Thank you for shopping at Ufree.
If you have any suggestions or questions about our product,please feel
free to send us an email. Ufree attach great importance to the customer
experience. We will help you solve it at the first time.
full size combs a-d. precision comb e.
Ways of replacement and installation
4 length full size trimmer combs
Adjustable precision trimmer comb
4
5
6
7
8
9
10
3mm
6mm
9mm
11
Detachable blade
Press
Press
Push the blades in the direction of the arrow shown in the figure(fig. 1-2)
Remove the heads
Align the protruding part(fig. 3 ②) of the blade with the body groove(fig. 3
①), press the blade in the direction of the arrow(fig. 4)
Install the heads
Lift from the bottom of the combs to remove as picture.(fig. 5-6)
Remove full size trimmer combs
Align the guide comb(3/6/9/12mm) with the head, press down on the bottom
of the guide comb to install.(fig. 7-8)
Install full size trimmer combs
Slide the comb from the top to the bottom of the head, adjustable in 4 levels
from 1-4 mm.(fig. 9)
Install adjustable precision comb
The body trimmer head includes 3mm/6mm
/9mm, slide the head up and down
to adjust the lengths. (fig. 10)
Adjust body trimmer lengths
Press the buttons on both sides and
push forward to remove.(fig.11)
Remove foil head
