Compatible with all automobile boats and devices
equipped with a 12V DC power source.
Make sure all wiring is away from moving parts.
Do not all wiring near anything flammable after
being used.
After installing lights, make sure to position lamps
and avoid dazzling.
Lighting laws and regulations vary by state. Check
your local laws before using.
Activate
2-year Warranty and get a FREE GIFT
Warranty Certificate
Caution
CO LIGHT official website is a community for you to
connect with us. Here you can share your shopping
experiences , get advice and inspiration , and discover
new exciting products!
All products are under quality warranty for normal usage
within 2 YEARS since the purchasing date.
During use, if you have any questions, please find your
Amazon order and contact us in time. We provide 24
hours service.
You can contact us at this email address:
TO KNOW MORE
SCAN THE QR CODE
Our Service
1.
2.
3.
4.
5.
UTV Side Mirror with Lights
Installation Manual
Mounting The Mirror
Adjusting The Mirror
Mounting The Brackets
Wiring Harness Arrangement
1.
2.
3.
4.
Pass the wiring harness through the
firewall and leave part of the switch
segment in the vehicle.
Pull it through the rubber cable ring and
install it somewhere near the battery so
that the power and ground cables can
be connected.
Install the fusing relay, plug the fuse, and
install the red positive cable directly into
the battery or 12-volt circuit.
Install the negative cable and attach it
to the body ground or battery.
Put the non-slip
rubber on the roll bar.
Loosen the bracket,
adjust the appropriate
width to clip it onto
the cage.
Tighten the two long
screws.
Put the nut and spacer into the
screw of the ball joint
Turn the screw of the ball joint
into the screw hole of the
bracket, and then tighten the
nut
Loosen the screw on the side
of the ball joint.
Tighten the screw after
adjusting to the desired angle.
~
1.75 ~ 2inch tube
1 2 3
1 2
1 2
Parts List
24 Months Warranty
Please try to swap the position of the 2 light, if it work, pls
check the wires connection.
One of the light can't work:
Can't mount the brackets?
If it also can't work, take the picture and let us replace you a
new mirror light.
If your UTV is a profit roll cage, please search for CO LIGHT
mirror light with profit bracket on Amazon.
If the diameter of your roll bar is less than 1.75inch, you can add
a rubber pad to fit it.
If the diameter of your roll bar is larger than 2inch, you can
replace the non-slip rubber with a thinner one.
C
1 2
3
1
2
3
Turn Right/Left
LED Work Lights
Blade Fuse
Automotive
Relay
Switch 1
Switch 2
Battery
Waterproof
Connector
Connect to Positive
Connect to Ground
Connect to Mirror Light
Find your order, contact with us.
We believe that No problem can't be solved
by communication.
