Before starting your rst session, please make sure to read this manual as it may
explain important operating procedures.
Notes: Each led diode inside with three chips at 1 pc 660nm and 2 pcs 850nm.
Features:
• Portable Infrared & Red Light Therapy
• A great gift for family and friends
• Used for Pain Relief and Muscle Relaxation
• Multifunctional Controller
• Soft Comfortable & Flexible Wrap
• Invisible Infrared Lights
• Benecial for Bones, Joints, and Deep Muscle Problems
• Thick but Lightweight Microplush Fibers
• Designed for Pain Relief, Injury Recovery, and Muscle Relaxation
• Auto Shut-O for 20 minutes with Time Controller
• Safe for All Skin Types
• Upgraded Pulse Function
• Conveniently Plugs into the USB Port
• Friendly Materials to Human Body and Environment.
• 3 LED Chips in One LED Diode
• Can be Equipped with Power Bank
• Wrap cannot be Washed Directly with Water, but can be Cleaned with a Wrung Towel
www.squatz.com
3
What’s in the box:
• (1) KR180 Wrap
• (1) Power Cord
• (1) Adapter
• (1) Portable Pocket
Technical Specs:
• Construction Material: Fabric
• Charging Adapter of the Power Bank: 5V-1A, 12V-3A
• LED PCS: 180 x 0.5W
• LED Chips: 540pcs.
• Power Output: AC 100 - 240 V, DC 12 V, US Plug
• Product Dimensions: 31.5’’ x 6.3’’ x 0.25’’ -inches
The red light device uses combo red 660nm and Infrared 850nm leds which is chosen
to give the ideal wavelengths found in the scientic research of the last three decades.
660nm of red light
This light can be seen by the human eyes and targets skin cells.
850nm of near infrared light
This light cannot be seen by the human eyes and targets deep tissue.
www.squatz.com
4
User Instruction
1. Connecting the wire into each DC port for the wrap with power cord and adaptor.
2. Plug into the AC socket and wait for the button to turn green. Press the power button
to turn the device on. The unit is set to run for 20 minutes before shutting down.
3. Distance: Place directly on skin for best results.
Place anywhere on the body that you suer joint pain.
4. Attach the velcro strap to the device on either side to x it.
5. Select options:
To turn on device, quickly press the power button once and
wait for it to turn green:
a. Press the power button once to turn on all LEDs.
b. Press the power button twice to to activate only the red LEDs (the near infrared
will be o).
www.squatz.com
5
c. Press the power button a third time to activate only the near infrared LEDs (the
red LEDs are now o). NOTE: Infrared light is invisible to the human eye so it may
appear that the LEDs are o when in fact they are on.
d. Press again, and all LED diodes will turn o.
To control LED modes, hold the power button down for more than 3 seconds and
wait for the light to turn blue:
a. Press the power button once to turn all LEDS to pulse mode.
b. Press the power button a second time to turn only the red
LED lights to pulse mode.
c. Press the power button a third time to turn only the near
infrared LEDs to pulse mode.
d. Press the power button a fourth time and all LED diodes will turn o.
6. Usage Frequency: Use device 1-3 times per day for at least 4 weeks, and for a
duration of 20 minutes on one treatment area before moving the device to the
next treatment area.
7. Unplug device and store in cool dry area.
8. Maintenance: For cleaning we recommend using a damp towel or toothbrush to
slightly clean your wrap and elastic strap. Make sure the device is unplugged from
any power, cords disconnected and turned o. Only clean the fabric portion of the
wrap and not the LED diodes directly. Do not submerge the wrap in water.
Allow the wrap to air dry and make sure to keep it out of direct sunlight.
www.squatz.com
6
Benets backed by science
Research shows that wavelengths in the spectrum of 600-900nm help optimal
biotical response.
• Muscle and Joints pain
• Enhanced blood circulation
• Weight loss
• Speed wound healing
• Aging spots and wrinkle removal
• Anti-inammatory
• Hair Re-growth
• Increase collagen
• Decreases pain
