KQD114VPX
EN
58 4749 0100/AA
Refrigerator
User Manual
A
A
A
C
SUPPLIER’S NAME
MODEL IDENTIFIER
(*)
INFORMATION
C
.The model information as stored in the product data base
can be reached by entering following website and searching
for your model identifier (*) found on energy label.
https://eprel.ec.europa.eu/
Dear Customer,
Please read this manual before using the product.
Thank you for choosing this product. We would like you to achieve the optimal efficiency
from this high quality product which has been manufactured with state of the art technol-
ogy. To do this, carefully read this manual and any other documentation provided before
using the product and keep it as a reference.
Heed all information and warnings in the user manual. This way, you will protect yourself
and your product against the dangers that may occur.
Keep the user manual. Include this guide with the unit if you hand it over to someone else.
The following symbols are used in the user guide:
Hazard that may result in death or injury.
NOTICE A hazard that may cause material damage to the product or its
surroundings
Important information or useful tips on operation.
Read the user manual.
Risk of fire / Flammable materials.
2 / 37 EN
Refrigerator / User Manual
1 Safety Instructions 3
2 Your Refrigerator 8
3 Installation 9
3.1 Appropriate location for installation . . . . . . . .9
3.2 Installing the plastic wedges . . . . . . . . . . . . .9
3.3* Adjusting the feet . . . . . . . . . . . . . . . . . . .10
3.4 Electric connection . . . . . . . . . . . . . . . . . . .10
3.5 Adjusting the gap between the upper door. .11
4 Preparation 12
4.1 Things to be done for saving energy . . . . .12
4.2 Recommendations about the fresh food
compartment. . . . . . . . . . . . . . . . . . . . . .13
4.3 Initial use. . . . . . . . . . . . . . . . . . . . . . . . .13
5 Operating the product 14
5.1 Indicator panel . . . . . . . . . . . . . . . . . . . . . .14
5.2 Indicator panel. . . . . . . . . . . . . . . . . . . . .19
5.3 Freezing fresh food. . . . . . . . . . . . . . . . . . .20
5.4 Recommendations for preserving the frozen
food . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
5.5 Deep-freeze information . . . . . . . . . . . . . . .22
5.6 Placing the food . . . . . . . . . . . . . . . . . . . . .22
5.7 Door open warning . . . . . . . . . . . . . . . . . . .22
5.8 Crisper. . . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.9 Humidity-controlled crisper . . . . . . . . . . . . .22
5.10 Egg tray . . . . . . . . . . . . . . . . . . . . . . . . . .23
5.11 Movable Middle Section . . . . . . . . . . . . . .23
5.12 Cool Control Storage Compartment . . . . .23
5.13 Blue light/VitaminCare+ . . . . . . . . . . . . . .23
5.14 Odour filter. . . . . . . . . . . . . . . . . . . . . . . .23
5.15 Use of internal water dispenser and water
dispenser at the door . . . . . . . . . . . . . . . .24
5.16 Dispensing water . . . . . . . . . . . . . . . . . . .24
5.17 For using water dispenser. . . . . . . . . . . . .25
5.18 Icematic . . . . . . . . . . . . . . . . . . . . . . . . .25
5.19 Icematic and ice storage container . . . . . .26
6 Maintenance and Cleaning 27
7. Troubleshooting 28
3 / 37 EN
Refrigerator / User Manual
• This section includes the safety
instructions necessary to prevent
the risk of personal injury or material
damage.
• Our company shall not be held
responsible for damages that may
occur if these instructions are not
observed.
Installation and repair operations shall always
be performed by Authorized Service.
Always use genuine spare parts and acces-
sories.
Original spare parts will be provided for 10
years, following the product purchasing date.
Do not repair or replace any part of the product
unless specified expressly in the user manual.
Do not perform any modifications on the
product.
1.1 Purpose of usage
• This product is not intended for commercial
use and it shall not be used out of its intended
purpose.
This product is intended for operating interiors, such
as households or similar.
For example;
- In the staff kitchens of the stores, offices and
other working environments,
- In farm houses,
- In the units of hotels, motels or other resting
facilities that are used by the customers,
- In hostels, or similar environments,
- In catering services and similar non-retail applica-
tions.
This product shall not be used in open or enclosed
external environments such as vessels, balconies or
terraces. Exposing the product to rain, snow, sunlight
and wind may cause risk of fire.
1.2 Safety of children,
vulnerable persons and pets
• This product may be used by children
aged 8 years and older and persons
with underdeveloped physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given supervision
or instruction concerning use of the
appliance in a the product safe way
and the hazards involved.
• Children between 3 and 8 years are
allowed to put and take out food to/
from the cooler product.
• Electrical products are dangerous for
children and pets. Children and pets
must not play with, climb on, or enter
the product.
• Cleaning and user maintenance
should not be performed by children
unless there is someone overseeing
them.
• Keep the packaging materials away
from children. Risk of injury and
suffocation.
• Before disposing of old products that
shall not be used any more:
1.
Unplug the power cord from the mains socket.
2.
Cut the power cord and remove it from the
appliance together with the plug.
3.
Do not remove the racks and drawers from the
product to prevent children from getting inside the
appliance.
4.
Remove the doors.
5.
Store the product so that it shall not be tipped over.
6.
Do not allow children to play with the scrapped
product.
• Do not dispose of the product by throwing it
into fire. Risk of explosion.
• If there is a lock available in the product’s door,
keep the key out of children’s reach.
1 Safety Instructions
4 / 37 EN
Refrigerator / User Manual
Important instructions regarding safety and environment
1.3 Electrical safety
• The product shall not be plugged
into the outlet during installation,
maintenance, cleaning, repair, and
transportation operations.
• If the power the cord is damaged, it
shall be replaced by authorized service
only to avoid any risk that may occur.
• Do not tuck the power cord under the
product or to the rear of the product.
Do not put heavy items on the power
cord. The power cord should not be
bent, crushed, and come into contact
with any heat source.
• Do not use an extension cord, multi-
plug or adaptor to operate your
product.
• Portable multi sockets or portable
power supplies may overheat and
cause fire. Thus, do not have a multi-
plug behind or in the vicinity of the
product.
• The plug shall be easily accessible. If
this is not possible, a mechanism that
meets the electrical legislation and
that disconnects all terminals from
the mains (fuse, switch, main switch,
etc.) shall be available on the electrical
installation.
• Do not touch the plug with wet hands.
• When unplugging the appliance, don’t
hold the power cord, but the plug.
• When positioning the appliance,
ensure the supply cord is not trapped
or damaged
•
Do not locate multiple portable socket-
outlets or portable power supplies at the
rear of the appliance.
1.4 Handling Safety
• This product is heavy, do not handle it
by yourself.
• Do not hold the product from its door
while handling the product.
• Be careful not to damage the cooling
system and the pipes while handling
the product. Do not operate the
product if the pipes are damaged, and
contact an authorized service.
1.5 Installation Safety
• Contact the Authorized Service
for the product’s installation. To
prepare the product for installation,
see the information in the user
guide and make sure the electric
and water utilities are as required.
If the installation is not suitable, call
a qualified electrician and plumber
to have them make the necessary
arrangements. Otherwise, electric
shock, fire, issues with the product or
injuries may occur.
• Check for any damage on the product
before installing it. Do not have the
product installed if it is damaged.
• Place the product on a level and
hard surface and balance with the
adjustable legs. Otherwise, the
refrigerator may tip over and cause
injuries.
• The product shall be installed in a
dry and ventilated environment.
Do not keep carpets, rugs or similar
floor covers under the product. This
may cause risk of fire as a result of
inadequate ventilation!
• Do not block or cover ventilation
holes. Otherwise, power consumption
may be increased and damage to your
product may occur.
• Do not connect the product to supply
systems such as solar power supplies.
Otherwise, damage to your product
may occur as a result of the abrupt
voltage fluctuations!
• The more refrigerant a refrigerator
contains, the bigger its installation
5 / 37 EN
Refrigerator / User Manual
Important instructions regarding safety and environment
room shall be. In very small rooms,
a flammable gas-air mixture may
occur in case of a gas leak in the
cooling system. At least 1 m³ of
volume is required for each 8 grams
of refrigerant. The amount of the
refrigerant available in your product
is specified in the Type Label.
• The installation place of the product
shall not be exposed to direct
sunlight and it shall not be in the
vicinity of a heat source such as
stoves, radiators, etc.
If you cannot prevent installation of the
product in the vicinity of a heat source,
you shall use a suitable insulation plate
and the minimum distance to the heat
source shall be as specified below.
- At least 30 cm away from heat
sources such as stoves, heating units
and heaters, etc.,
- And at least 5 cm away from electric
ovens.
• Your product has the protection
class of I. Plug the product in a
grounded socket that conforms with
the Voltage, Current and Frequency
values specified in the type label. The
socket outlet shall be equipped with a
fuse with a rating of 10 A – 16 A. Our
company shall not be responsible for
the damages that shall be incurred
as a result of operating the product
without ensuring ground and
electrical connections made as per
local or national regulations.
• The product’s power cable must
be unplugged during installation.
Otherwise, risk of electric shock and
injury may occur!
•
Do not plug the product to loose, broken, dirty,
greasy sockets or sockets that has come out
their seats or sockets with a risk of water con
-
tact.
• Place the power cord and hoses (if available) of
the product so that they shall not cause a risk of
tripping over.
• Penetration of humidity to live parts or to the
power cord may cause short circuit. Thus, do
not use the product in humid environments or
in areas where water may splash (e.g. garage,
laundry room, etc.) If the refrigerator is wet
by water, unplug it and contact an authorized
service.
• Do not connect your refrigerator to power sav-
ing devices. These systems are harmful for the
product.
1.6
Operational safety
• Do not use chemical solvents on the
product. These materials contain an
explosion risk.
• In case of a failure of the product,
unplug it and do not operate until it
is repaired by the authorized service.
There is a risk of electric shock!
• Do not place a source of flame (e.g.
candles, cigarettes, etc.) on the
product or in the vicinity of it.
• Do not get on the product. Risk of
falling and injury!
• Do not cause damage to the pipes of
the cooling system using sharp and
piercing tools. The refrigerant that
sprays out in case of puncturing the
gas pipes, pipe extensions or upper
surface coatings may cause irritation
of skin and injuries of the eyes.
• Do not place and operate electric
appliances inside the refrigerators/
deep freezer unless it is advised by
the manufacturer.
• Do not jam any parts of your hands or
your body to the moving parts inside
the product. Be careful to prevent
jamming of your fingers between the
refrigerator and its door. Be careful
while opening or closing the door if
there are children around.
6 / 37 EN
Refrigerator / User Manual
Important instructions regarding safety and environment
• Do not put ice cream, ice cubes or
frozen food to your mouth as soon as
you take them out of the freezer. Risk
of frostbite!
• Do not touch the inner walls, metal
parts of the freezer or food kept
inside the refrigerator with wet
hands. Risk of frostbite!
• Do not place soda cans or cans
and bottles that contain fluids
that may be frozen to the freezer
compartment. Cans or bottles may
explode. Risk of injury and material
damage!
• Do not use or place materials
sensitive against temperature
such as flammable sprays,
flammable objects, dry ice or other
chemical agents in the vicinity of
the refrigerator. Risk of fire and
explosion!
• Do not store explosive materials
such as aerosol cans with flammable
materials inside the product.
• Do not place cans containing fluids
over the product. Splashing of water
on an electrical part may cause the
risk of an electric shock or a fire.
• This product is not intended for
storage and cooling of medicines,
blood plasma, laboratory preparations
or similar materials and products that
are subject to the Medical Products
Directive.
• If the product is used against its
intended purpose, it may cause
damage to or deterioration of the
products kept inside.
• If your refrigerator is equipped with
blue light, do not look at this light
with optical devices. Do not stare
directly at UV LED light for a long
time. Ultraviolet rays may cause eye
strain.
• Do not fill the product with more food
than its capacity. Injuries or damages
may occur if the contents of the
refrigerator falls when the door is
opened. Similar problems may occur
when an object is placed over the
product.
• Ensure that you have removed any
ice or water that may have fallen to
the floor to prevent injuries.
• Change the locations of the racks/
bottle racks on the door of your
refrigerator while the racks are
empty only. Danger of physical injury!
• Do not place objects that may fall/
tipped over on the product. These
objects may fall while opening or
closing the door and cause injuries
and/or material damages.
• Do not hit or exert excessive pressure
on glass surfaces. Broken glass
may cause injuries and/or material
damages.
• The cooling system in your product
contains R600a refrigerant. The
refrigerant type used in the product
is specified in the the type label.
This gas is flammable. Therefore, be
careful not to damage the cooling
system and the pipes while operating
the product. In case of damage to the
pipes;
- do not touch the product or the power cord,
- Keep the product away from potential sources
of fire that may cause the product to catch fire.
- ventilation the area where the product is
placed. Do not use a fan.
- Contact authorized service.
• If the product is damaged and you
observe gas leak, please stay away
from the gas. Gas may cause frostbite
if it contacts your skin.
7 / 37 EN
Refrigerator / User Manual
Important instructions regarding safety and environment
For Products With Water Fountain / Ice Maker
• Use only drinking water. Do not fill the water
tank with fruit juice, milk, fizzy beverages,
alcoholic beverages or any other liquids
incompatible for use in the water fountain. This
may cause risk to your health and safety.
• Do not allow the children to play with the water
dispenser or Ice Maker to prevent accidents
and injuries.
• Do not insert your fingers or other objects
inside the hole of the water dispenser, ice
channel or inside the container of the Ice
Maker. This may cause injuries or material
damages.
1.7 Maintenance and
cleaning safety
• Do not pull by the door handle if you
shall move the product for cleaning
purposes. Handle may cause injuries
if it is pulled too hard.
• Do not clean the product by spraying
or pouring water on the product and
inside the product. Risk of electric
shock and fire.
• Do not use sharp or abrasive tools
to clean the product. Do not use
materials such as household cleaning
agents, detergents, gas, gasoline,
alcohol, wax, etc.
• Use cleaning and maintenance
agents that are not harmful for food
only inside the product.
• Do not use steam or steamed
cleaning materials for cleaning the
product and thawing the ice inside it.
Steam contacts the live areas in your
refrigerator and causes short circuit
or electric shock!
• Take care to keep water away from
the electronic circuits or lighting of
the product.
• Use a clean, dry cloth to wipe the dust
or foreign material on the tips of the
plugs. Do not use a wet or damp piece
of cloth to clean the plug. Otherwise,
risk of fire or electric shock may occur.
1.8HomeWhiz
(May not be applicable for all models)
• Follow the safety warnings even if
you are away from the product while
operating the product via HomeWhiz
app. Also, pay attention to the
warnings in the app.
1.9 Lighting
(May not be applicable for all models)
• Contact an authorized service when
you shall replace the LED / bulb using
for lighting.
8 / 37 EN
Refrigerator / User Manual
C
Figures in this user manual are schematic and may not match the product exactly. If the subject parts
are not included in the product you have purchased, then those parts are valid for other models.
2 Your Refrigerator
6
*12
1- Control and indicator panel
2- Butter & Cheese section
3- Movable door shelf
4- Fridge compartment glass shelf
5- Fridge compartment crisper
6- Bottle shelf
7- Chiller compartment
8- Icebox drawer
9- Multizone compartment glass shelf/cooler
10- Freezer compartment drawers
11- Multizone Compartment's drawer
12- Water tank
* OPTIONAL
9 / 37 EN
Refrigerator / User Manual
3.1 Appropriate location
for installation
In order to prepare the product for use, refer the
information in the user manual and ensure that
electrical installation and water installation are
appropriate. If not, call a qualified electrician and
technician to have any necessary arrangements
carried out.
B
WARNING: Manufacturer shall not
be held liable for damages that may
arise from procedures carried out by
unauthorized persons.
B
WARNING: Product must not be plugged
in during installation. Otherwise, there is
the risk of death or serious injury!
A
WARNING: : If the door clearance of the
room where the product shall be placed is
so tight to prevent passing of the product,
remove the door of the room and pass the
product through the door by turning it to
its side; if this does not work, contact the
authorized service.
•Placetheproductonalevelfloorsurfaceto
prevent jolts.
•Installtheproductatleast30cmawayfrom
heat sources such as hobs, heater cores and
stoves and at least 5 cm away from electrical
ovens.
•Productmustnotbesubjectedtodirectsunlight
and kept in humid places.
•Yourproductrequiresadequateaircirculationto
function efficiently. If the product will be placed
in an alcove, remember to leave at least 5 cm
clearance between the product and the ceiling,
rear wall and the side walls.
•Iftheproductwillbeplacedinanalcove,
remember to leave at least 5 cm clearance
between the product and the ceiling, rear
wall and the side walls. Check if the rear wall
clearance protection component is present at
its location (if provided with the product). If the
component is not available, or if it is lost or
fallen, position the product so that at least 5 cm
3 Installation
clearance shall be left between the rear surface
of the product and the wall of the room. The
clearance at the rear is important for efficient
operation of the product.
•Donotinstalltheproductinplaceswherethe
temperature falls below -5°C.
3.2 Installing the plastic wedges
Plastic wedges supplied with the product are
used to create the distance for the air circulation
between the product and the rear wall.
1.
To install the wedges, remove the screws on the
product and use the screws supplied together with the
wedges.
2.
Insert the 2 plastic wedges onto the rear ventilation
cover as illustrated in the figure.
10 / 37 EN
Refrigerator / User Manual
Installation
3.3* Adjusting the feet
If the product stands unbalanced after installation,
adjust the feet on the front by rotating them to the
right or left.
To adjust the doors vertically,
Loosen the fixing nut located at the bottom.
Rotate the adjusting nut according to the position
of the door (clockwise/counter-clockwise).
Tighten the fixing nut in order to fix the position.
To adjust the doors horizontally,
Loosen the fixing nut located at the top.
Rotate the side adjusting nut according to the
position of the door (clockwise/counter-clockwise).
Tighten the fixing nut which is at the top in order to
fix the position.
adjusting nut
fixing nut
fixing nut
adjusting nut
3.4 Electric connection
A
WARNING: Do not make connections via
extension cables or multi-plugs.
B
WARNING: Damaged power cable must
be replaced by the Authorized Service
Agent.
C
If two coolers are to be installed side
by side, there should be at least 4 cm
distance between them.
• Our company shall not be liable for any
damages that will arise when the product
is used without grounding and electrical
connection in accordance with the national
regulations.
• Power cable plug must be within easy reach
after installation.
• Do not use extension cords or multiple socket
outlets.
11 / 37 EN
Refrigerator / User Manual
Installation
3.5 Adjusting the gap between
the upper door
•Youcanadjustthegapbetweenthefridge
compartment doors as illustrated in the figures.
•Adjustthedoorasyoudesirebyloosingthe
screws.
•Fixthedooryouhaveadjustedbytightening
the screws without changing the position of the
door.
Door shelves should be empty when
adjusting the door height.
Using a screwdriver, remove two screws of
upper hinge cover of the door you want to
adjust.
Center Screw
The hinge cover is attached after the sockets are
installed.
Replace the hinge cover and fix with two screws.
12 / 37 EN
Refrigerator / User Manual
4 Preparation
• In case of multiple options are present glass
shelves must be placed so that the air outlets
at the backwall are not blocked, prefably air
outlets are remaining below the glass shelf.
This combination may help impoving air
distribution and energy efficiency.
• Airflow should not be blocked by placing
foods in front of the freezer and the multizone
compartment fans. Foods should be loaded by
leaving minimum 5 cm space in front of the
protective fan grid.
• Thawing the frozen foods in the fridge
compartment both saves energy and reserves
the quality of the foods.
C
Temperature of the room where your
refrigerator is located should at least
be
10ºC /50°F. Operating your
refrigerator under cooler conditions is not
recommended with regard to its efficiency.
C
Inside of your refrigerator must be cleaned
thoroughly.
C
If two coolers are to be installed side
by side, there should be at least 4 cm
distance between them.
4.1 Things to be done for
saving energy
A
Connecting your refrigerator to systems
that save energy is dangerous as they may
cause damage on the product.
• For a freestanding appliance; ‘this refrigerating
appliance is not intended to be used as a built-
in appliance.
• Do not leave the doors of your refrigerator open
for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload the refrigerator. Cooling
capacity will fall when the air circulation in the
refrigerator is hindered.
• Do not place the refrigerator in places subject
to direct sunlight. Install the product at least
30 cm away from heat sources such as hobs,
ovens, heater units and stoves and at least 5
cm away from electrical ovens.
• Pay attention to store your food in refrigerator
in closed containers.
• For storage flexibility it is OK to remove
some freezer compartment drawers. Power
consumption stated for your refrigerator has
been determined after removing the icematic
and the upper drawers as to allow maximum
loading.
• Since hot and humid air will not directly
penetrate into your product when the doors
are not opened, your product will optimize
itself in conditions sufficient to protect your
food. Functions and components such as
compressor, fan, heater, defrost, lighting,
display and so on will operate according to
the needs to consume minimum energy under
these circumstances.
13 / 37 EN
Refrigerator / User Manual
Preparation
4.2 Recommendations about the
fresh food compartment
• Make sure that the food does not touch the
temperature sensor in fresh food compartment.
To allow the fresh food compartment to keep
its ideal storage temperature, the sensor must
not be hindered by food.
• Do not place hot foods or beverages inside the
product.
4.3 Initial use
Before using the product, make sure that all
preparations have been made in accordance
with the instructions given in the "Important
instructions regarding safety and environment" and
"Installation" chapters.
• Clean the interior of the refrigerator as
recommended in the “Maintenance and
cleaning” section. Before you start the
refrigerator, make sure that the interior is dry.
• Plug the refrigerator in a grounded socket. The
interior illumination is lit when the door of the
refrigerator is opened.
• Operate the refrigerator for 6 hours without
placing any food in it and do not open its door
during this time unless it is necessary.
C
Youwillhearanoisewhenthecompressor
starts up. The liquids and gases sealed
within the refrigeration system may also
give rise to noise, even if the compressor is
not running and this is quite normal.
C
Front edges of the refrigerator may
feel warm. This is normal. These areas
are designed to be warm to avoid
condensation.
14 / 37 EN
Refrigerator / User Manual
5 Operating the product
C
Figures in this user manual are schematic and may not match the product exactly. If the subject parts
are not included in the product you have purchased, then those parts are valid for other models.
5.1 Indicator panel
Touch-controlled indicator panel allows you to set the temperature and control the other functions related
to the refrigerator without opening the door of the product. Just press the relevant buttons for function
settings.
Select
Quick FreezeQuick Cool
FN
OK
3 “
3 “
1
2 3
4
5 *6
9 10 11
12
*13
14
15
16
*17
*18
19
20
27
*28
29
30
31
32
33
*34.1
*34.2
Select
Quick FreezeQuick Cool
FN
OK
3 “
3 “
*7
*8
*22
21
23
24
*25
26
15 / 37 EN
Refrigerator / User Manual
Operating the product
1. Quick cooling function indicator
It turns on when the quick fridge function is
activated.
2. Fridge compartment temperature indicator
Temperature of the fridge compartment is shown;
it can be set to 8,7,6,5,4,3,2,1.
3. Fahrenheit indicator
It is a Fahrenheit indicator. When the Fahrenheit
indication is activated, the temperature set values
are shown in Fahrenheit and the relevant icon
turns on.
4. Key lock
Press key lock button continually for 3 seconds.
Key lock symbol will light up and key lock mode
will be activated. Buttons will not function if the
Key lock mode is active. Press key lock button
continually for 3 seconds again. Key lock symbol
will turn off and the key lock mode will be exited.
Press the key lock button if you want to prevent
changing of the temperature setting of the
refrigerator.
5. Power failure/High temperature / error
warning
This indicator illuminates during power failure, high
temperature failures and error warnings. During
long-term power failures, the highest temperature
value that the freezer compartment reaches will
blink on the digital display. After checking the food
located in the freezer compartment, press the
alarm off button to clear the warning.
Please refer to "solutions recommended for
troubleshooting" section on your manual if you
observe that this indicator is illuminated.
6.* Filter reset icon
This icon turns on when the filter needs to be
reset.
7. *Temperature change cabin icon
Indicates the cabin whose temperature is to be
changed. When the temperature change cabin icon
starts flashing, it is understood that the relevant
cabin has been selected.
8. *Multizone freezer icon
Illuminate the Multizone freezer icon using the FN button;
the icon will start to flash. When you press the OK key,
Multizone cabin freezer icon turn on and operates as a
freezer.
9. Freezer compartment temperature
indicator
Temperature of the fridge compartment is shown;
it can be set to -16-18,-19, -20, -21, -22,-24.
10. Quick freeze function indicator
It turns on when the quick freeze function is
activated.
11. Fahrenheit indicator
It is a Fahrenheit indicator. When the Fahrenheit
indication is activated, the temperature set values
are shown in Fahrenheit and the relevant icon
turns on.
12. Quick freeze function button
Press this button to activate or deactivate the quick
freeze function. When you activate the function,
the freezer compartment will be cooled to a
temperature lower than the set value.
C
Use the quick freeze function when you
want to quickly freeze the food placed
in freezer compartment. If you want
to freeze large amounts of fresh food,
activate this function before putting the
food into the product.
C
If you do not cancel it, Quick Freeze
will cancel itself automatically after 24
hours at the most or when the fridge
compartment reaches to the required
temperature.
C
This function is not recalled when
power restores after a power failure.
13.* Filter reset
The filter is reset when the quick freeze button is
pressed for 3 seconds. Filter reset icon goes off.
14. FN button
Using this key, you can switch between the
functions that you want to select. Upon pressing
this key, the icon, whose function is required to be
16 / 37 EN
Refrigerator / User Manual
Operating the product
activated or deactivated, and this icon's indicator
starts flashing. The FN button gets deactivated if
notpressedfor20seconds.Youneedtopressthis
button to change the functions again.
15. Celsius indicator
It is a Celsius indicator. When the Celsius indication
is activated, the temperature set values are shown
in Celsius and the relevant icon turns on.
16. OK button
After navigating the functions using the FN button,
when the function is cancelled via the OK button,
the relevant icon and the indicator flashes. When
the function is activated, it remains on. The
indicator continues to flash in order to show the
icon it is on.
17. *Temperature change cabin icon
Indicates the cabin whose temperature is to be
changed. When the temperature change cabin icon
starts flashing, it is understood that the relevant
cabin has been selected.
18. *Temperature change cabin icon
Indicates the cabin whose temperature is to be
changed. When the temperature change cabin icon
starts flashing, it is understood that the relevant
cabin has been selected.
19. Set increasing button
Select the relevant cabin with the select button;
the cabin icon representing the relevant cabin will
start to flash. If you press the set increasing button
during this process, the set value gets increased. If
you keep pressing it in a loop, the set value returns
to the beginning.
20. Temperature change cabin icon
Indicates the cabin whose temperature is to be
changed. When the temperature change cabin icon
starts flashing, it is understood that the relevant
cabin has been selected.
21. Setting the Celsius and Fahrenheit
indicator
Illuminate this key using the FN key and select
Fahrenheit and Celsius via the OK key. When
the relevant temperature type is selected, the
Fahrenheit and Celsius indicator turns on.
22. *Ice machine off icon
Press the FN key (until it reaches the ice icon and
the lower line) to switch off the ice machine. The
ice machine off icon and the ice machine function
indicator start flashing when you Illuminate them,
thus you can understand whether the ice machine
will be turned on or off. When you press the OK
button, the ice machine icon lights continuously
and the Indicator continues to flash during this
process. If you do not press any button after 20
seconds, the icon and the indicator remains on.
Thus, the ice machine is switched off. In order to
switch on the ice machine again, Illuminate the
icon and the indicator; thus, both the ice machine
off icon and the indicator will start flashing. If you
do not press any button within 20 seconds, the
icon and the indicator will go off and thus the ice
machine will be switched on again.
C
Indicates whether the icematic is
on or off.
C
Water flow from water tank
will stop when this function is
selected. However, ice made
previously can be taken from the
icematic.
23. Eco fuzzy function icon
Press the FN key (until it reaches the letter e
icon and the lower line) to activate the eco fuzzy.
When you Illuminate the eco fuzzy icon and the
eco fuzzy function indicator, they start flashing.
Thus, you can understand whether the eco fuzzy
function will be activated or deactivated. When you
press the OK button, the eco fuzzy function icon
lights continuously and the Indicator continues to
flash during this process. If you do not press any
button after 20 seconds, the icon and the indicator
remains on. Thus, the eco fuzzy function is
activated. In order to cancel the eco fuzzy function,
Illuminate the icon and the indicator again and
press the OK key. Thus, both the eco fuzzy function
icon and the indicator will start flashing. If you do
not press any button within 20 seconds, the icon
and the indicator will go off and the eco fuzzy
function will be cancelled.
17 / 37 EN
Refrigerator / User Manual
Operating the product
24. Vacation function icon
Press the FN key (until it reaches the umbrella
icon and the lower line) to activate the vacation
function. When you Illuminate the vacation
function icon and the vacation function indicator,
they start flashing. Thus, you can understand
whether the vacation function will be activated or
deactivated. When you press the OK button, the
vacation function icon lights continuously and thus
the Vacation function is activated. The Indicator
continues to flash during this process. Press the
OK key to cancel the vacation function. Thus, both
the vacation function icon and the indicator will
start flashing and the vacation function will be
cancelled.
25. *Multizone fridge icon
When you select the Multizone fridge icon using
the FN button and press the OK key, the Multizone
cabin turns into a fridge cabin and operates as a
cooler.
26. Celsius indicator
It is a Celsius indicator. When the Celsius indication
is activated, the temperature set values are shown
in Celsius and the relevant icon turns on.
27. Set decreasing function
Select the relevant cabin with the select button;
the cabin icon representing the relevant cabin
will start to flash. If you press the set decreasing
button during this process, the set value gets
decreased. If you keep pressing it in a loop, the set
value returns to the beginning.
28. *Temperature change cabin icon
Indicates the cabin whose temperature is to be
changed. When the temperature change cabin icon
starts flashing, it is understood that the relevant
cabin has been selected.
29. Temperature change cabin icon
Indicates the cabin whose temperature is to be
changed. When the temperature change cabin icon
starts flashing, it is understood that the relevant
cabin has been selected.
30. Key lock
Press key lock button simultaneously for 3 sec-
onds. Key lock symbol
will light up and key lock mode will be activated.
Buttons will not function if the Key lock mode is
active. Press key lock button simultaneously for 3
seconds again. Key lock symbol will turn off and
the key lock mode will be exited.
Press the key lock button if you want to prevent
changing of the temperature setting of the
refrigerator.
31.Select button
Use this button to select the cabin whose tem-
perature you want to change. Switch between
the cabins by pressing this button. The selected
cabin can be understood from the cabin icons
(7,17,18,20,28,29). Whichever cabin icon is flash-
ing, the cabin, whose temperature set value you
want to change, is selected. Then, you can change
the set value by pressing the cabin set value
decreasing button (27) and the cabin set value in-
creasing button (19). If you do not press the select
button for 20 seconds, the cabin icons will go off.
Youneedtopressthiskeytoselectacabinagain.
32. Alarm off warning
In case of power failure/high temperature
alarm, after checking the foods in the freezer
compartment, press the alarm off button to clear
the warning.
33. Quick cooling function button
The button has two functions. To activate or
deactivate the quick cool function, press it briefly.
Quick Cool indicator will turn off and the product
will return to its normal settings.
C
Use quick cooling function when you
want to quickly cool the food placed
in the fridge compartment. If you want
to cool large amounts of fresh food,
activate this function before putting the
food into the product.
18 / 37 EN
Refrigerator / User Manual
Operating the product
C
If you do not cancel it, quick cooling
will cancel itself automatically after 1
hours at the most or when the fridge
compartment reaches to the required
temperature.
C
If you press the quick cooling button
repeatedly with short intervals, the
electronic circuit protection will be
activated and the compressor will not
start up immediately.
C
This function is not recalled when
power restores after a power failure.
34. *1 Multizone temperature indicator
Temperature set values of the Multizone cabin are
displayed.
34. 2 Wine cooler compartment tempature
indicator
Tempature set values of the winecabin are dis-
played.
19 / 37 EN
Refrigerator / User Manual
Operating the product
C
Figures in this user manual are schematic and may not match the product exactly. If the subject parts
are not included in the product you have purchased, then those parts are valid for other models.
5.2 Indicator panel
Touch-control indicator panel allows you to set the temperature and control the other functions related to
the refrigerator. Just press the relevant buttons for function settings.
1-On/Off function
Press the On/Off button for 3 seconds to turn off or
turn on the fridge.
2-Quick Fridge Function
When you press Quick Fridge button, the tempera-
ture of the compartment will be colder than the
adjusted values.
This function can be used for food placed in the
fridge compartment and required to be cooled
down rapidly.
If you want to cool large amounts of fresh food, it
is recommended to active this feature before put-
ting the food into the fridge. Quick Fridge indicator
will remain lit when the Quick Fridge function is
enabled. To cancel this function press Quick Fridge
button again. Quick Fridge indicator will turn off
and return to its normal settings.
If you do not cancel it, Quick Fridge will cancel
itself automatically after 2 hours or when the fridge
compartment reaches to the required temperature.
This function is not recalled when power restores
after a power failure.
3-Vacation Function
Press the Quick Fridge\Vacation button for 3 sec-
onds to activate Vacation function.”--” icon comes
on when the function is active. Function is deac-
tivated by pressing the same button for 3 seconds
again or by pressing Fridge set button.
When vacation mode is activated, set values does
not seem for fresh food cabin. Line is occured on
segments of fresh food.
When vacation mode is activated, tempature of
fresh food is hotter than 50 Fahrenheit degree(
10 celcius degree) so please do not keep foods
in fresh food cabinet. Tempature of freezer is not
affected.
4-Fridge Set Function
This function allows you to make the fridge com-
partment temperature setting. Press this button to
set the temperature of the fridge compartment to
47, 45, 43, 41, 39, 37, 35 or 33° respectively.
5-Off Indicator
Off Indicator lits when the fridge is “Off” mode.
6-Quick Fridge Indicator
This icon lits when the Quick Fridge function is
active.
7-Fridge Compartment Temperature Setting
Indicator
Indicates the temperature set for the Fridge
Compartment.
8-Vacation Indicator
This icon lits when the Vacation function is active.
1
2
3
4 5 6
7
8
9
10
11
12
13
14 15 16
*17
*18
*19*20
20 / 37 EN
Refrigerator / User Manual
Operating the product
9-High Temperature Error / Warning
Indicator
This icon comes on during high temperature fail-
ures and error warnings.
10-Freezer Compartment
Temperature Setting Indicator Indicates the tem-
perature set for the Freezer Compartment.
11-Eco-Extra Indicator
Eco-Extra Indicator lits when the Eco Extra function
is active.
12-Quick Freeze Indicator
This indicator lits when the Quick Freezer function
is active.
13-Freezer Set Function
This function allows you to make the freezer com-
partment temperature setting. Press this button to
set the temperature of the freezer compartment to
0, -2, -4, -6, -8, -10 and -12 respectively.
14-Quick Freeze Function
Quick Freeze indicator turns on when the Quick
Freeze function is on. To cancel this function press
Quick Freeze button again. Quick Freeze indicator
will turn off and return to its normal settings. If
you do not cancel it, Quick Freeze will cancel itself
automatically after 4 hours or when the freezer
compartment reaches to the required temperature.
If you want to freeze large amounts of fresh food,
press the Quick Freeze button before putting the
food into the freezer compartment. If you press
the Quick Freeze button repeatedly with short
intervals, the electronic circuit protection will be
activated immediately.
This function is not recalled when power restores
after a power failure.
15-Eco-Extra (Special Economic Usage)
Function
Press the Quick Freeze\Eco Extra button for
3 seconds to activate the Eco Extra Function.
Refrigerator will start operating in the most
economic mode at least 6 hours later and the
economic usage indicator will turn on when the
function is active. Press the Quick Freeze button
for 3 seconds again to deactivate the Eco Fuzzy
Function.
16-Alarm Off
When the fridge door is opened for 2 minutes or
when there a sensor failure, a sound alarm turns
on. Alarm can be turned off by pressing “Alarm
Off” button.
Sensor failure alarm will not sound till power
failure. If you close the door and then open again
“Door open alarm” will be activated again after 2
minutes later .
17-Filter reset button (*optional)
The filter is reset when the alarm off button is
pressed for 3 seconds. Filter reset icon goes off.
18-Ice machine off button (*optional)
Ice machine active or deactive when freezer set
button is pressed for 3 seconds.
19. Filter reset icon (*optional)
This icon turns on when the filter needs to be
reset.
20-Ice machine off icon (*optional)
This icon lits when the ice machine is deactive, this
icon power off when the ice machine is active.
5.3 Freezing fresh food
• In order to preserve the quality of the food, it
shall be frozen as quickly as possible when it is
placed in the freezer compartment, use the fast
freezing feature for this purpose.
• Youmaystorethefoodlongerinfreezer
compartment when you freeze them while they
are fresh.
• Pack the food to be frozen and close the
packing so that it would not allow entrance of
air.
• Ensure that you pack your food before putting
them in the freezer. Use freezer containers,
foils and moisture-proof papers, plastic
bags and other packing materials instead of
traditional packing papers.
• Label each pack of food by adding the date
beforefreezing.Youmaydistinguishthe
freshness of each food pack in this way when
you open your freezer each time. Store the food
frozen before in the front side of compartment
to ensure that they are used first.
• Frozen food must be used immediately after
they are thawed and they should not be re-
frozen.
21 / 37 EN
Refrigerator / User Manual
Operating the product
• Do not freeze too large quantities of food at
one time.
• “24 hours before freezing the fresh food,
activate “Quick Freeze Function”.
The fresh food packages should be placed in
bottom drawers.
After placing fresh food packages, activate
“Quick Freeze Function” again.
When the freezer cabinet is set to quick
function, joker cabinet is also set to quick
function automatically.
“
Freezer
Compartment
Setting
Fridge
Compartment
Setting
Remarks
-18°C 4°C This is the normal recommended setting.
-20, -22 or
-24°C
4°C
These settings are recommended when the ambient temperature
exceeds 30°C.
Quick Freeze 4°C
Usewhenyouwishtofreezeyourfoodinashorttime.Yourproduct
will return to its previous mode when the process is over.
-18°C or colder 2°C
Use these settings if you think that your fridge compartment is not
cold enough because of the hot ambient conditions or frequent
opening and closing of the door.
5.4 Recommendations for
preserving the frozen food
Compartment shall be set to -18°C at least.
1. Put packages in the freezer as quickly as
possible after purchase without allowing the
to thaw.
2. Check whether the "Use By" and "Best
Before" dates on the packaging are expired or
not before freezing it.
3. Ensure that the package of the food is not
damaged.
22 / 37 EN
Refrigerator / User Manual
Operating the product
5.5 Deep-freeze information
According to IEC 62552 standards, the product
shall freeze at least 4.5 kg of food at 25°C
ambient temperature to -18°C or lower within 24
hours for every 100-litres of freezer volume.
It is possible to preserve the food for a long time
only at -18°C or lower temperatures.
Youcankeepthefreshnessoffoodformany
months (at -18°C or lower temperatures in the
deep freeze).
Foods to be frozen should not be allowed to come
in contact with the previously frozen items to
prevent them from getting thawed partially.
Boil the vegetables and drain their water in order
to store vegetables for a longer time as frozen.
After draining their water, put them in air-proof
packages and place them inside the freezer. Food
such as bananas, tomatoes, lettuce, celery, boiled
eggs, potatoes are not suitable for freezing. When
these foods are frozen, only their nutritional value
and taste shall be affected negatively. They shall
not be spoiled so that they would create a risk for
human health.
5.6 Placing the food
Freezer
compartment
shelves
Various frozen food such
as meat, fish, ice cream,
vegetables and etc.
Refrigerator
compartment
shelves
Food in pans, covered plates
and closed containers, eggs (in
closed container)
Door shelves
of fridge
compartment
Small and packaged food or
beverage
Crisper Vegetables and fruits
Fresh zone
compartment
Delicatessen (breakfast food,
meat products that shall be
consumed in a short time)
5.7 Door open warning
(This feature is optional)
The door open alert system of your refrigerator
may differ depending on the model.
Version 1;
If the door of the product remains open for a
certain time (between 60 s and 120 s), an audio
warning signal sounds; depending on the product
model, a visual warning signal (light flash) can also
be displayed. If you close the door of the device or
press a button on the screen of the device, if any,
the warning sound will stop.
Version 2;
If the door of the device remains open for a certain
period of time (between 60 s and 120 s), the
door open alert is sounded. The door open alert is
sounded gradually. First, an audible warning starts
to sound. After 4 minutes, if the door is still not
closed, a visual warning (lighting flash) is activated.
The door open alert will be delayed for a certain
period of time (between 60 s and 120 s) when any
key on the product screen, if any, is pressed. Then
the process will start again. When the device door
is closed, the door open alert will be cancelled.
5.8 Crisper
Crisper of the refrigerator is designed specially
to keep the vegetables fresh without loosing their
humidity. For this purpose, cool air circulation is
intensified around the crisper in general. Remove
the door shelves that stand against the crisper
before removing the crisper.
5.9 Humidity-controlled crisper
Humidity rates of fruits and vegetables are kept
under control thanks to the humidity-controlled
crisper and thus the food is ensured to stay fresh for
a longer period.
We recommend that you place leafy vegetables such
as lettuce and spinach and vegetables sensitive to
humidity loss as horizontally as possible when put
-
ting them in the crisper; not in a horizontal position
on their roots.
While the vegetables are being replaced, their
specific weights should be taken into consideration.
Heavy and hard vegetables must be placed at the
bottom of the crisper and light and soft vegetables
must be on the upper part.
Never leave the vegetables in their plastic bags in
the crisper. If they are left in their plastic bags, this
will cause them to rot in a little while. If you not
prefer the vegetable to get in contact with other veg
-
etables for hygienic reasons, use perforated paper or
a similar material instead of plastic bags.
23 / 37 EN
Refrigerator / User Manual
Operating the product
Do not place pears, apricots, peaches etc., especially
those fruits that generate large amounts of ethylene,
in the same crisper with other fruits and vegetables.
The ethylene gas emitted by these fruits cause other
fruits to ripen sooner and to rot in a
shorter span of
time.
5.10 Egg tray
Youcaninstalltheeggholdertothedesireddoor
or body shelf.
Never keep the egg holder in the freezer
compartment.
5.11 Movable Middle Section
*May not be available in all models
Movable middle section is intended to prevent
the cold air inside your refrigerator from escaping
outside.
1- Sealing is provided when the gaskets on the
door presses on the surface of the movable middle
section while the fridge compartment doors are
closed.
2- Another reason that your refrigerator is
equipped with a movable middle section is that it
increases the net volume of the fridge compart-
ment. Standard middle sections occupy some
non-usable volume in the refrigerator.
3-Movable middle section is closed when the left
door of the fridge compartment is opened.
4-It must not be opened manually. It moves under
the guidance of the plastic part on the body while
the door is closed.
5.12 Cool Control Storage
Compartment
*May not be available in all models
The Cool Control Storage Compartment of your
refrigerator may be used in any desired mode
by adjusting it to fridge (2/4/6/8 °C) or freezer
(-18/-20/-22/-24)temperatures.Youcankeepthe
compartment at the desired temperature with the
Cool Control Storage Compartment's Temperature
Setting Button. The temperature of the Cool
Control Storage Compartment may be set to 0 and
10 degrees in addition to the fridge compartment
temperatures and to -6 degrees in addition to the
freezer compartment temperatures. 0 degree is used
to store the deli products longer, and -6 degrees is
used to keep the meats up to 2 weeks in an easily
sliceable condition.
The feature of switching to a Fridge or Freezer
compartment is provided by a cooling element
located in the closed section (Compressor
Compartment) behind the refrigerator. During
operation of this element, sounds similar to the
sound of seconds heard from an analogue clock may
be heard. This is normal and is not fault cause.
5.13 Blue light/VitaminCare+
*May not be available in all models
For the blue light,
Fruits and vegetables stored in the crispers that are
illuminated with a blue light continue their photosyn-
thesis by means of the wavelength effect of blue light
and thus preserve their vitamin content.
ForVitaminCare+,
Fruits and vegetables stored in crispers illuminated
with the VitaminCare technology preserve their
vitamins for a longer time thanks to the blue, green,
red lights and dark cycles, which simulate a day
cycle.
If you open the door of the refrigerator during the
dark period of the VitaminCare technology, the
refrigerator will automatically detect this and enable
the blue-green or red light to illuminate the crisper
for your convenience. After you have closed the door
of the refrigerator, the dark period will continue,
representing the night time in a day cycle.
5.14 Odour filter
Odour filter in the air duct of the fridge compartment
prevents build-up of unpleasant odours in the
refrigerator.
24 / 37 EN
Refrigerator / User Manual
Operating the product
5.15 Use of internal water dispenser
and water dispenser at the door
(in some models)
After connecting the refrigerator to a water source
or replacing the water filter, flush the water
system. Use a sturdy container to depress and
hold the water dispenser lever for 5 seconds,
then release it for 5 seconds. Repeat until water
begins to flow. Once water begins to flow, continue
depressing and releasing the dispenser paddle
(5 seconds on, 5 seconds off) until a total of 4
gal. (15L) has been dispensed. This will flush air
from the filter and water dispensing system, and
prepare the water filter for use. Additional flushing
may be required in some households. As air is
cleared from the system, water may spurt out of
the dispenser.
Allow 24 hours for the refrigerator to cool down
and chill water. Dispense enough water every week
to maintain a fresh supply.
C
After 5 minutes of continuous
dispensing, the dispenser will stop
dispensing water to avoid flooding.
To continue dispensing, press the
dispenser paddle again.
5.16 Dispensing water
Hold a container under the dispenser spout while
pressing the dispenser pad.
Release the dispenser pad to stop dispensing.
C
It is normal for the first few glasses of
water taken from the dispenser to be
warm.
C
If the water dispenser is not used for a long
period of time, dispose of first few glasses
of water to obtain fresh water.
During initial use, you will have to wait
approximately 24 hours for the water to cool down.
Take out the glass a little while after you pull the
trigger.
Select
Quick FreezeQuick Cool
FN
OK
3 “
3 “
Select
Quick FreezeQuick Cool
FN
OK
3 “
3 “
Water dispenser at the door (in some models)
Select
Quick FreezeQuick Cool
FN
OK
3 “
3 “
Select
Quick FreezeQuick Cool
FN
OK
3 “
3 “
Built-in water dispenser (in some models)
25 / 37 EN
Refrigerator / User Manual
Operating the product
Built-in water dispenser (in some models)
5.17 For using water dispenser
A
Before using your fridge first time and
after replacing your water filter, water
dispenser may drip drops of water. To
prevent water dripping or leaking from
dispenser, please bleed the air from
the system by dispensing 5-6 gallons
(about 20 liter) of water through the
water dispenser before the first use
and every time after you change
the water filter. This will remove any
air trapped in the system and stop
the water dispenser from leaking.
Checking coupler position and the
straightness of water line at the back
of the unit will be required if there’s an
obstruction in water flow.
C
If your water dispenser is leaking just a few
drops of water after you have dispensed some
water, this is normal.
5.18 Icematic
(in some models)
To get ice from the icematic, fill the water tank
in the fridge compartment with water up to the
maximum level.
Ice cubes in the ice drawer may stick to each
other and become a bulk due to hot and humid
air in approximately 15 days. This is normal. If you
cannot break the bulk apart, you can empty the ice
container and make ice again.
C
It is recommended to change the water
in the water tank if it remains in the
water tank for more then 2-3 weeks.
C
Strange noises you hear from the refrig-
erator at 120-minute intervals are the
sounds of ice-making and pouring. This
is normal.
C
If you do not want to make ice, press the Ice
off icon to stop the icematic to save energy
and prolong the service life of your refrigerator.
C
It is normal that a few drops of water drop
from the dispenser after you have taken water.
26 / 37 EN
Refrigerator / User Manual
Operating the product
5.19 Icematic and ice
storage container
(in some models)
Using the Icematic
Fill the Icematic with water and place it into its
seat.Youricewillbereadyapproximatelyintwo
hours. Do not remove the Icematic from its seating
to take ice.
Turn the knobs on the ice reservoirs clockwise by
90 degrees.
Ice cubes in the reservoirs will fall down into the
ice storage container below.
Youmaytakeouttheicestoragecontainerand
serve the ice cubes.
If you wish, you may keep the ice cubes in the ice
storage container.
Ice storage container
Ice storage container is only intended for
accumulating the ice cubes. Do not put water in it.
Otherwise, it will break.
27 / 37 EN
Refrigerator / User Manual
6 Maintenance and Cleaning
Cleaning the product regularly will prolong its
service life.
B
WARNING: Disconnect the power
before cleaning the refrigerator.
• Do not use sharp and abrasive tools,
soap, house cleaning materials,
detergents, gas, gasoline, varnish and
similar substances for cleaning.
• Melt a teaspoonful of carbonate in
the water. Moisten a piece of cloth
in the water and wring out. Wipe the
device with this cloth and dry off
thoroughly.
• Take care to keep water away from
the lamp’s cover and other electrical
parts.
• Clean the door using a wet cloth.
Remove all items inside to detach
the door and chassis shelves. Lift the
door shelves up to detach. Clean and
dry the shelves, then attach back in
place by sliding from above.
• Do not use chloric water or cleaning
products on the exterior surface and
chrome-coated parts of the product.
Chlorine will cause rust on such
metallic surfaces.
• Do not use sharp, abrasive tools,
soap, household cleaning agents,
detergents, kerosene, fuel oil,
varnish etc. to prevent removal and
deformation of the prints on the
plastic part. Use lukewarm water and
a soft cloth for cleaning and then
wipe it dry.
6.1. Preventing Bad Odour
The product is manufactured free of any
odorous materials. However, keeping the food in
inappropriate sections and improper cleaning of
internal surfaces may lead to malodour.
To avoid this, clean the inside with carbonated
water every 15 days.
• Keep the foods in sealed holders.
Microorganisms may spread out
of unsealed food items and cause
malodour.
• Do not keep expired and spoilt foods
in the refrigerator.
6.2. Protecting Plastic Surfaces
Oil spilled on plastic surfaces may damage the
surface and must be cleaned immediately with
warm water.
28 / 37 EN
Refrigerator / User Manual
7. Troubleshooting
Check this list before contacting the service. Doing so will save you time and money. This list includes
frequent complaints that are not related to faulty workmanship or materials. Certain features mentioned
herein may not apply to your product.
The refrigerator is not working.
• The power plug is not fully settled. >>> Plug it in to settle completely into the socket.
• The fuse connected to the socket powering the product or the main fuse is blown. >>> Check
the fuses.
Condensation on the side wall of the cooler compartment (MULTI ZONE, COOL,
CONTROL and FLEXI ZONE).
• The door is opened too frequently >>> Take care not to open the product’s door too frequently.
• The environment is too humid. >>> Do not install the product in humid environments.
• Foods containing liquids are kept in unsealed holders. >>> Keep the foods containing liquids in
sealed holders.
• The product’s door is left open. >>> Do not keep the product’s door open for long periods.
• The thermostat is set to too low temperature. >>> Set the thermostat to appropriate
temperature.
Compressor is not working.
• In case of sudden power failure or pulling the power plug off and putting back on, the gas
pressure in the product’s cooling system is not balanced, which triggers the compressor
thermic safeguard. The product will restart after approximately 6 minutes. If the product does
not restart after this period, contact the service.
• Defrosting is active. >>> This is normal for a fully-automatic defrosting product. The defrosting
is carried out periodically.
• The product is not plugged in. >>> Make sure the power cord is plugged in.
• The temperature setting is incorrect. >>> Select the appropriate temperature setting.
• The power is out. >>> The product will continue to operate normally once the power is
restored.
The refrigerator's operating noise is increasing while in use.
• The product’s operating performance may vary depending on the ambient temperature
variations. This is normal and not a malfunction.
The refrigerator runs too often or for too long.
29 / 37 EN
Refrigerator / User Manual
Troubleshooting
• The new product may be larger than the previous one. Larger products will run for longer
periods.
• The room temperature may be high. >>> The product will normally run for long periods in
higher room temperature.
• The product may have been recently plugged in or a new food item is placed inside. >>> The
product will take longer to reach the set temperature when recently plugged in or a new food
item is placed inside. This is normal.
• Large quantities of hot food may have been recently placed into the product. >>> Do not place
hot food into the product.
• The doors were opened frequently or kept open for long periods. >>> The warm air moving
inside will cause the product to run longer. Do not open the doors too frequently.
• The freezer or cooler door may be ajar. >>> Check that the doors are fully closed.
• The product may be set to temperature too low. >>> Set the temperature to a higher degree
and wait for the product to reach the adjusted temperature.
• The cooler or freezer door washer may be dirty, worn out, broken or not properly settled. >>>
Clean or replace the washer. Damaged / torn door washer will cause the product to run for
longer periods to preserve the current temperature.
The freezer temperature is very low, but the cooler temperature is adequate.
• The freezer compartment temperature is set to a very low degree. >>> Set the freezer
compartment temperature to a higher degree and check again.
The cooler temperature is very low, but the freezer temperature is adequate.
• The cooler compartment temperature is set to a very low degree. >>> Set the freezer
compartment temperature to a higher degree and check again.
The food items kept in cooler compartment drawers are frozen.
• The cooler compartment temperature is set to a very low degree. >>> Set the freezer
compartment temperature to a higher degree and check again.
The temperature in the cooler or the freezer is too high.
• The cooler compartment temperature is set to a very high degree. >>> Temperature setting
of the cooler compartment has an effect on the temperature in the freezer compartment. Wait
until the temperature of relevant parts reach the sufficient level by changing the temperature of
cooler or freezer compartments.
• The doors were opened frequently or kept open for long periods. >>> Do not open the doors
too frequently.
• The door may be ajar. >>> Fully close the door.
• The product may have been recently plugged in or a new food item is placed inside. >>> This
is normal. The product will take longer to reach the set temperature when recently plugged in
or a new food item is placed inside.
• Large quantities of hot food may have been recently placed into the product. >>> Do not place
hot food into the product.
Shaking or noise.
• The ground is not level or durable. >>> If the product is shaking when moved slowly, adjust
the stands to balance the product. Also make sure the ground is sufficiently durable to bear the
product.
• Any items placed on the product may cause noise. >>> Remove any items placed on the
product.
30 / 37 EN
Refrigerator / User Manual
Troubleshooting
The product is making noise of liquid flowing, spraying etc.
• The product’s operating principles involve liquid and gas flows. >>> This is normal and not a
malfunction.
There is sound of wind blowing coming from the product.
• The product uses a fan for the cooling process. This is normal and not a malfunction.
There is condensation on the product's internal walls.
• Hot or humid weather will increase icing and condensation. This is normal and not a
malfunction.
• The doors were opened frequently or kept open for long periods. >>> Do not open the doors
too frequently; if open, close the door.
• The door may be ajar. >>> Fully close the door.
There is condensation on the product's exterior or between the doors.
• The ambient weather may be humid, this is quite normal in humid weather. >>> The
condensation will dissipate when the humidity is reduced.
The interior smells bad.
• The product is not cleaned regularly. >>> Clean the interior regularly using sponge, warm
water and carbonated water.
• Certain holders and packaging materials may cause odour. >>> Use holders and packaging
materials without free of odour.
• The foods were placed in unsealed holders. >>> Keep the foods in sealed holders. Micro-
organisms may spread out of unsealed food items and cause malodour. Remove any expired or
spoilt foods from the product.
The door is not closing.
• Food packages may be blocking the door. >>> Relocate any items blocking the doors.
• The product is not standing in full upright position on the ground. >>> Adjust the stands to
balance the product.
• The ground is not level or durable. >>> Make sure the ground is level and sufficiently durable
to bear the product.
The vegetable bin is jammed.
• The food items may be in contact with the upper section of the drawer. >>> Reorganize the
food items in the drawer.
If The Surface Of The Product Is Hot.
• High temperatures may be observed between the two doors, on the side panels and at the rear
grill while the product is operating. This is normal and does not require service maintenance!Be
careful when touching these areas.
A
WARNING:
If the problem persists after following the instructions in this section, contact your
vendor or an Authorised Service. Do not try to repair the product.
DISCLAIMER / WARNING
Some (simple) failures can be adequately
handled by the end-user without any safety
issue or unsafe use arising, provided that
they are carried out within the limits and in
accordance with the following instructions
(see the “Self-Repair” section).
Therefore, unless otherwise authorized
in the “Self-Repair” section below,
repairs shall be addressed to registered
professional repairers in order to avoid
safety issues. A registered professional
repairer is a professional repairer that has
been granted access to the instructions
and spare parts list of this product by the
manufacturer according to the methods
described in legislative acts pursuant to
Directive 2009/125/EC.
However, only the service agent (i.e.
authorized professional repairers)
that you can reach through the phone
number given in the user manual/
warranty card or through your
authorized dealer may provide service
under the guarantee terms. Therefore,
please be advised that repairs by
professional repairers (who are not
authorized by Blomberg) shall void the
guarantee.
Self-Repair
Self-repair can be done by the end-user
with regard to the following spare parts:
door handles,door hinges, trays, baskets
and door gaskets (an updated list is also
available in support.blombergappliances.
com as of 1st March 2021).
Moreover, to ensure product safety and to
prevent risk of serious injury, the mentioned
self-repair shall be done following the
instructions in the user manual for self-
repair or which are available in support.
blombergappliances.com. For your safety,
unplug the product before attempting any self-
repair.
Repair and repair attempts by end-users
for parts not included in such list and/or not
following the instructions in the user manuals
for self-repair or which are available in
support.blombergappliances.com, might
give raise to safety issues not attributable to
Blomberg, and will void the warranty of the
product.
Therefore, it is highly recommended that
end-users refrain from the attempt to carry
out repairs falling outside the mentioned
list of spare parts, contacting in such cases
authorized professional repairers or registered
professional repairers. On the contrary,
such attempts by end-users may cause
safety issues and damage the product and
subsequently cause fire, flood, electrocution
and serious personal injury to occur.
By way of example, but not limited to, the
following repairs must be addressed to
authorized professional repairers or registered
professional repairers: compressor, cooling
circuit, main board,inverter board, display
board, etc.
The manufacturer/seller cannot be held liable
in any case where end-users do not comply
with the above.
The spare part availability of the refrigerator
that you purchased is 10 years.
During this period, original spare parts will be
available to operate the refrigerator properly
The minimum duration of guarantee of the
refrigerator that you purchased is 36 months.
This product is equipped with a lighting
source of the "G" energy class.
The lighting source in this product shall
only be replaced by professional repairers.
32 / 37 EN
Refrigerator / User Manual
BLOMBERG UK AND IRELAND STANDARD MANUFACTURER GUARANTEE TERMS AND
CONDITIONS
YournewBlombergproductisguaranteedagainstfaultymaterials,defectivecomponentsor
manufacturing defects.
The standard guarantee starts from the date of original purchase of the product, and lasts for
a period of thirty six (36) months unless Beko plc (the “Manufacturer”) agrees to extend the
guarantee for the product in writing.
If you have any questions about the guarantee on your product (including how long it is valid), please
contact your retailer or our contact centre on 0333 207 9870 (UK and Northern Ireland) or 01 691
0160 (Republic of Ireland)
This guarantee does not in any way diminish or affect your statutory rights in connection with the
product. This guarantee is in addition to your statutory rights as a consumer. If you have any questions
about these rights, please contact the retailer from which you purchased the product. In certain
circumstances, it is possible that your statutory rights may offer additional or higher levels of protection
than those offered under the terms of this guarantee.
What is covered by this guarantee?
• Repairs to the product required as a result of faulty materials, defective components or manufacturing
defects.
• Functional replacement parts to repair a product.
• The costs of a Blomberg Approved Engineer to carry out the repair.
What is not covered?
• Transit and delivery damage.
• Cabinet or appearance parts, including but not limited to control knobs, flaps and handles.
• Accessories and/or consumable items including but not limited to ice trays, scrapers, cutlery baskets,
filters and light bulbs.
• Repairs necessary as a direct or indirect result of:
Accidental damage, misuse or abuse of a product.
An attempted repair of a product by anyone other than a Blomberg Approved Engineer (the
“Engineer”).
Installation or use of a product where such installation or use fails to meet the requirements
contained in this guarantee or the User Instructions Booklet.
• Repairs to a product operated at any time on commercial or non-residential household premises (unless
we have previously agreed to the installation environment).
This guarantee is limited to the cost of repairing the product. To the extent permitted by law, the
Manufacturer does not accept and will not be held liable for any financial loss incurred in connection
with the failure of any product to operate in accordance with the expected standards. Such financial loss
includes but is not limited to loss arising from:
• Time taken off work.
33 / 37 EN
Refrigerator / User Manual
• Damaged food, clothing or other items.
• Meals taken at restaurants or from takeaways.
• General compensation for inconvenience.
Important Notes
1.
Yourproductisdesignedandbuiltfordomestichouseholduseonly.
2.
The guarantee will automatically be void if the product is installed or is used in commercial or non-
residential domestic household premises, unless we have previously agreed to the installation environment.
3.
The product must be correctly installed, located and operated in accordance with the instructions contained in
the User Instructions Booklet provided with your product.
4.
Professional installation by a qualified Electrical Domestic Appliance Installer is recommended for all Washing
Machines, Dishwashers and Electric Cookers (as incorrect installation may result in you having to pay for the cost
of repairing the product).
5.
Gas Cookers must be professionally installed by a Gas Safe (or Gas Networks Ireland for Republic of Ireland)
registered gas installer.
6.
This guarantee is given in respect of products purchased and used within the United Kingdom and the Republic
of Ireland.
7.
This guarantee is effective from the initial date of purchase of a new product from an authorised
retailer and will be void if the product is resold.
8.
This guarantee does not apply to graded sales (where the product is purchased as a “second”).
9.
Possession of a copy of these terms and conditions does not necessarily mean that a product has the
benefit of this guarantee. If you have any questions, please call our Call Centre on the number set out above.
10.
The Manufacturer reserves the right to terminate the guarantee if its staff or representatives are
subjected to physical or verbal abuse in the course of carrying out their duties.
11.
Optional extras, where available (i.e. extendable feet) are supplied on a chargeable basis only.
Does Blomberg offer replacements?
This is a repair-only guarantee. On occasion, the Manufacturer may at its sole discretion, replace your
product with a new product instead of carrying out a repair. Where a replacement is offered, this would
normally be an identical model but when this is not possible, a model of similar specification will be
provided. The Manufacturer will cover the costs and arrange for the delivery of the new product and for
the return of the old product. Any costs related to disconnecting the faulty product and installing the
replacement product will not be borne by the Manufacturer unless previously agreed to in writing. The
original guarantee will continue to apply to the replacement product; the new product will not come with
a new guarantee.
When will the repair take place?
Our Engineers work Monday to Friday 9.00am to 5.00pm. Appointments outside these hours may be
possible at the sole discretion of the Manufacturer but cannot be guaranteed. Whilst our Engineers will
endeavour to minimize inconvenience and to meet requests for specific timed appointments, this cannot
be guaranteed. We will not be liable for delays or if it is unable to carry out a repair because a convenient
appointment cannot be arranged.
34 / 37 EN
Refrigerator / User Manual
Will there be any charge for the repairs?
It is your responsibility to provide evidence to the Engineer that your product is covered by this guarantee
with a proof of purchase. The Manufacturer reserves the right to charge for the reasonable cost of any
service call if:
• Youcannotprovideevidencethatyourproductiscoveredbythisguarantee.
• Where a service call has been made and the engineer finds that there is no fault with your product.
• That your product has not been installed or operated in accordance with the User Instructions Booklet.
• That the fault was caused by something other than faulty materials, defective components or
manufacturing defects.
• For missed appointments.
Payment of these costs are due immediately upon the Engineer providing you with an invoice. The
Manufacturer reserves the right to terminate the guarantee if you fail to pay the costs for the service call
in a timely manner.
If you are a resident of the United Kingdom, this guarantee will be governed by English law and subject to
the English Courts, save where you live in another part of the United Kingdom, in which case the law and
courts of that location will apply.
If you are resident in the Republic of Ireland, this guarantee will be governed by Irish law and the Irish
courts will have jurisdiction.
This guarantee is provided by Beko plc. Beko House, 1 Greenhill Crescent, Watford, Hertfordshire. WD18
8QU.
Beko plc is registered in England and Wales with company registration number 02415578.
All Blomberg appliances come with a 3 year parts and labour guarantee as standard. When you register
your appliance for the Optima Inverter Motor 10 year guarantee, you are also registering your appliance
for the standard 3 year parts and labour guarantee.
Blomberg built-in or integrated products purchased from Euronics agents come with a 3 year parts and
labour guarantee which is extended to 5 years, free of charge, upon registration of the appliance. When
you register your appliance for this additional 2 years, you will automatically activate the Optima Inverter
Motor10yearguarantee.Youdonotneedtoregistertwice.TomakeaclaimagainstyourBlomberg
Optima Inverter Motor Guarantee (the “Guarantee”), all customer and product details must be registered
with Beko plc using the procedure outlined below.
1. This extra 7 years or 5 years (for built-in appliances from Euronics agents) Guarantee is only
effective after the expiration of the standard manufacturer’s guarantee.
2. It is only valid for the Optima Inverter motors of selected washing machines, washer-dryers,
tumble dryers and dishwashers. It does not cover any labour charge or any other components of the
product. In addition, it is only valid for one replacement of the Optima motor during the extra 9-year (for
free standing appliances) or 8 year (for built-in appliances) guarantee period.
3. To activate your guarantee, you MUST register your appliance within 90 days of the original
purchase date, by visiting blomberguk.com/register.
35 / 37 EN
Refrigerator / User Manual
4. Customers will receive a unique reference code as proof of guarantee validation by email or post,
which must be quoted at the time of a claim being made.
5. Any repair/replacement of the Optima Inverter motor must only be carried out by an authorised
Blomberg Service Agent (the “Service Agent”).
6. Labour for the repair/replacement of the Optima Inverter motor is not included in this guarantee
and is chargeable directly by the Service Agent
7. Any additional components fitted to the product at any time will not be covered by this guarantee
and will be chargeable directly by the Service Agent.
8. The guarantee is not transferable and cannot be exchanged for cash.
9. There are no alternative or additional offers to this Guarantee.
10. The guarantee is exclusive of the manufacturer’s standard guarantee
11. The Terms and Conditions shown above are in addition to the standard terms and conditions of
your product guarantee. Please read and refer to such Terms and Conditions when making any claim.
12. We may use the information you provide for marketing purposes and to analyse your purchasing
preferences. We may keep your information for a reasonable period for these purposes in accordance
withtheapplicableDataProtectionLawsandGeneralDataProtectionRegulations(GDPR).Youcanopt
into this service during the registration process. Further details are available at http://www.blomberguk.
com/cookie-and-privacy.
13. These Terms and Conditions are governed by the laws of England and Wales; manufacturer: Beko
plc, Beko House, 1 Greenhill Crescent, Watford WD18 8QU. Company Registration Number: 02415578.
HOW TO OBTAIN SERVICE FOR YOUR APPLIANCE
Please keep your purchase receipt or other proof of purchase details in a safe place; you will need to
have this documentation available should the product require attention under guarantee.
Please take a few moments to complete the details below, as you will need this information when you call
us, or to use our online services. When you call us you may be required to input your serial number into
your telephone keypad. For help please visit Blomberguk.com/support/model-finder
• The product model number is printed on the Operating Instruction Booklet / User guide
• The product model and serial number is printed on the Rating Label affixed to the appliance.
• The Retailer (Purchased from) and Date of purchase will be printed on your purchase receipt or other
proof of purchase paperwork
Recording of these details alone will not count as proof of purchase. A valid proof of purchase is required
for requesting service under guarantee.
36 / 37 EN
Refrigerator / User Manual
Model number Serial number Purchased from Date of purchase
For service under guarantee or for product advice please call our Contact centre
Before requesting service please check the troubleshooting guide in the Operating Instructions booklet,
as a charge may be levied where no fault is found, and even though your product may still be under
guarantee.
After arranging service the area around the product must be easily accessible to the Engineer, without the
need for cabinets or furniture to be removed or moved.
It is your responsibility to ensure our Engineers have a clean and safe environment to carry out any
repairs.
Please have your Model number and Serial number available when you call us, as you may be required to
input your serial number into your telephone keypad during your call.
UK Mainland & Northern Ireland:
0333 207 9870
Landline or mobile calls to 0333 numbers cost no more than calls to geographic numbers 01 or 02, and
are charged at the basic rate. Calls from landlines and mobiles are included in free call packages but
please check with your telephone service provider for exact call charges.
Republic of Ireland:
01 691 0160
37 / 37 EN
Refrigerator / User Manual
Service once the manufacturers guarantee has expired
If you have purchased an extended guarantee please refer to the instructions contained within the
extended guarantee agreement document, otherwise please call us using the appropriate number above,
where service can be obtained at a charge.
Should you experience any difficulty in obtaining service please call us on
0333 207 9870 or 01 691 0160
Contact us though our website
Send us a secure message through our online contact us form. Please visit our website, click Contact Us
and choose a product support topic from the list of options. Complete the required details and click send
message.
Product registrations
For UK and Republic of Ireland product registrations please visit blomberguk.com/register
