OWNER'S MANUAL
VACUUM CLEANER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
A9-SWIFT
MFL71935428
Rev.00_090226
www.lg.com
Copyright © 2026 LG Electronics. All Rights Reserved
Scan the QR code to see the manual.
TABLE OF CONTENTS
This manual may contain images or
content that may be different from the
model you purchased.
This manual is subject to revision by the
manufacturer.
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE...........................................................3
WARNING............................................................................................................3
CAUTION ...........................................................................................................10
INSTALLATION
Product Overview.............................................................................................11
Installing the Charging Station ......................................................................14
Storing the Accessories ...................................................................................14
Charging the Battery .......................................................................................15
OPERATION
Getting Started .................................................................................................17
Using the Nozzles and Tools...........................................................................18
MAINTENANCE
Cleaning the Appliance ...................................................................................20
Cleaning the Nozzles .......................................................................................22
TROUBLESHOOTING
Before Calling for Service................................................................................25
3
SAFETY INSTRUCTIONS
ENGLISH
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
The following safety guidelines are intended to prevent unforeseen
risks or damage from unsafe or incorrect operation of the appliance.
The guidelines are separated into ‘
WARNING
’ and ‘
CAUTION
’ as
described below.
Safety Messages
WARNING
WARNING
• To reduce the risk of explosion, fire, death, electric shock, injury or
scalding to persons when using this product, follow basic
precautions, including the following:
Technical Safety
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
This symbol is displayed to indicate matters and
operations that can cause risk. Read the part with this
symbol carefully and follow the instructions in order to
avoid risk.
WARNING
This indicates that the failure to follow the instructions can
cause serious injury or death.
CAUTION
This indicates that the failure to follow the instructions can
cause the minor injury or damage to the product.
4
SAFETY INSTRUCTIONS
responsible for their safety. Children should be supervised to ensure
that they do not play with the appliance.
• Do not allow the appliance to be used as a toy. Close attention is
necessary when used by or near children.
• Do not allow children to play with or hang on the appliance.
• Do not use the appliance with damaged power cord or plug. The cord
must be replaced. If the appliance is not working as it should, has
been dropped, damaged, left outdoors, or dropped into water, return
it to an LG Electronics service centre.
• Do not pull or carry by cord, use cord as a handle, close a door on
cord, or pull cord around sharp edges or corners. Do not run
appliance over cord. Keep cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the
cord.
• Place the cords from other appliances out of the area to be cleaned.
Battery
• Never use the battery, adapter, and the charging station from other
appliances with this appliance. Use only the battery and the charging
station provided by LG Electronics.
• Never use the battery, adapter, and the charging station from this
appliance with other appliances.
• Unplug the power cord and remove the battery if the appliance will
not be used for an extended period of time.
• Do not use modified or damaged batteries.
• Do not disassemble, remove or short-circuit the battery.
• When disposing of the battery or the appliance, remove the battery
from the appliance and safely dispose of it.
• Have specifically designated battery packs replaced when it is no
longer able to hold a charge.
• Refer to the
Charging the Battery
section instructions for the
method of replacing the battery.
5
SAFETY INSTRUCTIONS
ENGLISH
• When disposing of this appliance, follow regulations for disposal of
rechargeable lithium-ion batteries.
• Follow all local ordinances and regulations when handling or
disposing of the battery.
• Prevent unintentional starting. Ensure the switch is in the off position
before connecting to the battery pack, picking up or carrying the
appliance.
• Disconnect the battery pack from the appliance before making any
adjustments, changing accessories, cleaning, serviing, or storing
appliance.
• When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small metal
objects, that can make a connection from one terminal to another.
• Under abusive conditions, liquid may be ejected from the battery. If
this happens, avoid contact. If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally seek medical help.
• If the appliance is to be stored unused for a long period, the batteries
should be removed.
• Before removing the battery, you must turn off this appliance.
• When fitting the battery into the product body, insert it completely
until it clicks.
Battery Specifications
•
Model Name
: VC-2339-5S1P
•
Type
: Rechargeable Lithium-ion Battery
•
Rated Capacity
: 2500 mAh
Installation
• To avoid an electrical shock or fire, do not install, charge or store the
appliance where it may be exposed to water, rainfall or high
humidity.
• Install, charge and store the appliance in a well-ventilated place.
6
SAFETY INSTRUCTIONS
• Avoid operating the appliance in areas where there is a risk of
leakage of flammable gas, industrial oil or metallic dust.
• Do not store or install the appliance, power cord or plug near heating
devices or open flames.
• Install the charging station on a firm, level surface.
• Do not use or store the appliance at temperatures below 5 ℃ or
above 38 ℃.
• Do not store or install the appliance where it is exposed to
temperatures below freezing or exposed to outdoor weather
conditions.
• When installing or moving the appliance, be careful not to pinch,
crush, or damage the power cord or plug.
• Use the anchoring screws only when attaching to concrete or similar
solid surfaces.
• Never drill into a wall without first checking that the area behind it is
free from power conduits, plumbing, vents, or cables.
Operation
• Read all instructions before using the appliance, and save these
instructions.
• Use only as described in this manual. Use only manufacturer’s
recommended attachment.
• This appliance is designed for normal indoor domestic use only. It is
not to be used for any non-residential, commercial, or industrial
application.
• This product should only be used with a 100 - 240 V~ 50/60 Hz outlet.
Make sure to check the power specifications of the place where you
intend to use the appliance.
• Do not handle the power cord, plug, or appliance controls with wet
hands.
• Wipe any moisture or dirt off the cord or plug with a dry cloth.
• Never attempt to operate this appliance if it is damaged,
malfunctioning, partially disassembled, or has missing or broken
7
SAFETY INSTRUCTIONS
ENGLISH
parts, including a damaged cord or plug. Take it to an authorized LG
Electronics service centre or dealer for assistance.
• Do not apply excessive force to the power cord to bend it, or place it
under a heavy object as this will damage it.
• Do not use multiple-outlet adapters with this appliance. Make sure to
use a power socket with a capacity of 10 A.
• Do not plug the appliance into a damaged or loose outlet.
• Make sure to unplug the power cord when the appliance is not to be
used for an extended period of time.
• Do not damage, alter, excessively bend, twist, pull, pinch or heat the
power cord.
• Before using the appliance, remove any wire or string on the floor.
• Avoid touching the prongs of the power plug with your finger(s) when
unplugging the power cord.
• Do not cover the power cord with a rug or carpeting.
• Push the power plug firmly into the wall outlet so that it is not loose.
• If the product has been submerged, contact an LG Electronics service
centre or dealer for instructions before resuming use.
• If the product makes a strange noise or emits an odour or smoke,
discontinue use and contact an LG Electronics customer information
centre.
• Only qualified technicians or service personnel from LG Electronics
may disassemble, repair or modify the appliance.
• Never insert a sharp metallic object such as a pin, nail or knife in a
hole or gap in the appliance or the charging station.
• Do not vacuum liquids with this appliance. Make sure that no water,
beverage or detergent gets inside the appliance or the charging
station.
• Do not allow the appliance to sweep up blades, thumb tacks,
sawdust, sharp objects, or hot or cold ashes.
• Do not allow children to use the appliance.
• Do not let children or pets get close to the appliance when using,
charging or storing.
8
SAFETY INSTRUCTIONS
• Do not insert the nozzle or tools in your mouth.
• Keep clothing and hair, fingers, or other parts of the body away from
openings and moving parts.
• Do not operate the appliance with the suction inlet or outlet blocked.
• Do not use the appliance without the dust bin and filters in place.
• Do not use in an enclosed space where vapors are present from paint
thinner, mothproofing substances, flammable dust or other
explosive or toxic materials.
• Do not touch the charging terminals on the appliance or the charging
station, or insert an electrified object inside the appliance or the
station.
• Always store the appliance on the floor standing or wall-mounted
charging station when it is not in use.
• Do not lean the appliance on walls, chairs or tables.
• If the earth leakage breaker is tripped when the product is put on the
charging station, immediately remove the appliance from the
charging station. Contact an LG Electronics customer service centre.
• Use extra care when cleaning on stairs.
• Do not use or store a heating device or flammable substance(ether,
benzene, alcohol, chemicals, combustible sprays, insecticide, air
freshener or cosmetics) in close proximity to the appliance.
• Do not attempt to clean up a liquid substance (water, beverage),
odourous substances (candy, chocolate, pet excrement), metallic
objects (blades, pins), flammable substances, burning/
smoking(cigarettes, matches, or hot ashes), surfactants, or glass
shards with this appliance.
• In the event of a gas leak(natural gas, propane gas, etc.), do not
operate this or any other appliance. Open a window or door to
ventilate the area immediately.
• Do not hold the charging station upside down with the battery in the
charging station.
• Do not expose the appliance, and the battery in particular, to heat, a
heating device or direct sunlight.
9
SAFETY INSTRUCTIONS
ENGLISH
• Do not keep the appliance or its battery inside a vehicle which is
exposed to direct sunlight.
• Never allow any water, beverage or detergent to get inside the
battery.
• Do not apply physical impacts to the battery.
Maintenance
• Make sure to unplug the power cord when cleaning or maintaining
the charging station.
• Do not wash the inlet port or the dust bin with water or detergent.
• Do not use detergents, polishes or air fresheners to clean the dust
bin.
• Do not apply or spray a flammable substance (gasoline or thinner) or
surfactants (detergent or bath soap) on the appliance.
• Wash hands after handling nozzles. The nozzles contain carbon fiber,
and contact may cause minor skin irritation.
Disposal
• Keep packing materials out of the reach of children. Packaging
materials can pose a suffocation risk for children.
• Destroy the carton, plastic bag, and other packing materials after the
appliance is unpacked. Children might use them for play. Cartons
covered with rugs, bedspreads, or plastic sheets can become airtight
chambers.
• Dispose of this appliance according to local, state, and regional laws
and regulations.
• Contact your local city council or the related government authority
before disposing of this appliance.
10
SAFETY INSTRUCTIONS
CAUTION
CAUTION
• To reduce the risk of injury to persons, malfunction, or damage to the
product or property when using the appliance, follow basic safety
precautions, including the following:
Operation
• This appliance has a built-in safety device to prevent damage from
overheating. If the appliance becomes overheated after extended
use, it may automatically turn off. If this occurs, leave the appliance
in a cool, well-ventilated area for about an hour before turning on the
power again.
• Do not subject the product to shocks or drop it.
• Do not install wet or damp filters.
• Always use a soft cloth to clean the appliance. Do not clean the
product with a volatile or organic solvent(thinner or acetone).
• Do not clean the same spot repeatedly for an extended period of
time. Doing so may damage the carpet or flooring surface.
• Keep fingers away from pinch points when assembling the appliance
or the charging station.
• Do not use the double-sided tape to anchor the charging station on
wallpaper. Use the provided screws to anchor the charging station.
The weight of the charging station and the appliance could damage
the paper.
• Do not apply force or any impact to the Dust bin Filter.
• Do not remove the battery during operation.
11
INSTALLATION
ENGLISH
INSTALLATION
Product Overview
The images in this guide may be different from the actual components and accessories, which are subject
to change by the manufacturer without prior notice for product improvement purposes.
Front View
a
Battery
b
Crevice Tool
c
Combination Tool
d
Tool Holder
e
Charging Station
f
Product Body
g
Fixed Pipe
h
Nozzle
i
Charging Station Support
j
Exhaust Filter
k
Micro Filter
l
Dust bin Filter
*2
*1 This feature is only available on some models.
12
INSTALLATION
*2 The Dust bin Filter refers to a combination of a Metal Mesh Filter and 2nd Turbo Cyclone.
Accessories
Included Accessories
a
Fixed Pipe
b
Battery
c
Charging Station
d
Charging Station Support
e
Allen Key
f
Charging Station Screws
g
Tool Holder
h
Cleaning Brush
Basic Accessories
a
Crevice Tool
b
Combination Tool
Nozzles
a
Slim Carpet Nozzle
NOTE
• The batteries, exhaust filter and the micro filter
will eventually need to be replaced. Contact an
LG Electronics customer service centre.
13
INSTALLATION
ENGLISH
Specifications
Appliance
• Dimensions are given for the assembled product body, pipe and nozzle.
• Battery run time is the result of using a fully charged battery according to the LG Electronics test
standard. Results may be different depending on actual use environment and period of use.
Power Supply Unit
Model
A9-SWIFT
Dimensions
(Width X
Depth X Height)
251 mm x 215 mm x 1112 mm
Weight
Approximately 1.88 kg
Battery Run Time
(Using one battery)
Using with the Nozzle
Up to 6 minutes in
Turbo Mode
Up to 15 minutes in
Power Mode
Up to 30 minutes in
Normal Mode
Using without the Nozzle
Up to 7 minutes in
Turbo Mode
Up to 20 minutes in
Power Mode
Up to 40 minutes in
Normal Mode
Model
ZD012M220075AU
Input
100 - 240 V~ 50/60 Hz, 0.5 A
Output
DC 22.0 V 0.75 A
14
INSTALLATION
Installing the Charging
Station
Self-Standing Installation
WARNING
• Install the charging station on a level surface so
that it does not tip over.
• Supervise children or pets to avoid the product
and its charging station from tipping over.
CAUTION
• When assembling the product or charging
station, be careful not to pinch your fingers.
• Be careful not to drop the accessories when
taking them out of the packaging box.
• Use wall screws only for solid walls, such as
concrete walls.
Be Sure to Follow the Steps below for
the Charging Station
1
Mount the charging station
d
to the charging
station support
c
.
2
Use the included screws
b
and allen key
a
to
assemble the charging station and charging
station support.
• Assemble according to the triangular
assembly guide on the charging station and
the charging station support.
CAUTION
• When assembling, be careful not to let the
charging adapter wire get caught between the
charging station and the charging station
support.
Storing the Accessories
Storing the Tools
Store the frequently used tools such as the
combination tool and crevice tool attached to the
charging station.
1
Insert tool holder into the hole above the
charging station. The tool holder can be
assembled in 3 directions.
15
INSTALLATION
ENGLISH
2
Insert the accessory tools into the holder.
Assembling the Appliance
Follow these steps to safely assemble the
appliance.
1
Assemble pipe
c
and floor nozzle
d
onto the
main unit
a
.
• To remove the pipe, press and pull down the
pipe release button
b
.
2
Align the product with the bottom groove
a
of
the charging station.
• When the vacuum cleaner is successfully
placed into the charging station it will emit
an audible chime and the battery status bar
will flash briefly. if the chime is not heard,
then lift the vacuum cleaner from the
charging station then lift it from the
charging station and refit it again properly.
Charging the Battery
Before Charging the Battery
• Make sure that the adapter is connected to both
the charging station and the power outlet.
• Fully charging a single battery usually takes 4
hours.
• The battery will not be charged if the indoor
temperature is below 5 ℃. Only charge the
battery when indoor temperatures are between
5 ℃ and 38 ℃.
• The battery will eventually need to be replaced.
Due to the battery characteristics, runtime is
shortened after using the appliance repeatedly
for an extended period.
Charging the Product Body
Storing the appliance on the charging station
automatically recharges the battery.
1
Press the
Power
button to turn the appliance
off.
2
Align the product with the groove at the
bottom of the charging station
a
.
• Lower the cleaner into the charging station.
When the cleaner is successfully placed into
16
INSTALLATION
the charging station it will emit an audible
chime and the battery status bar will flash
briefly. if the chime is not heard, then lift the
cleaner from the charging station then lift it
from the charging station and refit it again
properly.
• When charging is complete, the battery level
indicator
c
will turn off.
WARNING
• Make sure to securely fit the product body onto
the charging station. If the appliance falls off the
charging station, it could cause injuries, property
damage or product damage.
17
OPERATION
ENGLISH
OPERATION
Getting Started
Before Using the Appliance
• Support the bottom of the appliance when
cleaning an elevated surface.
• To avoid scratches on polished floors, keep tools
and the brushes and rollers of the nozzles free
from hair, grit, sand, or abrasive objects.
• Make sure that the exhaust filter or micro filter is
properly assembled before using the appliance.
• Close the dust bin cover properly before using
the appliance. If the dust bin cover is left open,
the suction strength may deteriorate and affect
the cleaning results.
• Store the appliance in the charging station or
place it flat on the floor when not in use. Leaning
the appliance against a wall or chair can result in
product damage or personal injury if the
appliance falls.
• Environmental conditions such as temperature
and humidity may cause static electricity to
accumulate on the appliance. Please contact LG
Electronics customer information centre if the
problem persists.
• Make sure to remove any foreign object such as
a sock or stocking before using the appliance.
Any foreign object on the inlet port or fixed pipe
will prevent the appliance from functioning
properly.
• Please use the product at normal room
temperatures as the battery runtime may
deteriorate severely if used at temperatures
lower than 5 ℃ or higher than 38 ℃ for an
extended period of time.
• The battery runtime is dependent on the surface
type and the suction power.
• Follow manufacturer’s recommendations when
cleaning flooring, carpets, and rugs.
• Refer to the
Specifications
section for battery
runtime details.
Assembling Attachments
Nozzles and tools can be attached to either the
product body or the end of the fixed pipe.
1
Insert the fully charged battery
a
into the
cavity at the bottom of the handle on the
product body and push the battery until it
clicks.
• If it is not properly inserted, the battery may
fall out, causing product to malfunction or
personal injury.
2
Attach the nozzles, tools, or fixed pipe by
sliding them onto the inlet
b
on the body until
they click into place. The nozzles and tools can
also be attached to the end of the fixed pipe
b
.
• Detach the accessories by pressing the
release button
c
.
3
Press the
Power
button to activate the
Normal
mode.
• To turn off the appliance, press the
Power
button again.
18
OPERATION
Control Panel Features
a
Power
Button
• Press the
Power
button to turn the appliance
on or off.
• When turned on, it operates in
Normal
mode.
b
Increase suction (+) button
• Press the (+) button to increase suction
power. The below 3 suction power modes are
available.
Normal
~
Power
~
Turbo
mode.
c
Reduce suction (-) button
• When you press the (-) button, the suction
power changes from
Turbo
~
Power
~
Normal
mode.
d
Battery Level Indicator
• The corresponding icon indicates the
remaining battery capacity during use and
also turns off when charging is complete.
e
Filter cleaning interval reminder light
• If you use the product for more than a certain
amount of time, the icon will light up. Check
the micro filter, exhaust filter, and dust bin
filter and clean if necessary.
f
Foreign matter clogging indicator lamp
• If the inside of the product, pipes, suction
parts, inlets, micro filters, exhaust filters, etc.,
are blocked by foreign objects, the icon will
light up.
• If the foreign matter clogging persists, the
appliance will switch off and a Foreign matter
clogging notification will sound. Remove any
debris that may be lodged in the pipe and
clean the micro filter, exhaust filter, and dust
bin filter.
Using the Nozzles and
Tools
Before Using the Nozzles and
Tools
Some accessories are only available on some
models.
Specialized attachments can help you clean more
effectively. Tools and nozzles can be attached to
the product body or the fixed pipe.
• Adjust the suction power if the inlet gets stuck on
the floor, carpet, or bedding.
• Each Nozzle is equipped with a motor and may
make a sound when operating.
CAUTION
• Do not use the
Hard Floor Power Drive Nozzle
on PVC or polyurethane mats for infants and
children. The mat may stick to the nozzle,
making it difficult to operate, causing damage to
the mat or static electricity on the appliance.
Clean mats using the crevice tool.
Hard Floor Power Drive Nozzle
Use the Hard Floor Power Drive Nozzle for hard
floors. it is not suitable for mats rugs or carpets.
• Do not push the
PUSH
button on the floor power
nozzle during use as the rotating brush will
detach and may cause damage or injury. It
should only be pressed for cleaning purposes
and when the nozzle is detached from the
cleaner.
Crevice Tool
Use this tool to remove dust from corners or
narrow spaces.
• Use it for areas with static electricity such as
mats.
19
OPERATION
ENGLISH
• Use it with the
Turbo
mode to clean pet hair out
of furniture, mats, or tight areas like corners.
Combination Tool
Can be used in either crevice mode or brush mode
for cleaning corners or small gaps where dust and
dirt gather.
Crevice Mode
Use the tool in the crevice mode to clean flat
surfaces such as sofas or mattresses.
Brush Mode
Use the tool in the brush mode to clean delicate
surfaces such as frames or furniture.
• To convert modes, press the adjustment button
a
and push forward.
20
MAINTENANCE
MAINTENANCE
Cleaning the Appliance
Before Cleaning the Appliance
To maintain the optimum suction power, the dust
bin filter, the exhaust filter and the micro filter
should be cleaned regularly and washed under
running water at least once a month.
• Turn off the power before cleaning the
appliance.
• The frequency of cleaning varies depending on
the usage environment and usage time. In a
dusty environment, clean frequently.
WARNING
• Never wash the Nozzle, rotating brush or
product body with water. Water could reach the
motor and cause electric shock or fire.
• Do not use the cleaner without any of the filter
fitted as this will allow foreign objects to enter
the motor. Doing so may cause electric shock,
fire or product damage.
• Do not insert fingers or sharp objects into the
motor. Doing so could cause product damage,
personal injury or electric shock.
CAUTION
• Do not apply force or allow impacts to the dust
bin filter. Doing so could deform the filter,
compromise product performance, or cause the
product to malfunction.
Removing Foreign Objects
In order to maintain product performance, be sure
to remove any foreign objects and dust from inside
the product body, fixed pipe or air inlets.
• Foreign materials inside the product can cause
the product to be noisy, have poor suction, or
shut down during operation.
• If the inside of the product body, fixed pipe,
inlets, micro filter, or exhaust filter is clogged
with foreign objects, the power will surge
(alternating from Hi to Lo power) a few times to
alert you to the blocked airflow. The appliance
will then automatically turn off to prevent
damage.
Separate the battery from the product body and
remove the foreign objects before resuming use of
the appliance.
Cleaning the Dust Bin
Empty and clean the dust bin after every use.
• If the dust bin is completely full of dust or the
filter is clogged, the suction power will be
reduced.
1
Remove the battery from the product body
before cleaning the dust bin.
2
Push down dust bin cover release button
a
to
open the dust bin cover and empty the dust
bin.
• Empty the dust bin into a larger waster bin.
21
MAINTENANCE
ENGLISH
• For less dust, the dust bin can first be
emptied into a plastic or paper bag before
disposing the bag into a waste bin.
3
Rotate the dust bin filter
b
counterclockwise to
detach it.
• When the dust bin filter is removed, the
micro filter
c
should be attached to the dust
bin filter. If it is not attached with the dust
bin filter then, check the inside of the
vacuum cleaner and take it out by hand.
4
Remove dust from the dust bin filter and micro
filter and wash with water at least once a
month.
• If there is any stubborn dust left in the dust
bin filter, soak it in lukewarm water (about
40°C) for 30 minutes and then gently clean it
with a brush before rinsing it again.
• Never tap or hit the dust bin filter against
any surface as it will damage.
• Allow all the filters to dry in a well-ventilated
area out of direct sunlight for at least 24
hours before reassembling.
• Any remaining moisture or undried filters
may cause odour or severe damage to the
suction motor.
5
Use the cleaning brush
d
to remove the dust
inside the dust bin.
WARNING
• Never wash the product body with water. Water
could reach the motor and cause electric shock
or fire.
• Do not use the product body to suck up oils or
any liquids, including water.
• Do not use the appliance without the dust bin
filter and micro filter installed. Doing so could
damage the product.
• Do not insert fingers or sharp objects into the
motor to avoid product damage, personal injury,
or electric shock.
• Do not allow foreign objects to reach the motor
to avoid product damage, explosion or fire.
22
MAINTENANCE
CAUTION
• Do not apply force or allow impacts to the dust
bin filter. Doing so could deform the filter,
compromise product performance, or cause the
product to malfunction.
Cleaning the Exhaust Filter
1
Remove the battery from the product body.
2
Rotate the exhaust filter
a
counterclockwise to
the open position
b
to remove it from the
product body.
3
Use the cleaning brush
c
to clean the dust
from the motor exhaust area.
• To prevent fire or permanent product
damage, do not wash the body of the
product with water as the suction motor is
directly under the filter.
4
Dust off the filter and wash with water at least
once a month.
• After washing the filter with water, allow it to
dry completely in a well-ventilated area out
of direct sunlight for at least 24 hours before
reassembling. Any remaining moisture may
cause odor or damage to the motor.
5
Align the exhaust filter to the open position
and rotate clockwise to the locked position
d
to assemble it onto the product body.
CAUTION
• Do not use the appliance without the exhaust
filter installed. Doing so could result in product
damage.
Cleaning the Nozzles
Clean the nozzle and rotating brush regularly.
CAUTION
• Always separate the nozzle from the product
body or remove the battery before cleaning. If
the nozzle starts to operate during cleaning, it
could cause an injury.
23
MAINTENANCE
ENGLISH
• Keep fingers away from pinch points when
assembling the nozzle on the appliance or the
rotating brush on the nozzle.
• Do not use the rotating brush as a wet mop. It
may cause product damage.
• Do not rinse or submerge the rotating brush or
nozzle in water. It may cause product damage.
Cleaning the Slim Carpet Nozzle
Clean the brush and roller heads before each use.
• If the brush contains foreign objects, the brush
may not spin or a noise may occur during
operation.
1
Press the nozzle release button
a
to remove
the nozzle from the pipe or product body.
2
Turn the nozzle upside down and remove the
rotating brush while holding down the
PUSH
button on the nozzle.
NOTE
• When removing the rotating brush from the
nozzle, part of the edge of the rotating brush
may detach. Reassemble the rotating brush by
holding the rotating brush and the detached
part of the edge and pushing them in until a click
is heard.
3
Attach the crevice tool to the product body and
use the vacuum to remove foreign objects and
dust from the brush and the bottom of the
nozzle.
4
Use a damp towel or cloth to remove any
remaining foreign objects and dust from the
brush and the bottom of the nozzle.
• Do not wash the rotating brush and the
nozzle with water or immerse them in water.
• Wrap the handle of the cleaning brush with
a wet towel or cloth and use it to clean the
rotating brush and nozzle.
24
MAINTENANCE
CAUTION
• Ensure all foreign objects are removed from the
nozzles when performing a clean. Foreign
objects left in the nozzle may cause damage to
product and surfaces.
5
When holding both ends of the rotating brush
and pulling it out, the rotating brush and part
of the edge will separate. If hair is wrapped
around the edge of the rotating brush, remove
the rotating brush and clean it.
6
Reassemble the rotating brush and the part of
the edge and insert the end of the rotating
brush into the groove at the end of the nozzle.
7
Slide the brush back into the nozzle until it
clicks into place.
25
TROUBLESHOOTING
ENGLISH
TROUBLESHOOTING
Before Calling for Service
Operation
Symptoms Possible Cause & Solution
The appliance does not
operate.
Battery is fully discharged.
• Charge the battery.
Appliance is turned off.
• Press the
Power
button to turn on the appliance.
Suction power is too
weak.
Dust bin is full of dust.
• Empty the dust bin.
Filters are clogged.
• Clean the micro filter and the exhaust filter.
Inlet is clogged.
• Remove any foreign objects from inside the product body or the fixed pipe.
Foreign object is on rotating brush, or in inlet port.
• Remove any foreign objects (thread, hair) from the rotating brush or the
inlet port.
The product body does
not appear to be
charging.
Power cord is unplugged.
• Plug the power cord securely into the outlet
Foreign object is on the charging terminals.
• Remove dirt or foreign objects from the charging terminals with a dry
cloth.
Hot air is coming from
the product body.
Motor is cooling.
• If the appliance is running normally, the hot air is a result of the motor
cooling and is not a sign of malfunction.
A strange odour is
coming from the
appliance.
Appliance was purchased within the last 3 months.
• The cleaner may emit a smell of rubber for about 3 months after purchase.
Dust bin is full of dust.
• The dust in the bin may cause some odour. Empty the bin and clean it.
Foreign object is on the filter.
• The filter may emit an odour if it has not been cleaned for some time. Clean
the micro filter and exhaust filter regularly.
26
TROUBLESHOOTING
A strange odour is
coming from the
appliance.
micro filter, Exhaust Filter or the dust bin filter were installed while
damp or wet.
• Wash the filters with running water. To avoid odour, allow the filters to dry
completely in a well-ventilated area out of direct sunlight for at least 24
hours before reassembling.
The appliance makes
too much noise.
Vacuum cleaner is running in Turbo mode.
• The motor may be louder at the higher suction power settings. This is
normal.
The appliance turns off
unexpectedly or by
itself after the motor
speed fluctuates
repeatedly.
Battery is not fully charged.
• The battery must be fully charged before cleaning. If the problem persists
when the battery is fully charged and the fixed pipe and attachments are
clear from obstructions, contact an LG customer information centre for
service.
Foreign object is in the product body, fixed pipe, inlet port or nozzle.
• Remove any foreign objects from the product body, fixed pipe, inlet port
or nozzle.
Filters are clogged.
• Clean the micro filter and the exhaust filter.
The rotating brush
does not rotate.
Brush is improperly installed.
• Remove the brush, clean it if necessary and attach it again.
Foreign object is on rotating brush.
• Remove any foreign objects from the rotating brush.
Symptoms Possible Cause & Solution
Memo
