SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER)
OWNER’S MANUAL AND SAFETY INSTRUCTIONS
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: (909) 628 0880 MON-FRI 9AM TO 3PM PST
160FPS CROSSBOW
ITEM: 98021
GENERAL SAFETY WARNINGS
The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible
conditions and situations that may occur. It must be understood by the operator that common sense and
caution are factors which cannot be built into this product, but must be supplied by the operator. Read
carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to
follow the safety rules and other basic safety precautions may result in serious personal injury.
Read and understand all instructions. Failure to follow all instructions may result in serious injury or
property damage.
DO NOT allow persons to operate or assemble the crossbow until they have read this manual and have
developed a thorough understanding of how it works.
DO NOT modify this product in any way. Unauthorized modication may impair the function and/or
safety and could affect the life of the crossbow. Mishandling or misuse may result in serious injury to
yourself or others, damage to your crossbow or poor performance. It’s critical that you maintain a regular
maintenance schedule so your crossbow continues to function at a high level.
1
IMPORTANT SAFETY INFORMATION
NEVER place ngers or thumbs on, in or near the arrow/ight track, the string and/or the cables. Placing
ngers or thumbs on, in or near the arrow/ight track, the string and/or the cables may result in serious
injury, including nger and/or thumb amputation.
DO NOT allow any foreign object(s) on, in and/or near the arrow/ight track, the string and/or the cables.
Allowing any foreign objects, including tree branches, vines, tree bark, clothing, hunting accessories (e.g.,
binoculars, rangenders, game calls, pull-up/hoist ropes, etc.) on, in and/or near these areas may result
in crossbow and/or property damage and may lead to serious injury or death!
NEVER “dry re” (i.e., release a cocked crossbow string without a recommended arrow properly loaded
into the receiver) your crossbow. Dry ring this crossbow will immediately void your warranty and result in
catastrophic damage to the crossbow. Should this crossbow dry re, it must be inspected by a qualied
service representative prior to further use. Failure to follow these instructions may result in serious injury!
Under no circumstances should you attempt to use your rope cocking device to de-cock your crossbow.
Attempting to do so will put you at immediate risk of personal injury and will result in catastrophic damage
to your crossbow. Failure to follow these instructions may result in serious injury!
NEVER attempt to use improperly spined (stiffness), improperly weighted (less than 380 grains) and/or
improperly sized (length) arrows. Attempting to use improperly spined, weighted and/or sized arrows will
immediately void your warranty, may cause crossbow and/or property damage and may lead to serious
injury!
DO NOT allow children under the age of 16 and/or older children who have not been properly trained
to handle, operate and/or otherwise use this crossbow and/or its accessories without proper adult
supervision. Crossbows are serious sporting implements and should be treated as such. Failure to follow
these instructions may result in serious injury or death!
You must wear quality, close-toed shoes or boots while operating this crossbow. Never operate this
product barefooted. Sandals, house shoes, socks/stockings, open-toed shoes, slippers, etc. must not be
worn when operating this crossbow. Failure to follow these instructions may result in serious injury!
ALWAYS keep your ngers below the arrow/ight track and out of the path of the string and cables. Should
the string strike your ngers, they may be amputated.
2
FEATURES AND SPECIFICATIONS
ALWAYS inspect the crossbow and arrows prior to each use. Frayed and/or worn strings and cables must
be replaced immediately and never red. Bent and/or damaged arrows/nocks are not safe to re and
should be discarded. NEVER attempt to use a damaged arrow or nock.
ALWAYS use arrows designed for crossbows that are the appropriate weight and length. Attempting to use
“compound arrows,” “vertical bow arrows” or “recurve bow arrows” (i.e., full-length arrows) will immediately
void your warranty, lead to catastrophic crossbow and/or property damage and may lead to serious injury.
ALWAYS make certain the arrow is properly loaded, with the odd-colored vane (etching) facing down and
the anti-dry re device fully engaged, thus precluding a dry re.
NEVER attempt to re this crossbow until you are sure of your intended target.
ALWAYS use a crossbow-approved target/backstop. Using an inadequate target/backstop will result in
dangerous conditions and may result in personal injury and/or property damage.
ALWAYS wear safety glasses when assembling, cleaning, cocking, loading or shooting this crossbow.
ALWAYS wear quality close-toed shoes or boots while operating a crossbow. Bare feet, ip ops, house
shoes, slippers, socks/stockings or open-toed shoes should not be worn when operating a crossbow.
NEVER attempt to transport, carry and/or stalk with a loaded crossbow.
NEVER attempt to store a cocked and/or loaded crossbow.
NEVER attempt to re this crossbow when obstructions are present (e.g., tree branches, vines, leaves,
etc.) which block or encumber the limbs, string, cables and/or arrow’s ight path. Attempting to re an
obstructed crossbow will lead to catastrophic crossbow and/or property damage and may lead to serious
injury or death.
NEVER attempt to use a crossbow for any purpose other than hunting or target shooting. Any other use can
lead to catastrophic crossbow and/or property damage and may lead to serious injury or death.
NEVER consume drugs and/or alcohol before or while attempting to operate a crossbow. Such behavior
may impair your ability to use this product safely and responsibly.
NEVER attempt to carry or haul a crossbow up or down a tree while climbing. Use a pull-up or hoist rope
of sufcient strength to haul the crossbow up or down after safely securing yourself in a tree stand with a
full-body fall arrest harness attached.
NEVER attempt to use this crossbow if you have a history of heart problems, back problems and/or any
other physical impairment, which may limit your ability to use and/or operate this crossbow in a safe manner.
NEVER allow bystanders to stand in front of or beside you while operating this crossbow. Bystanders must
stand a signicant distance BEHIND the shooter’s location.
ALWAYS grip the rope cocking device rmly, in a manner which precludes it slipping from your hands while
cocking this crossbow. NEVER attempt to cock this crossbow with wet or damp hands. Should the cocking
device slip while cocking this crossbow, serious injury and/or equipment damage may result.
NEVER attempt to perform service and/or repair to this crossbow yourself. Service and/or repairs should be
performed by a qualied service representative only. Attempting to perform service/repairs to this crossbow
will immediately void your warranty, lead to catastrophic crossbow and/or property damage and may lead
to serious injury or death.
3
PRODUCT INFORMATION
1. Do not cock the bow for an extended period as it will affect the life and safety of the bow parts.
INCLUDED ACCESSORIES: 8mm Steel Balls x80, Featherless Finishing Fork x1, Featherless Hunting
Arrow x2, Inner Hexagonal Spanner x1, Gloves x1, Laser Light x1, Tactocal Light x1
NOTE:
2. Only use approved balls and arrows with the crossbow and discontinue use if signs of damage or wear
are visible.
3. ALWAYS operate safely, be mindful of persons or items in the area that may be damaged in case of misre.
SPECIFICATIONS:
WEIGHT: 6.83LBS
MAX RANGE: 75M
DRAW WEIGHT: 187LBS
LET-OFF DRAW WEIGHT: 66LBS
TRIGGER PULL: 3.96LBS
MAGAZINE CAPACITY: 200PCS
4
OPERATION / MAINTENANCE
COCKING: Use the belly to hold the stock. Pull the string backward. When you hear the “click”, it is now
cocked. A steel ball will drop at the same time and the crossbow is in the safety position. Pull the safety
button to shoot.
ASSEMBLY: Insert the libm assembly into the rest of the parts. The main string is up and the cross string
down in the groove with the slider. The four localized pins will t into the rest of the parts. After connecting,
use the spanner to tighten.
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only and are not available individually
as replacement parts.
PLEASE READ THE FOLLOWING CAREFULLY
5
PRODUCT MADE IN CHINA
WARRANTY
