Upright Vacuum with DuoClean
Detect
™
, Self-Cleaning Brushroll,
and Odor Neutralizer Technology
LA742
OWNER’S GUIDE
SPEED
sharkclean.comsharkclean.com
READ ALL INSTRUCTIONS BEFORE USING
THIS VACUUM
1. Inspect power cord and plug for any
damage before use. DO NOT use vacuum
cleaner with a damaged cord or plug.
Turn off all controls before plugging
in or unplugging the vacuum cleaner.
Store your vacuum cleaner with the
power cord secured around the two cord
hooks. To minimize the risk of power
cord damage, do not allow the motorized
brush roll to ingest the cord. If this
occurs, immediately shut off power to
the vacuum and remove the cord.
2. This appliance has a polarized plug. If
the plug does not fit fully into the outlet,
reverse the plug (one blade is wider than
the other). If it still does not fit, contact a
qualified electrician. DO NOT force into
outlet or try to modify to fit.
3. Your vacuum cleaner may consist of
a motorized nozzle, wand, hose, and/
or vacuum pod. This device contains
electrical connections, electrical wiring,
and moving parts that potentially
present risk to the user. The hose
contains electrical wires.
Do not use when damaged, cut,
or punctured.
4. Use only identical replacement parts.
5. Carefully observe and follow the
instructions provided below to avoid
improper use of the appliance.
DO NOT use the vacuum for any
purpose other than those described in
this manual.
6. Before use, carefully inspect all parts for
any damage. DO NOT use if any parts
are damaged.
7. The use of an extension cord is
NOT recommended.
8. This vacuum cleaner contains
no serviceable parts.
9. This appliance can be used by persons
with reduced physical, sensory, or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way
and understand the hazards involved.
Cleaning and user maintenance shall not
be made by children. Keep the appliance
and its cord out of reach of children. DO
NOT allow the appliance to be used by
children. DO NOT allow to be used as a
toy. Close supervision is necessary when
used near children.
10. Always turn off the vacuum cleaner
before connecting or disconnecting any
motorized nozzles, hose, or
other accessories.
a) Unplug before connecting Pet Power
Brush and HairPro® Self-Cleaning Pet
Power Brush
11. DO NOT handle plug or vacuum cleaner
with wet hands.
12. DO NOT use without filters in place.
13. Only use Shark® branded filters
and accessories.
14. DO NOT damage the power cord:
a) DO NOT pull or carry vacuum
cleaner by the cord or use the cord
as a handle.
b) DO NOT unplug by pulling on cord.
Grasp the plug, not the cord.
c) DO NOT run the vacuum cleaner
over the power cord, close a door
on the cord, pull the cord around
sharp corners, or leave the cord near
heated surfaces.
15. DO NOT put any objects into nozzle or
accessory openings. DO NOT use with
any opening blocked; keep free of dust,
lint, hair, and anything that may reduce
airflow.
16. DO NOT use if nozzle or accessory
airflow is restricted. If the air paths or
the motorized floor nozzle become
blocked, turn the vacuum cleaner
off and unplug from electrical outlet.
Remove all obstructions before you plug
in and turn on the unit again.
17. Keep nozzle and all vacuum openings
away from hair, face, fingers, uncovered
feet, or loose clothing.
18. DO NOT use if vacuum cleaner is
not working as it should, or has been
dropped, damaged, left outdoors, or
dropped into water.
19. Use extra care when cleaning on stairs.
20. DO NOT leave the vacuum cleaner
unattended while plugged in.
21. When powered on, keep the vacuum
cleaner moving over the carpet surface
at all times to avoid damaging the
carpet fibers.
22. DO NOT place vacuum cleaner on
unstable surfaces such as chairs
or tables.
23. Your Shark® vacuum may not
be designed to stand up on its own.
When taking a break from cleaning, you
may need to lean it against furniture or
a wall, or lay it flat
on the floor. Using the vacuum
for an application where the unit lacks
stability may result in personal injury.
24. DO NOT use to pick up:
a) Liquids
b) Large objects
c) Hard or sharp objects
(glass, nails, screws, or coins)
d) Large quantities of dust (drywall
dust, fireplace ash, or embers). DO
NOT use as an attachment to power
tools for dust collection.
e) Smoking or burning objects
(hot coals, cigarette butts,
or matches)
f) Flammable or combustible materials
(lighter fluid, gasoline,
or kerosene)
g) Toxic materials (chlorine bleach,
ammonia, or drain cleaner)
25. DO NOT use in the following areas:
a) Poorly lit areas
b) Wet or damp surfaces
c) Outdoor areas
d) Spaces that are enclosed and may
contain explosive or toxic fumes
or vapors (lighter fluid, gasoline,
kerosene, paint, paint thinners,
mothproofing substances, or
flammable dust).
26. Turn off all controls before plugging in
or unplugging the vacuum.
ODOR CARTRIDGE
27. Observe the following when interacting
with the Odor Neutralizer Technology
cartridge:
a) DO NOT attempt to
disassemble Odor Neutralizer
Technology cartridge.
b) Avoid direct contact with the
fragrance pod in the cartridge.
c) DO NOT directly inhale
from the Odor Neutralizer
Technology cartridge.
d) Keep away from children and pets.
e) Keep away from heat, sparks, and
open flame.
f) DO NOT place in direct sunlight.
ODOR CARTRIDGE FIRST AID
a) Avoid contact with fabrics and
finished surfaces.
b) Eye contact: Remove contact lenses if
present. Rinse continuously with water
for several minutes.
c) Skin contact: Wash hands thoroughly
after handling. If irritation or rash
develops, seek medical advice/
attention.
d) Inhalation: Move person to
fresh air if they are experiencing any
respiratory symptoms. If symptoms
persist, seek medical advice/
attention.
e) Ingestion: DO NOT induce vomiting.
Seek medical
advice/attention.
28. Unplug from electrical outlet when not
in use and before any maintenance or
cleaning.
29. Hand wash with water only.
Washing with cleaning chemicals could
damage the unit.
30. During cleaning or routine maintenance,
DO NOT cut anything other than hair,
fibers, or string wrapped around the
brushroll.
31. Allow all filters to air-dry completely
before replacing in the vacuum to
prevent liquid from being drawn
into electric parts.
32. Make sure the dust cup and
all filters are in place after
routine maintenance.
33. If provided, secure the power
cord around the two cord hooks during
storage.
WARNING
To reduce the risk of fire, electric shock, injury, or property damage, when using
an electrical appliance, basic precautions should always be followed, including
the following:
IMPORTANT SAFETY INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
sharkclean.comsharkclean.com
ASSEMBLY ASSEMBLY
Tool Storage
Posts
Upper Cord
Hook
Lower Cord Hook
POWER CORD
For cord access, rotate upper hook
down and remove cord.
Use cord holder on the side of wand
to hold cord in place while vacuuming.
UPPER CORD HOOK CORD HOLDER
1. Place Pod down onto Nozzle.
2. Insert Wand into Pod.
3. Insert Handle into wand.
4. Attach Hose to back of pod.
5. Remove Odor Neutralizer Technology Dial from bag. Flip up the dial handle,
align the teal arrows, then insert the dial into the nozzle.
6. To lock and engage the dial, rotate it counterclockwise until it clicks into the desired
odor intensity setting.
IMPORTANT: For proper operation, ensure all connections are securely clicked into place.
(Click)
2
(Click)
1
(Click)
3
(Click)
4
(Turn to
Click)
6
5
sharkclean.comsharkclean.com
ODOR NEUTRALIZER TECHNOLOGY
ODOR CARTRIDGE REPLACEMENT
TECHNOLOGY SETTINGS
ODOR NEUTRALIZER TECHNOLOGY TIPS
SETTINGS
Flip up the dial handle and rotate the odor dial
to adjust Odor Neutralizer Technology intensity
or to unlock the dial for cartridge access.
Flip up the handle and rotate the dial clockwise
until the two teal arrows are aligned. Pull the
handle to remove the dial from the nozzle.
Rotate the cartridge counterclockwise
in the dial housing and pull out the
cartridge to remove it.
Align the yellow arrow on the side of the cartridge
with the yellow arrow on the side of the dial
cover, then insert the cartridge into the dial.
Rotate the cartridge clockwise to lock it in place.
Dispose of the old cartridge by
dropping it into the trash.
Remove the new odor cartridge from the
sealed packaging. To maintain the life of
the cartridge, keep it in the sealed
packaging until you are ready to install it.
Align the teal arrow on the dial cover with
the teal arrow on the nozzle, then reinsert
the dial into the nozzle. Rotate the dial
counterclockwise until it clicks into an
intensity setting to engage. Rotate further
to change the intensity setting.
ODOR DIAL
1. REMOVE ODOR DIAL
FROM NOZZLE
2. REMOVE OLD ODOR
CARTRIDGE
3.REMOVE NEW CARTRIDGE
FROM BAG
5. INSTALL DIAL IN NOZZLE
4. INSTALL NEW CARTRIDGE
IN DIAL
6. USED CARTRIDGE
DISPOSAL
NOTE: Odor cartridges should be replaced
every 6 months for optimal Odor Neutralizer
Technology performance.
NOTES: • The odor dial needs to be installed for the vacuum to function properly, with or without the odor cartridge.
• Odor Neutralizer Technology eectively deodorizes while interacting with odors from inanimate sources.
Insertion/Removal: Rotate the odor dial to align the teal arrows. Remove the dial to
access the odor cartridge for removal or replacement.
Low: Rotate the dial toward the Low position to decrease the intensity to the lowest level
when the vacuum is in use.
High: Rotate the dial toward the High position for the highest intensity level when the
vacuum is in use. This position is the recommended setting for optimal performance.
Odor Dial Must be Installed for Vacuum to Function Properly
• Remove odor cartridge from dial if you don’t want the benefits of the
Odor Neutralizer Technology.
Maintenance Required
• Clean all filters as recommended under Cleaning Filters.
• Empty the dust cup before storing your vacuum.
• Replace the cartridge as recommended under Odor Cartridge Replacement.
• Visit qr.sharkclean.com/odortech to learn more and purchase replacements.
• If wet pet messes are cleaned up, thoroughly clean the vacuum.
Fragrance Strength Over Time
• The intensity of the Odor Neutralizer Technology’s fragrance may diminish over time. It may
also have no noticeable fragrance at all. This is natural and does not indicate the technology
isn’t working. Follow replacement instructions to ensure continued performance.
TURN UNTIL
CLICK TO LOCK
sharkclean.comsharkclean.com
NOTE: Only the icon of the mode that is currently
selected on the dial will be illuminated on the
display. The other icons will remain dark.
MODE DIAL
WHOLE-HOME CLEANING
SETTINGS
Press down on power button to turn on
vacuum. The vacuum will power on in
whatever mode it was left in. Refer to Mode
Dial section to review each setting.
POWER BUTTON
To select a cleaning mode, turn the dial to
one of the four icons on the screen.
Detect Mode: Select Detect mode
to activate DuoClean Detect™. In
this mode, the vacuum will detect
hidden dirt, dierent floor types,
edges and corners, and cleaning
direction. Suction will adjust to
maximize cleaning performance.
Manual Surface Modes: To clean specific
surfaces without DuoClean Detect, turn the
dial to select a surface mode:
Hard Floor: Suction and brushroll
speed optimized for cleaning hard floor
surfaces and above-floor areas.
Carpet/Low Pile: Suction and brushroll
speed optimized for deep cleaning low-
pile carpets.
Thick Carpet/Area Rug: Suction and
brushroll speed optimized for cleaning
thick carpets and area rugs.
Solid White Lights: The brushrolls are spinning and the unit is working as intended.
Solid Red Lights: There is a jam in the brushroll area. Turn o the vacuum and unplug it,
then remove any blockages in the nozzle.
Flashing Red Lights: The motorized floor nozzle is overheating. Turn o the vacuum, unplug it,
and remove any blockages. Let the vacuum cool down for at least 60 minutes before restarting.
Flashing White Lights: The vacuum is operating in an environment that is either too hot or too cold.
White: Cleaning.
Purple: Cleaning Boost. Surface is dirty,
suction will increase to pull in hidden debris.
Red: Sensors require cleaning. Reference
the Detect Sensor Maintenance section.
When an edge is detected, the arrow
indicator closest to edge will turn on, and the
headlights closest to the edge will brighten
to illuminate hidden debris.
Blinking White Arrows: When the Edge Detect
sensors are obstructed, the arrow indicator
lights will blink. Move the unit away from
the edge, turn o power, and restart. If the
arrows continue to blink, clean the sensors.
DIRT DETECT INDICATOR EDGE DETECT INDICATORS
WHOLE-HOME CLEANING
HEADLIGHT INDICATOR LIGHTS
DETECT INDICATORS
HEADLIGHTS
The headlights will flash or turn red to
indicate issues that need attention.
DIRT DETECT INDICATOR
EDGE DETECT INDICATORS
NOTE: Detect Indicators will be o in manual
surface modes.
NOTE: For deep cleaning per ASTM F608 (embedded dirt in carpets) and IEC 62885-2 Cl 5.5 (debris on carpet) tests,
use Carpet/Low Pile mode.
NOTE: For best cleaning per ASTM F2607 (hard surface floor cleaning) and IEC 62885-2 Cl 5.3 (debris on hard floor)
tests, use Hard Floor mode.
NOTE: For maximum suction for above-floor cleaning per ASTM F558, use Hard Floor mode.
sharkclean.comsharkclean.com
WHOLE-HOME CLEANING
CLEANING MODES
To engage the brushrolls, select a
surface mode, step on the floor nozzle,
and tilt the handle back firmly.
Step on the Lift-Away pedal to
detach the pod, then lift it o
the nozzle.
Press the Wand Release button
and pull up on the wand to
detach it from the pod.
Press the Handle Release button
and pull up on the handle to
detach it from the wand.
Attach an optional cleaning
accessory to handle or wand.
UPRIGHT MODE LIFT-AWAY® MODE
ABOVE-FLOOR—WAND
ACCESSORIES—WAND
ABOVE-FLOOR—HANDLE
ACCESSORIES—HANDLE
Wand
Release
EMPTYING THE DUST CUP
To remove the Dust Cup, slide up on the release
button located on the side of dust cup handle.
Tilt dust cup forward, then lift to remove.
To reinstall, place the bottom of the dust
cup onto the pod and then tilt until it clicks
into place.
To empty debris into the trash, press the
lower release button and the bottom of the
dust cup will drop open.
Clear debris from the Lint Screen in the dust
cup. Lift the upper release tab at the top of
the dust cup and open the lid. Gently brush
the lint screen to remove debris.
IMPORTANT: Unplug the power cord before performing any maintenance.
Empty the dust cup each time you vacuum and periodically during cleaning,
when debris in the dust cup reaches the MAX fill line.
NOTES: • All accessories are compatible with both the wand and the handle. Included accessories will vary by model.
• For best above-floor cleaning suction, use Hard Floor mode. For more delicate above-floor cleaning such as curtains
or drapes, use Thick Carpet/Area Rug mode.
sharkclean.comsharkclean.com
RINSE HEPA FILTER
EVERY YEAR
To remove the HEPA Filter, first pull the tab
on the bottom of the filter door, then lift o
the door. Press the tab on the side of the
HEPA filter and pull out the filter.
To reinstall the door, align the top first, then
press in the bottom until it clicks into place.
RINSE PRE-MOTOR FILTERS
EVERY MONTH
Remove the dust cup, then lift out the Foam
and Felt Filters.
Regularly rinse and replace the filters to maintain your vacuum's suction power and to
maximize the eectiveness of the Odor Neutralizer Technology.
Rinse filters with cold water only. Allow all filters to air-dry for at least 24 hours before
reinstalling them to prevent liquid from being drawn into electronic parts.
CLEANING THE FILTERS
IMPORTANT: DO NOT use soap when cleaning the filters.
Post-Motor
HEPA Filter
Foam
Felt
Filter
Door
MAINTENANCE
Slide the Soft Roller access button
forward to release the Soft Roller.
Hand wash the Soft Roller as needed.
Use only water, and allow it to air-dry
completely for at least 24 hours. Reinsert
the Soft Roller in the front of the nozzle
until it clicks into place.
CLEANING THE SOFT ROLLER
SELF-CLEANING BRUSHROLL
If any hair is wrapped around the brushroll, continue vacuuming, using Carpet/Low Pile mode
on a bare floor surface, a low-pile carpet, or a small area rug. This will allow the self-cleaning
brushroll to remove the hair wrap and send it to the dust cup.
If you run over a hard or sharp object or notice a noise change while vacuuming, check for
blockages or objects caught in the brushroll.
If some fibers remain wrapped around the brushroll after continued use, carefully remove them.
NOZZLE MAINTENANCE
To minimize the risk of power cord damage,
DO NOT run the vacuum over the power cord.
If this occurs, immediately shut o power to
the vacuum and remove the cord from the
brushrolls or nozzle.
1. DO NOT pull or carry vacuum cleaner by
the cord or use cord as a handle.
2. DO NOT unplug by pulling on the cord.
Grasp the plug, not the cord.
3. DO NOT close the door on the cord.
4. DO NOT pull the cord around sharp
corners.
5. DO NOT leave the cord near heated
surfaces.
CORD MAINTENANCE
sharkclean.comsharkclean.com
CHECKING FOR BLOCKAGES
Detach wand from pod and handle,
and check both ends for blockages.
Detach dust cup from vacuum
pod. Empty dust cup and remove
debris from lint screen in the top
of the dust cup.
Detach hose from handle by
pressing on the release button
at the top of the hose. Detach
the hose from the pod, and
check openings for blockages.
DUST CUP BLOCKAGES
WAND BLOCKAGES
HOSE BLOCKAGES
Detach handle from wand and
hose from the vacuum pod, and
check openings for blockages.
HANDLE/HOSE BLOCKAGE
To access the nozzle hose, pinch
the release touchpoints on the
bottom of the nozzle, then lift the
cover and clear any blockages.
NOZZLE HOSE BLOCKAGE
Detach wand from floor nozzle,
tilt nozzle neck back, and check
opening for blockages.
NOZZLE BLOCKAGE
BOTTOM OF NOZZLE
EDGE DETECT SENSORS
WIPE OFF SENSORS
MAINTENANCE
Make sure to clean the Detect sensors regularly, or when the Dirt Detect Indicator is red,
as hair and other debris may build up and obstruct the sensors. If the sensors are partially
obstructed, Detect mode will not function as expected. To easily access the nozzle for sensor
cleaning, step on the Lift-Away pedal to detach the pod, then press the wand release button to
detach the wand from the nozzle.
DETECT SENSOR MAINTENANCE
1. Locate Edge Detect sensors on the sides
of the nozzle (small clear ovals on the
top, rear edge).
2. Check the sensors, and remove any dirt
or debris that may be blocking them.
3. Gently wipe the sensors with a microfiber
cloth, using a circular motion.
1. Turn the nozzle upside
down and locate the
nozzle inlet access point
between the brushrolls
and rear wheels.
2. Pinch the nozzle hose inlet
and pull open the door.
Arrows indicate the two
small Dirt Detect sensors.
3. Gently wipe the sensors
with a microfiber cloth and
remove all hair and debris.
1. Locate the Floor Detect sensor on
the bottom of the nozzle.
2. Use a cotton swab to wipe away
dirt and debris from the sensor
and surrounding area.
CLEANING THE DIRT DETECT SENSORS
CLEANING THE FLOOR DETECT™ SENSOR CLEANING THE EDGE DETECT SENSORS
NOZZLE INLET ACCESS
FLOOR DETECT SENSOR
sharkclean.comsharkclean.com
SQUEEGEE BRISTLE STRIP
REMOVING THE SQUEEGEE BRISTLE STRIP
REINSTALLING THE SQUEEGEE BRISTLE STRIP
CLEANING THE SQUEEGEE BRISTLE STRIP & CAVITY
NOZZLE MAINTENANCE NOZZLE MAINTENANCE
1. Turn the nozzle over and locate the
squeegee bristle strip between the brushroll
and the rear wheels. Use a Phillips-head
screwdriver to remove the 4 screws.
1. Hold the squeegee strip by the fabric flaps
on the ends, with the bristle side facing
up. Insert the plastic piece into the cavity
first, while tilting the strip forward, toward
the brushroll.
2. Remove the squeegee strip by pulling up on
the fabric flaps on both ends of the strip.
2. Align the 4 screw holes on the squeegee
strip over the holes in the nozzle. Make sure
the strip sits flush with the nozzle, then
fasten it securely in place with the screws.
1. With the strip removed, clean the
squeegee cavity and bristle strip. Use a
paper towel to wipe o any debris or
dust in the cavity and on the bristle strip.
If your vacuum has low suction or no suction, or if it is struggling to pick up debris while
moving in reverse, then you’ll need to remove and clean the Squeegee Bristle Strip on the
bottom of the nozzle.
To access the squeegee strip, step on the Lift-Away pedal to detach the pod from
the wand, then press the wand release button to detach the wand from the nozzle.
REMOVE SQUEEGEE
SQUEEGEE REPLACEMENT
REMOVE SCREWS
LINE UP SCREW HOLES
CLEANING THE CAVITY
NOTE: Keep screws after removal.
sharkclean.comsharkclean.com
TROUBLESHOOTING
Power cord caught in brushrolls or floor nozzle.
• To minimize the risk of power cord damage, DO NOT run the vacuum over the power cord.
If this occurs, immediately shut o power to the vacuum and remove the cord from the
brushrolls or nozzle.
• Inspect power cord and plug for any damage before use. DO NOT use vacuum cleaner with
a damaged cord or plug. Turn o all controls before plugging in or unplugging the vacuum
cleaner. Store your vacuum cleaner with the power cord secured around the two cord hooks.
Vacuum will not turn on.
• All parts may not be connected properly or completely. Disassemble the vacuum, then
reassemble it, making sure the nozzle, pod, wand, handle, and hose all click securely into
place when connected.
• Make sure the Odor Neutralizer Technology dial is installed in the nozzle completely and
correctly. Remove the odor cartridge if desired.
• Try plugging unit into a confirmed working outlet.
Vacuum is not picking up debris. No suction or light suction.
• Check filters to see if they need cleaning. Follow instructions for rinsing and air-drying the
filters before reinstalling them in the vacuum.
• Dust cup may be full; empty dust cup.
• Check handle, hose, hose connections, nozzle, wand, pod, and accessories for blockages.
Clear any blockages found.
Vacuum lifts area rugs.
• Make sure Power/Mode Dial is set to Hard Floor.
• Suction is powerful. Take care when vacuuming area rugs or rugs with delicately sewn edges.
Dirt Detect indicator light not responding or is red.
• Make sure the mode dial on the pod is set to Detect Mode. The Dirt Detect indicator will be
o in manual surface modes.
• Check sensors located in nozzle inlet to see if there are any blockages (See Detect Sensor
Maintenance section for more information.).
• Remove any blockages and clean sensors.
Brushrolls do not spin.
• If the headlight indicator lights turn red, immediately turn o and unplug the vacuum.
Detach the pod and the wand from the floor nozzle. Using a flashlight, check the brushroll
and Soft Roller and remove any debris, jams, or clogs. Reconnect nozzle, plug in vacuum,
and turn on power.
• With the power on, recline the handle, which will automatically turn on the brushrolls.
Vacuum turns o on its own or headlight indicator lights flash red.
If your vacuum overheats, the thermostat will automatically turn o the motor. Perform the
following steps to restart:
1. Turn vacuum o and unplug it.
2. Empty dust cup and clean filters. See Emptying the Dust Cup and Cleaning and Replacing
the Filters sections for more information.
3. Check for blockages in handle, hose, wand, floor nozzle, accessories, and inlet openings.
4. Allow unit to cool for a minimum of 60 minutes.
5. Plug in vacuum and turn it on.
Vacuum is emitting air that smells bad.
• Dust cup may be full; empty dust cup. Empty dust cup after each use for optimal Odor
Neutralizer Technology performance.
• Check filters to see if they need cleaning. Follow instructions for rinsing and air-drying the
filters before reinstalling them.
• Check to make sure odor cartridge is installed in the dial and the dial is installed in the nozzle.
• Check the Odor Neutralizer Technology dial on the nozzle to see what setting is enabled.
• If the odor cartridge is still emitting a scent but you dislike it, consider turning the intensity
down, or reinstall the dial in the nozzle without the cartridge.
• If the Odor Neutralizer Technology cartridge is not emitting a scent, consider replacing it.
For all other issues, please go to support.sharkclean.com or call Customer Service 1-855-427-5127.
AVAILABLE ACCESSORIES
D
F
G
I
E
C
B
A
Crevice Tool
This slender tool oers extended reach to
access corners, baseboards, tight spaces,
and ceilings.
B
Upholstery Tool
Picks up hair, dust, and large debris from
mattresses, couches, curtains, lampshades,
and other delicate upholstered fabrics.
C
Pet Multi-Tool
A single convertible tool for cleaning tough
pet messes two ways: use the sti bristle
brush to clean stuck-on debris, or take o
the bristles to reveal an upholstery tool
perfect for removing stubborn pet hair and
large piles of debris.
D
Duster Crevice Tool
Two cleaning tools in one. The crevice tool
gives you extended reach to clean in tight
spaces, while the soft brush is ideal for
dusting delicate surfaces.
E
Pet Power Brush
The turbine brush loosens and removes
pet hair and debris from carpets, and
powerfully deep-cleans dander out of
upholstery and other surfaces.
F
Under-Appliance Wand
Clean under and behind hard-to-move
appliances and furniture with this adjustable
36” tool. Flip the extension piece over to
clean the underside of appliances.
G
Anti-Allergen Dust Brush
This brush features nylon fiber bristles
specifically designed for removing fine
dust and allergen particles from the most
delicate surfaces.
H
HairPro® Self-Cleaning Pet Power Brush
Tackles pet hair and ground-in dirt from
above-floor areas like carpeted stairs and
upholstery, while actively removing hair
wrap as it cleans.
I
Home & Car Detail Kit
Deep-clean your car like a professional
detailer, or clean hard-to-reach areas
in your home. Micro-sized tools let you
clean around delicate objects and access
the tightest spaces like car vents and
computer keyboards.
J
Accessory Bag
This convenient accessory storage bag
measures 32 cm x 70 cm and fits the Under-
Appliance Wand. Smaller size available at
sharkaccessories.com.
A
J
H
NOTE: Not all accessories come with all units. For a list of the accessories included with this model, see the top inside flap
of the box. To order additional accessories, visit sharkaccessories.com.
sharkclean.comsharkclean.com
TIP: You can find the model and serial
numbers on the QR code label on the
bottom of the back of the vacuum pod.
Benefits of registering your product and
creating an account:
• Get easier, faster product support and
access to warranty information
• Access troubleshooting and product care
instructions
• Be among the first to know about
exclusive product promotions
RECORD THIS INFORMATION
Model Number:
����������������������������������������������������������������������������������������������������
Serial Number:
������������������������������������������������������������������������������������������������������
Date of Purchase:
��������������������������������������������������������������������������������������������
(Keep receipt)
Store of Purchase:
������������������������������������������������������������������������������������������
FIVE (5) YEAR LIMITED WARRANTY
The Five (5) Year Limited Warranty applies to purchases made from authorized retailers of SharkNinja
Operating LLC. Warranty coverage applies to the original owner and to the original product only and is
not transferable.
SharkNinja warrants that the unit shall be free from defects in material and workmanship for a period
of five (5) years from the date of purchase when it is used under normal household conditions and
maintained according to the requirements outlined in the Owner’s Guide, subject to the following
conditions and exclusions:
CALIFORNIA RESIDENTS ONLY:
The Five (5) Year Limited Warranty period begins on the original date of delivery or pickup.
What is covered by this warranty?
1. The original unit and/or non-wearable parts deemed defective, in SharkNinja’s sole discretion, will be
repaired or replaced up to five (5) years from the original purchase date.
2. In the event a replacement unit is issued, the warranty coverage ends six (6) months following the
receipt date of the replacement unit or the remainder of the existing warranty, whichever is later.
SharkNinja reserves the right to replace the unit with one of equal or greater value.
What is not covered by this warranty?
1. Normal wear and tear of wearable parts (such as foam filters, HEPA filters, pads, etc.), which require
regular maintenance and/or replacement to ensure the proper functioning of your unit, are not covered
by this warranty. Replacement parts are available for purchase at sharkclean.com/find-parts.
2. Any unit that has been tampered with or used for commercial purposes.
3. Damage caused by misuse (e.g., vacuuming up water or other liquids), abuse, negligent handling, failure
to perform required maintenance (e.g., not cleaning the filters, not removing debris from the brushroll),
or damage due to mishandling in transit.
4. Consequential and incidental damages.
5. Defects caused by repair persons not authorized by SharkNinja. These defects include damages caused
in the process of shipping, altering, or repairing the SharkNinja product (or any of its parts) when the
repair is performed by a repair person not authorized by SharkNinja.
6. Products purchased, used, or operated outside North America.
How to get service
If your appliance fails to operate properly while in use under normal household conditions within the warranty
period, visit sharkclean.com/support for product care and maintenance self-help. Our Customer Service
Specialists are also available at 1-855-427-5127 to assist with product support and warranty service options,
including the possibility of upgrading to our VIP warranty service options for select product categories. So
we may better assist you, please register your product online at registeryourshark.com and have the product
on hand when you call.
SharkNinja will cover the cost for the customer to send in the unit to us for repair or replacement. A fee of
$25.95 (subject to change) will be charged when SharkNinja ships the repaired or replacement unit.
How to initiate a warranty claim
You must call 1-855-427-5127 to initiate a warranty claim. You will need the receipt as proof of purchase.
We also ask that you register your product online at registeryourshark.com and have the product on hand
when you call, so we may better assist you. A Customer Service Specialist will provide you with return and
packing instruction information.
How state law applies
This warranty gives you specific legal rights, and you also may have other rights that vary from state to
state. Some states do not permit the exclusion or limitation of incidental or consequential damages, so the
above may not apply to you.
REGISTER YOUR PURCHASE
registeryourshark.com
Scan QR code using
mobile device
Scan here or visit
qr.sharkclean.com/odortech
for more information
TECHNICAL SPECIFICATIONS
Voltage: 120V~, 60Hz
Watts: 960W
ODOR NEUTRALIZER TECHNOLOGY SPECIFICATIONS
1. Product Name: Odor Neutralizer Technology Cartridge
2. Manufacturer: Shark Ninja 89 A Street Needham, MA 02494
3. Weight: 17.6g / 0.62oz
4. Ingredients: Solid SM composite polymer C17 + fragrance SE 272235
sharkclean.comsharkclean.com
NOTES NOTES
© 2025 SharkNinja Operating LLC. DETECTPRO, HAIRPRO, LIFT-AWAY, and SHARK are registered trademarks
of SharkNinja Operating LLC.
DUOCLEAN DETECT and FLOOR DETECT are trademarks of SharkNinja Operating LLC.
LA742�IB�MP�Mv1
PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
This Owner’s Guide is designed to help you get a complete understanding of your new Shark®
DetectPro® Lift-Away® ADV Speed Upright Vacuum with DuoClean Detect™, Self-Cleaning
Brushroll, and Odor Neutralizer Technology.
SharkNinja Operating LLC
US: Needham, MA 02494
CAN: Ville St-Laurent, QC H4S 1A7
1-855-427-5127
sharkclean.com
Illustrations may dier from actual product. We are constantly striving to improve our products;
therefore the specifications contained herein are subject to change without notice.
This product may be covered by one or more U.S. patents.
See sharkninja.com/patents for more information.
