ENDaily Reference Guide
1. ON-OFF/Reset button with indicator light
2. Eco program button with indicator light
3. Auto Intensive program button with indicator light
4. Auto Mixed program button with indicator light
5. Auto Fast program button with indicator light
6. Rapid program button with indicator light
7. Crystals program button with indicator light
8. Prewash program button with indicator light
9. Salt reservoir empty indicator light
10. Rinse Aid reservoir empty indicator light
11. Display
FIRST TIME USE
SETTING MENU
1. Switch on the appliance by pressing the ON-OFF button.
2. Hold the Settings
(Half Load ) button for 3 seconds until you hear
a beep.
3.
h”) will be displayed.
4. Press
button to scroll through the list of available settings (see
table below), then press START/Pause
to view and change the value
of the currently selected setting.
5. Press
to change the value, then press START/Pause to save
the new value.
6. To change another setting, repeat points 2 and 5.
7. Press ON-OFF
or wait 30 seconds to exit the menu.
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machine’s functional components.
The salt reservoir is located in the lower part of the dishwasher (under the
lower rack on the left side).
• It is important to set the water hardness.
•
on the con-
trol panel is lit.
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Position the funnel
right up to its edge (approximately 0,5 kg); it is not un-
usual for a little water to leak out.
3.
with water.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly so that no detergent can get into
the container during the wash program (this could damage the water
softener beyond repair).
reservoir to avoid corrosion.
Setting the water hardness
To allow the water softener to work in a perfect way, it is essential that
the water hardness setting is based on the actual water hardness in your
house. This information can be obtained from your local wa .reilppus ret
The factory setting is “3”. See “WATER HARDNESS TABLE”
.
To change, follow instructions in section “SETTING MENU”.
LETTER SETTING
VALUES
(Default - in bold)
Water Hardness Level
(see “SETTING THE WATER HARDNESS”
and “WATER HARDNESS TABLE”)
1 | 2 | 3 | 4 | 5
Rinse Aid Level
(see “ADJUSTING THE DOSAGE OF RINSE AID”)
0 | 1 | 2 | 3 | 4 | 5
NaturalDry (see “OPTIONS AND FUNCTIONS”)
1 | 0
Sound
1 | 0
Factory Settings
Press START/Pause to restore to the factory
default all the values of the settings included in
the settings menu.
-
element may be damaged as a result of limescale accumulation.
Use of salt is recommended with any type of dishwasher detergent.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently pre-
venting scale buildup on the heater, contributing also to better cleaning ef-
This system regenerates itself with salt, therefore it is required
The frequency of regeneration
depends on the water hardness level setting - regeneration takes place
once per 4-6 Eco cycles with the water hardness level set to 3. The regen-
eration process occurs at the beginning of the cycle with additional fresh
water.
• Single regeneration consumes: ~3L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid dispenser A should be
in the control panel is lit.
1. Open the dispenser B by
pressing and pulling up the
tab on the lid.
2. Pour in the rinse aid (max.110
ml), making sure it does not
If this happens, clean the spill
immediately with a dry cloth.
3. Press the lid down until you hear a click to close it.
NEVER pour the rinse aid directly into the appliance tub.
Adjusting the dosage of rinse aid
the quantity of rinse aid used.
To change, follow instructions in the section “SETTING MENU”.
If the rinse aid level is set to ZERO, no rinse aid will be supplied. The LOW
RINSE AID indicator light will not be lit if you run out of rinse aid.
A maximum of 6 levels can be set according to the dishwasher model.
• If you see bluish streaks on the dishes, set a low number (0-3).
• If there are drops of water or limescale marks on the dishes, set
a mid-range number (4-5).
A
B
12. Program number and remaining time indicator
13. Closed water tap indicator light
14. DESCALE indicator light
15. Power Clean® option button with indicator light
16. Half Load option button with indicator light/ Settings - 3 sec. press
17. Extra Dry option button with indicator light
18. Silent option button with indicator light/ Key lock - 3 sec. press
19. Sani Rinse option button with indicator light
20. Self-Clean program button with indicator light
21. Delay option button with indicator light
22. START/Pause button with indicator light
Water Hardness Table
Level
°dH
German degrees
°fH
French degrees
°Clark
English degrees
1 (soft) 0 - 6 0 - 10 0 - 7
2 (medium) 7 - 11 11 - 20 8 - 14
3 (average) 12 - 16 21 - 29 15 - 20
4 (hard) 17 - 34 30 - 60 21 - 42
5 (very hard) 35 - 50 61 - 90 43 - 62
Before using the appliance carefully read
Safety and Installation Instructions. More information about your
product available on website: whirlpool.com.au
After installation, please remember to remove all transport
protection parts from the dishwasher.
1
2 3 4
5
6
7
8
9
10
11 12 13
14
15 16 17 18 19 20 21 22
CONTROL PANEL
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: whirlpool.com.au
After the salt has been poured into the reservoir, the SALT REFILL indicator
•
It is necessary that
limescale accumulation and damage to internal components may happen
)
.
the salt reservoir never be empty
(otherwise
2
EN
ADVICE AND TIPS
TIPS
Before loading the baskets, remove all food residues from the crockery
and
empty the glasses. You do not need to rinse beforehand under running
water.
Arrange the crockery so that it is held in place rmly and does not tip over;
and arrange the containers with the openings facing downwards and the
concave/convex parts placed obliquely, thus allowing the water to reach
every surface and ow freely.
Warning: lids, handles, trays and frying pans should not prevent the
sprayer arms from rotating.
Place any small items in the cutlery basket.
Very soiled dishes and pans should be placed in the lower basket because
in this sector the water sprays are stronger and allow a higher washing
performance.
After loading the appliance, make sure that the sprayer arms can rotate
freely.
UNSUITABLE CROCKERY
• Wooden crockery and cutlery.
• Delicately decorated glasses, artistic handicrafts and antique crockery.
Their decorations are not resistant.
• Parts in synthetic material which do not withstand high temperatures.
• Copper and tin crockery.
• Crockery soiled with ash, wax, lubricating grease or ink.
The colours of glass decorations and aluminium/silver pieces can change
and fade during the washing process. Some types of glass (e.g. crystal
objects) can become opaque after a number of wash cycles too.
DAMAGE TO GLASS AND CROCKERY
• Only use glasses and porcelain guaranteed by the manufacturer as
dishwasher safe.
• Use a delicate detergent suitable for crockery
• Collect glasses and cutlery from the dishwasher as soon as the wash
cycle is over.
TIPS ON ENERGY SAVING
• When the household dishwasher is used according to the manufactur-
er’s instructions, washing tableware in a dishwasher usually con-
sumes less energy and water than hand dishwashing.
• In order to maximize dishwasher eciency, it is recommended to
initiate the wash cycle once the dishwasher is fully loaded. Loading
the household dishwasher up to the capacity indicated by the manu-
facturer will contribute to energy and water savings. Information on the
correct loading of tableware can be found in the Loading chapter.
In case of partial loading, it is recommended to use a dedicated wash op-
tions if available (Half load/ Zone Wash/ Multizone), lling up only select-
ed racks. Incorrect loading or overloading of the dishwasher may increase
resources usage (such as water, energy and time, as well as increase noise
level), reducing cleaning and drying performance.
• Manual pre-rinsing of tableware items leads to increased water and
energy consumption and is not recommended.
HYGIENE
To avoid odour and sediment which can be accumulated in the dishwash-
er please run a high-temperature program at least once a month. Use
a teaspoon of detergent and run it without loading to clean your appli-
ance.
RESISTANCE TO FROST
If the appliance is placed in surroundings exposed to the risk of frost, it
must be drained completely. Turn o the water tap, remove the inlet and
outlet hoses, and let all the water drain away. Make sure that the water
softener is full of dissolved regeneration salt in the salt container, to
protect the appliance from temperatures of up to -20°C.
If the appliance was stored in frost conditions the appliance must remain at
an ambient temperature of min. 5°C for at least 24 hours before the rst run.
DAILY USE
1. CHECK WATER CONNECTION
Check that the dishwasher is connected to the water supply and that
the tap is open.
2. SWITCH ON THE DISHWASHER
Press the ON/OFF button.
3. LOAD THE RACKS (see LOADING THE RACKS).
4. FILL THE DETERGENT DISPENSER
5. CHOOSE THE PROGRAM AND CUSTOMISE THE CYCLE
Select the most appropriate program in accordance with the type of
crockery and its soiling level (see PROGRAMS DESCRIPTION) by pressing
the PROGRAM button.
Select the desired options (see OPTIONS AND FUNCTIONS).
Not all options are compatible with all programs.
6. START
Start the wash cycle by closing the door and pressing START/Pause
button (led is lit). When the program starts you hear a single beep.
7. END OF WASH CYCLE
The end of the wash cycle is indicated by sound and the display
shows END. Switch o the appliance by pressing the ON/OFF button
and opening the door.
Wait for a few minutes before removing the crockery - to avoid burns.
Unload the racks, beginning with the lower one.
MODIFYING A RUNNING PROGRAM
If a wrong program was selected, it is possible to change it, provided that it
has only just begun. RESET the machine: press and hold the ON/OFF button
for more than 3. sec., and the machine will switch o. The dashboard will
show “0:01”. Wait until drain cycle ends (around 1 minute).
Switch the machine back on using the ON/OFF button and select the
new wash cycle and any desired options. Start the cycle by pressing
the START/Pause button.
ADDING EXTRA CROCKERY
Without switching o the machine, open the door rst slightly to avoid wa-
ter splashing out (START/Pause led starts blinking) (Caution!: Hot steam!)
and place the crockery inside the dishwasher. Close the door and press the
START/Pause button, the cycle will resume from the point at which it was
interrupted.
ACCIDENTAL INTERRUPTIONS
If the door is opened during the wash cycle, or if there is a power cut, the
cycle stops. Close the door and ONLY IF YOU PRESS the START/Pause
button the cycle will resume from the point at which it was interrupted.
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device C. Introduce
the detergent into the dry dispenser D only. Place the amount of
detergent for pre-washing directly inside the tub.
1. When measuring out the detergent refer to the
mentioned earlier information to add the proper
quantity. Inside the dispenser D, there are indica-
tions to help the detergent dosing.
2. Remove detergent residues from the edges of the
dispenser and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling
it up until the closing device is secured in place.
The detergent dispenser automatically opens up at the right time accord-
ing to the program.
Usage of detergent not designed for dishwashers may cause
malfunction or damage to the appliance.
D
C
3
ENDaily Reference Guide
The Eco 50° wash cycle adheres to the regulation standard AS/NZS 2007. Although it has a longer duration than other wash cycles it uses less energy and is less
harmful to the environment.
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) The duration of the program shown on the display or in the booklet is an estimate calculated on standard conditions. The actual time may vary
depending on many factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load
balancing, additional selected options and sensor calibration. The sensor calibration can increase program duration up to 20 min.
WARNING: Dishwasher detergents are strongly alkaline. They can be extremely dangerous if swallowed. Avoid contact with the skin and eyes and
keep children away from the dishwasher when the door is open. Check that the detergent receptacle is empty after completion of the wash cycle.
PROGRAMS TABLE
Program
Programs description
Drying
phase
NaturalDry
Available
options
*)
Duration
of wash
program
(h: min)
**)
Water
con-
sumption
(litres/cycle)
Energy
con-
sumption
(kWh/cycle)
Eco 50°- Environmentally - friendly wash cycle with low energy con-
sumption level. Standard cycle suitable to wash normally soiled load.
3:40 11.53 0.58
Auto Intensive 65° - Automatic program
for heavily soiled crockery, especially for pots
and saucepans (not be used for delicate item)
Senses the level of
soiling on the dishes
and adjusts the
program accor-
dingly. When the
sensor is detecting
the soil level an
animation appears
in the display and
the cycle duration is
updated.
2:25 - 3:10 15.5 - 24.5 1.30 - 1.70
Auto Mixed 55° - Automatic program for
mixed soiled dishes with dried food residues.
1:20 - 3:00 7.5 - 19.5 0.75 - 1.20
Auto Fast 50° - Automatic program for
everyday mixed soiled crockery. Ensures
optimal cleaning and drying performance in
a shorter time.
1:00 - 1:50 7.5 - 15.5 0.70 - 1.10
Rapid 45° - Program to be used for lightly -soiled dishes with not
dried food residues. Does not include the drying phase. Recom-
mend throw detergent on the bottom of dishwasher.
-
0:30 - 0:40 10.0 - 12.0 0.55 - 0.65
Crystals 45° - Used to refresh crockery planned to be washed
later. No detergent is to be used with this program.
1:40 - 1:50 12.5 - 16.5 0.95 - 1.20
Prewash - Use to refresh crockery planned to be washed later. No
detergent is to be used with this program.
-
0:12 4.5 0.10
Self-Clean 65° - Program to be used to perform maintenance of
the dishwasher, to be carried out only when the dishwasher is EMPTY
using specic detergents designed for dishwasher maintenance.
-
-
1:15 11.0 1.10
DESCALE – Alarm - Limescale accumulation was detected on internal
components of the appliance. Check if the Water Hardness Setting is
at the correct value and salt is present in the salt container (see FIRST TIME
USE), then use a descaling product (WPro brand is recommended) with
Self-Clean program. After a successful descaling, the icon will stop being
displayed.
If the actions above are not performed, product performance will deteriorate.
DESCALE warning will start blinking and «dES» alarm will appear on the
display. If still no action is taken, the appliance will only allow a certain
number of cycles to be started (indicated during «dES» alarm display)
and then will be BLOCKED to prevent component damage, with only
the Self-Clean program available. Performing a full descaling will unblock
the product. In the case of extremely high amounts of limescale, descaling
may have to be performed twice to be ecient.
DELAY - The start of the program may be delayed for a period of
time between 0:30 and 24 hours.
1. Select the program and any desired options. Press the DELAY button
(repeatedly) to delay the start of the program. Adjustable from 0:30 to 24
hours. Once the 24 hours setting is reached, press the DELAY another time
to deactivate the DELAY function.
2. Close the door and press the START/Pause button. The timer will begin
counting down.
3. Once this time has elapsed, the indicator light switches o and the program
begins automatically.
The DELAY function cannot be set once a program has been started.
WATER TAP CLOSED – Alarm - Flashes, when there is no inlet water or
water tap is closed.
NaturalDry - It is a convection drying system which automatically opens
the door during/after the drying phase to ensure exceptional drying
performance every day. The door opens at a temperature that is safe to
your kitchen furniture, thus door will not be opened when the option of
SANI RINSE is on.
As additional steam protection, specially designed protection foil is added
together with the dishwasher.
To see how to mount protection foil please refer to the INSTALLATION GUIDE.
This feature is active by default, but it is possible to deactivate it in
the “SETTINGS MENU”.
SENSING - When the sensor is detecting the soil level an
animation appears in the display (around 20 min.) and the cycle
duration is updated. SENSING is for the level of soiling on the
dishes and it is present for all cycles (excepting Eco) adjusting the program
accordingly.
KEYLOCK - A long press (for 3 seconds) of SILENT button, will activate
the KEYLOCK function. The KEYLOCK function will block the control panel
except for the ON/OFF button. To deactivate the KEYLOCK, long press again.
POWER CLEAN® - Thanks to the additional power jets this option
provides a more intensive and powerful wash in the lower rack, in the
specific area. This option is recommended for washing pots and casseroles
(Please refer to the Power Clean® loading section).
EXTRA DRY - The higher temperature during the final rinse and the
extended drying phase allows for improved drying. The EXTRA DRY
option results in the lengthening of the wash cycle.
HALF LOAD - If there are not many dishes to be washed, HALF LOAD is
used to save water, electricity or time depending on the selected program.
Remember to reduce the amount of detergent.
OPTIONS AND FUNCTIONS
OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator lights up)
(see CONTROL PANEL). If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and
beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.
SILENT - Suitable for night-time operation of the appliance. This option
can be used to limit noise emissions during wash phases. It will increase
cycle time depending on base cycle selection.
SANI RINSE - This option can be used to sanitize washed dishes. It will
increase the nal rinse temperature and add an antibacterial wash to
the selected program. Ideal to clean crockery and feeding bottles. The
dishwasher door must be kept shut for the entire duration of the program
in order to guarantee a reduction of germs.
WARNING: the crockery and plates could be extremely hot at the end
of the cycle.
4
EN
LOADING THE RACKS
TOP RACK
The Top Rack provides a targeted cleaning
Wash Zone for saucers, cups, glasses and
racks, making extra space for the rest of the
day’s dishes.
UPPER RACK
Load delicate and light dishes: glasses, cups,
saucers, low salad bowls.
The upper rack has tip-up supports which can
be used in a vertical position when arranging
tea/ dessert saucers or in a lower position to
load bowls and food containers.
(loading example for the upper rack)
Adjusting the height of the upper rack
The height of the upper rack can be adjusted: a high position to place bulky
crockery in the lower basket and low position to make the most of the tip-up
supports by creating more space upwards and avoiding collision with the
items loaded into the lower rack.
The upper rack is equipped with an Upper Rack height
adjuster (see figure), without pressing the levers, lift it up
by simply holding the rack sides, as soon as the rack is sta-
ble in its upper position. To restore to the lower position,
press the levers A at the sides of the rack and move the
basket downwards.
We strongly recommend that you do not adjust the
height of the rack when it is loaded.
NEVER raise or lower the basket on one side only.
Foldable flaps with adjustable position
The side foldable flaps can be folded or unfolded
to optimize the arrangement of crockery inside
the rack. Wine glasses can be placed safely in
the foldable flaps by inserting the stem of each
glass into the corresponding slots.
Depending on the model:
LOWER RACK
For pots, lids, plates, salad bowls, cutlery etc. Large plates and lids should
ideally be placed at the sides to avoid interferences with the spray arm.
The lower rack has tip-up supports which can be used in a vertical position
when arranging plates or in a horizontal position (lower) to load pans and
salad bowls easily.
(loading example for the lower rack)
POWER CLEAN®
Power Clean® uses the special water jets in
the rear of the cavity to wash more intensi-
vely the highly dirty items. The lower rack has
a Space Zone, special pull-out support in the
rear of the rack that can be used to support
frying pans or baking pans in an upright
position, thus taking up less space.
Placing the pots/casseroles faced to the
Power Clean® component please activate
the POWER CLEAN® on the panel.
How to use the Power Clean®:
1. Adjust the Power Clean® area G folding
down the rear plate holders to load pots.
2. Load pots and casseroles inclined vertically
in the Power Clean® area. Pots have to be
inclined towards the powerful water jets.
CAPACITY: 14 standard place-settings
NOTES:
Knives and other utensils with sharp
points must be positioned with the
blades facing down.
CUTLERY BASKET
It is equipped with two upper racks to fa-
cilitate the arrangement of cutlery.
The basket can only be positioned at the
front of the lower basket.
NOTES:
Knives and other sharp utensils must be
placed in the cutlery basket with the
points facing down or they must be
positioned horizontally in the tip-up
compartments on the top rack.
cutlery that you’d normally load in the lower
A separate arrangement of the cutlery
makes collection easier after washing
and improves washing and drying
performance.
5
ENDaily Reference Guide
CLEANING THE SPRAY ARMS
On occasions, food residue
may become encrusted onto
the spray arms and block the
holes used to spray the water.
It is therefore recommended
that you check the arms from
time to time and clean them
with a small non-metallic
brush.
To remove the upper spray
you must remove it together
with the manifold.
The lower spray arm may be removed
by pulling it upwards and rotating it
anti-clockwise. Mounting back the
spray arm is by pulling it down and
rotating it clockwise.
The top spray arm may be removed
by pressing it up and then rotating it
anti-clockwise. Mounting back the
spray arm is by pulling it upwards and
rotating it clockwise.
TROUBLESHOOTING
PROBLEMS POSSIBLE CAUSES SOLUTIONS
The salt
indicator is lit
Salt reservoir is almost empty.
Refill the reservoir with salt (for more information - see FILLING THE SALT RESERVOIR).
Check the water hardness setting if necessary - see WATER HARDNESS TABLE.
The salt
indicator
is blinking
Salt reservoir is empty.
Refill the reservoir with salt as soon as possible. Using the appliance without salt may cause
damage to its internal components.
The rinse aid
indicator is lit
or blinking
Rinse aid dispenser is empty. (After refill the rinse
aid indicator may remain lit for a short time).
Refill the dispenser with a rinse aid (for more information - see FILLING THE RINSE AID DISPENSER).
Descale indicator
is lit or blinking;
«dES» alarm
is displayed.
Limescale is accumulating on internal components
of the appliance.
Descale the appliance immediately using the Self Clean program and a commercially available
descaling product (see OPTIONS AND FUNCTIONS). Refill the reservoir with salt. Check the
water hardness setting. If the appliance is not descaled, it will stop functioning.
The dishwasher
won’t start or does
not respond to
commands.
The appliance has not been plugged in properly. Insert the plug into the socket.
Power outage.
For safety reasons, the dishwasher will not restart automatically when power returns.
Close the door and press START/Pause button.
The dishwasher door is not closed.
NaturalDry pin is not pulled in.
Vigorously push the door until you hear the “click”.
A cycle is interrupted by door opening for more
than 4 seconds.
Close the door within 4 seconds and press START/Pause button.
The control panel does not respond or F6 E1 is
displayed.
Switch off the appliance by pressing the ON-OFF/Reset button, switch it back on after approxi-
mately one minute and restart the program. If the problem persists, unplug the appliance for
1 minute, then plug it back in.
In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list.
For other errors or issues please contact authorized After-sales Service whose contact details can be found in the warranty booklet.
CLEANING THE FILTER ASSEMBLY
Regularly clean the filter assembly so that the filters do not clog and that
the waste water flows away correctly.
Using the dishwasher with clogged filters or foreign objects inside the fil-
tration system or spray arms may cause unit malfunction resulting in loss of
performance, noisy work or higher resources usage.
The filter assembly consists of three filters which remove food residues
from the washing water and then recirculate the water.
The dishwasher must not be used without filters or if the filter is loose.
At least once per month or after every 30 cycles, check the filter assembly
and if necessary clean it thoroughly under running water, using a non-me-
tallic brush and following the instructions below:
1. Turn the cylindrical filter A in an anti-clockwise direction and pull it out
(Fig 1). It is important when reinstalling the filter that the two trian-
gles shown on the zoom meet.
2. Remove the cup filter B by exerting a slight pressure on the side flaps
(Fig 2).
3. Slide out the stainless-steel plate filter C (Fig 3).
4. In case you find foreign objects (such as broken glass, porcelain, bones,
fruit seeds etc.) please remove them carefully.
5. Inspect the trap and remove any food residues. NEVER REMOVE the
wash-cycle pump protection (shown by an arrow) (Fig 4).
After cleaning the filters, replace the filter assembly and fix it in position
correctly; this is essential for maintaining the effcient operation of the dish -
washer.
CARE AND MAINTENANCE
2
1
4
3
A
A
B
C
6
EN
PROBLEMS POSSIBLE CAUSES SOLUTIONS
Policy and standard documentation and additional product information can be found by:
• Visiting our website: whirlpool.com.au
• Using QR Code
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet).
When contacting our After-sales Service, please state the codes provided on your product’s
identification plate.
IEC 436
:
The dishwasher
finishes the cycle
prematurely.
Display shows:
F8 E3
The filter is clogged with food residues or lime-
scale.
Clean the filter and descale the appliance (see CLEANING THE FILTER ASSEMBLY and DESCALE
INSTRUCTION).
Drain hose positioned too low or siphoning into
the home sewage system.
Check if the end of the drain hose is placed at the correct height (see INSTALLATION). Check
for siphoning into the home sewage system, and install a siphon breaker/air admittance valve
if necessary.
An excessive amount of foam is present.
The detergent has not been measured out correctly or it is not suitable for use in dishwashers
(see FILLING THE DETERGENT DISPENSER).
Air in the water supply. Check water supply for leaks or other issues letting air inside.
The dishes are not
dried well.
Rinse aid is not present or the dosage is too low.
Make sure the rinse aid dispenser is filled (see FILLING THE RINSE AID DISPENSER). Multifunc-
tional tablets only will not provide as good drying effects as the actual use of liquid rinse aid.
The dishes have been unloaded after the door
was opened automatically but before the actual
cycle end.
Make sure the cycle has ended before starting to unload the dishes (see DAILY USE). For even
better drying results, it is recommended to let the dishes sit inside the dishwasher with the
door open for additional 15 minutes after the cycle ends.
The dishes are sitting too flat.
If you notice puddles of water inside cavities of cups, mugs or bowls, try loading the dishes
(especially in the upper rack) providing more inclination to let larger amounts of water drip
down before drying starts.
The selected cycle does not have the drying
phase.
Please check in the PROGRAMS TABLE if the selected program is equipped in the drying phase.
A cycle without the drying phase may not deliver desired drying effciency, so it is
recommended to change cycle selection for the one that has the drying phase.
The dishes are made of non-stick or plastic. Some water drops remaining on this type of material are normal.
Dishes and glasses
have blue streaks
or bluish tinges.
Rinse aid dosage is excessive. Adjust the dosage to a lower setting.
Dishes and glasses
are covered with
limescale or a whi-
tish film.
The salt reservoir is empty.
Refill the reservoir with salt as soon as possible. Using the appliance without salt may cause
damage to its internal components.
The water hardness setting is too low.
Increase the setting (see WATER HARDNESS TABLE).
The cap of the salt reservoir is not properly
closed.
Check and close the salt reservoir cap.
The rinse aid reservoir is empty or the rinse aid
dosage is insucient.
Refill the dispenser with rinse aid and check the dosage setting (for more information - see
FILLING THE RINSE AID DISPENSER).
The dishwasher
shows F8 E5
Valve is blocked or faulty. Close the water tap, if possible. Do not switch off the power supply. Call the service.
The dishwasher
won’t drain.
Display shows:
F7 E3 or F9 E1
The filter is clogged with food residues or lime-
scale.
Clean the filter and descale the appliance (see CLEANING THE FILTER ASSEMBLY and DESCALE
INSTRUCTION).
The drain hose is kinked. Check the drain hose (see INSTALLATION INSTRUCTION).
The sink drain pipe is blocked. Clean the sink drain pipe.
The dishwasher
makes excessive
noise.
Dishes are rattling against each other. Position the crockery correctly (see LOADING THE RACKS).
An excessive amount of foam is present.
The detergent has not been measured out correctly or it is not suitable for use in dishwashers
(see FILLING THE DETERGENT DISPENSER). Restart the current cycle by switching OFF the
dishwasher, then switch it on again, select a new program, close the door and press
START/Pause button. Please do not add any detergent.
Crockery has not been arranged properly. Arrange the crockery correctly (see LOADING THE RACKS).
The filter is clogged with food residues or limescale.
Clean the filter assembly (see CARE AND MAINTENANCE).
The dishes are not
clean.
Crockery has not been arranged properly. Arrange the crockery correctly (see LOADING THE RACKS).
Spray arms cannot rotate freely, being hindered
by the dishes.
Arrange the crockery correctly (see LOADING THE RACKS). Check that the upper rack is in the
correct position and adjust (lift up) if necessary.
The wash cycle is too gentle. Select an appropriate wash cycle (see PROGRAMS TABLE).
An excessive amount of foam is present.
The detergent has not been measured out correctly or it is not suitable for use in dishwashers
(see FILLING THE DETERGENT DISPENSER).
The cap on the rinse aid compartment has not
been closed correctly.
Make sure the cap of the rinse aid dispenser is closed.
The filter is clogged with food residues or limescale.
Clean the filter and descale the appliance (see CLEANING THE FILTER ASSEMBLY).
The salt reservoir is empty. Fill the salt reservoir (see FILLING THE SALT RESERVOIR).
The dishwasher
does not fill the
water.
The display shows:
H
2
O and is
lit; acoustic alarm
sounds.
No water in the water supply or the tap is closed. Make sure there is water in the water supply and the water tap is open.
The water inlet hose is kinked. Check the inlet hose (see INSTALLATION). Close the door and press START/Pause button.
The screen in the water inlet hose is clogged; it is
necessary to clean it.
Check and clean the screen in the water inlet hose. Close the door and press START/Pause
button.
7
ENDaily Reference Guide
8
EN
703D850020412A
