1. "+": Short press to increase volume.
2. : Short press to play music, then press Se again to stop. In
BT mode, press within a few seconds to pair TWS, press twice
to disconnect.
3. REC/DEL: After connecting the microphone and memory, press
once to start recording, then press again to complete recording
and check the recorded audio. To delete recorded audio, hold
down the button while playing the recorded audio.
4. MIC/ECHO: Short press this button, the screen will display "N",
and you can adjust the volume of the microphone at this time.
Short press this button again, and the screen will display "E",
at which point you can adjust the reverb volume.
5. : Short press to change the lighting display mode, with a
total of 7 lighting display modes to choose from.
6. Mode: Start automatic Bluetooth mode, short press to enter
USB-AUX mode, then press to return to Bluetooth mode.
7. : Short press this button to select EQ sound effects. Long
press this button to enter cycle mode. When the display screen
shows "ONE", it is a cycle of a song; When the display screen
shows "ALL", it is a loop of all songs. When the display screen
shows "RAND", the song is played randomly. When the display
screen shows "FOLD", it loops through all the songs in the
current folder.
8. : Short press to open, then press to close.
9. : Put this song at the beginning.
10. "-": Short press to lower the volume.
11. : Put down a song.
12. MIC IN: Microphone input
13. AUX: Audio Input
14. USB input
15. AC input~127-220V 50/60Hz
CHARGE
12 13 14
15
Protable Wireless Speaker System
Model: FS-L1216M
Operation Manual
Button function description.
Specifications
Accessories
Functional panel diagram
Audio cable 1 PC
Power cable 1 PC
Microphone 1 PC
Instruction manual 1 PC
Speaker Size: 6.5”+2.25x2
Frequency Response: 40Hz - 20KHz
S/N Ratio:≥78dB
Output Power: 30W+10Wx2
Power: IN 120-220V 50/60Hz
Battery Capacity:14.8V 2000mAh
MIC
ECHO
1 2
3
4
5
6
7
8
9 10 11
FCC Warnning:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable
protection againstharmful interference in a residential installation. This equipment generates,
uses and can radiateradio
frequency
energy
and,
if
not
installed
and
used
in
accordance
with
the
instructions,
maycause
harmful
interference
to
radio
communications.
However,
there
is
no
guarantee
thatinterference
will
not
occur
in
a
particular
installation.
If
this
equipment
does
cause
harmfulinterference to radio or television reception, which can be
determined by turning the equipmentoff
and
on,
the
user
is
encouraged
to
try
to
correct
the
interference
by
one
or
more
of
thefollowing measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution:
Any
changes
or
modifications
to
this
device
not
explicitly
approved
by
manufacturer
could void your authority to operate this equipment.
This
device
complies
with
part
15
of
the
FCC
Rules.
Operation
is
subject
to
the
following
two
conditions:
(1)This
device
may
not
cause
harmful
interference,
and
(2)
this
device
must
accept
any
interference received, including interference that may cause undesired operation.
This
equipment
complies
with
FCC
radiation
exposure
limits
set
forth
for
an
uncontrolled
environment.
This
equipment
should
be
installed
and
operated
with
minimum
distance
0cm
between the radiator and your body.
