recommendation or the
instructions provided in the product user manual and
the product supportive documentation can cause
damage to the product and will void the warranty for
such cases.
A television set may fall, causing serious personal injury
or death. Many injuries, particularly to children, can be
avoided by taking simple precautions such as:
• ALWAYS ensure the television set is not overhanging
the edge of the supporting furniture.
• ALWAYS use cabinets or stands or mounting methods
recommended by the manufacturer of the television
set.
• ALWAYS use furniture that can safely support the
television set.
• ALWAYS educate children about the dangers of
climbing on furniture to reach the television set or its
controls.
• ALWAYS route cords and cables connected to your
television so they cannot be tripped over, pulled or
grabbed.
• NEVER place a television set in an unstable location.
• NEVER place the television set on tall furniture (for
example, cupboards or bookcases) without anchoring
both the furniture and the television set to a suitable
support.
• NEVER place the television set on cloth or other
materials that may be located between the television
set and supporting furniture.
• NEVER place items that might tempt children to climb,
such as toys and remote controls, on the top of the
television or furniture on which the television is placed.
If the existing television set is going to be retained and
relocated, the same considerations as above should be
applied.
Risk of Batteries
• Do not ingest the battery. Chemical burn hazard.
• The remote control may contain a coin/button cell
battery. If the coin/button cell battery is swallowed, it
can cause severe internal burns in just 2 hours and can
lead to death.
• Keep new and used batteries away from children.
• If the battery compartment does not close securely,
stop using the product and keep it away from children.
• If you think batteries might have been swallowed or
81
placed inside any part of the body, seek immediate
medical attention.
• Risk of fire or explosion if the battery is replaced by an
incorrect type.
• Replacement of a battery with an incorrect type that
can defeat a safeguard (for example, in the case of
some lithium battery types).
• Disposal of a battery into fire or a hot oven, or
mechanically crushing or cutting of a battery, that can
result in an explosion.
• Leaving a battery in an extremely high temperature
surrounding environment that can result in an
explosion or the leakage of flammable liquid or gas.
• A battery subjected to extremely low air pressure that
may result in an explosion or the leakage of flammable
liquid or gas.
Risk of Overheating
Never install the TV in a confined space. Always leave a
space of at least 10 cm or 4 inches around the TV for
ventilation. Ensure curtains or other objects never cover
the ventilation slots on the TV.
Lightning Storms
Disconnect the TV from the power outlet and antenna
before lightning storms.
During lightning storms, never touch any part of the TV,
power cord or antenna cable.
Risk of Hearing Damage
Avoid using earphones or headphones at high volumes
or for prolonged periods of time.
Low Temperatures
If the TV is transported in temperatures below 5°C or
41°F, unpack the TV and wait until the TV temperature
reaches room temperature before connecting the TV to
the power outlet.
Humidity
In rare occasions, depending on temperature and
humidity, minor condensation can occur on the inside
of the TV glass front (on some models). To prevent this,
do not expose the TV to direct sunlight, heat or extreme
humidity. If condensation occurs, it will disappear
spontaneously while the TV is playing for a few hours.
The condensation moisture will not harm the TV or
cause malfunction.
26.2. Screen Care
• Never touch, push, rub or strike the screen with any
object.
• Unplug the TV before cleaning.
• Clean the TV and frame with a soft damp cloth and
wipe gently. Avoid touching the Ambilight* LEDs on
the backside of the TV. Never use substances such as
alcohol, chemicals or household cleaners on the TV.
• To avoid deformations and colour fading, wipe off
water drops as quickly as possible.
• Avoid stationary images as much as possible.
Stationary images are images that remain onscreen for
extended periods of time. Stationary images include
onscreen menus, black bars, time displays, etc. If you
must use stationary images, reduce screen contrast and
brightness to avoid screen damage.
* Ambilight LED is only for models which support
Ambilight function.
82
27. Terms of Use
27.1. Terms of Use - TV
2025 © TP Vision Europe B.V. All rights reserved.
This product was brought to the market by TP Vision
Europe B.V. or one of its affiliates, hereinafter referred
to as TP Vision, which is the manufacturer of the
product. TP Vision is the warrantor in relation to the TV
with which this booklet was packaged. Philips and the
Philips Shield Emblem are registered trademarks of
Koninklijke Philips N.V.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V
or their respective owners. TP Vision reserves the right
to change products at any time without being obliged
to adjust earlier supplies accordingly.
The written material packaged with the TV and the
manual stored in the memory of the TV or downloaded
from the Philips
website www.philips.com/TVsupport are believed to be
adequate for the intended use of the system.
The material in this manual is believed adequate for the
intended use of the system. If the product, or its
individual modules or procedures, are used for
purposes other than those specified herein,
confirmation of their validity and suitability must be
obtained. TP Vision warrants that the material itself
does not infringe any United States patents. No further
warranty is expressed or implied. TP Vision cannot be
held responsible neither for any errors in the content of
this document nor for any problems as a result of the
content in this document. Errors reported to Philips will
be adapted and published on the Philips support
website as soon as possible.
Terms of warranty - Risk of injury, damage to TV or void
of warranty!
Never attempt to repair the TV yourself. Use the TV and
accessories only as intended by the manufacturer. The
caution sign printed on the back of the TV indicates risk
of electric shock. Never remove the TV cover. Always
contact Philips TV Customer Care for service or repairs.
Find the telephone number in the printed
documentation that came with the TV. Or consult our
website www.philips.com/TVsupport and select your
country if needed. Any operation expressly prohibited
in this manual, or any adjustments and assembly
procedures not recommended or authorised in this
manual, shall void the warranty.
Pixel characteristics
This TV product has a high number of colour pixels.
Although it has effective pixels of 99.999% or more,
black dots or bright points of light (red, green or blue)
may appear constantly on the screen. This is a structural
property of the display (within common industry
standards) and is not a malfunction. Therefore, please
note this is not subjected to repair, exchange or refund
within and/or out of the warranty period.
Backlight characteristics
All Philips TV have gone through stringent tests and
checks before shipping to you. You can be rest assured
that we place the quality of our TVs the utmost
importance so that you do not suffer any viewing
displeasure while watching your TV. However, please
note that backlight bleeding (“Mura effect”) and /or
unevenness of background light that can only be
observed in dark images or in a very dark and dim room
are considered to be within TV specifications. Such
occurrences do not represent a deterioration nor shall
be regarded as a defect of the TV. Hence, we regret
that claims of this nature for warranty, free of charge
service, replacement or refund cannot be accepted
within and/or out of the warranty period.
CE compliance
Hereby, TP Vision Europe B.V. declares that this
television is in compliance with the essential
requirements and other relevant provisions of
Directives 2014/53/EU (RED), 2011/65/EU (RoHS), and
ESPR Regulation (EU) 2024/1781 (Regulation (EU)
2019/2021).
UKCA compliance
Hereby, TP Vision Europe B.V. declares that this
television is in compliance with the essential
requirements and other relevant provisions of the
Radio Equipment Regulations 2017, Ecodesign for
Energy-Related Products and Energy Information
(Amendment) (EU Exit) Regulations 2019, and
Restriction of the Use of Certain Hazardous Substances
in Electrical and Electronic Equipment Regulations
2012.
Compliance with EMF
TP Vision manufactures and sells many products
targeted at consumers which, like any electronic
apparatus, in general have the ability to emit and
receive electromagnetic signals. One of TP Vision’s
leading business principles is to take all necessary
health and safety measures for our products, to comply
with all applicable legal requirements and to stay well
within the Electro Magnetic Field (EMF) standards
applicable at the time of producing the products.
TP Vision is committed to developing, producing and
marketing products that cause no adverse health
effects. TP Vision confirms that, as long as its products
are handled properly for their intended use, they are
safe to use according to scientific evidence available
today. TP Vision plays an active role in the development
of international EMF and safety standards, enabling TP
Vision to anticipate further developments in
standardisation for early integration in its products.
83
27.2. Terms of Use - Smart TV
You can view the Terms of use, privacy policy, and also
set privacy settings of your Smart TV.
To view the contents or change settings:
1 - Go to Settings > System > About > Legal
Information.
2 - Select Terms of use or Privacy settings.
84
28. Copyrights
28.1. Google TV
Google TV is the name of this device's software
experience and a trademark of Google LLC.
Google, YouTube and other marks are trademarks of
Google LLC.
28.2. HDMI
The terms HDMI, HDMI High-Definition Multimedia
Interface, HDMI trade dress and the HDMI Logos are
trademarks or registered trademarks of HDMI Licensing
Administrator, Inc.
28.3. HEVC Advance
Covered by one or more claims of the HEVC patents
listed at patentlist.accessadvance.com.
Future proof with advanced HEVC decoding.
28.4. Works with Apple
AirPlay
Use of the Works with Apple badge means that an
accessory has been designed to work specifically with
the technology identified in the badge and has been
certified by the developer to meet Apple performance
standards. Apple is not responsible for the operation of
this device or its compliance with safety and regulatory
standards.
Apple, AirPlay and Apple Home, HomeKit are
trademarks of Apple Inc., registered in the U.S. and
other countries and regions.
28.5. Works with Apple Home
Use of the Works with Apple badge means that an
accessory has been designed to work specifically with
the technology identified in the badge and has been
certified by the developer to meet Apple performance
standards. Apple is not responsible for the operation of
this device or its compliance with safety and regulatory
standards.
Apple, AirPlay and Apple Home, HomeKit are
trademarks of Apple Inc., registered in the U.S. and
other countries and regions.
28.6. NVIDIA G-SYNC
NVIDIA® G-SYNC® make for gamers
85
28.7. AMD FreeSync Premium
No Stuttering. No Tearing. Fluid Gaming.
28.8. Dolby Vision and Dolby
Atmos
Dolby, Dolby Vision, Dolby Atmos, and the double-D
symbol are registered trademarks of Dolby Laboratories
Licensing Corporation. Manufactured under license
from Dolby Laboratories. Confidential unpublished
works. Copyright © 2012–2024 Dolby Laboratories.
All rights reserved.
28.9. IMAX Enhanced
Manufactured under license from IMAX Corporation.
IMAX® is a registered trademark of IMAX Corporation
in the United States and/or other countries. For DTS
patents, see http://patents.dts.com. Manufactured
under license from DTS Licensing Limited. DTS and the
DTS logo are registered trademarks or trademarks of
DTS, Inc. in the United States and other countries. ©
2022 DTS, Inc. ALL RIGHTS RESERVED.
28.10. DTS:X
FOR DTS PATENTS, SEE HTTP://XPERI.COM/DTS-
PATENTS/. MANUFACTURED UNDER LICENSE FROM
DTS, INC. AND ITS AFFILIATES.
DTS, DTS:X, AND THE DTS:X LOGO ARE REGISTERED
TRADEMARKS OR TRADEMARKS OF DTS, INC. AND ITS
AFFILIATES IN THE UNITED STATES AND/OR OTHER
COUNTRIES. © DTS, INC. AND ITS AFFILIATES. ALL
RIGHTS RESERVED.
28.11. DTS Play-Fi
FOR DTS PATENTS, SEE HTTP://XPERI.COM/DTS-
PATENTS/. MANUFACTURED UNDER LICENSE FROM
DTS, INC. AND ITS AFFILIATES.
DTS, THE DTS LOGO, DTS PLAY-FI, PLAY-FI AND THE DTS
PLAY-FI AND PLAY-FI LOGOS ARE REGISTERED
TRADEMARKS OR TRADEMARKS OF DTS, INC. AND ITS
AFFILIATES IN THE UNITED STATES AND/OR OTHER
COUNTRIES.
28.12. Wi-Fi CERTIFIED 6
Wi-Fi CERTIFIED 6® and the Wi-Fi CERTIFIED 6 Logo are
registered trademarks of Wi-Fi Alliance®.
86
28.13. Kensington
(If applicable)
Kensington and Micro Saver are registered US
trademarks of ACCO World Corporation with issued
registrations and pending applications in other
countries throughout the world.
28.14. Other Trademarks
All other registered and unregistered trademarks are
the property of their respective owners.
87
29. Disclaimer
regarding services
and/or software
offered by third
parties
Services and/or software offered by third parties may
be changed, suspended, or terminated without prior
notice. TP Vision does not bear any responsibility in
these sorts of situations.
88
Index
A
Advanced Ambilight Settings 52
Advanced Colour Settings 44
AI Picture style 42
Alexa 73
Ambient Dark Detail Optimization 43
Ambient Intelligence 43
Ambient Light Level Optimization 43
Ambient mode 59
Ambilight animation 52
Ambilight Personalisation 51
Ambilight Style 51
Ambilight Suite 52
Ambilight Suite, Lounge 53
Ambilight Suite, Sleep 53
Ambilight Suite, Sunrise 53
Ambilight, Settings 51
Apple AirPlay and HomeKit 40
Apps 55
Audio Language 24
Audio Language, Primary 24
Audio Language, Secondary 24
Audio Out Settings 50
Aurora 54
Auto Film Picture style 42
Automatic Channel Update 18
B
Black Level 43
Blu-ray Disc player, connect 33
Bluetooth®, Remove device 63
Bluetooth®, Select device 63
Brightness 43
C
CAM, Conditional Access Module 32
Channel 22
Channel List 22
Channel List Copy 20
Channel List Copy, copy 20
Channel List Copy, current version 20
Channel List Copy, upload 20
Channel List, filter 22
Channel List, open 22
Channel List, search 22
Channel Lists 22
Channel Update Message 18
Channel, Antenna Installation 18
Channel, Automatic Channel Update 18
Channel, Installation 18
Channel, Manual channel update 18
Channel, Options 23
Channel, Reinstall 18
Channel, Satellite Installation 15
Channel, switch to a channel 23
Channel, TV guide 29
Child Lock 60
CI+ 32
Colour, Colour control 44
Colour, Colour gamut 44
Colour, Colour temperature 44
Common Interface Slot 32
Computer, connect 36
Connectivity Guide 30
Connects with Control4® 38
Consumer Care 80
Contact Philips 80
Contrast Enhancement 44
Contrast, Peak Light Boost 43
D
Dark Details 43
Dashboard 6
Digital Text 27
Display and Sound 42
Disposal of TV or batteries 74
Dolby Atmos 47
Dolby Atmos for Headphone 49
DVB (Digital Video Broadcast) 19
E
EasyLink 2.0 48
EasyLink HDMI CEC 30
Eco Settings 65
End of use 74
Environmental 74
European Ecolabel 74
F
Factory reset 19
Frequency Scan 19
Frequency Step Size 19
Frequent Settings 41
G
Game Console, connect 34
Gaming 70
Gaming Bar 70
Gamma 43
H
HbbTV 28
HDMI Ultra HD 31
HDMI Variable Refresh Rate 31
HDR Control 44
HDR tone mapping 44
Home 6
Home Theatre System, problems 32
I
Interactive TV 28
Interactive TV, about 28
Internet Channel Installation 21
I
iTV 28
K
Key on TV 14
Kids Profile 38
L
Lounge light autostart 52
89
M
Media 66
Media files, from a computer or NAS 66
Media files, from a USB drive 66
Motion 45
MPEG Artefact Reduction 45
Multi View 50
N
Network Frequency 19
Network Frequency Mode 19
Network Installation 37
Network, connect 37
Network, setting 37
Network, Wired 37
Network, Wireless 37
O
OLED Contrast 43
OLED screen settings 46
Online support 80
Open Source Software 58
Operator Apps 17
Optimal (Auto Game) 31
Options on a Channel 23
P
Parental Rating 23
Personal mode, Clear dialogue 47
Personal mode, Equalizer 47
Philips Smart TV App 69
Photos, Videos and Music 66
Picture Settings Menu 42
Picture, picture format 46
Picture, quick settings 46
Play-Fi Wireless Home Theater 50
Power cable 8
Power on behavior 59
Problems, Channels 78
Problems, Connection, Internet 79
Problems, Connection, Wi-Fi 79
Problems, HDMI Connection 79
Problems, Picture 78
Problems, Remote control 78
Problems, Sound 79
Problems, USB Connection 79
Problems, Wrong menu language 80
Q
Quick Connect 38
Quick Menu 41
R
Radio station 22
Reception Quality 19
Register your product 77
Repair 80
Reset 58
S
Safety Instructions 81
Satellite CAMs 15
Satellite Installation 15
Satellite, Channel packages 16
Satellite, Manual Channel Update 16
Satellite, Manual Installation 16
Satellite, Unicable 16
Screen care 82
Screen off 59
Self-diagnose 77
Sharpness, MPEG Artefact Reduction 45
Shop Setup 61
Simple Setup App 13
Sleep timer 59
Smart Card, CAM 32
Software, Update 57
Sound Style 47
Subtitle 24
Subtitle Language 24
Subtitle Language, Primary 24
Subtitle Language, Secondary 24
Switch off timer 59
Switching On 14
T
Teletext 27
Terms of Use 83
Test Reception 19
Text 27
Text language, Primary 28
Text language, Secondary 28
Troubleshooting 78
TV Control with Matter 38
TV diagnose 77
TV Guide 29
TV Guide Data 29
TV Installation 19
TV placement 8
TV, standby 14
U
Unicable 1 16
Unicable 2 16
Universal Access 24
USB Keyboard 34
USB Keyboard, connect 34
V
Video Level 43
View Software update history 57
Viewing distance 8
W
Watch TV 23
Wi-Fi 37
Wired Network 37
Wireless Network 37
90
