Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back
of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep
this manual and the receipt in a safe and dry place for future reference. 23a
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright
©
2022 by Harbor Freight Tools
®
. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 59810
Specifications
Run Time Up to 24 hours (Fully Charged)
Length 72 ft (66ft Rope Light with 6ft Wire lead)
Battery 3.7 V 2000 mAh 18650 Li-Ion
IMPORTANT SAFETY INFORMATION
1. Verify that installation surface has
no hidden utility lines before drilling,
driving screws, or to insert stake.
2. Place/mount the LED Rope to prevent
tripping or choking. Keep out of reach
of young children and babies.
3. Install only according to these instructions.
Improper installation can create hazards.
4. Wear ANSI-approved safety goggles and
heavy-duty work gloves during installation.
5. Keep installation area clean and well lit.
6. Keep bystanders out of the area during installation.
7. Do not install when tired or when under
the influence of drugs or medication.
8. This product is not a toy. Do not allow
children to play with or near this item.
9. Use as intended only.
10. Contains Li-Ion battery. Battery must be
recycled or disposed of properly. Do not open,
crush, heat above 140° F or incinerate.
11. Maintain product labels and nameplates.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
Installation Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document
including all text under subheadings therein before set up or use of this product.
Selecting a Location
Choose a location for the Rope Light where the Solar Panel can receive full, direct sunlight a minimum of 8 hours
a day; even partial shade will greatly hinder charging and therefore limit operation time. The location should not
be near nighttime light sources such as porch lights or streetlights as this will cause the Solar Light to remain off.
The Solar Panel is provided with a 6ft wire lead to aid in positioning the Solar Panel in its optimum orientation.
Solar Panel Mounting
Stake Mounting
1. Select a ground location to insert the Stake.
2. With a rubber mallet (not included), gently
tap the Stake into the ground.
3. Attach the Hinge Mount on the back of the
Solar Panel onto the top of the Stake.
4. Orientate the Solar Panel for
optimum sunlight exposure.
Wall Mounting
1. Remove the Screw and Nut securing the Hinge
Mount to the back of the Solar Panel.
2. Place the Hinge Mount in the desired
location on the wall and mark the mounting
hole locations onto the wall.
3. Screw the Hinge Mount to the wall with the Wall
Screws; if mounting to sheetrock, drill holes in the
marked locations appropriate for the Wall Anchors.
4. Insert the Wall Anchors into the holes, align the
holes in the Hinge Mount base with the Anchors,
and secure it in place with the Wall Screws.
5. Reattach the Solar Panel to the Hinge
Mount with the Screw and Nut.
Page 3For technical questions, please call 1-888-866-5797.Item 59810
Rope Light Mounting
Ground Mounting
1. The LED Rope can be left loose
or secured to the ground.
2. Route the LED Rope in the desired location; if
desired, secure the LED Rope to the ground
using appropriate hardware (not included).
Alternative Mounting
1. The LED Rope can be secured to a wall or object.
2. Wall Mounting: Mount the LED Rope to a wall
using appropriate hardware (not included).
Use Caution when mounting as walls often
have hidden wiring and plumbing.
3. Object Mounting: Mount the LED Rope to an object
by wrapping the LED Rope around the object or
using appropriate hardware (not included). Use
Caution when mounting with hardware as the object
may have wiring, plumbing, or other hidden hazards.
Operation Instructions
1. For best results, allow sunlight to charge
the Solar Panel while it is turned OFF for
at least 8 hours before powering on.
2. Press the Power Button to turn the unit ON.
Note: The Solar Panel is equipped with a
light sensor, so it will need to be covered
or dark for the LED lights to turn on.
3. Press the Mode Button to select operation mode.
Mode sequences display approximately ten seconds.
Note: The operation mode will need to be
selected again if the unit is powered down.
a. Steady On.
b. Slow Glow.
c. Fast Twinkling.
d. Slow Twinkling.
e. Flashing in Series.
f. Flashing in
Reverse Series.
g. Fast Flashing
in Series
h. Slow Flashing in
Series followed by
Reverse Series
and All Off.
Battery Disposal
1. Press the Power Button to turn the Solar Panel OFF.
2. Remove the eight Screws from the back of
the Solar Panel and open the Solar Panel.
3. Remove old Battery.
4. Contains Li-Ion battery. Battery must be
recycled or disposed of properly. Do not open,
crush, heat above 140° F or incinerate.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available individually as
replacement parts.
Visit harborfreight.com/parts for a list of in stock parts. Reference UPC 193175486622.
26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Parts List and Diagram
Part Description Qty
1 Solar Panel / Hinge Mount / LED Rope 1
2 Stake 1
Part Description Qty
3 Screw (Not Shown) 2
4 Wall Anchors (Not Shown) 2
1
2
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
