BN68-25135A-00
1
1
2
3
Unpacking and Installation Guide
Guide de déballage et d’installation
Guía de desembalaje e instalación
Manual de desempacotamento e instalação
Auspacken und Installationsanleitung
Guida al disimballaggio e all’installazione
Руководство по распаковке и установке
Қаптамадан шығару және орнату нұсқаулығы
Посібник з розпаковки та встановлення
Qadoqdan chiqarish va o‘rnatish qo‘llanmasi
85″
85″
43″- 55″
43″- 75″
43″- 65″
65″- 75″
75″
75″
3
4 5
43M7*H
43MH7*
43M1EH
37.7 inches
(957.8 mm)
(957,8 мм)
(95.78 cm)
22.0 inches
(558.8 mm)
(558,8 мм)
(55.88 cm)
3.0 inches
(76.3 mm)
(76,3 мм)
(7.63 cm)
24.0 inches
(609.0 mm)
(609,0 мм)
(60.90 cm)
6.2 inches
(157.0 mm)
(157,0 мм)
(15.70 cm)
42.5 inches
(108 cm)
(108 см)
14.8 lbs
(6.7 kg)
(6,7 кг)
15.2 lbs
(6.9 kg)
(6,9 кг)
50M7*H
50MH7*
50M1EH
43.7 inches
(1110.8 mm)
(1110,8 мм)
(111.08 cm)
25.3 inches
(643.8 mm)
(643,8 мм)
(64.38 cm)
3.0 inches
(76.4 mm)
(76,4 мм)
(7.64 cm)
27.4 inches
(696.0 mm)
(696,0 мм)
(69.60 cm)
7.8 inches
(199.0 mm)
(199,0 мм)
(19.90 cm)
49.5 inches
(125 cm)
(125 см)
18.7 lbs
(8.5 kg)
(8,5 кг)
19.4 lbs
(8.8 kg)
(8,8 кг)
55M7*H
55MH7*
55M1EH
48.2 inches
(1224.6 mm)
(1224,6 мм)
(122.46 cm)
27.9 inches
(707.8 mm)
(707,8 мм)
(70.78 cm)
3.0 inches
(76.6 mm)
(76,6 мм)
(7.66 cm)
29.9 inches
(760.0 mm)
(760,0 мм)
(76.00 cm)
7.8 inches
(199.0 mm)
(199,0 мм)
(19.90 cm)
54.6 inches
(138 cm)
(138 см)
22.0 lbs
(10.0 kg)
(10,0 кг)
22.7 lbs
(10.3 kg)
(10,3 кг)
65M7*H
65MH7*
65M1EH
56.9 inches
(1444.1 mm)
(1444,1 мм)
(144.41 cm)
32.7 inches
(831.2 mm)
(831,2 мм)
(83.12 cm)
3.0 inches
(76.8 mm)
(76,8 мм)
(7.68 cm)
34.7 inches
(882.2 mm)
(882,2 мм)
(88.22 cm)
8.7 inches
(222.0 mm)
(222,0 мм)
(22.20 cm)
64.5 inches
(163 cm)
(163 см)
31.3 lbs
(14.2 kg)
(14,2 кг)
32.0 lbs
(14.5 kg)
(14,5 кг)
75M7*H
75MH7*
75M1EH
65.7 inches
(1668.1 mm)
(1668,1 мм)
(166.81 cm)
37.7 inches
(957.8 mm)
(957,8 мм)
(95.78 cm)
3.0 inches
(77.0 mm)
(77,0 мм)
(7.70 cm)
39.7 inches
(1007.9 mm)
(1007,9 мм)
(100.79 cm)
11.0 inches
(280.0 mm)
(280,0 мм)
(28.00 cm)
74.5 inches
(189 cm)
(189 см)
47.6 lbs
(21.6 kg)
(21,6 кг)
48.5 lbs
(22.0 kg)
(22,0 кг)
85M7*H
85MH7*
85M1EH
74.4 inches
(1889.9 mm)
(1889,9 мм)
(188.99 cm)
42.7 inches
(1083.5 mm)
(1083,5 мм)
(108.35 cm)
3.0 inches
(77.0 mm)
(77,0 мм)
(7.70 cm)
44.6 inches
(1132.8 mm)
(1132,8 мм)
(113.28 cm)
12.8 inches
(326.0 mm)
(326,0 мм)
(32.60 cm)
84.5 inches
(214 cm)
(214 см)
63.3 lbs
(28.7 kg)
(28,7 кг)
64.4 lbs
(29.2 kg)
(29,2 кг)
* : 0~9, A~Z
VESA
x (mm)
VESA
x (мм)
(mm)
(мм)
x 4
43M7*H / 43MH7* / 43M1EH 200 x 200
23-25 M8
50M7*H / 50MH7* / 50M1EH 200 x 200
23-25 M8
55M7*H / 55MH7* / 55M1EH 200 x 200
23-25 M8
65M7*H / 65MH7* / 65M1EH 200 x 200
23-25 M8
75M7*H / 75MH7* / 75M1EH 400 x 300
10-12 M8
85M7*H / 85MH7* / 85M1EH 400 x 300
10-12 M8
* : 0~9, A~Z
70inch
85″
85″
