DECRIPTION OF PLAYBACK PANEL
FS-S227
尺寸
157g双铜 单黑印刷 200*140mm
说明书
2025-03-26
Protable Wireless Speaker System
Model: FS-S227
Operation Manual
Button function description.
Functional panel diagram
1. "-": Short press to play the previous song, long press to
decrease the volume. In FM mode, short press to play the
previous channel.
2. " " : Press and hold to turn on, then press and hold again to
turn off.
3. "M": Automatically enter Bluetooth mode when turned on. Short
press this button to enter USB-TF-FM-AUX mode in sequence,
and then press to return to Bluetooth mode.
*Lithium battery (3.7V/3000mAh) 18650x1
*Charging time: approximately 4 hours (5v/2A)
*Charging port: USB Type-C
*audio takes about 3-4 hours (depending on volume and content,
dynamic light off)
*Speaker size: 57mm x2.
*Bass amplifier: Reverse channel type.
*Output power: 10W x2.
*Frequency response: 60Hz~20kHz.
*S/N. Ratio: above 89dB.
*Total harmonic distortion: ≤ 1%
*Bluetooth 5.0 version
4. "+": Short press to play the next song, long press to increase
the volume. In FM mode, short press to play the next channel.
5. " ": Short press to pause playing music, then press to
resume playing music. In FM mode, short press to search for
channels, then press to stop searching.
6. " ": Short press to switch lighting modes.
7. AUX: Audio input port.
8. USB: USB drive insertion port.
9. TYPE-C: TYPE-C charging port.
10. TF: TF card insertion port.
Specifications
Accessories
speaker 1pc
TYPE-C charging cable 1pc
user 's manual 1pc
FCC Warnning:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable
protection againstharmful interference in a residential installation. This equipment generates,
uses and can radiateradio
frequency
energy
and,
if
not
installed
and
used
in
accordance
with
the
instructions,
maycause
harmful
interference
to
radio
communications.
However,
there
is
no
guarantee
thatinterference
will
not
occur
in
a
particular
installation.
If
this
equipment
does
cause
harmfulinterference to radio or television reception, which can be
determined by turning the equipmentoff
and
on,
the
user
is
encouraged
to
try
to
correct
the
interference
by
one
or
more
of
thefollowing measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution:
Any
changes
or
modifications
to
this
device
not
explicitly
approved
by
manufacturer
could void your authority to operate this equipment.
This
device
complies
with
part
15
of
the
FCC
Rules.
Operation
is
subject
to
the
following
two
conditions:
(1)This
device
may
not
cause
harmful
interference,
and
(2)
this
device
must
accept
any
interference received, including interference that may cause undesired operation.
This
equipment
complies
with
FCC
radiation
exposure
limits
set
forth
for
an
uncontrolled
environment.
This
equipment
should
be
installed
and
operated
with
minimum
distance
0cm
between the radiator and your body.
