ALUMINIUM EXTRUSION LINEAR RAIL
USER MANUAL
MODEL:2020-120-4 / 2020-100-10 / 2020-120-10 / 2020-150-10 / 2020-200-10 / 4040-60-4
/ 4040-100-4 / 2040-100-4 / 2040-100-5 / 2040-120-5 / 2040-150-5 / 2040-200-5
(The picture is for reference only, please refer to the actual object)
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the
major top brands and does not necessarily mean to cover all categories of tools offered
by us. You are kindly reminded to verify carefully when you are placing an order with us
if you are actually saving half in comparison with the top major brands.
This is the original instruction, please read all manual instructions carefully before
operating. VEVOR reserves a clear interpretation of our user manual. The appearance
of the product shall be subject to the product you received. Please forgive us that we
won't inform you again if there are any technology or software updates on our product.
Warning-To reduce the risk of injury, user must read instructions
manual carefully.
Product Model
2020-120-4
2020-100-10
2020-120-10
2020-150-10
2020-200-10
Product
Specifications
2020
2020
2020
2020
2020
Product
Length
1200mm
1000mm
1200mm
1500mm
2000mm
Number of
Products
4pcs
10pcs
10pcs
10pcs
10pcs
Center Hole
Size
Φ5
Φ5
Φ5
Φ5
Φ5
Net Weight of
the Product
2.15kg
4.5kg
5.36kg
6.7kg
9.0kg
Product
Dimensions
1200*20*20
mm
1000*20*20
mm
1200*20*20
mm
1500*20*20
mm
2000*20*20
mm
Product
Accessories
1.Screw*9PCS
2.Nut * 9PCS
3.Connection
Code *4PCS
1.Screw*21PCS
2.Nut * 21PCS
3.Connection
Code*10PCS
1.Screw*21PCS
2.Nut * 21PCS
3.Connection
Code*10PCS
1.Screw*21PCS
2.Nut * 21PCS
3.Connection
Code*10PCS
1.Screw*21PCS
2.Nut * 21PCS
3.Connection
Code*10PCS
Product
Drawings
Product Model
2040-100-4
2040-100-5
2040-120-5
2040-150-5
2040-200-5
Product
Specifications
2040
2040
2040
2040
2040
Product Length
1000mm
1000mm
1200mm
1500mm
2000mm
Number of
Products
4pcs
5pcs
5pcs
5pcs
5pcs
Center Hole Size
Φ4.2
Φ4.2
Φ4.2
Φ4.2
Φ4.2
Net Weight of
the Product
3.15kg
3.95kg
4.73kg
5.92kg
7.73kg
Product
Dimensions
1200*20*4
0mm
1200*20*40
mm
1200*20*40
mm
1200*20*40
mm
1200*20*40
mm
Product
Accessories
/
/
/
/
/
Product
Drawings
This product is subject to the provision of European Directive
2012/19/EC. The symbol showing a wheelie bin crossed through
indicates that the product requires separate refuse collection in the
European Union. This applies to the product and all accessories
marked with this symbol. Products marked as such may not be
discarded with normal domestic waste, but must be taken to a
collection point for recycling electrical and electronic devices
Product Model
4040-60-4
4040-100-4
Product Drawings
Product
Specifications
4040
4040
Product
Length
600mm
1000mm
Number of
Products
4pcs
4pcs
Center Hole
Size
Φ6.8
Φ6.8
Net Weight of
the Product
2.15kg
4.5kg
Product
Dimensions
600*40*40
mm
1000*40*40
mm
Product
Accessories
/
/
Manufacturer: Shanghaimuxinmuyeyouxiangongsi
Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu,
shanghai 200000 CN.
Imported to AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD NSW
2122 Australia
Imported to USA: Sanven Technology Ltd., Suite 250, 9166 Anaheim Place,
Rancho Cucamonga, CA 91730
REP
EC
E-CrossStu GmbH
Mainzer Landstr.69, 60329 Frankfurt am Main.
REP
UK
YH CONSULTING LIMITED.
C/O YH Consulting Limited Office 147, Centurion House,
London Road, Staines-upon-Thames, Surrey, TW18 4AX
Technique Certificat d'assistance et de garantie électronique
www.vevor.com/support
RAIL LINÉAIRE EN EXTRUSION D'ALUMINIUM
