EG10.30 Rev. 11/23
Catalog Specification Sheet No.
EG10.30
Spec-Master
®
Enclosed Worktables with Flat Top
Item No.:
Project No.:
S.I.S. No.:
Specification Sheet
Spec-Master
®
Enclosed
Worktables with Flat Top
MODELS:
Options / Accessories
CB2436SE
CB2448SE
CB2460SE
CB2472SE
CB2484SE
CB2496SE
CB24120SE
CB3036SE
CB3048SE
CB3060SE
CB3072SE
CB3084SE
CB3096SE
CB30120SE
OB2436SE
OB2448SE
OB2460SE
OB2472SE
OB2484SE
OB2496SE
OB24120SE
OB3036SE
OB3048SE
OB3060SE
OB3072SE
OB3084SE
OB3096SE
OB30120SE
CBH2436SE
CBH2448SE
CBH2460SE
CBH2472SE
CBH2484SE
CBH2496SE
CBH24120SE
CBH3036SE
CBH3048SE
CBH3060SE
CBH3072SE
CBH3084SE
CBH3096SE
CBH30120SE
Design and Construction Features
• All-welded design.
• Available with open front, sliding doors, or hinged doors.
• Doors are 20 gauge type 430 stainless steel.
• Top mechanically polished to satin finish.
• Sound-deadened between top and frame.
• 1
5
⁄8˝ (42mm)-diameter type 304 stainless legs.
• 1˝ (25mm) stainless steel adjustable bullet feet.
• 1
1
⁄2˝ (38mm) sanitary rolled rim on front and back with
square edge on ends for flush fit.
• Optional fixed center shelf available. To order, add suffix
“-CS” to model number. Example: OB2436SE-CS
Lock (for units with doors)
Casters*
Overshelf
Center shelf
Sound deadening
* To order table with 4˝ (102mm)-diameter casters, add suffix “-CA”
(ex: OB3048SE-CA). To order table with 5˝ (127mm)-diameter casters,
add suffix “-CAH” (ex: CB3048SE-CAH).
Short Form Specifications
Eagle Spec-Master
®
Enclosed Base Worktable, model
________________. Top is 14/304 stainless steel, sides and
back are heavy gauge stainless steel. (Open Front, Stainless
steel Sliding Doors, or Stainless steel Hinged Door) models with
1
1
⁄2˝ rolled edge on front and rear, sides turned down.
Constructed with uni-lok
®
patented gusset system, with the
gussets recessed into the hat channels to reduce lateral
movement. 1
5
⁄8˝ O.D. stainless steel tubular legs with adjustable
bullet feet.
Patented uni-lok
®
System
(Patent No. 5,165,349)
enclosed worktable
with sliding doors
Certifications / Approvals
For custom configuration or fabrication needs, contact our SpecFAB
®
Division.
Phone: 302-653-3000 • Fax: 302-653-2065 • e-mail: [email protected]
Eagle Foodservice Equipment, Eagle MHC, and SpecFAB
®
are divisions of Eagle Group. ©2023 by the Eagle Group
Spec sheets available for viewing, printing or downloading from our online literature library at our websites
EAGLE GROUP
100 Industrial Boulevard, Clayton, DE 19938-8903 USA
Phone: 302-653-3000 • 800-441-8440 • Fax: 302-653-2065
www.eaglegrp.com
www.eaglemhc.com
EAGLE GROUP
100 Industrial Boulevard, Clayton, DE 19938-8903 USA
Phone: 302-653-3000 or 800-441-8440 • Fax: 302-653-2065
www.eaglegrp.com • www.eaglemhc.com
Spec sheets available for viewing, printing or downloading from our online literature library at our websites
Although every attempt has been made to ensure the accuracy of the information provided, we cannot be held responsible for
typographical or printing errors. Information and specifications are subject to change without notice. Please confirm at time of order.
Rev. 11/23
Printed in U.S.A.
©2023 by Eagle Group
Catalog Specification Sheet No.
EG10.30
Spec-Master
®
Enclosed Worktables with Flat Top
Item No.:
Project No.:
S.I.S. No.:
Spec-Master
®
Enclosed Worktables with Hinged Doors
Spec-Master
®
Enclosed Worktables with Open Front
Spec-Master
®
Enclosed Worktables with Sliding Doors
width length weight no. of
model # in. mm in. mm lbs. kg legs
CBH2436SE 24˝ 610 36˝ 914 197 89.4 4
CBH2448SE 24˝ 610 48˝ 1219 263 119.3 4
CBH2460SE 24˝ 610 60˝ 1524 328 148.8 4
CBH2472SE 24˝ 610 72˝ 1829 394 178.7 4
CBH2484SE* 24˝ 610 84˝ 2134 459 208.2 6
CBH2496SE* 24˝ 610 96˝ 2438 525 238.1 6
CBH24120SE* 24˝ 610 120˝ 3048 656 297.6 6
CBH3036SE 30˝ 762 36˝ 914 207 93.9 4
CBH3048SE 30˝ 762 48˝ 1219 276 125.2 4
CBH3060SE 30˝ 762 60˝ 1524 344 156.0 4
CBH3072SE 30˝ 762 72˝ 1829 413 187.3 4
CBH3084SE* 30˝ 762 84˝ 2134 482 218.6 6
CBH3096SE* 30˝ 762 96˝ 2438 551 249.9 6
CBH30120SE* 30˝ 762 120˝ 3048 689 313.5 6
* Note: Worktables 84˝ (2134mm) and longer have two sets of doors.
FRONT VIEW
FRONT VIEW
SIDE VIEW
SIDE VIEW
FRONT VIEW
SIDE VIEW
width length weight no. of
model # in. mm in. mm lbs. kg legs
CB2436SE 24˝ 610 36˝ 914 186 84.4 4
CB2448SE 24˝ 610 48˝ 1219 249 113.0 4
CB2460SE 24˝ 610 60˝ 1524 311 141.1 4
CB2472SE 24˝ 610 72˝ 1829 369 167.4 4
CB2484SE* 24˝ 610 84˝ 2134 435 197.3 6
CB2496SE* 24˝ 610 96˝ 2438 497 225.4 6
CB24120SE* 24˝ 610 120˝ 3048 621 281.7 6
CB3036SE 30˝ 762 36˝ 914 202 91.6 4
CB3048SE 30˝ 762 48˝ 1219 270 122.5 4
CB3060SE 30˝ 762 60˝ 1524 336 152.4 4
CB3072SE 30˝ 762 72˝ 1829 404 183.3 4
CB3084SE* 30˝ 762 84˝ 2134 471 213.7 6
CB3096SE* 30˝ 762 96˝ 2438 539 244.5 6
CB30120SE* 30˝ 762 120˝ 3048 672 304.8 6
* Note: Worktables 84˝ (2134mm) and longer have two sets of doors.
width length weight no. of
model # in. mm in. mm lbs. kg legs
OB2436SE 24˝ 610 36˝ 914 179 81.2 4
OB2448SE 24˝ 610 48˝ 1219 238 108.0 4
OB2460SE 24˝ 610 60˝ 1524 298 135.2 4
OB2472SE 24˝ 610 72˝ 1829 357 161.9 4
OB2484SE 24˝ 610 84˝ 2134 417 189.2 6
OB2496SE 24˝ 610 96˝ 2438 476 215.9 6
OB24120SE 24˝ 610 120˝ 3048 595 269.9 6
OB3036SE 30˝ 762 36˝ 914 186 84.4 4
OB3048SE 30˝ 762 48˝ 1219 248 112.5 4
OB3060SE 30˝ 762 60˝ 1524 309 140.2 4
OB3072SE 30˝ 762 72˝ 1829 371 168.3 4
OB3084SE 30˝ 762 84˝ 2134 431 195.5 6
OB3096SE 30˝ 762 96˝ 2438 494 224.1 6
OB30120SE 30˝ 762 120˝ 3048 616 279.4 6
