尺寸：60*90mm
操作说明
VS040
2
4
1
3
A:按键顺序
1.开关键;2.暂停键;3.上一曲/音量+;4.下一曲/音量-
1.长按开关机，短按模式切换《BT-TF-FM》，双击切换灯光
2.短按播放暂停，来电模式下短按接听，长按拒接，通话
中短按挂断，双击回拨。蓝牙模式下长按进入和退出TWS，
FM模式下长按自动搜台，短按静音。
3.短按音量减，长按上一曲
B:技术规范
C:特点
C: Features
1.Wireless connection
2.Supports BT, TF, FM, TWS, LED colorful light & call
function
3.Bluetooth frequency: 2.402GHz ~ 2.480GHz
4.TF card decoding: MP3 format
5.IPX7 Grade Waterproof
3.Short press Volume Down; long press Previous Track
4.Short press Volume Up; long press Next Track
5.Red LED stays lit during charging and turns off once fully
charged
6.3.5: Low-battery alert triggers at 3.3 V; device shuts down
below 3.3 V and fails to power on.
B: Technical Specification
Model:VS040
BluetoothVersion:6.0
TransmissionDistance:10m
BatteryCapacity:1200mAh
PlaybackTime:3-4hours
StandbyTime:20-30days
ChargingTime:3-4hours
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
NOTE 1: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician
for help
NOTE 2: Any changes or modifications to this unit not
expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure
condition without restriction.
Operation description
VS040
2
4
1
3
A:Button Layout & Functions
1: Power 2: Play/Pause 3: Previous Track / Volume+
4: Next Track / Volume-
1.Long press for power on/off; short press to switch modes
(BT-TF-FM); double-tap to toggle lighting.
2.Short press to play/pause. Short press to answer incoming
calls and long press to reject; short press to end ongoing
calls, double tap to redial. Long press to activate or exit
TWS under Bluetooth mode; long press for automatic
channel search and short press to mute under FM mode.
4.短按音量加，长按下一曲
5.充电红灯常亮，充满红灯灭
6.3.5报低电3.3关机。低于3.3机器不能开机
型号:VS040
蓝牙版本:6.0
传输距离:10米
电池容量:1200毫安
播放时间:3-4小时
待机时间:20-30天
时充电时间:3-4小时
1.无线连接
2.支持BT-TF-FM-TWS-炫彩灯-通话
3.蓝牙频率:2.402GHz至2.480GHz
4.TF解码:MP3格式
5.IP防水7级
本设备符合美国联邦通信委员会（FCC）规则第 15 部分的规
定。设备运行需满足以下两个条件：
(1) 本设备不得产生有害干扰；
(2) 本设备必须接受接收到的任何干扰，
包括可能导致设备意外运行的干扰。
注 1： 本设备已经过测试，符合 FCC 规则第 15 部分对 B
类数字设备的限制要求。这些限制旨在为住宅安装环境提供
合理的保护，防止有害干扰。本设备会产生、使用并可能辐
射射频能量，如果未按照说明进行安装和使用，可能会对无
线电通信造成有害干扰。但我们无法保证在特定安装环境中
不会发生干扰。如果本设备确实对无线电或电视接收造成了
有害干扰（可通过关闭再打开设备来确认），建议用户尝试
通过以下一种或多种方式消除干扰：
-调整接收天线的方向或位置。
-增大设备与接收器之间的距离。
-将设备连接到与接收器不同的电路插座上。
-咨询经销商或有经验的无线电 / 电视技术人员寻求帮助。
注 2： 未经合规责任方明确批准，对本设备进行任何更改
或修改，可能会导致用户失去操作本设备的权限。
本设备已通过评估，符合通用射频暴露要求。设备可在无限
制的便携式暴露条件下使用。
FCC 警告
FCC Warning
