CIR515A Bluetooth Contact Smart Card Reader User Manual
Page 1 of 2
Version 1.00
April 2026
CIR515A Bluetooth Contact Smart Card Reader User Manual
Driver installation Procedure
The driver package is already signed by Microsoft so that the user can install the driver
directly via Windows Update. Otherwise, please follow the steps below to do manual
installation.
Hardware requirement(s):
• 1 x CIR515A
• 1 x PC with OS Windows 7 or above
Software requirement(s):
• 1 x CIR515 Driver Package
Steps:
1. Connect CIR515 to PC
2. On PC, open “Control Panel > System”
3. Open “Device Manager”
4. Select and open “Smart card readers”
if “Microsoft Usbccid ... (WUDF)” is shown, continue with step 5
if “CIR515 ICC” are shown, it means driver installation is completed
5. Right click on the “Microsoft Usbccid ... (WUDF)” and select “Update driver”
6. Select “Browse my computer for drivers…”
7. Select “Let me pick from a list …”
8. Select “Browse…”
9. Select “CIR515.inf”
10. Follow the steps on the screen to complete the driver installation
11. Then the device is ready to use
Warning:
• Any Changes expressly or modifications not approved by the party responsible for compliance could
void the user's authority to operate the equipment.
• Do not use a power supply with more than 5VDC 500mA to power this product.
• Max Operating Temp: 40 °C
FCC compliance statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC exposure
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
CIR515A Bluetooth Contact Smart Card Reader User Manual
Page 2 of 2
Version 1.00
April 2026
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Bluetooth Profile:
The CIR515A is a smart card reader that uses Bluetooth as its communication interface.
It implements a customized Smart Card Service, which includes a Primary Service for
smart‑card operations, an RX characteristic for receiving requests, and a TX
characteristic for sending responses or notifications.
Service
UUID
Description
Smart Card
6e400001-b5a3-f393-e0a9-
e50e24dcca9e
Smart Card Service
6e400002-b5a3-f393-e0a9-
e50e24dcca9e
RX characteristic –
Request
6e400003-b5a3-f393-e0a9-
e50e24dcca9e
TX characteristic –
Response / Notification
Generic Access (GAP)
0x2A00
Device Name
0x2A01
Appearance
0x2A04
Peripheral Preferred Connection
Parameters
0x2AA6
Central Address Resolution
Tx Power (TPS)
0x2A07
Tx Power Level
Device Information (DIS)
0x2A29
Manufacturer Name
0x2A25
Serial Number
0x2A26
Firmware Revision
