CG-I-36
CG-I-48
CG-I-60
CG-I-72
CG-O-36
CG-O-48
CG-O-60
CG-O-72
EG10.14 Rev. 07/23
Catalog Specification Sheet No.
Corner Guards
Item No.:
Project No.:
S.I.S. No.:
Corner Guards
Specification Sheet
MODELS:
Short Form Specifications
Eagle Corner Guard, model __________, to include adhesive
tape backing. Heavy gauge stainless steel. Inside and outside
corners available.
outer
corner
guard
inner
corner
guard
• Heavy gauge type 304 stainless steel construction.
• Inside and outside corners available.
• 4˝-wide strip folded to a 90˚ angle, creating a finished
2˝ x 2˝ width and length.
• Heights available range from 36˝ to 72˝.
• Adhesive tape backing.
width length height
model # in. mm in. mm in. mm
CG-I-36 2˝ 51 2˝ 51 36˝ 914
CG-I-48 2˝ 51 2˝ 51 48˝ 1219
CG-I-60 2˝ 51 2˝ 51 60˝ 1524
CG-I-72 2˝ 51 2˝ 51 72˝ 1829
Inside Corner Guards
width length height
model # in. mm in. mm in. mm
CG-O-36 2˝ 51 2˝ 51 36˝ 914
CG-O-48 2˝ 51 2˝ 51 48˝ 1219
CG-O-60 2˝ 51 2˝ 51 60˝ 1524
CG-O-72 2˝ 51 2˝ 51 72˝ 1829
Outside Corner Guards
EG10.14
For custom configuration or fabrication needs, contact our SpecFAB
®
Division.
