TIDE
BT speaker
BT reproduktor
BT reproduktor
BT hangszóró
Głośnik BT
EN - 2
SAFETY INSTRUCTIONS
This product has been designed with the utmost safety in mind. However, incorrect
use may lead to electric shock or fire. This is why users should observe the following
instructions when using this device.
This device uses a semiconductor unit and contains no user serviceable parts. Do
not disassemble this device, otherwise you are exposed to the risk of electric shock.
If any damage to this product occurs, please have this product repaired by a qualified
service technician.
Power
Power supply of this unit must be match the serial plate data.
Heat Source
Keep this unit out of heat sources like stove or direct sunlight.
Cleaning
Prior to cleaning, please disconnect power first. For cleaning, don’t use liquid
detergents or caustic liquids - just clean the unit with a soft cloth.
Heavy Objects
Do not place heavy objects on the unit, otherwise damage might occur.
Connecting Other Devices
Before connecting other devices to this unit, please make sure to disconnect power.
Otherwise damage to the unit or personal injury might occur.
EN - 3
Faults to Be Repaired
If any of the following problems occurs, please disconnect power to the unit and
contact a qualified service technician.
A. Power cord or plug is damaged.
B. Liquids or other foreign objects have penetrated inside the product.
C. If the unit does not work even if it’s being operated according to the instructions,
don’t press any buttons other than those described in these instructions.
Otherwise, damage to this unit may occur along with a more demanding repair.
D. This unit has fallen on the ground from a big height.
E. Burns can be smelled from the product inside.
Maintenance
If you don’t have enough technical knowledge necessary to maintain this unit, don’t
attempt to repair it by yourself. By removing the cover, you are exposed to a risk of
electric shock. If needed, please contact a qualified service technician.
Replacement of Parts
If you need to replace any part of this unit, ask your service technician to make
a replacement for equal spare part models. If other spare part models are used for
replacement, serious damage, electric shock or shortening the unit’s lifetime may
occur.
Safety Check
After completing maintenance, ask the service technician to perform an on-site safety
check to ensure that the unit is operating safely.
Note:
Before using this product, read these instructions carefully and keep it well for
future use.
EN - 4
INCLUDED CONTENTS
1x BT speaker TIDE
1x USB-C charging cable
1x user's manual
1X BT speaker carrying loop
EN - 5
BT SPEAKER DESCRIPTION
9
P
H
1
R
L
2
3
4
6
7
5
8
P
Z
Z
E
E
EN - 6
1 BT speaker on/off button (long press)
Dial the last number called (2x short press)
End an incoming call (1× short press)
Answer an incoming call (1× short press)
Rejecting an incoming call (1× long press)
Disconnect from the paired device using BT (3× short press)
PLAY / PAUSE during music playback (1x short press)
2 Volume up button (short press)
Next track (long press)
3 Volume down button (short press)
Previous track (long press)
2+3 Switching notification tones and alerts on/off (long press of the “+” and “-” buttons)
4 M button
TWS mode in BT mode (long press)
Change mode when memory card, USB-A storage or AUX-IN is connected
(short press)
Switch on/off/change lighting effects (2x short press)
5 LED charging indicator, Microphone
6 Memory card slot
7 USB-A slot for inserting storage
8 Charging socket (USB-C)
9 Audio AUX IN mini jack (3.5mm) socket, RESET button
L Speaker – left channel
R Speaker – right channel
P Passive radiator
E LED effect
H Device carrying loop eyelet
Z BT speaker feet
EN - 7
PUTTING INTO OPERATION
Before first use, be sure to read the safety instructions contained in this
user's manual carefully.
Before first use, please charge the BT speaker to a maximum level. Press and hold
the “On/Off” button to turn on the BT speaker. Turning on/off is indicated by a sound
signal. To turn the BT speaker off, press and hold the “On/Off” button. Changing the
source of the music being played is done by briefly pressing the button “M” when the
power is on.
Attention: After a longer period of inactivity, the appliance will turns itself off.
POSITION A - BT SPEAKER TRANSPORT
The speaker offers a vertical position of placement on a flat surface. The main figure
shows the underside of the BT speaker “Z - BT speaker feet”.
To carry the BT speaker, use the loops that you attach to the “H" eyelet.
Attention: Always position the device so that it does not endanger the health of
persons in the vicinity or cause damage to property.
PAIRING DEVICES VIA BLUETOOTH
Turn on the BT speaker and search for its Bluetooth name “TIDE” in the device to
be paired, then start the pairing process. If you are requested to enter a pairing
code while your device and the BT speaker are pairing, use the code: “0000”. To
disconnect a paired device, end the pairing session on your mobile device or press
the “On/Off” 3 times. Disconnection will be confirmed by an acoustic signal.
EN - 8
Note: To ensure a stable Bluetooth connection, make sure that the distance between
the BT speaker and your connected device is kept within 10 meters.
Attention: Some connected devices support common volume setting. If some of
the connected devices do not support this feature, the volume setting will operate
separately on each device.
TWS FEATURE
If you purchase another Bluetooth speaker (“TIDE”), you can pair them together for
optimal stereo sound. First, make sure your device is not connected to any BT speaker.
Switch on both BT speakers, press and hold the “M” button on both BT speakers at the
same time and wait until the speakers pair together automatically. Successful pairing
will be accompanied by an acoustic signal. Then connect your mobile device to one of
the BT speakers.
Changing the volume level using the volume control buttons will take effect
automatically on both paired BT speakers. To exit TWS mode, hold down the “M”
button on one of the participating BT speakers until an acoustic signal sounds.
Warning: The TWS feature is only available in the Bluetooth mode. It is not possible
to pair the device with another type of BT speaker with TWS function, even in re-
editions of products with a different name.
EN - 9
PLAY/PAUSE BUTTON
● Pressthe“On/Off”buttontostartorpausemusicplaybackduringBluetooth
connection or while a memory media is inserted.
● TheincomingcalltoaBluetoothconnectedpaireddevicewillbeannouncedbyan
acoustic signal which will interrupt the music being played back. To answer/hang
up an incoming call, press the “On/Off” button briefly. To reject the incoming call,
long-press the “On/Off” button.
Note: Microphone reception in the BT speaker may be attenuated due to the
waterproof nature of the device. To improve reception, turn the BT speaker
microphone (“5”) towards you and speak loudly near the BT speaker.
VOLUME AND TRACK PLAYBACK CONTROL
To control the BT speaker’s volume (+/- buttons), use the buttons on the BT speaker.
During music playback, you can press and hold the “+” button to jump to the next track
playback. To select the previous track, press and hold the “-” button.
LIGHT EFFECTS
The BT loudspeaker is equipped with light effects in the area of passive light emitters.
To switch the lighting effects off/on or change them, press the “M” button twice.
EN - 10
TURNING OFF BT SPEAKER NOTIFICATIONS AND
ALERTS
The BT speaker offers the option to turn the notification tones off or on. Press
and hold the “- “ and “+” buttons together to activate or deactivate the BT speaker
notification and alert tones. When turned off and on, the BT speaker will remember
the last selected mode.
Caution: in the off state, no tones will indicate the status of the BT speaker. Charge
the BT speaker as a preventive measure. Avoid using the sound at a maximum level.
RESET BUTTON
To reset the BT speaker, use a blunt, non-metallic object with a diameter of 3 mm and
carefully insert it into the AUX-IN connector. Gently press into the connector until you
feel the click of the button located behind the AUX-IN connector. Then switch on the
BT speaker using the power button.
RECOMMENDATION: If there is an unexpected problem with the BT speaker
connection or its functions. Reset the BT speaker.
AUDIO AUX IN
The BT speaker is equipped with a 3.5mm jack. Your device can be connected to the
BT speaker with an audio cable. First connect the audio plug to your device and then
to the BT speaker’s jack.
EN - 11
Please note: before connecting your device and BT speaker, make sure that the
output signal from your device is at the minimum level (minimum output volume). This
will prevent the BT speaker from damage. When the audio cable is connected, the
BT speaker does not meet the water ingression protection class.
Note: In this mode, not all functions of the BT speaker are available. The Bluetooth
function is not active if the audio jack is connected to the BT speaker.
USB-A AND MEMORY CARD PLAYBACK
Insert the memory card with the contacts facing the USB-A connector. After inserting
the memory card or USB-A memory storage, the BT speaker will automatically start
playing the content. If there is no file to play on the memory storage, the BT speaker
will switch to Bluetooth mode. To release the TF memory card, press it gently into
the BT speaker with your fingernail or a blunt instrument and the card will release.
Then you can carefully remove it with your fingernails (or with tweezers). Supported
playback formats are listed in the technical specification.
Attention: Due to a number of devices on the market, compatibility and playback
support are not guaranteed for all media. The memory devices you want to connect
should be tested in advance and/or formatted as FAT32. The playback of protected
media, files or content stored inside them may fail.
CHARGING THE BT SPEAKER
A charged battery provides power for several hours of operation at normal volume
levels. A high volume consumes more battery power; therefore, we recommend
listening at normal volume levels. To charge the BT speaker, please connect the
charging adapter to the mains and then to the BT speaker. The charging indicator
LED will glow red during the charging process until the charging adapter is
EN - 12
disconnected or the battery reaches full capacity. A low battery level will be indicated
by an audible alert – start charging the battery.
Attention: For charging, use only the original accessories supplied with the
appliance. To achieve the maximum battery lifetime, it is best not to start charging
until the low battery audible alert is output. Charge continuously until fully charged.
When the battery operating time becomes very short, the battery lifetime has been
used up; we recommend that you have the battery replaced at your authorized
centre.
Recommendation: If the unit is not to be used for an extended period of time,
we recommend to fully charge the battery once every two to three months. We
recommend to store the unit with a the battery charged to prevent irreparable
damage to the battery (loss of capacity). For optimal charging, use a 5V 2A charging
adapter.
EN - 13
INGRESSION PROTECTION (IPX4)
The device is waterproof, allowing you to listen to music near water.
IPX4 ingression protection - Water passing at all angles at a flow rate of 10 litres per
minute, at a pressure of
80–100 kN/m2 for at least 5 minutes.
Warning: Always remember to seal the BT speaker inputs (No. 6–9 in the “BT
speaker description” picture) with the original gasket and make sure that the gasket
is not damaged. Never charge the unit during possible contact with fluids. The unit is
designed for contact with clean water only without any additives. Avoid exposing the
unit to contaminated or industrially treated fluids (such as lemonade, sea/salt water,
oils, etc.).
TECHNICAL SPECIFICATIONS
Features
Water-resistant speaker with IPX4 protection class
The speaker cover is made of fabric
TWS function (True Wireless Stereo)
LED speaker illumination
Sound:
Maximumspeakeroutput20W(Impedance:4Ω)
2 speakers + 2 passive radiators
Frequency response: 20 Hz – 20 kHz
Totalharmonicdistortion:≤10%
EN - 14
Inputs:
Bluetooth Audio 5.3
AUX audio input (3.5mm stereo connector)
TF card slot
USB-A playback
Other:
Handsfree Function
Built-in rechargeable battery: 2000 mAh Li-Ion
Playbacktimeofupto8hours(@50%volume)
USB-C charging
Max. charging time 3 hours
Accessories: USB charging cable, user’s manual
Dimensions: 188×79×79 mm
Weight: 538 g
Bluetooth Version 5.3
Maximum Transmitter
Power
100mW @ 2.4GHz–2.4835GHz
Codec SBC
Profiles A2DP/AVRCP/HFP
EN - 15
INSTRUCTIONS AND INFORMATION ON THE DISPOSAL OF DISCARDED
PACKAGING MATERIALS
Take the packaging to a collection centre for recycling.
DISPOSAL OF DISCARDED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on the product, accessory or packaging means that the
product must not be disposed of in normal household waste. Please
dispose of this product in a collection yard designated for the recycling
of electrical and electronic equipment. In some EU countries or other
European countries, you can return the old product to your local retailer
when you buy a new equivalent product. By disposing of this product
correctly, you help protect valuable natural resources and prevent
potential negative environmental and human health impacts that could
result from improper disposal. For more information, contact your local
authorities or the nearest collection centre. You may be fined by law for
improper disposal of this type of waste.
For companies in the EU
If you need to dispose of electrical or electronic equipment, ask your
dealer or supplier for the necessary information.
Disposal in countries outside the European Union
Ask your local authorities or your dealer for information on proper
disposal.
This product meets the EU requirements.
FASTČR,a.s.herebydeclaresthatthetypeofradioequipmentTIDEcomplies
with the Directive 2014/53/EU. The full text of the EU Declaration of Conformity is
available at the following web address: www.sencor.com.
EN - 16
Text, design and technical data are subject to change without notice; we reserve the
right to make such changes.
The original version is Czech.
Manufacturer:FASTČR,a.s.,USanitasu1621,Říčany25101,CzechRepublic
EN
Warranty conditions
Warranty card is not apart of the device packaging.
This product is warranted for the period of 24 months from the date of purchase to the end-user. Warranty
is limited to the following conditions. Warranty is referred only to the customer goods using for common
domestic use. The claim for service can be applied either at dealer’sshop where the product was bought, or
at below mentioned authorized service shops. The end-user is obligated to set up aclaim immediately when
the defects appeared but only till the end of warranty period. The end user is obligated to cooperate to certify
the claiming defects. Only completed and clean (according to hygienic standards) product will be accepted.
In case of eligible warranty claim the warranty period will be prolonged by the period from the date of claim
application till the date of taking over the product by end-user, or the date the end-user is obligated to take it
over. To obtain the service under this warranty, end-user is obligated to certify his claim with duly completed
following documents: receipt, certificate of warranty, certificate of installation.
This warranty is void especially if apply as follows:
Defects which were put on sale.
Wear-out or damage caused by common use.
The product was damaged by unprofessional or wrong installation, used in contrary to the applicable
instruction manual, used in contrary to legal enactment and common process of use or used for another
purpose which has been designed for.
The product was damaged by uncared-for or insufficient maintenance.
The product was damaged by dirt, accident of force majeure (natural disaster, fire, and flood).
Defects on functionality caused by low duality of signal, electromagnetic field interference etc.
The product was mechanically damaged (e.g. broken button, fall).
Damage caused by use of unsuitable media, fillings, expendable supplies (batteries) or by unsuitable
working conditions (e.g. high temperatures, high humidity, quakes).
Repair, modification or other failure action to the product by unauthorized person.
End-user did not prove enough his right to claim (time and place of purchase).
Data on presented documents differs from data on products.
Cases when the claiming product cannot be indentified according to the presented documents (e.g. the
serial number or the warranty seal has been damaged).
Manufacturer:
FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic
Visit www.sencor.com for detailed information about authorized service centers.
The original version of the instructions is in the Czech language, other language versions are made by the
appropriate translation.
EN - 17
EN
Warranty conditions
Warranty card is not apart of the device packaging.
This product is warranted for the period of 24 months from the date of purchase to the end-user. Warranty
is limited to the following conditions. Warranty is referred only to the customer goods using for common
domestic use. The claim for service can be applied either at dealer’sshop where the product was bought, or
at below mentioned authorized service shops. The end-user is obligated to set up aclaim immediately when
the defects appeared but only till the end of warranty period. The end user is obligated to cooperate to certify
the claiming defects. Only completed and clean (according to hygienic standards) product will be accepted.
In case of eligible warranty claim the warranty period will be prolonged by the period from the date of claim
application till the date of taking over the product by end-user, or the date the end-user is obligated to take it
over. To obtain the service under this warranty, end-user is obligated to certify his claim with duly completed
following documents: receipt, certificate of warranty, certificate of installation.
This warranty is void especially if apply as follows:
Defects which were put on sale.
Wear-out or damage caused by common use.
The product was damaged by unprofessional or wrong installation, used in contrary to the applicable
instruction manual, used in contrary to legal enactment and common process of use or used for another
purpose which has been designed for.
The product was damaged by uncared-for or insufficient maintenance.
The product was damaged by dirt, accident of force majeure (natural disaster, fire, and flood).
Defects on functionality caused by low duality of signal, electromagnetic field interference etc.
The product was mechanically damaged (e.g. broken button, fall).
Damage caused by use of unsuitable media, fillings, expendable supplies (batteries) or by unsuitable
working conditions (e.g. high temperatures, high humidity, quakes).
Repair, modification or other failure action to the product by unauthorized person.
End-user did not prove enough his right to claim (time and place of purchase).
Data on presented documents differs from data on products.
Cases when the claiming product cannot be indentified according to the presented documents (e.g. the
serial number or the warranty seal has been damaged).
Manufacturer:
FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic
Visit www.sencor.com for detailed information about authorized service centers.
The original version of the instructions is in the Czech language, other language versions are made by the
appropriate translation.
EN - 18
EN
Warranty conditions
Warranty card is not apart of the device packaging.
This product is warranted for the period of 24 months from the date of purchase to the end-user. Warranty
is limited to the following conditions. Warranty is referred only to the customer goods using for common
domestic use. The claim for service can be applied either at dealer’sshop where the product was bought, or
at below mentioned authorized service shops. The end-user is obligated to set up aclaim immediately when
the defects appeared but only till the end of warranty period. The end user is obligated to cooperate to certify
the claiming defects. Only completed and clean (according to hygienic standards) product will be accepted.
In case of eligible warranty claim the warranty period will be prolonged by the period from the date of claim
application till the date of taking over the product by end-user, or the date the end-user is obligated to take it
over. To obtain the service under this warranty, end-user is obligated to certify his claim with duly completed
following documents: receipt, certificate of warranty, certificate of installation.
This warranty is void especially if apply as follows:
Defects which were put on sale.
Wear-out or damage caused by common use.
The product was damaged by unprofessional or wrong installation, used in contrary to the applicable
instruction manual, used in contrary to legal enactment and common process of use or used for another
purpose which has been designed for.
The product was damaged by uncared-for or insufficient maintenance.
The product was damaged by dirt, accident of force majeure (natural disaster, fire, and flood).
Defects on functionality caused by low duality of signal, electromagnetic field interference etc.
The product was mechanically damaged (e.g. broken button, fall).
Damage caused by use of unsuitable media, fillings, expendable supplies (batteries) or by unsuitable
working conditions (e.g. high temperatures, high humidity, quakes).
Repair, modification or other failure action to the product by unauthorized person.
End-user did not prove enough his right to claim (time and place of purchase).
Data on presented documents differs from data on products.
Cases when the claiming product cannot be indentified according to the presented documents (e.g. the
serial number or the warranty seal has been damaged).
Manufacturer:
FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic
Visit www.sencor.com for detailed information about authorized service centers.
The original version of the instructions is in the Czech language, other language versions are made by the
appropriate translation.
