BRIOBITE
lce Cream Maker
User Manual
Model:BL500
·Return the product to the authorized service facility for
2
BL500 Rechargeable Ice Cream Maker Instructions
Please read the instructions carefully before using
SAFETY CAUTIONS
.This product contains lithium batteries.To avoid potential
damage to the battery core or other dangers,do not dismantle
the product by yourself.
Do not squeeze this product,or put it into water,fire or expose
it to an environment with a temperature higher than 140.0F
(60℃).
Make sure to use an adapter with a voltage of DC5V 2A to
charge the product.
maintenance.Do not dismantle by yourself to avoid unnecessary
·This is not a toy.Children can only use it under adult
supervision.
·Only use this product on a stable and flat surface.
Do not immerse the motor in water.Wipes it with a damp cloth
·To avoid battery damage,please charge the product every three
months if the product is stored without being used for a long
time.
for cleaning.
injury.
3
PARTS
② 20MIN Button
④Motor
⑥Transparent Lid
⑧Freezer Bowl Container-
① Type-C Charging Port
③ 30MIN Button
⑤Mixing Paddle
⑦Freezer Bowl
-⑨Charging Cable
Indicators
20 minutes mode
White indicator continuously on.Red indicator flashes
every 5 seconds while charging in a running state.
30 minutes mode
Orange indicator continuously on.Red indicator flashes
every5 seconds while chargingin a running state.
Charging mode
Red indicator slowly flashes.
Fully charge when blue indicator iscontinuously on.
Low power
Red indicator slowly flashes.
Fully charge when blue indicator is continuously on.
TIPS BEFORE USE
4
·Before placing the freezer bowl into the refrigerator,make sure to
wipe the bowl dry from inside out.
·Charge the motor with a suitable power adapter [with a voltage of
DC5V 2A.The light turns red and flashes every 5 seconds
when charging,and turns blue when fully charged.It takes about 3
hours to fully charged.Motor can be used 3 times per charge.
·Always make sure the freezer bowl is not stored upside down or tilted
in the refrigerator (Note:the motor cannot be put in the refrigerator).
·Freezer bowl should be stored in a freezer compartment at -
0.4°F [-18℃] (mechanical refrigerators should be set to the
lowest
temperaturesetting]to ensure ideal freezing effect.
·The freezing time must be more than 12 hours,less than 12 hours
may result in poor results or unsuccessful making of ice cream.
·Prepare the ice cream ingredient strictly according to the recipes to
less than 300ML.
·The ingredients must be prepared before production,chop &mix the
ingredients with a blender or other tools.
·After Pouring the ingredients into the freezing bowl.Turn on power to
start blending immediately to prevent the ingredients from freezing
and avoid the peddle from being stuck.
·Do not use sharp tableware and metal spoon to take the ice cream out
of the freezer bowl to avoid damage on the freezer bowl.A rubber
spatula or a wooden spoon is recommended.
· Wash the freezer bowl with water or diluted kitchen cleaner,rinse
and clean it,then wipe it with a dry cloth.Do not use liquids with a
temperature higher than 140.0°F [60℃]for cleaning,all parts are not
suitable for dishwashers or disinfection cabinet
ensure a good taste,the total amount of ingredient used should be
USER GUIDE
5
Step 1
1.Freeze the bowl in freezer compartment at-0.4°F[-18℃]for
more than 12 hours before using.
2.The freezing bowl can be kept in the refrigerator all the time,you can
always take it out and use it as long as it is stored for more than 12
hours.
3.Prepare your ingredients,and you can place the prepared ice-cream
mixture in the refrigerator for an hour for a harder ice cream texture.
(Note:Mix all ingredients before pour it into the freezing bowl)
4.Ice cream ingredients used should not exceed 300ml at a time.
-0.4°F(-18℃)
USER GUIDE
6
Step 2
1.Install the mixing paddle and motor as below
2.Long Press[1.5s]any button to switch on the motor.check and make
sure the mixing paddle rotates normally and the motor is in a normal
power state.
USER GUIDE
7
Step 3
1.Take the freezer bowl out of the fridge,fit it into the freezer bowl
container and install the transparent lid.
2.Pour the ingredients into the freezer bowl,the amount ingredient
must not exceed the MAX line,then immediately load the motor into
the bowland start mixing to avoid the ingredients from freezing and
stick to the wall of the bowl.
3.You can select the 20 minutes or 30 minutes mode according to the
ambient temperature and your prefer ice cream taste &texture.
4.After stirring,immediately pour out the ice cream to avoid freezing
at the bottom of the ice bucket.The ice cream can be eaten right
away,if you want a harder icecream texture you can put it in the
fridge for an hour before serving.
Note:Do not stop or restart the machine during the operating,as the
Ice cream mixture may freeze and stick to the sidewall of the bowl
and stop the paddle from blending.It is normal for the mixing paddle
to separate from the motor when motor is pulled out.
CLEANING
8
Freezer bowl
1.Wait until the Freezer bowl reaches room temperature before
cleaning.
2.Do not wash in a dishwasher.
3.Do not use scouring powder,steel wool pads or rough materials to
clean the freezer bowl.
4.Dry thoroughly after cleaning.
Mixing Paddle
1.Pull out the mixing Paddle from the motor,clean and dry it
Motor
1.Wipe with a clean damp cloth and then dry it thoroughly.
Transparent cover
1.Clean and dry thoroughly.
thoroughly.
WHY ICE CREAM MAKING FAILED
9
Make sure that the refrigerator temperature is -0.4°F[-18℃]or
less.(For refrigerator with mechanical temperature control
switches,need to set the refrigerator to the lowest temperature
setting.]
·Try to freeze the bowl for a longer period of time,say 24 hours.
·Freezer bowl should not be placed upside down or tilted,and should
be placed in the innermost part of the refrigerator to reduce the
impact of the refrigerator door being opened frequently.
Recipe or ingredients problems
·Ice cream recipes have strict requirements on the amount of water,
sugar and fat content used.Sugar and fat lower the freezing point,
and if there is too much of them,they do not condense easily,thus,
resulting in the ice cream being too soft.On the contrary,if not
enough sugar and fat,the ice cream will be less creamy.
·Egg yolk is a natural emulsifier,it improves the stability of an ice
cream
·You can strictly adhere to our recipe which has been tried and tested
many times.Or you can keep experimenting according to your own
preferences and eventually make your favorite combination,the
process of exploration is the most fun.
I
．
nadequate freezing of Freezer bowl
WARRANT
10
Y
1-Year Warranty
The original purchaser for this unit is provided with a 1-YEAR Warranty.The warranty period begins
from the date of purchase.For the first year,warranty is provided for both components and repair
services.After the first year,the Limited Lifetime Warranty covers parts only,and does not cover
labor fees and Accessories.Accessories such as straps and batteries are covered for the first year
only.All shipping fees incurred,the cost of accessories after the first year,and labor fees
associated with out of warranty repair work are the customers responsibility.
Not Covered Under Warranty
We DO NOT offer warranty for products that have been bought secondhand or were resold.Issues
of replacement and refunds on units purchased less than 30 days from an authorized dealer must
be addressed to the dealer directly.If the products purchased from an authorized dealer are after
30 days from the date of purchase,please send the units to us for service and repair
We DO NOT cover the cost of repairs and replacements due to misuse by the owner,improper
maintenance,and/or lost units.The warranty isvoid if the unit has been altered or an unauthorized
person has damaged the unit while attempting repairwork.
Procedure for Repair Work
A copy of the sales receipt showing the purchase date may be required before warranty work is
initiated.Please include a brief explanation outlining the problem,and include your name,
address,city/state/zip code,daytime phone number,evening phone number,and email address.
SHENZHEN JINGYI TECHNOLOGY CO.,LTD.
Rm 411-413,Jinhongfeng Bldg,Area 71,Xingdong Community,Xin'an St,Baoan,Shenzhen
1 Year Warranty
