USER GUIDE | EN
WATCH
Weight: 62g
Water resistance: IP67
Shock resistance: IK04
OLED Screen: 26 x 10,66 mm
Cleaning: water and soap only
Wristband processing: hypoallergenic
Opera�ng temperature: -10°C / +50°C
Geoloca�on : indoor becon connec�on and SIGFOX,
NBiOT and LTE-M outdoor connec�on.
Ba�ery : Rechargeable polymer lithium, replaceable,
removable. Up to 30 days ba�ery.
Charging current: 220mA
Charging method:
place the watch on the charging dock (the watch is
mechanically hold), the white LED indicates that the
watch is charging.
CHARGING DOCK
Weight: 51g
Charging current : 220mA
Manufacturer: Telecom Design (with removable
external USB wall plug charger TenPao
S015BTV0500200)
Opera�ng temperature: 0°C / +35°C
Remark: do not use another charging dock neither
another external USB wall plug,
Manual alarm (fig. 1):
An SOS key bu�on is located on the le� side of the
watch allowing the wearer to send an alarm.
Automa�c alarm (fig. 2):
A set of sensors combined with a new algorithm
allow to send an alarm automa�cally in case of
heavy fall detec�on*. 20 seconds a�er an automa�c
fall detec�on and before sending the alarm to the
transmi�er, the watch starts to vibrate intermi�ently
and blink for 20 seconds. To manually cancel the
alarm, the user must cover the watch with the palm
of his hand. His hand has to be removed when
vibra�ons stop.
Accessing the Regulatory Informa�on
This device uses an electronic label to display regulatory
informa�on. To access the FCC ID, IC cer�fica�on number, and
compliance logos directly on the watch screen, follow these
steps :
1. Scroll to Se�ngs using the Right Bu�on, then press and hold
to enter.
2. Scroll to Regulatory, then press and hold again.
3. Scroll through the screens to view the regulatory
informa�on.
TECHNICAL SPECIFICATION
ONBOARDING
FUNCTIONS
INSTALLATION
1. Plug the docking sta�on on and plug the watch on
the docking sta�on
2. The QR code is displayed on the watch screen
Scan the QR code with the App provided by Telecom
Design and follow the App instruc�ons for the watch
configura�on
3. Once the configura�on is over, “WAIT” is displayed
on the watch screen. This step can take several
minutes. Keep the watch in the docking sta�on.
4. Once the configura�on is overn, the watch displays
“READY”. The watch can taken out of the docking
sta�on.
Automa�c Fall Detector
The watch is a hybrid watch combining a
mechanical system to move the hands and a
digital display. The watch is an IoT device
which must be worn permanently as a
wristband. Any other use may cause false
alarms such as non fall detec�ons. The
watch is configured by your installer.
Ikarya Watch
Model : TD-WTC-11
DESIGN BY
USER GUIDE | EN
FCC Compliance
This device complies with part 15 of the FCC Rules. Opera�on is
subject to the following two condi�ons:
(1) This device may not cause harmful interference,
(2) This device must accept any interference received, including
interference that may cause undesired opera�on.
NOTE: The grantee is not responsible for any changes or
modifica�ons not expressly approved by the party responsible
for compliance. Such modifica�ons could void the user's
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable
protec�on against harmful interference in a residen�al
installa�on. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instruc�ons, may cause harmful
interference to radio communica�ons. However, there is no
guarantee that interference will not occur in a par�cular
installa�on. If this equipment does cause harmful interference
to radio or television recep�on, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separa�on between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help.
ISED CANADA COMPLIANCE
This device contains licence-exempt transmi�er(s)/receiver(s)
that comply with Innova�on, Science and Economic
Development Canada’s licence-exempt RSS(s). Opera�on is
subject to the following two condi�ons:
(1) This device may not cause interference.
(2) This device must accept any interference, including
interference that may cause undesired opera�on of the device.
L'éme�eur/récepteur exempt de licence contenu dans le présent
appareil est conforme aux CNR d'Innova�on, Sciences et
Développement économique Canada applicables aux appareils
radio exempts de licence. L'exploita�on est autorisée aux deux
condi�ons suivantes :
(1) L'appareil ne doit pas produire de brouillage;
(2) L'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est suscep�ble d'en comprome�re le
fonc�onnement.
WARNING
Danger of explosion if ba�ery is incorrectly replaced.
Replacement can only be done by a qualifies
technician.
Replace only with the same ba�ery type. Must be
disposed of properly. Disposal of a ba�ery into fire
or a hot oven, or mechanically crushing or cu�ng of
a ba�ery can result in an explosion
FCC ID: 2AGMK-WTC11
IC: 21552-WTC11
CAN ICES-3 (B)/NMB-3(B)
Contains
FCC ID: HSW-TY1SCDM
IC: 4492A-TY1SCDM
Declara�on of conformity
We hereby cer�fy that the Ikarya Watch designed by
Telecom Design, complies with the main
requirements and other associated regula�ons
presented in Direc�ves 2011/65/EU(RoHS).
IMPORTANT : The device’s technology does not allow for the analysis and
interpreta�on of all situa�ons and the detec�on of all falls. Some falls,
such as so� falls, controlled falls against a wall or chair, or some heavy
falls, are not detected by the Ikarya Watch. Excep�onally, certain fall
pa�erns and/or movements of the watch may be analyzed as a heavy fall
even though they do not meet the heavy fall scenario. If a false alarm is
triggered, quickly clarify the situa�on. For more informa�on on
automa�c fall detec�on or the opera�ng of the product, please consult:
h�ps://telecomdesign.com/downloads/
TECHNICAL SPECIFICATION
CE COMPLIANCE
INSTALLATION
EU Declara�on of conformity
We hereby cer�fy that the Ikarya Watch designed by Telecom
Design, complies with the main requirements and other
associated regula�ons presented in Direc�ves 2014/53/EU
(RED), 2015/863/EU (RoHS-3) and EC 1907/2006: NO_SVHC
REACH.
Waste Electronic and Electrical Equipment (WEEE)
Elimina�ng household Waste Electrical and Electronic
Equipment in the European Union. The presence of this symbol
on a product or packaging indicates that you should not
dispose of this product with other household waste. On the
contrary, it is your duty to dispose of waste equipment by
deposi�ng it at a dedicated collec�on point for recycling Waste
Electrical and Electronic Equipment. For further informa�on on
these collec�on points, please contact your local town hall,
waste disposal service or dealer. When ba�eries are collected
at the same �me as Waste Electrical and Electronic Equipment
in accordance with direc�ve 2002/96/CE, they must first be
removed from appliances.
Automa�c Fall Detector
The watch is a hybrid watch combining a
mechanical system to move the hands and a
digital display. The watch is an IoT device
which must be worn permanently as a
wristband. Any other use may cause false
alarms such as non fall detec�ons. The
watch is configured by your installer.
Ikarya Watch
Model : TD-WTC-11
DESIGN BY
Address of the Manufacturer
The Ikarya Watch is a product manufactured by
Telecom Design, Zone Ac�polis II, 2bis rue Nully de
Harcourt, 33610 Canéjan, France
