INVERTER GENERATOR
HY6500SEi
Instruction Manual
Introduction
Thank You For Purchasing Your HYUNDAI Product
We work very hard to give all of our customers the best possible service. If you have any
problems, before leaving negative feedback, please contact us to give us a chance to resolve
the issue. We would be delighted if you left us positive feedback! Thank you for purchasing this
product.
Important!
This manual has been produced by Hyundai Power Products and should be kept with the
product. Please read and understand these instructions before you use your product. Failure to
do this may result in personal injury or damage to the product.
The safety precautions and warnings are to ensure your safety and protect you from harm or
damage to the product.
The information contained in this manual was accurate at the time of production, however
HYUNDAI Power Products may make modifications to the product without notification.
WARNING : READ THE INSTRUCTION BOOKLET THOROUGHLY BEFORE
USING THE MACHINE. Keep for future reference and pass it on if the machine is
loaned or sold to another user.
!
Contents
Safety Information.....................................4-15
Symbols On The Machine......................4
Intended Use..........................................5
Understand Your Machine.....................6
Personal Safety...................................6-7
Inspect Your Machine............................7
Work Area..............................................8
During Use.............................................8
Engine Safety.........................................9
Carbon Monoxide.................................10
Electrical Safety....................................11
Batteries...............................................11
Vibrations.............................................12
Noise.....................................................12
Personal Protective Equipment............13
Fuel Safety......................................14-15
Features....................................................16-21
Wiring Diagram.....................................22
Unboxing..............................................23
Pre-Operation Checks.............................24-26
Check Engine Fuel...............................24
Check Engine Oil..................................25
Ground (Earth)......................................26
Connect Battery...................................26
Before Each Use...........................................27
Operation..................................................28-33
Starting The Engine.........................28-29
Using Electric Power.......................30-32
Stopping The Engine............................33
Maintenance.............................................34-41
Maintenance Safety..............................34
Cleaning................................................35
Transportation......................................35
Maintenance Chart...............................36
Engine Oil Replacement.......................37
Air Filter................................................38
Cleaning And Adjusting Spark Plug.....39
Fuel Tank Filter.....................................40
Muffler Screen......................................41
Storage......................................................42-43
Troubleshooting............................................44
Technical Data.........................................45-46
Specification.........................................45
Spare Parts...........................................46
Declaration Of Conformity...........................47
Recycling And Disposal................................48
Notes.........................................................49-51
Our Product Range.......................................52
Useful Information.........................................53
Contact Us.....................................................54
Product Information......................................55
19
4
Safety Information
Symbols On The Machine
We have provided safety messages in this manual and on the machine. This information alerts
you to potential hazards that could hurt you or others. Please read these messages carefully.
However, we may not have listed all of the possible hazards, you must also use your own
judgment.
IMPORTANT
Please read this instruction manual carefully, especially the safety
warnings marked with the symbol. Read and understand
operator’s manual before using the machine. Failure to follow
instructions could result in death or serious injury.
CE SYMBOL
This product complies with the applicable European directives and an evaluation
method of conformity for these directives was done.
CARBON MONOXIDE
Never operate the engine indoor or in areas with
poor ventilation. The exhaust gas from the engine
contains carbon monoxide.
DANGER
Hot surfaces. Keep away from exhaust.
DANGER
Risk of electric shock.
Earthing point.
DANGER
Do nor back feed into the mains supply.
5
Safety Information
The HY6500SEi is a petrol powered inverter generator from HYUNDAI. The HY6500SEi is
powered by a 389cc 4-stroke OHV petrol engine.
The generator is manufactured according to the latest safety requirements. Every precaution is
only effective when it is followed exactly.
User Types
This machine is intended for use by consumers, i.e. non professional operators. The machine is
intended for “DIY” and domestic use only.
Improper Use
Examples of improper use may include, but are not limited to:
- use in a marine environment
- use as permanent sole source of power
Intended Use
For full specification, go to page 45 or visit www.hyundaipowerproducts.co.uk
19
6
Safety Information
Personal Safety
!
• WARNING! Never allow children or people unfamiliar with these instructions to use the
product. Local regulations can restrict the minimum age of the operator.
• Keep children, pets, and other people not using the unit away from the work area. Be alert and
shut off the unit if anyone enters work area. Keep children under the watchful care of a
responsible adult.
• Stay alert, watch what you are doing and use common sense when operating the machine.
Never operate the machine when unwell or tired, or if you have taken alcohol, medicine, drugs or
any substances which may slow your reflexes and compromise judgment. A moment of
inattention while operating the machine may result in serious personal injury.
• Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when operating
or repairing the machine. Always wear anti-slip and resistant work footwear and long trousers
while using the machine. Do not use the machine when barefoot, wearing sandals or similar
lightweight footwear. Do not wear chains, bracelets or clothing that is loose fitting or hanging
ties or cords. Tie long hair back. Always wear protective earplugs. Loose clothes, jewellery, or
long hair can be caught in moving parts. Protect eyes, face, and head from objects that may be
thrown from the unit. Always wear safety goggles or safety glasses with side shields when
operating.
Understand Your Machine
• WARNING! You must read these instructions carefully before operating the machine. Make
sure that you are familiar with the controls and properly operate the machine. You must learn how
to stop the machine quickly. If you do not follow the warnings and instructions, it may result in fire
and/or serious injury. Make sure to save all warnings and instructions for future reference.
• Read this manual and labels affixed to the machine to understand its limitations and potential
hazards.
• Be thoroughly familiar with the controls and their proper operation. Know how to stop the
machine and disengage the controls quickly.
• If the unit is to be used by someone other than original purchaser, or is to be loaned, rented, or
sold, always provide this manual and any needed safety training before operation. The user can
prevent and is responsible for accidents or injuries that may occur to themselves, to other
people, or to property.
• Do not force the machine beyond its limits. Use the correct machine for your application.
• Know how to stop the machine quickly in case of emergency. Understand the use of all
controls.
• ALL MAINTENANCE other than that listed in this manual, should be carried out by
professionally trained and certified personnel.
!
7
Safety Information
• Always keep hands and feet away from all pinch points.
• Do not touch parts that might be hot from operation. Allow parts to cool before attempting to
maintain, adjust, or service.
• Never place any part of your body where it would be in danger if movement should occur
during assembly, installation, and operation, maintenance, repairing or moving.
• Keep in mind that the operator or user is responsible for accidents, hazards or unexpected
events involving the machine that occur to other people or their property. It is the responsibility of
the user to assess the potential risk of the area where work is being carried out. The operator or
user must take all necessary precautions to ensure their own safety and that of others, especially
on slopes or rough, slippery and unstable ground.
Inspect Your Machine
• Check your machine before starting it. Keep guards in place and in working order. Make
sure all nuts, bolts, etc., are securely tightened.
• You must check the general condition of the machine before use.
• Never operate the machine when it is in need of repair or is in poor mechanical condition.
Replace damaged, missing, or failed parts before using it. Check for fuel leaks. Keep the machine
in safe working condition.
• Do not use the machine if the engine’s switch does not turn off the engine when running. Any
petrol powered machine that can’t be controlled with the engine switch is dangerous and must
be replaced.
• If the machine should start to vibrate abnormally, stop the engine and check immediately for the
cause. Vibration is generally a warning sign of trouble.
• Avoid accidental starting. Be sure the engine’s switch is off before transporting the machine or
performing any maintenance or service on the unit. Transporting or performing maintenance or
service on a machine with its switch on invites accidents.
• Do not tamper with or disable safety systems. Only use manufacturer-recommended
attachments.
• Before using, always visually inspect to see that the tools are not worn out or damaged.
Replace worn out or damaged elements and bolts.
• Keep all nuts, bolts and screws tight to ensure the equipment is in safe working condition.
• Keep the machine in good operating condition. Operating the machine in poor or questionable
condition could result in serious injury.
• Be sure all safety devices are in working order and warning labels are in place. These items are
installed for your safety.
!
19
8
Safety Information
Work Area
• You must only work in daylight or with good artificial light in good visibility conditions. Keep
people, children and animals away from the working area.
• Operate on flat, level ground.
• Never park the machine in a place with unstable ground which could give way.
• You must be careful near ravines, ditches or embankments.
• Do not work in the rain or when there is a thunderstorm or lightning risk. If there is bad weather
conditions, do not use the machine.
!
During Use
• WARNING! If something breaks or an accident happens whilst working, you must turn off the
engine immediately and move the machine away to prevent further damage. If an accident
happens with injuries or third parties are injured, carry out the first aid measures most suitable
for the situation immediately and contact the medical authorities for any necessary health care.
Carefully remove any debris that might cause damage or harm persons or animals should it not
be seen.
• Never attempt to move the machine in any way other than intended for normal use while the
engine is running.
• Place the machine in a place where pedestrians or children are not likely to touch the machine.
• Avoid placing any flammable materials near the exhaust outlet during operation.
• Keep the machine at least 1m (3 ft) from buildings or other equipment, or the engine may
overheat.
• Avoid operating the engine with a dust cover.
• Put the machine on the flat ground, for the machine eliminating heat freely.
• Never touch the machine with wet hands or electrical shock will occur.
• Be sure to ground (earth) the generator.
• Do not use in a vehicle.
!
9
Safety Information
Engine Safety
• This machine is equipped with an internal combustion engine. Do not use on, or near,
forest-covered or brush-covered land unless the exhaust system is equipped with a spark
arrester meeting applicable local, state, or federal laws.
• A spark arrester, if used, must be maintained in effective working order by the operator.
• Never start or run the engine inside a closed area. The exhaust fumes are dangerous,
containing carbon monoxide, an odourless and deadly gas. Operate this unit only in a
well-ventilated outdoor area. (See carbon monoxide safety).
• Do not tamper with the engine in an effort to get it to run at higher speeds. The maximum
engine speed is preset by the manufacturer and is within safety limits.
• Keep a fire extinguisher on hand when operating this machine in dry areas as a precautionary
measure.
• Never leave the operating position when the engine is running.
• The engine parts get very hot when running, do not touch. Danger of burns.
• Follow the instructions to ignite the engine carefully whilst keeping feet away from moving
parts.
• Never incline the machine during ignition. Ignite the machine on a flat surface without obstacles
or high grass.
• Do not over-rev the engine or change the engine settings.
• Never pick up or carry the machine while the engine is running.
• Stop the engine whenever you leave the machine, or before refuelling, when cleaning or while
maintaining.
• Reduce the throttle setting during engine shut down and, if the engine is provided with a
shut-off valve, turn the fuel off at the conclusion of working.
• Do not tilt the machine when starting the engine.
!
19
10
Safety Information
Carbon Monoxide
!
CARBON MONOXIDE IS A COLOURLESS, ODOURLESS GAS. INHALING THIS GAS CAN
CAUSE DEATH OR SERIOUS LONG-TERM HEALTH PROBLEMS SUCH AS BRAIN DAMAGE.
Never operate the engine in a confined space where dangerous carbon monoxide fumes can
develop. All ignition operations have to be effected in an open or well-ventilated area. Always
remember that exhaust fumes are toxic.
The symptoms of carbon monoxide poisoning can include but are not limited to the following;
Headaches, dizziness, nausea, breathlessness, collapsing or loss of consciousness.
Carbon monoxide poisoning symptoms are similar to flu, food poisoning, viral infections and
simply tiredness. It is quite common for people to mistake this very dangerous poisoning for
something else.
To avoid carbon monoxide poisoning DO NOT use Petrol/Diesel powered equipment inside any
of the following; Home, garage, tent, camper van, mobile home, caravan or boat. DO NOT use
in an enclosed area or moving vehicle. This is not exhaustive and if you are in any doubt contact
your dealer.
If you think you have or someone around you has been affected by carbon monoxide poisoning;
Get them fresh air immediately, by leaving the affected area or by opening doors and windows. If
safe and practical to do so make sure that the machine is turned off. DO NOT enter a room you
suspect of having carbon monoxide present – instead call the emergency services.
Contact a Doctor immediately or go to Hospital – let them know that you suspect carbon
monoxide poisoning.
!
Engine exhaust fumes contain Carbon Monoxide. This is a poisonous gas and can kill in
minutes. NEVER use inside a building or in an area with poor ventilation. NEVER use inside
a confined space, such as but not limited to a house, garage, vehicle, boat or tent. ONLY
use outside and far away from windows, doors and vents.
DANGER!
11
Safety Information
Electrical Safety (Where Applicable)
!
ELECTRICITY CAN KILL - NEVER WORK ON LIVE/ENERGISED EQUIPMENT.
DANGER!
• Prior to carrying out any maintenance work you MUST identify electrical isolation methods and
isolate all electrical supplies.
• Prior to use and with all electrical supplies isolated, you MUST check all electrical cables, plugs
and connectors for the following;
- Are intact and have no signs of damage, to include but not limited to bare wires, chaffing, cuts
and loose wiring.
- If there are any signs of damage, the damaged item MUST be taken out of service until the
damage has been repaired by an electrically competent person.
- All trailing cables should be routed so as not to cause any kind of trip hazard.
- NEVER work on or near electricity with wet hands, wet clothing and wet gloves.
Batteries (Where Present)
Batteries present a risk if they become damaged by the possible leaking of electrolyte. This
electrolyte is an acid and can cause serious burn injuries. Care should be taken when working on
or near them. NOTE the electrolyte may be in a liquid or gel form.
Should you come in to contact with electrolyte you should;
• Remove all clothing contaminated with
electrolyte. If you cannot remove then saturate them in water.
• Get medical assistance as soon as possible.
You must advise the medical staff of the type of acid.
• Lead/acid battery = dilute sulphuric acid.
• Nickel/cadmium = potassium hydroxide alkali electrolyte.
• Use fresh running water to wash off excess electrolyte, continue this until medical assistance
arrives. Make sure that you do not wash the electrolyte to another part of your body or face.
• If electrolyte comes in to contact with Eyes the electrolyte needs to be immediately washed
away with large amounts of water. Make sure that you do not wash the electrolyte to another part
of your face or body.
• Gasses from charging batteries are highly flammable and great care should be taken to charge
in well ventilated areas.
!
• There is an explosion risk if the battery terminals are short circuited, when
connecting/disconnecting ALWAYS exercise great care so that the terminals or battery
leads are NOT allowed to touch and cause a spark. ALWAYS use suitable insulated tools.
19
12
Safety Information
• Prolonged use of hand held (operated) machines will cause the user to feel the effects of/from
vibrations. These vibrations can lead to white finger (Raynaud’s phenomenon) or carpal tunnel
syndrome. This condition reduces the ability of the hand to feel and regulate temperature,
causing numbness and heat sensations and may cause nerve damage and circulatory tissue
death.
• Not all factors that lead to white finger disease are known, but cold weather, smoking and other
diseases that affect blood vessels and blood circulation as well as large and long-lasting impact
of shocks are considered factors in the formation of white finger. Note the following to reduce the
risk of white finger and carpal tunnel syndrome;
• Wear gloves and keep your hands warm.
• Take regular breaks.
• All of the above precautions may help reduce the risk of white finger disease but not rule out
the carpal tunnel syndrome. Long-term and regular users are therefore recommended to observe
the condition of your hands and fingers. Seek medical attention immediately if any of the above
symptoms should occur.
Vibrations (Where Applicable)
!
• The operating noise of the machine can damage your hearing. When wearing protection such
as earplugs or ear defenders to protect your hearing. Long-term and regular users are advised to
have hearing checked regularly. Be especially vigilant and cautious when wearing ear protection
because your ability to hear alarm warnings will be reduced.
• Noise emissions for this equipment is unavoidable. Carry out noisy work at approved times and
for certain periods. Limit the working time to a minimum. For your personal protection and
protection of people working nearby it is also advisable for them to wear hearing protection.
• See Certificate of Conformity section for Outdoor Noise declaration of conformity.
Noise (Where Applicable)
!
13
Safety Information
Personal Protective Equipment
!
HAND PROTECTION MUST BE WORN
Protective electrically non-conductive gloves are highly recommended when working.
HEARING PROTECTION MUST BE WORN
Suitable safety hearing protection is recommended.
EYE PROTECTION MUST BE WORN
Always wear safety glasses/goggles and/or face shields. Everyday eyeglasses have
only impact resistant lenses; they are not safety glasses/goggles.
FOOT PROTECTION MUST BE WORN
Non-skid heavy duty footwear are highly recommended when working.
PROTECTIVE CLOTHING MUST BE WORN
Do not wear loose clothing, gloves, scarfs, neckties or jewellery
(rings, wrist watches), which can be caught in moving parts.
HEAD PROTECTION MUST BE WORN
Wear a safety helmet with a safety visor.
FACE SHIELD MUST BE WORN
Wear a face shield to protect your face.
RESPIRATOR MUST BE WORN
Wear a respirator.
Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when
operating or repairing the machine. No protective equipment can ensure 100%
protection.
When selecting PPE, make sure it’s CE marked and it suits the user in terms of size, fit, etc. If
more than one item of PPE is worn at the same time, make sure they can be used together, e.g.
wearing safety glasses may disturb the seal of a respirator, causing air leaks.
19
14
Safety Information
Spilled Fuel
• If you have spilled fuel, make sure you do not attempt to ignite the engine but move the
machine away from the area of spilled fuel and avoid creating any source of ignition until the fuel
has evaporated and fuel vapours have dissipated.
• When fuel is spilled on yourself or your clothes, wash your skin and change clothes
immediately.
• ALWAYS clean up spills promptly using absorbent granules and a lidded bin.
Fuel Safety
!
CAUTION! ALL FUELS ARE HIGHLY FLAMMABLE AND PETROL VAPOUR IS
EXPLOSIVE. TAKE EXTREME CARE WHEN HANDLING FUEL. KEEP FUEL OUT OF
REACH OF CHILDREN.
General Safety
• Do not smoke each time fuel is handled.
• ALWAYS avoid inhaling fumes.
• ALWAYS carry fuel in the correct and clearly marked container.
• ALWAYS wear correct, suitable and fit for purpose Personal Protective Equipment (PPE),
suggested items are but not limited to safety gloves and overalls.
• To avoid sparking or arcing, keep grounded conductive objects – such as tools – away from
exposed, live electrical parts and connections. These events could ignite fumes or vapours.
• Do not operate the machine with known leaks in the fuel system.
• Fire hazard - keep fuel away from all sources of ignition for example heaters, lamps, sparks
from grinding or welding.
• DO NOT carry out hot work on tanks that have contained fuel.
• ALWAYS keep the work area tidy.
• ALWAYS dispose of waste fuels correctly.
• Serious personal injury can occur when petrol is spilled on yourself or your clothes. Rinse your
skin and change your clothes immediately.
General Safety
15
Safety Information
• ALWAYS fuel and de-fuel in a well ventilated area outside of buildings. Use a funnel to add fuel,
only outdoors. Do not smoke during this and each time fuel is handled.
• Add fuel before igniting the engine, never remove the fuel tank cap or add fuel whilst the engine
is running or when it is hot.
• When de-fuelling ALWAYS use a proper fuel retriever.
• Never overfill the fuel tank. Engine heat can cause fuel to expand, never fill the tank to more
than 1/2” below the bottom of the filler neck. This will provide space for fuel expansion.
• When refilling or draining the fuel tank, use an approved fuel storage container while in a clean,
well-ventilated outdoor area. While adding fuel or operating the unit, do not smoke, and stay
away from sparks, open flames, or other sources of ignition near the area of operation.
• Always stop the engine and allow it to cool before filling the fuel tank. Never remove the cap of
the fuel tank or add fuel while the engine is running or when the engine is hot.
• Loosen the fuel tank cap slowly to relieve any pressure in the tank.
• ALWAYS keep the handles dry, clean and free of oil and fuel.
• After fuelling, ensure to tighten the cap securely.
• Never use the lock-function when filling with fuel.
Fuelling / De-Fuelling
• Store fuel in containers specifically designed and approved for fuel storage.
• Store fuel in a cool, well-ventilated area, safely away from sparks, open flames, or other
sources of ignition.
• Never store fuel – or a machine with fuel in the tank – inside a building where fumes may reach
a spark, open flame, or any other source of ignition (such as a water heater, furnace, or clothes
dryer). Allow the engine to cool before storing in any enclosure.
• Replace all fuel tank and container caps securely and wipe up spilled fuel. Never operate the
unit without the fuel cap securely in place.
Storage
19
16
Features
HY6500SEi Features
1615
26
25
24 2123 22
17
20
1814
19
27
2
3
4
6
5 7
131211
108
1
9
1 2
3
4
5
6
7
8
9
10
11
12 13
14
15
16
17
1819
20
21
22
23
24
17
Features
Spark Plug
1
Fuel Tank
2
Engine Switch
15
Muffler
7
Brake Lever
10
Air Filter
9
Battery
8
Wheel
11
HY6500SEi Features
Carrying Handle
Fuel Level Gauge
6
5
Fuel Tank Cap
Oil Filler Cap
12
3
Oil Drain Plug
13
Fuel Tap
14
Fuel Filter
4
Economy Control Switch
23
Remote Control
24
DC 12V Receptacle
20
Data Display Instrument
16
AC Receptacle
18
Ground (Earth) Terminal
17
USB Output
19
Output Reset
22
DC Protector
21
19
4
Features
Oil Warning System
When the oil level falls below the lower level, the engine stops automatically. Unless you refill with
oil, the engine will not start again. Check oil level daily to ensure oil level is to the upper mark on
the dipstick.
Engine Switch
The engine switch controls the ignition system.
RUN
The engine can be started.
1
STOP
Ignition circuit is switched off. The engine will not run.
2
START
The starter motor starts the engine.
3
Economy Control Switch
When the economy control switch is turned ON, the engine speed matches the load. The results
are better fuel economy and reduced noise.
STOP
RUN
START
ENGINE
SWITCH
ON
OFF
ECON. SW
18
19
Features
DC Overload Breaker
The DC overload breaker turns off automatically when the load exceeds the generator rated
output.
CAUTION
!
Reduce the load to within specified generator rated output if the DC overload breaker is off.
AC Overload Breaker
If overloaded the breaker button will pop out. Push back in to reconnect AC output power.
NOTE
!
Please reduce the load of generator to ensure that the total load is within the rated power.
RESET
19
4
Features
Remote Control Switch
The remote control switch controls the ignition system.
Push to start.
Push to stop.
Brake Lever
The function of brake lever is preventing generator moving.
Release brake to move generator.
1
Push brake down when in use.
2
Fuel Tap
The fuel tap is used to supply fuel from the tank to the carburettor.
1
2
ON
OFF
20
Push to start.
Push to stop.
21
Features
Data Display Instrument
Normal
Short Circuit
Over Current
Maintenance
High volt of AC output
High volt DC mother line
Low volt of AC output
Low volt of DC output
MCU high temperature with E3 indicated
IGBT high temperature with E4 indicated
Low oil when yellow light on
Defects or overloads when red light on
Normal running when green light on
Mode selections: V1 A1 V2 A2 VA Total Running Time Current Running Time
FAULT
OUTPUT
19
22
Wiring Diagram
Y/G
R
BL
AC OUTPUT
BL
BL
BL
BL
BL
BL
W
W
INVERTER
UNIT
R
PI
BL
BR
GR
P
W
O
R
R
SUB
WINDING
MAIN
WINDING
M
Y
O
PI
Bu
IGNITION
WINDING
OIL SENSOR
DC
WINDING
DC
WINDING
Bu
Bu
Bu
Bu
SPARK PLUG
SPRING WINDING
BATTERY
START MOTOR
1
2
3
4
5
CONTROL PANEL BLOCK
GENERATOR BLOCK
ENGINE BLOCK
ELE VALVE
ELECTRIC MAGNET
ELECTRIC LOCK
GROUND
TERMINAL
BL
Bu
BL/W
W
G
IGNITION
CONTROLLER
ECON. SWITCH
STEPPER MOTOR ASSY.
GRAY
BLACK/WHITE
PI
Gr
PINK
BL/W
ORANGE
YELLOW
O
Y
BL
Bu
BLACK
BLUE
BROWN
RED
Br
R
WWHITE
GGREEN
PPURPLE
W
BL P
W
IGNITION COIL
BL O
R
Y/G
RBL
P
W
Gr
R
BL
Bu
BL
FUSE 5A
O
Y
W
R
BL
O
R
Y
W
BL
Bu
RW
REMOTE+ATS
UNIT
RECTIFIER
DC 12V OUTPUT
Bu
Bu
Bu
Bu
Bu
BL
FUSE 15A
R
DC PROTECTOR 6A
YELLOW/GREENY/G
DC5V OUTPUT
Bu
OUTPUT RESET
U-I-P-Hz-T
R
Y/G
PROTECTOR
16A
PROTECTOR
16A
WGr
1
2
3
ATS
RECEPTACLE
R
Y/G
O
Unboxing
WARNING! Unboxing and assembling the machine should be done on a flat, stable surface
with enough room. Disposal of the packaging should be done in accordance with the local
regulations in force.
Carefully remove the product from the packaging and examine it for any sign of damage caused
during shipping. Lay the contents out and check them. If any part is damaged or missing, you
must not use the machine. Contact HYUNDAI Power Products immediately. You must keep the
packaging material in case the machine needs to be returned or repaired.
WARNING! Some of the packaging material may be harmful to children. Keep out of reach of
children.
Ensure that you have all the accessories and tools you need for assembly and operation including
the suitable personal protective equipment.
Unboxing Safety
!
!
!
• User Manual
• HY6500SEi
Box Contents
23
We recommend that you fill out the information on page 55. If you need to contact an
authorised dealer or customer service for information on servicing, you may need to
provide this information.
There is also a service record so you can keep track of your machine service dates.
19
24
Pre-Operation Check
• Make sure there is sufficient fuel in the tank.
• If fuel is low, refill with unleaded petrol.
• Be sure to use the fuel filter screen on the fuel filter neck.
• Recommended fuel: Unleaded petrol.
• Fuel tank capacity: 18.5L
Check Engine Fuel
Pre-operation checks should be made each time the generator is used.
!
WARNING
!
• Do not refill tank while engine is running or hot.
• Close fuel cock before refuelling with fuel.
• Be careful not to admit dust, dirt, water or other foreign objects into fuel.
• Do not fill above the top of the fuel filter or it may overflow when the fuel heats up later and
expands.
• Wipe off spilt fuel thoroughly before starting engine.
• Keep open flames away.
NOTE - The machine is delivered without petrol. All machines are tested and inspected so there
may be some residual petrol left in the machine so please fill with caution.
Make sure you read the fuel safety section before handling fuel.
25
Pre-Operation Check
UPPER
LEVEL
Make sure the engine oil is at the upper level of the oil filler hole. Add oil as necessary.
Check Engine Oil
• Remove oil filler cap and check the engine oil level.
• If oil level is below the lower level line, refill with suitable oil to upper level line. Do not screw in
the oil filler cap when checking oil level.
• Change oil if contaminated, or after 100 hours use.
Oil Type : SAE 30 or 15w40 Engine Oil
Oil Capacity : 1.1L
NOTE - The machine is delivered without oil in the engine. All machines are tested and inspected
so there may be some residual oil left in the machine so please fill with caution.
19
26
Pre-Operation Check
• Be sure to ground (earth) the generator.
Ground (Earth)
• Loosen the screw and remove the battery cover.
• Clamp the red wire to the positive (+) terminal and the black wire to the negative (-) terminal of
the battery. Do not reverse these positions.
• Be sure the battery is installed on the battery mount tray securely.
• Install the cover and tighten the screw.
• Recommended Battery : 12V18AH.
Connect Battery
27
Before Each Use Checks
Always ensure that the machine is in a safe working condition. Inspect and check safety devices
and guards and check all nuts, bolts and screws are secure.
1
Check the oil level and fill the fuel tank.
2
Make sure you know how to stop the machine and ensure you are familiar with emergency stop.
3
Start the machine following the instructions.
4
YOU MUST read and understand the full safety instruction manual before starting the
machine.
!
CAUTION - For OUTDOOR use ONLY. Petrol machines produce carbon monoxide –
poisonous, colourless and odourless gas that can cause serious injury or death. Petrol is highly
flammable, always handle with extreme care and in a well ventilated area.
!
Before Each Use
19
28
Operation
The generator has been shipped without oil. Fill with oil or it will not start. Do not tilt the
generator when adding engine oil. This could result in overfilling and damage to the engine.
!
Starting The Engine
Before starting the engine, do not connect the electric apparatus.
!
A) Electric Start
Turn the fuel tap to the ON position.
1
ON
Turn the engine switch to the START position until engine starts.
2
START
ENGINE
SWITCH
29
Operation
Release the engine switch to the RUN position.
3
RUN
ENGINE
SWITCH
Warm up the engine without any load for a few minutes.
4
B) Remote Start
Please make sure the fuel shutoff valve to the ON position, the engine switch to the RUN position.
1
Press the button on the remote control (key fob) twice.
2
Please wait 10 seconds and repeat again if it didn’t start.
3
Warm up the engine without a load for a few minutes.
4
RUN
ENGINE
SWITCH
19
30
Operation
Using Electric Power
AC Application
Check the AC pilot lamp for correct voltage.
1
Turn off the switch(es) of the electrical appliance(s) before connecting to the generator.
2
Insert the plug(s) of the electrical appliance(s) into the sockets.
3
WARNING
!
• Be sure the electric apparatus is turned off before plugging in.
• Be sure the total load is within generator rated output.
• Be sure the socket load current is within socket rated current.
• The economy control switch must be turned to OFF when using electric devices that require a
large starting current, such as a compressor or a submersible pump.
OFF
ECON. SW
31
Operation
Overload Indicator Light
Turn off any connected electric devices.
1
The overload indicator light comes on when an overload of a connected electrical device is
detected, the inverter unit overheats, or the AC output voltage rises. The electronic breaker will
then activate, stopping power in order to protect the generator and any connected electric
devices. The overload indicator light (red) will turn on, then the generator will stop output. If so
please follow the following steps:
Reduce the total wattage of connected electric devices within the application range.
2
Check for blockages in the cooling air inlet and around the control unit. If any blockages are
found, remove.
3
After checking, push output reset.
4
WARNING
!
• The generator AC output automatically resets when the engine is stopped and then restarted.
• The overload indicator light may come on for a few seconds at first when using electric devices
that require a large starting current, such as a compressor or a submersible pump. However, this
is not a malfunction.
RESET
19
32
Operation
DC Application (Option)
Charging instruction for battery.
• Disconnect the leads for the battery.
• Loosen the battery fluid filler cap.
• Fill distilled water to the upper limit, if the battery fluid is low level.
1
Connect between the DC output socket and the battery terminals using the charging leads. The
leads shall be connected making sure of the (+) and (-) polarity.
2
The DC circuit protector is to be set to ON after confirming the connection, if the protector is in
OFF position.
3
This usage is applicable to 12V battery charging only.
WARNING
!
• Be sure the economy control switch is turned off while charging the battery. Do not overcharge
the battery.
33
Operation
Stopping The Engine
Turn off the power switch of the electric apparatus or disconnect any electric devices.
1
Turn the engine switch to STOP position. Click remote switch to the position.
2
Turn the fuel cock lever to OFF.
3
STOP
ENGINE
SWITCH
OFF
Maintenance Safety
!
IMPORTANT - Routine and accurate maintenance is essential for maintaining original
machine safety and performance levels.
WARNING - Before cleaning or doing maintenance work, you need to stop the engine,
and read the relevant instructions. You need to wear proper clothing and protective gloves
whenever your hands are at risk.
If there are worn or damaged parts, never use the machine. Faulty or worn-out parts must be
replaced and not repaired. You must only use original spare parts. The use of non-original and/or
incorrectly fitted parts will jeopardize the safety of the machine. This may also cause accidents or
personal injuries for which the manufacturer is under no circumstance liable or responsible.
Any maintenance operations or adjustments not explained in this manual must be carried out
by your Dealer or a specialised Service Centre with the necessary knowledge and equipment to
ensure that the work is done correctly maintaining the machine’s original safety level. Any
operations performed in unauthorised centres or by unqualified persons will invalidate the
Warranty and all obligations and responsibilities of the Manufacturer.
!
!
!
!
19
34
Maintenance
35
Maintenance
CAUTION - DO NOT use a hose pipe or pressure washer to clean the engine. Water can
damage the engine or contaminate the fuel system.
NOTE Engine must be switched off.
!
!
• Make sure not to drip petrol onto the plastic parts to prevent damaging them and remove all
traces of spilt petrol immediately. The warranty will not cover damage to plastic parts caused by
petrol.
• Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from
various types of commercial solvents and may be damaged by their use.
Cleaning
Whenever the machine is to be handled, lifted, transported or tilted, you must:
Transportation
Wear sturdy work gloves.
1
Hold the machine at the points that offer a safe grip, taking into account the weight and
relative distribution of the same.
2
Use an appropriate number of people for the weight of the machine and the characteristics of
the vehicle or the place where it must be placed or collected.
3
You must make sure that machine movements to not cause petrol leaks, damage or injuries.
4
During transport, make sure to fasten the machine securely with cables or straps.
5
The machine must be transported on a flat surface.
6
Do not run this generator in a vehicle or confined space.
7
19
36
Maintenance
Maintenance Chart
Item Remarks Pre-
Operation
Check
(Daily)
Initial 1
Month
or 20Hr
Every 3
Months
Or 50Hr
Every 6
Months
Or
100Hr
Every 12
Months
Or
300Hr
Spark Plug Check condition adjust gap and
clean. Replace is necessary.
X
Engine Oil Check oil level.
Replace.
X X X
Oil Filter Clean oil filter. X
Air Filter Clean. Replace if necessary. X
Fuel Filter Clean fuel cock filter. Replace is
necessary.
X
Valve
Clearance
Check and adjust when engine
is cold.
X
Fuel Line Check fuel hose for crack or
damage. Replace if necessary.
X
Exhaust
System
Check for leakage. Re-tighten
or replace gasket is necessary.
Check muffler screen. Clean /
replace if necessary.
X
X
Carburettor Check operation. X
Cooling
System
Check fan damage. X
Starting
System
Check recoil starter operation. X
Idle Speed Check and adjust engine idle
speed.
X
Fittings /
Fasteners
Check all fittings and fasteners
correct if necessary.
X
Crankcase
Breather
Check breather hose for cracks
or damage. Replace if
necessary.
X
Generator Check the pilot light comes on. X
Routine and accurate maintenance is essential for maintaining original machine safety and
performance levels.
It is recommended that the following maintenance schedule is followed.
37
Maintenance
Engine Oil Replacement
Place the machine on a level surface and warm up the engine for several minutes. Then stop
the engine and turn the fuel cock knob to OFF. Turn the fuel tank cap air vent knob
clockwise, to OFF.
1
Loosen the screw and remove the cover.
2
Remove the oil filler cap and insert tube to drain oil.
3
Place an oil pan under the engine. Tilt the generator to drain the oil completely.
4
Replace the generator on a level surface.
5
Add engine oil to the upper level.
6
Install the oil filler cap.
7
Install the cover and tighten the screw.
8
WARNING
!
• Be sure no foreign material enters the crankcase.
• Do not tilt the generator when adding engine oil. This could result in overfilling and damage to
the engine.
• Clean the oil filter and change oil every other 100hr.
UPPER
LEVEL
Oil Type : SAE 30 or 15w40 Engine Oil
Oil Capacity : 1.1L
19
38
Maintenance
Air Filter
Remove the cover.
1
Remove the air filter cover and element.
2
Wash the element in soapy water and dry.
3
Oil the element with fresh engine oil and squeeze out excess oil. The element should be wet
but not dripping.
4
Insert the element into the air filter.
5
Refit the cover.
6
CAUTION
!
The engine should never run without the
element, excessive piston and/or cylinder
wear may result.
CAUTION - A dirty air filter will restrict the air flow to the carburettor, which will reduce engine
efficiency. When using the machine in very dusty areas you must clean or replace the air filter
more often. Never operate the machine without the air filter being fitted it can cause damage to
the engine which is not covered by warranty.
!
39
Maintenance
Cleaning And Adjusting Spark Plug
Remove the cover.
1
Check for discolouration and remove any carbon.
2
Check the spark plug type and gap.
3
Replace the spark plug.
4
Install the cover.
5
Standard electrode colour : Tan colour
Standard spark plug : F6RTC (TORCH)
Spark plug gap : 0.6mm-0.7mm (0.024-0.028in)
For good performance, the spark plug must be properly gapped and free of deposits.
19
40
Maintenance
Fuel Tank Filter
Remove the fuel tank cap and filter.
1
Clean the filter with solvent. If damaged, replace.
2
Wipe the filter and insert it.
3
WARNING
!
Be sure the tank cap is tightened securely.
41
Maintenance
Muffler Screen
Remove the cover.
1
Remove the muffler screen.
2
Use the flat head screw driver to pry the spark arrester out from the muffler.
3
Remove the carbon deposits on the muffler screen and spark arrester using a wire brush.
4
Install the muffler screen.
5
Install the cover.
6
WARNING
!
• The engine and muffler will be very hot after the engine has been run.
• Avoid touching the engine and muffler while they are still hot with any part of your body or
clothing during inspection or repair.
19
42
Storage
Short Term
After use, please follow the below steps before storing your machine.
Storage
Allow the engine to fully cool down.
1
Clean the machine. See the ‘Cleaning’ section.
2
Store the machine following the guidelines above.
3
Where To Store
!
Store in a cool, dry place away from sources of ignition and varying changes in temperature.
Store on a flat and level surface.
DO NOT stack other items on top of the machine when in storage.
Store the machine in a safe place, out of the reach of children or anyone who is not familiar
with operation.
DO NOT store the machine with fuel in the tank in an area where the fuel vapours could reach
an open flame, a strong heat source or a spark.
DO NOT store a machine that has not been given time to fully cool down. Engine must be
cooled down fully before storage.
!
!
!
!
!
43
Long Term
If storing the machine for a period of 30 days or more, you must follow proper storage and
winterisation guidelines to avoid any possible issues with the machine. Incorrect storage can lead
to possible fuelling or engine issues that will not be covered by the warranty.
Allow the engine to fully cool down.
1
Drain all the fuel from the fuel tank. Remove the cover, drain fuel from the carburettor by
loosening the drain screw.
2
Preparation To Re-Use
Check oil level before using.
1
Check spark plug is inserted correctly.
2
Fill engine with fresh unleaded petrol that has not been stored for periods of more than 30 days.
3
Storage
Remove the spark plug, pour in about one tablespoon of SAE30 or 15W40 engine oil in the spark
plug hole and reinstall the spark plug.
3
Use the recoil starter to turn the engine over several times (with ignition off).
4
Pull the recoil until you feel compression.
5
Stop pulling.
6
Clean exterior of the generator and apply a rust inhibitor.
7
19
44
Troubleshooting
1. Fuel System
No fuel supplied to combustion chamber.
• No fuel in tank - Supply fuel.
• Fuel in tank - Fuel tank cap air vent knob to ON, fuel cock knob to ON.
• Clogged fuel line - Clean fuel line.
• Clogged carburettor - Clean carburettor.
Engine Will Not Start
2. Engine Oil System
• Oil level is too low - Add engine oil.
3. Electrical System
• Spark plug dirty with carbon or wet - Remove carbon or wipe spark plug dry.
• Faulty ignition system - Consult dealer.
4. Compression Insufficient
• Worn out piston and cylinder - Consult dealer.
Generator Will Not Produce Power
• Safety device (AC) to OFF - Stop the engine, then restart.
• Safety device (DC) to OFF - Press to reset the DC protector.
Technical Data
45
Specifications
Model HY6500SEi Inverter Generator
AC Voltage 230V, 240V
Frequency 50Hz
Max. Output 6.6kW
Rated Output 6kW
Power Factor 1.0
DC Output 12V/5.0A 5V/3.1A
Model IC390E
Engine Type Air-cooled, 4 cycle, OHV petrol engine
Bore x Stroke 88 x 64
Displacement 389cc
Max. Output 7.5kW / 3600rpm
Fuel Unleaded petrol
Fuel Tank Capacity 18.5L
Rated Continuous Operation 4hr 30min (100% load)
Lubricating Oil SAE30 or 15W40
Lubricating Oil Capacity 1.1L
Starting System Electric Starter / Remote Starter
Ignition System C.D.I
Spark Plug Type F6RTC
Net Dimension (L x W x H) 750 x 537 x 630mm
Overall Dimension (L x W x H) 825 x 615 x 700mm
Net Weight 89kg
Measured Sound Level 73.69dB(A)
Guaranteed Sound Level 94.76dB(A)
GeneratorEngineOther
Specifications subject to change without prior notice.
19
46
Technical Data
Spare Parts
Part Part Number
Wheel HY6500SEiWHEEL
Spark Plug HY6500SEiSPARKPLUG
Air Filter HY6500SEiAIRFILTER
Recoil Starter HY6500SEiRECOILSTARTER
Engine Oil SAE 30 or 15W40 600MLSAE30OIL
Only use original spare parts: The use of non-original and/or incorrectly fitted parts will jeopardize
the safety of the machine, may cause accidents or personal injuries for which the Manufacturer is
under no circumstance liable or responsible.
47
Declaration Of Conformity
EC Declaration of Conformity
We hereby declare that the machine detailed in this declaration complies to all the relevant
provisions of the following EC directives.
• 2006/42/EC The Machinery Directive
• 2014/30/EU Annex ll Electromagnetic Compatibility Directive
• 2016/1628/EC The Emission of Gaseous and Particulate Pollutants from internal Combustion
engines
• 2000/14/EC Noise Emissions in the Environment by Equipment for use Outdoors.
And is in conformity with the applicable requirements of the following documents:
• EN ISO 8525 13A
• EN ISO 8528-13:2016
• EN ISO 8528-10:1998
Declaration for 2000/14/EC Noise Emissions in the Environment by Equipment for use Outdoors.
Notified Body for EC Directive 2000/14/EC- Intertek Testing Services Hangzhou
Model Type Maximum
Output
Measured
Sound Power
Guaranteed
Sound Power
Rated Output
HY6500SEi Petrol
generator
6.6kW 73.69dB(A) 94.76dB(A) 6.0kW
Product Details:
Brand: Hyundai
Model: HY6500SEi
Description: Petrol generator
Name and address of technical documentation holder and EU distributor:
Genpower Ltd, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW, UK.
Signed by: Roland Llewellin, Managing Director
Date: 01/07/2020
19
48
Recycling And Disposal
We do not offer a takeback scheme for the recovery of Waste Electrical Electronic
Equipment (WEEE) & Batteries. Instead the responsibility to dispose of WEEE and/or
Batteries is passed onto you by us.
So when it becomes necessary to dispose of your machine you must take it to your
local Civic Amenity Site. For further information please contact your local Authority
for disposal advice.
You MUST make sure that all unused oil and fuel is disposed of correctly either beforehand
or at your local Civic Amenity Site.
• Under NO circumstances must any fuel or oil be put down any drains.
• Certain products contain WEEE waste which should not be disposed of in your domestic waste.
• You MUST recycle WEEE in accordance with your local authority or recycling centre.
• Certain products contain batteries which should not be disposed of in your domestic waste.
• You MUST recycle batteries in accordance with your local authority or recycling centre.
• Unwanted packaging and materials should be stored and taken to a recycling centre so it can
be disposed of in a manner which is compatible with the environment.
We are a Member of the VALPAK National Compliance Scheme and our registration number is
RM08660. For further information about disposal please contact your Local Authority.
You can also get more advice and guidance about recycling at the following website
http://www.recycle-more.co.uk
Should you pass this product on to another user either sold or loaned, you MUST pass on this
user manual. This will make sure that all other users can use and maintain this machine safely.
1. Environmental protection should be a priority of considerable importance when using the
machine, for the benefit of both social coexistence and the environment in which we live. Try not
to cause any disturbance to the surrounding area.
2. You must comply with local regulations and provisions for the disposal of packaging, oils,
petrol, filters, damaged parts or any elements which have a strong impact on the environment.
This waste must not be disposed of as normal waste. It needs to be separated and taken to
specified waste disposal centres where the material will be recycled.
3. You must comply with local regulations for the disposal of waste materials after mowing.
4. When disposing, do not pollute the environment with the machine, but hand it over to a
disposal centre, in accordance with the local laws in force.
Recycling And Disposal
Environmental Protection
49
Notes
19
50
Notes
51
Notes
Generators
Leisure Inverter, Petrol, Diesel And Built-In
Motorhome Generators
Pressure Washers
Petrol, Diesel And Electric Pressure Washers
Water Pumps
Submersible, Clean And Dirty Water And
Professional Chemical Water Pumps
Lawnmowers
Petrol, Cordless, Electric, Roller, Self Propelled,
Electric Start And Robotic Lawnmowers
Grass Trimmers And Brush Cutters
Petrol, Cordless, Electric And Wheeled Grass
Trimmers And Brush Cutters
Chainsaws
Petrol, Cordless And Electric Chainsaws
Hedge Trimmers
Petrol And Cordless Hedge Trimmers
Leaf Blowers
Petrol, Electric, Cordless, Backpack And 3 -in-1
Leaf Blowers
Log Splitters
Horizontal, Vertical, Petrol And Electric Log
Splitters
Wood Chippers
Petrol And Electric Start Wood Chippers
Tillers
Petrol Garden Tiller And Cultivator
Earth Augers And Trenchers
Petrol Earth Augers And Heavy Duty Trenchers
Compactor Plates
Petrol Compactor Plates
Cement Mixers
Portable Electric Cement Mixers
If you would like more information on any of
these products, please contact our sales team
on 01646 687880 or visit our website
www.hyundaipowerproducts.co.uk
Mini Dumpers
4-Wheel Drive Mini Dumpers And Tracked
Dumpers
Yard Sweeper
Self Propelled Yard Sweeper Power Brush
Scarifiers
Petrol Lawn Scarifier And Aerator
Stump Grinders
Petrol 4-Stroke Stump Grinders
Welders And Plasma Cutters
MIG, TIG, MMA, ARC Welders And Plasma Cutters
Power Tools And Tool Chests
Electric And Cordless Power Tools And Filled Tool
Chests
Vacuum Cleaners
Wet And Dry Vacuum Cleaners
Engines
Petrol And Electric Start Engines
Battery Chargers / Starters
6V, 12V, 24V Battery Chargers, Jump Starters And
Hydraulic Floor Jack
Air Compressors
Home, Domestic, DIY And Professional Use Air
Compressors
Lighting Towers
Mobile Lighting Towers With Diesel Generators
Portable Power Stations
Camping Power Packs And Solar Chargers
And More
We Are Constantly Expanding Our Range With
New Products
19
52
Our Product Range
53
Useful Information
Check Out Our YouTube Channel
Our videos on YouTube include:
• Unboxing
• Assembly of your machine
• How to service your machine
• Products in use
• ‘How To’ videos
• Product features
Go to www.hyundaisupport.co.uk or search ‘Hyundai Power Products’ in YouTube.
Warranty
Proof of purchase will be required before you make a warranty claim.
Full warranty terms and conditions can be found on the HYUNDAI POWER PRODUCTS website:
www.hyundaipowerproducts.co.uk
Manual Updates
Our manuals are constantly being reviewed and updated. Should you find an error, omission or
something unclear, please contact us for assistance.
We reserve the right to make any modifications without prior notice whenever necessary.
Our latest manuals are also placed online.
All our manuals can be downloaded at: www.hyundaipowerproducts.co.uk
Returning Your Product
If you are returning your product, please contact the dealer for their returns policy.
Leaving A Review
We work very hard to give all of our customers the best possible service. If you have any
problems, before leaving negative feedback, please contact us to give us a chance to resolve the
issue. We would be delighted if you left us positive feedback!
To leave a review, please go to: uk.trustpilot.com/review/hyundaipowerequipment.co.uk
Ordering Spare Parts
Only use original spare parts: The use of non-original and/or incorrectly fitted parts will jeopardize
the safety of the machine, may cause accidents or personal injuries for which the Manufacturer is
under no circumstance liable or responsible.
19
54
Need Help? Talk To Our Experts
Our friendly aftersales team will be more than happy to help you.
Phone
Call our team on 01646 687880, open Monday-Friday 8.30am-5pm.
Email
Online Live Chat
Go to www.hyundaipowerproducts.co.uk
Live chat is open Monday-Friday from 8.30am-5pm.
Post
Genpower Limited, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW, UK.
Contact Us
55
Product Information
Date Of Purchase: ........................................................................................................................
Dealer Name:.................................................................................................................................
Dealer Phone:................................................................................................................................
Model Number:.............................................................................................................................
Serial Number:..............................................................................................................................
As soon as you have purchased the machine, we recommend that you fill out the
following. If you need to contact an authorised dealer or customer service for
information on servicing, you may need to provide the following information.
The model number and serial number can be found on the grey specification sticker on
your machine.
1st Service
Date Of Service..............................
Next Service Due...........................
2nd Service
Date Of Service..............................
Next Service Due...........................
3rd Service
Date Of Service..............................
Next Service Due...........................
4th Service
Date Of Service..............................
Next Service Due...........................
Information
Service Record
Importer:
GENPOWER LTD
Isaac Way, London Road,
Pembroke Dock, UNITED KINGDOM, SA72 4RW
T: +44 (0) 1646 687 880 F: +44 (0) 1646 686 198
www.hyundaipowerproducts.co.uk
Imported/Distributed by Genpower Ltd for The United Kingdom & Ireland
Licensed by Hyundai Corporation, Korea
