EN
CORDLESS HAND BLENDER
Translation of the original manual
SHM 9000WH
SHM 9001GY
SHM 9000WH
SHM 9001GY
A
9
2
3
4
5
7
6
8
10 11
1
B
2
3
1
- 1 -
06/2023
2023,
EN Cordless hand mixer
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
General warnings
• This appliance may not be used by children. Keep the
appliance and its power cord away from children.
• The appliance may be used by persons with reduced
physical, sensory or mental capabilities or with alack of
experience and knowledge, if they are supervised or have
been instructed to use the appliance in asafe manner and
understand the potential dangers.
• Children must not play with the appliance.
• Cleaning and maintenance performed by the user must
not be performed by unsupervised children.
• In the event that the power cord is damaged, have it
repaired at aprofessional service centre to prevent causing
adangerous situation. It is forbidden to use the appliance if
it has adamaged power cord.
Attention:
Incorrect use may lead to injuries.
• Be careful when handling and cleaning the attachments.
• The surfaces of the appliance that come into contact with
food must always be cleaned according to the instructions
in this user'smanual.
- 2 -
06/2023
2023,
• Always turn off the appliance and disconnect it from
the power supply if you will not be using it and if you
will be leaving it without supervision, before assembly,
disassembly, cleaning or moving it.
• Before replacing the accessories or accessible parts that
move during use, turn the appliance off and disconnect it
from the power supply.
Electrical safety
• Before connecting this appliance to an electrical power socket, make sure that the voltage stated on its rating label corresponds to the voltage in
your power socket.
• Connect the appliance only to aproperly grounded socket. Do not use an extension cord.
• Fully unwind the power cord before using it.
• Do not connect and disconnect the power cord and adapter to and from the power socket with wet hands.
• Ensure that the adapter plug contacts do not come into contact with water or any other liquid. If precisely this happens, carefully dry the power plug
before using it again.
• Do not disconnect the appliance from the power socket by pulling on the power cord. This could damage the power cord or the power socket.
Disconnect the power cord from the power socket by pulling on the plug.
• Do not place heavy items on the power cord. Make sure the power cord does not hang over the edge of atable or that it is not touching ahot
surface or sharp objects.
• Keep the power cord and adapter dry.
• If the power cord or the adapter is damaged, it must be replaced by the manufacturer, its service technician or by asimilarly qualified person, as
this will prevent adangerous situation from arising. It is forbidden to use adamaged power cord or adapter.
• Do not wind the power cord around the appliance.
• Always turn off the appliance and disconnect it from the power socket when not using it, when leaving it without supervision and before removing
or replacing accessories, and before cleaning, maintenance or storage.
• The appliance is equipped with abuilt-in long-life battery that can only be removed at aprofessional service centre. Never attempt to remove it
from the appliance yourself.
Attention:
Never disassemble the appliance for the purpose of removing the battery. Never short circuit the appliance or throw it into afire.
Incorrect use, risks releasing toxic substances or causing afire or explosion.
• Do not repair the appliance yourself or make any adjustments to it. Have all repairs or adjustments of the appliance performed at an authorised
service centre. Tampering with the appliance during the warranty period may void the warranty.
• To prevent the risk of injury by electrical shock, never submerge the motor unit and its power cord in water or any other liquid, or wash these parts
under running water.
• Always turn off the appliance and disconnect it from the power socket when you have finished charging it.
• If the appliance falls into water, under no circumstances continue using it, but rather hand it over to an authorised service centre for inspection.
• This appliance is designed for household use. Do not use it for commercial purposes or for other purposes for which it is not intended.
Safety during use
• This appliance is designed for household use and is intended for whisking/beating ingredients. It is suitable for whipping whipped cream, creams,
mashed potatoes, spreads, egg whites and yolks etc.
• Do not use the appliance in an industrial environment or outdoors. Do not use it for any other purposes than those intended.
• The appliance is intended for domestic use and similar locations such as:
- kitchens in stores; offices and other workplaces;
- in agriculture;
- for guests of hotels, motels and other similar locations;
- in bed and breakfast establishments.
• This appliance is not intended to be operated using an external timer switch or aremote control system.
• Use the appliance and its accessories in accordance with the instructions contained in this user'smanual.
• Only use the appliance with the original accessories that came with it.
• Before every use, check the selected accessory for damage. Never use the appliance with adamaged accessory.
• Do not place the appliance or its accessories on an electric or gas stove or in its vicinity, on the edge of atable or on an unstable surface. Only place
the appliance on an even, dry and stable surface.
• Do not expose the appliance and its accessories to the outdoor environment, extreme temperatures, direct sunlight, excessive humidity or
excessively dusty environments.
• Do not place the appliance and its accessories near heaters, open fires or other sources of heat.
• Make sure that the appliance is correctly assembled before putting it into operation.
• Do not touch moving rotating parts during operation. Otherwise, this could result in injury.
- 3 -
06/2023
2023,
• Be especially careful when handling hot liquids and foodstuffs. Hot steam or splattering hot foods and liquids may cause scalding. For reasons of
increased safety, allow hot foods and liquids to cool down to at least 45 °C before whisking them.
• The operating time of the appliance is 3 minutes. Before turning it on again, allow it to cool down for at least 10 minutes. When using the appliance
to beat sticky or harder foodstuffs, interrupt operation already after 1 minutes.
• Do not turn on the appliance when it is empty. Incorrect use of the appliance may negatively affect its lifetime.
• Check that the motor unit is turned off and that the rotating parts have come to acomplete stop before disassembling the appliance into its
individual parts.
• Do not perform any maintenance on the appliance other than cleaning the individual components as described in this user'smanual.
• Never use an appliance that is damaged in any way.
• Do not use the appliance if it has fallen on the floor, if it was submerged in water, if it is not functioning correctly or if it is damaged in any other way.
• Do not use the appliance when it is not functioning properly or showing signs of damage.
• In order to prevent ahazardous situation arising, do not repair the appliance yourself or modify it in any way. Have all repairs performed at an
authorised service centre. By tampering with the appliance, you risk voiding your legal rights arising from unsatisfactory performance or quality
warranty.
• Store the appliance in adry environment.
- 4 -
06/2023
2023,
• Thank you for purchasing aSENCOR brand product and we hope that
you will be happy with it.
• Prior to using this appliance, please read the user'smanual
thoroughly, even in cases, when one has already familiarised
themselves with previous use of similar types of appliances. Only use
the appliance in the manner described in this user’smanual. Keep this
user'smanual in asafe place where it can be easily retrieved for future
use. In the event that you hand this appliance over to somebody else,
make sure to also include this user'smanual.
• Carefully unpack the appliance and take care not to throw away any
part of the packaging before you find all its parts. We recommend
saving the original cardboard box, packaging material, purchase
receipt and responsibility statement of the vendor or warranty card for
at least the duration of the legal liability for unsatisfactory performance
or quality. In the event of transportation, we recommend that you pack
the appliance in the original box from the manufacturer.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE APPLIANCE
A1 Holes for attaching removable
attachments
A2 Battery power level indicators
A3 USB slot
A4 Attachment release button
A5 Speed and On/Off switch
0 – Off
1 – low speed
2 – medium speed
3 – high speed
A6 Handle
A7 Stainless steel whisk
It is suitable for whipping
whipped cream, creams,
mashed potatoes, spreads,
egg whites and yolks etc.
A8 Base stand
A9 Set of chrome-plated beater
attachments
These are suitable for beating
milk cream, creams, mashed
potatoes, spreads, etc.
A10 USB power cable
A11 Power cable adapter
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B1 High battery capacity
indicator
B2 Medium battery capacity
indicator
B3 Low battery capacity indicator
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PURPOSE OF USE
• The hand mixer is intended for beating/whisking astandard amount of
ingredients in the household.
• There are two beater attachments and a single whisk attachment
for processing food. Both the beaters and the whisk are easily
exchangeable and washable with water.
• The beater attachments are suitable for processing soft ingredients
and liquids. They are used for effective blending of ingredients for
smoothies, various types of cocktails, soups, sauces, spread, baby
food, etc.
• After a complete charge, the battery enables 8-10 work cycles. The
lifetime of the battery is up to 300 cycles.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEFORE FIRST USE
• Before first use, thoroughly wash the beaters and the whisk using
warm water and neutral kitchen detergent. Then rinse everything with
clean water and allow to dry naturally or wipe dry thoroughly using
awiping cloth. The whisk can also be washed in a dishwasher.
• Wipe the external part of the appliance itself using adry or alightly
dampened wiping cloth. Ensure that no moisture or water enters
into the appliance, especially into the speed control buttons. Never
submerge the appliance in water, do not clean it under running water
or wash it in adishwasher.
• Wash the base stand with warm water, then rinse with clean water
and allow it to dry naturally or dry it out using afine wiping cloth. The
base stand is not intended to be washed in adishwasher.
• Only clean the power cord and adapter using adry wiping cloth, never
wash with water.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CHARGING THE BATTERY
• To ensure the best possible performance, we recommend to fully
charge the appliance before first use. Acomplete charge takes up to
5 hours.
• Insert the smaller end of the power cord into the USB socket in the
appliance and the larger end into the supplied power adapter. Then
insert the power adapter into apower socket.
• During the charging process, indicators on the appliance may flash or
be lit depending on the charge status. The meaning of the light signals
is the following:
Indicator (fig. B) Battery capacity
All indicators are flashing Low
Indicator B3 is lit, and indicators B2 and B1 are
flashing
Medium
All indicators are lit
The battery is fully
charged
• After a complete charge, the battery enables 8-10 work cycles.
The lifetime of the battery is up to 300 cycles. The actual number
of cycles, however, will differ depending on the load placed on the
appliance, the selected speed and the ingredients that are processed.
For example, with frequent use of high speed, the battery will
discharge faster.
RECOMMENDATIONS FOR EXTENDING THE LIFETIME OF THE
BATTERY
In order for the battery to serve you as long as possible, charge, use and
store the appliance in adry environment at an ambient temperature of
15-35 °C. Lower or higher temperatures have anegative impact on the
lifespan of the battery.
When the appliance is not used for an extended period of time, charge it
at least once every 6 months.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ASSEMBLY
Attention:
Before attaching/removing the beater/whisk
attachment/s, the appliance must be turned off and
disconnected from the power cord.
• Select the attachment type suitable for the intended task and insert
it/them into the holes in the appliance according to the following
instructions:
– Beater attachments: Their mounting parts are identical and it is
thus possible to attach them to any of the holes in the appliance.
– Whisk: Can be mounted in either of the two holes in the appliance.
• Push the selected attachments in until they safely click into position.
Attention:
Always only mount two attachments of the same
function into the appliance – always either two
beater attachments or the single whisk. Never insert
two different types of attachments, otherwise the
appliance will be damaged.
EN
Cordless hand mixer
User'smanual
- 5 -
06/2023
2023,
OPERATION
Attention:
Always keep fingers, hair, clothing, etc. at asafe
distance from the moving attachments.
Do not blend hot ingredients. Splattering hot liquids
and ingredients may cause serious scalding. For
reasons of increased safety, allow hot ingredients to
cool down before blending them.
Note:
You may detect aslight odour when the appliance is used
for the first time. That is normal and this odour will go away
with further use.
• Place the food and liquids that you wish to process into asufficiently
large container.
• Submerge the attachments into the container and then start the
appliance by setting switch A5 to the required speed level in the range
from 1 to 3.
• We recommend to start at alower speed and to increase it gradually.
You can change the speed setting even while the hand mixer
is running. We recommend that runny doughs and sauces are
processed at lower speed levels; this will prevent ingredients from
splashing out of the bowl.
Attention:
The maximum continuous operating time of the
appliance is 3 minutes. Then allow it to cool down for
approximately 10 minutes. When using the appliance
to beat sticky or harder foodstuffs, interrupt operation
already after 1 minutes.
Items such as spoons, kitchen knives, forks, etc. must
not be placed into the bowl with the ingredients while
blending/whisking as this could result in injury or
damage to the appliance.
AUTOMATIC ANTI-OVERLOADING FUNCTION
• The appliance has an automatic anti-overloading function. In the event
that the motor unit is overloaded, e.g. due to the ingredients being too
tough or hard, all the indicators will simultaneously flash five times
and then the appliance will turn itself off. If this happens, allow the
appliance to rest for at least 10 minutes and adjust the amount and/or
size of the ingredients. Only then continue using the appliance.
BATTERY CAPACITY INDICATOR
• The battery will start discharging when the appliance is used. Its
capacity is shown using indicators B1 to B3 as follows:
INDICATOR BATTERY CAPACITY
All indicators are lit High
Indicators B2 andB3 are lit
Medium
Indicator B3 is lit
Low
Indicator B3 is flashing
The battery is almost flat
TURNING OFF AND REMOVING THE ATTACHMENTS
• After you have finished, set switch A5 to position 0 (off). Make
sure that the rotating parts have stopped rotating and remove the
attachments from the container.
• Press button A4 to release the attachments. The attachments can
only be released when the switch is in position 0. When the switch
is in positions 1–3, the attachments are locked in position against
removal.
• Remove and clean the used attachments according to the instructions
in chapter Cleaning and maintenance
CLEANING AND MAINTENANCE
Warning:
Before cleaning, the appliance must always be turned
off and disconnected from the power cord.
Do not use solvents, abrasive cleaning products, etc.
for cleaning the appliance. Otherwise the surface coat
of the appliance may be damaged.
• Remove the used attachments and thoroughly wash them in warm
water with the use of neutral kitchen detergent. Then rinse all these
parts with clean water and dry them thoroughly with afine wiping
cloth. The whisk can also be washed in a dishwasher.
Attention:
When washing the attachments, do not leave them
submerged in water for longer than 4 hours (for the
purpose of soaking them), otherwise their surface will
be damaged.
• Wipe the body of the appliance with adry or slightly dampened
cloth. Make sure that water does not enter into speed control buttons.
Never wash the body of the appliance under running water or in
adishwasher.
• Only clean the power cord and adapter using adry wiping cloth, never
wash with water liquids or other liquids.
• Never dry parts of the appliance over heat sources such as wood
stoves, electric or gas stoves, etc.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
STORAGE
• When you have finished using the appliance and have cleaned it,
place it and its accessories in aclean, dry place out of children'sreach.
Keep the stored appliance and its accessories away from extreme
temperatures, direct sunlight and excessive humidity and do not store
it in an overly dusty environment.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TECHNICAL SPECIFICATIONS
Power Adapter:
Input ................................................................ 100-240V ~ 50/60Hz, 0.5A Max
Output ...................................................................................... 5.0V
2.0A, 10W
Unit:
Battery ................................................................................... 7,4V Li-Ion, 2000mAh
Rated Input ........................................................................................ 5.0V
, 2.0A
Work Power ........................................................................................................... 50W
Electrical shock protection class .............................................................................. II
Noise level ...................................................................................................... 85 dB(A)
The declared noise emission level of the appliance is 85 dB(A), which
represents alevel Aof acoustic power with respect to areference acoustic
power of 1 - pW.
Explanation of technical terminology
Safety class for electrical shock protection:
Class II – Electrical shock protection is provided by
double or heavy-duty insulation.
Changes to text and technical parameters are reserved.
- 6 -
06/2023
2023,
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF
USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your
municipality.
DISPOSAL OF USED BATTERIES
Prior to handing over the appliance at aspecialised collection facility, it is
necessary to ensure that the built-in battery is removed. Battery removal
will be performed at the authorised service centre. In the event that the
product has been disassembled for the purpose of ecological disposal
then it must not be reassembled.
This symbol indicates that the used battery does not
belong in ordinary municipal waste. Hand over the used
battery to designated collection points for proper disposal.
Correct disposal of the battery will help prevent negative
impacts on the environment and human health.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to
dispose of this product, request the necessary information
about the correct disposal method from the local council or
from your retailer.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF
USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your
municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that
used electric or electronic products must not be added to
ordinary municipal waste. For proper disposal, renewal and
recycling, hand these appliances over to determined
collection points. Alternatively, in some European Union
states or other European countries you may return your
appliances to the local retailer when buying an equivalent
new appliance. Correct disposal of this product helps save
valuable natural resources and prevents potential negative effects on the
environment and human health, which could result from improper waste
disposal. Ask your local authorities or collection facility for more details. In
accordance with national regulations penalties may be imposed for the
incorrect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electrical or electronic equipment, ask your
retailer or supplier for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this
product, request the necessary information about the correct disposal
method from the local council or from your retailer.
This product meets all the basic requirements of EU
directives related to it.
FAST ČR, a.s.
U Sanitasu 1621
CZ-251 01 Říčany
www.sencor.eu
